❶ ❷ ❸
❹
❺
❻ ❼
❽
❾ ❿
⓫
❶
❶
❷
❷
❶
❶
❷
❷
❶
❶
❷
❷
❶
❶
❷
❷
❶
❶
❷
❷
❶
❶
❷
❷
Specifications
05
Size: 101.5*264*161.2 mm
Weight: 721 g
Operating Temperature: -20°C to 55°C (-4°F to 131°F)
Charging Temperature: 0°C to 45°C (32°F to 113°F)
Operating Humidity: 10%~90%
Weather Resistance: IP66 certied weatherproof
For more specications, visit https://reolink.com/.
Troubleshooting
06
Camera is Not Powering On
If your camera is not turning on, please apply the following solu-
tions:
Charge the battery with a DC 5V/2A power adapter. When the
blue light is on, the battery is fully charged.
If the problem is not solved, please contact Reolink Support.
Failed to Connect to Wi-Fi During Initial Setup Process
If the camera fails to connect to Wi-Fi, please try the following
solutions:
• Ensure that you have entered the correct Wi-Fi password.
• Put the camera closer to your router to ensure a strong Wi-Fi
signal.
• Change the encryption method of the Wi-Fi network to WPA2-
PSK/WPA-PSK on your router interface.
• Change your Wi-Fi SSID or password and make sure that SSID is
within 31 characters and password is within 64 characters.
• Set your password using only the characters available on the
keyboard.
If the problem is not solved, please contact Reolink Support.
Important Safety Instructions
07
Please read the instructions carefully before using the camera.
For tips on extending battery life, visit our support post:
https://support.reolink.com/hc/en-us/articles/360006991893
1. Charge the battery with a standard and high-quality DC 5V
battery charger or Reolink solar panel. It is not compatible with
solar panels from any other brands.
2. Replace only with the same or equivalent type of equipment
and accessories recommended by the manufacturer. Using
an incorrect type poses an explosion risk.
3. Do not remove a built-in battery from the camera.
4. Charge the battery only in temperatures between 0°C and
45°C. And use it only in temperatures ranging from -20°C and
55°C.
5. Do not charge, use or store a battery camera near heat
sources, such as space heaters, cooking surfaces, cooking
appliances, irons, radiators, or replaces. Extreme heat may
cause an explosion.
6. Do not expose the camera with a battery to extremely low air
pressure environments, as this may cause an explosion.
7. Do not place the camera with a battery in hot wilderness areas
or expose it to lightning, as this poses a risk of re.
8. Do not hit or heavily compress the camera with a battery, as
this poses a risk of re or explosion.
9. Do not use the battery if it appears damaged, swollen, or
compromised in any way (e.g., leaking, emitting odors, dented,
corroded, rusted, cracked, swollen, melted, or scratched).
10. Keep the camera and battery away from children.
11. Do not ingest or swallow battery. If the battery is ingested or
swallowed, it can cause severe internal burns and damage.
Seek immediate medical attention if you suspect the battery
has been ingested or placed inside any part of the body.
12. Do not attempt to disassemble, repair, or alter the camera or
battery by yourself.
13. Keep the charging port dry, clean and free of any debris.
Cover it with the rubber plug after the battery is fully charged.
14. Always follow the local safety laws and regulations when
using the camera.
15. Always follow the local waste and recycling laws to dispose of
used batteries.
16. The light source of this luminaire is not replaceable; when the
light source reaches its end of life the whole luminaire shall be
replaced.
Legal Discalimer
08
To the maximum extent permitted by applicable law, this
document and the product described, with its hardware,
software, rmware, and services, are delivered on an "as-is" and
"as-available" basis, with all faults and without warranty of any
kind. Reolink disclaims all warranties, express or implied, including
but not limited to, warranties of merchantability, satisfactory
quality, tness for a particular purpose, accuracy, and non-
infringement of third-party rights. In no event will Reolink, its
directors, ofcers, employees, or agents be liable to you for any
special, consequential, incidental or indirect damages, including
but not limited to damages for loss of business prots, business
interruption, or loss of data or documentation, in connection with
the use of this product, even if Reolink has been advised of the
possibility of such damages.
To the extent permitted by applicable law, your use of the Reolink
products and services is at your sole risk and you assume all
risks associated with internet access. Reolink does not take any
responsibilities for abnormal operation, privacy leakage or other
damages resulting from cyber attacks, hacker attacks, virus
inspections, or other internet security risks. However, Reolink will
provide timely technical support if required.
The laws and regulations related to this product vary by
jurisdiction. Please check all relevant laws and regulations in your
jurisdiction before using this product to ensure that your use
conforms to the applicable law and regulation. During the use
of the product, you must comply with relevant local laws and
regulations. Reolink is not responsible for any illegal or improper
use and its consequences. Reolink is not liable in the event that
this product is used with illegitimate purposes, such as third-
party rights infringement, medical treatment, safety equipment,
or other situations where the product failure could lead to death
or personal injury, or for weapons of mass destruction, chemical
and biological weapons, nuclear explosion, and any unsafe
nuclear energy uses or anti-humanity purposes. In the event of
any conicts between this manual and the applicable law, the
latter prevails.
Notication of Compliance
09
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation. Changes or
modications not expressly approved by the party responsible
for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
FCC Radiation Exposure statement
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between
the radiator & your body.
ISED Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the device.
This equipment should be installed and operated with a
minumum distance of 20 cm between the radiator and your
body.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Cet équipement doit être installé et utilisé avec une distance
minimale de 20 cm entre la source de rayonnement et votre
corps.
MODIFICATION:
Any changes or modications not expressly
approved by the grantee of this device could void the user's
authority to operate the device.
MODIFICATION :
les changements ou modications non
expressément approuvés par le fournisseur de licence de
l'appareil sont susceptibles d'annuler l'autorisation accordée à
l'utilisateur de se servir de l'équipement.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
Operation of 5150-5350 MHz is restricted to indoor use only.
Le fonctionnement de 5150-5350 MHz est limité à une utilisation
en intérieur uniquement.
Hereby, REOLINK INNOVATION LIMITED declares that this device is
in compliance with Cyber Security (Security Standards for Smart
Devices) Rules 2025. For the Statement of Compliance, visit the
Web site https://reolink.com/product-compliance/.
Limited Warranty
This product comes with a 2-year limited warranty that is
valid only if purchased from Reolink Ofcial Store or a Reolink
authorized reseller. Learn more:
https://reolink.com/warranty-and-return/.
NOTE:
We hope that you enjoy the new purchase. But if you are
not satised with the product and plan to return, we strongly
suggest that you reset the camera to factory default settings
and take out the inserted SD card before returning.
Terms and Privacy
Use of the product is subject to your agreement to the Terms of
Service and Privacy Policy at reolink.com
58.03.001.0908
Terms of Service
By using the Product Software that is embedded on the Reolink
product, you agree to the terms&conditions between you and
Reolink. Learn more: https://reolink.com/terms-conditions/
Technical Support
If you need any technical help, please visit our ofcial support
site and contact our support team before returning the products,
https://support.reolink.com.
Trademarks Acknowledgement
"Reolink" and other Reolink's trademarks and logos are the
properties of Reolink. Other trademarks and logos mentioned are
the properties of their respective owners.
