Strong|Weak SPABMAF
Light
ECO
Self-cleaning
Stop
Rear|Move
Bidet|Move
Dry
Flush
Strong
Weak
Water Pressure
Nozzle Position
Water Temp.
Seat Temp.
Dryer Temp.
Rear
Front
Lid| Seat
Cold|Heat SPA
2.4G
Description Of The Remote Control
19
11
01. Stop/Shutdown
02. Rear washing / Oscillating washing
03. Bidet washing / Oscillating washing
04. Temperature Display
05. Drying
06. Open/close the lid/seat
Cold/Heat SPA
07. Flush
08. Decrease washing intensity
09. Increase washing intensity
10. Water temperature adjustment
11. Dryer temperature adjustment
12. Seat temperature adjustment
13. Washing position backward
14. Washing position forward
15. Bowel Movement Aid Function
16. Self-cleaning
17. Night light
18. ECO mode
19. Strong/Weak SPA
Description Of The Remote Control
01 02 03 04 05 06 07
08 09 10 11 12 13 14
15 16
17 18
19
Remote Control Operating Instructions
20
Remote Control Operating Instructions
Stop
Rear | Move
Bidet | Move
Dry
Flush
Strong | Weak SPA
Cold | Heat SPA
Open/close the
Lip or seat
BMAF
Self-cleaning
Nozzle Position
Water Pressure
Water Temp.
Dryer Temp.
Seat Temp.
Light
ECO
Press the button once to stop the current cleaning or drying functions.
Hold and press for 5 seconds to power off the toilet.
Switch from the current state to rear wash;
During washing, Press the button again switch to the moving wash mode.
Switch from the current state to bidet wash;
During washing, Press the button again switch to the moving wash mode.
Switch from the current state to drying mode.
Press the button once to activate the flushing function.
In Rear/Bidet wash mode, press this button to start strong/weak SPA
(Water pressure alternates).
In Rear/Bidet wash mode, press this button to start cold/heat SPA
(Water temperature alternates).
Switch from current state to Bowel Movement Aid;
Water temp 37℃/98℉, Water pressure max level.
Press this button the nozzle comes out for 120s;
press "Stop" anytime to exit.
In Rear wash or Bidet wash mode, press this button to adjust the
nozzle position; there are 6 positions in total.
In Rear wash or Bidet wash mode, press this button to adjust the
water pressure; there are 4 levels in total.
When no one is seated, press this button to control the opening or
closing of the lid and seat. According to the following cycle:
Adjust water temperature level; cycles through 4 levels.
Adjust dryer temperature level; cycles through 4 levels.
Adjust seat temperature level; cycles through 4 levels.
Press the button to turn the night light on or off.
Press the remote "ECO" button to enable Eco mode;
Seat temp stays at 28℃/82℉. Exit ECO mode to adjust seat temp.
Open Lid Open Seat Close Lid&Seat
1 2
3
Troubleshooting guide
21
Troubleshooting guide
Problem Cause Solution
Water supply hose is kinked.
Straighten the hose to remove the kink.
Angle valve is not fully
Poor flushing Turn on the angle valve fully.
turned on.
Filter is dirty. Clean the filter.
Angle valve is shut off.
Turn on the angle valve.
A power outage occurred.
Use a bucket to manually flush.
Not flushing
A water failure occurred.
Use a bucket to manually flush.
Wait until the previous cycle finishes
Previous cycle not finished.
then flush.
"Auto flushing" is set to "OFF"
Auto flushing
The seat switch will not turn
does not work
on unless the user is seated
properly.
"Auto pre-wetting" is set to
Set to "ON".
"OFF".
Auto pre-wetting
The seat switch will not turn
does not work
on unless the user is seated
properly.
The water temperature is not
Adjust the water temperature.
set properly.
Low water
temperature
When the temperature of the water supply or of the bathroom is low,
the water temperature may be low when first sprayed.
The seat temperature is not
Reset the seat temperature.
set properly.
Switch to functional mode and wait for
In energy saving mode.
5+ minutes.
Switch to functional mode and wait for
In standby mode.
Low seat
5+ minutes.
temperature
When seated, after 10
minutes, the temperature
begins to decrease. Then Stand up from the seat and then sit
after 5 minutes, the toilet again.
seat heater turns to level 1
and stays.
Low air
The air temperature is not
Reset the air temperature.
temperature
set properly.
Sit back on the toilet seat.
Set to "ON".
Sit back on the toilet seat.
Power off
Turn on the power.
The seat switch will not turn
on unless the user is seated
properly.
Stuck due to impurities
Remove impurities.
Spray rod does
not operate or
Press the "STOP" button on the remote
water pressure
Water failure has occurred.
control and wait until water service is
is low
restored.
Angle valve is shut off Turn on the angle valve.
Filter is dirty
Clean the filter.
Water supply set to a low
Set the water pressure to required
pressure.
range.
Angle valve is not fully open.
Water filter is clogged. Clean the filter.
The water supply to the toilet
Cease using other fixtures and
is disrupted by other running
then flush toilet
water fixtures
Waste material
does not flush
The original supplied angle Install the original angle valve which
down completely
valve was not installed has a filter included.
Flush the toilet again. If the bowl unit
Flushing may be difficult
is not cleansed with flushing, remove
depending the consistency
the stains with a brush or similar
of the waste material.
instrument.
Inspect to see if any nuts in
Firmly tighten the nuts.
Water is leaking
the connection are loose.
from the plumbing
Close the angle valve and consult
connections
Water leak does not stop.
service provider.
There are black
Ammonia in urine may cause
stains on or around
black stains.
If urine has splashed on the bowl unit
or floor, wipe it up immediately.
the bowl unit
This is a result of growth of
There is black or
airborne fungal spores or
Clean with a (non-abrasive) neutral
pink slime on the
bacteria that feed on waste
toilet detergent.
toilet bowl surface
residue on the toilet bowl.
There is residue
Oil and other hard-to-see
Clean with a (non-abrasive) neutral
on the bowl
grime may stick to the bowl
toilet detergent.
unit surface
unit surface.
Problem Cause Solution
22
Sit back on the toilet seat.
Turn on the angle valve fully.
Night light
Night light function is "OFF".
does not work
The positive and negative
direction of the batteries is
Remote control
incorrect.
does not work
Batteries have expired
The drying feature stops automatically after about 3 minutes of
continuous use.
The cleaning feature stops automatically after about 2 minutes of
continuous use.
Stops in the
middle of use
The seat switch has difficulty detecting that the seat is in use.
Sit back on the toilet seat. If the user gets up slightly from the seat,
or sits forward on the seat, the seating switch may temporarily stop
detecting the user‘s presence.
Water comes out
When the user sits on the toilet seat, water comes out for several
unexpectedly from
seconds while the water is warmed up. This is normal function.
the spray rod
When flushing, a When the toilet is flushed together with waste material, the sound is
gurgling sound a result of air, waste material and water being pulled through the
canbe heard. system. This is normal function.
Set to "ON".
Re-load batteries.
Load new batteries.
Caution
Please disconnect the power, wait for 30 seconds, then reconnect the
power to restore to factory settings.
If the problem still cannot be resolved, please disconnect the power
and contact service providers.
Problem Cause Solution
23
