Quick Installation Guide
Wall Plate Access Point
Note: EAP725-Wall is used as an example throughout the guide.
Images may dier from your actual product.
©2026 TP-Link 7100002929 REV2.0.0
Scan for
EAP Start Guide
1 2 3 4
1 2 3 4
Note: This equipment shall be installed at a height
of less than 2 meters.
Package Contents Installation
Note: Accessories may vary by region and model.
Choose the accessory screws that
t your junction box.
Compatible wall junctions:
Note: For simplicity, this guide uses a Single
Gang US wall junction box for demonstration.
Note: Reinforced or irregularly-designed network
cables may not support this cable routing option.
Φ≤6.5 mm
40–43.6 mm
≤40 mm
Φ≤6.5 mm
40–43.6 mm
≤40 mm
Guide
1×1× 1×
Option 1
Option 2
2
1
2× Φ 7.6 mm (19/64 in)
1× Φ 25 mm (63/64 in)
1×
1×
Option 1
Option 2
Option 3
2× 2×2×
OR
2×2×
Standard EU
Single Gang US Dual Gang US
86 mm
Octagon
Note: Reinforced or irregularly-designed network
cables may not support this cable routing option.
Configuration
PoE Switch
Gateway/Router
EAP EAP
Congure and manage each EAP on its
standalone page.
Option 1: Standalone Mode
Scan for
Standalone Start Guide
PoE Switch
Gateway/Router
On-Premises
Controller
Omada Central
(Cloud-Based)
Or
EAPEAP EAP
Congure and manage EAPs (and other Omada
devices) centrally with an Omada Controller.
Option 2: Controller Mode
Scan for
Controller Start Guide
More Configurations
For more congurations, refer to the User
Guides of the Omada Controller and Omada
Access Points at:
https://support.omadanetworks.com/document/
Omada App
With the TP-Link Omada app, you can access
and manage your Omada devices at a local
site or remotely with a tap of your phone.
Scan for Omada Omada
or
Safety Information
• Keep the device away from water, re, humidity or hot
environments.
• Do not attempt to disassemble, repair, or modify the
device. If you need service, please contact us.
• Do not use the device where wireless devices are not
allowed.
• This device can be powered only by equipments that
comply with Power Source Class 2 (PS2) or Limited
Power Source (LPS) dened in the standard of IEC
62368-1.
• The PoE ports shall not be used to charge lithium
batteries or devices supplied by lithium batteries.
TP-Link hereby declares that the Access Point is in
compliance with the essential requirements and other
relevant provisions of directives 2014/53/EU, 2011 /65/EU
and (EU) 2015/863.
The original EU Declaration of Conformity may be found at
https://www.tp-link.com/en/support/ce/
TP-Link hereby declares that the Access Point is in
compliance with the essential requirements and other
relevant provisions of the Radio Equipment Regulations
2017.
The original UK Declaration of Conformity may be found at
https://www.tp-link.com/support/ukca/
The EAP will be locked after installed.
To uninstall, unlock with the provided
L-Key.
Appendix
For details on the warranty period, policy, and procedures, visit
https://support.omadanetworks.com/warranty-services/.
Warranty
Support
For technical support, user guides, and other
information, please visit
https://support.omadanetworks.com/, or
simply scan the QR code.
More Resources
Main Site
https://www.omadanetworks.com/
https://support.omadanetworks.com/video/
https://support.omadanetworks.com/document/
https://support.omadanetworks.com/product/
https://support.omadanetworks.com/contact-support/
Video Center
Product Support
Documents
Technical Support
1 2 3 4
Option 3
2
1
2× Φ 7.6 mm (19/64 in)
1
2
