SKU: DL_BFDR56-13W-27K_5K
User Manual
5/6″ LED Retrot
Selectable Bae Downlight
support@sunco.com
(844) 334-9938
Lighting made better.
1
Let there be light!
(literally)
x1
x1
Light Fixture
TP24 Connector
E26 Base
x1
What’s in the Box?
Retrofit Downlight
Accessories
Spring Clips
x2
DCBA
Locate the recessed
housing.
Connect the adapter with
lamp base connector.
Determine type of
connector available.
Push downlight into
can until secure.
Step 1 Step 2 Step 3 Step 4
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference that may
cause undesired operation. Please review all
instructions carefully prior to installation.
• Turn o circuit breaker before installing this xture.
• This product should be installed by a person familiar with
the construction and operation of the product the hazards
involved. Safety eyeglasses and gloves are recommended.
• Abide by related regional and local laws or regulations.
• Proper grounding is required to ensure safety.
• Do not alter, relocate, or remove wiring during installation.
• Do not make or alter any open holes in wiring enclosure or
electrical components during installation.
• Check for shipping damage before installing. If the
product is damaged, do not use it.
• Keep xture away from corrosive substances.
• Suitable for damp locations at temperature ranging from
-4°F to 113°F. Not for use where directly exposed to water.
• This product is not compatible with 3rd party sensors.
• This product is not compatible with photo controls.
• This product is not compatible with occupancy sensors.
• This product is not compatible with timing devices.
To reduce the risk of fire, electric shock, or physical injury:
2
2
Safety Information
Before You Start
Quickstart Guide
WARNING:
Cancer & Reproductive Harm- www.P65Warnings.ca.gov
21
3
Installation Guide
a. Determine the type of connector available, then
connect the wires.
(B) TP24 Connector
(C) E26 Base
a. Turn off circuit breaker before installation.
b. Locate the housing and remove the previous fixture.
NOTE: Light fixture may be hot! Allow time for the fixture
to cool after the power is off.
STEP 3
STEP 1
(B)
(C)
a. Secure the springs to the luminaire.
STEP 2
Installation Guide (Cont.)
a. Line up trim ring with opening, then push the downlight
into the can. Ensure that both ends of each spring are
installed into the C-clips (1).
b. Tuck all the wires into the can.
STEP 5
STEP 4
a. Use the switch on the back of the retrofit to select
one of five color temperatures.
2700K
3000K
3500K
4000K
5000K
4
a. Turn on circuit breaker and test the light.
STEP 6
(1)
5
Product Details
Recommended Dimmers
Specifications
Sc�� f�� the ��l�
c��pa����e ����e� list!
Brand
Model
6672-1LW
DSL06-1LZ
AYCL-153P-WH
DVCL-153PR-WH
MACL-153M-WH
SCL-153P-WH
LUTRON
6674-10W
LUTRON
LUTRON
LEVITON
LEVITON
LEVITON
LUTRON
Voltage
Wattage
Beam Angle
Efficacy
Housing Material
Dimmable
120V
13W
120°
74 lm/W
PA6+30%GF
Yes
50000 Hours
965 lm
Damp Rated
80+
Indoor
7 Years
Average Lifetime
Lumens
Moisture Rating
CRI
Usage
Warranty
6
Feeling in the dark about an issue with your product? No
worries! Our troubleshooting section is here to shed some light
and provide you with easy-to-follow solutions for any problem.
Light unexpectedly fails.
Light not dimming to lowest setting.
Fixture buzzing with appliances or electronic devices.
Fixture buzzing when dimmed.
Look for nearby interferences that can cause buzzing.
Such as televisions, radios, computers, etc.
Light not dimming smoothly.
Light ickering with other lights on the same circuit.
Check that the lights on the same circuit are not
overloading the circuit.
Light ickering when turned on.
Light ickering when dimmed.
Verify dimmer switch compatibility.
Double check if xture is properly connected
and circuit breaker hasn’t been tripped.
Check light-dimmer compatibility. Consider purchasing
compatible switch if necessary.
Verify dimmer compatibility with xture.
Light isn’t turning on.
Light not compatible with dimmer switch.
Fixture buzzing with power outages. Verify light is connected to surge protector securely.
Verify dimmer switch compatibility.
Verify xture compatibility.
Light is ickering when turning on.
Check that xture wiring connections are secure.
For further assistance, contact our customer support.
Ensure minimum dimmer load requirement is met.
If you still need some assistance, please feel free to
contact us with any questions. Our team of lighting experts
are happy to help brighten your day.
Installation
Dimming
Flickering
Buzzing
Common Troubleshooting
support@sunco.com
(844) 334-9938
Lighting made better.
REV2.0
