TOWING MIRRORS
MODEL:YH3337-M-B
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: YH3337-M-B
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
1. Please read this instruction carefully before starting installation.
2. Proper tools will improve the quality of installation and reduce the time
required.
3. All mirrors are symmetrical and designed for better view range.
4. If you find missing parts or damaged, please take a photo and contact
us.
5. Please reference the vehicle owner's manual to adjust the new mirrors.
6. If you can't install it yourself, contact an auto repair professional to
replace it for you.
MODEL AND PARAMETERS
Model
YH3337-M-B
Auto Part Position
Front Outside
Fold
Manual Telescopic/Manual Folding
Applicable Vehicle Type
Chevy Silverado
1999-2007/GMC/Cadillac
Color
Black
STRUCTURE DIAGRAM
1.
Manual Folding 2.Manual Telescopic
3.Convex Glass (Manual Adjustment)
4.Flat Glass (Manual Adjustment)
3
1
2
4
- 3 -
INSTALLATION INSTRUCTIONS
STEP 1
1. Open the front door to remove the upper extension triangular trim panel.
2. Remove the foam pad form door sheet panel.
3. Remove (3) 10mm hex nuts securing the factory mirror.
4. Carefully remove the factory mirror.
STEP 2
1. Take the new mirror, feed studs through the holes on door panel.
2. Install (3) provided hex nuts to secure the new mirror. Torque to 80 lb in.
3. Insert the foam pad into the door sheet and reinstall the upper extension
triangular trim panel.
4. Repeat on the passenger side.
MAINTENANCE
1.Scrub the towing mirror when it is dirty.
2.Get into the habit of folding the towing mirrors when parking.
- 4 -
Address：Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
Made In China
- 5 -
- 7 -
Assistance technique et certificat de garantie électronique
www.vevor.com/support
RÉTROVISEURS DE REMORQUAGE
MODÈLE : YH3337-MB
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
- 1 -
MODÈLE : YH3337-MB
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
7. Veuillez lire attentivement ces instructions avant de commencer
l'installation.
8. Des outils appropriés amélioreront la qualité de l’installation et réduiront
le temps requis.
9. Tous les miroirs sont symétriques et conçus pour une meilleure portée
de vue.
10.Si vous constatez des pièces manquantes ou endommagées, veuillez
prendre une photo et nous contacter.
11.Veuillez vous référer au manuel du propriétaire du véhicule pour régler
les nouveaux rétroviseurs.
12.Si vous ne pouvez pas l'installer vous-même, contactez un
professionnel de la réparation automobile pour le remplacer à votre place.
MODEL AND PARAMETERS
Modèle
YH3337-MB
Position des pièces
automobiles
Façade Extérieure
Pli
Télescopique manuel/pliage manuel
Type de véhicule
applicable
Chevrolet Silverado 1999-2007
/GMC/Cadillac
Couleur
Noir
STRUCTURE DIAGRAM
1.
Pliage manuel 2. Télescopique manuel
3
1
2
4
- 3 -
3. Verre convexe (réglage manuel)
4. Verre plat (réglage manuel)
INSTALLATION INSTRUCTIONS
ÉTAPE 1
4. Ouvrez la porte avant pour retirer le panneau de garniture triangulaire
d'extension supérieure.
5. Retirez le coussin en mousse du panneau de porte.
6. Retirez les (3) écrous hexagonaux de 10 mm fixant le miroir d'usine.
4. Retirez soigneusement le miroir
d'usine.
ÉTAPE 2
4. Prenez le nouveau miroir, insérez les goujons dans les trous du
panneau de porte.
5. Installez les (3) écrous hexagonaux fournis pour fixer le nouveau miroir.
Serrez à 80 lb-po.
6. Insérez le coussin en mousse dans le panneau de porte et réinstallez le
panneau de garniture triangulaire d'extension supérieure.
4. Répétez du côté passager.
MAINTENANCE
- 4 -
1. Frottez le rétroviseur de remorquage lorsqu'il est sale.
2. Prenez l'habitude de replier les rétroviseurs de remorquage lors du
stationnement.
Adresse : Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Importé en Australie : SIHAO PTY LTD, 1 ROKEVA STREETASTWOOD
NSW 2122 Australie
Importé aux États-Unis : Sanven Technology Ltd., Suite 250, 9166
Anaheim Place, Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
Fabriqué en Chine
- 5 -
- 7 -
Zertifikat für technischen Support und E-Garantie
www.vevor.com/support
ANHÄNGERSPIEGEL
MODELL:YH3337-MB
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
- 1 -
MODELL: YH3337-MB
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
13.Bitte lesen Sie diese Anleitung sorgfältig durch, bevor Sie mit der
Installation beginnen.
14.Die richtigen Werkzeuge verbessern die Qualität der Installation und
verkürzen den Zeitaufwand.
15.Alle Spiegel sind symmetrisch und für eine bessere Sichtweite
ausgelegt .
16.Wenn Sie fehlende oder beschädigte Teile finden, machen Sie bitte ein
Foto und kontaktieren Sie uns.
17.Bitte beachten Sie die Bedienungsanleitung des Fahrzeugs, um die
neuen Spiegel einzustellen.
18.Wenn Sie es nicht selbst einbauen können, wenden Sie sich an einen
Autoreparaturfachmann, um es für Sie auszutauschen.
MODEL AND PARAMETERS
Modell
YH3337-MB
Autoteilposition
Vorne draußen
Falten
Manuelles Teleskopieren/manuelles
Zusammenklappen
Anwendbarer
Fahrzeugtyp
Chevy Silverado 1999–2007
/GMC/Cadillac
Farbe
Schwarz
STRUCTURE DIAGRAM
1.
Manuelles Zusammenklappen 2. Manuelles Teleskopieren
3
1
2
4
- 3 -
3.Konvexes Glas (manuelle Einstellung)
4.Flachglas (manuelle Einstellung)
INSTALLATION INSTRUCTIONS
SCHRITT 1
7. Öffnen Sie die Vordertür, um die obere dreieckige Verlängerungsverkleidung zu
entfernen.
8. Entfernen Sie das Schaumstoffpolster von der Türverkleidung.
9. Entfernen Sie (3) 10-mm-Sechskantmuttern, mit denen der Werksspiegel
befestigt ist.
4. Entfernen Sie vorsichtig den
Werksspiegel.
SCHRITT 2
7. Nehmen Sie den neuen Spiegel und führen Sie die Bolzen durch die
Löcher in der Türverkleidung.
8. Installieren Sie (3) der mitgelieferten Sechskantmuttern, um den neuen
Spiegel zu befestigen. Mit 80 lb in anziehen.
9. Setzen Sie das Schaumstoffpolster in das Türblech ein und bringen Sie
die obere dreieckige Verlängerungsverkleidung wieder an.
4. Wiederholen Sie den Vorgang auf der Beifahrerseite.
- 4 -
MAINTENANCE
1.Schrubben Sie den Anhängerspiegel, wenn er verschmutzt ist.
2. Gewöhnen Sie sich an, beim Parken die Abschleppspiegel
einzuklappen.
Adresse: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Importiert nach AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australien
In die USA importiert: Sanven Technology Ltd., Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
In China hergestellt
- 5 -
- 7 -
Supporto tecnico e certificato di garanzia elettronica
www.vevor.com/support
SPECCHIETTI DA TRAINO
MODELLO:YH3337-MB
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
- 1 -
MODELLO: YH3337-MB
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
19.Si prega di leggere attentamente queste istruzioni prima di iniziare
l'installazione.
20.Strumenti adeguati miglioreranno la qualità dell'installazione e
ridurranno il tempo richiesto.
21.gli specchietti sono simmetrici e progettati per una migliore portata
visiva.
22.Se trovi parti mancanti o danneggiate, scatta una foto e contattaci.
23.Fare riferimento al manuale del proprietario del veicolo per regolare i
nuovi specchietti.
24.Se non riesci a installarlo da solo, contatta un professionista della
riparazione auto per sostituirlo.
MODEL AND PARAMETERS
Modello
YH3337-MB
Posizione della parte
automatica
Parte anteriore esterna
Piega
Telescopico manuale/Pieghevole
manuale
Tipo di veicolo
applicabile
Chevy Silverado 1999-2007
/GMC/Cadillac
Colore
Nero
STRUCTURE DIAGRAM
1.
Piegatura manuale 2. Telescopica manuale
3. Vetro convesso (regolazione manuale)
3
1
2
4
- 3 -
4.Vetro piano (regolazione manuale)
INSTALLATION INSTRUCTIONS
PASSO 1
10. Aprire la porta anteriore per rimuovere il pannello di rivestimento triangolare
dell'estensione superiore.
11. Rimuovere il pannello in lamiera della porta con il cuscinetto in schiuma.
12. Rimuovere (3) dadi esagonali da 10 mm che fissano lo specchietto di fabbrica.
4. Rimuovere con attenzione lo specchietto di
fabbrica.
PASSO 2
10. Prendi il nuovo specchio e fai passare i perni attraverso i fori sul
pannello della porta.
11. Installare i (3) dadi esagonali forniti per fissare il nuovo specchietto.
Coppia a 80 libbre pollici.
12. Inserire il cuscinetto in schiuma nella lamiera della porta e reinstallare
il pannello di rivestimento triangolare dell'estensione superiore.
4. Ripetere dal lato passeggero.
MAINTENANCE
1. Strofinare lo specchietto retrovisore quando è sporco.
- 4 -
2. Prendi l'abitudine di ripiegare gli specchietti del rimorchio quando
parcheggi.
Indirizzo: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Importato in AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Importato negli Stati Uniti: Sanven Technology Ltd., Suite 250, 9166
Anaheim Place, Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
Made in China
- 5 -
- 7 -
Soporte técnico y certificado de garantía electrónica
www.vevor.com/support
ESPEJOS DE REMOLQUE
MODELO:YH3337-MB
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
- 1 -
MODELO: YH3337-MB
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
25.Lea atentamente estas instrucciones antes de comenzar la instalación.
26.Las herramientas adecuadas mejorarán la calidad de la instalación y
reducirán el tiempo necesario.
27.Todos los espejos son simétricos y están diseñados para ofrecer un
mejor rango de visión.
28.Si encuentra piezas faltantes o dañadas, tome una foto y contáctenos.
29.Consulte el manual del propietario del vehículo para ajustar los nuevos
espejos.
30.Si no puede instalarlo usted mismo, comuníquese con un profesional
de reparación de automóviles para que lo reemplace por usted.
MODEL AND PARAMETERS
Modelo
YH3337-MB
Posición de pieza de
automóvil
Frente exterior
Doblar
Telescópico manual/plegado manual
Tipo de vehículo
aplicable
Chevy Silverado 1999-2007
/GMC/Cadillac
Color
Negro
STRUCTURE DIAGRAM
1.
Plegado manual 2. Telescópico manual
3.Vidrio convexo (ajuste manual)
4.Vidrio plano (ajuste manual)
3
1
2
4
- 3 -
INSTALLATION INSTRUCTIONS
PASO 1
13. Abra la puerta delantera para quitar el panel de moldura triangular de
extensión superior.
14. Retire la almohadilla de espuma del panel de la puerta.
15. Retire las (3) tuercas hexagonales de 10 mm que sujetan el espejo de fábrica.
4. Retire con cuidado el espejo de
fábrica.
PASO 2
13. Tome el espejo nuevo y pase los montantes a través de los orificios
del panel de la puerta.
14. Instale (3) tuercas hexagonales proporcionadas para asegurar el
nuevo espejo. Apriete a 80 lb pulg.
15. Inserte la almohadilla de espuma en la hoja de la puerta y vuelva a
instalar el panel de moldura triangular de extensión superior.
4. Repita en el lado del pasajero.
MAINTENANCE
1. Frote el espejo retrovisor cuando esté sucio.
2. Adquiera el hábito de plegar los espejos retrovisores al aparcar.
- 4 -
Dirección: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Importado a AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Importado a EE. UU.: Sanven Technology Ltd., Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
Hecho en china
- 5 -
- 7 -
Wsparcie techniczne i certyfikat e-gwarancji
www.vevor.com/support
HOLOWANIE LUSTEREK
MODEL: YH3337-MB
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
- 1 -
MODEL: YH3337-MB
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
31.Przed rozpoczęciem instalacji prosimy o dokładne zapoznanie się z
niniejszą instrukcją.
32.Odpowiednie narzędzia poprawią jakość montażu i skrócą czas jego
montażu.
33.Wszystkie lustra są symetryczne i zaprojektowane z myślą o lepszym
zasięgu widzenia.
34.Jeśli znajdziesz brakujące lub uszkodzone części, zrób zdjęcie i
skontaktuj się z nami.
35., zapoznaj się z instrukcją obsługi pojazdu.
36.Jeśli nie możesz zainstalować go samodzielnie, skontaktuj się z
warsztatem samochodowym, aby go wymienił.
MODEL AND PARAMETERS
Model
YH3337-MB
Automatyczne położenie
części
Przód na zewnątrz
Zginać
Ręczne składanie teleskopowe/ręczne
Odpowiedni typ pojazdu
Chevy Silverado 1999-2007
/GMC/Cadillac
Kolor
Czarny
STRUCTURE DIAGRAM
1.
Składanie ręczne 2. Ręczne teleskopowe
3. Szkło wypukłe (regulacja ręczna)
3
1
2
4
- 3 -
4. Szkło płaskie (regulacja ręczna)
INSTALLATION INSTRUCTIONS
KROK 1
16. Otwórz przednie drzwi, aby zdjąć trójkątny panel wykończeniowy górnego
przedłużenia.
17. Zdjąć podkładkę piankową z panelu drzwi.
18. Odkręć (3) nakrętki sześciokątne 10 mm mocujące lusterko fabryczne.
4. Ostrożnie zdejmij lusterko
fabryczne.
KROK 2
16. Weź nowe lustro i przełóż kołki przez otwory w panelu drzwi.
17. Zamontuj (3) dostarczone nakrętki sześciokątne, aby zabezpieczyć
nowe lusterko. Moment obrotowy do 80 funtów na cal.
18. Włóż podkładkę piankową do poszycia drzwi i ponownie zamontuj
trójkątny panel wykończeniowy górnego przedłużenia.
4. Powtórz po stronie pasażera.
MAINTENANCE
1. Wyszoruj lusterko holownicze, gdy jest brudne.
- 4 -
2. Wyrób sobie nawyk składania lusterek holowniczych podczas
parkowania.
Adres: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Szanghaj
Import do AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW
2122 Australia
Import do USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim Place,
Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
Wyprodukowano w Chinach
- 5 -
- 7 -
Technische ondersteuning en e-garantiecertificaat
www.vevor.com/support
SLEEPSPIEGELS
MODEL: YH3337-MB
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
- 1 -
MODEL: YH3337-MB
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
37.Lees deze instructie zorgvuldig door voordat u met de installatie begint.
38.Het juiste gereedschap verbetert de kwaliteit van de installatie en
verkort de benodigde tijd.
39.Alle spiegels zijn symmetrisch en ontworpen voor een beter zichtbereik.
40.Als u ontbrekende onderdelen of beschadigingen aantreft, maak dan
een foto en neem contact met ons op.
41.Raadpleeg de gebruikershandleiding van het voertuig om de nieuwe
spiegels af te stellen.
42.Als u het niet zelf kunt installeren, neem dan contact op met een
autoreparateur om het voor u te vervangen.
MODEL AND PARAMETERS
Model
YH3337-MB
Automatische
onderdeelpositie
Voorkant Buiten
Vouw
Handmatig telescopisch/handmatig
vouwen
Toepasselijk
voertuigtype
Chevy Silverado 1999-2007
/GMC/Cadillac
Kleur
Zwart
STRUCTURE DIAGRAM
1.
Handmatig vouwen 2. Handmatig telescopisch
3. Convex glas (handmatige aanpassing)
4. Plat glas (handmatige aanpassing)
3
1
2
4
- 3 -
INSTALLATION INSTRUCTIONS
STAP 1
19. Open de voordeur om het bovenste driehoekige sierpaneel te verwijderen.
20. Verwijder het schuimkussentje uit het deurpaneel.
21. Verwijder (3) 10 mm zeskantmoeren waarmee de fabrieksspiegel is bevestigd.
4. Verwijder voorzichtig de
fabrieksspiegel.
STAP 2
19. Neem de nieuwe spiegel en voer de noppen door de gaten in het
deurpaneel.
20. Installeer (3) de meegeleverde zeskantmoeren om de nieuwe spiegel
vast te zetten. Aandraaien tot 80 lb in.
21. Steek het schuimrubberen kussentje in de deurplaat en plaats het
bovenste driehoekige verlengingspaneel terug.
4. Herhaal dit aan de passagierszijde.
MAINTENANCE
1.Schrob de trekspiegel als deze vuil is.
2. Maak er een gewoonte van om de trekspiegels in te klappen tijdens het
parkeren.
- 4 -
Adres: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Geïmporteerd naar AUS: SIHAO PTY LTD, 1 ROKEVA
STREETEASTWOOD NSW 2122 Australië
Geïmporteerd naar de VS: Sanven Technology Ltd., Suite 250, 9166
Anaheim Place, Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
Gemaakt in China
- 5 -
- 7 -
Teknisk support och e-garanticertifikat
www.vevor.com/support
DRAGANDE SPEGLAR
MODELL: YH3337-MB
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
- 1 -
MODELL: YH3337-MB
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
TOWING MIRRORS
- 2 -
NOTES
43.Läs denna instruktion noggrant innan du påbörjar installationen.
44.Rätt verktyg kommer att förbättra kvaliteten på installationen och
minska den tid som krävs.
45.Alla speglar är symmetriska och designade för bättre siktområde .
46.Om du hittar delar som saknas eller är skadade, ta ett foto och kontakta
oss.
47.Se fordonets instruktionsbok för att justera de nya speglarna.
48.Om du inte kan installera den själv, kontakta en bilreparatör för att byta
ut den åt dig.
MODEL AND PARAMETERS
Modell
YH3337-MB
Auto Part Position
Framsida Utanför
Vika ihop
Manuell teleskopisk/manuell fällning
Tillämplig fordonstyp
Chevy Silverado 1999-2007
/GMC/Cadillac
Färg
Svart
STRUCTURE DIAGRAM
1.
Manuell vikning 2. Manuell teleskopisk
3. Konvext glas (manuell justering)
4.Plat glas (manuell justering)
3
1
2
4
- 3 -
INSTALLATION INSTRUCTIONS
STEG 1
22. Öppna den främre luckan för att ta bort den övre förlängningens triangulära
klädselpanel.
23. Ta bort skumkudden från dörrpanelen.
24. Ta bort (3) 10 mm sexkantsmuttrar som håller fast fabriksspegeln.
4. Ta försiktigt bort
fabriksspegeln.
STEG 2
22. Ta den nya spegeln, för dubbarna genom hålen på dörrpanelen.
23. Montera (3) medföljande sexkantsmuttrar för att fästa den nya spegeln.
Vridmoment till 80 lb in.
24. Sätt in skumkudden i dörrarket och sätt tillbaka den övre
förlängningens triangulära beklädnadspanel.
4. Upprepa på passagerarsidan.
MAINTENANCE
1.Skrubba dragspegeln när den är smutsig.
2. Ta för vana att fälla dragspeglarna vid parkering.
- 4 -
Adress: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi
Shanghai
Importerad till AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD
NSW 2122 Australien
Importerad till USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
REP
EC
SHUNSHUN GmbH
Römeräcker 9 Z2021, 76351
Linkenheim-Hochstetten, Germany
REP
UK
Pooledas Group Ltd
Unit 5 Albert Edward House, The
Pavilions Preston, United Kingdom
Tillverkad i Kina
