INSTRUCTION MANUAL
9W LED
Rechargeable Worklight
9W Rechargeable
Worklight
Light Output
High quality & uniform
output of 500 lumen
Dual Colour Output
• White
• Amber
Sturdy, Weather
Proof Construction
a. IP 65 Rated
Protected against
dust and eects
of low pressure
water jet from any
direction
b. Corrosion resistant
aluminum die
cast housing in
premium powder
coated finish
Available with
magnetic base;
conveniently attaches
to any metallic surface
leaving both hands
free
RUN TIME
4 H
10 M
BEAM
DISTANCE
BEAM ANGLE
60°
LUMEN
500
IP65
WATER & DUST
PROOF RATING
−10°C TO 45°C
(14°F to 113°F)
OPERATING TEMPERATURE
SPECIFICATIONS
LIGHT 9W LED Rechargeable Worklight
LUMEN OUTPUT (WORKLIGHT) 500
OPERATING TIME (WORKLIGHT) 4 hours
MATERIAL PC, TPR, Aluminum
DIMENSION 5-23/32 × 7-11/64 × 3-21/32 Inch (145 x 182 x 93 mm)
WEIGHT
270°
Rotation
270° pivoting head
directs the light
beam to the required
direction
LITHIUM-ION
RECHARGEABLE
RECHARGEABLE
BATTERY
3.7V 6600 mAH
Charging of Battery
Battery can be
recharged using USB
cable provided with
the light
Charge Time
8-10 hours
Ideal For Portable
Working
In maintenance,
building construction,
temporary lighting
jobs etc.
2
SAFETY INFORMATION
• Follow workshop health & safety rules,
regulations and conditions when using the 9W
LED Rechargeable Worklight.
• When not in use, 9W LED Rechargeable
Worklight should be stored in a dry location to
inhibit rust.
• During their period of use, accessories must be
checked for wear, cracks and other damage,
replace any damaged or worn parts.
• Use genuine parts only. Unauthorized parts
may be dangerous and will void the warranty.
• Keep the 9W LED Rechargeable Worklight
clean and in good working order for best and
safest performance.
• DO NOT use the lamp in the immediate vicinity
of inflammable materials or gases.
• DO NOT point the light directly in your own or
any other person’s or animal’s eyes.
• DO NOT drop, throw or abuse the 9W LED
Rechargeable Worklight.
• Eyes protection: Wear a protective mask or
protective eyewear.
• Check that the product has not suered any
damage during transport or storage. Clean and
remove any dust or residual packing material.
• Read the instructions carefully before using
9W LED Rechargeable Worklight and keep
them for further reference.
WARNING!
• DO NOT immerse 9W LED Rechargeable
Worklight.
• DO NOT place 9W LED Rechargeable
Worklight near a fire or any other source of
intense heat.
• DO NOT attempt to open, disassemble, modify
or service the worklight.
• DO NOT expose 9W LED Rechargeable
Worklight to temperatures above 45°C (113° F).
• DO NOT use 9W LED Rechargeable Worklight
if you suspect that the batteries or the casing
is damaged
PACKAGING CONTENT
DESCRIPTION QTY.
9W LED Rechargeable Worklight 1
USB cable 1
O.I.P.M. 1
OPERATING INSTALLATION
1. Fully charge the battery before the first use.
To charge, connect the worklight with USB
charger cable provided with it.
2. While charging, the LED Charging Indicator
will glow Red colour.
3. When the battery is fully charged, the LED
Charging Indicator will glow Green colour. Full
charging takes about 8-10 hours.
4. Press the power button located at the back of
the light
• Once for High Intensity Worklight “ON”
• Twice for Low Intensity Worklight “ON”
• Three times for Amber SOS Flashing “ON”
• Four times for switching “OFF” the light
MAINTENANCE
• Clean any dirt from the housing or the lens
immediately, since it could cause overheating.
• If required, clean with a dry and clean cloth.
Do not use cleaners that contain abrasives or
solvents.
• When not in use, 9W LED Rechargeable
Worklight should be stored in a dry location.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The 9W LED Rechargeable Worklight has low
lumen output or does not work.
Low battery Recharge the battery
If the 9W LED Rechargeable Worklight still
doesn't work
Contact nearest authorized service dealer
DISPOSAL
The components or the used products must be given to companies that specialize in the disposal and
recycling of industrial waste.
TROUBLE SHOOTING
