Solar-Powered Pan/Tilt
Security Camera Kit
Datasheet
Tapo C660 KIT
Starlight Color
Night Vision
Forever-Powered, Enhanced with 4K
Free Person/Pet/
Vehicle Detection
360° AI
Tracking
Datasheet
Highlights
360° AI Tracking
The camera provides 360° horizontal coverage and 90° vertical coverage. Accurately identies and tracks people, pets, and vehicles,
ensuring it focuses on what truly matters.
Datasheet
Free Person/Pet/Vehicle Detection
Identies people, pets, and vehicles while only sending you
alerts when truly needed.
Privacy Lock
Secure your microSD card with a password through the
Tapo app for enhanced privacy protection.
Premium Features. Total Control. All in One App.
Secure and control your home anywhere, anytime with the Tapo app. View live footage, speak to visitors, share clips, and easily tailor
advanced settings.
Highlights
Features
Datasheet
Flexible Dual Band Connection
Experience seamless, lag-free 4K streaming with
lightning-fast 5GHz or enhanced stability on 2.4GHz.
Customizable Sound and Light Alarm
Record your voice and set the spotlight brightness to
create an alarm that ts your needs.
High-Eciency Solar Charging
Just 45 minutes of direct sunlight daily* powers Tapo
C660 for full-day use.
Local and Cloud Storage
Store footage on a microSD card (up to 512 GB)
†
with no
subscription required, or opt for cloud storage
‡
with a 30-day
free trial for added convenience.
Starlight Color Night Vision
Enhances your security by revealing brighter, full-color
images and vivid details even in low-light conditions with
built-in spotlights and the starlight sensor.
Two-Way Audio
Talk and listen through the device with its integrated microphone
and speaker.
4K Crystal-Clear Surveillance
Capture every detail with precision. Tapo C660 KIT
features 4K resolution and 18× digital zoom for superior
clarity.
Smart Playback
Swiftly nd and download moments of interest by
choosing the event type or sliding the timeline.
Patrol Mode
Assign points for the camera to patrol for dynamic
monitoring.
Specications
Camera
Image Sensor 1/2.7“ Progressive Scan CMOS Starlight Sensor
Lens
Focal Length: 4 mm ± 5%
Aperture: F1.6 ± 5%
Field of View: 105° (Diagonal), 88° (Horizontal), 45° (Vertical)
Night Vision
850 nm IR LED (40 ft / 12 m)
Starlight Color Night Vision
Day/Night Switch IR-Cut Filter with Auto-Switching
Lighting
2× Built-in Spotlights
Motion Activiated, App-Controlled
Interface & Button
1× POWER Button
1× RESET Button
1× microSD Card Slot (Up to 512 GB)
Solar Panel
Connection Capacity A solar panel can only connect to one camera.
Output Port Type-C
Video & Audio
Maximum Resolution 4K 8MP (3840 × 2160 px)
Frame Rate 15/20 fps
Digital Zoom 18×
Video Compression H.264
Live View Ye s
Datasheet
Video & Audio
Image Enhancement
3DNR
WDR
Audio Input & Output Built-in Microphone and Speaker
Audio Communication Two-Way Audio with Noise Cancellation
Siren Volume
93.3 dBA (Level measured at 10 cm distance)
72.3 dBA (Level measured at 300 cm distance)
Storage
Local Storage microSD Card Slot on Camera (Up to 512 GB, Purchase Separately)
Cloud Storage Tapo Care Cloud Storage Services (Subscription required)
Detection &
Notication
AI Detection
Motion Detection
Person Detection
Vehicle Detection
Pet Detection
Activity Zones Ye s
Output Notication
System Notication
System Notication with Snapshot (Tapo Care Services)
Network
Network Connectivity Connect via Wi-Fi
Wireless Connectivity
IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
IEEE 802.11a/n, 5 GHz Wi-Fi
Transmission Rate
11b: 11 Mbps
11a/g: 54 Mbps
11n: 72.2 Mbps
Protocol TCP, UDPTCP/IP, ICMP, DNS, HTTPS, TCP, UDP
Datasheet
Security Security
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK
Power
Power Source Solar Panel, Built-in Rechargeable Lithium-ion Battery
Solar Panel Max Charging
Voltage
5.2 V
Solar Panel Max Charging
Power
2.5 W
Camera Adapter Input 100-240 V, 50/60 Hz (Not Included)
Camera Adapter Output 5.0 V, 2.0 A (Not Included)
Power Cord Length
USB Adapter Cable Length: 0.5 m (19.68 in.)
Solar Panel Charging Cable Length: 0.25 m (9.84 in.)
Solar Panel Extension Charging Cable Length: 3.8 m (149.61 in.)
Camera Typical Power
Consumption
1.2 W
Camera Maximum Power
Consumption
4.2 W
General
Smart Integration Google Assistant, Amazon Alexa, Samsung SmartThings
Weather Resistance IP65
Mounting Options
Wall-Mounted
Ceiling-Mounted
Operating Temperature -20 ºC ~ 45 ºC (-4 °F ~ 113 °F)
Datasheet
General
Storage Temperature -40 ºC ~ 60 ºC (-40 °F ~ 140 °F)
Operating Humidity 10% ~ 90% RH, Non-condensing
Storage Humidity 0 ~ 90% RH, Non-condensing
Mounting Screw Size
Unit: mm
Dimensions
Camera Dimensions: 185 x 147 x 75 mm (7.28 x 5.79 x 2.95 in.)
Solar Panel Dimensions: 173.4 x 120.4 x 15.7 mm (6.83 x 4.74 x 0.618 in.)
Weight
Camera: 21.41 oz / 607 g
Solar Panel: 5.08 oz / 144 g
Package Contents
Tapo C660 Camera × 1
Mounting Bracket × 1
Camera Mount Adapter × 1
USB Adapter Cable × 1
Tapo A201 Solar Panel × 1
Tapo A201 Solar Panel Bracket × 1
Base Cover × 1
Extension Wire × 1
Cable Zip Tie × 1
Mounting Screws × 7
Mounting Anchors × 7
Mounting Templates × 2
Quick Start Guide
Datasheet
Appearance
Datasheet
△
Actual charging power may vary based on installation location, weather conditions, temperature, and other environmental factors.
§
The suitable temperature for the Solar Panel is -20
℃
~45
℃
. The working temperature range for battery charging should be maintained at 0°C~45°C.
†
microSD card purchased separately. Actual storage capacity depends on the size of the microSD card used.
‡
Subscribe for cloud storage at https://www.tapo.com/tapocare/
*
45 min of sunlight is based on standard environmental conditions (1000W/m2, 25
℃
, AM1.5) and specied working scenes (up to 100 events triggered per day). Actual required time of
sunlight may vary.
Specications are subject to change without notice. All brands and product names are trademarks or registered trademarks of their respective holders.
©2025 TP-Link
9
10
11
12
12 23 3
4
5
7
8
6
10
Reset Button
Press and hold for 5s:
Reset Wi-Fi while preserving the other.
Press and hold for 10s:
Reset to factory settings.
11
USB Type-C Charging Port
Open the cover for USB charging.
9
On/O Power Button
Press and hold for about 3s:
Turn on/o the camera.
12
PRESS Button
Press the button to
loosen the camera
bracket.
Camera Bracket
8
microSD Card Slot
Open the cover. Insert a
microSD card* and initialize it on
the Tapo app for local recording.
*microSD card not included.
White Light LEDs
Microphone
IR LEDs
6
Status LED
5
Light Sensor
4
Lens
3
1
2
7
Motion Sensor
microSD
