产品配色与工艺说明图
Product Colour,Material & Finishing Specfications
Tolerance
公差
Product Model
产品型号
Part Number
物料编号
Material
材质
Remark
备注
Original Designer
原设计师
Verifing
审核
Date
日期
Color
颜色
Membrane
表面工艺
Dimension
尺寸
Scale
比例
Job No.
图档编码
Revision
版本号
Change Description
版本变更描述
Brand
品牌
Product Type
产品类
Description
描述
1.0
1:1
说明书
2026.6.23
中性MQ10
(MQ10)
128g哑粉纸
双面印 风琴折 四色印刷
手机正确充电方式
① 确认无线充电器连接电源，并处于待机状态。
注：本产品需另外购买PD 30W以上的适配器使用，请根据适配器接口选择是
否使用转接头。
② 将带有磁吸无线充电功能的手机放置在充电板上，充电板会自动
吸附对位。
* 本产品同时支持对不带磁吸功能的无线充电设备进行充电。
Note: This product requires an additional purchase of a PD 30W or
higher adapter for use. Please select whether to use an adapter based
on the adapter interface.
① Connect the power adapter to socket.
② Connect adapter to the Type-C interface.
Fast
Wireless Charger
User Manual
用户手册
Thanks for choosing us！
感谢您购买本产品！
Specification
Connect To Power Adapter Charging Mode
This product is a magnetic wireless charger that enables fast
charging for smartphones, allowing you to easily enjoy the
endless fun of digital devices.
Please read this manual carefully before using the product and
keep it properly for future reference.
本产品是一款磁吸无线充电器，可以对智能手机进行快速充
电功能，能让您轻松体验数码产品的无限乐趣。
使用本产品前请认真阅读本手册并妥善保存，以备查阅。
规格参数
连接适配器充电
磁吸无线充电器
① Make sure the wireless charger dock connect to the power supply.
② Place the phone with the magnetic wireless charging function on
the charging plate, and the charging plate will automatically align
and attach.
注意事项
1、 请勿挤压或碰撞。
2、 请勿自行拆卸或投入火中、水中,避免造成短路漏电。
3、 请勿在严重高温、潮湿或腐蚀性环境下使用无线充电器，避免
损坏电路出现漏电现象。
4、 请勿与带磁条或者芯片的磁卡 (身份证、银行卡等) 放置太近,
避免造成磁卡失效。
5、 请保持植入医疗设备 (心脏起搏器、植入性耳蜗等) 与无线充
电器之间的距离至少为20cm,以避免对医疗设备造成潜在干扰。
6、 应看管好儿童,以确保他们不将无线充电器当成玩具来玩,以
避免不必要的意外。
说明书涉及图片均为示意图， 最终产品以实物为准。
内含：无线充电器、产品说明书。
1、 Do not squeeze or collisions.
2、 Do not disassemble or throw into fire or water, to avoid causing a
short circuit leakage.
3、 Do not use wireless charger in severely hot, humid or corrosive
environments, to avoid circuit damage and occurs leakage
phenomenon.
4、 Do not place too close with magnetic stripe or chip card (ID card,
bank cards, etc.) to avoid magnetic failure.
5、 Please keep the distance at least 20cm between implantable
medical devices ( pacemakers, implantable cochlear, etc. ) and the
wireless charger, to avoid potential interference with the medical
device.
6、 To take care of the children, to ensure that they won' t play the
wireless charger as a toy, to avoid unnecessary accidents.
The involved images are sketch maps, the final product as per the
material subjects.
Includes: wireless charger, user's manual.
Notes
输入： 5V⎓3A，9V⎓3A，12V⎓2.5A，15V⎓2A
输出： 25W MAX
频率： 115-205kHz, 360kHz
规格尺寸： φ58×8mm
接收距离： ≤3mm
电力转换： ≥72%
产品重量： 53g
Input： 5V⎓3A，9V⎓3A，12V⎓2.5A，15V⎓2A
Output： 25W MAX
Frequency： 115-205kHz, 360kHz
Dimension： φ58×8mm
Charging distance： ≤3mm
Conversion： ≥72%
NW.： 53g
* The device also support wireless charging to other nonmagnatic
wireless charging function device.
产品外观
90*65mm
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception,which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20 cm between the radiator
and your body.
FCC Warning
3
2
1
磁吸无线充电区域 1.2M电源线 USB-C电源接口
3
2
1
2
1
2
1
Product Appearance
3
2
1
Magnetic wireless charging area
1.2M power cord USB-C power port
3
2
1
① 将电源适配器插在插座上。
② Type-C电源线一端连接适配器。
FCC警告
本设备符合FCC规则第15部分规定， 操作受以下两个条件的约束：
(1)本设备不得造成有害干扰；
(2)本设备必须接受收到的任何干扰，包括可能导致意外操作的干
扰 。
任何未经合规责任方明确批准的更改或修改都可能导致用户操作
设备的权力失效。
注意：根据FCC规则第15部分规定，本设备已经过测试，并符合B类
数字设备的限值要求。 这些限制旨在提供合理的保护，防止住宅安
装中的有害干扰。 本设备会产生并使用射频能量，如果未按照说明
安装和使用，可能会对无线电通信造成有害干扰。 但是不能保证在
特定安装中不会发生干扰。如果本设备确实对无线电或电视接收造
成有害干扰（可通过关闭设备再打开来确定），我们鼓励用户尝试通
过以下一种或多种措施来纠正干扰：
• 重新定向或重新定位接收天线。
• 增加设备和接收器之间的分离。
• 将设备连接到与接收器连接的电路不同的电路上的出口。
• 咨询经销商或经验丰富的广播/电视技术人员寻求帮助。
FCC辐射暴露声明
该设备符合针对不受控制环境规定的FCC辐射暴露限值。
在安装和操作此设备时，应确保与散热器的距离至少为20厘米，且
避免靠近身体。
65.0 mm
90.0 mm
