USER GUIDE
Portable Air Conditioner
SLPAC8
www.SereneLifeHome.com
2
CONTENTS
Features and Technical Specications
Important Safety Tips
Precautions
Product Introduction
Main Parts and Components
Control Panel and Remote Controller
Product Operation
Placement and Installation
Operation Method
Clean and Maintenance
Drainage Method
Maintenance
Common Failures and Diagnosis
Intelligent Error Detection
Fuse Parameters
Troubleshooting
Register Product
READ AND SAVE THESE INSTRUCTIONS
California Prop 65 Warning
WARNING:
This product contains Acrylonitrile which is known to the state
of California to cause cancer birth defects and other
reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
3
4
4
7
7
9
10
10
11
12
12
13
14
14
14
14
15
www.SereneLifeHome.com
3
Features:
•
Lightweight & Portable A/C Unit
• Compact Freestanding Room Air Conditioner
• (3) Operation Modes: AC Cooling / Dehumidier / Fan
• Hassle-Free Room Cooling, Quick Setup
• Simple Electric Plug-in Operation
• Temp Control Air Circulator Function
• Automatic Swing Mode: Moving Wind Vents for Air Circulation
• Convenient Wide-Area Climate Control Room AC Coverage
• Digital Touch Button Control Panel with LED Display
• Time, Temperature & Fan Speed Adjustment Settings
• Includes Universal Window Mount AC Exhaust Kit
• Removable & Washable Air Filter Screen
• Modern Style, Sleek Body Housing
• Energy Ecient: Low Power Consumption
• Low Noise Level Motor
• Rolling Wheels for Easy Portability
• Used for Home, Oce, School & Business Rooms
What's in the Box
•
AC Unit • Exhaust Hose • Window Installation Plate • Remote Control
Technical Specs:
• Cooling Power: 8,000 BTU
• Rated Power: 900 Watt
• Coverage Area: Cools Rooms up to 215'+ Square Feet
• Air Flow: 290 Cubic Meters / Hour
• Operating Modes: Cool / Fan / Dry (Dehumidier)
• Moisture Removal / Dehumidier: 1.2 Liters / Hour
• Operating Noise Level: 57+/-3dBA
• Fan Speed Settings: Low / High
• Temperature Unit Selectable: °F / °C (Fahrenheit / Celsius)
• Adjustable Timer Settings: Up to 24 Hours
• Construction Material: Engineered ABS Housing
• Battery Operated Remote Control, Requires (2) x ‘AAA’ Batteries, Included
• Power Cable Length: 4.3'ft.
• Power Supply: 120V
• Dimensions (L x W x H): 14.6’’ x 13.8’’ x 27.2’’ -inches
www.SereneLifeHome.com
4
Important Safety Tips
Precautions
Please read the Manual carefully before operating the machine:
• This machine is for household use only.
• This machine is for indoor use only. Please place it in dry environment.
• Check power cord frequently. If power cord, plug or A/C is damaged, please
don’t operate. If the power cord is not long enough, power extension cable
can be used. Cable should not scatter at places where power cord may be
pulled out or people may be stumbled.
• The A/C should be away from heat source and avoid direct sunlight.
• Turn o the A/C before unplugging.
• Turn o and unplug the A/C before removing or cleaning it, or replacing its
parts or when it is not used.
• Clean the A/C according to the Manual.
• Voltage of the A/C should meet requirements.
Any damage incurred by incorrect power isn’t included in the warranty.
• Children are not allowed to play with the A/C.
This appliance is not intended for use by children, unless they have been given
supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Don’t insert your ngers or any hard object to wind guide bar of the air outlet.
• Don’t place the A/C at any place with water or other liquid.
Prevent water or liquid from entering the A/C.
• Don’t repair the A/C by yourself. Any possible hazard incurred by maintenance
of laypeople will violate the warranty. If the supply cord is damaged, it must be
replaced by professional maintenance personnel.
• Please use the accessories provided by the A/C manufacturer; otherwise, the
A/C may be damaged.
• Cleaning and user maintenance shall not be made by children without
supervision.
www.SereneLifeHome.com
5
READ ALL INSTRUCTIONS BEFORE USE
Your safety and the safety of others are very important. We have provided many
important safety messages in this manual and on your appliance.
Always read and follow all safety messages.
REFRIGERANT (FOR R32 ONLY)
CAUTION ON FIRE
READ THE MANUAL CAREFULLY BEFORE USING THE APPLIANCE.
R32 refrigerant gas complies with international environmental directives.
Warnings
• Do not use methods to accelerate the defrosting process or cleaning other
than those recommended by the manufacturer.
• The appliance shall be stored in a room without continuously operating ignition
sources (e.g., open ames, operating gas appliances, or operating electric
heaters).
• Do not pierce or burn the appliance.
• Be aware that refrigerants may not contain an odor.
The instructions should contain the following information:
• Piping material, pipe routing, and installation should include protection from
physical damage during operation and service, and comply with national and
local codes and standards, such as ASHRAE 15, IAPMO Uniform Mechanical
Code, ICC International Mechanical Code, or CSA B52.
This symbol indicates that this appliance uses a ammable
refrigerant. If the refrigerant leaks and comes into contact with an
external ignition source, there is a risk of re.
This symbol indicates that the operation manual should be read
carefully.
This symbol indicates that service personnel should handle this
equipment with reference to the installation manual.
This symbol indicates that information is available, such as the
operating manual or installation manual.
www.SereneLifeHome.com
6
• All eld joints shall be accessible for inspection prior to being covered or
enclosed.
• The installation of pipework should be kept to a minimum.
• Provisions should be made for expansion and contraction of long runs of piping.
• Protection devices, piping, and ttings should be protected against adverse
environmental eects (e.g., the risk of water collecting and freezing in relief
pipes or the accumulation of dirt and debris).
• The piping in refrigeration systems should be designed and installed to minimize
the likelihood of hydraulic shock damaging the system.
• Steel pipes and components should be protected against corrosion with a
rustproof coating before applying any insulation.
• Flexible pipe elements should be protected against mechanical damage,
excessive stress by torsion, or other forces, and should be checked for
mechanical damage annually.
• Precautions should be taken to avoid excessive vibration or pulsation.
When using the product:
• Keep any required ventilation openings clear of obstructions.
• Servicing should be performed only as recommended by the manufacturer.
Unventilated Area
• An unventilated area where the appliance using ammable refrigerants is
installed should be constructed so that, in case of a refrigerant leak, it will not
stagnate and create a re or explosion hazard.
• The non-xed appliance should be stored in an area where the size corresponds
to the room area specied for operation.
• The non-xed appliance should be stored in a room without continuously
operating open ames or other potential ignition sources.
• The manufacturer should specify any other continuously operating sources
known to cause ignition of the refrigerant used.
• The appliance should be stored in a manner that prevents mechanical damage.
• Non-duct connected appliances containing A2L refrigerants with air openings
in the conditioned space may have the body of the appliance installed in open
areas such as false ceilings (not used as return air plenums), as long as the
conditioned air does not directly communicate with the air in the false ceiling.
www.SereneLifeHome.com
7
Qualication of Workers
• All operators or refrigeration circuit maintenance personnel should obtain a
valid certicate issued by an industry-recognized evaluation agency to
demonstrate that they have the qualications to safely handle refrigerants, as
required by the industry-recognized evaluation scope.
• Perform equipment maintenance and repairs only in accordance with the
methods recommended by the appliance manufacturer.
If another professional is required to assist in maintenance and repairs, it
should be carried out under the supervision of personnel qualied to handle
ammable refrigerants.
Special Warning:
• Place the A/C on even ground and install it vertically, so as to ensure normal
operation of the compressor.
• The A/C should be at least 50cm away from surrounding objects.
Keep air inlet and outlet smooth.
• Don’t use the A/C beside gasoline or any other inammable liquid.
• Don’t use spraying agent and other solvent or ammable substances near the
A/C; otherwise, its plastic may deform and electric parts may be damaged.
Power
• The plug should be in good condition and can’t be damaged.
Don’t replace the plug with power plug.
• In order to run the A/C, plug the power cord rst, and then press the power key.
• Place unit in upright position for 2 hours before turning on for rst time.
Product Introduction
MAIN PARTS AND COMPONENTS
1. Handle
2. Control panel
3. Louver
4. Caster
5. Air outlet
6. Air inlet
7. Drainage nozzle
8. Remote controller
9. Exhaust duct assembly
10. Window sealing plate assembly
www.SereneLifeHome.com
8
C
8
10
9
Sleep
2
3
4
1
5
7
6
www.SereneLifeHome.com
9
Control Panel and Remote Controller
1. Power key
Press the key to turn ON/OFF the A/C.
2. Mode key
Press the key to choose cool, fan and dry.
3. Temperature/ time adjusting key
Press the key at cooling mode to increase/
reduce the setting temperature; press it at
timing mode to adjust time; press Up and
Down keys simultaneously to switch
Fahrenheit and Centigrade degree
temperature.
4. Speed key
Press the key to choose high/low speed.
5. Timer key
Press the key at standby mode to set ON time.
Press this key at ON mode to set OFF time.
6. Temperature/ Time Display Window
Displays the adjusted temperature and time
7. Remote controller receiving window
It is used to receive signal of the remote controller.
8. °C/°F switching key
Press the key to switch °C and °F
9. Sleep key
In the cooling mode, the sleep mode can be selected by this key
Cooling Model
SPEED
Cool
Fan
Dry
High
Low
C
POWER
TIMER
MODE
1
8
2
3
5
4
9
www.SereneLifeHome.com
10
Product Operation
Placement and Installation
Placement
Place it at even and dry place, and keep it at least 50cm. away from its
surrounding object.
Installation
• Screw the exhaust duct assembly in the air outlet behind the panel
(counterclockwise).
• Insert the air exhaust hose into the window sealing plate, adjust opening width
of window so that the window can match with the sealing plate properly;
length of the sealing plate is adjustable.
www.SereneLifeHome.com
11
Incorrect Installation
• It’s important to keep the exhaust duct smooth. Incorrect installation will aect
work of the A/C.
• Prevent the exhaust duct from sharp bending.
• Ensure air can ow smoothly in the duct.
Warning:
The exhaust duct is designed especially
for this model. Don’t replace or lengthen it;
otherwise, it will result in failure.
Notice: Max. developed length of the exhaust duct is 1,500mm. It’s better to
shorten it while in use and keep it horizontal while installation.
OPERATION METHOD
Cooling Mode
• When the A/C enters cooling mode automatically or cooling mode is selected
after power ON, the cooling indicator lamp lights up.
• Press Up/Down key to adjust setting temperature (16°C~30°C)(60°F~86°F).
• Press Speed key to choose High/Mid/Low speed.
Fan Mode
• When pressing mode key or choosing Fan mode by pressing the remote
controller, the wind indicator lamp lights up.
• Press Speed key to choose High/Mid/Low speed.
• Temperature can’t be set.
50cm
Best Installation
www.SereneLifeHome.com
12
Dehumidication Mode
• When pressing mode key or choosing dehumidication mode
by pressing the remote controller, the dehumidication
indicator lamp lights up.
• Remove the dehumidication water wedge, insert water
manifold, place the other end of the water manifold into the
water vessel or drainage passage, as shown in the right gure.
• After entering the dehumidication mode, f room
tempearture≥17°C (62°F), the compressor is ON.
Then control as follows: when room temperature ≤15°C (59°F), the compressor
is OFF; when temperature increases to room temperature≥17°C (62°F), the
compressor will start again (in order to protect the compressor, it will be
restarted 3min. later).
• In dehumidication mode, the fan is defaulted to run at low speed, and wind
speed can’t be adjusted.
• Temperature can’t be set.
Note: When use dehumidify function, should remove exit pipe components, otherwise,
it will cause worse dehumidify performance, and appear “FL” water full alarm
Sleep mode (optional function)
• Under cool mode, pressing sleep mode key on the remote controller or pressing
time key and down key together on the machine, it will start sleep mode with low
wind speed and can’t be adjusted. Pressing the sleep mode key again or pressing
time key and down k ey together on the machine to quit the sleep mode.
• If you press the wind speed key under the sleep mode, the screen will display ”SL”
Timer Mode
• In standby state, press the Timer key to set ON time. Press Up and Down keys to
set ON time (1~24H), and the timer indicator lamp lights up.
• In ON state, pressure the timer key to set OFF time. Press Up and Down keys to
set OFF time (1~24H), and the timer indicator lamp lights up.
Clean and Maintenance
DRAINAGE METHOD
This product is equipped with automatic water vaporization system.
The condenser is cooled with the circulating of condensing water, so as to
improve cooling eciency and save energy.
www.SereneLifeHome.com
13
MAINTENANCE
Notice:
In order to avoid electric shock, please turn o the A/C and unplug before
maintenance or repair.
CLEANING
• Unplug before cleaning.
• Wipe with soft semi-dry cloth. Don’t use chemical reagent, such as benzene,
alcohol and gasoline etc; otherwise surface of the A/C and even the whole A/C
will be damaged.
• Prevent water from spattering in the A/C.
FILTER SCREEN
• Wash the lter screen once every two weeks. If it is blocked by dust, eciency of
the A/C will be reduced.
• Take out the air inlet grille and pull out the lter screen at both sides according
to the direction shown in the following gures.
• Put the lter screen into the warm water (about 40°C or 104°F) added with
neutral detergent, dry it at a shady place after cleaning.
• If the internal vessel is full of water, the display screen will
display “FL”, and the compressor stops working automatically.
After power o, unscrew the water cover, pull out the water
plug to drain o water, and it will become normal after
being restarted.
If the lter is dirty, clean it in
warm water (about 40°C/
104°F) with a neutral
detergent.
If the lter is not very dirty,
you can clean o the dust
using a vacuum cleaner.
www.SereneLifeHome.com
14
SEASONAL CLEANING
If the A/C will not be used for a long time:
• Pull out the water plug to drain.
• Run the A/C in fan mode for 2H till the inside is dry.
• Turn o the A/C and unplug.
• Wash the lter screen and reassemble it.
• Dismantle the exhaust duct and keep it properly.
• Cover the A/C with a plastic bag and place it at a dry place.
Common Failures and Diagnosis
Intelligent Error Detection
FUSE PARAMETERS
• Voltage: 250VAC
• Current: 3.15A
Troubleshooting
In case of any of the following trouble, please contact professional maintenance
personnel in time.
Error-detecting code Multi-functional defection
E1 Error of the coil’s temperature sensor
E2 Error of indoor temperature sensor
E4
Anti-freezing protection: temperature of the coil is too low
and the whole A/C is o. When temperature excesses 8°C
or 46.4°F, the protection is released and previous working
state is recovered.
Trouble Cause Solution
The A/C doesn’t work
No display
Reset the circuit breaker on the
A/C cord
The display panel shows “FL”
Restart the A/C after powering
o and draining; it will normalize
The Time OFF function is
started
The A/C can be restarted 3 min.
after being turned o
www.SereneLifeHome.com
15
Notice: When there is any abnormal to the A/C, turn it o and unplug, and then
contact professional maintenance personnel.
The above technical parameters are subject to change without notice.
Register Product
Thank you for choosing SereneLife. By registering your product,
you ensure that you receive the full benets of our exclusive
warranty and personalized customer support.
Complete the form to access expert support and to keep your
SereneLife purchase in perfect condition.
Start Here
Serenelifehome.com/pages/register
Do not dispose of electrical appliances as unsorted municipal
waste, use separate collection facilities.
Contact you local government for information regarding the
collection systems available.
If electrical appliances are disposed of in landlls or dumps,
hazardous substances can leak into the groundwater and get into
the food chain, damaging your health and well -being.
When replacing old appliances with new ones, the retailer is
legally obligated to take back your old appliance for disposals at
least free of charge.
The A/C starts
frequently
Direct sunlight Close the curtains
Filter screen is very dirty Clean or replace the lter screen
Big noise from the A/C The A/C is placed unevenly
Place the unit on even, rm
ground to prevent shaking
The compressor
doesn’t work
Delay protection activated
Wait for 3 minutes for the
temperature to decrease, then
turn on again
The Time OFF function is
started
The A/C can be restarted 3 min.
after being turned o
Open doors and windows
or too many people/heat
sources in the room
Close doors and windows,
remove heat sources
Air inlet or outlet is blocked Remove the obstruction
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
Serenelifehome.com/ContactUs
