1
INSTRUCTION MANUAL
20W Heavy Duty
Rechargeable COB Worklight
Powerful COB lights
produce super bright
light upto 2000 lumens
with wide spread
illumination
Rugged construction
with aluminium die cast
housing & rubberised
plastic corner protectors
make these lights Impact
Resistant
Swivel Handle can be
rotated 180° and can be
adjusted to any angle
Detachable magnet
attaches onto any
metallic surface leaving
both hands free
2 Working Mode
1. 100% Intensity
2. 50% Intensity
Ideal for outdoor use on
construction equipment,
tractors, farm machinery,
service vans, emergency
vehicles etc.
Available in 2 variants
1. 10W
2. 20W
5V DC
USB CABLE
POWER
SOURCE
IP54
WATER & DUST
PROOF RATING
NEW!
COB LED 20W COB
LUMEN 1000-2000
BATTERY 7.4V, 4400 mAh Li-ion
RUN TIME 3-6 hrs
CHARGING TIME 5 hrs
SPECIFICATIONS
2
SAFETY INFORMATION
• Keep the work area clean and dry. Damp or
wet work areas can result in injury.
• Check for damaged parts and any other
conditions that may aect the operation
of this product. Replaced damaged parts
immediately
• Do not use the lamp in the immediate vicinity
of inflammable materials or gases.
• Only use the accessories included with the
product.
• Keep the lamp out of reach of unauthorised
persons, especially children.
• Do not point the light directly in your own or
any other person’s or animal’s eyes.
PACKAGING CONTENT
NOMENCLATURE
OPERATING INSTRUCTIONS (Refer
“NOMENCLATURE”)
Charging:
• Fully charge the battery before the first use.
• Turn o the light and connect to the supplied
micro USB charger cable.
• When the battery is fully charged, all the
indicator LEDs will constantly turn GREEN .
• Full charging takes about 5 hours.
Operation:
• To switch ON the light press the button at
the back of the unit.
• To change the intensity of light press the
button again.
• Mount the magnetic base on the stand
as shown below to mount the light on a
metallic surface.
MAINTENANCE
• Before cleaning the LED worklight,
disconnect the USB cable(if being charged)
and allow the worklight to cool down
suciently.
• Clean with a dry or slightly moist, clean, lint-
free cloth and a mild detergent if required.
• Do not use cleaners that contain abrasives
or solvents.
• Check the LED worklight for damage before
each use. If the lens is damaged it must be
replaced immediately.
• Clean any dirt from the housing or the
lens immediately, since it could cause
overheating.
DISPOSAL
The components or the used products must
be given to companies that specialize in the
disposal and recycling of industrial waste.
DESCRIPTION QUANTITY
Light 1
Magnetic base 1
USB cable 1
A. ON/OFF button (100% /50%)
B. 5V DC micro USB charging port
C. USB output port for use as Power Bank
D. 4 Battery level indicator
A
B
C
D
3
