QUICK START GUIDE
Networked Multi-room Amplier
MODEL M4
1
EN
DE
FR
IT
ES
NL
SV
RU
PL
ZH
JA
Before you begin STEP 1: Unpack
The MODEL M4 is designed
to add HEOS multi-room
audio functionality with the
convenience of a centrally
located and rack-mountable
multi-channel amp.
Make sure you have the following items in working order:
Apple iOS or Android
mobile device connected
to your network
Speakers &
Speaker Wires
Internet
Connection
Network
router
Carefully unpack your new MODEL M4.
Verify that the following items are included in the box.
MODEL M4
Power cords
Rack mount brackets
Ethernet cable
2
EN
DE
FR
IT
ES
NL
SV
RU
PL
ZH
JA
STEP 2: Place
Place the MODEL M4 on a sturdy shelf.
Mount in a rack (Optional)
Remove the two screws on each side of MODEL M4.
Align the included rack mount brackets with the screw
holes and reattach the screws making sure they are secure.
1
Remove the feet on the bottom of MODEL M4.
2
Rack mount the MODEL M4 using the included rack
mount brackets.
3
3
EN
DE
FR
IT
ES
NL
SV
RU
PL
ZH
JA
STEP 3: Connect
Connect up to 4 pairs of speakers.
1
(R)
wq
wq
(L)
Connect the power cord.
Choose proper power cord in your region.
3
Turn on the power switch.
4
Connect the MODEL M4 to your network using the
included Ethernet cable.
2
4
EN
DE
FR
IT
ES
NL
SV
RU
PL
ZH
JA
STEP 4: Control
Download the HEOS app.
Go to the Apple App Store, Google Play or Amazon App Store and
search for “HEOS” to download and install.
1
Launch the HEOS app and follow the instructions in the app.
2
STEP 5: Con gure
1
2
Home
Add Device
Home
Settings
My Devices
ENJOY!
The MODEL M4 will appear on the Rooms Tab. Go to Settings/
My Devices to edit the default settings of your MODEL M4.
5
EN
DE
FR
IT
ES
NL
SV
RU
PL
ZH
JA
Owner’s manual
Refer to the online manual for other functions, information and
operation procedure details.
manuals.marantz.com/MODELM4/ALL/EN/
We hope you will enjoy your Marantz product for years to come. If
you ever have any question or need any support, just get in touch
via the free helpline. We are happy if you are happy.
In case you can’t reach the helpline please check the support
section on www.marantz.com for more information.
Contact Marantz
1-800-654-6633
(for North America)
00800-43674357
(for Europe)
