SW159
Micro SD
TROLLEY SPEAKER
Operating
Instructions
Technical Specifications
Content
Power: 80W
Impedance: 4 Ω
Input Sensitivity: 92±3 dB
Frequency Response: 50-18K Hz
S/N Ratio: ≥70dB
Drive Unit: 1″+12″
Wireless Mic Frequency: 212.0MHZ
Bluetooth Name: SW159
Power Adapter:DC9V/1.5A
1
6
BT Operation
2.Search the BT device list and select the BT name "SW159".The speaker will make a
notification tone when the connection is successful.
Open the mobile phone music player and play a song. The music is transferred via BT and
sound comes out through the BT speaker.
3.Select the BT which is on BT device list.
First connection of BT with cellophane
Instructions
Connect to the mobile phone which already been connected before.
When the mobile phone BT is turned on, press the“MODE”and select to BT mode, the BT
speaker will automatically connect to the mobile phone which is connected last time.
Another way is that you can search the BT list on your mobile phone, when you find
the“SW159”, select it and connect your mobile phone to the BT speaker.
1.Turn the power on, press the "MODE" key or “INPUT" key on the panel or remote control,
and switch the speaker to Bluetooth channel. Then turn on the mobile phone BT function.
The battery charges for 8hours before the first use of this product.
It must be replaced with batteries of the same specifications when needed,otherwise,
the product may not work properly or be damaged.
To extend battery life, it needs to be charged regardless of the lack of power after
each use.
The charging time depends on the battery specifications. The charging scheme
(or the power supply voltage is unstable) is generally 8-16hours.
Please keep away from the product more than 2meters from CRT display or television,
because of the speaker magnet field is strong, magnetic interference causes display
magnetization or discoloration phenomenon.
Operation wireless microphone
Safety Precautions
Instruction & BT Operation
Safety Precautions
DC9V 1.5A
2
TWS function Operation
TRUE WIRELESS STEREO (TWS) TECHNOLOGY
TWS technology enables user to make wireless connection between two speakers which are
same model and compatible with TWS. In TWS connection, two speakers will be automatically
grouped to be a Stereo-speaker System which outputs the left and right channel.
Two speakers which were connected by TWS will be automatically reconnected when they are power
on and both in BT mode. Long press TWS button to disconnect two speakers by TWS.
DISCONNECT TWS
HOW TO ESTABLISH
“ ”1.Please switch on both speakers and select BT Mode.
2.Press the TWS button on the control panel of one of the speakers until you hear a Prompt sound.It
becomes the main speaker (left channel), automatically searches for and connects with the other
speaker (right channel). After connection, you will hear a Prompt sound
TWS MODE MANIPULATIONS In TWS mode, manipulations to the main speaker will be
simultaneously effected in the other speaker, for example, volume up and down, previous
and next song selection, play and pause, power on and off.
TWS CONNECTION? Reminding: Two speakers must be same model and both compatible with
TWS.
3.Connect your mobile phone or BT player to the speaker by BT. After connection,
you can play music with the TWS Stereo-speaker System.
Please turn off the microphone after using
Operation wireless microphone
If you buy more than two sets of active speaker with wireless microphones and want to use
together at the same time, please select standard frequency of different varieties. If not,
there must be 10 meters distance at lease between two sets speaker in same frequency.
So as not to cause interference and other unnecessary trouble. At the same time, don't put
speakers too close to VCD/CD/DVD during using. They are strong interference frequency
equipments. In order to avoid mutual interference between the same frequency and
directly affects the normal work of the wireless microphone signal receiving.
Please don't use the same frequency of microphone to sing at the same time in a short
distance.It will lead to silence or interference.
To achieve the best effect of singing, the distance of mouth and microphone should be keep
in 5-15 cm, and the best angle is 45 degrees.
Wireless microphone effective distance within meters. In order to not affecting the effect, 10
please do not use over than the valid range. When the battery decreased or the environment
radio interference source signal is too strong, it will shorten the using distance.
To adjust the microphone volume knob to you like when you are demo.
This product built-in battery, especially suitable for outdoor concert, advertising,
entertainment and other activities. Please charge the battery full first before using in outdoor
environment. To ensurethat the speaker can be used for a long time for outdoor activities.
5
Top Panels operating instructions
1
1.USB jack
2. Micro SD jack
3. AUX input
4. Microphone input1
5. Microphone input2
6. Charging indicator light
7. DC 9V/1.5V Adapter input
8. Function Menu
Music volume adjustment
Music treble adjustment
Music bass adjustment
Microphone volume adjustment
Microphone reverb adjustment
Press once to switch between
adjustment modes
9. Long press for recording,
short press for replay recording
10.Microphone priority
11. Previous key & FM channel - key
12. Long press for True wireless stereo key
short press for Play/Pause key & FM scan key
13. Next key & FM channel + key
14. Adjust according to 8
Master Volume Control
15. Short press mode Key
BT cut off press for 3seconds
16. Power ON/OFF switch
17. Short press for LED light switch,
long press for LED light ON/OFF
2
3
4 75
6
8
9
10
11
12
13
15 16 17
14
4
Operating instructions for Remote controllers
1.Standby Key
2.Mode Key- to Select
Input Signal Source
3.LED Switch
4.Volume +/- Key
5.Repeat Key
6.Track selection key
7.Mute Key
8.Previous /FM ch-Key
9.Next /FM ch+ Key
10.Play/ Pause & FM scan key
11.EQ Mode Key
3
FCC Caution:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the
radiator your body: Use only the supplied antenna.
