Website: www.mova-tech.com
Manufactured by:Moonstone Technology (Shaoxing) Co., Ltd.
Made in China
HMH15A-AU-A02
The illustrations in this manual are
for reference only. Please refer to the
actual product.
User
Manual
Wet and Dry Vacuum
M10
CONTENTS
Important Safety Instructions
Product Overview
Installation
Charging
How to Use
Care & Maintenance
Troubleshooting
Error Prompts and Solutions
Specifications
Battery Disposal and Removal
Warranty
01
04
08
08
09
13
16
17
18
18
19
THANK YOU
For purchasing this
Wet and dry vacuum.
The high-quality product is engineered
for optimal performance.
If you have any questions on the product,
please contact us:
https://global.mova-tech.com/pages/contact-us
For more product information,
please visit www.mova-tech.com
1
EN
Important Safety Instructions
Please read this manual carefully before use and retain it for future reference.
When using an electrical appliance, basic precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE). Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
To reduce the risk of fire, electric shock, or injury:
WARNING —
· This appliance should not be used by children younger than 8 years old nor persons with
physical, sensory, intellectual deficiencies, or limited experience or knowledge with out the
supervision of a parent or guardian to ensure safe operation and to ayoid any risks. Cleaning
and maintenance shall not be performed by children without supervision.
· Plastic film can be dangerous. To avoid the danger of suffocation, keep it away from
children. Children shall not play with the appliance.
· Use indoors only, on non-carpeted floor surfaces such as vinyl, tile, sealed wood, etc. Be
careful not to run over loose objects or the edges of area rugs. Stalling the brush may result
in premature belt failure.
· Use only as described in this user guide. Use only manufacturer's recommended
attachments.
· Do not expose the appliance to fire or excessive temperature. Exposure to fire or excessive
temperature may cause an explosion.
· Do not use in extremely hot or cold environments (below 5° C/41° F or above 40° C/104° F).
Please charge the appliance in temperature above 5° C/41° F and below 40° C/104° F.
· Do not immerse the appliance in liquid.
· Do not use to pick up flammable or combustible liquids, such as gasoline. Do not use in
areas where flammable or combustible liquids may be present.
· Do not put any object into openings. Do not use the appliance when any opening is blocked.
Keep free of dust, lint, hair, and anything that may inhibit air flow.
· Do not pick up toxic material (chlorine bleach, ammonia, drain cleaner, etc.). Do not pick up
hard or sharp objects such as glass, nails, screws, coins, etc.
· Do not use the appliance in an enclosed space filled with vapor given off by oil-based paint,
paint thinner, some moth-proofing substances, flammable dust, or other explosive or toxic
vapour. Do not pick up anything that is burning or smoking, such as cigarettes, matches or
hot ashes.
· Do not use the appliance without filters in place.
· Keep hair, loose clothing, fingers, and all parts of the body away from openings and moving
parts of the appliance and its accessories.
· Keep ground cables away from the appliance when using it. A hazard may occur if the
appliance runs over a supply cord.
· Use extra care when cleaning on stairs.
Usage Restrictions
2 3
EN EN
Important Safety Instructions
· Under abusive conditions, never contact the battery from which the liquid may be ejected.
If contact accidentally occurs, rinse with water. If liquid contacts eyes, seek medical help
immediately. Liquid ejected from the battery may cause irritation or burns.
· The charging base is capable of charging the 6-cell 4000 mAh battery pack. This charging
base should not be used to charge non-rechargeable batteries. Failing to do so may cause
the lithium-ion battery to catch fire.
· The charging base is marked with a icon indicating "Caution: Hot Surface". Do not touch
the brush roller, hot water, or heating module of the charging base while self-cleaning with
hot water.
· The instructions for appliance with a liquid dispensing system specify the amount and type
of the liquid to be used (IEC 60335-2-10).
We, Moonstone Technology (Shaoxing) Co., Ltd., hereby declares that this equipment is in
compliance with the applicable Directives, European Norms, and amendments. The full text of
the EU declaration of conformity is available at the following internet address:
www.mova-tech.com
For detailed e-manual, please go to
https://www.mova-tech.com/pages/user-manuals-and-faqs
Symbols
Read operator's manual
Caution: Hot Surface
All products bearing this symbol are waste electrical and electronic equipment (WEEE
as in directive 2012/19/EU) which should not be mixed with unsorted household waste.
Instead, you should protect human health and the environment by handing over your waste
equipment to a designated collection point for the recycling of waste electrical and electronic
equipment, appointed by the government or local authorities. Correct disposal and recycling
will help prevent potential negative consequences to the environment and human health.
Please contact the installer or local authorities for more information about the location as
well as terms and conditions of such collection points.
WEEE Information
For indoor use only
Time-lag miniature fuse-link where T 3.15A is the symbol for the time/current
characteristic
Class II equipment
T 3.15A
Important Safety Instructions
Maintenance and Storage
· Prevent unintentional starting. Ensure the switch is in the OFF-position before picking
up or carrying the appliance. Carrying the appliance with your finger on the switch or
turning on the appliance may result in an accident.
· Ensure that the appliance is placed on a horizontal surface. Do not use the appliance at
the same position if the appliance is equipped with a brush roller and the handle is not
completely upright. Do not store the appliance in a place where it may freeze.
· Switch off and unplug the appliance when not in use, before cleaning, maintaining or
servicing it, and before connecting or disconnecting it with a moving brush.
· Do not use an appliance that is damaged or modified. A damaged or modified appliance
may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury.
· Do not modify or attempt to repair the appliance except as indicated in the instructions
for use and care.
· Do not use the appliance with a damaged attachment (eg: charging base, supply cord
etc.). If the appliance or attachment has been dropped, damaged, left outdoors, dropped
into water, or is not working as it should, never attempt to operate it. Please have it
repaired at an authorized service center.
· Have servicing performed by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the appliance is maintained.
· For the purpose of recharging the appliance, only use the charging base provided with
this appliance. Use only with HCBX charging base.
· Follow all charging instructions and do not charge the appliance outside of the
temperature range specified in the battery as doing so increases the risk of fire.
· Charging base is equipped with drying function and only suitable for drying this
appliance's brush.
· Keep the charging base cable away from heated surfaces. Do not handle the charging
base plug or appliance with wet hands. To unplug, grasp the charging base plug, rather
than the cable.
· Do not pull or carry charging base by cable, use cable as a handle, close door on cable,
or pull cable around sharp edges or corners.
· Do not use any non-rechargeable battery pack. Failing to do so may cause the lithium-
ion battery to catch fire. This appliance contains batteries that can only be replaced by
qualified technicians or after-sales service.
· The lithium-ion battery pack contains substances that are hazardous to the environment.
Before disposing of the appliance, please first remove the battery pack, then discard,
or recycle it in accordance with local laws and regulations of the country or region it is
used in.
· The appliance must be disconnected from the power supply when removing the battery.
Keep batteries out of the reach of children. Never put batteries in mouth. If swallowed,
contact your physician or local poison control.
Battery and Charging
4 5
EN EN
Product Overview
Display Screen
Used Water Tank
Brush Roller
Cover Release
Buttons
Self-Cleaning Button
Mode Switch
Carrying Handle
Voice Prompt Button
Power Switch
Brush Roller Release
Button
Clean Water
Tank
· Press briefly to activate the voice prompt
or adjust the volume.
· Press and hold for 3 seconds to access
the language settings. Press to switch
between languages. Press and hold to
confirm the selection.
Vacuum
Product Overview
Packing List
Main Body Charging Base
Cleaning Brush
Handle
Spare Brush
Roller
Replacement
Filter
6 7
EN EN
Product Overview
Display Screen
1
2
3
4
5
7
8
9
10
6
1
6
8
7
9
10
2
3
4
5
Note: If the appliance is not working properly, the display screen will show an error message. Please refer to
the Error Prompts and Solutions table to find your solution.
Drying Mode
Low Battery/Charging Indicator
Smart Mode
Suction Mode
Mode Switch
Press briefly to switch.
Dust Concentration Indicator
The color of the indicator changes
with the amount of dirt in real time.
Error Messages
Ultra Mode
Self-Cleaning Mode
Power Switch
Press briefly to start/stop cleaning.
Product Overview
Charging Base
Clean Water Tank
Clean Water Tank
Release Button
Charging
Contacts
Power Cord
Clean Water
Tank Cover
8 9
EN EN
Switching Modes
Press the mode switch to switch modes according to your needs.
How to Use
Filling the Clean Water Tank
Press the Clean Water Tank release button to remove the tank. Open the tank cover and fill
the tank with clean water. Install the Clean Water Tank and ensure it clicks into place.
Adding Cleaning Fluid
1. Remove the seal before use.
2. Measure the floor cleaner with the bottle cap (*approximately 10 ml/0.34 fl oz ).
3. Pour it into the Clean Water Tank and gently shake to mix evenly before use.
Note: Do not add any liquids other than the officially-approved cleaner. The cleaner can be available on the
official online store.
WARNING: To reduce the risk of fire and electric shock due to internal component damage, use only mova
AWH10 cleaning fluid intended for use with the appliance.
Note: To disassemble, extend a hard object into the hole of the appliance as indicated to press in
the contacts and pull the handle upwards at the same time.
click
Installation
· Breathing Orange: Battery level ≤ 20% (charging)
· Breathing Green: Battery level > 20% (charging)
· Solid Green: Full charged
· Solid Orange: Battery level ≤ 20%
Charging/Low Battery Indicator
Insert the end of the handle vertically into the port on the top of the appliance as indicated
until you hear a click.
1. Place the charging base against a wall on level ground and connect it to a power source.
Fully charge the appliance before first use.
2. Place the appliance on the charging base. The battery is fully charged when the number on
the display screen reaches 100.
Note:
· If there is no operation within 10 minutes of being fully charged, the vacuum will enter sleep mode.
Please restart the appliance if you need to use it.
· To extend the battery life time, the battery keeps cooling down automatically after you have used the
appliance for a long time.
Charging
10 11
EN EN
How to Use
Emptying the Used Water Tank
1. Press the Used Water Tank release button to remove the tank.
2. Pull up the Used Water Tank cover handle, lift off the cover, and pour out the used water.
1
2
How to Use
Starting Cleaning
Note:
· Do not vacuum any foamy liquids.
· Make sure the appliance is in upright position before turning off the power while the appliance is lying
flat.
· The appliance is suitable for cleaning floors, marble, tiles and other hard surfaces.
· When the appliance is in operation, do not lift it off the ground, move it or tilt it. Otherwise, the used
water may flow into the motor.
Gently step on the brush cover and recline the appliance backwards. Press the power
switch to start/stop operating. If the appliance is in the upright position while working,
the current task will be suspended. The appliance is designed for lying flat at a 180-degree
angle, enabling it to reach and clean under the low-profile furniture.
12 13
EN EN
Cleaning the Used Water Tank
Care & Maintenance
· Turn off the appliance before maintenance. Do not touch the power switch.
· Replace parts if needed. The parts must be replaced by those available from the
manufacturer or its service agent.
· If the appliance is not used for an extended period, fully charge it, unplug the power plug,
and store the appliance in a cool, low-humidity environment away from direct sunlight. To
avoid over-discharge of the battery, charge the appliance at least once every 3 months.
Note: It is recommended to clean the Used Water Tank in time after each use, as well as before and after
the self-cleaning.
1. Press the Used Water Tank release button
to remove the tank.
2. Pull up the Used Water Tank cover
handle, lift off the cover. Remove the filter
from the cover.
4. Re-install the filter and the Used Water
Tank cover. Then re-install the Used Water
Tank until you hear a click.
3. Rinse the Used Water Tank and
the tank cover with water. Use the
provided cleaning brush to clean the
inner walls of the tank.
Filter
Used Water
Tank Cover
Solid Waste
Filter Basket
Used Water
Tank
Tips:
click
How to Use
Self-Cleaning With Hot Water & Drying Mode
1. Place the appliance back onto the base. Ensure that the water in the Clean Water Tank is
sufficient for self-cleaning.
2. Briefly press the self-cleaning button on the top of the handle to start/stop self-cleaning.
Switch the self-cleaning with hot water mode according to the voice prompts.
3. Please empty the Used Water Tank after self-cleaning is completed and drying mode has
been engaged. Press the button to exit drying mode.
Note:
· Do not touch the brush roller, hot water, or heating module of the charging base while self-cleaning with
hot water.
· The self-cleaning function can be enabled only when the appliance is being charged and the battery
level is more than 20%. If the battery level is lower, please charge to 20% before starting self-cleaning.
1
2
14 15
EN EN
Care & Maintenance
Cleaning the Brush Assembly
Note:
· Do not rinse the brush assembly with water.
· Clean as needed. Replacing the brush roller every 3 to 6 months is recommended.
· Ensure the Used Water Tank is removed or empty before laying the appliance on its side to clean the
roller brush.
1. Press the brush roller cover release
buttons to remove the brush roller cover.
3. Clear any hair and debris caught on the
brush roller with the provided cleaning
brush. Rinse the brush roller and the cover
with clean water and dry it completely.
5. Re-install the brush roller and the brush
roller cover until you hear a click.
2. Press the brush roller release button and
pull the handle to take out the brush roller.
Separate the handle from the brush roller.
4. Wipe the suction inlet with a dry cloth or
wet tissue.
2
1
click
Care & Maintenance
Cleaning the filter
Note: Replacing the filter every 3 to 6 months is recommended.
Note: Do not rinse the tube or the dirt sensor.
Cleaning the Tube and the Dirt Sensor
Remove the Used Water Tank. Wipe the tube and the dirt sensor with a wet cloth before
use.
1. Remove the filter and gently knock off the
floating dust on the surface.
2. When the filter is dirty and needs
washing, rinse it with water. It must be
completely dry before use.
16 17
EN EN
Error Prompts and Solutions
Error Code Possible Cause Solution
E1-E7
Error
Restart the appliance for troubleshooting.
If the problem persists, please contact
customer service.
F1-F3
H2/H3/H5/H6
If the appliance is not working properly, the screen display will show an error message. Please
refer to the below table to find your solution.
Troubleshooting Troubleshooting
If an error occurs, the appliance will stop working. Please refer to the following table for
troubleshooting. If the problem persists, please contact the customer service.
Error Possible Cause Solution
The appliance
does not work.
The appliance is out of battery
or its battery level is low.
Fully charge its battery before
use.
The appliance is in the upright
position.
Recline the appliance
backwards.
Blockage activated overheat
protection mode.
Clear the blockage and wait
until the temperature returns
normal.
The Used Water Tank is full. Empty the Used Water Tank.
The parts are not installed in
place.
Ensure all parts are all properly
in place.
The appliance
charges slowly.
The temperature of the battery
is too low or too high.
Wait until the battery's
temperature returns normal.
The suction
power of the
appliance is
weak.
The filter is clogged. Clean the filter.
The suction inlet or tube is
blocked by a foreign object.
Clean the tube and the suction
inlet.
The motor
is making a
strange noise.
There is too much dirty water
in the Used Water Tank.
Empty the Used Water Tank.
The suction inlet is blocked.
Clear any blockage in the
suction inlet.
The battery
level indicator
on the display
screen does
not light up
while charging.
The charging base plug is not
inserted into the electrical
outlet properly.
Make sure the charging base
plug is inserted in place.
The appliance is not placed
onto the charging base
properly.
Make sure the appliance is
placed onto the charging base
properly.
No water is
coming out of
the appliance.
The Clean Water Tank is not
properly installed in place, or
the water in the Clean Water
Tank is insufficient.
Re-install or fill the Clean
Water Tank.
It takes 30 seconds to dampen
the brush roller.
Turn on the appliance and
check again after a while.
The vent leaks
water.
A collision or a sharp pull causes
water to enter the motor.
Move the appliance gently back
and forth while it is turned on.
The filter is not completely dry
after being cleaned.
Dry the filter completely before
use.
Self-cleaning
fails.
The brush roller may be
jammed by large debris.
Remove the brush roller cover
to check and clean the brush
roller.
The appliance is not placed
onto the charging base
properly.
Make sure the appliance is
being charged before enabling
the self-cleaning function.
Self-cleaning cannot be
enabled if the battery level is
lower than 20%.
Self-cleaning can only be
enabled while the appliance is
being charged and the battery
level is more than 20%.
The Used Water Tank is full. Empty the Used Water Tank.
The Clean Water Tank is not
installed in place, or the water
in the Clean Water Tank is
insufficient.
Re-install or fill the Clean Water
Tank.
Poor drying
performance.
The air outlet and air inlet of
the charging base may be
blocked.
Check and clear the blockage
of air outlet and air inlet.
18 19
EN EN
Specifications Warranty
Vacuum
Model HMH15A Rated Power 300 W
Rated Voltage 21.6V Charging Voltage 27V
Clean Water Tank
Capacity
800mL
Used Water Tank
Capacity
700mL
Charging Time Approx. 4 hours
Charging Base
Model HCBX Rated Power Input* 650W
Rated Input
220-240V
50-60Hz
Rated Output 27V 1.6A
Protection against harmful ingress of water IPX1
* The rated input power refers to the power measured during a representative cycle for entering the drying
mode.
Battery Disposal and Removal
The built-in lithium-ion battery contains substances that are hazardous to the environment.
Before disposing of the battery, make sure the battery is removed by qualified technicians and
discarded at an appropriate recycling facility.
- the battery must be removed from the appliance before it is scrapped;
- the appliance must be disconnected from the supply mains when removing the battery;
- the battery is to be disposed of safely.
CAUTION:
· Before removing the battery, disconnect the power and run out the battery as much as
possible.
· Unneeded batteries should be discarded at an appropriate recycling facility.
· Do not expose to high temperature environment to avoid risks of explosion.
· Under abusive conditions, liquid may be ejected from the battery. If contact occurs, flush
with water and seek medical help.
1. Remove the handle by refering to the Installation section.
2. Use a proper tool to remove the top and body decorative covers of the appliance.
3. Remove the wastewater tank, and use a screwdriver to remove all the fixing screws from
the body.
4. Remove the fixing screws on the appliance front cover. Remove the cover.
5. Remove the main control board cover, disconnect the battery pack connector cables, and
remove the battery from the battery pack assembly.
Removal Guide
1. MOVA is liable to the consumer for any lack of conformity in material or
workmanship not detectable at the time of the purchase.
2. Warranty period: 2 years, starting for the date the product is sold to the consumer
or delivered to the consumer (which ever occurs later). If the territory where the
consumer is located has dierent regulations, local regulations prevail.
3. The warranty will not be applicable in the following cases:
a)Issues due to carelessness, use, or installation that does not comply with the
instructions provided by MOVA.
b)Tampering and/or modications of the product by entities or individuals not
expressly authorized by MOVA.
c)Damage due to accidental causes and/or negligence on the part of the consumer,
with particular reference to external parts.
d)Parts subject to wear that do not have manufacturing defects.
e)No valid purchasing document (receipt, invoice, or other) is provided to certify the
date the product was purchased.
f)The model and/or numbers of the product on the purchase certicate is not
consistent with the model and/or numbers shown on the product.
4.For more warranty information, please refer to the ocial MOVA website: www.
mova-tech.com
5. For further assistance, please contact us via 07-3737-3143 or https://global.mova-
tech.com/pages/contact-us.
