Children do not close to the machine
operator before using this machine
Please read the instructions carefully and use
them in accordance with the instructions.
YF-90T
Desktop cutting machine
User manual
！
The machine advantages
Feature of this machine is to count the arbor translated into cantilever one end of the
movable parts and special cantilever taxis motor is installed in a closed chassis.while
the other end of the arbor (ie the other end of the installation arbor)Then in the case
of such a structure outside a meat chopper, both in terms of cleaning and replacement
knife set better than similar products.
Security
Motor control loop in series magnetic switches and placed inside the chassis control
magnet is mounted on the shield.When opened the cover magnetic switch in the off
state the motor does not rotate security The personal safety(WARNING Never remove
the safety guard operation)
Instructions
Press the nameplate voltage connected to the power supply with leakage protection,
ground connection must be good.
Arbor close the switch, press the start button, observe the correct knife steering
group,will eliminate meat from bone material at the temperature of the body slowly
down.The first cut sheet heavy cut into filamentous.then cut Into a granular, and
through changing different knife sets slice.ShredDiced.Loose meat. Meat tenderizer
and other effects.
Replacing the knife Group;First cut off the power oen the coverandremove the nut
compression spring his hands grip the knife handle pull the group(Asshown)
Use and maintenance
1.the motor must be grounded.
2. the use of meat slicers first remove the top steel comb
start the motor turn inward to see if the blade
3.the meat must be cut to remove the bone to prevent blade
damage.
4. after use,wash with hot water clean the right amount of
oil antirust empty after startup-drying water.
Gloss brand series of cutting machine
Can be cut
：
cattle,pigs,sheep,chickens,jellyfish and other meat
Knife unit
specificatio
n
Slice
thickness(
mm)
Yirld
(kg/h)
Dimension
s(cm)
Weig
ht(kg)
Motor
power(
w)
Voltag
e(V)
YF-90T
About 2.5 More
than250
26*48*46.
5
33 600 220
About 3 More
than250
26*48*46.
5
33 600 220
About 5 More
than250
26*48*46.
5
33 600 220
Cleaning Maintenance
Method 1:Flush with water from the entrance to the blade guard,or remove the knife
group soaked in water for cleaning
Method 2:Remove the blade set(do not wash),directly store in the freezer degrees
below both
health And convenience.Worm tankgear bearings should be regularly
lubricatedoil,blunt blade should be available.Whetstone grinding
General Troubleshooting
Whether the motor can not rotate the cover is installed the control magnet is offo
whether TheNianman iron magnet. Motor rotary cutter group does not turn the torque
rings installed.
