Liebherr ENERGY HERO data-next-head> Fridge-freezer User Manual

User Guide

Quality, Design and Innovation

home.liebherr.com/fridge-manuals

Contents

1 Appliance at a glance............................................ 3

1.1 Scope of delivery.......................................................... 3

1.2 Overview of the appliance and equipment.............. 3

1.3 SmartDevice.................................................................. 4

1.4 Appliance range of use............................................... 4

1.5 Conformity..................................................................... 4

1.6 SVHC substances according to REACH regulation. 4

1.7 EPREL database........................................................... 4

1.8 Spare parts.................................................................... 5

2 General safety instructions.................................. 5

3 Functionality of the Touch&Swipe display......... 6

3.1 Navigation and symbol explanation......................... 6

3.2 Menus............................................................................. 6

3.3 Sleep mode................................................................... 7

4 Putting into operation........................................... 7

4.1 Switching on appliance (first use)............................ 7

4.2 Putting InfinitySpring into operation*...................... 8

4.3 Starting the IceMaker for the first time*................. 8

4.4 Starting the EasyTwist-Ice for the first time*......... 8

4.5 Starting the HydroBreeze for the first time*........... 8

5 Storage.................................................................. 8

5.1 Information regarding storage................................... 8

5.2 Fridge compartment.................................................... 8

5.3 BioFresh......................................................................... 8

5.4 Freezer compartment.................................................. 9

5.5 Storage times............................................................... 10

6 Saving energy........................................................ 10

7 Controls................................................................. 11

7.1 Controls and displays.................................................. 11

7.1.1 Status display............................................................ 11

7.1.2 Display symbols.........................................................11

7.2 Appliance functions..................................................... 11

7.2.1 Notes on the appliance functions.......................... 11

Switching the appliance off and on...................... 11

Switching temperature zone off and on.............. 12

WiFi.............................................................................13

Temperature..............................................................13

Temperature unit......................................................14

BioFresh B-Value .....................................................14

D-Value...................................................................... 15

SuperCool*................................................................15

VarioTemp*................................................................ 15

SuperFrost.................................................................16

Start defrosting cycle..............................................17

PartyMode .................................................................17

HolidayMode*........................................................... 18

SabbathMode........................................................... 18

EnergySaver .............................................................19

HydroBreeze*............................................................19

IceMaker / MaxIce *................................................20

IceMaker water supply*.......................................... 21

TubeClean *...............................................................21

CleaningMode...........................................................22

Display brightness...................................................22

Door alarm................................................................ 22

Input lock.................................................................. 23

Language.................................................................. 23

Device information.................................................. 24

Software....................................................................24

Reminder...................................................................24

Demo mode...............................................................24

Resetting to factory settings.................................25

7.3 Messages...................................................................... 26

7.3.1 Overview of warnings.............................................. 26

7.3.2 Ending warnings....................................................... 26

7.3.3 Overview of reminders............................................. 27

7.3.4 Ending reminders......................................................27

8 Features................................................................. 28

8.1 Door rack....................................................................... 28

8.2 Shelves.......................................................................... 30

8.3 Dividing shelf................................................................ 30

8.4 VarioSafe *.................................................................... 31

8.5 InfinitySpring*.............................................................. 33

8.6 Adjustable bottle shelf................................................ 33

8.7 Drawers.......................................................................... 34

8.8 Compartment lid for Fruit & Vegetable Safe........... 35

8.9 HydroBreeze*................................................................ 36

8.10 Glass shelves................................................................ 37

8.11 EasyTwist-Ice*.............................................................. 37

8.12 IceMaker*...................................................................... 38

8.13 VarioSpace*.................................................................. 39

8.14 Butter dish*................................................................... 39

8.15 Egg rack*....................................................................... 39

8.16 Bottle holder*............................................................... 39

8.17 FlexSystem*.................................................................. 39

8.18 Ice cube tray with cover*............................................ 40

8.19 Flexible ice compartment divider*............................ 40

8.20 FlexCube*...................................................................... 41

9 Maintenance.......................................................... 41

9.1 FreshAir carbon filter................................................... 41

9.2 Water tank*................................................................... 42

9.3 Water filter*.................................................................. 42

9.4 Disassembling / assembling pull-out systems...... 43

2 * Depending on model and options

9.5 Removing / inserting the variable bottle rack........ 43

9.6 Compartment lid for Fruit & Vegetable Safe........... 44

9.7 Defrosting the appliance............................................ 44

9.8 Cleaning the appliance............................................... 44

10 Customer help....................................................... 47

10.1 Technical specifications............................................. 47

10.2 Operating noises.......................................................... 48

10.3 Technical fault.............................................................. 48

10.4 Customer Service......................................................... 50

10.5 Model plate................................................................... 50

11 Shutting down....................................................... 50

12 Disposal................................................................. 51

12.1 Preparing appliance for disposal.............................. 51

12.2 Disposing of the appliance in an environmentally

friendly manner............................................................ 51

The manufacturer is continually working on the further

development of all types and models. Please be aware that

we reserve the right to make changes to the shape, equip‐

ment and technology.

Symbol

Explanation

Read instructions

Please read the information in these instruc‐

tions carefully to understand all of the benefits

of your new appliance.

Additional information on the Internet

The digital manual with additional informa‐

tion and in other languages can be found

via the QR code on the front of the

manual or by entering the service number at

home.liebherr.com/fridge-manuals.

The service number can be found on the serial

tag:

Fig.Example illustration

Check appliance

Check all parts for transport damage. If you

have any complaints, please contact your

agent or customer service.

Differences

These instructions apply to a range of models,

so differences are possible. Sections that

apply to certain models only are marked with

an asterisk (*).

Instructions and results

Instructions are marked with a .

Results are marked with a .

Videos

Videos about the appliances are available on

the YouTube channels of Liebherr-Hausgeräte.

Open source licences:

The appliance contains software components that use

open source licences. Information on the open source

licences used can be found here: home.liebherr.com/

open-source-licences

These operating instructions apply to:

CBN ..

57..i / 76..i / 77..i

SBN .. 52..i

Note

If your appliance has an N in its appliance designation, it is

a NoFrost appliance.

1 Appliance at a glance

1.1 Scope of delivery

Check all parts for transport damage. Contact your

dealer or customer service in the event of complaints.

(see 10.4 Customer Service)

Your new appliance comes with the following parts:

Standalone appliance

Features (depending on the model)

Installation materials (depending on the model)

“Quick Start Guide”

“Installation Guide”

Service Brochure

1.2 Overview of the appliance and

equipment

Fig. 1 Example illustration

Temperature range

(A)

Fridge section (C) Freezer section

(B) BioFresh (D) Coldest area

Equipment

(1)

Transport handle (10) Fish & Seafood Safe*

(2) Controls (11) Drain opening

(3) Fan with FreshAir acti‐

vated charcoal filter

(12) Drawer

(4) Divisible shelf (13) IceMaker*

(5) VarioSafe* (14) EasyTwist-Ice*

(6) Variable bottle rack (15) Type plate

(7) HydroBreeze* (16) Door rack

(8) Compartment lid for

Fruit & Vegetable Safe

(17) VarioBox*

(9) Fruit & Vegetable Safe (18) Bottle holder*

(10) Meat & Dairy Safe (19) Adjustable feet (front),

transport rollers (rear),

carrying loops at the top

(rear) and bottom (front)

Appliance at a glance

* Depending on model and options 3

Note

► Shelves, drawers and baskets are arranged for optimum

energy efficiency when the appliance is delivered.

Changing how the shelves, for example, are inserted in

the fridge compartment does not have any impact on

energy consumption.

1.3 SmartDevice

SmartDevice is the networking solution for your fridge-

freezer.

If your appliance SmartDevice-enabled or compatible, you

can quickly and easily connect your appliance to your

WiFi. With the SmartDevice app, you can operate your appli‐

ance from a mobile device. Additional functions and setting

options are available in the SmartDevice SmartDevice app.

SmartDevice-

enabled appliance:

Your appliance is capable of being a

SmartDevice. To be able to connect

your device to WiFi, you need to

download the SmartDevice app.

More information

about SmartDe‐

vice:

smartdevice.liebherr.com

Downloading the

SmartDevice app:

After installing and configuring the

SmartDevice, you can connect your

appliance to the WiFi using the

SmartDevice app and the WiFi appli‐

ance function (seeWiFi) .

Note

The SmartDevice function is not available in the following

countries: Russia, Belarus, Kazakhstan.

1.4 Appliance range of use

Intended use

The appliance is only suitable for cooling

food products in a domestic or household-like

environment. This includes, for example, use:

in staff kitchens, bed and breakfast estab‐

lishments,

by guests in country houses, hotels, motels

and other accommodation,

for catering and similar services in the

wholesale trade.

The appliance is not suitable as a built-in

unit.

All other types of use are not permitted.

Foreseeable misuse

The following applications are expressly

forbidden:

Storing and refrigerating medicines, blood

plasma, laboratory preparations or similar

substances and products based on the

Medical Device Directive 2007/47/EC

Use in areas at risk of explosions

Misusing the appliance may lead to damage

to the goods stored or they may spoil.

Climate classifications

Depending on the climate classification the

appliance is designed to operate in restricted

ambient temperatures. The climate classifica‐

tion applying to your appliance is printed on

the rating plate.

Note

►Keep to the specified ambient tempera‐

tures in order to guarantee that the appli‐

ance works properly.

Climate clas‐

sification

for ambient temperatures of

SN 10°C to 32°C

N 16°C to 32°C

ST 16°C to 38°C

T 16°C to 43°C

SN-ST 10°C to 38°C

SN-T 10°C to 43°C

1.5 Conformity

The refrigerant circuit has been tested for leaks. The appli‐

ance complies with the applicable safety regulations and

with the corresponding directives.

For the EU

market:

The appliance complies with directive

2014/53/EU.

For the GB

market:

The appliance complies with Radio

Equipment Regulations 2017 SI 2017 No.

1206.

The full text of the EU Declaration of Conformity is available

on the following website: www.Liebherr.com

The BioFresh compartment meets the requirements of a

cold storage compartment as set out in DIN EN 62552:2020.

1.6 SVHC substances according to

REACH regulation

You can check whether your appliance contains SVHC

substances according to REACH regulation at the following

link: home.liebherr.com/de/deu/de/liebherr-erleben/nach‐

haltigkeit/umwelt/scip/scip.html

1.7 EPREL database

Details about energy labelling and ecodesign requirements

will be available on the European product database (EPREL)

from 1st March 2021. You can access the product database

at the following link: https://eprel.ec.europa.eu/ You will be

asked to enter the model ID. You can find the model ID on

the nameplate.

Appliance at a glance

4 * Depending on model and options

1.8 Spare parts

The spare parts availability for functional parts and stock‐

able parts of the equipment is 15 years.

2 General safety instructions

Please keep these operating instructions in a

safe place so you can refer back to them at

any time.

If you pass the appliance on, please hand

these operating instructions to the next user.

Read these operating instructions carefully

before use to ensure safe and correct use of

the appliance. Follow the instructions, safety

instructions and warning messages included

at all times. They are important for ensuring

you can operate and install the appliance

safely and without any problems.

Danger for the user:

This device can be used by children and

people with impaired physical, sensory or

mental abilities or with a lack of experi‐

ence and knowledge provided that they are

supervised or have received instruction in

the safe use of this device, and about the

resulting hazards.

Children must not play with this appliance.

Cleaning and user maintenance work must

not be carried out by children without adult

supervision. Children aged between 3 and

8 are allowed to load and unload the appli‐

ance. Children below the age of 3 must be

kept away from the appliance unless they

are under continuous adult supervision.

The socket must be easily accessible so

that the appliance can be disconnected

quickly from the electricity in an emer‐

gency. It must not be located in the area

behind the appliance.

When disconnecting the appliance from the

supply, always take hold of the plug. Do not

pull the cable.

In the event of a fault pull out the mains

plug or deactivate the fuse.

Do not damage the mains power cable. Do

not operate the appliance with a defective

mains power cable.

Only customer service or other specially

trained staff may repair or perform other

operations on the appliance.

Only assemble, connect and dispose of the

appliance according to the instructions.

The manufacturer is not liable for damage

caused by a faulty fixed water connection.*

Fire hazard:

The coolant used (information on the model

plate) is ecofriendly but also flammable.

Any leaking coolant may ignite.

•

Do not damage the refrigerant circuit

pipes.

•

Do not handle ignition sources inside the

appliance.

•

Do not use electrical appliances inside

the appliance (e.g. steam cleaners,

heaters, ice cream makers, etc.).

•

If the refrigerant leaks: remove any naked

flames or ignition sources from the

vicinity of the leakage point. Properly air

the room. Inform customer services.

Do not store explosives or sprays using

combustible propellants such as butane,

propane, pentane, etc. in the appliance. To

identify these spray cans, look for the list

of contents printed on the can, or a flame

symbol. Gases possibly escaping may ignite

due to electrical components.

Keep burning candles, lamps and other

items with naked flames away from the

appliance so that they do not set the appli‐

ance on fire.

Please be sure to store alcoholic drinks

or other packaging containing alcohol in

tightly closed containers. Any alcohol that

leaks out may be ignited by electrical

components.

Danger of tipping and falling:

Do not misuse the plinth, drawers, doors

etc. as a step or for support. This applies

particularly to children.

Danger of food poisoning:

Do not consume food which has been

stored too long.

Danger of frostbite, numbness and pain:

Avoid prolonged skin contact with cold

surfaces or refrigerated/frozen goods or

take protective measures, e.g wear gloves.

Danger of injury and damage:

Hot steam can lead to injury. Do not use

electrical heating or steam cleaning equip‐

ment, open flames or defrosting sprays to

defrost.

Do not use sharp implements to remove the

ice.

Risk of crushing:

Do not hold the hinge when opening and

closing the door. Fingers may get caught.

Symbols on the appliance:

General safety instructions

* Depending on model and options 5

This symbol may be located on the

compressor. It relates to the oil in the

compressor and makes reference to the

risk that: Swallowing or inhaling can be

fatal. This advice is only relevant to recy‐

cling. There is no danger in normal opera‐

tion.

This symbol is located on the compressor

and indicates the danger of flammable

materials. Do not remove the sticker.

This or a similar sticker may be located

on the rear of the appliance. This sticker

indicates that there are vacuum insulation

panels (VIP) or perlite panels in the door

and/or housing. This advice is only relevant

to recycling. Do not remove the sticker.

Please note the warning messages and other

specific advice in the other chapters:

DANGER

indicates an immediately

hazardous situation which will

lead to death or serious injuries if

it is not avoided.

WARNING indicates a hazardous situation

which may lead to death or serious

injuries if it is not avoided.

CAUTION indicates a hazardous situation

which may lead to minor or

moderate injuries if it is not

avoided.

NOTICE indicates a hazardous situation

which may lead to damage to

property if it is not avoided.

Note indicates useful instructions and

tips.

3 Functionality of the

Touch&Swipe display

You operate your appliance using the Touch & Swipe display.

You select appliance functions in the Touch & Swipe display

(hereafter referred to as display) by tapping them. If you

do not perform any action on the display for 10 seconds,

the display either jumps back to the higher-level menu or

directly to the status display.

3.1 Navigation and symbol explanation

In the illustrations, different symbols are used to navigate

the display. The following table describes these symbols.

Symbol

Description

Briefly touch the display:

Activates/deactivates function.

Confirms selection.

Opens submenu.

Touch the display for a specified time

(e.g. 3seconds):

Activates/deactivates function or

value.

Symbol Description

Swipe left or right:

Navigate in the menu.

Briefly touch the Back symbol:

Jumps back one menu level.

Press and hold the Back symbol for

3seconds:

Jumps back to the status display.

Arrow with clock:

It takes more than 10 seconds for the

following message to appear in the

display.

Arrow with a time indication:

It takes the specified amount of time

until the following message appears in

the display.

“Open Settings menu” symbol:

Navigates to the Settings menu and

opens the settings menu.

If necessary: Navigate to the desired

function in the Settings menu.

(see 3.2.1 Opening the Settings menu)

“Open Advanced menu” symbol:

Navigates to the Advanced menu and

opens the advanced menu.

If necessary: Navigate to the desired

function in the Advanced menu.

(see 3.2.2 Opening the expanded

menu)

No action for

10seconds

If you do not perform any action on

the display for 10 seconds, the display

either jumps back to the higher-level

menu or directly to the status display.

Open door and

close it again.

If you open the door and immedi‐

ately close it again, the display jumps

directly back to the status display.

Note: Illustrations of the display are shown in the English

version.

3.2 Menus

The appliance functions are distributed over various menus:

Description

Main menu When you switch the appliance on, you

are automatically in the main menu.

From here you can navigate to the most

important appliance functions, to the

Settings menu and to the Advanced

menu.

Functionality of the Touch&Swipe display

6 * Depending on model and options

Menu Description

Settings menu

The Settings menu contains additional

appliance functions for setting up your

appliance.

Advanced menu The advanced menu contains special

appliance functions for setting up your

appliance. Access to the Advanced menu

is protected by the numerical code 151.

3.2.1 Opening the Settings menu

Fig. 2 Example illustration

► Carry out action steps according to the illustration.

▷ Settings menu is open.

► If necessary: Navigate to the desired function.

3.2.2 Opening the expanded menu

Fig.3

Fig. 4 Example illustration, access with numerical code 151

► Carry out action steps according to the illustration.

▷ The expanded menu is open.

► If necessary: Navigate to the desired function.

3.3 Sleep mode

If you do not touch the display for 1 minute, the display

switches to sleep mode. In sleep mode, the display bright‐

ness is dimmed.

3.3.1 Ending sleep mode

► Touch the display briefly with your finger.

▷ Sleep mode is ended.

4 Putting into operation

4.1 Switching on appliance (first use)

Make sure that the following requirements are fulfilled:

❑

The appliance has been installed and connected in

accordance with the installation instructions.

❑

All adhesive strips, adhesive and protective films and

transport locks are removed from inside and on the appli‐

ance.

❑

All marketing leaflets are removed from the drawers.

❑

You are familiar with the functionality of the

Touch & Swipe display. (see 3 Functionality of the

Touch&Swipe display)

Switch on the appliance using the Touch&Swipe display:

► If the display is in sleep mode: Briefly touch the display.

► Carry out action steps according to the illustration.

Fig. 5 Example illustration

▷ Status display appears.

▷ The appliance cools to the temperature set at the factory.

▷ The appliance starts in demo mode (status display with

DEMO appears): If the appliance starts in demo mode,

you can deactivate demo mode within the next 5 minutes.

(seeDemo mode)

More information:

Start the InfinitySpring for the first time. (see 4.2 Putting

InfinitySpring into operation*) *

Start the IceMaker for the first time. (see 4.3 Starting the

IceMaker for the first time*) *

Start the EasyTwist-Ice for the first time. (see4.4Starting

the EasyTwist-Ice for the first time*) *

Start the HydroBreeze for the first time. (see 4.5 Starting

the HydroBreeze for the first time*) *

Start the SmartDevice for the first time. (see 1.3 Smart‐

Device) and (seeWiFi)

Note

The manufacturer recommends:

► Stock with food: Wait for around 6 hours until the set

temperature is reached.

► Store frozen foods at -18°C or colder.

► Observe the notes on storing food. (see 5.1 Information

regarding storage)

Note

Accessories can be purchased from the Liebherr-

Hausgeräte store at home.liebherr.com/shop/de/deu/

zubehor.html.

Putting into operation

* Depending on model and options 7

4.2 Putting InfinitySpring into opera‐

tion*

If your appliance is equipped with an InfinitySpring, before

the first use you must bleed the water system for the Infini‐

tySpring and clean the InfinitySpring.

Make sure that the following requirements are fulfilled:

❑

The water supply is connected. See the Installation Guide

or installation instructions.

❑

The water tank is fitted. See the Installation Guide or

installation instructions.

❑

The water filter is fitted. See the Installation Guide or

installation instructions.*

❑

Appliance is properly connected.

4.2.1 Bleeding the water system

► Open the appliance door.

► Push a glass against the lower part of the InfinitySpring

dispenser.

▷ The upper part moves out and air escapes or water flows

into the glass.

► Continue until the water flows evenly into the glass.

▷ The water system is now bled.

4.2.2 Cleaning the InfinitySpring

(see 9.8.5 Cleaning the InfinitySpring *)

4.3 Starting the IceMaker for the first

time*

If your appliance is equipped with IceMaker, you must clean

the IceMaker before using it for the first time.

Make sure that the following requirements are fulfilled:

❑

The water supply has been connected. See Installation

Guide or mounting instructions.*

❑

The appliance is properly connected.

► Clean the IceMaker. (see 9.8.7 Cleaning the EasyTwist-

Ice*) *

4.4 Starting the EasyTwist-Ice for the

first time*

If your appliance is equipped with EasyTwist-Ice, you must

clean the EasyTwist-Ice before using it for the first time.

Make sure that the following requirements are fulfilled:

❑

The appliance is properly connected.

► Clean the EasyTwist-Ice. (see 9.8.7 Cleaning the Easy‐

Twist-Ice*)

► Fill the water tank. (see Filling the water tank)

4.5 Starting the HydroBreeze for the

first time*

If your appliance is equipped with HydroBreeze, you must

clean the HydroBreeze before using it for the first time.

Make sure that the following requirements are fulfilled:

❑

The appliance is properly connected.

► Clean the HydroBreeze. (see 9.8.6 Cleaning the Hydro‐

Breeze*)

► Fill the water tank. (see 8.9.1 Fill the water tank)

► Activate HydroBreeze. (see HydroBreeze*)

5 Storage

5.1 Information regarding storage

WARNING

Risk of fire

► Do not use any electrical appliances in the food area of

the appliance unless recommended by the manufacturer.

Note

The energy consumption increases and the cooling power

goes down if ventilation is not sufficient.

► Always keep air slots clear.

Observe the following specifications for storage:

Keep the air vents on the fan free.

In the freezer compartment: Package food properly.

Package or cover foods that readily take on or give off

odours or taste in closed containers.

Package raw meat or fish in clean, closed containers.

This will prevent meat or fish from touching or dripping

onto other food.

Keep liquids in closed containers.

Leave space between goods to ensure good air circula‐

tion.

Store food according to the instructions on the pack‐

aging.

Always observe the best-before date indicated on the

packaging.

Note

Failure to follow these guidelines can lead to foodstuffs

spoiling.

5.2 Fridge compartment

The air circulation in the appliance creates different temper‐

ature zones. You will find the different temperature zones in

the appliance and equipment overview. (see 1.2 Overview of

the appliance and equipment)

5.2.1 Arranging your food properly

► Upper area and door: Store butter, cheese, tinned food

and tubes.

► Coldest temperature zone: Store perishable foods such

as pre-cooked meals.

5.3 BioFresh

BioFresh will extend the storage time for some fresh foods

compared to traditional refrigeration.

Note

If the temperature drops below 0°C foods may freeze.

► Store cold-sensitive produce such as cucumbers, auber‐

gines, courgettes and tropical fruit in the fridge compart‐

ment.

5.3.1 Fruit & Vegetable safe

This safe creates a storage climate of close to 0 °C. The

compartment lid ensures constant levels of humidity. This

storage climate is suitable for storing unpackaged food with

high intrinsic moisture (for example, lettuce, vegetables,

fruit).

Storage

8 * Depending on model and options

The humidity in the compartment depends on the moisture

content of the chilled goods placed in it, and also depends

on how often the compartment is opened. You can regulate

the humidity level.

Arranging your food properly

► Store unpackaged fruit and vegetables.

If the humidity is too high:

► Regulate the humidity.

5.3.2 Meat & Dairy safe

This safe creates a storage climate of close to 0 °C. This

storage climate is suitable for more sensitive foods (e.g.

dairy products, meat, fish, sausage).*

This safe creates a storage climate of close to 0 °C. This

storage climate is suitable for more sensitive foods (e.g.

dairy products, meat, sausage).*

Arranging your food properly

► Store dry or packaged food.

5.3.3 Fish & Seafood safe

This safe creates a storage climate of between -2 °C and

0 °C. This storage climate is great for dry or packaged

groceries (for example, dairy products, meat, fish, seafood,

sausage).

This compartment includes a Fish & Seafood tray that you

can move or take away.

You can set the temperature via the Touch & Swipe display.

Dividing the compartment into different temperature zones

is only possible with the Fish & Seafood tray inserted.

(see Setting the temperature in the fridge section)

The following temperature combinations are possible:

Fig.6

Arranging your food properly

Fig.7

► For an optimum cooling function: Position Fish & Seafood

tray according to illustration (see Fig.7) .

► Temperature zone -2°C: Store fresh seafood or fish.

► Temperature zone 0 °C: Store dairy products or packaged

meats.

Note

You can achieve the highest level of energy efficiency using

the temperature combination 0°C /0°C.

Energy consumption is slightly higher using the temperature

combination -2°C /0°C and -2°C /-2°C.

5.4 Freezer compartment

Here, a dry, frosty storage climate is created at -18 °C. The

frosty storage climate is suitable for storing frozen food for

several months, for making ice cubes or freezing fresh food.

5.4.1 Freezing food

Freezing quantity

The maximum amount of fresh food that you can

freeze within 24 hours is specified on the type plate

(see 10.5 Model plate) under “Freezing capacity ... kg/24h”.

To ensure that food quickly freezes through, adhere to the

following quantities per package:

Fruit and vegetables up to 1 kg

Meat up to 2.5 kg

Freezing food using SuperFrost

Depending on the quantity to be frozen, you can activate

SuperFrost before freezing in order to achieve lower freezing

temperatures. (see SuperFrost)

► Activate SuperFrost if the amount of food you have to

freeze is more than approx. 2 kg.

The time at which you activate SuperFrost depends on the

amount of food you have to freeze:

Freezing quan‐

tity

Time at which you should activate

SuperFrost

Small amount of

food to freeze

Activate SuperFrost about 6 hours

before freezing.

You can place the food in the freezer

as soon as the appliance automatically

deactivates SuperFrost.

Maximum

amount of food

to freeze

Activate SuperFrost about 24 hours

before freezing.

You can place the food in the freezer

as soon as the appliance automatically

deactivates SuperFrost.

Arranging your food properly

CAUTION

Risk of injury from broken glass!

Bottles and cans with beverages can burst during freezing.

This applies in particular to carbonated beverages.

► Only freeze bottles and cans with beverages if you have

activated the BottleTimer function in the SmartDevice

app.

Freezing quan‐

tity

Arranging your food properly

Small amount of

food to freeze

Place packaged food in the top drawer.

If possible, place groceries at the back

of the drawer near the rear wall.

Maximum

amount of food

to freeze

Distribute packaged groceries

throughout all drawers, but only place

frozen food in the bottom drawer.

If possible, place groceries at the back

of the drawer near the rear wall.

5.4.2 Defrosting food

WARNING

Risk of food poisoning!

► Do not re-freeze thawed food.

► Use defrosted foodstuff as soon as possible.

You can defrost food in several ways:

In the fridge compartment

In the microwave

Storage

* Depending on model and options 9

In the oven/fan-assisted oven

At room temperature

► Take out only as much food as necessary.

5.5 Storage times

Refer to the specified storage times as a guide.

In the case of foods with a minimum shelf life, the date

indicated on the packaging still applies.

5.5.1 Fridge section

Always follow the best-before date stated on the packaging.

5.5.2 BioFresh

Recommended storage periods in the Meat & Dairy-Safe

Butter at 1°C up to 90 days

Hard cheese at 1°C up to 110 days

Milk at 1°C up to 12 days

Sausage, cold meats at 1°C up to 8 days

Poultry at 1°C up to 6 days

Pork at 1°C up to 6 days

Beef at 1°C up to 6 days

Game at 1°C up to 6 days

Note

► Remember that high-protein foods perish quicker; shell‐

fish and crustaceans do not last as long as fish, and fish

does not last as long as meat.

Recommended storage periods in the Fruit & Vegetable-

Safe

Vegetables, salads

Artichokes at 1°C up to 14 days

Celery at 1°C up to 28 days

Cauliflower at 1°C up to 21 days

Broccoli at 1°C up to 13 days

Chicory at 1°C up to 27 days

Lettuce at 1°C up to 19 days

Peas at 1°C up to 14 days

Kale at 1°C up to 14 days

Carrots at 1°C up to 80 days

Garlic at 1°C up to 160 days

Turnip at 1°C up to 14 days

Lettuce at 1°C up to 13 days

Herbs at 1°C up to 13 days

Leeks at 1°C up to 29 days

Mushrooms at 1°C up to 7 days

Radishes at 1°C up to 10 days

Brussels sprouts at 1°C up to 20 days

Asparagus at 1°C up to 18 days

Spinach at 1°C up to 13 days

Savoy at 1°C up to 20 days

Recommended storage periods in the Fruit & Vegetable-

Safe

Fruit

Apricots at 1°C up to 13 days

Apples at 1°C up to 80 days

Pears at 1°C up to 55 days

Blackberries at 1°C up to 3 days

Dates at 1°C up to 180 days

Strawberries at 1°C up to 7 days

Figs at 1°C up to 7 days

Blueberries at 1°C up to 9 days

Raspberries at 1°C up to 3 days

Currants at 1°C up to 7 days

Sweet cherries at 1°C up to 14 days

Kiwis at 1°C up to 80 days

Peaches at 1°C up to 13 days

Plums at 1°C up to 20 days

Cranberries at 1°C up to 60 days

Rhubarb at 1°C up to 13 days

Gooseberries at 1°C up to 13 days

Grapes at 1°C up to 29 days

Recommended storage periods in the Fish & Seafood-

Safe*

Seafood

Crabs at -2°C up to 4 days

Mussels at -2°C up to 6 days

Sushi at -2°C up to 4 days

Fish at -2°C up to 4 days

5.5.3 Freezer compartment

Recommended storage period for various types of food

Ice cream at -18°C 2 to 6 months

Sausages, ham at -18°C 2 to 3 months

Bread, baked goods at -18°C 2 to 6 months

Game, pork at -18°C 6 to 9 months

Fatty fish at -18°C 2 to 6 months

Lean fish at -18°C 6 to 8 months

Cheese at -18°C 2 to 6 months

Poultry, beef at -18°C 6 to 12 months

Vegetables, fruit at -18°C 6 to 12 months

6 Saving energy

Pay attention to good ventilation. Do not cover ventilation

holes or grids.

Always keep the fan air slits clear.

Do not place the appliance in direct sunlight or near radi‐

ators or similar sources of heat.

Saving energy

10 * Depending on model and options

If the appliance is placed directly next to an oven,

the energy consumption may increase slightly. This is

dependent on the service life and usage intensity of the

oven.

Energy consumption depends on the installation condi‐

tions, e.g. the ambient temperature (see 1.4 Appliance

range of use) . A warmer ambient temperature can

increase the energy consumption.

Open the appliance for as short a time as possible.

The lower the temperature is set the higher the energy

consumption.

Sort your food: home.liebherr.com/food.

Keep all food properly packed and covered. This prevents

frost from forming.

Only take food out for as long as necessary so that it

doesn’t warm up too much.

Inserting warm food: allow to cool down to room temper‐

ature first.

Thaw frozen food in the refrigerator.

If you intend to be on holiday for a long time empty the

refrigerator and switch it off.*

For longer periods of absence, use HolidayMode

(see HolidayMode*) .*

7 Controls

7.1 Controls and displays

7.1.1 Status display

Fig. 8 The status display shows the actual temperature.*

(1)

Temperature display of

the fridge section

(3) Freezer compartment

temperature display

(2) BioFresh tempera‐

ture display

(Fish & SeaFood-Safe)

Fig. 9 The status display shows the actual temperature.*

(1)

Temperature display of

the fridge section

(3) Freezer compartment

temperature display

(2) Temperature display

BioFresh

The status display shows the actual temperature and is the

initial display. Navigation to the functions takes place from

there.

7.1.2 Display symbols

Display symbols provide information on the current appli‐

ance status:

Symbol

Appliance status

Standby

The appliance or temperature zone

is switched off.

Symbol Appliance status

Flashing number

Appliance is working. Temperature

flashes until the set temperature is

reached.

Flashing symbol

Appliance is working. Setting is

made.

7.2 Appliance functions

7.2.1 Notes on the appliance functions

The appliance functions are set at the factory so that your

appliance is fully functional.

Before you alter, activate or deactivate the device functions,

make sure that the following requirements are met:

❑

You have read and understood the descriptions of

how the display works. (see 3 Functionality of the

Touch&Swipe display)

❑

You have familiarised yourself with the operating and

display elements of your appliance.

Switching the appliance off and on

Use this function to switch the entire appliance off and on.

Switching off the appliance

When you switch the appliance off, then the previously

saved settings are saved.

Make sure that the following requirements are fulfilled:

❑

Handling instructions (see 11 Shutting down) are carried

out.

Fig. 10

Fig.11

Controls

* Depending on model and options 11

Fig.11

► Carry out action steps according to the illustration.

▷ Appliance is switched off.

▷ The standby symbol appears in the display.

▷ Display turns black.

Switching on the appliance

If the display is in sleep mode:

► Briefly touch the display.

Fig. 12 Example illustration

► Carry out action steps according to the illustration.

When the appliance starts in demo mode:

► Deactivating demo mode. (see Deactivating demo mode)

▷ The appliance is switched on.

▷ Previous settings are restored.

▷ The appliance cools to the target temperature set.

Switching temperature zone off and on

You can switch temperature zones of the appliance off inde‐

pendently.

Switching the fridge compartment off

Make sure that the following requirements are fulfilled:

❑

Refrigerator compartment has been emptied.

❑

InfinitySpring water tank is empty.*

Fig. 13 Example illustration

► Carry out action steps according to the illustration.

▷

Refrigerator compartment is switched off.

Switching the freezer compartment off*

Make sure that the following requirements are fulfilled:

❑

Freezer compartment has been emptied.

❑

IceMaker is deactivated.*

❑

EasyTwist-Ice water tank is empty.*

Fig. 14 Example illustration

► Carry out action steps according to the illustration.

▷ Freezer compartment is switched off.

Switching the fridge compartment on

Fig. 15 Example illustration

► Carry out action steps according to the illustration.

▷ Refrigerator compartment is switched on.

▷ The appliance cools to the last set temperature.

Switching the freezer compartment on*

Fig. 16 Example illustration

► Carry out action steps according to the illustration.

▷ Freezer compartment is switched on.

▷ The appliance cools to the last set temperature.

Controls

12 * Depending on model and options

WiFi

Use this function to connect your appliance to WiFi. You can

then operate it via the SmartDevice app on a mobile device.

You can also use this function to disconnect or reset the

WiFi connection.

More information on the SmartDevice: (see 1.3 SmartDevice)

Note

The SmartDevice function is not available in the following

countries: Russia, Belarus, Kazakhstan.

Establishing the WiFi connection for the first time

Make sure that the following requirements are fulfilled:

❑

You have installed the SmartDevice app (see

apps.home.liebherr.com).

❑

Registration in the SmartDevice app is completed.

Fig.17

Fig. 18

► Carry out action steps according to the illustration.

▷ Connection is established.

Disconnecting from the WiFi

Fig. 19

Fig.20

► Carry out action steps according to the illustration.

▷ There is no connection.

Resetting the WiFi connection

Fig.21

Fig.22

► Carry out action steps according to the illustration.

▷ WiFi connection and other WiFi settings are reset to

factory settings.

Showing information about the WiFi connection

Fig.23

Fig. 24

► Carry out action steps according to the illustration.

Temperature

Use this function to set the temperature.

The temperature depends on the following factors:

Frequency of door opening

Duration of door opening

Room temperature of the installation site

Type, temperature and quantity of food

Controls

* Depending on model and options 13

Temperature zone Factory-set

temperature

Recommended

setting

Fridge section

5°C 4°C

Freezer section

-18°C -18°C

BioFresh*

Fruit & Vegetable-

safe*

Meat & Dairy-safe*

0°C B-Value

(see BioFresh B-

Value )

Fish & Seafood-

safe*

-2°C| 0°C* (see 5.3.3 Fish & S

eafood safe *) *

Setting the temperature in the fridge section

Fig. 25 Example illustration

► Carry out action steps according to the illustration.

▷ Temperature is set.

Setting the temperature in the freezer section

Fig. 26

► Carry out action steps according to the illustration.

▷ Temperature is set.

Setting the temperature in BioFresh

Set the temperature using the BioFresh B-Value.

(see BioFresh B-Value )

Setting the temperature in the Fish & Seafood safe*

Fig. 27 Example illustration

► Carry out action steps according to the illustration.

▷ Temperature is set.

Temperature unit

Use this function to set the temperature unit. You can set

degrees Celsius or degrees Fahrenheit as the temperature

unit.

Setting the temperature unit

Fig.28

Fig. 29 Example illustration: Switch from degreesCelsius

to degrees Fahrenheit.

► Carry out action steps according to the illustration.

▷ The temperature unit is set.

BioFresh B-Value

Use this function to set the BioFresh B-Value. With the

BioFresh B-Value, you can set BioFresh slightly warmer or

colder if necessary due to higher or lower ambient temper‐

atures. The BioFresh B-Value is pre-set to value B5 as deliv‐

ered. If you change the B-Value, refer to the following table:

Value

Description

B1 Lowest temperature

B1-B4 The temperature can drop below 0 °C which means

foods can easily freeze.

B5 Pre-set temperature

B9 Highest temperature

Controls

14 * Depending on model and options

Setting the BioFresh B-Value

Fig.30

Fig. 31 Example illustration: Switch from B5 to B6.

► Carry out action steps according to the illustration.

▷ The BioFresh B-Value is set.

▷ Status display shows target temperature.*

D-Value

The D-Value is pre-set for your appliance and is not

permitted to be changed.

SuperCool*

You can use this function to activate or deactivate Super‐

Cool. If SuperCool is activated, then the appliance increases

the cooling capacity. It allows you to achieve lower cooling

temperatures. You can activate SuperCool when you would

like to cool a large quantity of food quickly.

If the function is active, the appliance operates at higher

power. As a result, the appliance's operating noise may be

temporarily louder and energy consumption will increase.

Activating SuperCool

Time for activation of the function:

When you would like to store fresh food in the fridge

section: Activate the function when inserting food.

Fig.32

Fig.33

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

▷ SuperCool is activated.

▷ The temperature display turns blue.

Deactivating SuperCool

SuperCool is deactivated automatically after 18 hours.

However, you can also deactivate SuperCool manually at

any time:

Fig.34

Fig.35

► Carry out action steps according to the illustration.

-or-

► Deactivate with the SmartDevice app.

▷ SuperCool is deactivated.

▷ The appliance continues to run in normal mode.

▷ The appliance cools to the temperature set previously.

VarioTemp*

This function allows you to use the freezer compartment

as an additional cooling zone. You can set the temperature

from -2 °C to 14 °C. If you activate this function, it may

cause more noise. However, the appliance is still fully func‐

tional.

For storage of foodstuff in the freezer compartment with

the VarioTemp function activated, Liebherr recommends:

Temperature

range

Foodstuff

4°C to 9°C Cooked foods, cheese, preserves

0°C Packaged fruit and vegetables

-2°C Fresh fish and seafood

10°C to 14°C Cold-sensitive foodstuffs such as

sweet potatoes, pumpkin or exotic

fruits, food or drinks that should not be

eaten too cold

Activating VarioTemp

Ensure that the following requirements are met:

❑

The IceMaker has been cleaned. (see 9.8.7 Cleaning the

EasyTwist-Ice*) *

❑

The EasyTwist-Ice has been cleaned. (see 9.8.7 Cleaning

the EasyTwist-Ice*) *

WARNING

Risk of food poisoning!

► Do not re-freeze thawed food.

► Use defrosted foodstuff as soon as possible.

Fig.36

Controls

* Depending on model and options 15

Fig.37

► Carry out steps according to the illustration.

▷ VarioTemp is activated.

▷ IceMaker is deactivated.*

▷ VarioTemp is set to the preselected value.

▷ The status display does not show the preset temperature

until it is reached.

Adjusting VarioTemp

Ensure that the following requirements are met:

❑

The VarioTemp is activated. (see Activating VarioTemp)

WARNING

Risk of food poisoning!

► Do not re-freeze thawed food.

► Use defrosted foodstuff as soon as possible.

Fig. 38 Example illustration: Change VarioTemp from 12°C

to 5°C for a fridge-freezer combination with BioFresh.*

Fig. 39 Example illustration: Change VarioTemp from

12°C to 5°C for a fridge-freezer combination with

Fish & Seafood safe.*

► Carry out steps according to the illustration.

▷

VarioTemp is adjusted.

▷ The status display does not show the new set tempera‐

ture until it is reached.

Deactivating VarioTemp

Fig.40

Fig. 41

► Carry out steps according to the illustration.

▷ VarioTemp is deactivated.

▷ The freezer compartment is cooled to the preset temper‐

ature.

SuperFrost

You can use this function to activate or deactivate

SuperFrost. If SuperFrost is activated, then the appliance

increases the freezing capacity. It allows you to achieve

lower freezing temperatures.

Application:

Quickly freeze fresh food through to the core.

This ensures that the nutrition, appearance and taste of

frozen food is maintained.

Increase the cold reserve in stored frozen food before

defrosting the appliance.

If the function is active, the appliance operates at higher

power. As a result, the appliance's operating noise may be

temporarily louder and energy consumption will increase.

Activating SuperFrost

Make sure that the following requirements are fulfilled:

❑

Freezing quantity and time for activation of SuperFrost

are taken into account. (see Freezing food using

SuperFrost)

❑

VarioTemp is deactivated. (see VarioTemp*) *

Fig. 42

Fig.43

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

Controls

16 * Depending on model and options

▷ SuperFrost is activated.

▷ The temperature display turns blue.

Deactivating SuperFrost

SuperFrost is automatically deactivated after 56 to 72 hours

depending on the quantity of the food inserted. However,

you can also deactivate SuperFrost manually at any time:

Fig.44

Fig.45

► Carry out action steps according to the illustration.

-or-

► Deactivate with the SmartDevice app.

▷ SuperFrost is deactivated.

▷ The appliance continues to run in normal mode.

▷ The appliance cools to the temperature set previously.

Start defrosting cycle

Use this function to start the automatic defrosting cycle

manually if it does not start automatically in the event of a

fault.

Starting defrosting cycle

Fig.46

Fig. 47

► Carry out action steps according to the illustration.

▷ Defrosting cycle has started: Icon flashes until defrosting

cycle is automatically completed.

▷ When defrosting cycle is finished: The device continues

to run in normal mode.

Cancelling defrosting cycle

The defrosting cycle will be stopped automatically. However,

you can also cancel the defrosting cycle at any time during

the defrosting process:

Fig.48

► Carry out action steps according to the illustration.

▷ Defrosting cycle is cancelled.

▷ The device continues to run in normal mode.

PartyMode

You can use this function to activate or deactivate Party‐

Mode. PartyMode activates various functions that are useful

for a party.

PartyMode activates the following functions:

SuperCool (see SuperCool*) *

SuperFrost (see SuperFrost)

IceMaker with MaxIce (see IceMaker / MaxIce *) *

You can adjust all listed functions individually and flexibly.

When you deactivate PartyMode, all changes are discarded.

If the function is active, the device operates at higher

power. As a result, the device's operating noise may be

temporarily louder and energy consumption will increase.

Activating PartyMode

Make sure that the following requirements are fulfilled:

❑

The IceMaker has been started. (see 4.3 Starting the

IceMaker for the first time*) *

Fig. 49

Fig.50

► Carry out action steps according to the illustration.

▷ PartyMode and the associated functions are activated.

▷ The temperature display turns blue.

▷ The current temperature flashes until the target tempera‐

ture is reached.

Deactivating PartyMode

The PartyMode is automatically deactivated after

24 seconds. However, you can also deactivate PartyMode

manually at any time:

Fig.51

Controls

* Depending on model and options 17

Fig.52

► Carry out action steps according to the illustration.

▷ PartyMode is deactivated.

▷ The appliance cools to the temperature set previously:

The current temperature flashes until the target tempera‐

ture is reached.

HolidayMode*

You can use this function to activate or deactivate Holiday‐

Mode. If you activate HolidayMode, the fridge section is set

to 15 °C. This saves you energy during longer periods of

absence and prevents bad odours and growth of mould.

Appliance status when HolidayMode is active

Fridge section cools to 15°C.

BioFresh cools to 15°C.

The set temperature is maintained in the freezer section.

PartyMode is deactivated.

SuperCool is deactivated.*

Activating HolidayMode

► Empty the fridge section completely.

► Empty BioFresh completely.

Fig.53

Fig.54

► Carry out action steps according to the illustration.

▷ HolidayMode is activated.

▷ Temperature display turns blue and shows HolidayMode

symbol.

Deactivating HolidayMode

Fig.55

Fig.56

► Carry out action steps according to the illustration.

▷

HolidayMode is deactivated.

▷ The appliance cools to the temperature set previously.

SabbathMode

You can use this function to activate or deactivate

SabbathMode. If you activate this function, some electronic

functions are switched off. As a result, your device meets

the religious requirements for Jewish holidays such as

Sabbath and complies with STAR-K Kosher certification.

Device status when SabbathMode is active

The status display shows SabbathMode permanently.

All functions on the display are locked except for the

Deactivate SabbathMode function.

Active functions remain active.

The display remains bright when you close the door.

The interior lighting is deactivated.

Reminders are not implemented. The set time interval

stops.

Reminders and warnings are not displayed.

There is no door alarm.

There is no temperature alarm.

The IceMaker is switched off.*

The InfinitySpring is switched off.*

The defrosting cycle operates only for the specified time,

without considering the appliance consumption.

After a power failure, the appliance returns to

SabbathMode.

Device status

Note

This appliance has certification from the “Institute for

Science and Halacha”. (www.machonhalacha.co.il)

You can find a list of STAR-K-certified appliances at

www.star-k.org/appliances.

Activating SabbathMode

WARNING

Danger of food poisoning from spoiled food!

If you have SabbathMode activated and a power failure

occurs, no message appears in the status display about the

power failure. Once the power is restored, the appliance

continues to operate in SabbathMode. The power failure

may mean that food spoils and the consumption of this food

could lead to food poisoning.

After a power failure:

► Do not consume food that was frozen and has thawed

out.

Fig.57

Controls

18 * Depending on model and options

Fig.58

► Carry out action steps according to the illustration.

▷ SabbathMode is activated.

▷ The status display shows SabbathMode permanently.

Deactivating SabbathMode

The SabbathMode is automatically deactivated after

80 hours. However, you can also deactivate SabbathMode

manually at any time:

Fig. 59

► Carry out action steps according to the illustration.

▷ SabbathMode is deactivated.

EnergySaver

You can use this function to activate or deactivate Energy

saving mode. If energy saving mode is activated, the energy

consumption decreases and the temperature in the device

increases. The food remains fresh, but the shelf life is short‐

ened.

Temperature zone

Recommended

setting (see Setting

the temperature in

the fridge section)

Temperature

with active

EnergySaver

Fridge section

4°C 7°C

Freezer section

-18°C -16°C

Temperatures

Activating EnergySaver

Fig.60

Fig.61

► Carry out action steps according to the illustration.

▷ Energy saving mode is activated.

Deactivating EnergySaver

Fig. 62

Fig.63

► Carry out action steps according to the illustration.

▷ Energy saving mode is deactivated.

HydroBreeze*

You can use this function to activate or deactivate Hydro‐

Breeze. If you activate the function, HydroBreeze generates

a fine, cool mist in BioFresh-safe. This extends the shelf

life of unpackaged salad, vegetables and fruit with high

intrinsic moisture.

If you activate the function, HydroBreeze activates every

90 minutes for 4 seconds when the door is closed. When

you open the door, HydroBreeze activates according to the

setting:

Value

Description

1 HydroBreeze is active for 4 seconds when

the door is open.

2 HydroBreeze is active for 6 seconds when

the door is open.

3 HydroBreeze is active for 8 seconds when

the door is open.

Deactivated

(pre-setting)

HydroBreeze is deactivated.

HydroBreeze duration when the door is open

Activating HydroBreeze

Note

If you activate HydroBreeze but there is no food in the

drawer, condensate forms on the base of the drawer.

► Only activate HydroBreeze if you are storing food in the

drawer.

Make sure that the following requirements are fulfilled:

❑

The HydroBreeze is clean. (see 9.8.6 Cleaning the Hydro‐

Breeze*)

❑

The water tank is full. (see 8.9.1 Fill the water tank)

Activate HydroBreeze by selecting a value for the Hydro‐

Breeze duration:

Fig.64

Controls

* Depending on model and options 19

Fig. 65 Example illustration: Activate HydroBreeze with

value 3.

► Carry out action steps according to the illustration.

▷ HydroBreeze is activated.

Deactivating HydroBreeze

Fig.66

Fig. 67

► Carry out action steps according to the illustration.

▷ HydroBreeze is deactivated.

IceMaker / MaxIce *

Use the IceMaker function to activate or deactivate the

production of ice cubes. Use the MaxIce function to

increase the amount of ice cubes produced by the IceMaker.

MaxIce is automatically deactivated after 48 hours.

However, you can also deactivate MaxIce manually at any

time: (see Deactivating MaxIce)

More information on the

number of ice cubes:

(see 10.1 Technical speci‐

fications)

Further information on the

IceMaker water supply:

(see IceMaker water

supply*)

More information on cleaning

the lines of the IceMaker:

(see TubeClean *)

If the function is active, the device operates at higher

power. As a result, the device's operating noise may be

temporarily louder and energy consumption will increase.

Activating the VarioTemp function will result in the auto‐

mated deactivation of the IceMaker. (see VarioTemp*) *

Activating IceMaker

Make sure that the following requirements are fulfilled:

❑

The water supply is established at the fixed water

connection. See installation instructions.*

❑

IceMaker is put into operation. (see8.12 IceMaker*)

Fig.68

Fig. 69

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

▷ IceMaker is activated. It can take up to 24 hours for the

IceMaker to produce the first ice cubes.

Activating the IceMaker with MaxIce

If you have not activated the IceMaker function before,

make sure that the following requirements are met:

❑

The water supply is established at the fixed water

connection. See installation instructions.*

❑

IceMaker is put into operation. (see8.12 IceMaker*)

Fig.70

Fig.71

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

▷ The IceMaker is activated with MaxIce.

Changing between the IceMaker and MaxIce

If you have activated the IceMaker and would like to change

to MaxIce:

Fig.72

Controls

20 * Depending on model and options

Fig.73

► Carry out action steps according to the illustration.

▷ The IceMaker is activated with MaxIce.

If you have activated MaxIce and would like to change to the

IceMaker:

Fig. 74

Fig.75

► Carry out action steps according to the illustration.

▷ IceMaker is activated.

▷ MaxIce is deactivated.

Deactivating the IceMaker and MaxIce

Fig. 76

Fig. 77 Example illustration of the active IceMaker function

► Carry out action steps according to the illustration.

-or-

► Deactivate with the SmartDevice app.

▷ IceMaker and MaxIce are deactivated.

▷ If ice cubes are currently being made, the system

completes the process.

▷ The IceMaker goes off automatically.

Deactivating MaxIce

► Activate the IceMaker. (see Activating IceMaker )

▷ MaxIce is deactivated.

▷ IceMaker is activated.

▷ To deactivate the IceMaker and MaxIce: (see Deactivating

the IceMaker and MaxIce)

IceMaker water supply*

Use this function to set the water supply. The water supply

regulates the amount of water supplied. The water supply

can be changed if it does not match the water pressure and

the ice cube size dispensed.

The water supply is pre-set to value 4 as delivered. A value

from 1 (smallest inflow volume) to 8 (largest inflow volume)

can be selected.

Setting water supply

Make sure that the following requirements are fulfilled:

❑

The IceMaker has been started. (see 4.3 Starting the

IceMaker for the first time*) *

❑

IceMaker is activated. (see IceMaker / MaxIce *) *

Fig.78

Fig. 79 Example illustration: Switch from value 5 to value6.

► Carry out action steps according to the illustration.

▷ The water supply is set.

TubeClean *

You can use this function to activate or deactivate Tube‐

Clean. If TubeClean is activated, it cleans the IceMaker lines.

Activating TubeClean

Make sure that the following requirements are fulfilled:

❑

IceMaker cleaning is prepared. (see 9.8.8 Cleaning the

IceMaker*)

❑

Empty container with a capacity of 1.5 l and with a

maximum height of 10cm is ready.

► Place the container in the drawer under the IceMaker.

Fig.80

Controls

* Depending on model and options 21

Fig.81

► Carry out action steps according to the illustration.

▷ TubeClean is activated.

▷ The cleaning process has started: Icon flashes until

the cleaning process is automatically completed after

60 minutes.

▷ When the cleaning process is complete: The device

continues to run in normal mode.

Deactivating TubeClean

TubeClean is automatically ended after 60 minutes.

However, TubeClean can also be deactivated at any time

during the cleaning process:

Fig.82

► Carry out action steps according to the illustration.

▷ TubeClean is deactivated: Cleaning process is aborted.

▷ The device continues to run in normal mode.

CleaningMode

You can use this function to activate or deactivate Cleaning‐

Mode. CleaningMode enables the appliance to be cleaned

conveniently.

This setting applies to the fridge section.

Application:

Clean the fridge section. (see 9.8Cleaning the appliance)

Clean the InfinitySpring. (see 9.8.5 Cleaning the Infinity‐

Spring *) *

Device status when CleaningMode is active

The status display shows CleaningMode permanently.

The fridge section is switched off.

Interior lighting is activated.

The reminders and warnings are not displayed. No signal

tone sounds.

The InfinitySpring is switched off.*

Device status

Activating CleaningMode

Fig.83

Fig.84

► Carry out action steps according to the illustration.

▷ CleaningMode is activated.

▷ The status display shows CleaningMode permanently.

Deactivating CleaningMode

CleaningMode is deactivated automatically after

60 minutes. However, you can also deactivate Cleaning‐

Mode manually at any time:

Fig.85

► Carry out action steps according to the illustration.

▷ CleaningMode is deactivated.

▷ The appliance cools to the temperature set previously.

Display brightness

Use this function to set the display brightness in stages.

You can select the following brightness levels:

40%

60%

80%

100 % (pre-setting)

Setting the brightness

Fig.86

Fig. 87 Example illustration: Switch from 80 % to 60%.

► Carry out action steps according to the illustration.

▷ The brightness is set.

Door alarm

Use this function to activate or deactivate the door alarm.

The door alarm sounds if the door is open for too long. The

door alarm is activated on delivery. You can set how long

the door may be open before the door alarm sounds.

The following values can be set:

1 minute

2 minutes

Controls

22 * Depending on model and options

3 minutes

Off

Setting the door alarm

Fig.88

Fig. 89 Example illustration: Change door alarm from

1 minute to 3 minutes.

► Carry out action steps according to the illustration.

▷ The door alarm is set.

Deactivating the door alarm

Fig. 91

Fig.92

► Carry out action steps according to the illustration.

▷ The door alarm is deactivated.

Input lock

You can use this function to activate or deactivate the input

lock. The input lock prevents the appliance being operated

accidentally, e.g. by children.

Application:

Avoid unintentional modification of functions.

Avoid unintentional switching off of the device.

Avoid unintentional temperature setting.

Activating the input lock

If you activate the input lock, you can continue to navigate

in the menus but you cannot select or change other func‐

tions.

Fig. 93

Fig. 94

► Carry out action steps according to the illustration.

▷ Input lock is activated.

Deactivating the input lock

Fig.95

Fig.96

► Carry out action steps according to the illustration.

▷ Input lock is deactivated.

Language

Use this function to set the display language.

You can select the following languages:

Deutsch

English

Français

Español

Italiano

Nederlands

Čeština

Polski

Português

Bulgarian

Русский

温度单位

Setting the language

Fig.97

Fig. 98 Example illustration depending on the language

and temperature

► Carry out action steps according to the illustration.

▷ The language is set.

Controls

* Depending on model and options 23

▷ The display returns to the status display.

Device information

Use this function to indicate the model name, index, serial

number and service number of your device. You will need

the device information when you contact customer service.

(see 10.4 Customer Service)

This function also opens the Advanced menu. (see 3 Func‐

tionality of the Touch&Swipe display)

Indicating the device information

Fig.99

Fig. 100

► Carry out action steps according to the illustration.

▷ Display indicates device information.

Software

Use this function to indicate the software version of your

device.

Indicating the software version

Fig. 101

Fig. 102

► Carry out action steps according to the illustration.

▷ Display indicates software version.

Reminder

Use this function to activate or deactivate the reminders.

The function is activated on delivery.

If the function is activated, the following reminders will

appear:

Replace the water filter (see Replace the water filter*) *

Replace the FreshAir activated carbon filter (see Replace

the FreshAir activated carbon filter)

Activating the reminder

Fig. 103

Fig. 104

► Carry out action steps according to the illustration.

▷ Reminder is activated.

Deactivating the reminder

Fig. 105

Fig. 106

► Carry out action steps according to the illustration.

▷ Reminder is deactivated.

Demo mode

Demo mode is a special feature for dealers who want to

demonstrate appliance features. If you activate demo mode,

all refrigeration functions are deactivated.

If you switch on your appliance and “Demo” appears in the

status display, then demo mode is already activated.

If you activate and then deactivate demo mode, the appli‐

ance will be reset to factory defaults. (see Resetting to

factory settings)

Activating demo mode

Fig. 107

Controls

24 * Depending on model and options

Fig. 108

► Carry out action steps according to the illustration.

▷ Demo mode is activated.

▷ Appliance is switched off.

► Switch on the appliance. (see 4.1 Switching on appliance

(first use))

▷ “DEMO” appears in the status display.

Deactivating demo mode

Fig. 109

Fig. 110

► Carry out action steps according to the illustration.

▷ Demo mode is deactivated.

▷ Appliance is switched off.

► Switch on the appliance. (see 4.1 Switching on appliance

(first use))

▷ Appliance is reset to factory settings.

Resetting to factory settings

Use this function to reset all settings to factory defaults.

All settings you have made so far are reset to their original

settings.

Performing a reset

Fig.111

Fig.112

► Carry out action steps according to the illustration.

▷ Device is reset.

▷ Device is switched off.

► Restart the device. (see 4.1 Switching on appliance (first

use))

Controls

* Depending on model and options 25

7.3 Messages

There are two categories of messages:

Category Importance

Warning Warnings appear in the event of a door alarm or

malfunction.

Simple warnings can be cancelled by yourself.

In the event of serious malfunctions, you must

contact customer service. (see 10.4 Customer

Service)

Reminder Reminders remind you of general processes.

You can carry out these operations to end the

message.

7.3.1 Overview of warnings

Behaviour of the appliance in the event of warnings:

Warning appears in red on the display.

The alarm tone sounds at an ever-increasing volume.

The interior lighting pulsates for some warnings.

Message

Cause Exit the

message

Door alarm

The message appears

if the door is open for

too long.

Carry out

action steps

(see Door

alarm) .

Power outage

alarm

The message appears

if the freezing temper‐

ature has risen due to

a power failure.

Carry out

action steps

(see Power

outage

alarm) .

Temperature

alarm

The message appears

if the freezing temper‐

ature does not corre‐

spond to the set

temperature.

Carry out

action steps

(see Tempera‐

ture alarm) .

Error

The message appears

if there is an appliance

error. A component of

the appliance has a

fault.

Carry out

action steps

(see Error) .

WLAN error

The message appears

if the appliance could

not be connected to

the WLAN. (see Estab‐

lishing the WiFi

connection for the

first time)

Carry out

action steps

(see WLAN

error) .

7.3.2 Ending warnings

Door alarm

Fig. 113 Example illustration

►

Carry out action steps according to the illustration.

-or-

► Close the door.

▷ The display returns to the status indicator.

You can set how long the door may be open before the door

alarm sounds. (see Setting the door alarm)

Power outage alarm

When the power failure has ended, the appliance cools

down to the previously set target temperature.

Fig. 114 Example illustration

► Briefly touch the display.

▷ Display shows information about the warning.

► Briefly touch the display.

▷ Warmest freezing temperature is displayed.

▷ If the freezing temperature was below -9 °C: Food can

still be consumed.

If the freezing temperature has risen above -9°C:

► Check the food.

► Briefly touch the display.

▷ The display returns to the status indicator: Current

temperature and target temperature are displayed.

Temperature alarm

Temperature differences can be caused by:

You have put in warm, fresh food.

Too much warm air has got in while you were sorting out

the freezer or removing items.

There has been a longer power failure.

The appliance is faulty.

► Eliminate causes.

▷ The appliance cools to the target temperature set previ‐

ously.

Fig. 115 Example illustration

► Briefly touch the display.

▷ Display shows information about the warning.

► Briefly touch the display.

▷ Warmest freezing temperature is displayed.

▷ If the freezing temperature was below -9 °C: Food can

still be consumed.

If the freezing temperature has risen above -9°C:

► Check the food.

► Briefly touch the display.

▷ The display returns to the status indicator: Current

temperature and target temperature are displayed.

Controls

26 * Depending on model and options

Error

Fig. 116 Example illustration

► Briefly touch the display.

▷ Error code is displayed.

► Note the error code.

► Briefly touch the display.

▷ The display returns to the status indicator.

► Contact Customer Service. (see 10.4 Customer Service)

WLAN error

► Check WLAN connection.

► Reconnect the appliance to the WLAN. (seeWiFi)

7.3.3 Overview of reminders

Behaviour of the appliance during reminders:

Reminder appears yellow on the display.

Alarm tone sounds.

The interior lighting pulsates for some reminders.

Message

Cause Exit the message

Insert the IceMaker

drawer*

The message

appears if the

IceMaker is acti‐

vated but the

IceMaker drawer

is open.*

Carry out action

steps (see Insert

the IceMaker

drawer*) .*

Replace the water

filter*

The message

appears when the

water filter needs

to be replaced.*

Carry out

action steps

(see Replace the

water filter*) .*

Replace the Fres‐

hAir activated

carbon filter

The message

appears when the

activated carbon

filter needs to be

replaced.

Carry out

action steps

(see Replace

the FreshAir acti‐

vated carbon

filter) .

7.3.4 Ending reminders

Insert the IceMaker drawer*

Fig. 117 Example illustration

► Briefly touch the display.

▷ Display shows reminder information.

► Briefly touch the display.

► Insert the IceMaker drawer.

-or-

► Deactivate IceMaker. (see IceMaker / MaxIce *)

▷ If IceMaker drawer is inserted and IceMaker is activated:

IceMaker produces ice cubes.

Replace the water filter*

Liebherr recommends: Replace the InfinitySpring water filter

every 6 months.

Note

Water filters are available from the Liebherr-Hausgeräte

store at home.liebherr.com/shop/de/deu/zubehor.html.

Fig. 118 Example illustration

► Briefly touch the display.

▷ Display shows reminder information.

► Briefly touch the display.

► Replace the water filter. (see 9.3 Water filter*)

▷ Water filter ensures optimum water quality.

▷ Reminder appears again after 6 months.

If you no longer wish to receive this reminder, you can deac‐

tivate it. (see Deactivating the reminder)

Replace the FreshAir activated carbon filter

Liebherr recommends: Replace the FreshAir activated

carbon filter every 6 months.

Note

FreshAir activated charcoal filters can be purchased

from the Liebherr-Hausgeräte store at home.liebherr.com/

shop/de/deu/zubehor.html.

Fig. 119 Example illustration

► Briefly touch the display.

▷ Display shows reminder information.

► Briefly touch the display.

► Replace the activated carbon filter. (see 9.1 FreshAir

carbon filter)

▷ Activated carbon filter ensures optimum air quality in the

cooling unit.

▷ Reminder appears again after 6 months.

If you no longer wish to receive this reminder, you can deac‐

tivate it. (see Deactivating the reminder)

Controls

* Depending on model and options 27

8 Features

8.1 Door rack

Door racks are suitable for storing drinks and food. You can

move door racks for your own individual use and take them

apart for cleaning. However, Liebherr recommends using the

door racks in the position in the door as delivered from the

factory.

Fig. 120 Example illustration, Door rack

(1)

Shelf

Fig. 121 Example illustration, Door racks with VarioBoxes*

(1)

Shelf (3) VarioBoxes

(2) Holding part for Vario‐

Boxes

(4) Side part

Fig. 122 Example illustration, Door rack with bottle holder*

(1)

Shelf (2) Bottle holder

The following table shows examples of what can be stored

in each door rack. Do not exceed the maximum loading

weight of the door.

Door rack

Food

Door rack (see Fig.120) Butter, cheese, tinned

food, tubes

Door rack with bottle holder

(see Fig.122) *

Bottles*

The sliding bottle holder

secures the bottles in the

door rack.*

Door rack with VarioBoxes

(see Fig.121) *

small food items*

8.1.1 Removing VarioBoxes*

Either one or both VarioBoxes can be used. If you want to

store particularly tall bottles in the door rack under the

door rack with VarioBoxes, you can remove one or both Vari‐

oBoxes.

Fig.123

► Pull out VarioBox to the end stop.

► Lift VarioBoxes out forwards.

► Take VarioBox out forwards.

8.1.2 Removing the door rack

Ensure that the following requirements are met:

❑

VarioBoxes have been removed. (see 8.1.1 Removing Vari‐

oBoxes*) *

Fig. 124 Example illustration

► Push the door rack upwards.

► Pull the door rack forward.

8.1.3 Inserting the door rack

Ensure that the following requirements are met:

❑

VarioBoxes have been removed. (see 8.1.1 Removing Vari‐

oBoxes*) *

Fig. 125 Example illustration

► Slide in the door rack.

► Press the door rack down.

Features

28 * Depending on model and options

8.1.4 Inserting VarioBoxes*

Fig. 126

► Place VarioBoxes at an angle on the rib of the door rack.

► Lower VarioBoxes.

► Push in the VarioBoxes.

8.1.5 Converting VarioBoxes*

Ensure that the following requirements are met:

❑

VarioBoxs have been removed. (see 8.1.1 Removing Vario‐

Boxes*)

❑

Door rack has been removed. (see 8.1.2 Removing the

door rack)

Fig.127

► Take off the holding part Fig.127(1) in position Fig.127(A)

backwards.

► Insert the holding part Fig.127(1) in position Fig.127(B).

► Insert the door rack. (see 8.1.3 Inserting the door rack)

Fig.128

► Insert the VarioBoxes in reverse order. (see Fig.128)

8.1.6 Removing the bottle holder*

Fig.129

► Slide the bottle holder to the side as far as the recess.

► Remove the bottle holder forwards.

8.1.7 Inserting the bottle holder*

Fig.130

► Insert the bottle holder in the recess.

► Push the bottle holder to the desired position to the side.

8.1.8 Dismantling the door rack*

It is possible to dismantle some of the door racks if you

want to clean them or install or remove spare parts.

Dismantling the door rack

Ensure that the following requirements are met:

❑

Door rack has been removed. (see 8.1.2 Removing the

door rack)

Fig. 131 Door rack with shelf

► Remove the shelf Fig.131(1).

Dismantling the door rack with VarioBoxes*

Ensure that the following requirements are met:

❑

Door rack has been removed. (see 8.1.2 Removing the

door rack)

Features

* Depending on model and options 29

Fig.132

► Remove the VarioBoxes. (see8.1.1 Removing VarioBoxes*)

► Pull off the holding part Fig.132(1).

► Pull off the side parts Fig.132(2).

► Remove the shelf Fig.132(3).

Dismantling the door rack with bottle holder*

Fig. 133 Door rack with bottle holder and shelf

► Slide the bottle holder Fig.133(1) to the side as far as the

recess.

► Remove the bottle holder Fig.133(1).

► Remove the shelf Fig.133(2).

8.1.9 Assembling the door rack*

Assembling the door rack

Fig. 134 Door rack with shelf

► Push the shelf Fig.134(1) into the side recesses.

Assembling the door rack with VarioBoxes*

Fig.135

►

Push the shelf Fig.135(1) into the side recesses.

► Insert the side parts Fig.135(2).

► Insert the holding part Fig.135(3).

► Insert the VarioBoxes. (see8.1.4 Inserting VarioBoxes*)

Assembling the door rack with bottle holder*

Fig. 136 Door rack with shelf

► Push the shelf Fig.136(1) into the side recesses.

► Insert the bottle holder Fig.136(2) in the recess.

► Push the bottle holder Fig. 136 (2) to the desired position

to the side.

8.2 Shelves

8.2.1 Adjusting/removing the shelves

The shelves are prevented from being pulled out acciden‐

tally by pull out stops.

Fig.137

► Lift the shelf and pull forward.

▷ Line up the side runner.

► Adjust the height of the shelf: Lift or lower it to the

desired height and slide it in.

-or-

Fig.138

► Remove the shelf completely: Pull it out to the front.

► Easier removal: Set the shelf at an angle.

► Insert the shelf again: Slide it in all the way.

▷ The pull-out stoppers point downwards.

▷ The pull-out stoppers are behind the front support.

8.3 Dividing shelf

8.3.1 Using the dividing shelf

The shelves are prevented from being pulled out acciden‐

tally by pull out stops.

Features

30 * Depending on model and options

Fig. 139

► Push the dividing shelf underneath as shown.

Fig. 140

Adjusting the height:

► Pull the glass panels out Fig. 140(1) from the front, one at

a time.

► Release the support rails and click in at the height you

want.

► Slide in the glass panels one at a time.

▷ Flat pull-out stoppers at the front, right behind the

support rails.

▷ High pull-out stoppers at the back.

Using both shelves:

► Hold the glass panel with one hand and pull it to the

front.

▷ The glass panel Fig. 140(1) and trim strip are at the front.

▷ The stops Fig. 140(3) point down.

8.4 VarioSafe *

The VarioSafe offers space in the refrigerator compartment

for small groceries, packages, tubes and jars, for example.

Fig. 141

(1)

VarioSafe drawer (3) Recesses on the left and

right side panel

(2) Side panels with ribs

for VarioSafe drawer

8.4.1 Inserting the VarioSafe

Fig. 142

► Insert the VarioSafe into the fridge section at an angle

Fig. 142(1) until the recesses in the side Fig. 142(2) of the

VarioSafe are at the level of the support rib in the fridge

section.

Fig. 143

► Set VarioSafe straight. Fig. 143(1)

► Lift VarioSafe at the front. Fig. 143(2)

Fig. 144

► Lift VarioSafe up toward the front.

► Push VarioSafe in to the rear.

► Lower VarioSafe.

▷ VarioSafe audibly engages.

▷ VarioSafe is inserted.

Features

* Depending on model and options 31

8.4.2 Repositioning the VarioSafe

You can move the VarioSafe as a whole in the refrigerator

compartment.

Fig. 145

► Lift VarioSafe at the front.

Fig. 146

► Pull VarioSafe forwards until the recesses in the side of

the VarioSafe are at the level of the support rib in the

refrigerator compartment. Fig. 146(1)

► Move VarioSafe up or down in the refrigerator compart‐

ment until the desired height is reached. Fig. 146(2)

Fig. 147

► Lift VarioSafe at the front.

► Push VarioSafe in to the rear.

▷ VarioSafe audibly engages.

▷ VarioSafe is offset in height.

8.4.3 Moving the VarioSafe drawer

You can use the VarioSafe drawer at two different heights.

If you would like to store taller foodstuffs in the VarioSafe

drawer, slide the VarioSafe drawer in on the bottom rib. If

you would like to store smaller foodstuffs in the VarioSafe

drawer, slide the VarioSafe drawer in on the top rib.

Fig. 148

► Pull out the VarioSafe drawer as far as it will go.

► Lift the VarioSafe drawer up at the front.

► Remove the VarioSafe drawer to the front.

Fig. 149

► Lift the VarioSafe drawer up at the front.

► Place the VarioSafe drawer behind the stoppers on

desired rib Fig. 149(1) or Fig. 149(2).

▷ VarioSafe drawer is offset in height.

8.4.4 Removing the VarioSafe

You can remove the VarioSafe as a whole.

Fig. 150

► Lift VarioSafe at the front.

Features

32 * Depending on model and options

Fig. 151

► Pull VarioSafe forwards Fig. 151 (1) until the recesses in

the side of the VarioSafe are at the level of the support

rib in the fridge section. Fig. 151(2)

Fig. 152

► Set VarioSafe in refrigerator compartment at an angle.

Fig. 152(1)

► Take VarioSafe out to the front. Fig. 152(2)

▷ VarioSafe is removed.

8.4.5 Disassembling the VarioSafe

You can disassemble the VarioSafe into its individual parts if

you want to clean the VarioSafe or if you need to install or

remove parts.

Fig. 153

► Remove VarioSafe as a whole. (see 8.4.4 Removing the

VarioSafe )

► Disassemble VarioSafe according to the illustration.

8.5 InfinitySpring*

The built-in water dispenser is great for drinking water.

The water temperature depends on the temperature in the

fridge.

Fig. 154

► Push the glass against the bottom pushbutton of the

dispenser.

▷ Pouring unit moves out: Water flows into the glass.

► Avoid spillages: Remove your cup slowly.

For more water:

► If the water flow stops, remove the water tank and push

your container against the bottom pushbutton of the

dispenser again.

8.6 Adjustable bottle shelf

Either the glass shelf or the variable bottle rack can be used

in the bottom section of the refrigerator. The glass shelf is

inserted at delivery.

Fig. 155 Example illustration

(1)

Variable bottle rack

8.6.1 Using the variable bottle rack

Fig. 156

► Lift the glass shelf Fig. 156(1) at the front and remove.

► Store the glass shelf Fig. 156 (1) in a safe place outside

the appliance.

Features

* Depending on model and options 33

Fig. 157

► Place bottles in the back row with their bases against the

back wall. (see Fig. 157)

Note

When the bottles protrude over the variable bottle rack at

the front:

► Set the lower door rack one position higher.

8.6.2 Using the glass shelf

Ensure that the following requirements are met:

❑

Bottles have been removed.

❑

Variable bottle rack has been cleaned.

(see 9.5 Removing / inserting the variable bottle rack)

(see 9.8.4 Clean the components)

Fig. 158

► Place the glass shelf Fig. 158 (1) at an angle, sloping it

downwards and backwards.

► Lower the glass shelf Fig. 158(1) at the front.

8.7 Drawers

You can remove the drawers for cleaning.

You can remove the drawers to use VarioSpace.*

The way to remove/insert the drawers varies depending

on the pull-out system. Your appliance can contain various

pull-out systems.

Note

The energy consumption increases and the cooling power

goes down if ventilation is not sufficient.

► Leave the bottom drawer in the appliance!

► Always leave the fan air vents clear on the back wall!

8.7.1 Drawer on appliance base or glass shelf

The drawer runs directly on the appliance base or on a glass

shelf. There are no rails.

When you remove the drawers, you can use the glass

shelves below them as storage shelves.

Removing drawer

Fig. 159

► Remove drawer as shown in the illustration.

Inserting drawer

Fig. 160

► Insert drawer as shown in the illustration.

8.7.2 Drawer on telescopic rails

The drawer runs on extendible rails (telescopic rails). There

are fully extendible telescopic rails and telescopic rails with

partial pull-out. Drawers which are fully extendible can be

pulled out fully from the appliance. Drawers with partial

pull-out cannot be removed fully from the appliance. The

system in your appliance depends on the type of appliance.

Fully extendible*

If you have fully extendible rails, there is a clamp located at

the back on the left and right of the rail.

Removing drawer

Fig. 161

► Pull out drawer as far as it will go.

► Lift left clamp and simultaneously pull drawer forwards

on the left. Fig. 161(1)

► Lift right clamp and simultaneously pull drawer forwards

on the right. Fig. 161(2)

► Remove drawer to the front. Fig. 161(3)

► Slide rails in.

Inserting drawer

Fig. 162

► Slide rails in.

► Place drawer on rails.

► Slide in drawer to the back.

▷ Drawer latches in audibly at the back.

Features

34 * Depending on model and options

Partial pull-out fridge compartment*

Removing drawer

Fig. 163

► Pull out drawer half-way. Fig. 163(1)

► Push the drawer down at the front. Fig. 163(2)

► Push the left rail in by about 2cm. Fig. 163(3)

► Push the right rail in by about 2cm. Fig. 163(4)

► Remove drawer to the front. Fig. 163(5)

Fig. 164

If the rails are not yet fully inserted after removing the

drawer:

► Push rails in completely.

Inserting drawer

Fig. 165

► Slide rails in.

► Place drawer on rails.

► Slide in drawer to the back.

Partial pull-out freezer compartment*

Note

If the magnet on the top drawer in the freezer compartment

is damaged or removed, the door sensors will malfunction.

► Do not damage or remove the magnet.

Removing drawer

Fig. 166

If the drawer is in the top freezer:

► Pull out drawer as far as it will go.

► Raise the drawer forwards.

► Remove the drawer forwards.

► Slide rails in.

-or-

Fig. 167

If the drawer is in the middle part of the freezer compart‐

ment:

► Pull out drawer half-way.

► Lift the drawer from the bottom rear.

► Remove the drawer forwards.

► Slide rails in.

Inserting drawer

Fig. 168

► Slide rails in.

► Guide drawer around the stoppers Fig. 168(1).

► Place drawer on rails.

► Slide in drawer to the back.

8.8 Compartment lid for Fruit & Vege‐

table Safe

The compartment lid ensures constant levels of humidity.

The compartment lid is directly on the drawer and can be

covered by shelves or additional drawers.

Fig. 169 Example illustration, compartment lid for

Fruit & Vegetable Safe

(1)

Fruit & Vegetable Safe

(2) Compartment lid for

Fruit & Vegetable Safe

(3) Variable bottle rack

Features

* Depending on model and options 35

8.8.1 Reducing the air humidity in the drawer

Fig.170

► Pull out the drawer Fig.170(1).

► Grasp the recessed grip Fig. 170 (2) on the compartment

lid and pull the compartment lid forwards at the same

time.

▷ When the drawer is closed, there is a small gap between

the compartment lid and the drawer.

▷ Using HydroBreeze is not possible. (see 8.9 Hydro‐

Breeze*) *

8.8.2 Increasing the air humidity in the drawer

Fig.171

► Pull out the drawer Fig.171(1).

► Grasp the recessed grip Fig. 171 (2) on the compartment

lid and push the compartment lid backwards at the same

time.

▷ When the drawer is closed, the compartment lid seals

with the drawer.

▷ Using HydroBreeze is possible. (see 8.9 HydroBreeze*) *

8.8.3 Using Fruit & Vegetable Safe as

Meat & Dairy Safe

You can use the Fruit & Vegetable Safe as Meat & Dairy

Safe. To do this, you must reduce the humidity in the drawer.

(see8.8.1 Reducing the air humidity in the drawer)

8.8.4 Using Fruit & Vegetable Safe with Hydro‐

Breeze*

You can use the Fruit & Vegetable Safe with HydroBreeze.

To do this, you must increase the humidity in the drawer.

(see8.8.2 Increasing the air humidity in the drawer)

8.9 HydroBreeze*

HydroBreeze emits a mist over the refrigerated goods to

provide moisture every time the door is opened.

The HydroBreeze and its water tank are located in the

adjustable bottle shelf.

Ensure that the following conditions are met:

The water tank is clean. (see 9.8.4 Clean the components)

The water tank is properly engaged.

The humidity in the drawer is set to high air humidity.

(see8.8.2 Increasing the air humidity in the drawer)

HydroBreeze is activated. (see HydroBreeze*)

8.9.1 Fill the water tank

WARNING

Unclean water!

Contaminants.

► Only fill with drinking water.

► The HydroBreeze is off: empty water tank.

► The HydroBreeze is no longer in use: empty water tank.

NOTICE

Sugar-content liquids!

Damage to HydroBreeze.

► Only fill with drinking water.

Note

Only use filtered, decarbonised water for the best quality

drinking water and to make the HydroBreeze, work

smoothly.

This water quality can be achieved using a table water filter

of the kind available in trade retail outlets.

► Only ever fill the water tank with filtered, decarbonised

drinking water.

The water tank is built into the adjustable bottle shelf

(see1.2 Overview of the appliance and equipment) .

Fig.172

► Press on the back-left corner of the front glass plate.

▷ The glass panel folds up at the front.

► Lift the glass panel and fold towards the rear until it

clicks into place Fig.172(1).

▷ Glass panel stands upright.

► Slide the slider Fig.172(2) to the left.

▷ The water tank jumps out of its recess.

► Remove the water tank Fig.172(3).

► Cleaning the water tank (see 9.8.4 Clean the compo‐

nents) .

Square opening:

► Fill with drinking water up to the marker.

► Insert the water tank into the recess, bottom first.

► Slowly lower the front part and push the tank in.

▷ The water tank is clicked into place.

8.9.2 Dismantling the water tank

You can remove the HydroBreeze water tank for cleaning.

Features

36 * Depending on model and options

Fig.173

► Push the water tanks Fig. 173 (2) together, leverage

the cover Fig. 173 (1) carefully over the latching

tabs Fig.173(3) and lift it up.

▷ The cover is released.

Fig. 174

► Move the cover Fig.173(1) slightly forwards and back, and

remove to the top.

▷ The water tank has been dismantled.

8.10 Glass shelves

You can remove the glass shelves under the drawers for

cleaning.

You can remove the glass shelves under the drawers to use

VarioSpace.*

8.10.1 Removing / inserting the glass shelf

Make sure that the following requirements are fulfilled:

❑

Glass shelf under the drawer: The drawer has been

removed. (see 8.7 Drawers)

Removing glass shelf

Fig. 175 Example illustration, glass shelf*

Fig. 176 Example illustration, glass shelf*

► Lift the glass shelf forwards.

► Remove the glass shelf forwards.

Inserting glass shelf

Fig. 177 Example illustration, glass shelf*

Fig. 178 Example illustration, glass shelf*

► Place the glass shelf at an angle behind the stoppers.

► Lower glass shelf.

► Slide in glass shelf to the back.

8.11 EasyTwist-Ice*

With the EasyTwist-Ice you can make enough ice cubes for

the whole household. The EasyTwist-Ice is supplied with

water via a water tank.

Fig. 179 Example illustration

(1)

Freezer drawer with

EasyTwist-Ice

(4) Rotary knob

(2) Body with ice cube tray (5) Ice cube drawer

(3) Water tank

Features

* Depending on model and options 37

Note

Do not change the position of the freezer drawer with the

EasyTwist-Ice in the appliance.

8.11.1 Making ice cubes

The amount of ice cubes you can make in a given period of

time with the EasyTwist-Ice depends on the freezer temper‐

ature of the appliance. The lower the temperature in the

appliance, the more ice cubes you can make.

Maximum number of ice

cubes in the ice cube tray:

20 ice cubes

Maximum capacity of the ice

cube drawer:

40 ice cubes (equivalent to

two ice cube batches)

More information about the

time needed for ice cube

production:

(see 10.1 Technical specifi‐

cations)

Make sure that the following requirements are fulfilled:

❑

Components of the EasyTwist-Ice have been cleaned.

Filling the water tank

WARNING

Risk of poisoning due to contaminated water!

► Only fill the water tank with potable water.

NOTICE

Sugar-content liquids!

Damage to EasyTwist-Ice.

► Only fill with cold drinking water.

Note

Using filtered, decarbonised water ensures the best-tasting

drinking water for your ice cubes.

This water quality can be achieved using a table water filter

of the kind available in trade retail outlets.

► Always fill the water tank only with filtered, decarbonised

drinking water.

Fig. 180

► Pull out freezer drawer as far as it will go.

► Lift the water tank at the recess Fig. 180(1).

► Remove the water tank by lifting it upwards. Fig. 180(2)

► Fill the water tank with drinking water up to the mark

Fig. 180(3).

Fig. 181

► Position the water tank at the front. Fig. 181(1)

► Lower the water tank at the rear. Fig. 181(2)

► Slide in the freezer drawer.

Releasing the ice cubes

Make sure that the following requirements are fulfilled:

❑

The required time for the production of ice cubes has

been observed. (see 10.1 Technical specifications)

❑

Freezer drawer is fully inserted.

❑

Ice cube drawer is fully inserted.

► Turn the rotary knob Fig. 179 (4) clockwise as far as it will

go.

▷ Ice cubes fall from the ice cube tray into the ice cube

drawer Fig.179(5).

If all the ice cubes do not come out of the ice cube tray:

► Turn the rotary knob clockwise several times to the stop.

8.12 IceMaker*

The IceMaker will produce ice cubes for household use only.

Ensure that the following conditions are met:

The IceMaker is clean. (see9 Maintenance)

IceMaker drawer is cleaned.

IceMaker drawer is fully inserted.

8.12.1 Producing ice cubes

The volume depends on the freezing temperature. The

colder the temperature, the more ice cubes the system can

produce in a certain time period.

After the IceMaker is turned on for the first time, it can take

up to 24 hours for the first ice cubes to be made.

► Activate the IceMaker function.

► Producing many ice cubes: Activate the MaxIce function.

► To make a high number of ice cubes: Move the divider in

the IceMaker drawer or remove it completely.*

► Distribute the ice cubes evenly in the drawer to increase

the capacity.

► Closing the drawer: IceMaker starts making ice cubes

again automatically.

Note

When a certain level is reached in the IceMaker drawer, it

stops producing ice cubes. The IceMaker does not fill the

drawer all the way to the top.

8.12.2 Using the drawer with the IceMaker

deactivated

If you deactivate the IceMaker, then you can use the entire

IceMaker drawer as a freezer drawer.

Features

38 * Depending on model and options

► Deactivate IceMaker. (see Deactivating the IceMaker and

MaxIce)

Fig. 182

► Place food in drawer.

If you put food in the left side of the drawer:

► Watch out for the IceMaker Fig. 182(1).

8.13 VarioSpace*

Fig. 183

You can remove drawers and glass panels from your appli‐

ance. This provides more room for large food items such as

poultry, joints of meat, large game, and tall baked products.

You can then freeze these items whole for later preparation.

► Note the weight limits on the drawers and glass panels

(see 10.1 Technical specifications) .

8.14 Butter dish*

8.14.1 Opening/closing the butter dish

Fig. 184

8.14.2 Dismantling the butter dish

You can take the butter dish apart for cleaning.

Fig. 185

► Disassembling the butter dish.

8.15 Egg rack*

You can pull out and turn the egg rack. You can use both

sides of the egg rack so you can label specifics like the

purchase date.

8.15.1 Using the egg rack

Fig. 186

► Top layer: for storing hen eggs.

► Bottom layer: for storing quail eggs.

8.16 Bottle holder*

8.16.1 Using the bottle holder

Fig. 187

► Push the bottle holder onto the bottles.

▷ The bottles are prevented from falling over.

8.17 FlexSystem*

8.17.1 Using the FlexSystem

The FlexSystem helps you store and organise your food in

a clear and flexible way. It lets you clearly divide your food

into fruit, vegetables or by use-by dates, for example.

Features

* Depending on model and options 39

Fig. 188

► Move the inner shell.

8.17.2 Removing the FlexSystem

Fig. 189

► Lift the FlexSystem from the back.

► Pull up and out.

8.17.3 Inserting the FlexSystem

Fig. 190

► Insert the FlexSystem front-first.

► Lower the rear part.

8.17.4 Disassembling the FlexSystem

You can take the FlexSystem apart for cleaning.

Fig. 191

► Disassembling the FlexSystem

8.18 Ice cube tray with cover*

8.18.1 Using the ice cube tray

Fig. 192

When the water is frozen:

► Hold ice cube tray under hot water for a short time.

► Remove the lid.

► Gently turn the ends of the ice cube tray in opposite

directions.

► Release the ice cubes.

8.18.2 Dismantling the ice cube tray

You can take the ice cube tray apart for cleaning.

Fig. 193

► Disassembling the ice cube tray.

8.19 Flexible ice compartment divider*

The IceMaker’s ice cube drawer has a flexible ice compart‐

ment divider. This allows you to store larger quantities of ice

cubes or additional food items as needed. You can move or

remove the ice compartment divider.

8.19.1 Moving in the flexible ice compartment

divider

Fig. 194 Example illustration of the ice compartment

divider

► Move the ice compartment divider to the desired position.

Features

40 * Depending on model and options

8.19.2 Removing the flexible ice compartment

divider

Make sure that the following requirements are fulfilled:

❑

Ice cube drawer is removed. (see 8.7 Drawers)

Fig. 195

► Lift the rear part of the ice compartment divider.

Fig. 195(1)

► Remove the ice compartment divider upwards. Fig. 195(2)

8.19.3 Putting in the flexible ice compartment

divider

Make sure that the following requirements are fulfilled:

❑

Ice cube drawer is removed. (see 8.7 Drawers)

Fig. 196

► Insert the front part of the ice compartment divider.

Fig. 196(1)

► Lower the rear part of the ice compartment divider to the

drawer bottom. Fig. 196(2)

8.20 FlexCube*

The FlexCube has different sized openings, so you can store

small items such as tubes, open yoghurt pots or quail

eggs in it. The FlexCube fits into all Liebherr door racks,

for example. If necessary, you can also set up several Flex‐

Cubes next to each other.

Fig. 197 Example illustration

Note

These accessories can be purchased from the Liebherr-

Hausgeräte shop at home.liebherr.com/shop/de/deu/

zubehor.html.

8.20.1 Using the FlexCube

Fig. 198 Example illustration

► Insert the FlexCube in the door rack.

-or-

Fig. 199 Example illustration

► Place FlexCube on shelf.

► Sort small parts into the FlexCube for storage.

9 Maintenance

9.1 FreshAir carbon filter

The FreshAir carbon filter is in the compartment above the

fan.

It guarantees the best air quality.

❑

Replace the carbon filter every 6 months.

When the reminder is set, a message on the display

prompts you to change it.

❑

The carbon filter can be disposed of with the regular

household waste.

Maintenance

* Depending on model and options 41

Note

FreshAir activated charcoal filters can be purchased

from the Liebherr-Hausgeräte store at home.liebherr.com/

shop/de/deu/zubehor.html.

9.1.1 Removing the FreshAir carbon filter

Fig.200

► Pull out the compartment Fig.200(1).

► Remove the carbon filter Fig.200(2).

9.1.2 Inserting the FreshAir carbon filter

Fig.201

► Insert the carbon filter as shown in the diagram

Fig.201(1).

▷ The carbon filter clicks into place.

If the carbon filter is pointing downwards:

► Push the compartment in Fig.201(2).

▷ The carbon filter is now ready for use.

9.2 Water tank*

The InfinitySpring water tank is located behind the bottom

drawer in the fridge section.*

9.2.1 Removing the water tank

► Turn off the tap.

► Drain the InfinitySpring for 30 seconds and collect

remaining water using a glass.*

► Remove the drawer compartment.

► Turn the water tank all the way anti-clockwise and pull it

out.

▷ Water dripping out is collected in the drip tray.

► Empty out the water from the drip tray.*

► Clean the drip tray with a cloth or in the dishwasher.*

9.2.2 Inserting the water tank

Fig.202

► Remove the drawer compartment.

► Insert the water tank and rotate approx. 90° clockwise

until it clicks in.

► Check that the tank is sealed and no water leaks out.

► Insert the drawer compartment.

► Turn on the tap.

► Bleed the water system. (see 4.2.1 Bleeding the water

system) *

Instead of the water filter you can insert an additional water

tank.*

Note

You can purchase this water tank as an optional extra.

9.2.3 Removing / inserting the drip tray*

You can remove the drip tray for cleaning.

Fig.203

► Pull out the drip tray to the front.

9.3 Water filter*

The water filter is located behind the lowest drawer in the

fridge section.

It filters out deposits in the water and reduces the taste of

chlorine.

❑

Replace the water filter at least every 6 months, or if

there is a significant reduction in the flow rate.

❑

The water filter contains carbon and can be disposed of

with the regular household waste.

Note

Water filters are available from the Liebherr-Hausgeräte

store at home.liebherr.com/shop/de/deu/zubehor.html.

Maintenance

42 * Depending on model and options

9.3.1 Removing the water filter

► Remove the drawer compartment.

► Turn the water filter all the way anti-clockwise and pull it

out.

▷ Water dripping out is collected in the drip tray.

► Clean the drip tray with a cloth or in the dishwasher.*

9.3.2 Inserting the water filter

Fig.204

► Remove the drawer compartment.

► Insert the water filter and rotate approx. 90° clockwise

until it clicks in.

► Check that the filter is sealed and no water leaks out.

► Insert the drawer compartment.

CAUTION

Risk of infection due to potential particulate matter in new

water filters!*

Nausea and vomiting.

► After replacing the filter: Draw and dispose of 3l water at

the InfinitySpring.

▷ The water filter is now ready for use.

9.4 Disassembling / assembling pull-

out systems

9.4.1 Notes on disassembly

You can disassemble some of the pull-out systems for

cleaning. Your appliance can contain a variety of pull-out

systems.

The following pull-out systems can be disassembled or

cannot be disassembled:

Pull-out system

can be disassembled/

cannot be disassembled

Drawer on appliance

base or glass shelf

cannot be disassembled

Fully extendible* cannot be disassembled*

Fridge section partial

pull-out*

cannot be disassembled*

Freezer section partial

pull-out*

can be disassembled (see Partial

pull-out freezer compartment*) *

9.4.2 Drawer on telescopic rails

Partial pull-out freezer compartment*

Disassembling pull-out system

Make sure the following prerequisites are met:

❑

Drawer has been removed.

❑

Glass shelf has been removed. (see 8.10 Glass shelves)

Fig. 205 Glass shelf with rails

► Push up front click-in hooks. Fig.205(1)

► Move the pull-out rails to the side Fig. 205 (2) and to the

rear Fig.205(3).

Installing pull-out system

Fig. 206 Glass shelf with rails

► Hook in rail at the back. Fig.206(1)

► Hook in rail at the front. Fig.206(2)

9.5 Removing / inserting the variable

bottle rack

The variable bottle rack can be removed for cleaning.

9.5.1 Removing the variable bottle rack

Ensure that the following requirements are met:

❑

Bottles have been removed.

❑

Glass shelf has been removed. (see 8.6.1 Using the vari‐

able bottle rack)

Fig.207

► Lift the variable bottle rack at the front and pull it out.

▷ The compartment lid is visible.

Note

Liebherr recommends:

Do not place any items on the compartment lid below.

Maintenance

* Depending on model and options 43

9.5.2 Inserting the variable bottle rack

Fig.208

► Push the variable bottle rack in to the end stop and press

it down.

▷ The connectors at the back of the variable bottle rack are

connected via automated processes.

▷ LED lights up.

► Insert the glass shelf. (see8.6.2Using the glass shelf)

-or-

► Use the variable bottle rack for bottles.

9.6 Compartment lid for Fruit & Vege‐

table Safe

You can remove the compartment lid for cleaning.

9.6.1 Removing the compartment lid

Ensure that the following requirements are met:

❑

The glass shelf directly above the variable bottle rack has

been removed.

❑

The variable bottle rack has been removed.

❑

The drawer directly below the compartment lid has been

removed. (see 8.7 Drawers)

Fig.209

► Push the compartment lid backwards.

► Lift the compartment lid forwards.

► Remove the compartment lid forwards and upwards at an

angle.

9.6.2 Inserting the compartment lid

Fig. 210

If the THIS SIDE UP lettering is at the top:

► Insert the rear retaining parts into the relevant rear open‐

ings.

► Push the compartment lid backwards.

► Lower the compartment lid forwards and engage the

front retaining parts into the openings.

► Move the compartment lid into the required position.

9.7 Defrosting the appliance

9.7.1 Defrosting the fridge compartment

Defrosting is performed automatically. The water from the

thawing process drains through the outlet and evaporates.

► Clean the drain opening at regular intervals.

(see 9.8Cleaning the appliance)

9.7.2 Defrosting the freezer compartment with

NoFrost

Defrosting is performed automatically with the NoFrost

system. The moisture is deposited on the evaporator, is peri‐

odically defrosted and evaporates.

The appliance does not have to be defrosted.

9.8 Cleaning the appliance

9.8.1 Ready

WARNING

Danger of electric shock!

► Remove the refrigerator connector or interrupt the power

supply.

WARNING

Risk of fire

► Do not damage the refrigeration circuit.

► Empty the appliance.

► Remove mains connector.

-or-

► Activate CleaningMode. (seeCleaningMode)

Maintenance

44 * Depending on model and options

9.8.2 Clean the housing

NOTICE

Improper cleaning!

Damage to the appliance.

► Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

► Do not uses abrasive sponges or steel wool which may

cause scratches.

► Do not use any sharp or abrasive cleaning agents, nor

any that contain sand, chloride or acid.

WARNING

Risk of injury and damage as a result of hot steam!

Hot steam can lead to burns and can damage the surfaces.

► Do not use any steam cleaners!

► Wipe the housing down with soft, clean cloth. If very

dirty, use lukewarm water with a neutral cleaner. Glass

surfaces can also be cleaned with glass cleaner.

9.8.3 Cleaning the interior

NOTICE

Improper cleaning!

Damage to the appliance.

► Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

► Do not uses abrasive sponges or steel wool which may

cause scratches.

► Do not use any sharp or abrasive cleaning agents, nor

any that contain sand, chloride or acid.

► Plastic surfaces: clean by hand with a soft clean cloth,

lukewarm water and a little detergent.

► Metal surfaces: clean by hand with a soft clean cloth,

lukewarm water and a little detergent.

► Drain hole: remove deposits using a thin item (for

example a cotton bud).

9.8.4 Clean the components

NOTICE

Improper cleaning!

Damage to the appliance.

► Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

► Do not uses abrasive sponges or steel wool which may

cause scratches.

► Do not use any sharp or abrasive cleaning agents, nor

any that contain sand, chloride or acid.

Clean with a soft, clean cloth, lukewarm water and some

detergent:

- Door rack*

- Dividing shelf

- VarioSafe*

- Compartment lid for Fruit & Vegetable Safe

- Drawer

Please note: Do not remove the magnet on the drawer.

The magnet ensures the functionality of the IceMaker.*

- Flexible ice compartment divider in the IceMaker's ice

cube drawer*

- Adjustable bottle shelf

- FlexSystem*

- Components of the EasyTwist-Ice*

Clean with a damp cloth:

- Retractable rails

Please note: The grease in the tracks is used for lubrica‐

tion and must not be removed!

Wash in the dishwasher up to 60°C:

- Door rack*

- VarioBox*

- Bottle rack*

- Holder of the dividing shelf

- HydroBreeze water tank and water tank lid*

- Drip tray*

- Egg rack*

- Butter dish*

- Ice cube tray*

- Ice cube scoop*

- FlexCube*

► To disassemble components: see the relevant section.

► Clean the components.

9.8.5 Cleaning the InfinitySpring *

You can clean the InfinitySpring outlet and around it without

disconnecting the appliance from the mains.

Cleaning is required in the following cases:

❑

Initial operation

❑

If out of use for more than 5 days.

► Press the bottom pushbutton of the dispenser.

▷ The outlet unit moves out.

► Clean the water outlet and around it with a soft, clean

cloth, lukewarm water and some detergent.

► Release the bottom pushbutton.

► Draw and dispose of 2l water at the InfinitySpring.

9.8.6 Cleaning the HydroBreeze*

Cleaning is required in the following cases:

❑

Initial operation

❑

HydroBreeze is off for more than 48 hours.

❑

Refill the water tank.

Ensure that the following conditions are met:

❑

HydroBreeze is off (see HydroBreeze*) .

❑

Water tank has been removed and cleaned in the dish‐

washer.

► Wipe out the recess with a damp cloth.

► Insert the water tank.

► Activate the HydroBreeze.

9.8.7 Cleaning the EasyTwist-Ice*

Clean the EasyTwist-Ice in the following situations:

First use

Not using for more than 48 hours

When cleaning is required

Dismantling the EasyTwist-Ice

Make sure that the following requirements are fulfilled:

❑

The drawer has been removed. (see 8.7 Drawers)

❑

The drawer is placed on a table.

Maintenance

* Depending on model and options 45

Fig.211

► Removing the water tank: Lift the water tank by the

recess Fig.211(1).

► Remove the water tank Fig.211(2) upwards.

► Remove the ice cube drawer Fig.211(3) to the front.

Fig.212

► Removing the EasyTwist-Ice body: Use your finger to

push the tab Fig.212(4) down and use your other hand to

lift the EasyTwist-Ice body Fig. 212 (5) from behind at the

same time.

► Remove the EasyTwist-Ice body from the freezer drawer.

Fig.213

► Removing the EasyTwist-Ice body cover: Push the tabs

Fig. 213 (6) on both sides of the EasyTwist-Ice body with

one hand.

► Use the other hand to remove the cover Fig. 213 (7)

upwards.

▷ EasyTwist-Ice is dismantled into four parts. (see Fig. 214)

Fig. 214 Components of the EasyTwist-Ice

(1) EasyTwist-Ice body

with ice cube tray

(3) Cover

(2) Water tank (4) Ice cube drawer

NOTICE

Risk of damage due to improper dismantling!

Equipment breaking, jumping and cracking. If you dismantle

the EasyTwist-Ice body further, you may damage the rotary

knob or other parts of the EasyTwist-Ice body.

► Only dismantle the EasyTwist-Ice into the components

shown. (see Fig. 214)

► Clean the EasyTwist-Ice body Fig. 214(1) as a whole.

Cleaning the EasyTwist-Ice

Make sure that the following requirements are fulfilled:

❑

The EasyTwist-Ice is dismantled. (see Dismantling the

EasyTwist-Ice)

► Clean the ice cube drawer, water tank, cover and Easy‐

Twist-Ice body with warm water and a little detergent.

► Dry all cleaned components thoroughly with a dry cloth.

▷ The EasyTwist-Ice is clean.

Installing the EasyTwist-Ice

Fig. 215

► Installing the EasyTwist-Ice body cover: Place the cover

on the front. Fig. 215(1)

► Lower the cover at the rear. Fig. 215(2)

▷ The cover locks into both tabs Fig. 215(3) audibly.

Maintenance

46 * Depending on model and options

Fig. 216

► Installing the EasyTwist-Ice body: Push the axes for the

EasyTwist-Ice body into the guides Fig. 216(4).

► Press the EasyTwist-Ice body Fig. 216 (5) down at the

back.

▷ The EasyTwist-Ice body locks in audibly.

Fig.217

► Insert the ice cube drawer Fig.217(6).

WARNING

Risk of poisoning due to contaminated water!

► Only fill the water tank with potable water.

► Fill the water tank with water.

► Insert the water tank.

► Insert the drawer. (see 8.7 Drawers)

If you are using unfiltered water:

► Dispose of ice cubes that were produced 24 hours after

initial ice cube production.

-or-

If you are using filtered water:

► Dispose of ice cubes that were produced 48 hours after

initial ice cube production.

9.8.8 Cleaning the IceMaker*

There are various options for cleaning the IceMaker.

Cleaning is required in the following cases:

❑

Initial operation

❑

With mains connection:*

If out of use for more than 5 days.*

Ensure that the following conditions are met:

❑

IceMaker drawer is emptied.

❑

IceMaker drawer is in place.

❑

The IceMaker is activated.

First use or after a long period of non-use

Clean the IceMaker with the TubeClean function.

► Put an empty 1.5 l vessel (max. height 10 cm) in the

drawer under the IceMaker.

► Activate the TubeClean function.

▷ The rinse process is prepared (max. 60 min.): Symbol

flashes.

▷ Water pipes are rinsed: Symbol flashes.

▷ Rinsing process is complete: Function turns off automati‐

cally.

► Remove the IceMaker drawer and remove the container.

► Clean the IceMaker drawer with warm water and a little

detergent.

► Push the IceMaker drawer in.

▷ The system starts making ice cubes automatically.

Without a water filter*

► Dispose of any ice cubes that were made 24 hours after

the first ice cubes.*

With a water filter:*

► Dispose of any ice cubes that were made 48 hours after

the first ice cubes.*

-or-

► Draw 2 l of water from the InfinitySpring and dispose of

it.*

If cleaning is required

Clean the IceMaker by hand.

► Remove the IceMaker drawer and clean with warm water

and a little detergent.

► Push the IceMaker drawer in.

▷ The system starts making ice cubes automatically.

9.8.9 After cleaning

► Wipe the appliance and the components dry.

► Connect and switch on the appliance.

► Activate SuperFrost (see 7.2Appliance functions) .

The temperature is cold enough:

► Place the food inside.

► Repeat cleaning regularly.

10 Customer help

10.1 Technical specifications

Temperature range

Cooling 3°C to 9°C

BioFresh 0°C to 3°C

Fish & SeaF

ood*

-2°C to 0°C*

Possible settings :*

0°C | 0°C*

-2°C | 0°C*

-2°C | -2°C*

Freeze -26°C to -15°C

Maximum ice cube quantity / 24 hours

Freezer compart‐

ment

see type plate under “Freezing

capacity …/ 24 h”

Customer help

* Depending on model and options 47

Maximum loading weight for the equipment

Equipment Appliance

width

600 mm

(see

installa‐

tion

instruc‐

tions,

device

dimen‐

sions)

Appliance

width

700 mm

(see instal‐

lation

instruc‐

tions,

device

dimen‐

sions)

Appliance

width

750 mm

(see

installa‐

tion

instruc‐

tions,

device

dimen‐

sions)

Drawer on glass

shelf

(see 8.7.1 Drawer on

appliance base or

glass shelf)

15 kg -- 23 kg

Freezer section

partial pull-out*

(see 8.7.2 Drawer

on telescopic rails)

15 kg* 22 kg* 22 kg*

Ice cube production with IceMaker*

Ice cube produc‐

tion / 24 hours

At a temperature of -18 °C: 1.2 kg of

ice cubes

maximum ice

cube produc‐

tion / 24 hours

With the MaxIce function on: 1.5 kg of

ice cubes

Ice cube production with EasyTwist-Ice*

Time required at -18°C approx. 5.5 hours

Time required with SuperFrost activated approx. 3 hours

Time required to reach various temperatures with Vario‐

Temp*

Initial tempera‐

ture*

Target tempera‐

ture*

Time taken to reach

target temperature*

-18°C 0°C > 8 hours

-18°C 8°C > 12 hours

8°C 14°C > 6 hours

14°C -18°C > 4 hours

Lighting

Class

Light source

This product contains one or more energy

efficiency class G light sources.

LED

The appliance may contain light sources with different

energy efficiency classes. The lowest energy efficiency class

is indicated.

For appliances with a WiFi connection:

Frequency specification

Frequency band 2.4GHz

Maximum radiated

power

< 100 mW

Frequency specification

Purpose of the

wireless equipment

Integration in the local WiFi network

for data communication

10.2 Operating noises

The appliance makes different noises when it is on.

At higher temperatures the appliance uses less energy

but works for longer. It is quieter.

At lower temperatures the food is cooled faster. It is

louder.

Examples:

•

Functions on (see 7.2Appliance functions)

•

Fan running

•

Food recently added

•

High ambient temperature

•

Door open for a while

Noise

Possible cause Type of noise

Bubbling and

splashing

Coolant flowing

into the cooling

circuit.

Normal operating

noise

Hissing Coolant sprays

into the cooling

circuit.

Normal operating

noise

Humming The appliance

is cooling. The

volume depends

on the cooling

output.

Normal operating

noise

Suction noises Soft-closing door

is being opened

and closed.

Normal operating

noise

Humming and

rustling

The fan is running. Normal operating

noise

Clicking Components are

switched on and

off.

Normal switching

noise

Rattling or

humming

Valves or flaps are

working.

Normal switching

noise

Noise Possible

cause

Type of noise Lifting

Vibration Improper

setup

Defective

noise

Level the

appliance

using the

adjustable

feet.

Rattling Components,

items inside

the appliance

Defective

noise

Secure

components.

Leave

enough

space

between the

items.

10.3 Technical fault

Your appliance is designed and built to ensure it works reli‐

ably and has a long service life. In the unlikely event that

a fault occurs during operation, please check whether it is

Customer help

48 * Depending on model and options

due to an operating error. If so, you will be charged for the

callout and repair costs even if it falls within the warranty

period.

You can fix the following faults yourself.

10.3.1 Appliance function

Defect Cause Remedy

The appliance is

not working.

→ The appliance is not switched on. ► Switch the appliance on.

→ The power plug is not properly

plugged into the socket.

► Check the power plug.

→ There is something wrong with the

power outlet fuse.

► Check the fuse.

→ Power cut ► Keep the appliance closed.

► Safeguarding food: Place cold packs on top of food or

use another freezer if the power cut lasts longer.

► Do not re-freeze defrosted food,

→ The IEC socket is not plugged into

the appliance correctly.

► Check the IEC socket.

Temperature is not

cold enough.

→ The appliance door is not closed

properly.

► Close the appliance door.

→ The ambient temperature is too

high.

► Problem solution: (see1.4 Appliance range of use)

→ The appliance was opened too

many times or for too long.

► Wait to see if the required temperature corrects itself.

If not, contact Customer Service. (see 10.4 Customer

Service)

→ Too much fresh food was placed

inside without SuperFrost.

► Solution: (see SuperFrost)

→ The temperature is set incorrectly. ► Turn down the temperature and check after 24 hours.

→ The appliance is too close to a heat

source (oven, radiator, etc).

► Move the appliance or the heat source.

The door seal is

defective or needs

to be replaced for

another reason.

→ The door seal can be replaced. It

can be replaced without the need

for special tools.

► Contact Customer Service. (see 10.4 Customer Service)

The appliance

builds up too much

ice or condensa‐

tion.

→ The door seal may have slipped out

of its groove.

► Check that the door seal is well fitted in the groove.

The exterior

surfaces of the

appliance are

warm.*

→ The heat of the refrigeration circuit

is used to avoid condensation.

► This is normal.

10.3.2 Features

Defect Cause Remedy

You cannot acti‐

vate the IceMaker.*

→ The appliance and therefore the

IceMaker are not connected.

► Connect the appliance (see the Installation Guide).

The IceMaker is

not producing ice

cubes.*

→ The IceMaker is not on. ► Activate the IceMaker.

→ The drawer of the IceMakers is not

connected properly.

► Push the drawer in correctly.

→ The water connection is not open. ► Open the water connection.*

The InfinitySpring

is not working.*

→ Ice cube tray rotates. ► Try again after 1 minute.*

→ There is air in the water system. ► Bleed the water system. (see 4.2 Putting InfinitySpring

into operation*)

Customer help

* Depending on model and options 49

Defect Cause Remedy

→ The water connection is not open. ► Open the water connection.

The water flow

through the Infin‐

itySpring is irreg‐

ular.*

→ The aerator is dirty. ► Replace aerator. Contact Customer Service.

(see 10.4 Customer Service)

HydroBreeze is not

keeping refriger‐

ated goods moist.*

→ The HydroBreeze is not on. ► Activate the HydroBreeze.

→ There is not enough water in the

water tank.

► Fill the water tank.

→ There is dirt in front of the concen‐

trator.

► Clean the HydroBreeze.

→ The water tank is not clicked into

place properly.

► Click the water tank into place.

→ The compartment cover of the Fruit

& Vegetable Safe is set to “low

humidity”.

► The compartment cover of the Fruit & Vegetable Safe is

set to “high humidity”.

The internal light

does not come on.

→ The appliance is not switched on. ► Switch the appliance on.

→ The door was open for longer than

15 minutes.

► Interior lighting switches off automatically after

about 15 minutes when the door is open.

→ The LED interior light is faulty or

the lid is damaged.

► Contact Customer Service. (see 10.4 Customer Service)

10.4 Customer Service

First check whether you can rectify the fault yourself

(see 10 Customer help) . If you cannot rectify the problem,

contact Customer Service.

You can find the address in the enclosed brochure “Liebherr-

Service” or at home.liebherr.com/service.

WARNING

Unprofessional repair!

Injuries.

► Have any repairs and action - not expressly specified -

on the appliance and mains cable carried out by service

personnel only. (see9 Maintenance)

► A damaged mains cable may only be replaced by the

manufacturer, the manufacturer’s Customer Service or a

similarly qualified person.

► In the case of appliances with an IEC connector, the

change may be made by the customer.

10.4.1 Contacting Customer Service

Make sure that the following appliance information is avail‐

able:

❑

Appliance name (model and index)

❑

Service no. (Service)

❑

Serial no. (S no.)

► Call up the appliance information via the display.

(see Device information)

-or-

► Refer to the type plate for appliance information.

(see 10.5 Model plate)

► Note down the appliance information.

► Notify customer service: Report errors and the appliance

information.

▷ This will help us to provide you with a faster, more accu‐

rate service.

► Follow further instructions from Customer Service.

10.5 Model plate

The model plate is behind the drawers on the inside of the

appliance.

Fig. 218

(1)

Appliance description (3) Serial no.

(2) Service no.

► Note the data on the model plate.

11 Shutting down

► Empty the appliance.

► Deactivate IceMaker. (see Deactivating the IceMaker and

MaxIce) *

► Deactivate HydroBreeze. (see Deactivating HydroBreeze)

► Switch off appliance. (see Switching the appliance off

and on)

► Pull the mains plug out of the socket.

► Remove the IEC socket if required: Pull the IEC socket out

of the appliance plug and move it to the left and right at

the same time.

► Clean appliance. (see 9.8Cleaning the appliance)

► Leave the door open, so that no unpleasant odours arise.

Shutting down

50 * Depending on model and options

12 Disposal

12.1 Preparing appliance for disposal

Liebherr uses batteries in some of its appli‐

ances. In the EU, for environmental reasons,

legislation obliges the end user to remove

these batteries before disposing of old appli‐

ances. If your appliance contains batteries, a

corresponding notice is attached.

Lamps If you can remove the lamps yourself without

destroying them, also remove these before

disposal.

► Take the appliance out of operation.

► If possible: remove lamps without destroying them.

12.2 Disposing of the appliance in an

environmentally friendly manner

The appliance still contains

valuable materials and must

be disposed of separately from

unsorted municipal waste.

Dispose of batteries separately

from the old appliance. To do

this, you can return the batteries

free of charge to retailers as

well as recycling centres and

collection centres for recyclable

materials.

Lamps Dispose of removed lamps

via the respective collection

systems.

For Germany: You can dispose of the appli‐

ance free of charge via the

class 1 collection containers

at the local recycling and

recyclable material collection

centres. When purchasing a new

fridge/freezer, if the sales area

> 400 m

, retailers will also take

back the old appliance free of

charge.

WARNING

Leaking coolant and oil!

Fire. The coolant contained in the appliance is eco-friendly,

but also flammable. The oil contained in the appliance

is flammable. Escaping coolant and oil can ignite if the

concentration is high enough and in contact with an

external heat source.

► Do not damage the pipelines of the coolant circuit and

the compressor.

► Observe the notes on transporting the appliance.

► Transport the appliance without damaging it.

► Dispose of batteries, lamps and the appliance according

to the above specifications.

Disposal

* Depending on model and options 51

home.liebherr.com/fridge-manuals

fridge/freezer with BioFresh

Issue date: 20250514

Part number index: 7083574-00

Liebherr-Hausgeräte Marica EOOD

Bezirk Plovdiv

4202 Radinovo

Bulgarien

Liebherr ENERGY HERO data-next-head> Fridge-freezer

Product's Documents

Operating instructions

Specifications

Liebherr ENERGY HERO Questions and Answers
