Overview
The WR01 is a high-performance RS-485 elevator card reader specifically engineered for Fanvil elevator control
systems. Supporting 13.56 MHz IC card identification with a stable reading range of 3 cm to 5 cm, the reader enables
precise and secure management of floor access permissions.
Features
Specification
Card Types
13.56 MHz RFID card
Identification Time
0.1 seconds
Communication Interface
RS-485
Frame Color
Starlight silver
Operating Voltage
12 VDC
Operating Current
50 mA
Operating Temperature
−30 °C to +70 °C (−22 °F to +158 °F)
Supports 13.56 MHz RFID card
Powder-coated metal frame and backlit tempered glass
Starlight silver finish delivers a premium look and feel
Fanvil WR01 Elevator Card Reader
Compatible with Fanvil elevator control systems
Fanvil Link Technology Co., Ltd.
Add: 13th Floor, Building 2, Runzhi R&D Center, Xin'an Street, Bao'an District, Shenzhen, China
Operating Humidity
15% to 95% RH
Mounting Dimensions
Cable hole: Ø20 mm;
Screw hole: Ø8 mm
Product Dimensions
86.0 mm × 56.0 mm × 8.0 mm (3.39" × 2.20" × 0.32") (L × W × H)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interferenc
(2)this device must accept any interference received, including interference that may cause unde operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This device meets the FCC requirements for RF exposure.The device is designed for normal indoor use and complieswith applicable
FCC exposure limits.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
