7.4 cu. ft. Top Mount Refrigerator
ERT74MEW, ERT74MEB, ERT74MES
EN
EN - 2
Thank you for choosing this product.
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
EN - 3
CONTENTS
1 SAFETY INSTRUCTIONS ............................................................................... 4
1.1 General Safety Warnings ...............................................................................................4
1.2 Installation warnings .......................................................................................................9
2 DESCRIPTION OF THE APPLIANCE .......................................................... 11
3 USING THE APPLIANCE .............................................................................. 12
3.1 Information on Less Frost Technology ..........................................................................12
3.2 Thermostat Setting .......................................................................................................12
3.3 Temperature Settings Warnings ...................................................................................12
3.4 Accessories ..................................................................................................................13
3.4.1 Ice Tray (In some models) .........................................................................................13
3.4.2 The Plastic Scraper (In some models) ......................................................................13
3.4.3 The Bottle Holder (In some models) ..........................................................................13
4 FOOD STORAGE ........................................................................................... 13
4.1 Refrigerator Compartment ............................................................................................13
4.2 Freezer Compartment ..................................................................................................14
5 CLEANING AND MAINTENANCE ................................................................ 17
5.1 Defrosting .....................................................................................................................18
6 SHIPMENT AND REPOSITIONING .............................................................. 19
6.1 Transportation and Changing Positioning ....................................................................19
6.2 Repositioning the Door .................................................................................................19
7 BEFORE CALLING AFTER-SALES SERVICE ........................................... 19
8 TIPS FOR SAVING ENERGY ........................................................................ 20
EN - 4
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the instructions.
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
EN - 5
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
– sta kitchen areas in shops, oces and other
working environments.
– farm houses and by clients in hotels, motels and
other residential type environments.
– bed and breakfast type environments.
– catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 10 amperes. If there is no such socket in your
house, please have one installed by an authorized
electrician.
EN - 6
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
• Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance
of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children
(3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older
children (8-14 years old) and vulnerable people can
use appliances safely after they have been given
appropriate supervision or instruction concerning
use of the appliance. Very vulnerable people are
not expected to use appliances safely unless
continuous supervision is given.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorized service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 6500 ft.
EN - 7
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a signicant increase of the temperature in the
compartments of the appliance.
• Regularly clean surfaces that can come in contact
with food and accessible drainage systems.
• Store raw meat and sh in suitable containers in the
refrigerator so that it is not in contact with or drip
onto other food.
• Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
• One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
• If the refrigerating appliance is left empty for long
periods, switch o, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
• WARNING: The refrigeration system is under high
pressure. Do not tamper with it. Contact qualied
service personal before disposal.
• CAUTION To prevent a child from being entrapped,
keep out of reach of children and not in the vicinity
of freezer or refrigerator.
• WARNING: Risk of child entrapment. Before you
throw away your old refrigerator or freezer:
• Take o the doors.
EN - 8
• Leave the shelves in place so that children may not
easily climb inside.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
EN - 9
1.2 Installation warnings
Before using your refrigeratorfor the rst
time, please pay attention to the following
points:
• The operating voltage for your refrigerator
is 115-127 V at 60Hz.
• The plug must be accessible after
installation.
• Your refrigeratormay have an odor
when it operatesfor the rst time. This is
normal and the odor will fade when your
refrigerator starts to cool.
• Before connecting your refrigerator,
ensure that the information on the data
plate (voltage and connected load)
matches that of the mains electricity
supply. If in doubt, consult a qualied
electrician.
• Insert the plug into a socket with an
ecient ground connection. If the socket
has no ground contact or the plug does
not match, we recommend you consult a
qualied electrician for assistance.
• The appliance must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
appliance (the name plate is located on
the inside left of the appliance).
• Place your refrigerator where it will not be
exposed to direct sunlight.
• Your refrigerator must never be used
outdoors or exposed to rain.
• Your appliance must be at least 20 inches
away from stoves, gas ovens and heater
cores, and at least 2 inches away from
electrical ovens.
• If your refrigerator is placed next to a
deep freezer, there must be at least 1
inch between them to prevent humidity
forming on the outer surface.
• Do not cover the body or top of
refrigerator with lace. This will aect the
performance of your refrigerator.
• Clearance of at least 6 inches is required
at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the
appliance.
• Clean the appliance thoroughly before
use (see Cleaning and Maintenance).
• Before using your refrigerator, wipe all
parts with a solution of warm water and
a teaspoon of sodium bicarbonate. Then,
rinse with clean water and dry. Return all
parts to the refrigerator after cleaning.
• Use the adjustable front legs to make
sure your appliance is level and stable.
You can adjust the legs by turning them
in either direction. This must be done
before placing food in the appliance.
• When the product is running, high
temperature can be noticed on the side
panels. This situation is normal.
• In order for the product to work eciently,
there must be some gap around it for
air circulation. If you are going to place
the product in a recessed area on the
wall, make sure that the gap should be 4
inches between top surface and ceiling,
2 inches between walls and side panels.
The distance between the appliance
and back wall must be a maximum of 3
inches.
• During Usage
• Do not connect your refrigerator to
the mains electricity supply using an
extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by
adults. Do not allow children to play with
the appliance or hang o the door.
• Never touch the power cord/plug with wet
hands. This may cause a short circuit or
electric shock.
• Do not place glass bottles or cans in the
ice-making compartment as they will
burst when the contents freeze.
• Do not place explosive or ammable
material in your fridge. Place drinks with
high alcohol content vertically in the
EN - 10
fridge compartment and make sure their
tops are tightly closed.
• When removing ice from the ice-making
compartment, do not touch it. Ice may
cause frost burns and/or cuts.
• Do not touch frozen goods with wet
hands. Do not eat ice-cream or ice cubes
immediately after they are removed from
the ice-making compartment.
• Do not re-freeze thawed frozen food. This
may cause health issues such as food
poisoning.
Old and Out-of-order Fridges
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause an
accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridges.
Notes:
• Please read the instruction manual
carefully before installing and using your
appliance.
• Follow all instructions on your appliance
and instruction manual, and keep this
manual in a safe place to resolve the
problems that may occur in the future.
• This appliance is produced to be used
in homes and it can only be used in
domestic environments and for the
specied purposes. It is not suitable for
commercial or common use.
• This appliance is produced to be used in
houses and it is only suitable for cooling
/ storing foods. It is not suitable for
commercial or common use and/or for
storing substances except for food.
EN - 11
2 DESCRIPTION OF THE
APPLIANCE
This appliance is not intended to be used
as a built-in appliance.
1
2
3
5
6
7
4
8
10
9
11
A
B
This presentation is only for
information about the parts of the
appliance. Parts may vary according to the
appliance model.
A) Freezer compartment
B) Refrigerator compartment
1) Ice box tray
2) Plastic ice scraper *
3) Freezer shelf
4) Thermostat box
5) Refrigerator shelves
6) Crisper cover
7) Crisper
8) Leveling feet
9) Bottle shelf
10) Door shelves
11) Egg holder
* In some models
General notes:
Fresh Food Compartment (Fridge): Most
ecient use of energy is ensured in the
conguration with the drawers in the bottom
part of the appliance, and shelves evenly
distributed, position of door bins does not
aect energy consumption.
Freezer Compartment (Freezer): Most
ecient use of energy is ensured in the
conguration with the drawers and bins are
on stock position.
EN - 12
3 USING THE APPLIANCE
3.1 Information on Less Frost
Technology
Thanks to the wrap around evaporator,
Less Frost technology oers more ecient
cooling, less manual defrost requirement,
and more exible storage room.
3.2 Thermostat Setting
The thermostat automatically regulates the
temperature inside the cooler and freezer
compartments. Refrigerator temperatures
can be obtained by rotating the knob
to higher numbers; 1 to 3, 1 to 5 or SF
(Maximum numbers on the thermostat
depends on your product.)
Important note: Do not try to rotate
the knob beyond position 1, it will stop
your appliance from working.
Super switch
(In some models)
Thermostat knob
Lamp cover
(The images are representative)
Thermostat settings:
1 – 2 : For short-term storage of food
3 – 4 : For long-term storage of food
5 : Maximum cooling position. The
appliance will work longer.If required,
change the temperature setting.
If device has SF position:
• Turn the knob to SF to freeze fresh
food quickly. In this position, the freezer
compartment will operate at lower
temperatures. After your food freezes,
turn the thermostat knob to its normal
use position. If you do not change the SF
position, your appliance will automatically
return to its last used thermostat position
according to the time indicated in the
note. Return the thermostat switch to
the SF position and return it to normal
use according to the time indicated in
the note.If the thermostat switch is in the
SF position when your appliance is rst
started, your appliance willautomatically
return to the operation in the thermostat-3
position according to the time indicated in
the note.
Super freezing: This switch shall be used
as superfreeze switch. For maximum
freezing capacity, please turn on this switch
before 24 hours placing fresh food. After
placing fresh food in the freezer, 24 hours
ON position is generally sucient. In order
to save energy, please turn o this switch
after 24 hours from placing and fresh food.
Winter Switch: If ambiant temperature
is below 61
o
F, this switch shall be used
as winter switch and it keeps your fridge
above 32
o
F while freezer is below 0
o
F in
low ambiants.
3.3 Temperature Settings Warnings
• Your appliance is designed to operate in
the ambient temperature ranges stated
in the standards, according to the climate
class stated in the information label. It
is not recommended that your fridge is
operated in the environments which are
outside of the stated temperature ranges.
This will reduce the cooling eciency of
the appliance.
• Temperature adjustments should be
made according to the frequency of
door openings, the quantity of food kept
inside the appliance and the ambient
temperature in the location of your
appliance.
• When the appliance is rst switched on,
allow it to run for 24 hours in order to
reach operating temperature. During this
time, do not open the door and do not
keep a large quantity of food inside.
• A 5 minute delay function is applied
to prevent damage to the compressor
of your appliance when connecting
or disconnecting to mains, or when
an energy breakdown occurs. Your
appliance will begin to operate normally
after 5 minutes.
EN - 13
3.4 Accessories
Visual and text descriptions in the
accessories section may vary according
to the model of your appliance.
3.4.1 Ice Tray (In some models)
• Fill the ice tray with water and place in
the freezer compartment.
• After the water has completely frozen,
you can twist the tray as shown below to
remove the ice cubes.
3.4.2 The Plastic Scraper
(In some models)
After some time, frost will build up in certain
areas of the freezer. The frost
accumulated in the freezer
should be removed regularly.
Use the plastic scraper
provided, if necessary. Do not
use sharp metal objects for this
operation. They could puncture the
refrigerator circuit and cause irreparable
damage to the unit.
3.4.3 The Bottle Holder (In some models)
Use the bottle holder to prevent
bottles from slipping or falling over.
Visual and text descriptions in
the accessories section may vary
according to the model of your
appliance.
4 FOOD STORAGE
4.1 Refrigerator Compartment
• To reduce humidity and avoid the
consequent formation of frost, always
store liquids in sealed containers in the
refrigerator. Frost tends to concentrate in
the coldest parts of the evaporating liquid
and, in time, your appliance will require
more frequent defrosting.
• Cooked dishes must remain covered
when they are kept in the fridge.Do
not place warm food in fridge.Place
them when they are cool, otherwise the
temperature/humidity inside the fridge will
increase, reducing the fridge’s eciency.
• Make sure no items are in direct contact
with the rear wall of the appliance as
frost will develop and packaging will stick
to it. Do not open the refrigerator door
frequently.
• We recommend that meat and clean sh
are loosely wrapped and stored on the
glass shelf just above the vegetable bin
where the air is cooler, as this provides
the best storage conditions.
• Store loose fruit and vegetable items in
the crisper containers.
• Storing fruit and vegetables separately
helps prevent ethylene-sensitive
vegetables (green leaves, broccoli,
carrot, etc.) being aected by ethylene-
releaser fruits (banana, peach, apricot,
g etc.).
• Do not put wet vegetables into the
refrigerator.
• Storage time for all food products
depends on the initial quality of the food
and an uninterrupted refrigeration cycle
before refrigerator storage.
• Water leaking from meat may
contaminate other products in the
refrigerator. You should package meat
products and clean any leakages on the
shelves.
• Do not put food in front of the air ow
passage.
EN - 14
• Consume packaged food before the
recommended expiry date.
• Do not allow food to come into contact
with the temperature sensor, which is
located in the refrigerator compartment,
in order to keep the refrigerator
compartment at optimum temperature.
• For normal working conditions, it will
be sucient to adjust the temperature
setting of your refrigerator to 39 °F.
• The temperature of the fridge
compartment should be in the range of
32-46 °F, fresh foods below 32 °F are
iced and rotted, bacterial load increases
above 46 °F, and spoils.
• Do not put hot food in the refrigerator
immediately, wait for the temperature
to pass outside. Hot foods increase the
degree of your refrigerator and cause
food poisoning and unnecessary spoiling
of the food.
• Meat, sh, etc. should be store in the
chiller compartment of the food, and the
vegetable compartment is preferred for
vegetables. (if available)
• To prevent cross contamination, meat
products, fruits and vegetables should
not be stored together.
• Food should be placed in the refrigerator
in closed containers or covered to
prevent moisture and odors.
The table below is a quick guide to show
you the most ecient way to store the
major food groups in your refrigerator
compartment.
Food
Maximum
storage time
How and where to
store
Vegetables
and fruits
1 week Vegetable bin
Meat and
sh
2 - 3 days
Wrap in plastic foil,
bags, or in a meat
container and store
on the glass shelf
Fresh
cheese
3 - 4 days
On the designated
door shelf
Butter and
margarine
1 week
On the designated
door shelf
Food
Maximum
storage time
How and where to
store
Bottled
products
e.g. milk
and
yoghurt
Until the
expiry date
recommended
by the
producer
On the designated
door shelf
Eggs 1 month
On the designated
egg shelf
Cooked
food
2 days All shelves
NOTE:
Potatoes, onions and garlic should not
be stored in the refrigerator.
4.2 Freezer Compartment
• The freezer is used for storing frozen
food, freezing fresh food, and making ice
cubes.
• Food in liquid form should be frozen
in plastic cups and other food should
be frozen in plastic folios or bags.For
freezing fresh food; wrap and seal fresh
food properly, that is the packaging
should be air tight and shouldn’t leak.
Special freezer bags, aluminum foil
polythene bags and plastic containers
are ideal.
• Do not store fresh food next to frozen
food as it can thaw the frozen food.
• Before freezing fresh food, divide it into
portions that can be consumed in one
sitting.
• Consume thawed frozen food within a
short period of time after defrosting
• Always follow the manufacturer's
instructions on food packaging when
storing frozen food. If no information is
provided, food should not be stored for
more than 3 months from the date of
purchase.
• When purchasing frozen food, make sure
that it has been stored under appropriate
conditions and that the packaging is not
damaged.
• Frozen food should be transported in
appropriate containers and placed in the
freezer as soon as possible.
• Do not purchase frozen food if there
EN - 15
packaging shows signs of humidity is
abnormal swelling. It is probable that
it has been stored at an unsuitable
temperature and that the contents have
deteriorated.
• The storage life of frozen food depends
on the room temperature, the thermostat
setting, how often the door is opened,
the type of food, and the length of time
required to transport the product from
the shop to your home. Always follow the
instructions printed on the packaging and
never exceed the maximum storage life
indicated.
• If the freezer door has been left open for
a long time or not closed properly, frost
will form and can prevent ecient air
circulation. To resolve this, unplug the
freezer and wait for it to defrost. Clean
the freezer once it has fully defrosted.
• The freezer volume stated on the label is
the volume without baskets, covers, and
so on.
• Do not refreeze thawed food. It may
pose a danger to your health and cause
problems such as food poisoning.
NOTE: If you attempt to open the freezer
door immediately after closing it, you
will nd that it will not open easily. This
is normal. Once equilibrium has been
reached, the door will open easily.
The table below is a quick guide to
show you the most ecient way to
store the major food groups in your freezer
compartment.
EN - 16
Meat and sh Preparation
Maximum storage time
(months)
Steak Wrap in foil 6 - 8
Lamb meat Wrap in foil 6 - 8
Veal roast Wrap in foil 6 - 8
Veal cubes In small pieces 6 - 8
Lamb cubes In pieces 4 - 8
Minced meat In packaging without using spices 1 - 3
Giblets (pieces) In pieces 1 - 3
Bologna sausage/salami Should be kept packaged even if it has a membrane
Chicken and turkey Wrap in foil 4 - 6
Goose and duck Wrap in foil 4 - 6
Deer, rabbit, wild boar In 5.5 Ib portions or as llets 6 - 8
Freshwater sh
(Salmon, Carp, Crane,
Catsh)
After cleaning the bowels and scales of the sh,
wash and dry it. If necessary, remove the tail and
head.
2
Lean sh (Bass, Turbot,
Flounder)
4
Fatty shes (Tuna,
Mackerel, Bluesh,
Anchovy)
2 - 4
Meat and sh Preparation
Maximum storage time
(months)
Shellsh Clean and in a bag 4 - 6
Caviar
In its packaging, or in an aluminium or plastic
container
2 - 3
Snails In salty water, or in an aluminium or plastic container 3
NOTE: Thawed frozen meat should be cooked as fresh meat. If the meat is not cooked after defrosting, it
must not be re-frozen.
Vegetables and Fruits Preparation
Maximum storage time
(months)
String beans and beans Wash, cut into small pieces and boil in water 10 - 13
Beans Hull, wash and boil in water 12
Cabbage Clean and boil in water 6 - 8
Carrot Clean, cut into slices and boil in water 12
Pepper
Cut the stem, cut into two pieces, remove the core
and boil in water
8 - 10
Spinach Wash and boil in water 6 - 9
Cauliower
Remove the leaves, cut the heart into pieces and
leave it in water with a little lemon juice for a while
10 - 12
Eggplant Cut into pieces of 1 inch after washing 10 - 12
Corn Clean and pack with its stem or as sweet corn 12
Apple and pear Peel and slice 8 - 10
EN - 17
Vegetables and Fruits Preparation
Maximum storage time
(months)
Apricot and Peach Cut into two pieces and remove the stone 4 - 6
Strawberry and
Blackberry
Wash and hull 8 - 12
Cooked fruits Add 10 % of sugar to the container 12
Plum, cherry, sourberry Wash and hull the stems 8 - 12
Maximum storage time
(months)
Thawing time at room
temperature (hours)
Thawing time in oven
(minutes)
Bread 4 - 6 2 - 3 4-5 (428-437 °F)
Biscuits 3 - 6 1 - 1,5 5-8 (374-392 °F)
Pastry 1 - 3 2 - 3 5-10 (392-437 °F)
Pie 1 - 1,5 3 - 4 5-8 (374-392 °F)
Phyllo dough 2 - 3 1 - 1,5 5-8 (374-392 °F)
Pizza 2 - 3 2 - 4 15-20 (392 °F)
Dairy products Preparation
Maximum storage time
(months)
Storage conditions
Packet (Homogenized)
Milk
In its own packet 2 - 3 Pure Milk – in its own packet
Cheese - excluding
white cheese
In slices 6 - 8
Original packaging may be
used for short-term storage.
Keep wrapped in foil for
longer periods.
Butter, margarine In its packaging 6
5 CLEANING AND
MAINTENANCE
Disconnect the unit from the power
supply before cleaning.
Do not wash your appliance by
pouring water on it.
Do not use abrasive products,
detergents or soaps for cleaning the
appliance. After washing, rinse with clean
water and dry carefully. When you have
nished cleaning, reconnect the plug to the
mains supply with dry hands.
• Make sure that no water enters the lamp
housing and other electrical components.
• The appliance should be cleaned
regularly using a solution of bicarbonate
of soda and lukewarm water.
• Clean the accessories separately by
hand with soap and water. Do not wash
accessories in a dish washer.
• Clean the condenser with a brush at least
twice a year. This will help you to save on
energy costs and increase productivity.
The power supply must be
disconnected during cleaning.
EN - 18
5.1 Defrosting
Defrosting the Refrigerator
Compartment
• Defrosting occurs automatically in
the refrigerator compartment during
operation. The water is collected by
the evaporation tray and evaporates
automatically.
• The evaporation tray and the water drain
hole should be cleaned periodically with
the defrost drain plug to prevent the
water from collecting at the bottom of the
refrigerator instead of owing out.
• You can also clean the drain hole by
pouring half a glass of water down it.
Freezer defrosting process
• Small amounts of frost will accumulate
inside the freezer, depending on the
length of time the door may be left open
or the amount of moisture introduced.
It is essential to ensure that no frost or
ice is allowed to form in places where
it will aect the close tting of the door
seal. This might allow air to penetrate the
cabinet, encouraging continuous running
of the compressor. Thin frost formation
is quite soft and can be removed with a
brush or plastic scraper. Do not use metal
or sharp scrapers, mechanical devices or
other means to accelerate the defrosting
process. Remove all dislodged frost from
the cabinet oor. It is not necessary to
switch o the appliance for the removal
of thin frost.
• For the removal of heavy ice deposits,
disconnect the appliance from the
mains supply, empty the contents into
cardboard boxes and wrap in thick
blankets or layers of paper to keep cool.
Defrosting will be most eective if carried
out when the freezer is nearly empty
and should be carried out as quickly
as possible to prevent an unnecessary
increase in the temperature of the
contents.
• Do not use metal or sharp scrapers,
mechanical devices or other means to
accelerate the defrosting process. An
increase in temperature of frozen food
during defrosting will shorten the storage
life. Keep contents well wrapped and cool
while defrosting is taking place.
• Dry the inside of the compartment with a
sponge or a clean cloth.
• To accelerate the defrosting process,
place one or more bowls of warm water
in the freezer compartment.
• Examine the contents when replacing
them in the freezer and if some of the
packages have thawed out, they should
be eaten within 24hours, or be cooked
and re-frozen.
• After defrosting is complete, clean the
inside of the appliance with a solution
of warm water and a little bicarbonate
of soda, then dry thoroughly. Wash all
removable parts in the same way and
reassemble. Reconnect the appliance
EN - 19
to the mains supply and leave for 2 to
3 hours on setting number MAX before
introducing the food back into the freezer.
Replacing LED Lighting
To replace any of the LEDs, please contact
the nearest Authorized Service Center.
Note: The numbers and location of the
LED strips may change according to
the model.
6 SHIPMENT AND
REPOSITIONING
6.1 Transportation and Changing
Positioning
• The original packaging and foam may be
kept for re-transportation (optional).
• Fasten your appliance with thick
packaging, bands or strong cords and
follow the instructions for transportation
on the packaging.
• Remove all movable parts or x them
into the appliance against shocks
using bands when re-positioning or
transporting.
Always carry your appliance in the
upright position.
6.2 Repositioning the Door
• It is not possible to change the opening
direction of your appliance door if door
handles are installed on the front surface
of the appliance door.
• It is possible to change the opening
direction of the door on models with
handel on the side of the door or without
handles.
• If the door-opening direction of your
appliance can be changed, contact the
nearest Authorized Service Center to
change the opening direction.
7 BEFORE CALLING AFTER-
SALES SERVICE
If you are experiencing a problem with
your appliance, please check the following
before contacting the after-sales service.
Your appliance is not operating
Check if:
• There is power
• The plug is correctly placed in the socket
• The plug fuse or the mains fuse has
blown
• The socket is defective. To check this,
plug another working appliance into the
same socket.
The appliance performs poorly
Check if:
• The appliance is overloaded
• The appliance door is closed properly
• There is any dust on the condenser
• There is enough space near the rear and
side walls.
Your appliance is operating noisily
Normal noises
Cracking noise occurs:
• During automatic defrosting
• When the appliance is cooled
or warmed (due to expansion of
appliance material).
Short cracking noise occurs: When
the thermostat switches the compressor
on/o.
Motor noise: Indicates the compressor
is operating normally. The compressor
may cause more noise for a short time
when it is rst activated.
Bubbling noise and splash occurs:
Due to the ow of the refrigerant in the
tubes of the system.
Water owing noise occurs: Due
to water owing to the evaporation
container. This noise is normal during
defrosting.
Air blowing noise occurs: In some
models during normal operation of the
system due to the circulation of air.
EN - 20
The edges of the appliance in contact
with the door joint are warm
Especially during summer (warm seasons),
the surfaces in contact with the door joint
may become warmer during the operation
of the compressor, this is normal.
There is a build-up of humidity inside
the appliance
Check if:
• All food is packed properly. Containers
must be dry before being placed in the
appliance.
• The appliance door is opened frequently.
Humidity of the room enters the
appliance when the doors are opened.
Humidity increases faster when the doors
are opened more frequently, especially if
the humidity of the room is high.
The door does not open or close
properly
Check if:
• There is food or packaging preventing the
door from closing
• The door joints are broken or torn
• Your appliance is on a level surface.
Recommendations
• If the appliance is switched o or
unplugged, wait at least 5 minutes before
plugging the appliance in or restarting
it in order to prevent damage to the
compressor.
• If you will not use your appliance for
a long time (e.g. in summer holidays)
unplug it. Clean your appliance according
to chapter cleaning and leave the door
open to prevent humidity and smell.
• If a problem persists after you have
followed all the above instructions,
please consult the nearest authorized
service center.
• The appliance you have purchased is
designed for domestic use only. It is not
suitable for commercial or common use.
8 TIPS FOR SAVING ENERGY
1. Install the appliance in a cool, well-
ventilated room, but not in direct sunlight
and not near a heat source (such as a
radiator or oven) otherwise an insulating
plate should be used.
2.
Allow warm food and drinks to cool
before placing them inside the appliance.
3.
Place thawing food in the refrigerator
compartment if available. The low
temperature of the frozen food will
help cool the refrigerator compartment
while the food is thawing. This will save
energy. Frozen food left to thaw outside
of the appliance will result in a waste of
energy.
4.
Drinks or other liquids should be
covered when inside the appliance. If
left uncovered, the humidity inside the
appliance will increase, therefore the
appliance uses more energy. Keeping
drinks and other liquids covered helps
preserve their smell and taste.
5.
Avoid keeping the doors open for long
periods and opening the doors too
frequently as warm air will enter the
appliance and cause the compressor to
switch on unnecessarily often.
6.
Keep the covers of the dierent
temperature compartments (such as the
crisper and chiller if available) closed.
7.
The door gasket must be clean and
pliable. In case of wear, replace the
gasket.
Element Appliance Limited Warranty
(the “Products” or “Product” when referencing a singular product herein)
This Product (including any accessories included in the original packaging) as supplied and distributed in
new condition, is warranted by Element Appliance Company, LLC ("Element") to the original customer
who purchases the Product from an authorized Element retailer (the “Original Customer” or “you”)
against defects in material and workmanship under proper use, maintenance, and care according to the
owner’s manual, warnings, and instructions accompanying the Product (“Warranty”) as follows:
* PLEASE NOTE – Proof of purchase evidencing the date of purchase by the Original Purchaser from an
authorized Element retailer (“Valid Proof of Purchase”) is required for all Warranty service. The express
Warranty set forth herein is subject to all terms and conditions set forth below.
1. WARRANTY SERVICE
:
A. ON
E-YEAR WARRANTY: Except as provided in subpart 1.B below, for a period of one (1)
year from the date of purchase by the Original Customer (the “Warranty Period”), if the parts or
components covered by this Warranty are determined by Element or Element’s authorized service
provider to be defective in material or workmanship, Element will, at its sole and absolute discretion and
option: (i) repair the defective part or component at no charge to the Original Customer, (ii) replace the
defective Product with a new Product of similar or better quality, at no charge to the Original Customer,
or (iii) refund the documented purchase price paid by the Original Customer (excluding tax) to the Original
Customer upon return of the defective Product as directed by Element. After the Warranty Period expires,
the Original Customer must pay for all parts, components, shipping and handling, labor, and replacement
costs associated with the Product or any part or component thereof, regardless of any defects in the
Product or any part or component thereof.
B. LIMITED EXTENDED WARRANTY THROUGH PRODUCT REGISTRATION: If and only if the
Original Customer registers the Product at www.elementelectronics.com within ninety (90) days of the
date of purchase by the Original Customer, then the Warranty Period discussed in subpart 1.A. above shall
be extended an additional one (1) year to a new Warranty Period equaling two (2) years from the date of
purchase by the Original Customer. If the Product is not registered as provided for in this subpart 1.B,
then the standard one-year Warranty Period set forth in subpart 1.A shall apply.
C. TIMING AND PROCEDURE: Before Warranty service can commence, the Original
Customer must contact either (i) the retailer from whom the Original Customer purchased the Product,
or (ii) Element directly, in either case for problem determination and service procedures. Valid Proof of
Purchase evidencing that the Product is within the Warranty Period MUST be presented by Original
Customer in order to obtain the requested Warranty service. Please have your model and serial number
available, along with your date of purchase of the Product. To remain eligible for Warranty service,
Original Customer may not return the Product or any part or component thereof to the retailer or Element
without Element’s prior written consent.
2. EXCLUSIONS AND LIMITATIONS TO WARRANTY SERVICE
The Warranty covers manufacturing defects in materials and workmanship of the Product encountered in
the normal, non-commercial use of the Product, and does not cover (a) damages or malfunctions resulting
from improper or unreasonable use or maintenance, abuse, negligence, failure to follow instructions
contained in any written materials that accompany the Product, deterioration by reason of excess
moisture, corrosive atmosphere, lightning, power surges, connections to improper voltage supply,
unauthorized alteration, or other external causes such as extremes in temperature or humidity,
modifications, scratches or discoloration; (b) any damage caused by using non-authorized parts or service
facilities for repair of Products (however, for avoidance of doubt, using non-authorized parts or service
facilities will not, in and of itself, void the Warranty); (c) transportation, shipping, delivery, pickup,
insurance, installation, or set-up costs; (d) ordinary wear and tear, cosmetic damage, or damage due to
acts of nature, including but not limited to, water, floods, wind, storm, tornado, earthquake, or fire, or
due to damage caused by extraordinary impact events, such as dropping, crushing, demolition or other
extraordinary damage; (e) commercial use of the Product, or use of the Product for anything other than
single-family household or residential use; or (f) modification of the Product or any part of the Product.
This Warranty is made to the Original Customer only and does not cover Products sold AS IS or WITH ALL
FAULTS. The Warranty is invalid if the factory-applied serial number has been altered or removed from
the Product. This Warranty is valid only in the United States, and only applies to Product if it was purchased
and serviced in the United States. The addition of equipment or features to the Product that are not
manufactured or recommended by Element could affect the intended function of the Product, and
therefore may void the Warranty. Furthermore, the exposure of the Product to chemicals, heat, cold,
humidity, or other elements can affect the Product components, and therefore, the Warranty does not
cover discoloration, fading, cosmetic changes, rust, or any damages or failure related to any such items.
The Warranty is contingent upon the proper use, maintenance, and care of the Product. The Warranty
may be void if the Product has been used in a manner contradictory to, or in violation of, the terms of the
user’s manual, warnings, or instructions accompanying the Product.
THIS WARRANTY IS MADE IN LIEU OF AND SUPERSEDES ALL OTHER WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR GENERAL USE, WHETHER EXPRESS,
IMPLIED, COLLATERAL, STATUTORY, OR PROVIDED BY COMMON LAW, THE UNIFORM COMMERCIAL
CODE, OR OTHERWISE. ELEMENT FURTHER DISCLAIMS ALL WARRANTIES AFTER THE END OF THE
WARRANTY TERM DEFINED ABOVE. NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY
OTHER PERSON, FIRM, OR ENTITY WITH RESPECT TO THE PRODUCT SHALL BE BINDING ON ELEMENT.
REPAIR, REPLACEMENT, OR REFUND OF THE ORIGINAL PURCHASE PRICE, AT ELEMENT’S SOLE
DISCRETION, ARE THE EXCLUSIVE REMEDIES OF THE CUSTOMER.
ELEMENT SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE
USE, MISUSE, OR INABILITY TO USE THE PRODUCT. THESE INCLUDE, BUT ARE NOT LIMITED TO, ANY
DAMAGES IN THE FORM OF LOST PROFITS, LOSS OF USE, LEGAL FEES, ECONOMIC LOSS, PERSONAL
INJURIES, OR ANY OTHER DAMAGES CAUSED BY CIRCUMSTANCES BEYOND THE CONTROL OF ELEMENT.
NOTWITHSTANDING THE FOREGOING, ELEMENT’S AGGREGATE LIABILITY TO ANY CUSTOMER SHALL
NOT EXCEED THE ORIGINAL PURCHASE PRICE OF THE PRODUCT. THIS WARRANTY SHALL NOT EXTEND
TO ANYONE OTHER THAN THE ORIGINAL CUSTOMER WHO PURCHASED THE PRODUCT, AND IS NOT
TRANSFERRABLE. NO PERSON IS AUTHORIZED TO ALTER, EXTEND, OR WAIVE THIS WARRANTY OR ANY
OF ITS TERMS OR CONDITIONS.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or allow
limitations on warranties, so the above limitations or exclusions may not apply to you. This Warranty gives
you specific rights, and you may have other rights, which vary from state to state. The exclusions and
limitations to the Warranty apply to the maximum extent permitted by law and unless restricted or
prohibited by law. Where any term of this Warranty is prohibited by applicable law, it shall be null and
void, but the remainder of this Warranty shall remain in effect.
PLEASE DIRECT ALL CORRESPONDENCE TO:
E
lement Appliance Company, LLC
customerservice@elementelectronics.com
(888) 842-3577
https://elementelectronics.com
52570409
Element, the Element Logo, and Bring it home are trademarks of Element Brand
Holding, LLC. All other trademarks are the property of their respective owner,
who has not sponsored, endorsed, or approved this product. ©2026 Element
Appliance Company, LLC. All rights reserved.
Distributed by Element Appliance Company, LLC
Augusta, GA 30909
For service, support and warranty information:
Call 888.842.3577, email us at [email protected] or visit
www.elementelectronics.com
