BIGTOAST DOUBLE
Tostador / Toaster
Manual de instrucciones
Instruction manual
Manuel d’instructions
Bedienungsanleitung
Manuale di istruzioni
Manual de instruções
03084_BigToast Double_Manual_YV_01200430.indd 103084_BigToast Double_Manual_YV_01200430.indd 1 4/5/20 12:014/5/20 12:01
BIGTOAST DOUBLE
26
ENGLISH
1. PARTS AND COMPONENTS
Fig. 1
1. 35-mm (maximum width) and 130-mm bread slots (maximum height).
The slots allow you to bake many different products.
2. Elevation-system control lever
For a 80-mm high slice of bread, the top edge should not be less than 20 mm above the
toaster's surface after the elevation system comes out.
3. Button for bagels
4. Reheating button
5. Defrosting button
Add extra time to the cycle for toasting frozen bread.
6. Stop button
7. Toasting-control selector
8. Removable crumb tray
9. Cord storage
10. Pastry holder
2. OPERATION
Unwind the power cord. Check that the crumb tray is in correctly placed and that there is
nothing inside the toaster slots. Plug the power cord into the wall outlet.
1. Insert slice(s) of bread inside the device.
2. Set the level of toasting
Turn the toasting-control selector to select the toasting of your toasts:
Browning control setting Toasting type
1-2 Light
2-4 Medium
5-6 Dark
3. Toasting the bread:
• For slightly dry bread, use a lower setting than you normally would.
• For fresh bread or whole-wheat bread, use a higher setting than normal.
• Breads with uneven surfaces (such as muffins) will require a higher toast setting.
• Thick slices of bread (including bagels or baguettes and muffins) will take longer to toast,
sometimes significantly longer, since more moisture must be evaporated for the bread to
03084_BigToast Double_Manual_YV_01200430.indd 2603084_BigToast Double_Manual_YV_01200430.indd 26 4/5/20 12:014/5/20 12:01
BIGTOAST DOUBLE
27
ENGLISH
be toasted. Very thick slices may require two cycles.
• When toasting bread with raisins or with other fruits, remove any loose raisins, etc. from
the surface of the bread before putting it into the toaster. This will prevent fruit pieces
from falling into the toaster or sticking inside the slot.
• Before toasting bagels/baguettes, slice each bagel/baguette into two equal halves.
3.1 Toasting one slice:
For toasting a single slice of bread, set the toasting selector to a lower setting than you
normally would. The device is designed to heat both bread slots. By lowering the heat lever for
a single slice, you will not over-toast it.
3.2 Frozen waffles, pancakes, French toasts and frozen bagels should be cooked using the
Defrost button.
3.3 Pastries
Be careful when toasting pastries; the filling can become quite hot, long before the surface of
the pastry is toasted. Do not leave pastries unattended while toasting.
4. Starting and stopping the toasting:
For starting the toasting, push down the lever until it reaches its lock-down position.
When the toasting cycle is over, the toast will come out automatically.
For stopping the toasting before it finishes, just press the Stop button.
Note: Do not force the bread into the slots.
Do not introduce glazed or stuffed pastries or buttered breads as this may cause a fire.
Uneven toasting usually happens because of toasting bread of uneven thickness.
After using it, unplug the device from the electrical outlet.
5. Defrosting button
The defrosting function is intended to defrost the bread and then toast it slightly.
5.1 Introduce a slice of bread
Make sure the slices of bread do not overlap and that the lever is lifted.
5.2 Set the toasting selector
• Settings 1-2: For frozen breads and thinner frozen pieces such as frozen pancakes.
• Settings 3-4: For pastries, frozen waffles, thin baguettes and frozen bagels.
• Settings 5-6: For thicker frozen items such as bagels, hand-cut bread and thick baguettes
5.3 Begin toasting: Push down the lever until it reaches its lock-down position (it must remain
fix).
5.4 Press the Defrost button. A LED light will indicate that this feature has been activated.
5.5. When the defrosting is completed, the lever will go to its upper position taking with it the
bread. If you wish to stop the cycle before it finishes, just press the Stop button. After using
the device, unplug it.
03084_BigToast Double_Manual_YV_01200430.indd 2703084_BigToast Double_Manual_YV_01200430.indd 27 4/5/20 12:014/5/20 12:01
BIGTOAST DOUBLE
28
ENGLISH
6. Reheating button
The reheating function is intended to reheat the bread without toasting it.
6.1 Introduce a slice of bread. Make sure they do not overlap and the lever is lifted (it must
remain fix).
6.2 To begin reheating, push down the lever until it reaches its lock-down position.
6.3 Press the Reheating button. A LED light will indicate that this feature has been activated.
6.4 When the reheating is completed, the lever will go to its upper position taking with it the
bread. If you wish to stop the cycle before it finishes, just press the Stop button. After
using the device, unplug it.
7. Bagel button
This functions is designed to last the same as the toasting cycle. When you use it to toast
thicker breads, baguettes, muffins or other thick breads, a higher toasting setting may be
required.
7.1 Insert slice(s) of halved bagels/baguettes. Make sure they do not overlap.
7.2 Push down the lever until it reaches its lock-down position (it must remain fix).
7.3 Press the Bagel button. A LED light will indicate that this feature has been activated.
7.4 When this function is completed, the lever will go to its upper position taking with it the
bread. If you wish to stop the cycle before it finishes, just press the Stop button. After
using the device, unplug it.
8. Pastry holder
To reheat the pastry, place the holder on the device, using the side clampings. Make sure the
clampings ends are slightly inside the slots. Place the food on the holder.
To start the reheating, push the lever all the way down (it should remain fix).
Press the reheat button. A LED light will indicate that this function has been activated
When the reheating is completed, the lever will go to its upper position. If you wish to stop the
cycle before it finishes, just press the Stop button. After using the device, unplug it.
3. CLEANING AND MAINTENANCE
Disconnect the appliance from the power supply and allow it to cool down before cleaning.
Use a soft, damp cloth to clean the product’s surface.
Do not immerse the appliance in water or other liquid.
Do not use abrasive scouring pads, powders or cleaners.
To remove any crumbs inside the device, take out the crumb tray. Do not operate the device
without the crumb tray in place.
To remove any crumbs of bread remaining in the device, turn the device upside down and shake
it carefully. Do not insert any hard or sharp objects inside the slot, as this could damage the
device.
Do not wrap the power cord around the outside of the device. Use the cord storage cleats
03084_BigToast Double_Manual_YV_01200430.indd 2803084_BigToast Double_Manual_YV_01200430.indd 28 4/5/20 12:014/5/20 12:01
BIGTOAST DOUBLE
29
ENGLISH
under the device.
4. TECHNICAL SPECIFICATIONS
Product reference: 03084
Product: BigToast Double
840-1000W, 220-240V~ 50-60Hz
5. DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), specifies that old household electrical appliances must
not be disposed of with the normal unsorted municipal waste. Old appliances
must be collected separately, in order to optimize the recovery and recycling
of the materials they contain and reduce the impact on human health and
the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation to dispose
of the appliance correctly. If the product has a built-in battery or uses batteries, they should be
removed from the appliance and disposed of appropriately.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.
6. TECHNICAL SUPPORT SERVICE AND WARRANTY
This product is under warranty for 2 years from the date of purchase, as long as the proof
of purchase is submitted, the product is in perfect physical condition, and it has been given
proper use, as explained in this instruction manual.
The warranty will not cover the following situations:
The product has been used for purposes other than those intended for it, misused, beaten,
exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault
attributable to the customer.
The product has been disassembled, modified, or repaired by persons, not authorised by the
official Technical Support Service of Cecotec.
Faults deriving from the normal wear and tear of its parts, due to use.
The warranty service covers every manufacturing defects of your appliance for 2 years, based
on current legislation, except consumable parts. In the event of misuse, the warranty will not
apply.
If at any moment you detect any problem with your product or have any doubt, do not hesitate
to contact Cecotec Technical Support Service at +34 963 210 728.
03084_BigToast Double_Manual_YV_01200430.indd 2903084_BigToast Double_Manual_YV_01200430.indd 29 4/5/20 12:014/5/20 12:01
Fig./Img./Abb. 1
2
10
3
4
5
6
9
7
8
1
03084_BigToast Double_Manual_YV_01200430.indd 4903084_BigToast Double_Manual_YV_01200430.indd 49 4/5/20 12:014/5/20 12:01
