Solar-Powered
Floodlight Pan/Tilt
Security Camera Kit
Datasheet
Tapo C615F KIT
Color Night
Vision
Wire-Free Easy Installation with Smart Lighting
Free Person/Pet/
Vehicle Detection
800-Lumen
Dimmable Floodlight
360° AI
Tracking
Solar Charging,
Maintenance-Free
Datasheet
Highlights
Go Where Wires Can’t with Smart Lighting
Enhance your security with customizable 800-lumen oodlight while not being limited to power outlet placement. Monitor your
property day and night.
Datasheet
All-in-One Floodlight and Camera
The compact camera kit features an 800-lumen oodlight that illuminates your property, keeping your space bright and your
neighbors undisturbed.
Highlights
Dimmable Floodlight Control
Set the brightness according to your needs.
Activate with Motion
Activate the oodlight with motion or just control it manually.
Install with Adjustable Angle
Adjust the angle of the oodlight to light up your monitoring area.
*The app screen shown is for reference only and
may dier from the actual nal experience.
Features
Datasheet
Local and Cloud Storage
Store footage on a microSD card (up to 512 GB)
†
with no
subscription required, or opt for cloud storage
‡
with a
30-day free trial for added convenience.
360° AI Tracking
The camera provides 360° coverage and tracks people,
pets, and vehicles automatically.
Two-Way Audio
Talk and listen through the device with its integrated microphone
and speaker.
Free Person/Pet/Vehicle Detection
The camera identies people, pets and vehicles while
only sending your alerts when truly needed.
Smart Playback
Swiftly nd and download moments of interest by
choosing the event type or sliding the timeline.
Privacy Lock
Secure your microSD card with a password through the
Tapo app for enhanced privacy protection.
High-Eciency Solar Charging
Just 45 minutes of direct sunlight* powers Tapo C615F
for full-day use.
Patrol Mode
Assign points for the camera to patrol for dynamic
monitoring.
Customizable Sound and Light Alarm
Record custom audio for alarms and adjust the brightness
of the oodlight to suit your needs.
†
microSD card purchased separately. Actual storage capacity depends on the size of the microSD card
used.
‡
Subscribe for cloud storage at https://www.tapo.com/tapocare/
*
45 min of sunlight is based on standard environmental conditions (1000W/m², 25ºC, AM1.5) and specied
working scenes (up to 100 events triggered per day). Actual required time of sunlight may vary.
**Actual charging power may vary based on installation location, weather conditions, temperature, and
other environmental factors.
Specications are subject to change without notice. All brands and product names are trademarks or
registered trademarks of their respective holders. ©2025 TP-Link
Specications
Camera
Image Sensor 1/2.8“ Progressive Scan CMOS Sensor
Lens
Focal Length: 4 mm ± 5%
Aperture: F1.6 ± 5%
Field of View: 100.6° (Diagonal), 84.4° (Horizontal), 44.3° (Vertical)
Pan-Tilt Range
Pan Mechanical Range: 338° (360° Pan Coverage)
Tilt Mechanical Range: 97° (141° Tilt Coverage)
Night Vision
2× 850 nm IR LEDs (32.8 ft / 10 m)
Color Night Vision
Day/Night Switch IR-Cut Filter with Auto-Switching
Lighting
2× Built-in Spotlights
1× Floodlight (Brightness: 800 Lumens)
Motion Activated, App-Controlled
Interface & Button
1× POWER Button
1× RESET Button
1× microSD Card Slot (Up to 512 GB)
Solar Panel
Connection Capacity A solar panel can only connect to one camera.
Output Port Type-C
Video & Audio
Maximum Resolution 2K 3MP (2304 × 1296 px)
Frame Rate 15/20 fps
Digital Zoom 10.8×
Datasheet
Video & Audio
Video Compression H.264
Live View Ye s
Image Enhancement 3DNR
Audio Input & Output Built-in Microphone and Speaker
Audio Communication Two-Way Audio with Noise Cancellation
Siren Volume
91.5 dBA (Level measured at 10 cm distance)
75 dBA (Level measured at 3 m distance)
Storage
Local Storage microSD Card Slot on Camera (Up to 512 GB, Purchase Separately)
Cloud Storage Tapo Care Cloud Storage Services (Subscription required)
Detection &
Notication
AI Detection
Motion Detection
Person Detection
Vehicle Detection
Pet Detection
Activity Zones Ye s
Output Notication
System Notication
System Notication with Snapshot (Tapo Care Services)
System Notication with Clip (Tapo Care Services)
Network
Network Connectivity Connect via Wi-Fi
Wireless Connectivity IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
Datasheet
Network
Transmission Rate
11b: 11 Mbps
11g: 54 Mbps
11n: 72.2 Mbps
Protocol TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
Security Security
PWPA/WPA2-PSK
WPA3-PSK
Power
Power Source
Built-in Rechargeable Lithium-ion Battery
Solar Panel: Tapo A201(included)
Solar Panel Max Charging
Voltage
5.2 V
Solar Panel Max Charging
Power
2.5 W**
Input Voltage 5 V, DC
Power Cord Length
USB Charging Cable Length: 0.5 m (19.68 in.)
Solar Panel Extension Charging Cable Length: 3.8 m (149.61 in.)
Camera Typical Power
Consumption
1.04 W
Camera Maximum Power
Consumption
11.28 W
General
Smart Integration Google Assistant, Amazon Alexa
Weather Resistance IP65
Datasheet
General
Mounting Options
Wall-Mounted/Eave-Mounted/
Pole-Mounted (Pole-Mounting loops required but not included)
Operating Temperature -20 ºC ~ 45 ºC (-4 °F ~ 113 °F)
Charging Temperature 0 ºC ~ 45 ºC (32 °F ~ 113 °F)
Storage Temperature -40 ºC ~ 60 ºC (-40 °F ~ 140 °F)
Operating Humidity 10% ~ 90% RH, Non-condensing
Storage Humidity 0 %~ 90% RH, Non-condensing
Mounting Screw Size
Unit: mm
Dimensions
Camera Dimensions: 132.86×82×161.1 mm (5.23 x 3.22 x 6.34 in.)
Solar Panel Dimensions: 173.42×120.42×15.7 mm (6.82 x 4.74 x 0.61 in.)
Weight
Camera: 24.06 oz / 682 g
Solar Panel: 5.08 oz / 144 g
Package Contents
Tapo C615F Camera × 1
Tapo A201 Solar Panel × 1
Tapo A201 Solar Panel Bracket × 1
Base Cover × 1
USB Charging Cable × 1
Solar Extension Cable × 1
Mounting Template Stickers × 2
Mounting Screws and Anchors
Quick Start Guide
