AIRC
HARGE
WIRELESS
CHARGING PAD
AIR43419
Ho
w to Use & Main Functions
US
B Type C / Charging Area
C
onnect a USB Type-C cable to the wireless charger
USB Type-C power input.
Place your wireless charging–compatible device on
the charging area; charging will start automatically.
This product uses magnetic induction technology.
Due to the characteristics of this technology, if the
device is not properly aligned with the charging
area, charging may not start correctly.
Using a USB power source with a lower current than
specied may cause malfunction. It is recommend-
ed to use an adapter that provides the specied
current.
In case of a charging error (indicated by the LED
blinking), li the device from the charger and place
it back on to resume normal charging.
If the problem persists, disconnect the USB cable,
wait about 10 seconds, and reconnect it before
using it again.
Depending on the device model and usage
environment, there may be a delay of about 4–5
seconds before charging begins aer placing the
device on the charger.
This is a natural phenomenon caused by magnetic
eld synchronisation and does not indicate a defect
in the device or charger.
U
sage Precautions
Do not
disassemble, modify, or repair the product
yourself.
As this is an electrical device, avoid use in places
with re, excessive heat, or humidity.
If the product comes into contact with water,
alcohol, benzene, or other chemicals, or is exposed
to re risk, immediately disconnect the power
supply and only use it again aer ensuring it is safe.
During charging, place the device on the wireless
charger and check the LED or device display to
conrm charging has started correctly.
Do not drop the product from high places.
Do not place heavy objects on the wireless charger.
Do not touch the outlet or plug with wet hands, as
this may cause electric shock or re.
LED St
atus & Sequence
Charging in Progress
RED
Fully Charged
GREEN
FLASHING RED
Error
On po
wered up, red for 2 seconds, then
green for 2 seconds, and then o (standby).
For certain devices, the LED indicator may
remain red even aer charging is complete.
This behaviour is normal and does not
indicate a malfunction
Input: 5V / 2A
Output: 5W Max
Operating Ambient Temperature: 0°C to 30°C
Product Dimensions: W: 70 mm / L: 70 mm / H: 11 mm
Product Weight: 44g
Operating Frequency: 115-205 kHz
Pr
oduct Specication
against harmful interference in a residential installation.
Any Changes or modifications not expressly approved
FCC Caution:
by the party responsible for compliance could void
the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
IMPORTANT NOTE:
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV
technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated with
body.
minimum distance 20cm between the radiator& your
