In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
INSTRUCTION MANUAL
SOLAR LED GARDEN LIGHT
TECHNICAL DATA
MODEL VT-84043
SKU 24287
SOLAR PANEL 5-7V,1800mAh-0.15W
RATED INPUT 5V 1A
LUMENS 150 Lm
BEAM ANGLE 180°
CRI ≥80
LIFE SPAN 20,000 Hours
MATERIAL METAL
DIMENSION Ø120*345mm
IP65
BATTERY CHARGING TIME WORKING TIME
1800 mAh
Ni-MH Battery
11 Hours 4-25 Hours
WARNING
1.
before starting the installation.
3. The light source of this luminaire is not
replaceable, when the light source reaches
2. Please charge before use !
its end of life the whole luminaire should be
replaced.
Solar panel
• Touch Dimming (3 Levels): Tap to cycle
slight – medium – brightest
• Power Off – Long touch (2 seconds)
PACKAGE CONTENTS
OPERATION CAUTIONS
1. Don’t connect with dimming sensing device
2. Don’t use the lamp in a humid or flammable environment.
3. Don’t pull the power plug when your hands are wet to prevent electric shock
4. Don’t cover the lamp with objects to prevent the lamp from being damaged
or causing danger.
LED Lamp
Instruction
SOLAR PANEL MAINTENANCE & WARNING
•
Do not use solvents, petrol, etc. Otherwise the light will be damaged.
•
Clean the light with a dry, lint-free cloth.
•
Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee
flawless function of the product.
•
Especially during the winter, keep the product free from snow and ice.
•
•
Keep away from the fire.
Don’t immerse in the water.
