Pocket speaker
User Manual
Please rea<I this manual carefully before oparatlng the speaker system
Customer Service : support@shopayl.com
57.00 mm-----1►
- I
Volume control function
Volume+
Short slide or slide and hold toward VOL+ to increase volume
Volume
Short slide or slide and hold toward VOL- to decrease volume
Opening The Packing
Please check the speaker Model number marked on the packing carton. Please contact the
sellerassoonaspossible1fyoufindthespeakeristheincorrectmodelorhassustained
shipping damage
Package Included:
• 1 x .t,YLPort bl U1niSp- k•r
• t x USB Ch r11in� Cable
• 1 x ,O.,udioExten,i,mC bl
•
1 x User Manual
h.Tn·'le ·, no!comc,,,.Y,fnfc·,.rH. •,tywlh
otlter destces except br this produu only
Warning!
This device contains an internal power supply
Please read the manual carefully before usage.
Playing music
2. Connect 2 and more speakers for ground-shaking sound
Linkspeakerstogetherbyusingthebuilt-in
3.Smmaudiocableforloudersoundandmorefun
Multi Speakers Linking.
Charge introduction
I .Standard USBconnector
\(. USB charge/ audio input
Charging
( 1 l. -:i Conn•ct •P••k•r ,nd .3 conn•ct with comput•r !or ch.irg•;
(2}.when the lii;ihtb&com&lor&d. iti1ch&ri;iini;i, become blue, th&
b•ttfilryi1fullch,rg•
Patented
Technology
Patented vacuum-bass
t::l f;:;J; - system
(patented Technology)
Diagram and Function Description
( 1). Coilin'il th& 3.5mm eudio plu'iJ on th& bottom wh&n ia not workin'il
(2). Put out the 1.�mm audio plui;i
when
th• i1 .,,,orking
(D. Bottom of the speaker
3.5rnmaudiDinput'Dulpu!
--
USBchmgulaudmiriput
J.�mn1 udioinpul /oulpulplug
@.
Close the
resonator
®· Open the resonator
.
�
Brand Name: AYL
Model
Name: SPK001
Specifications
Dimension: (4>)66MM x {H)S0MM (Closed Mode)
Weight:200g
Poweroutput:JW
Speakers:<D45mm
SNR.!:80dB
AMP Freq Range: 300Hz-16KHz
lithium ion battery input: 380mV
Charge voltage: 5V:!:0.5V
Battery capacity: 550mAh
Charging Time: 2 Hours
Work Time: up to 10 Hours
Suitableambient:0'C 40'C
Certification: CE\FCCIRoHS
A
Please don'tpullextendableresonanceofthe
� bassbox forciblylt will be damaged by this.I
AYL Pocket Speaker (Model: SPK001)
User Manual & Troubleshooting Guide (1 Page)
Product Overview
The AYL Pocket Speaker is a compact, portable wired speaker designed to enhance audio
from compatible devices using a 3.5mm AUX connection. It features a built-in
rechargeable battery, volume control slider, and patented vacuum-bass technology.
IMPORTANT: CONNECTION REQUIREMENT
��� This is a WIRED speaker. Bluetooth is NOT supported.
• Audio input requires a 3.5mm AUX / headphone jack
• Devices without a headphone jack (newer smartphones) require a compatible
3.5mm adapter
• This speaker will not pair wirelessly
Package Contents
• 1 × AYL Pocket Speaker (SPK001)
• 1 × USB Charging Cable
• 1 × 3.5mm Audio Extension Cable
• 1 × User Manual
Getting Started
1. Charging the Speaker
1. Connect the speaker to a computer or USB power source using the included USB
cable
2. Red light = charging
3. Blue light = fully charged
⏱ Charging time: approx. 2 hours
2. Connecting Audio (Required)
1. Pull out the built-in 3.5mm audio plug from the bottom of the speaker
2. Plug it firmly into your device’s headphone/AUX jack
3. Start playback on your device
��� Ensure the audio plug is fully inserted for proper sound output.
3. Volume Control
• Slide toward VOL+ to increase volume
• Slide toward VOL- to decrease volume
• For best performance, increase volume on both the speaker and your device
Troubleshooting Guide
�� No Sound or Low Volume
• Confirm the 3.5mm AUX plug is fully inserted
• Increase volume on both the speaker and the connected device
• Make sure your device is actively playing audio
• Try a dierent audio source to rule out device issues
�� Speaker Does Not Connect
• This speaker does not support Bluetooth
• Confirm your device uses a 3.5mm headphone jack
• If using a phone without a headphone jack, ensure the adapter supports audio
output (not charging only)
�� Speaker Will Not Charge or Turn On
• Use the included USB cable and a known working USB power source
• Allow the speaker to charge for at least 30 minutes before use
• Confirm the charging indicator light is on
�� Sound Is Distorted or Buzzing
• Lower the volume slightly on the speaker and source device
• Ensure the speaker is fully charged
• Avoid forcing or pulling the extendable resonator, as this may damage internal
components
Specifications (Summary)
• Power Output: 3W
• Battery Capacity: 550mAh
• Playback Time: Up to 10 hours (medium volume)
• Charging Voltage: 5V
• Weight: 200g
• Audio Input: 3.5mm AUX (Wired Only)
Warranty & Support
This product includes a 3-Year Manufacturer Warranty.
For questions, troubleshooting, or warranty support, contact:
������� support@shopayl.com
