Samsung WW80T4020CX/NQ 8kg Front Loader Digital Inverter Technology platinum

Product's Documents

Below are documents related to this product, you can read online or download:
User Manual Installation Instruction

User Manual

This is the main product document for model WW80T4020CX/NQ. Additionally, the document applies to other Samsung models: WW80T4020CX

The file format is pdf, 120 pages, you can download this manual here .

background
Washing Machine
User manual
WW8*T4***** / WW7*T4*****
WW70T4020CX_04221C-00_EN.indd 1 2021/2/2 14:33:26
background
2 English
Contents
Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols 4
Important safety precautions 5
Critical installation warnings 7
Installation cautions 8
Critical usage warnings 9
Usage cautions 10
Critical cleaning warnings 14
Installation 15
What’s included 15
Installation requirements 17
Step-by-step installation 19
Before you start 29
Initial settings 29
Laundry guidelines 29
Detergent drawer guidelines 32
Operations 35
Control panel 35
Simple steps to start 36
Cycle overview 37
Settings 41
Maintenance 42
Drum clean 42
Smart check 43
Emergency drain 44
Cleaning 45
Recovery from freezing 48
Care against an extended time of disuse 48
WW70T4020CX_04221C-00_EN.indd 2 2021/2/2 14:33:27
background
English 3
Contents
Troubleshooting 49
Checkpoints 49
Information codes 53
Specications 56
Fabric care chart 56
Protecting the environment 57
Spare parts guarantee 57
Specication sheet 58
WW70T4020CX_04221C-00_EN.indd 3 2021/2/2 14:33:27
background
4 English
Safety information
Safety information
Congratulations on your new Samsung washing machine. This manual contains important
information on the installation, use and care of your appliance. Please take some time to read
this manual to take full advantage of your washing machine’s many benets and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efciently
operate the extensive features and functions of your new appliance. Please store the manual
in a safe location close to the appliance for future reference. Use this appliance only for its
intended purpose as described in this instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible
conditions and situations that may occur. It is your responsibility to use common sense,
caution and care when installing, maintaining and operating your washing machine.
Because the following operating instructions cover various models, the characteristics of your
washing machine may differ slightly from those described in this manual and not all warning
signs may be applicable. If you have any questions or concerns, contact your nearest service
centre or nd help and information online at www.samsung.com.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or property
damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Indicates that a risk of personal injury or material damage exists.
Read the instructions
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
Read all instructions before using the appliance.
As with any equipment that uses electricity and moving parts, potential hazards exist. To
safely operate this appliance, familiarize yourself with its operation and exercise care when
using it.
WW70T4020CX_04221C-00_EN.indd 4 2021/2/2 14:33:27
background
English 5
Safety information
Important safety precautions
WARNING
To reduce the risk of re, electric shock, or injury to persons when
using your appliance, follow basic precautions, including the
following:
1. This appliance is not to be used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
2. For use in Europe: This appliance can be used by children aged
from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
3. Children should be supervised to ensure that they do not play
with the appliance.
4. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
5. The new hose-sets supplied with the appliance are to be used
and old hose-sets should not be reused.
6. For appliances with ventilation openings in the base, a carpet
must not obstruct the openings.
WW70T4020CX_04221C-00_EN.indd 5 2021/2/2 14:33:27
background
6 English
Safety information
Safety information
7. For use in Europe: Children of less than 3 years should be kept
away unless continuously supervised.
8. CAUTION: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on and off
by the utility.
9. This appliance is intended to be used in household only and it is
not intended to be used such as:
staff kitchen areas in shops, ofces and other working
environments;
farm houses;
by clients in hotels, motels and other residential type
environments;
bed and breakfast type environments;
areas for communal use in blocks of ats or in launderettes.
WW70T4020CX_04221C-00_EN.indd 6 2021/2/2 14:33:27
background
English 7
Safety information
Critical installation warnings
WARNING
The installation of this appliance must be performed by a qualied technician or service
company.
• Failure to do so may result in electric shock, re, an explosion, problems with the product,
or injury.
The appliance is heavy, therefore take care when lifting it.
Plug the power cord into a wall socket that meets local electrical specications. Use the
socket for this appliance only, and do not use an extension cord.
• Sharing a wall socket with other appliances using a power strip or extending the power
cord may result in electric shock or re.
• Ensure that the power voltage, frequency, and current are the same as those of the
product specications. Failure to do so may result in electric shock or re. Plug the power
plug into the wall socket rmly.
Remove all foreign substances such as dust or water from the power plug terminals and
contact points using a dry cloth on a regular basis.
• Unplug the power plug and clean it with a dry cloth.
• Failure to do so may result in electric shock or re.
Plug the power plug into the wall socket so that the cord is running towards the oor.
• If you plug the power plug into the socket in the opposite direction, the electric wires
within the cable may be damaged and this may result in electric shock or re.
Keep all packaging materials out of the reach of children as these may be dangerous.
• If a child places a bag over its head, it may suffocate.
When the appliance, power plug or power cord is damaged, contact your nearest service
centre.
This appliance must be properly grounded.
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
• This may result in electric shock, re, an explosion, or problems with the product.
• Never plug the power cord into a socket that is not grounded correctly and make sure
that it is in accordance with local and national regulations.
Do not install this appliance near a heater or any inammable material.
Do not install this appliance in a humid, oily or dusty location, or in a location exposed to
direct sunlight or water (rain drops).
Do not install this appliance in a location exposed to low temperatures.
WW70T4020CX_04221C-00_EN.indd 7 2021/2/2 14:33:27
background
8 English
Safety information
Safety information
• Frost may cause the tubes to burst.
Do not install this appliance in a location where gas may leak.
• This may result in electric shock or re.
Do not use an electric transformer.
• This may result in electric shock or re.
Do not use a damaged power plug, damaged power cord, or loose wall socket.
• This may result in electric shock or re.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord,
insert the power cord between objects, or push the power cord into the space behind the
appliance.
• This may result in electric shock or re.
Do not pull the power cord when unplugging the power plug.
• Unplug the power plug by holding the plug.
• Failure to do so may result in electric shock or re.
This appliance should be positioned so that the power plug, the water supply taps, and the
drain pipes are accessible.
Following the repair by a non-authorized service provider, self-repair or non-professional
repair of the product, Samsung is not liable for any damage to the product, any injury or
any other product safety issue caused by any attempt to repair the product which does
not carefully follow these repair and maintenance instructions. Any damage to the product
caused by an attempt to repair the product by any person other than a Samsung certied
service provider will not be covered by the warranty.
Installation cautions
CAUTION
This appliance should be positioned in such a way that the power plug is easily accessible.
• Failure to do so may result in electric shock or re due to electric leakage.
Install your appliance on a solid, level oor that can support its weight.
• Failure to do so may result in abnormal vibrations, movement, noise, or problems with
the product.
WW70T4020CX_04221C-00_EN.indd 8 2021/2/2 14:33:27
background
English 9
Safety information
Critical usage warnings
WARNING
If the appliance is ooded, turn off the water & power supplies immediately and contact your
nearest service centre.
• Do not touch the power plug with wet hands.
• Failure to do so may result in electric shock.
If the appliance generates a strange noise, a burning smell, or smoke, unplug the power plug
immediately and contact your nearest service centre.
• Failure to do so may result in electric shock or re.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without
touching the power plug. Do not touch the appliance or power cord.
• Do not use a ventilating fan.
• A spark may result in an explosion or re.
Do not let children play in or on the washing machine. In addition, when disposing of the
appliance, remove the washing machine door lever.
• If trapped inside the product, children may suffocate to death.
Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the
washing machine before using it.
Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or
other inammable or explosive substances.
• This may result in electric shock, re, or an explosion.
Do not open the washing machine door by force while it is operating (high-temperature
washing/drying/spinning).
• Water owing out of the washing machine may result in burns or cause the oor to be
slippery. This may result in injury.
• Opening the door by force may result in damage to the product or injury.
Do not insert your hand under the washing machine while an operation is in progress.
• This may result in injury.
Do not touch the power plug with wet hands.
• This may result in electric shock.
Do not turn the appliance off by unplugging the power plug while an operation is in progress.
• Plugging the power plug into the wall socket again may cause a spark and result in
electric shock or re.
Do not let children climb in or onto the appliance.
WW70T4020CX_04221C-00_EN.indd 9 2021/2/2 14:33:27
background
10 English
Safety information
Safety information
• This may result in electric shock, burns or injury.
Do not insert your hand or a metal object under the washing machine while it is operating.
• This may result in injury.
Do not unplug the appliance by pulling the power cord. Always grip the plug rmly and pull
it straight out of the outlet.
• Damage to the power cord may cause a short-circuit, re and/or electric shock.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use a fuse (such as copper, steel wire, etc.) other than a standard fuse.
• When the appliance needs to be repaired or reinstalled, contact your nearest service
centre.
• Failure to do so may result in electric shock, re, problems with the product, or injury.
If the water supply hose comes loose from the water tap and oods the appliance, unplug the
power plug.
• Failure to do so may result in electric shock or re.
Unplug the power plug when the appliance is not being used for long periods of time or
during a thunder or lightning storm.
• Failure to do so may result in electric shock or re.
If any foreign substance enters into the appliance, unplug the power plug and contact you
nearest Samsung Customer Service.
• This may result in electric shock or re.
Do not let children (or pets) play in or on your washing machine. The washing machine door
does not open easily from the inside and children may be seriously injured if trapped inside.
Usage cautions
CAUTION
When the washing machine is contaminated by a foreign substance such as detergent, dirt,
food waste, etc., unplug the power plug and clean the washing machine using a damp, soft
cloth.
• Failure to do so may result in discolouration, deformation, damage, or rust.
The front glass may be broken by a strong impact. Take care when using the washing
machine.
• If the glass is broken, it may result in injury.
After a water supply failure or when reconnecting the water supply hose, open the water tap
slowly.
WW70T4020CX_04221C-00_EN.indd 10 2021/2/2 14:33:27
background
English 11
Safety information
Open the water tap slowly after a long period of non-use.
• The air pressure in the water supply hose or the water pipe may damage a product part
or result in a water leak.
If a draining error occurs during an operation, check if there is a draining problem.
• If the washing machine is used when it is ooded because of a draining problem, it may
result in electric shock or re.
Insert the laundry into the washing machine completely so that the laundry does not get
caught in the door.
• If laundry gets caught in the door, it may result in damage to the laundry or the washing
machine, or result in a water leak.
Turn the water supply off when the washing machine is not being used.
Ensure that the screws on the water supply hose connector are properly tightened.
• Failure to do so may result in property damage or injury.
Ensure that the rubber seal and front door glass are not contaminated by a foreign substance
(e.g. waste, thread, hair, etc.).
• If a foreign substance is caught in the door or the door is not completely closed, it may
cause a water leak.
Open the water tap and check if the water supply hose connector is rmly tightened and that
there is no water leak before using the product.
• If the screws on the water supply hose connector are loose, it may result in a water leak.
The product you have purchased is designed for domestic use only.
Using the product for business purposes qualies as a product misuse. In this case, the
product will not be covered by the standard warranty provided by Samsung and no
responsibility can be attributed to Samsung for malfunctions or damages resulting from such
misuse.
Do not stand on the appliance or place objects (such as laundry, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
• This may result in electric shock, re, problems with the product, or injury.
Do not spray volatile material such as insecticide onto the surface of the appliance.
• As well as being harmful to humans, this may result in electric shock, re or problems
with the product.
Do not place objects that generate electromagnetic elds near the washing machine.
• This may result in injury due to a malfunction.
Water drained during a high-temperature wash or drying cycle is hot. Do not touch the water.
• This may result in burns or injury.
WW70T4020CX_04221C-00_EN.indd 11 2021/2/2 14:33:28
background
12 English
Safety information
Safety information
If the water temperatue is high before drain, it take time until the temperature goes down,
and it can be different depending on internal temperature.
Do not wash, spin, or dry water-proof seats, mats, or clothing (*) unless your appliance has a
special cycle for washing these items.
(*): Woollen bedding, rain covers, shing vests, ski pants, sleeping bags, diaper covers, sweat
suits, and bicycle, motor cycle and car covers, etc.
• Do not wash thick or hard mats even if the washing machine mark is on the care label.
This may result in injury or damage to the washing machine, walls, oor, or clothing due
to abnormal vibrations.
• Do not wash throw rugs or doormats with rubber backing. The rubber backing may come
off and stick to inside the drum, and this may result in malfunction such as a drainage
error.
Do not operate the washing machine when the detergent drawer is removed.
• This may result in electric shock or injury due to a water leak.
Do not touch the insides of the drum during or just after drying as it is hot.
• This may result in burns.
The door glass becomes hot during washing and drying. Therefore, do not touch the door
glass.
Also, do not allow children to play around the washing machine or touch the door glass.
• This may result in burns.
Do not insert your hand into the detergent drawer.
• This may result in injury as your hand may be caught by the detergent input device.
• The liquid detergent guide (applicable models only) is not used for powder detergent.
Remove the guide when using powder detergent.
Do not place any objects (such as shoes, food waste, animals) other than laundry into the
washing machine.
• This may result in damage to the washing machine, or injury and death in the case of
pets due to the abnormal vibrations.
Do not press the buttons using sharp objects such as pins, knifes, ngernails, etc.
• This may result in electric shock or injury.
Do not wash laundry contaminated by oils, creams or lotions usually found in skincare shops
or massage clinics.
• This may cause the rubber seal to become deformed and result in a water leak.
Do not leave metal objects such as safety pins, hair pins or bleach in the drum for long
periods of time.
• This may cause the drum to rust.
WW70T4020CX_04221C-00_EN.indd 12 2021/2/2 14:33:28
background
English 13
Safety information
• If rust starts appearing on the surface of the drum, apply a (neutral) cleansing agent to
the surface and use a sponge to clean it. Never use a metal brush.
Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry
contaminated by dry cleaning detergent.
• This may result in spontaneous combustion or ignition due to the heat from the oxidation
of the oil.
Do not use water from water cooling/heating devices.
• This may result in problems with the washing machine.
Do not use natural hand-washing soap for the washing machine.
• If it hardens and accumulates inside the washing machine, it may result in problems with
the product, discolouration, rust, or bad odours.
Place socks and brassieres in a washing net and wash them with the other laundry.
Do not wash large laundry items such as bedding in the washing net.
• Failure to do so may result in injury due to abnormal vibrations.
Do not use hardened detergent.
• If it accumulates inside the washing machine, it may result in a water leak.
Make sure that the pockets of all the clothing items to be washed are empty.
• Hard, sharp objects such as coins, safety pins, nails, screws, or stones can cause extensive
damage to the appliance.
Do not wash clothing with large buckles, buttons or other heavy metal objects.
Sort the laundry by colour on the basis of its colorfastness and select the recommended
cycle, water temperature and additional functions.
• This may result in discolouration or fabric damage.
Take care that children’s ngers are not caught in the door when you close it.
• Failure to do so may result in injury.
To prevent odours and mould, leave the door open after a wash cycle to allow the drum to
dry.
To prevent limescale build up, leave the detergent drawer open after a wash cycle and dry
inside it.
WW70T4020CX_04221C-00_EN.indd 13 2021/2/2 14:33:28
background
14 English
Safety information
Safety information
Critical cleaning warnings
WARNING
Do not clean the appliance by spraying water directly onto it.
Do not use the a strong acidic cleaning agent.
Do not use benzene, thinner or alcohol to clean the appliance.
• This may result in discolouration, deformation, damage, electric shock or re.
Before cleaning or performing maintenance, unplug the appliance from the wall socket.
• Failure to do so may result in electric shock or re.
WW70T4020CX_04221C-00_EN.indd 14 2021/2/2 14:33:28
background
English 15
Installation
Installation
Follow these instructions carefully to ensure proper installation of the washing machine and
to prevent accidents when doing laundry.
What’s included
Make sure all the parts are included in the product package. If you have a problem with
the washing machine or the parts, contact a local Samsung customer centre or the retailer.
01
02
12
11
10
09
03
04
06
08
07
05
01 Release lever 02 Detergent drawer 03 Control panel
04 Door 05 Drum 06 Lint lter
07 Emergency drain tube 08 Filter cover 09 Worktop
10 Power plug 11 Drain hose 12 Levelling feet
WW70T4020CX_04221C-00_EN.indd 15 2021/2/2 14:33:28
background
16 English
Installation
Installation
Spanner Bolt caps Hose guide
Cold water hose Hot water hose Liquid detergent container
Accessories (not supplied)
• Stacking kit: SKK-DF
- Staking kit is required to stack a dryer on a washing machine.
NOTE
• Spanner: For removing the shipping bolts and levelling the washing machine.
• Bolt caps : For covering the holes after removing the shipping bolts. The provided
number of bolt caps (3 to 6) depends on the model.
• Hose guide: For hanging the drain hose in the drainpipe or wash-basin.
• Cold/Hot water hose: For supplying water to the washing machine. (Hot water hoses is for
applicable models only.)
• Liquid detergent guide: Insert it in the detergent compartment to use liquid detergent.
(Applicable models only)
WW70T4020CX_04221C-00_EN.indd 16 2021/2/2 14:33:28
background
English 17
Installation
Installation requirements
Electrical supply and grounding
• AC 220-240 V / 50 Hz fuse or circuit
breaker is required
• Use an individual branch circuit specic
to the washing machine
To ensure proper grounding, the washing
machine comes with a power cord featuring
a three-prong grounding plug for use in a
properly installed and grounded outlet.
Check with a qualied electrician or
serviceperson if you are not sure about the
grounding.
Do not modify the provided plug. If it does
not t the outlet, call a qualied electrician
to install a proper outlet.
WARNING
• Do NOT use an extension cord.
• Use only the power cord that comes
with the washing machine.
• Do NOT connect the ground wire to
plastic plumbing, gas lines, or hot water
pipes.
• Improperly connected grounding
conductors may cause electric shock.
Water supply
A proper water pressure for this washing
machine is between 50 kPa and 800 kPa.
Water pressure less than 50 kPa may cause
the water valve not to close completely. Or,
it may take longer to ll the drum, causing
the washing machine to turn off. Water taps
must be within 120 cm from the rear of the
washing machine so that the provided inlet
hoses reach the washing machine.
To reduce the risk of leaks:
• Make sure water taps are easily
accessible.
• Turn off the taps when the washing
machine is not in use.
• Check for any leaks at the water inlet
hose ttings on a regular basis.
CAUTION
Before using the washing machine for the
rst time, check all connections at the water
valve and taps for any leaks.
Drain
Samsung recommends a standpipe in
height of 60~90 cm. The drain hose must
be connected through the hose clip to the
standpipe, and the standpipe must fully
cover the drain hose.
WW70T4020CX_04221C-00_EN.indd 17 2021/2/2 14:33:28
background
18 English
Installation
Installation
Flooring
For best performance, the washing
machine must be installed on a solid oor.
Wood oors may need to be reinforced
to minimize vibration and/or unbalanced
loads. Carpeting and soft tile surfaces are
not a good resistance to vibrations and may
cause the washing machine to move slightly
during the spin cycle.
CAUTION
Do NOT install the washing machine on a
platform or a poorly supported structure.
Water temperature
Do not install the washing machine in areas
where water may freeze as the washing
machine always retains some water in its
water valves, pumps, and/or hoses. Frozen
water left in the connection parts may
cause damage to belts, the pump, and other
components of the washing machine.
Alcove or closet installation
Minimum clearance for stable operation:
Sides 25 mm Rear 50 mm
Top 25 mm Front 550 mm
If both the washing machine and a dryer
are installed in the same location, the front
of the alcove or closet must have at least
a 550 mm unobstructed air opening. Your
washing machine alone does not require a
specic air opening.
WW70T4020CX_04221C-00_EN.indd 18 2021/2/2 14:33:28
background
English 19
Installation
Step-by-step installation
STEP 1 Select a location
Location requirements:
• Solid, level surface without carpeting or ooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room for ventilation and wiring
• The ambient temperature is always higher than the freezing point (0 ˚C)
• Away from a heat source
STEP 2 Remove the shipping bolts
Unpack the product package and remove all shipping bolts.
NOTE
Number of shipping bolts may differ depending on the model.
WARNING
• Packaging materials can be dangerous to children. Dispose all packaging material (plastic
bags, polystyrene, etc.) out of children’s reach.
• To avoid injury, cover the holes with bolt caps after removing the shipping bolts. Do not
move the washing machine without the shipping bolts in place. Assemble the shipping
bolts before moving the washing machine to another location. Keep the shipping bolts in
a safe place for future use.
WW70T4020CX_04221C-00_EN.indd 19 2021/2/2 14:33:29
background
20 English
Installation
Installation
A
1. Locate the shipping bolts (marked with
circle in the gure) on the rear side of
the washing machine.
CAUTION
Do not remove the screw (A) that xes the
hose clip.
2. Using the supplied spanner, loosen all
the shipping bolts by turning them
counterclockwise.
NOTE
You must keep the shipping bolts for future
use.
WW70T4020CX_04221C-00_EN.indd 20 2021/2/2 14:33:29
background
English 21
Installation
B
3. Insert the bolt caps (B) to the holes
(marked with circle in the gure).
STEP 3 Adjust the levelling feet
1. Gently slide the washing machine into
position. Excessive force may damage
the levelling feet.
2. Level the washing machine by manually
adjusting the levelling feet.
WW70T4020CX_04221C-00_EN.indd 21 2021/2/2 14:33:29
background
22 English
Installation
Installation
3. When levelling is complete, tighten the
nuts using the spanner.
CAUTION
When installing the product make sure the
levelling feet is not pressing the power cord.
CAUTION
Make sure all the levelling feet are seating on the oor surface to avoid the washing machine
from moving or generating noise due to vibration Then, check if the washing machine is not
rocking. If the washing machine is not rocking, tighten the nuts.
WW70T4020CX_04221C-00_EN.indd 22 2021/2/2 14:33:30
background
English 23
Installation
STEP 4 Connect the water hose
The provided water hose may differ depending on the model. Please follow the instruction
according to the provided water hose.
Connecting to a threaded water tap
1. Connect the water hose to the water tap,
and then turn the connector clockwise as
shown.
2. Connect the other end of the water
hose to the inlet valve on the back of
the washing machine. Turn the hose
clockwise to tighten.
3. Open the water tap and check if there
are any leaks around the connection
areas. If there are water leaks, repeat the
steps above.
WARNING
If there is a water leak, stop operating the washing machine and disconnect from the
electrical supply. Then, contact a local Samsung service centre in case of a leak from the
water hose, or contact a plumbing technician in case of a leak from the water tap. Otherwise,
this may cause electric shock.
WW70T4020CX_04221C-00_EN.indd 23 2021/2/2 14:33:30
background
24 English
Installation
Installation
CAUTION
Do not stretch the water hose by force. If the hose is too short, replace the hose with a
longer, high-pressure hose.
Connecting to a non-threaded water tap
A
B
1. Remove the adaptor (A) from the water
hose (B).
2. Use a Phillips screwdriver to loosen four
screws on the adaptor.
C
3. Hold the adaptor and turn part (C) in the
arrow direction to loosen it by 5 mm (*).
WW70T4020CX_04221C-00_EN.indd 24 2021/2/2 14:33:30
background
English 25
Installation
C
4. Insert the adaptor onto the water tap,
and then tighten the screws while lifting
the adaptor.
5. Turn part (C) in the arrow direction to
tighten it.
D
6. While pulling down part (D) on the
water hose, connect the water hose to
the adaptor. Then, release part (D). The
hose ts into the adaptor with a clicking
sound.
7. To complete connecting the water hose,
see 2 and 3 on the “Connecting to a
threaded water tap” section.
NOTE
• After connecting the water hose to the adaptor, pull the water hose down to check if it is
connected properly.
• Use a popular type of water taps. If the tap is square-shaped or too big, remove the
spacer ring before inserting the tap into the adaptor.
WW70T4020CX_04221C-00_EN.indd 25 2021/2/2 14:33:30
background
26 English
Installation
Installation
For models with an additional hot water inlet:
1. Connect the red end of the hot water
hose to the hot water inlet on the back
of the machine.
2. Connect the other end of the hot water
hose to the hot water tap.
Aqua stop hose (applicable models only)
A
The aqua stop hose alerts users of a risk of
water leaks. It senses the water ow and
turns red on the centre indicator (A) in case
of a leak.
NOTE
The end of the aqua stop hose must be tted to the water tap and not the machine.
WW70T4020CX_04221C-00_EN.indd 26 2021/2/2 14:33:30
background
English 27
Installation
STEP 5 Position the drain hose
The drain hose can be positioned in three ways:
A
Over the edge of a wash basin
The drain hose must be placed at a height
of between 60 cm and 90 cm (*) from the
oor. To keep the spout of the drain hose
bent, use the supplied plastic hose guide (A).
Secure the guide to the wall using a hook to
ensure stable drainage.
In a drain pipe
The drain pipe should be between 60 cm
and 90 cm high (*). It is advisable to use a
65 cm high vertical pipe.
• To ensure the drain hose stays in
position, use the plastic hose guide
provided (see the gure).
• To prevent the siphoning of water ow
during drainage, make sure to insert the
drain hose 15 cm in the drain pipe.
• To prevent the drain hose from moving
around, secure the hose guide to the
wall.
Drain standpipe requirements:
• Minimum diameter of 5 cm
• Minimum carry-away capacity of 60
litres per minute
WW70T4020CX_04221C-00_EN.indd 27 2021/2/2 14:33:31
background
28 English
Installation
Installation
In a sink drain pipe branch
The drain pipe branch mush be above the
sink siphone so that the end of the hose is
at least 60 cm above the ground.
(*) : 60 cm
CAUTION
Remove the lid on the sink drain pipe
branch before connecting the drain pipe to
it.
CAUTION
Do not put the drain hose in places of
stagnant water or ponding. The water may
ow back to the washing machine.
STEP 6 Turn on the washing machine
Plug the power cord into a wall socket that is correctly rated, grounded, and protected by a
fuse or circuit breaker. Then, press Power to turn on the washing machine.
WW70T4020CX_04221C-00_EN.indd 28 2021/2/2 14:33:31
background
English 29
Before you start
Before you start
Initial settings
Run Calibration (recommended)
Calibration ensures accurate weight detection by the washing machine. Make sure the drum
is empty before running Calibration.
1. Power off, and then power on the washing machine.
2. Hold down
Temp. and Delay End simultaneously for 3 seconds to enter
Calibration mode. The “CB” message appears.
3. Press Start/Pause to run the Calibration cycle.
4. The drum will rotate clockwise and counter-clockwise for about 3 minutes.
5. When the cycle is complete, “0” appears on the display and the washing machine will turn
off automatically.
6. The washing machine is now ready for use.
Laundry guidelines
STEP 1 Sort
Sort the laundry according to these criteria:
• Care Label: Sort the laundry into cottons, mixed bres, synthetics, silks, wools, and rayon.
• Colour: Separate whites from colours.
• Size: Mixing different-sized items together in the drum improves the washing
performance.
• Sensitivity: Wash delicate items separately using an Easy Iron option for pure, new
woollen items, curtains, and silk items. Check the labels on the items.
NOTE
Make sure to check the care label on the clothing, and sort them accordingly before starting
the wash.
STEP 2 Empty pockets
Empty all the pockets of your laundry items
• Metal objects such as coins, pins, and buckles on clothing may damage other laundry
items as well as the drum.
WW70T4020CX_04221C-00_EN.indd 29 2021/2/2 14:33:31
background
30 English
Before you start
Before you start
Turn clothing with buttons and embroideries inside out
• If pants or jacket zippers are open while washing, the drum may be damaged. Zippers
should be closed and xed with a string.
• Clothing with long strings may become entangled with other clothes. Make sure to tie the
strings before starting the wash.
STEP 3 Use a laundry net
• Brassieres (water washable) must be placed in a laundry net. Metal parts of the brassieres
may break through and tear other laundry items.
• Small, light clothing such as socks, gloves, stockings, and handkerchiefs may become
caught around the door. Place them inside a ne laundry net.
• Do not wash the laundry net by itself without other laundry. This may cause abnormal
vibrations that could move the washing machine and result in injury.
STEP 4 Prewash (if necessary)
Select the Prewash option for the selected cycle if the laundry is heavily soiled. Do not use
the Prewash option when detergent is manually added into the drum.
STEP 5 Determine the load capacity
Do not overload the washing machine. Overloading may cause the washing machine to not
wash properly. For the load capacity for the type of clothing, see page 37.
NOTE
When washing bedding or bedding covers, the wash time may be lengthened or the spin
efciency may be reduced. For bedding or bedding covers, the recommended maximum spin
cycle speed is 800 rpm, and the load capacity is 2 kg or less.
CAUTION
• Unbalanced laundry may reduce the spinning performance.
• Make sure the laundry is fully inserted in the drum and not caught in the door.
• Do not slam the door. Close the door gently. Otherwise, the door may not be closed
properly.
STEP 6 Apply a proper detergent type
The type of detergent depends on the type of fabric (cotton, synthetic, delicate items, wool),
colour, wash temperature, and degree of soiling. Always use “low suds” laundry detergent,
which is designed for automatic washing machines.
WW70T4020CX_04221C-00_EN.indd 30 2021/2/2 14:33:31
background
English 31
Before you start
NOTE
• Follow the detergent manufacturer’s recommendations based on the weight of the
laundry, the degree of soiling, and the hardness of the water in your local area. If you are
not sure about the water hardness, contact a local water authority.
• Do not use detergent that tends to be hardened or solidied. This detergent may remain
after the rinse cycle, blocking the drain outlet.
CAUTION
When washing wool using the WOOL/DELICATES cycle, use only a neutral liquid detergent.
If used with the WOOL/DELICATES cycle, powder detergent may remain on the laundry and
discolour the laundry.
Laundry capsules
To get the best results from using laundry capsules, please follow these instructions.
1. Put the capsule in the bottom of the
empty drum towards the rear.
2. Put the laundry in the drum on top of
the capsule.
CAUTION
For cycles using cold water or cycles that complete in less than one hour, the capsule may not
dissolve completely.
WW70T4020CX_04221C-00_EN.indd 31 2021/2/2 14:33:32
background
32 English
Before you start
Before you start
Detergent drawer guidelines
The washing machine provides a three-compartment dispenser: the left compartment for the
main wash, the centre compartment for fabric softeners, and the right compartment for the
preliminary wash.
A
01 Prewash compartment: Apply
prewash detergent.
02 Main-wash compartment: Apply
main-wash detergent, water softener,
soaking detergent, bleach, and/or stain
removers.
03 Softener compartment: Apply
additives such as fabric softener. Do not
exceed the max line (A).
CAUTION
• Do not open the detergent drawer while the washing machine is operating.
• Do not use the following types of detergent:
• Tablet or capsule types
• Ball or net types
• To prevent the compartment clogging, concentrated or highly-enriched agents (fabric
softener or detergent) must be diluted with water before being applied.
• When Delay End is selected, do not apply detergent directly into the drum. Otherwise,
this may discolour the laundry. Use the detergent drawer when Delay End is selected.
• Do not use any cleaning agents for cleaning the drum. Chemical residue in the drum
deteriorates the washing performance.
To apply washing agents to the detergent drawer
1. Slide open the detergent drawer.
2. Apply laundry detergent to the .
main-wash compartment as instructed
or recommended by the manufacturer.
To use liquid detergent, see page 34.
WW70T4020CX_04221C-00_EN.indd 32 2021/2/2 14:33:32
background
English 33
Before you start
A
3. Apply fabric softener to the softener
compartment. Do not exceed the max
line (A).
4. If you want to prewash, apply
prewash detergent to the prewash
compartment as instructed or
recommended by the manufacturer.
5. Close the detergent drawer.
CAUTION
• Do not apply powder detergent to the
liquid container.
• Concentrated fabric softener must be
diluted with water before applied.
• Do not apply main-wash detergent to
the softener compartment.
WW70T4020CX_04221C-00_EN.indd 33 2021/2/2 14:33:32
background
34 English
Before you start
Before you start
To use liquid detergent (applicable models only)
A
First insert the provided liquid container
in the main-wash compartment. Then,
apply liquid detergent to the container
below the marked max line (A).
CAUTION
• Do not exceed the max line that is
marked inside the container.
• Turn up the liquid container if using
powder detergent.
When using liquid detergent When using powder detergent
WW70T4020CX_04221C-00_EN.indd 34 2021/2/2 14:33:32
background
English 35
Operations
Operations
Control panel
09
02
08
03
04
05
06
07
01
01 Cycle Selector Turn the dial to select a cycle.
02 Display
The display shows current cycle information and estimated time
remaining, or an information code when a problem occurs.
03 Temp.
Press to change the water temperature for the current cycle.
04 Spin
Press to change the spinning speed for the selected cycle.
• Rinse Hold (No indicator): The nal rinse cycle is suspended so
that the laundry remains in the water. To unload the laundry, run
a drain or spin cycle.
• No Spin : The drum does not spin after the nal drain cycle.
• Spin Only : To run the Spin Only cycle, press Spin for 3
seconds. When the cycle time and spinning speed appear, press
Spin repeatedly until a desired spinning speed is selected. Then,
press Start/Pause to start the cycle. The spinning time depends
on the selected cycle.
05 Options
Press to select the options. Availability of the options depends on
the cycle.
06
Delay End
Delay End lets you set the end time of the current cycle. Based
on your settings, the start time of the cycle will be determined
by the machine’s internal logic. For example, this setting is useful
for programming your machine to nish a wash at the time you
normally return home from work.
• Press to choose a preset unit of hours.
07
Soak
Press to activate/deactivate the Soak function. This function helps
remove a wide variety of stubborn stains.
WW70T4020CX_04221C-00_EN.indd 35 2021/2/2 14:33:33
background
36 English
Operations
Operations
08
Start/Pause Press to start or stop operation.
09
Power
Press to turn on/off the washing machine.
For more information on the options, see the Special features section.
*(3 sec) : Press and hold for 3 seconds.
Simple steps to start
1
6
2
4
3
5
1. Press
Power to turn on the washing machine.
2. Turn the Cycle Selector to select a cycle.
3. Change the cycle settings ( Temp., and Spin) as necessary.
4. To add an option, press Options. Use the button again to choose a preferred item.
5. The machine provides two easy to access buttons for
Delay End and
Soak for your
convenience. If you want to use one of these options, press the corresponding button.
6. Press
Start/Pause.
To change the cycle during operation
1. Press Start/Pause to stop operation.
2. Select a different cycle.
3. Press Start/Pause again to start the new cycle.
WW70T4020CX_04221C-00_EN.indd 36 2021/2/2 14:33:33
background
English 37
Operations
Cycle overview
Standard ccycles
Cycle Description
Max load
(kg)
8kg 7kg
COTTON
• For cottons, bed linens, table linens, underwear, towels,
or shirts.
The washing time and the rinse count are
automatically adjusted according to the load.
Max Max
COTTON
• Optimal performance with lower energy for cotton
fabrics, bed linens, table linens, underwear, towels, or
shirts.
For energy saving, the actual washing temperature
may be lower than specied.
Max Max
SYNTHETICS
• For fabrics that are made of polyester(diolen, trevira),
polyamide (perlon, nylon), or the like.
4.0 4.0
RINSE+SPIN
• Featuring an additional rinse process after applying
fabric softener to the laundry.
Max Max
DRAIN/SPIN
• For draining the water inside the drum and running an
additional spin process to effectively remove moisture
from laundry.
Max Max
DRUM CLEAN
• Cleans the drum by removing dirt and bacteria from it.
• Perform once every 40 washes with no detergent or
bleach applied. It noties automatically after every 40
washes.
• Make sure the drum is empty.
• Do not use any cleaning agents for cleaning the drum.
- -
15’ QUICK WASH
• For lightly soiled items in less than 2.0 kg that you
want to wash quickly.
• Use less than 20 g of detergent. Using more than 20 g
of detergent may leave detergent residue.
• For liquid detergent, use a max of 20 ml of liquid
detergent.
2.0 2.0
DAILY WASH • For everyday items such as underwear and shirts. 4.0 4.0
WW70T4020CX_04221C-00_EN.indd 37 2021/2/2 14:33:33
background
38 English
Operations
Operations
Cycle Description
Max load
(kg)
8kg 7kg
WOOL/
DELICATES
• Specic for machine-washable wool and delicates
fabrics such as sheer fabrics, bras, lingerie (silk), and
other handwash-only fabrics.
• The WOOL/DELICATES cycle features gentle cradling
and soaking to protect bres from shrinkage/
distortion.
• A neutral detergent and liquid detergent is
recommended.
2.0 2.0
HYGIENE STEAM
• Cotton and linen fabric which have been in direct
contact with the skin, such as underwear.
• For optimum hygiene results select a temperature of
60 °C or above.
• Steam cycles feature allergy care and bacteria
elimination (sterilize).
4.0 4.0
COLORS
• Featuring additional rinses and reduced spinning to
ensure that the laundry is washed gently and rinsed
thoroughly.
4.0 4.0
BEDDING
• For bed spreads, bed sheets, bedding covers, etc.
• For best results, wash only 1 type of bedding. and
make sure the load weighs less than 2.0 kg.
2.0 2.0
WW70T4020CX_04221C-00_EN.indd 38 2021/2/2 14:33:33
background
English 39
Operations
NOTE
• Loading the household washing machine or the household washer-dryer up to the
capacity indicated by the manufacturer for the respective cycles will contribute to energy
and water savings.
• The noise and remaining moisture content are inuenced by the spinning speed: the
higher the spinning speed in the spinning phase, the higher the noise and the lower the
remaining moisture content.
• The most efcient cycle in terms of energy consumption are generally those that perform
at lower temperatures and longer duration.
Options
Option Description
Intensive
• For badly soiled laundry. The operation time for each cycle is
longer than normal.
Pre Wash
• This will add a preliminary washing cycle before the main
wash cycle.
Rinse+ • Press this button to add additional rinse cycles.
WW70T4020CX_04221C-00_EN.indd 39 2021/2/2 14:33:34
background
40 English
Operations
Operations
Delay End
You can set the washing machine to nish your wash automatically at a later time, choosing a
delay of between 1 to 24 hours (in 1 hour increments). The hour displayed indicates the time
the wash will nish.
1. Select a cycle. Then change the cycle settings if necessary.
2. Press Delay End repeatedly until a desired end time is set.
3. Press Start/Pause.
The corresponding indicator turns on with the clock running.
4. To cancel the Delay End, restart the washing machine by pressing Power.
Real-life case
You want to nish a two-hour cycle 3 hours later from now. For this, you add the Delay End
option to the current cycle with the 3-hour setting, and press Start/Pause at 2:00 p.m. Then,
what happens? The washing machine starts operating at 3:00 p.m., and ends at 5:00 p.m.
Provided below is the time line for this example.
2:00 pm
Set the Delay End to 3 hours
3:00 pm
Start
5:00 pm
End
WW70T4020CX_04221C-00_EN.indd 40 2021/2/2 14:33:34
background
English 41
Operations
Settings
Child Lock
To prevent children or infants from
accidentally starting or setting the washing
machine, Child Lock locks all buttons except
for the Power button.
• To set the Child Lock function, hold down
Temp. and Spin simultaneously for
3 seconds. To activate, press
Start/ Pause.
• To release the Child Lock function,
hold down Temp. and Spin
simultaneously for 3 seconds.
NOTE
• In the Child Lock state, you must rst
release the Child Lock if you want to add
detergent or laundry.
• Your setting will be kept even after
restarting the machine.
• You cannot open the door after a wash
cycle when the Child Lock is on. Turn the
function off before opening the door to
take out the laundry.
Sound On/Off
You can turn on or off the sound from the
washing machine. When this function is set
to Off, the melody of cycle completion, and
the power-off beep will not sound. However,
the other sounds stay active.
• To mute the sound, hold down Spin
and Options simultaneously for
3 seconds.
• To unmute the sound, hold down again
for 3 seconds.
• Your setting will be kept even after
restarting the machine.
WW70T4020CX_04221C-00_EN.indd 41 2021/2/2 14:33:35
background
42 English
Maintenance
Maintenance
Keep the washing machine clean to prevent deteriorated performance and to preserve its life
cycle.
Drum clean
Perform this cycle regularly to clean the drum by removing bacteria from it. This cycle heats
the water between 60 °C and 70 °C.
1. Press Power to turn on the washing machine.
2. Turn the Cycle Selector to select DRUM CLEAN.
3. Press Start/Pause.
NOTE
• The water temperature for DRUM CLEAN is set to 70 °C, which cannot be changed.
• It is recommended to run the DRUM CLEAN cycle once every 40 washes.
• To prevent limescale, add the proper amount of detergent according to your local water
hardness or add a water softener additive together with the detergent.
DRUM CLEAN reminder
Depending on the model, the DRUM CLEAN reminder is either an icon or an LED.
For icons, the icon lights up on the control panel.
For LEDs, the LED lights up next to DRUM CLEAN, or on the option area of the control panel.
• The DRUM CLEAN reminder blinks on the control panel once every 40 washes. It is
advisable to perform DRUM CLEAN regularly.
• When you rst see this reminder blinking, you can ignore the reminder for 6 consecutive
washes. From the 7
th
wash, the reminder no longer appears. However, it appears again on
the second 40
th
wash.
• Even after the last process is terminated, the “0” message may remain.
• You can record the running count of the DRUM CLEAN cycle by pressing the Power
button. This does not stop or turn off the machine but marks your cycle count.
• Even if “0” does not disappear, the machine operates normally.
• It is recommended to run the cycle regularly for hygienic purposes.
WW70T4020CX_04221C-00_EN.indd 42 2021/2/2 14:33:35
background
English 43
Maintenance
Smart check
To enable this function, you must rst download the Samsung Smart Washer app at the Play
Store or the Apple Store, and install it on a mobile device featuring a camera function.
The Smart Check function has been optimized for Galaxy & iPhone series (applicable models
only).
1. When the washing machine detects an issue to check, an information code appears on
the display. To enter Smart Check mode, press and hold Options and
Delay End
simultaneously for 3 seconds.
2. The washing machine starts the self-diagnosis procedure and displays an information
code if a problem is detected.
3. Run the Samsung Smart Washer app on your mobile device, and tap Smart Check.
4. Put the mobile device close to the washing machine’s display so that the smartphone
camera and the washing machine face each other. Then, the information code will be
recognised automatically by the app.
5. When the information code is recognised correctly, the app provides detailed information
about the problem with applicable solutions.
NOTE
• The function name, Smart Check, may differ depending on the language.
• If the washing machine reets light on the display, the app may fail to recognize the
information code.
• If the app fails to recognize the Smart Check code consecutively, enter the information
code manually onto the app screen.
WW70T4020CX_04221C-00_EN.indd 43 2021/2/2 14:33:35
background
44 English
Maintenance
Maintenance
Emergency drain
In case of a power failure, drain the water inside the drum before taking out the laundry.
A
1. Power off and unplug the washing
machine from the electrical outlet.
2. Gently press the top area of the lter
cover (A) to open.
B
3. Put an empty, spacious container around
the cover, and stretch the emergency
drain tube to the container while holding
the tube cap (B).
C
4. Open the tube cap and let water in the
Emergency drain tube (C) ow into the
container.
5. When done, close the tube cap, and
reinsert the tube. Then, close the lter
cover.
NOTE
Use a spacious container because the water
in the drum may be more than expected.
WW70T4020CX_04221C-00_EN.indd 44 2021/2/2 14:33:35
background
English 45
Maintenance
Cleaning
Surface of the washing machine
Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the
washing machine.
Mesh lter
Clean the mesh lter of the water hose once or twice a year.
1. Turn off the washing machine, and
unplug the power cord.
2. Close the water tap.
3. Loosen and disconnect the water hose
from the back of the washing machine.
Cover the hose with a cloth to prevent
water from gushing out.
4. Use pliers to pull out the mesh lter
from the inlet valve.
5. Submerge the mesh lter deeply in
water so that the threaded connector is
also submerged.
6. Dry the mesh lter completely in the
shade.
7. Reinsert the mesh lter into the inlet
valve, and reconnect the water hose to
the inlet valve.
8. Open the water tap.
NOTE
If the mesh lter is clogged, an information code of “4C” appears on the screen.
WW70T4020CX_04221C-00_EN.indd 45 2021/2/2 14:33:35
background
46 English
Maintenance
Maintenance
Debris lter
Clean the debris lter bi-monthly to prevent clogging. A clogged debris lter may reduce the
bubble effect.
1. Turn off the washing machine, and
unplug the power cord.
2. Drain the remaining water inside the
drum. See the “Emergency drain
section.
3. Gently press the top area of the lter
cover to open.
4. Turn the debris lter knob to the left,
and drain off the remaining water.
5. Clean the debris lter using soft brushes.
Make sure the drain pump propeller
inside the lter is unclogged.
6. Reinsert the debris lter, and turn the
lter knob to the right.
NOTE
• Some debris lters feature a safety knob
that is designed to prevent accidents
by children. To open the safety knob
of the debris lter, push in and turn it
anticlockwise. The spring mechanism of
the safety knob helps open the lter.
• To close the safety knob of the debris
lter, turn it clockwise. The spring makes
a rattling sound, which is normal.
NOTE
If the debris lter is clogged, an information code of “5C” appears on the screen.
CAUTION
• Make sure the lter cap is closed properly after cleaning the lter. Otherwise, this may
cause a leak.
WW70T4020CX_04221C-00_EN.indd 46 2021/2/2 14:33:36
background
English 47
Maintenance
• Make sure the lter is inserted properly after cleaning it. Otherwise, this may cause an
operational failure or a leak.
Detergent Drawer
1. While holding down the release lever (A)
on the inner of the drawer, slide open
the drawer.
2. Clean the drawer components in owing
water using a soft brush.
3. Clean the drawer recess using a bottle
brush to remove detergent residues and
limescale on the drawer recess.
4. Reinsert the release lever and the liquid
detergent container to the drawer.
5. Slide the drawer inward to close it.
NOTE
To remove remaining detergent, perform the RINSE+SPIN cycle with the drum being empty.
WW70T4020CX_04221C-00_EN.indd 47 2021/2/2 14:33:36
background
48 English
Maintenance
Maintenance
Recovery from freezing
The washing machine may freeze when it drops below 0 °C.
1. Turn off the washing machine, and unplug the power cord.
2. Pour warm water over the water tap to loosen the water hose.
3. Disconnect the water hose, and soak it in warm water.
4. Pour warm water into the drum and leave it for about 10 minutes.
5. Reconnect the water hose to the water tap.
NOTE
If the washing machine still doesn’t operate normally, repeat the above steps until it operates
normally.
Care against an extended time of disuse
Avoid leaving the washing machine unused for an extended time.
If this is the case, drain the washing machine and unplug the power cord.
1. Turn the Cycle Selector to select a RINSE+SPIN.
2. Empty the drum, and press Start/Pause.
3. When the cycle is complete, close the water tap and disconnect the water hose.
4. Turn off the washing machine, and unplug the power cord.
5. Open the door to let air circulate through the drum.
WW70T4020CX_04221C-00_EN.indd 48 2021/2/2 14:33:36
background
English 49
Troubleshooting
Troubleshooting
If there is any problem, check the information message on the LED screen and follow the on-
screen instructions.
If the problem persists, please contact the service center.
Checkpoints
If you encounter a problem with the washing machine, rst check the table below and try the
suggestions.
Problem Action
Does not start.
• Make sure the washing machine is plugged in.
• Make sure the door is properly closed.
• Make sure the water taps are open.
• Tap
Start/Pause to start the washing machine.
• Make sure Child Lock
is not activated.
• Before the washing machine starts to ll, it will make a series
of clicking noises to check the door lock and will do quick
drain.
• Check the fuse or reset the circuit breaker.
• Check if power is supplied properly.
• Low voltage detected.
- Check if the power cord is plugged in.
• Make sure laundry is not caught in the door.
Water supply is
insufcient, or no
water is supplied.
• Fully open the water tap.
• Make sure the door is properly closed.
• Make sure the water supply hose is not frozen.
• Make sure the water supply hose is not kinked or clogged.
• Make sure there is sufcient water pressure.
• Make sure that the cold water tap and the hot water tap are
properly connected.
• Clean the mesh lter as it may be clogged.
After a cycle,
detergent remains in
the detergent drawer.
• Make sure the washing machine is running with sufcient
water pressure.
• Make sure the detergent is added to the centre of the
detergent drawer.
• Make sure the rinse cap is inserted properly.
• If using granular detergent, make sure the detergent selector is
in the upper position.
• Remove the rinse cap and clean the detergent drawer.
WW70T4020CX_04221C-00_EN.indd 49 2021/2/2 14:33:36
background
50 English
Troubleshooting
Troubleshooting
Problem Action
Excessive vibrations
or makes noise.
• Make sure the washing machine is installed on a level, solid
oor that is not slippery.
If the oor is not level, use the levelling feet to adjust the
height of the washing machine.
• Make sure the shipping bolts are removed.
• Make sure the washing machine is not in contact with any
other object.
• Make sure the laundry load is balanced.
• The motor can cause noise during normal operation.
• Overalls or clothes with metallic decorations can cause noise
while being washed. This is normal.
• Metal objects such as coins can cause noise. After washing,
remove these objects from the drum or lter case.
• Redistribute the load. If only one item of clothing needs
washing, such as a bathrobe or pair of jeans, the nal spin
result might be unsatisfactory, and a “Ub” check message will
be shown in the display.
Does not drain and/
or spin.
• Make sure the drain hose is straightened all the way to the
drain system. If you encounter a drain problem, call for service.
• Make sure the debris lter is not clogged.
• Close the door and press or tap Start/Pause.
For your safety, the washing machine will not tumble or spin
unless the door is closed.
• Make sure the drain hose is not frozen or clogged.
• Make sure the drain hose is connected to a drain system that is
not clogged.
• If the washing machine is not supplied with sufcient power,
the washing machine temporarily will not drain or spin. As
soon as the washing machine regains sufcient power, it will
operate normally.
• Make sure the drain hose is positioned correctly, depending on
the connection type.
• Clean the debris lter as it may be clogged.
WW70T4020CX_04221C-00_EN.indd 50 2021/2/2 14:33:36
background
English 51
Troubleshooting
Problem Action
The door does not
open.
• Press or tap Start/Pause to stop the washing machine.
• It may take a few moments for the door lock mechanism to
disengage.
• The door will not open until 3 minutes after the washing
machine has stopped or the power has been off.
• Make sure all the water in the drum is drained.
• The door may not open if water remains in the drum. Drain the
drum and open the door manually.
• Make sure the door lock light is off. The door lock light turns
off after the washing machine has drained.
Excessive suds.
• Make sure you use the recommended types of detergent as
appropriate.
• Use high efciency (HE) detergent to prevent oversudsing.
• Reduce the detergent amount for soft water, small loads, or
lightly soiled loads.
• Non-HE detergent is not recommended.
Cannot apply
additional detergent.
• Make sure the remaining amount of detergent and fabric
softener is not over the limit.
Stops.
• Plug the power cord into a live electrical outlet.
• Check the fuse or reset the circuit breaker.
• Close the door and press or tap Start/Pause to start the
washing machine.
For your safety, the washing machine will not tumble or spin
unless the door is closed.
• Before the washing machine starts to ll, it will make a series
of clicking noises to check the door lock and will do quick
drain.
• There may be a pause or soak period in the cycle. Wait briey,
and the washing machine may start.
• Make sure the mesh lter of the water supply hose at the
water taps is not clogged. Periodically clean the mesh lter.
• If the washing machine is not supplied with sufcient power,
the washing machine will temporarily not drain or spin. As
soon as the washing machine regains sufcient power, it will
operate normally.
WW70T4020CX_04221C-00_EN.indd 51 2021/2/2 14:33:37
background
52 English
Troubleshooting
Troubleshooting
Problem Action
Fills with the wrong
water temperature.
• Fully open both taps.
• Make sure the temperature selection is correct.
• Make sure the hoses are connected to the correct taps. Flush
water lines.
• Make sure the water heater is set to supply a minimum of
49 °C hot water at the tap. Also, check the water heater
capacity and recovery rate.
• Disconnect the hoses and clean the mesh lter. The mesh lter
may be clogged.
• While the washing machine lls, the water temperature may
change as the automatic temperature control feature checks
incoming water temperature. This is normal.
• While the washing machine lls, you may notice just hot and/
or just cold water going through the dispenser when cold or
warm temperatures are selected.
This is a normal function of the automatic temperature
control feature as the washing machine determines the water
temperature.
Load is wet at the
end of a cycle.
• Use the High or Extra High spin speed.
• Use high efciency (HE) detergent to reduce oversudsing.
• Load is too small. Small loads (one or two items) may become
unbalanced and not spin completely.
• Make sure the drain hose is not kinked or clogged.
Leaks water.
• Make sure the door is properly closed.
• Make sure all hose connections are tight.
• Make sure the end of the drain hose is correctly inserted and
secured to the drain system.
• Avoid overloading.
• Use high efciency (HE) detergent to prevent oversudsing.
• Check the drain hose.
- Make sure the end of the drain hose is not placed on the
oor.
- Make sure the drain hose is not clogged.
Has odours.
• Excessive suds collect in recesses and can cause foul odours.
• Run cleansing cycles to sanitize periodically.
• Clean the door seal (diaphragm).
• Dry the washing machine interior after a cycle has nished.
WW70T4020CX_04221C-00_EN.indd 52 2021/2/2 14:33:37
background
English 53
Troubleshooting
Problem Action
No bubbles are seen
(Bubble models only).
• You may not be able to see bubbles if there is too much items
in the drum.
• Severely contaminated laundry may not generate bubbles.
If a problem persists, contact a service center.
Information codes
If the washing machine fails to operate, you may see an information code on the screen.
Check the table below and try the suggestions.
Code Action
4C
Water is not supplied.
• Make sure the water taps are open.
• Make sure the water hoses are not clogged.
• Make sure the water taps are not frozen.
• Make sure the washing machine is operating with sufcient
water pressure.
• Make sure that the cold water tap and the hot water tap are
properly connected.
• Clean the mesh lter as it may be clogged.
• When the “4C” message appears, the machine drains water for
3 minutes. In the meantime, the power button will be disabled.
4C2
• Make sure the cold water supply hose is rmly connected to
the cold water tap.
If it is connected to the hot water tap, the laundry may be
deformed with some cycles.
5C
Water is not draining.
• Make sure the drain hose is not frozen or clogged.
• Make sure the drain hose is positioned correctly, depending on
the connection type.
• Clean the debris lter as it may be clogged.
• Make sure the drain hose is straightened all the way to the
drain system.
• If the information code remains, contact a customer service
centre.
WW70T4020CX_04221C-00_EN.indd 53 2021/2/2 14:33:37
background
54 English
Troubleshooting
Troubleshooting
Code Action
dC
Operating the washer with the door open.
• Make sure the door is properly closed.
• Make sure laundry is not caught in the door.
OC
Water has overowed.
• Restart after spinning.
• If the information code remains on the display, contact a local
Samsung service centre.
LC, LC1
Check the drain hose.
• Make sure the end of the drain hose is not placed on the oor.
• Make sure the drain hose is not clogged.
• If the information code remains, contact a customer service
centre.
3C
Check the Motor for operation.
• Try restarting the cycle.
• If the information code remains, contact a customer service
centre.
UC
The electronic control needs to be checked (Over Voltage Error).
• Check the PCB and wire harness.
• Check if power is supplied properly.
• If the information code remains, contact a customer service
centre.
Low voltage detected.
• Check if the power cord is plugged in.
• If the information code remains, contact a customer service
centre.
HC
High temperature heating check.
• If the information code remains, contact a customer service
centre.
1C
The Water Level sensor is not working properly.
• Try power off and restarting the cycle.
• If the information code remains, contact a customer service
centre.
• When the “4C” message appears,
the washer do draining for 3
minutes. During this time, the Power button is inoperative.
WW70T4020CX_04221C-00_EN.indd 54 2021/2/2 14:33:37
background
English 55
Troubleshooting
Code Action
8C
The MEMS sensor is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service
centre.
AC
Check communications between main and sub PBAs.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service
centre.
AC6
Check communications between main and inverter PBAs.
• Depending on the state, the machine may automatically returns
to normal operation.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service
centre.
DC1
The Main Door lock/unlock is not working properly.
• Turn the machine off, and restart the cycle.
• If the information code remains, contact a customer service
centre.
0
The machine does not turn off automatically after the last
spinning process, and the “0” message remains.
• The machine operates normally without running the DRUM
CLEAN cycle. However, it is recommended to run the cycle for
hygienic purposes.
If any information code keeps appearing on the screen, contact a local Samsung service
centre.
WW70T4020CX_04221C-00_EN.indd 55 2021/2/2 14:33:37
background
56 English
Specications
Specications
Fabric care chart
The following symbols provide garment care directions. The care labels include four symbols
in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The
use of symbols ensures consistency among garment manufacturers of domestic and imported
items. Follow the care label directions to maximize garment life and reduce laundry problems.
Resistant material Do not iron
Delicate fabric
Can be dry cleaned using any
solvent
Item can be washed at 95 ˚C Dry Clean
Item can be washed at 60 ˚C
Dry clean with perchloride,
lighter fuel, pure alcohol or
R113 only
Item can be washed at 40 ˚C
Dry clean with aviation fuel,
pure alcohol or R113 only
Item can be washed at 30 ˚C Do not dry clean
Hand wash only Dry at
Dry clean only Can be hung to dry
Can be bleached in cold water Dry on clothes hanger
Do not bleach Tumble dry, normal heat
Can be ironed at 200 ˚C max Tumble dry, reduced heat
Can be ironed at 150 ˚C max Do not tumble dry
Can be ironed at 100 ˚C max
WW70T4020CX_04221C-00_EN.indd 56 2021/2/2 14:33:40
background
English 57
Specications
Protecting the environment
• This appliance is manufactured from recyclable materials. If you decide to dispose of this
appliance, please observe local waste disposal regulations. Cut off the power cord so that
the appliance cannot be connected to a power source. Remove the door so that animals
and small children cannot get trapped inside the appliance.
• Do not exceed the detergent quantities recommended in the detergent manufacturer’s
instructions.
• Use stain removal products and bleaches before the wash cycle only when strictly
necessary.
• Save water and electricity by only washing full loads (the exact amount depends upon
the program used).
Spare parts guarantee
We guarantee that the following spare parts will be available to professional repairers and
end-users for a minimum period of 10 years after placing the last unit of the model on the
market.
• Door, door hinges and seals, other seals, door locking assembly, and plastic peripherals
such as detergent dispensers.
WW70T4020CX_04221C-00_EN.indd 57 2021/2/2 14:33:40
background
58 English
Specications
Specications
Specication sheet
“ * ” Asterisk(s) means variant model and can be varied (0-9) or (A-Z).
A
B
C
D
E
Type Front loading washing machine
Model name
WW8*T4*4***
WW8*T4*2***
WW7*T4*4***
WW7*T4*2***
Dimensions
A (Width)
600 mm
B (Height)
850 mm
C (Depth)
550 mm
D
630 mm
E
1072 mm
Water pressure 50 kPa ~ 800 kPa
NET weight 65 kg 65 kg
Wash and spin capacity 8.0 kg 7.0 kg
Power
consumption
Washing and
heating
220 V 1900 W
240 V 2300 W
Spin revolutions
WW8*T4*4***
WW7*T4*4***
WW8*T4*2***
WW7*T4*2***
1400 RPM 1200 RPM
NOTE
The design and specications are subject to change without notice for quality improvement
purposes.
WW70T4020CX_04221C-00_EN.indd 58 2021/2/2 14:33:40
background
WW70T4020CX_04221C-00_EN.indd 59 2021/2/2 14:33:40
background
DC68-04221C-00
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
NIGERIA 0800 726 7864 www.samsung.com/africa_en/support
WW70T4020CX_04221C-00_EN.indd 60 2021/2/2 14:33:40
background
DC68-04221C-00
ةلاسغلا
مدختسملا ليلد
WW8*T4***** / WW7*T4*****
WW70T4020CX_04221C-00_AR.indd 1 2021/2/2 15:00:15
background
ةيبرعلا 2
اامحتوملا
اامحتوملا
4 ةمسلا اامحلعم
4 ةمسلاتاداشرإلوحهفرعتنأبجيام
4 ةماهلاةمسلازومر
5 ةماهلاةمسلاتاطايتحا
7 بيكرتلادنعةماهتاريذحت
8 بيكرتلابةصاختاهيبنت
8 زاهجلااذهلامعتسادنعةماهتاريذحت
10 لامعتساتاهيبنت
13 فيظنتلادنعةماهتاريذحت
14 بيكرتلا
14 ةلومشملاتايوتحملاام
16 بيكرتلاتابلطتم
18 ةوطخبةوطخبيكرتلا
28 ليغشتلا ءدب لبق ام
28 ةيلواتادادعا
28 سبملالسغليلد
31 فظنملاجردبةصاختاداشرإ
34 اايلمعلا
34 مكحتلاةحول
35 ءدبللةلهسوةريسيتاوطخ
36 ةرودللةماعةيؤر
40 تادادعإ
41 ةنايصلا
41 ضوحلافيظنت
42 )يكذلاصحفلا(Smart Check
43 ئراوطلادنعفيرصتلا
44 فيظنتلا
47 دمجتلاةلاححصإ
47 مادختساءوسنمةينمزلاتارتفلانأشبءاجررذحلابجي
WW70T4020CX_04221C-00_AR.indd 2 2021/2/2 15:00:15
background
3 ةيبرعلا
اامحتوملا
48 اهحصإو ءاطخا فاشكتسا
48 صحفلاوققحتلاطاقن
52 تامولعملازومر
54 اافصاحملا
54 ةشمقابةيانعلالودج
55 ةئيبلاةيامح
55 رايغلاعطقنامض
56 ةينفلاتافصاوملاةمئاق
WW70T4020CX_04221C-00_AR.indd 3 2021/2/2 15:00:15
background
ةيبرعلا 4
ةمسلا اامحلعم
ةمسلا اامحلعم
ةيانعلاوهمادختساوزاهجلابيكرتةيلمعلوحةماهتامولعمعليلدلااذهىوتحي.ةديدجلاSamsungةلاسغكئارشعانيناهت
.كتلاسغلةديدعلادئاوفلاوتازيملانمةلماكلاةدافتسانمنكمتتلةيانعبليلدلااذهةءارقىجري.هب
ةمسلا ااداشرإ لحح هفرعت نأ بجم ام
نمآلكشبديدجلاكزاهجيفةعونتملافئاظولاوتازيملاليغشتةيفيكفرعتكنأنمدكأتللةلماشةءارقليلدلااذهةءارقءاجرلا
ضرغللزاهجلااذهمدختسي.لبقتسملايفهيلإعوجرلالجأنمزاهجلانمبرقلابنمآناكميفليلدلااذهبظافتحاءاجرلا.لاعفو
.اذهكلاملاليلديفروكذموهامكطقفهلصصخملا
بجياذل.اهلضرعتلالمتحملافقاوملاوفورظلاعيمجةرورضلابلمشتليلدلااذهيفةدراولاةمسلاتاداشرإوتاريذحتلانإ
.اهليغشتواهتنايصوةلاسغلابيكرتدنعةيانعوهابتناورذحبلماعتلا
ةفوصوملاكلتنع
ً
يلقفلتختدقكبةصاخلاةلاسغلاصئاصخنإف،ةددعتمتازارطعقبطنتةيلاتلاليغشتلاتاداشرإنا
ً
رظن
برقأبلصتا،تؤاستوأةلئسأيأكيدلتناكاذإ.قيبطتللةلباقريغنوكتدقةروكذملاريذحتلاتامعضعبنأامك،ليلدلااذهيف
.www.samsung.comعقومعتنرتناربعتامولعملاوتاميلعتلاعرثعاوأةمدخزكرم
ةماهلا ةمسلا زحمر
:يلم ام إ اذه مدختسملا ليلد يف ةدحجحملا اامعلاو زحمرلا ريشت
رمذوت
.زاهجلا فلت وأ/و احملا وأ دارفل ةريطخ ااباصإإيدؤتدقيتلاةنماريغوأةريطخلاتاسرامملا
هيبنت
.زاهجلا فلت وأ/و دارفل ااباصإإيدؤتدقيتلاةنماريغوأةريطخلاتاسرامملا
ةظحم
.زاهجلابغلابررضبببستلاوأةباصضرعتلارطخإكلذريش
ُ
ي
ااميلعتلا أرقا
.نمرخلو كل ااباصإ ثودح عنم إ هذه رمذوتلا اامع فدهت
.ةمانعب اهعابتا ىجر
ُ
م اذل
.لبقتسملا يف هيلإ عحجرلا لجأ نم نمآ ناكم يف هتءارق دعب ليلدلا اذهب ظفتحا
.زاهجلامادختسالبق
ً
وأتاداشراعيمجأرقا
زاهجلااذهليغشتعكسفنبفرعت.ةكرحتملااهئازجأوةيئابرهكلاةزهجاعيمجعملاحلاوهامكرطاخمللضرعتلللامتحادجوي
.نمآلكشبهليغشتنمنكمتتىتحهلامعتسادنعرذحلا
ّ
خوتو
WW70T4020CX_04221C-00_AR.indd 4 2021/2/2 15:00:16
background
5 ةيبرعلا
ةمسلا اامحلعم
ةماهلا ةمسلا ااطايتحا
رمذوت
،زاهجلامادختساءانثأيفصاخشاةباصإوأءابرهكلابقعصللضرعتلاوأقيرحبوشنةيناكمإليلقتل
:يليامكلذيفامب؛ةيساساناماتاطايتحاعبتا
1 .ةيسحوةيلقعوةيدسجتكشممهيدلصاخشألب
ِ
قنممادختسلزاهجلااذهممص
ُ
يمل
نعلوؤسمصخشوتينأإةربخلاوةفرعملامهصقنتنموأ)لافطامهيفامب(
.زاهجلامادختسانأشبتاداشراريفوتوأمهيلعفارشامهتمس
2 .صاخشاوربكأوأتاونس8نساوغلبنيذلالافطلنكمي:ابوروأ يف مادختسل ةبسنلاب
ةربخلامهصقنتنموأةيلقعلاوأةيسحلاوأةيدسجلاتاردقلايفا
ً
روصقنوناعينيذلا
ةصاخلاتاداشرابمهتيعوتوفارشلمهعوضخةطيرشزاهجلااذهمادختساةفرعملاو
نملافطاعنمبجي.ةنماكلاةلمتحملارطاخملااومهفتينأوزاهجللنمامادختسل
نكمييتلاةنايصلالامعأوأفيظنتلاةيلمعذيفنتبلافطلحمس
ُ
يكلذك.زاهجلاببعللا
.مهيلعفارشإنوداهئادأمدختسملل
3 ..زاهجلابمهثبعمدعنامضللافطاةبقارمبجي
4 .ليكووأةع
ّ
نصملاةكرشلالبقنمهرييغتنيعتيهنإف،يئابرهكلارايتلاكلسفلتةلاحيف
.رطاخملضرعتلايدافتللهؤمينفةفرعمبوأاهبصاخلاةنايصلا
5 .مادختسامدعوزاهجلاعماهريفوتيرجييتلاةديدجلاميطارخلاتاعومجممادختسابجي
.ةميدقلاميطارخلاةعومجم
6 .تاحتفلاهذهدسوأةقاعإمدعنيعتي،اهتدعاقيفةيوهتلاتاحتفتاذةزهجلةبسنلاب
.ةداجسلاب
7 .ملامزاهجلانعتاونس3نملقالافطاداعبإبجي:ابوروأ يف مادختسل ةبسنلاب
.نيمئادلافارشاوةبقارملاتحتاونوكي
WW70T4020CX_04221C-00_AR.indd 5 2021/2/2 15:00:16
background
ةيبرعلا 6
ةمسلا اامحلعم
ةمسلا اامحلعم
8 .نيعتيهنإف،يرارحلالصافلليدصقلاريغطبضلاةداعإنعةمجانلارطاخملابنجتل :هيبنت
،يجراخلصوولصفزاهجمسابفرع
ُ
ياموأ،يجراخليدبتزاهجربعةقاطلابزاهجلاديوزتمدع
ةيصاخبمظتنملكشباهليغشتفاقيإواهليغشتيرجيةيبرهكةرئادبهليصوتوأتقؤملالثم
.ام
9 .:لثمتامادختسممصمريغوطقفةيلزنملاتامادختسلممصمزاهجلااذه
؛لمعلاتائيبنماهريغوبتاكملاوةيراجتلاتحملابنيفظوملاخباطمقطانم
؛ةيفيرلالزانملا
؛ةينكسلاتائيبلانماهريغوتاحارتساوقدانفلايفءمعلابناجنموأ
؛راطفاعمتيبمللةيقدنفلاتادحولا
.لساغملايفوأققشلاتتكتيفيعامجلامادختساقطانم
WW70T4020CX_04221C-00_AR.indd 6 2021/2/2 15:00:16
background
7 ةيبرعلا
ةمسلا اامحلعم
بيكرتلا دنع ةماه اارمذوت
رمذوت
.زاهجلااذهبيكرتةصصختمةنايصةكرشوألهؤمينفوتينأبجي
ضرعتلاوأجتنملابقلعتتلكاشموأراجفناوأقيرحبوشنوأةيئابرهكةمدصثودحتاميلعتلاهذهعابتايفلشفلانعجتنيدق
.ةباصل
.ليقثهنزونزاهجلاعفردنعرذحلايخوتبجي
مدختستوطقفزاهجلااذهلسباقلامدختسا.ةددح
ُ
ملاةيبرهكلاتافصاوملاهيفققحتينوكينأعسبقملايفةقاطلالباكبكر
.ةلاطإلباك
بوشنوأةيئابرهكةمدصثودحإةقاطلاكلسديدمتوأةقاطكلسمادختسابىرخأةزهجأعمطئاحلاسبقمكراشتيدؤيدق
.قيرح
إكلذبمازتلايفلشفلايدؤي.جتنملاتافصاومبةصاخلاتاسايقللةقباطمرايتلاوددرتلاوةقاطلليبرهكلادهجلانأدكأت
.ماكحإبطئاحلاسبقميفةقاطلاكلسليصوتنمدكأت،اذل.قيرحبوشنوأةيبرهكةمدصثودح
ةعطقكلذلمدختساوماظتنابلاصتاطاقنويئابرهكلارايتلاسباقلةيفرطلاتاياهنلانمءاملاوأةبرتالثمةيجراخلاداوملاعيمجلزأ
.ةفاجشامق
.ةفاجشامقةعطقمادختسابهفظنوسبقملانميئابرهكلارايتلاسباقعزنا
.قيرحبوشنوأةيبرهكةمدصثودحإكلذبمازتلايفلشفلايدؤي
.ةيضراوحنيبرهكلارايتلاكلسديدمتمتيثيحبطئاحلابيبرهكلارايتلاسبقميف"ةشيفلا"يبرهكلاسباقلاليصوتبمق
يدؤيدقولبكلالخادةدوجوملاةيئابرهكلاكسافلتتدقف،سكاعملاهاجتايفسبقملايفةقاطلاكلسليصوتبتمقاذإ
.قيرحوأةيبرهكةمدصثودحإرمااذه
.مهيلعا
ً
رطخلثمتدقاهنلافطالوانتمنعا
ً
ديعبفيلغتلاداومعيمجبظفتحا
.قانتخابهتباصإإهسأرقوفسيكللفطلاعضويدؤيدق
.كيلإةنايصزكرمبرقأبلصتا،ةقاطلالصوموأةقاطلاكلسوأزاهجلافلتةلاحيف
.ميلسلكشبضراعزاهجلااذهتيبثتنيعتي
.نوفيلتطخوأيكيتسبءامبوبنأوأزاغبوبنأبناجبضراعزاهجلاتبثت
.جتنملابلكاشموأراجفناوأقيرحبوشنوأةيئابرهكةمدصثودحرمااذهنعجتنيدق
ةيلحملانيناوقلاعمسبقملااذهقفاوتنمدكأتوحيحصلكشبضرؤمريغسبقميفيبرهكلارايتلاكلسليصوتبمقت
.ةينطولاو
.لاعتشلةلباقداوموأناخسنمبرقلابزاهجلااذهبيكرتمدعبجي
.)رطملاتارطق(ءاملاورشابملاسمشلاءوضلضرعتيناكميفوأةبرتأوأتيزهبعقوموأةبطرةئيبيفزاهجلااذهبيكرتمدعبجي
.ةضفخنمهترارحةجردنوكتعقوميفزاهجلااذهبيكرتمدعبجي
.بيباناراجفناإديلجلايدؤيدق
.زاغللبرستهبنوكيعقوميفزاهجلااذهبيكرتمدعبجي
.قيرحبوشنوأةيبرهكةمدصثودحرمااذهنعجتنيدق
WW70T4020CX_04221C-00_AR.indd 7 2021/2/2 15:00:16
background
ةيبرعلا 8
ةمسلا اامحلعم
ةمسلا اامحلعم
.يبرهكلوحممدختست
.قيرحبوشنوأةيبرهكةمدصثودحرمااذهنعجتنيدق
.مكحمريغطئاحسبقموأفلاتةقاطكلسوأيئابرهكرايتسباقمدختست
.قيرحبوشنوأةيبرهكةمدصثودحرمااذهنعجتنيدق
.ةوقبهينثوأةقاطلاكلسبذجمدعنيعتي
.هيطوأةقاطلاكلسفلمدعبجي
كلسعفدوأةقاطلاكلسنيبضارغأعضووأةقاطلاكلسقوفليقثضرغعضووأيندعمضرغقوفةقاطلاكلسقيلعتمدعبجي
.زاهجلافلخةدوجوملاةحاسملايفةقاطلا
.قيرحبوشنوأةيبرهكةمدصثودحرمااذهنعجتنيدق
.يئابرهكلارايتلاسباقليصوتمدعءانثأيفةقاطلاكلسبذجمدعبجي
.لصوملابا
ً
كسمميئابرهكلارايتلاسباقلصفا
.قيرحبوشنوأةيبرهكةمدصثودحإكلذبمازتلايفلشفلايدؤي
.اهيلإلوصولالهسيلءاملافرصميطارخوءاملاديروتريبانصو،يئابرهكلارايتلاسباقنمبرقلابزاهجلاعضوبجي
ةلوئسمنوكتSamsungنإف،جتنملليفارتحاريغحيلصتلاوأيتاذلاحيلصتلاوأدمتعمريغةمدخدوزمىدلحيلصتةيلمعرثإع
تاميلعتعبتتجتنمللحصةلواحميأنعةمجانجتنملاةمسلكاشمنمكلذريغوأةباصإوأجتنملابيصتتايفلتيأنع
نمدمتعمةمدخدوزمفخصخشلبقنمجتنملاحصةلواحمرثإعجتنملاقحليررضلكو.ا
ً
قيقدا
ً
عابتاةنايصلاوحصا
.نامضلاب
ً
ومشمنوكنلSamsung
بيكرتلاب ةصاخ ااهيبنت
هيبنت
.يبرهكلارايتلاسباقإةلوهسبلوصولااهلخنمنكميةقيرطبزاهجلااذهعضويغبني
.ءابرهكلابيرستلةجيتنقيرحوأةيبرهكةمدصثودحإرمااذهبمازتلايفلشفلايدؤي
.زاهجلانزولمحتتةبلصوةيوتسمةيضرأعكزاهجبيكرتبجي
.جتنملابقلعتتةيعيبطريغلكاشموأءاضوضوأتاكرحتوأتازازتهادوجوتاميلعتلاهذهعابتايفلشفلانعجتنيدق
زاهجلا اذه لامعتسا دنع ةماه اارمذوت
رمذوت
.ةنايصزكرمبرقأبلصتاو،يروفلكشبءابرهكلالاصتاعطقوهايملاليغشتفاقيإبمق،ءاملانمةدئازةيمكلزاهجلاضرعتةلاحيف
.نيتلتبمنيديبيبرهكلارايتلاسباقسملت
.ةيبرهكةمدصدوجورمااذهنعجتنيدق
.ةنايصللزكرمبرقأبلصتاوا
ً
روفةقاطلاكلسليصوتءاغلإبمق،ناخدوألاعتشاةحئاروأ،ةيعيبطريغءاضوضلزاهجلارادصإةلاحيف
WW70T4020CX_04221C-00_AR.indd 8 2021/2/2 15:00:16
background
9 ةيبرعلا
ةمسلا اامحلعم
.قيرحبوشنوأةيبرهكةمدصثودحإكلذبمازتلايفلشفلايدؤي
.ةقاطلاكلسسملنودبا
ً
روفناكملاةيوهتبجي،)كلذهباشامو،لاسملايطفنلازاغلاو،نابوربلازاغك(زاغللبيرستدوجوةلاحيف
.ةقاطلاكلسوأزاهجلاسملبمقت
.ةيوهتةحورممدختست
.قيرحوأةيبرهكةمدصثودحةرارشلانعجتنيدق
.زاهجلانمصلختلادنعةلاسغلابابلماحةلازإبجي،كلذك.اهلخادبوأةلاسغلاقوفنوبعليلافطاعدت
.ةلاسغلاهذهلخادمهسابتحاةلاحيفا
ً
قانتخالافطاتوميدق
.مادختسالبقةلاسغلالفسأبقفرملا)موفلا،جنفسا(فغلاةلازإنمدكأت
.راجفناوألاعتشلةلباقىرخأداوميأوألوحكلاوأءطلارنتوأنيزنبلاوأنيسوريكلاوأزاجلااهبقلاعلارصانعلالسغمدعبجي
.راجفناوأقيرحوأةيبرهكةمدصثودحرمااذهنعجتنيدق
.)ةيلاعةرارحةجرددنعفيشنتلا/فيفجتلا/لسغلا(ليغشتلاءانثأةوقلابةلاسغلابابحتفمدعبجي
رمااذهنعجتنيدق.ةقلزنمضراحبصتنأيفببستلاوأقورحلابةباصاثودحةلاسغلاجراخءاملاعافدنانعجتنيدق
.ةيصخشتاباصإ
.ةباصاوأجتنملافلتإةوقلاببابلاحتفيدؤيدق
.ليغشتلاديقاهدوجوءانثأةلاسغلاتحتكيديلخدت
.ةيصخشتاباصإرمااذهنعجتنيدق
.نيتلتبمنيديبيبرهكلارايتلاسباقسملت
.ةيئابرهكةقعصثودحإكلذببس
ُ
يدق
.زاهجلاليغشتءانثأةقاطلاكلسلاصتاعطققيرطنعزاهجلاليغشتفاقيإمدعبجي
.قيرحوأةيبرهكةمدصاهنعجتنيةرارشثودحإسبقملابىرخأةرمةقاطلاكلسليصوتيدؤيدق
.هقوفوأزاهجلااذهلخادقلستلابلافطلحمست
رخأتاباصإعوقووأقورحلابةباصاوأ،ةيبرهكةمدصلضرعتلاإكلذيدؤيدق
.اهليغشتءانثأةلاسغلالفسأيندعمنئاكيأوأكيديعضت
.ةيصخشتاباصإرمااذهنعجتنيدق
إميقتسمطخيفاهبحساوماكحإبا
ً
مئاد"ةشيفلا"سباقلاكسمأ.هسفنيبرهكلارايتلاكلسبحسقيرطنعزاهجلاسباقعزنت
.يبرهكلارايتلاسبقمجراخ
.ةيبرهكةمدصوأ/وقيرحوأيبرهكسامثودحإكلسلافلتيدؤيدق
.كسفنبهليدعتوأهكفوأزاهجلاحصإلواحت
.يسايقلارهصنملافخ)كلذإامويندعمكلسوأساحنلالثم(رهصنميأمادختسامدعبجي
.هبيكرتةداعإوأزاهجلااذهحصإيرورضلانمنوكيامدنعكلةمدخزكرمبرقأبلصتا
.تاباصإعوقووأجتنملابةقلعتمتكشمعوقووأقيرحبوشنوأةيبرهكةمدصلضرعتلاإكلذبمازتلامدعيدؤيدق
.ءابرهكلاذخأمنمةقاطلاكلسلصفبجي،زاهجلايفءامللبيرستهنعجتنيومكحمريغءاملابد
ّ
وزتلاموطرخحبصيامدنع
.قيرحبوشنوأةيبرهكةمدصثودحإكلذبمازتلايفلشفلايدؤي
.ةيقربلاةفصاعلا/دعرلاءانثأوأةليوطةينمزتارتفلزاهجلامادختسامدعلاحيفةقاطلاسباقعزنبمق
.قيرحبوشنوأةيبرهكةمدصثودحإكلذبمازتلايفلشفلايدؤي
WW70T4020CX_04221C-00_AR.indd 9 2021/2/2 15:00:16
background
ةيبرعلا 10
ةمسلا اامحلعم
ةمسلا اامحلعم
.زاهجلااذهإةبيرغداوميألوخدةلاحيفSamsungءمعةمدخلزكرمبرقأبلصتاو"ةشيفلا"يبرهكلارايتلاسباقعزنا
.قيرحبوشنوأةيبرهكةمدصثودحرمااذهنعجتنيدق
باصيدقو،لخادلانمةلوهسبةلاسغلابابحتفنكميثيح.اهلخادبوأةلاسغلاقوفنوبعلي)ةفيلاتاناويحلاوأ(لافطاعدت
.اهلخادبمهسابتحاةلاحيفةغلابتاباصإبلافطا
لامعتسا ااهيبنت
هيبنت
فيظنتوةقاطلاكلسليصوتءاغلإبمق،كلذإاموماعطلاتافلخموأةبرتاوأتافظنملالثمةبيرغةدامةلاسغلابقلعيامدنع
.ةمعانوةللبمشامقةعطقمادختسابةلاسغلا
.أدصلاوأفلتلاوأهيوشتلاوأناولايفرييغتدوجوإرمااذهبمازتلايفلشفلايدؤي
.ةلاسغلامادختسادنعصرحلابجي.يوقمادطصاثودحةجيتنيماماجاجزلارسكنيدق
.ةباصإثدحتدقجاجزلارسكنيامدنع
.ءطببروبنصلاحتفبجي،ءاملاديروتموطرخليصوتةداعإدنعوأءاملاديروتيفلشفثودحدنع
.ةليوطةرتفلمادختسامدعةلاحيفءطببروبنصلاحتفبجي
.ءامللبيرستدوجووأةلاسغلانمءزجفلتإءاملابوبنأوأءاملاديروتموطرخيفءاوهلاطغضدوجويدؤيدق
.فيرصتلابقلعتتةلكشمدوجونمققحت،ليغشتلاءانثأفيرصتلابقلعتيأطخثودحةلاحيف
وأةيبرهكةمدصلضرعتلاإيدؤيدقكلذنإف،فرصلايفةلكشمببسباهجراخءاملابايسناءانثأةلاسغلامادختسامتاذإ
.قيرحبوشن
.بابلابليسغلاقلعتمتيثيحبلماكلابةلاسغلايفليسغلاخدإبجي
.ءامللبيرستثودحهنعجتنيدقامك،ةلاسغلاوأليسغلافلتإكلذيدؤيدق،بابلابليسغلاقلعتةلاحيف
.ةلاسغلالامعتسامدعدنعهايملادادمإطوطخقلغأ
.ءاملاديروتموطرخليصوترامسمماكحإنمدكأت
.ةباصاوأزاهجلافلتإرمااذهبمازتلايفلشفلايدؤي
.)كلذريغوأ،رعشلاوأ،طويخلاوأتايافنلاك(ةبيرغداوميأبيمامابابلاجاجزوةيطاطملاةدادسلاخاستامدعنمدكأت
.هايملابرستيفببستيدقكلذنإف،ا
ً
مامتبابلاقلغمتيملوأبابلايفةبيرغةداميأتقلعاذإ
.جتنملامادختسالبقءامللبيرستدوجومدعوءاملاموطرخلصومماكحإنمققحتلاوروبنصلاحتفبجي
.ءامللبيرستثدحيدق،ءاملاديروتموطرخلصوموأريماسملاماكحإمدعةلاحيف
.طقفيلزنملامادختسلهئارشبتمقيذلاجتنملاميمصتمت
همدقتيذلايساسانامضلالبقنمجتنملاةيطغتمتي،ةلاحلاهذهيفو.هلمادختساءوسلمعلاضارغجتنملامادختسادع
ُ
ي
.مادختساءوسنعمجنتيتلارئاسخلاوألاطعانعةيلوئسمةيألمحتتSamsungةكرشنأامك،Samsungةكرش
داوملاوأقابطاوأةلعتشملارئاجسلاوألعتشملانادعمشلاوأليسغلالثم(هقوفءايشأعضووأزاهجلاقوففوقولامدعبجي
.)كلذإاموةيندعملاتانئاكلاوأةيواميكلا
WW70T4020CX_04221C-00_AR.indd 10 2021/2/2 15:00:16
background
11 ةيبرعلا
ةمسلا اامحلعم
.ةباصاوأجتنملابقلعتتلكاشموأقيرحوأةيئابرهكةمدصثودحرمااذهنعجتنيدق
.زاهجلاحطسقوفةيرشحلاتاديبملالثمةرياطتمداومشرمدعبجي
.جتنملابقلعتتلكاشموأقيرحوأةيئابرهكةمدصدوجوا
ً
ضيأهنعجتنيدقف،ناسنابرضيرمااذهنأإةفاضابف
.ةلاسغلاهذهنمبرقلابةيسيطانغمورهكتاجماهنمثعبنتماسجأةيأعضت
.ليغشتلابقلعتيأطخدوجوةجيتنةيصخشتاباصإرمااذهنعجتنيدق
.ةنخاسلافرصلاهايمسملت.فيفجتلاةرودوأةيلاعةرارحتاجرديفليسغلاءانثأاهفيرصتمتيامدنعةنخاسفرصلاهايمحبصت
رخأتاباصإعوقووأقورحلابةباصاإكلذيدؤيدق
ةرارحلاةجردلاعبتكلذفلتخينأنكميو،ضفخنتىتحاتقوقرغتستةرارحلاةجردنإف،فرصلالبقةيلاعهايملاةرارحةجردتناكاذإ
.ةيلخادلا
لسغلا
ً
صاخا
ً
جمانربنمضتيكزاهجنكيملاماهفيفجتوأاهفيشنتوأءامللداضملا)*(شامقلاوأداجسلاوأدعاقملالسغمدعبجي
.رصانعلاهذه
ةيضايرلالدبلاوأتاضافحلاوأمونلابئاقحوأجلزتلالاطنبوأديصلاتارتسوأراطمانمةيقاولاةيطغاوأةيفوصلاتاشورفملا:)*(
.كلذإاموتارايسلاوةيراخبلاتاجاردلاوتاجاردلاةيطغأو
دوجوإرمااذهيدؤيدق.ةيانعلاةمععةلاسغلاةمعدوجوةلاحيفىتحبلصلاوأكيمسلاداجسلالسغمدعبجي
.ةيعيبطلاريغتازازتهلةجيتنسبملاوأةيضراوأطئاوحلاوأةلاسغلافلتوأةباصإ
ةيطاطملاةيفلخلاةماعدلاهذهكفنتدق.ةيطاطمةيفلخةماعدعلمتشتيتلالجراتاحسمموأتاياشملامقطألسغت
.فيرصتلايفلطع
ً
ثمثدحينأكيفيظولاءادايفروصقإكلذيدؤيدقوةلاسغلاةلحلخادقصتلتو
.قوحسملاجرددوجومدعةلاحيفةلاسغلاليغشتمدعبجي
.ءاملابيرستلةجيتنةباصإوأةيبرهكةمدصدوجورمااذهنعجتنيدق
.
ً
انخاسنوكيهنإثيح
ً
ةرشابماهدعبوأفيشنتلاةيلمعءانثألخادلانمضوحلاسملمدعبجي
.قورحبةباصاكلذببس
ُ
يدق
.يجاجزلابابلاسملرذحاكلذل.فيفجتلاوليسغلايتيلمعءانثأا
ً
نخاسيجاجزلابابلاحبصي
.يجاجزلابابلاسملوأةلاسغلابةطيحملاةقطنملايفبعللابلافطلا
ً
ضيأحمست
.قورحبةباصاكلذببس
ُ
يدق
.فيظنتلاقوحسمجردلخادكديعضت
.قوحسملالاخدإزاهجةطساوبكيديةباصإنكميثيحةيصخشتاباصإاذهنعجتنيدق
لزأ.)طقفةيصاخلاهذهمعدتيتلاتيدوملايفكلذو(فظنملاقوحسملامادختساةلاحيفلئاسلافظنملاليلدمدختس
ُ
ي
.فظنملاقوحسملامادختسانعليلدلا
.ةلاسغلالخادبسبملاريغ)تاناويحلاوماعطلااياقبوةيذحالثم(ءايشأيأعضوبنجت
.ةيعيبطلاريغتازازتهلةجيتنةفيلأتاناويحدوجوةلاحيفتوملاوةباصاوأةلاسغلافلتإرمااذهيدؤيدق
.كلذإامورفاظاوأنيكاكسلاوأريماسملالثمةداحتانئاكمادختسابرارزاعطغضلامدعبجي
.ةباصإوأةيبرهكةمدصثودحرمااذهنعجتنيدق
رجاتميفةدوجومبلاغلايفنوكتيتلاو،مسجلابةيانعلاتارضحتسموأتاميركوأتويزعيوتحتيتلاسبملالسغرظح
ُ
ي
.كيلدتلاتادايعوأةرشبلابةيانعلاتارضحتسم
.هايملابرستإيدؤيوةيطاطملاةدادسلاهوشتيفكلذببستيدق
WW70T4020CX_04221C-00_AR.indd 11 2021/2/2 15:00:16
background
ةيبرعلا 12
ةمسلا اامحلعم
ةمسلا اامحلعم
.تقولانمةليوطتارتفلضوحلايفضييبتلاداوموأرعشلاسنبوأسيبابدلالثمةيندعمتانئاكيأكرتمدعبجي
.ضوحلاأدصإرمااذهيدؤيدق
بجي.هفيظنتيفجنفسإو)يداع(فيظنتلئاسمادختساببوبناحطسفيظنتلضف
ُ
ي،بوبناحطسعأدصلاروهظةلاحيفو
.
ً
ايئاهنةيندعمةاشرفمادختسامدع
فيظنتللقوحسمنمضتيناكاذإهفيشنتوأهفطشوأليسغلالسغمدعبجيامك،رشابملكشبفيظنتلالئاسمادختسامدعبجي
.فاجلا
.تيزلادسكأتنعةجتانلاةرارحللةجيتنيروفلاعتشادوجوإرمااذهيدؤيدق
.نيخستلا/ديربتلاةزهجأنمةباسنملاهايملامدختست
.ةلاسغلايفلكاشمثودحرمااذهنعجتنيدق
.ةلاسغلاعميعيبطلانيديلالسغنوباصمادختسامدعبجي
.ةئيسةحئاردوجووأأدصلاوأنوللارييغتلثمجتنملابقلعتتلكاشمثدحتدق،ةلاسغلالخادبلصتلاومكارتلاةلاحيفف
.رخأليسغعماهلسغوليسغلاةكبشيفتايردصلاوبراوجلاعضوبجي
.ليسغلاةكبشيفتاشورفملانمليسغلانمعاونألسغمدعبجي
.ةيعيبطلاريغتازازتهلةجيتنةباصإدوجوإرمااذهبمازتلايفلشفلايدؤي
.بلصليسغقوحسممدختست
.ةلاسغلالخادهمكارتةلاحيفءامللبيرستثدحيدقف
.اهلسغمتيسيتلاسبملابويجغيرفتنمدكأت
ةغلابرارضأثادحإيفراجحاوأيغاربلاوأريماسملاوأسيبابدلاوأةيندعملاتمعلالثمةداحلاوةبلصلاءايشاببستتدق
.زاهجلاب
زولاةليقثىرخاةيندعملاءايشاوأمجحلاةريبكرارزأوأتاميزبإبةدوزملاسبملالسغبمقت
ةجردو،اهبىصوملاةرودلاددحوناتهبلامدعونوللابظافتحاعاهتردقساسأعاهنولبسحاهفينصتوليسغلاسبمزرفبمق
.ةيفاضافئاظولاو،هايملاةرارح
.تاجوسنملافلتوأناولاهوشتإكلذيدؤيدق
.هبةقلاعلالافطاعباصأعةلاسغلابابقلغتىتحرذحلا
خوت
.ةباصإعوقويفكلذبمازتلامدعببستيدق
.ةيواحلافيفجتبحامسللليسغةروددعبا
ً
حوتفمبابلاعد،تامكارتلاوحئاورلانمةياقولل
.اهيففيفجتلاوليسغةروددعبا
ً
حوتفمفظنملاجردعد،سلكلامكارتعنمل
WW70T4020CX_04221C-00_AR.indd 12 2021/2/2 15:00:16
background
13 ةيبرعلا
ةمسلا اامحلعم
فيظنتلا دنع ةماه اارمذوت
رمذوت
.
ً
ةرشابمزاهجلاقوفءاملاشرقيرطنعزاهجلافيظنتمدعبجي
.يوقضمحعيوتحيفظنممادختسابمقت
.زاهجلافيظنتللوحكلاوأءطلاففخ
ُ
موأنيزنبلامادختسامدعبجي
.قيرحوأةيبرهكةمدصوأهيوشتوأنوللايفرييغتدوجورمااذهنعجتنيدق
.هتنايصوأهفيظنتلبقطئاحلاسبقمنمزاهجلاسباقلصفا
.قيرحبوشنوأةيبرهكةمدصثودحإكلذبمازتلايفلشفلايدؤي
WW70T4020CX_04221C-00_AR.indd 13 2021/2/2 15:00:16
background
ةيبرعلا 14
بيكرتلا
بيكرتلا
.ليسغلادنعثداوحعوقوعنموحيحصلكشبةلاسغلابيكرتنامضلةيانعبتاميلعتلاهذهعبتا
ةلحمشملا اامحتوملا ام
ءمعةمدخليلحملازكرملابلصتا،ءازجاوأةلاسغلايفامةلكشميناعتتناكاذإ.جتنملاةبلعيفةدوجومءازجالكنأدكأت
.ةئزجتلارجاتوأSamsungجنوسماس
01
02
12
11
10
09
03
04
06
08
07
05
01 ءاخراعارز02 ليسغلاقوحسمجرد03 مكحتلاةحول
04 بابلا05 ةيواحلا06 تاسنلاةافصم
07 ئراوطلادنعفيرصتلابوبنأ08 ةافصملاءاطغ09 ةلاسغلاحطس
10 ءابرهكلاسباق11 فيرصتلاموطرخ12 ةلاسغلالجرأءاوتسا
WW70T4020CX_04221C-00_AR.indd 14 2021/2/2 15:00:16
background
15 ةيبرعلا
بيكرتلا
طبرلاحيتافمةيطغاريماسمموطرخلالماح
درابلاءاملاديروتموطرخنخاسلاءاملاديروتموطرخلئاسلافظنملاةريجح
رفحتم ريغ( ااقولملا
SKK-DF:نيزختلاةعومجم
.ةلاسغلاعففجملابيكرتلةبولطمنيزختلاةعومجم-
ةظحم
.ةلاسغلاىوتسمطبضونحشلاريماسمةلاز:طبرلاحاتفم
.زارطلاعدمتعي)6إ3(رامسملاةيطغمدقملامقرلا.نحشلاريماسمةلازإدعبتاحتفلاةيطغتل:ةيطغاريماسم
.ليسغلاضوحوأفيرصتلابوبنأيففيرصتلاموطرخقيلعتل:موطرخلالماح
).طقفةنيع
ُ
متازارطيفةرفوتمنخاسلاءاملاديروتميطارخ(.ةلاسغلاإءاملاديروتل:درابلا/نخاسلاءاملاديروتموطرخ
)طقفاهبدوزملاتيدوملاب(.لئاسلافظنملامادختسفظنملاةريجحيفهلاخدإيرجي:لئاسلافظنملاةريجحليلد
WW70T4020CX_04221C-00_AR.indd 15 2021/2/2 15:00:17
background
ةيبرعلا 16
بيكرتلا
بيكرتلا
بيكرتلا اابلطتم
يضرا ليصحتلاو ةيئابرهكلا ةقاطلا ردصم
رايتطلوف240 - 220ةردقبرهصنموأةيئابرهكةرئادعطاق
زتره50/ددرتم
طقفةلاسغلاليغشتلةيعرفةيئابرهكةرئاد
رايتكلسبةلاسغلاديوزتيرجي،بسانملاضيرأتلانامضل
لكشباهمادختسضيرأتتاكوشثثيذسباقهبيئابرهك
.حيحصلكشببكر
ُ
ميضرأسبقميفحيحص
ريغتنكاذإةمدخينفوأءابرهكينفبا
ً
نيعتسمرمانمققحت
.ضيرأتلاةمسنأشب
ً
ادكأتم
ةلاحيفو.ةلاسغلابدوزملاسباقلاعتيدعتيأيرجت
لهؤميئابرهكينفبنعتسا،رايتلاذخأمعمهتمءممدع
.بسانمذخأمبيكرتل
رمذوت
.ديدمتلبكمدختست
.طقفةلاسغلاعمقفرملايئابرهكلارايتلاكلسمدختسا
ةكابسلاريساومطوطخبيضراكلسلالصت
.نخاسلاهايملاريساوموأزاغلاطوطخوأةيكيتسبلا
ببس
ُ
تدقبسانمريغلكشبةلصتملاضيرأتلاتصومنإ
.ةيبرهكتامدصثودح
هايملاب دادما
وليك50نيبنوكيةلاسغلاهذهلبسانملاهايملاطغضنإ
50نملقأهايملاطغضناكاذإ.لاكسابوليك800إلاكساب
.هايملامامصقغإماكحإمدعببسيدقكلذنإفلاكسابوليك
إيدؤياممعقوتملانملوطأا
ً
تقوةيواحلاءلمجاتحيدق
نمضهايملاريبانصنوكتنأنيعتي.لمعلانعةلاسغلافقوت
لوصوليهستلةلاسغلليفلخلابناجلانممس120ةفاسم
.ةلاسغلاإةقفرملاهايملاريبانصميطارخ
:يلاتلاذيفنتنيعتي،برستلارطاخمليلقتل
.هايملاريبانصإميطارخلالوصوريسيت
.ةلاسغلاليغشتمدعةلاحيفريبانصلاقغإ
يفبرستيأدوجونعفشكللمظتنملكشبصحفا
.ءاملالاخدإموطرختصو
هيبنت
ءاملاريبانصومامصيفةدوجوملاتيصوتلاةفاكصحفبمق
ةلاسغلامادختسالبقتابيرستيأكانهتناكاذإاممققحتلل
.واةرملل
فمرصتلا
90-60اهعافتراغلبيةيسأرةروساممادختسابSamsungيصوت
موطرخلاكبشملخفيرصتلاموطرخليصوتنيعتي.مس
بوبنأةيسأرلاةروساملايطغتنأنيعتيوةيسأرلاةروساملاإ
.فيرصتلا
WW70T4020CX_04221C-00_AR.indd 16 2021/2/2 15:00:17
background
17 ةيبرعلا
بيكرتلا
ةيضرا حطس
علوصحللبلصوتباثحطسعةلاسغلاتيبثتبجي
ليلقتلاهتيوقتإةيبشخلاحطساجاتحتدق.ءادألضفأ
طبلاحطسأوداجسلانوكي.ةنزتملاريغلامحاوأ/وزازتها
ةيلامتحاوزازتهاتايلمعيفةمهاسملماوعةباثمبةمعانلا
.فيشنتلاةرودءانثأفيفطلكشبةلاسغلاكرحت
هيبنت
.ةفيعضةينبوأةيضرأعةلاسغلابيكرتبمقت
هايملا ةرارح ةجرد
نأكلذدمجتللهايملااهيفضرعتيقطانميفةلاسغلابكرت
ةخضملاوهايملامامصيفهايملاضعببا
ً
مودظفتحتةلاسغلا
ءازجأيفيقبتملادمجتملاهايملاببس
ُ
يدق.ميطارخلاوأ/و
تانوكمنمكلذريغوأةخضملاوأرويسلافلتليصوتلا
.ةلاسغلا
ةنازخلا وأ ةرطنقلا بيكرت
:رقتسملاليغشتللىنداصولخلا
بناوجلامم25
بناجلا
يفلخلا
مم50
ءزجلا
يولعلا
مم25ةهجاولامم550
بناجلابنوكينأبجي،
ً
اعمففجملاوةلاسغلابيكرتةلاحيف
رتميللم550اهردقةيلاخءاوهةحتفةنازخلاوأةرطنقلليولعلا
.اهنيعبءاوهةحتفاهدحوةلاسغلابلطتت.لقاع
WW70T4020CX_04221C-00_AR.indd 17 2021/2/2 15:00:17
background
ةيبرعلا 18
بيكرتلا
بيكرتلا
ةحطخب ةحطخ بيكرتلا
ةلاسغلا ناكم رايتخا - 1 ةحطخلا
:ناكملا اابلطتم
ةيوهتلاةيلمعقوعيدقطبوأداجسدوجونوديوتسمبلصحطس
ةرشابملاسمشلاةعشأنعا
ً
ديعب
كساليصوتوةيوهتللةيفاكةحاسم
)سويزلس0(دمجتلاةطقننمعأةرارحلاةجردنوكتنأنيعتي
ةرارحلارداصمنعا
ً
ديعب
نوشلا ريماسم كف - 2 ةحطخلا
.نحشلاريماسملكلزأوجتنملاةوبعتايوتحمغرف
ةظحم
.زارطلابسحنحشلاريماسمددعفلتخيدق
رمذوت
نعا
ً
ديعب)كلذإامونيريتسيلوبلاوةيكيتسبلاسايكا(داوملاكلتنمصلخت.لافطاعا
ً
رطخفيلغتلاداومل
ّ
كشتدق
.لافطالوانتم
يفنحشلاريماسمنوكتنأنودةلاسغلاكرحت.نحشلاريماسمةلازإدعبريماسملاةيطغأبتاحتفلاطغ،ةباصابنجتل
ً
بقتسماهمادختسنمأعضوميفنحشلاريماسمعظفاح.رخأعضومإةلاسغلاكيرحتلبقنحشلاريماسمبكر.اهناكم
.ةجاحلادنع
WW70T4020CX_04221C-00_AR.indd 18 2021/2/2 15:00:17
background
19 ةيبرعلا
بيكرتلا
A
1 .)لكشلايفرئاودبةزيمملا(نحشلاريماسمعضومددح
.ةلاسغلانميفلخلابناجلاع
هيبنت
.موطرخلاكبشمت
ّ
بثييذلا)Aِ( يغربلاكفت
2 .نحشلاريماسمعيمجكفلقفرملاطبرلاحاتفممدختسا
.ةعاسلابراقعهاجتاسكعاهريودتلخنم
ةظحم
.لبقتسملايفاهمادختسنحشلاريماسمبظافتحابجي
WW70T4020CX_04221C-00_AR.indd 19 2021/2/2 15:00:17
background
ةيبرعلا 20
بيكرتلا
بيكرتلا
B
3 .ةرئادبةزيمملا(تاحتفلايف)B( ريماسملا ةيطغألخدأ
.)لكشلايف
ءاحتسا لجرأ طبض - 3 ةحطخلا
1 .وأةطرفملاةوقلانإ.قفربددحملاناكملايفةلاسغلاعض
.ةلاسغلاءاوتسالجرأفلتإيدؤتدقةدئازلا
2 .لجرأطبضقيرطنعا
ً
يوديةلاسغلاءاوتساطبضا
.ءاوتسا
WW70T4020CX_04221C-00_AR.indd 20 2021/2/2 15:00:18
background
21 ةيبرعلا
بيكرتلا
3 .حاتفممادختسابليماوصلامكحأ،ءاوتساةيلمعمامتإب
.طبرلا
هيبنت
لباكعءاوتسالجرأطغضمدعنمدكأت،جتنملابيكرتدنع
.ةقاطلا
هيبنت
ةلاسغلانأدكأتمث.زازتهاببسبءاضوضيفببستلاوأةلاسغلاكرحتبنجتلةيضراحطسعةرقتسماهلكءاوتسالجرأنأدكأت
.ليماوصلاطبرمكحأف،بذبذتةلاسغلاتناكاذإف.بذبذت
WW70T4020CX_04221C-00_AR.indd 21 2021/2/2 15:00:18
background
ةيبرعلا 22
بيكرتلا
بيكرتلا
هايملا محطرخ ليصحت - 4 ةحطخلا
.رفوتملاهايملاموطرخبسحتاميلعتلاعابتاىجري.زارطللا
ً
عبتفلتخيدقرفوتملاهايملاموطرخ
بلحلملا ءاملا رحبنصب ليصحتلا
1 .هاجتابلصوملاردأمث،ءاملاروبنصبءاملاموطرخلص
.حضوموهامكةعاسلابراقعةكرح
2 .لوخدلامامصبهايملادادمإموطرخنمرخافرطلالص
يفموطرخلاردأ.ةلاسغلانميفلخلابناجلابدوجوملا
.هطبرماكحةعاسلابراقعهاجتا
3 .لوحتابيرستيأدوجونمققحتوهايملاروبنصحتفا
دوجوةلاحيفةقباسلاتاوطخلاررك.تيصوتلانكامأ
.هايملاببرست
رمذوت
زكرمبلصتا،هايملاموطرخنمبرستثودحةلاحيف.ءابرهكلاردصمنعاهلصفاوةلاسغلاليغشتفقوأ،هايمللبرستثدحاذإ
قعصلاإكلذبمازتلامدعيدؤيدق.ءاملاروبنصنمبرستثودحةلاحيفةكابسلاينفبلصتاوأ،يلحملاجنوسماسةمدخ
.يبرهكلا
هيبنت
.يلاعلاطغضلالمحتيلوطأموطرخبهلدبتسا،ةياغللا
ً
ريصقموطرخلاناكاذإ.ةوقلابهايملابدادماموطرخليط
ُ
ت
WW70T4020CX_04221C-00_AR.indd 22 2021/2/2 15:00:18
background
23 ةيبرعلا
بيكرتلا
بلحلملا ريغ ءاملا رحبنصب ليصحتلا
A
B
1 ..)B( هايملا دادمإ محطرخنم)A( لحوملالزأ
2 .ريماسملاطبرءاخر)ةبيلص(يعابرسأرب
ً
اكفممدختسا
.ئياهملابةعبرا
C
3 .هكفلمهسلاهاجتايف)C( ءزجلاردأولوحملاكسمأ
.)*(رتميللم5رادقمب
C
4 .تنأوريماسملالفقامث،ءاملاروبنصعلوحملاعض
.لوحملاعفرت
5 ..هطبرماكحمهسلاهاجتايف)C( ءزجلاردأ
WW70T4020CX_04221C-00_AR.indd 23 2021/2/2 15:00:18
background
ةيبرعلا 24
بيكرتلا
بيكرتلا
D
6 .موطرخلص،ءاملاموطرخع)D( ءزجلادشءانثأيف
هعضومبموطرخلابكري.)D( ءزجلاررحمث.لوحملابءاملا
.ةقطقطتوصعمس
ُ
يولوحملاب
7 .عطقملايف3و2رظنا،ءاملاموطرخليصوتلامك
."بلحلملا ءاملا رحبنصب ليصحتلا"
ةظحم
.يغبنيامكهليصوتنمققحتلللفسءاملاموطرخبحسا،لوحملاإهايملاموطرخليصوتدعب
.لوحملايفروبنصلالاخدإلبقةلصافلاةقلحلالزأ،ا
ً
دجا
ً
ريبكوأا
ً
عبرمروبنصلاناكاذإ.هايملاريبانصنما
ً
جئارا
ً
عونمدختسا
WW70T4020CX_04221C-00_AR.indd 24 2021/2/2 15:00:18
background
25 ةيبرعلا
بيكرتلا
:نخاسلا هايملاب دادمل يفاضإ لخدمب ةدوزملا ةددوملا اازارطلل ةبسنلاب
1 .نخاسلاهايملابدادماموطرخنمرمحافرطلالص
.ةلاسغلانميفلخلابناجلابدوجوملالوخدلامامصب
2 .إنخاسلاهايملابدادماموطرخنمرخافرطلالص
.نخاسلاهايملاروبنص
)طقف ةددوم اازارط( يئاملا فقحتلا محطرخ
A
برسترطاخمنمنيمدختسملاهايملافاقيإموطرخرذح
ُ
ي
)A( رشؤملائضيوهايملاقفدترعشتسيوهف.اهعوقودنعهايملا
رستدوجوةلاحيفرمحانوللابيفزكرملابدوجوملا
ةظحم
.ةلاسغلاسيلوهايملاروبنصيفهايملافاقيإموطرخفرطبيكرتنيعتي
WW70T4020CX_04221C-00_AR.indd 25 2021/2/2 15:00:19
background
ةيبرعلا 26
بيكرتلا
بيكرتلا
فرصلا محطرخ ليصحت - 5 ةحطخلا
رطثثبفيرصتلاموطرخعضونكمي
A
ليسغلا ضحح ةفاح قحف
مس90ومس60نيبعافتراعفيرصتلاموطرخعضونيعتي
،فيرصتلاموطرخءانثناعءاقبل.ةيضراىوتسمنم)*(
عكساملاتبث.)A( يكيتسبلا محطرخلا كساممدختسا
.رقتسمفيرصتنامضلفاطخةطساوبرادجلا
فمرصتلا بحبنأ لحح
.)*(عافترامس90ومس60نيبفيرصتلابوبنأنوكينأبجي
.مس65غلبيعافترايذيسأربوبنأمادختسابحصن
ُ
ي
ليلدمدختسا،هناكميففيرصتلاموطرخءاقبنامضل
.)لكشلارظنا(رفوتملاكيتسبلاموطرخلا
لاخدإنمدكأت،فيرصتلاءانثأيفهايملاقفدتبحسعنمل
رصلابوبنأيفمس15فيرصتلاموطرخ
.رادجلابموطرخلاليلدت
ّ
بث،فيرصتلاموطرخلاقتناعنمل
:فيرصتلليسأرلابوبناتابلطتم
مس5ةرئادلارطقلىندأدح
ةقيقدلايفرتم60فرجلاةعسلىندادحلا
ضحولا فمرصت بحبنأ عرف يف
ثيحبضوحلاةكابسقوففيرصتلابوبنأعرفنوكينأبجي
عافتراعموطرخلافرطنوكي
.ضرانعلقاعمس60
مس60:)*(
هيبنت
بوبنأليصوتلبقضوحلافيرصتبوبنأعرفنعءاطغلالزأ
.هيلإفيرصتلا
WW70T4020CX_04221C-00_AR.indd 26 2021/2/2 15:00:19
background
27 ةيبرعلا
بيكرتلا
هيبنت
.ضاوحاوأةدكارلاهايملانكامأيففيرصتلاموطرخعضت
.ةلاسغلاإىرخأةرمءاملاقفدتيدقف
ةلاسغلا لغش - 6 ةحطخلا
رزعطغضا.ةرئادعطاقوأرهصنمبا
ً
دوزموةبسانمةردقهلوا
ً
يمحموا
ً
ضرؤمنوكينأعطئاحلابسبقملايفةقاطلالباكلص
.ةلاسغلاليغشتل ةقاطلا
WW70T4020CX_04221C-00_AR.indd 27 2021/2/2 15:00:19
background
ةيبرعلا 28
ليغشتلا ءدب لبق ام
ليغشتلا ءدب لبق ام
ةيلوا اادادعا
)كلذب ىص
ُ
حم( ةرماعملا عضو لغش
.ةيصاخلاهذهمادختسالبقةغرافةلاسغلاةيواحنأنمدكأت.ةقدبليسغلانزوباسحعةلاسغلاةردقنمضتةرياعملاةيصاخنإ
1 .رخأةرماهليغشتدعأمثةلاسغلاليغشتفقوأ
2 ..”CB“ةلاسررهظتانه."ةرياعملاعضو"ءدبلناوث3ةدملا
ً
عمليغشتلا ليجأت وةرارولا ةجرد
يرزع
ً
وطمطغضا
3 ..ةديدجةرودءدبلتقؤم فاقمإ/ءدب رزعطغضا
4 ..قئاقد3ةدملةعاسلابراقعدضوةعاسلابراقعهاجتايفةيواحلارودت
5 ..
ً
ايئاقلتةلاسغلاليغشتفاقيإيرجيوضرعلاةشاشع”0 “رهظت،ةرودلاهذهنمءاهتنادنع
6 ..نامادختسلةزهاجةلاسغلا
سبملا لسغ ليلد
زرفلا- 1 ةحطخلا
:ةيلاتلا ريماعملا نم يأ قفو سبملا زرفا
.نوياروفاوصأوةيريرحسبموةيعانصةشمقأوةطولخمفايلأوناطقأإسبملازرفا:ةيانعلاةقاطب
.ةنولملاسبملانعءاضيبلاسبملالصفبمف:نوللا
.ليسغلاءادأنسح
ُ
يةلاسغلاةناوطسأيفا
ً
عمسبملانمةفلتخمماجحأنيبعمجلانإ:مجحلا
رئاتسلاوةيفوصلاضارغاةلاحيفكلذولهسيوكرايخمادختساب،ةدحعلكةقيقرلاسبملالسغا:سململاةقر
.ضارغاعتاقصلملانمققحت.ةيريرحلاضارغاو
ةظحم
.ليسغلاءدبلبقكلذعءانباهزرفاوسبملابةيانعلاةيفيكتاقصلمنمققحتلانمدكأت
بحيجلا غارفإ - 2 ةحطخلا
سبملاو ليسغلا بحيج لك عرفأ
.سبملاعميزباوسيبابدلاوةيندعملاتمعلالثمةيندعملاضارغانإ
اهرهظ ع ةزرطملاو رارزاب ةنمزملا سبملا بلقا
تاباحسلاقلغبجياذل.ةناوطساةلسفلتببسيدقاذهنإف،لسغلاءانثأةحوتفمتكاوجلاوليوارسلاتاباحستكرتاذإ
.لسغلالبقطيخباهتيبثتو
.لسغلاءدبلبقطويخلاتيبثتعصرحا.ىرخأسبمعمةليوطلاةطرشاوطويخلاتاذسبملاكباشتتدق
WW70T4020CX_04221C-00_AR.indd 28 2021/2/2 15:00:19
background
29 ةيبرعلا
ليغشتلا ءدب لبق ام
ليسغلا ةكبش مادختسا- 3 ةحطخلا
رسكنتدقردصلاتامحيفةيندعملاءازجاف.ليسغةكبشيف)هايملايفاهلسغنكمييتلا(ردصلاتامحعضونمدكأت
رخاليسغلاضارغأفشتو
ةكبشلخادمهعضوبمقاذل.ليدانملاوتاجوسنملاوتازافقلاوبراوجلالثمبابلابةفيفخلاوةريغصلاسبملاقلعتتدق
.ةديجلسغ
اهكرحتدقةلاسغلايفةيعيبطريغتازازتهاثودحإكلذيدؤيدقف.اهبسبمدوجونوداهدحولسغلاةكبشلسغبمقت
.تاباصإثودحببستو
رورضلا ةلاح يف( ليسغلا لبق ام- 4 ةحطخلا
فيظنتلاقوحسمةفاضإةلاحيفليسغلالبقامرتخت.راتخملاجمانربللليسغلالبقامرايخلاددح،خاستاديدشليسغلاناكاذإ
.ةيواحلاإا
ً
يودي
ةلحمولا ةعس دمدوت- 5 ةحطخلا
36ةحفصرظنا.ليسغللةبسنلابةيضرمريغجئاتنإكلذيدؤيثيحةلاسغللددحملانزولازواجتت.ةلاسغللددحملانزولازواجتت
.سبملاعونقفونزولاةعسعفوقولل
ةظحم
يفاهبىصومفيفجتةرودةعرسىصقأنإفاذل.فيفجتلاةيلمعةيلاعفلقتوألسغلاةدملوطتدق،ةفحلاوأشرافملالسغدنع
.لقأوأمجك2نزولاةعسنوكتوةقيقدلايفةفل800يهةفحلاوأشرافملاةلاح
هيبنت
.فيفجتلاءادأةيلعافللق
ُ
يدقةلاسغلالخادنزاوتملاريغليسغلانإ
.بابلابةقلعتمتسيلاهنأو،امامتضوحلايفسبملالوخدنمدكأت
.حيحصلكشببابلاقلغنيامبر،إو.قفرببابلاقلغأ.ةدشببابلاقلغت
بسانملا فظنملا عضو - 6 ةحطخلا
هايملاةرارحةجردوناولاو،)فوصلاوأةمعانلاسبملاوأةيعانصلافايلاوأنطقلا(شامقلاعونعليسغلاقوحسمعوندمتعي
.ةيكيتاموتواتاسغلل
ً
اصيصخم
مصملا”ةليلقلاةوغرلا“اذليسغلاقوحسم
ً
امودمدختسا.خاستاةجردو
ةظحم
نكتملاذإف.كتقطنميفءاملاءاقنةجردوخاستاةجردوسبملانزولا
ً
قفوليسغلاقوحسملةعنصملاةكرشلاتايصوتعبتا
.ةلوئسملاةيلحملاتاهجلابلصتا،هايملارسعةجردنما
ً
دكأتم
رصلاجرخمدسيوفطشلاةورددعبفظنملالظيدق.ةلويسلاوأبلصتلاإليميفظنممدختست
هيبنت
فظنممادختساةلاحيفامأ.طقفلداعتملئاسفظنممادختسانيعتيهنإف،)ةقيقر /فحص( ةروديفةيفوصلاداوملالسغدنع
.هنولريغيوليسغلاعىقبيدقهنإف)ةقيقر /فحص( ةرودعمقوحسم
WW70T4020CX_04221C-00_AR.indd 29 2021/2/2 15:00:19
background
ةيبرعلا 30
ليغشتلا ءدب لبق ام
ليغشتلا ءدب لبق ام
ليسغلا احسبك
.ليسغلاتوسبكنمجئاتنلالضفأعلوصحللةيلاتلاتاوطخلاعابتإىجر
ُ
ي
1 .ءزجلاهاجتةغرافيهوليسغلاةلحعاقيفةلوسبكلاعضن
.اهنميفلخلا
2 ..ةلوسبكلاعأةلحلايفليسغلاعضن
هيبنت
.امامتةلوسبكلابوذتامبر،ةدحاوةعاسنملقأيفيهتنتيتلاتارودلاوأةدرابلاهايملامدختستيتلاتارودلايف
WW70T4020CX_04221C-00_AR.indd 30 2021/2/2 15:00:20
background
31 ةيبرعلا
ليغشتلا ءدب لبق ام
فظنملا جردب ةصاخ ااداشرإ
تامعنملىطسولاةريجحلاويسيئرلاليسغللةصصخ
ُ
مىرسيلاةريجحلاثيحتاريجحثثتاذعيزوتةدحوعةلاسغلايوتحت
.يديهمتلاليسغللىنميلاةريجحلاوةشمقا
A
01 لبقامفظنممدختسا :ليسغلا لبق ام ةريج
ُ
ح
.ليسغلا
02 ليسغلافظنممدختسا :يسيئرلا ليسغلا ةريج
ُ
ح
وأ/وضيبملاوعقنلافظنموءاملامعنمويسيئرلا
.عقبلاتيزم
03 معنملثمةيفاضاداوملاعض :معنملا ةريجح
.)A( ىصقا دولاةمعيطختمدعنيعتي.ةشمقا
هيبنت
.ةلاسغلالمعءانثأقوحسملاجردحتفت
:تافظنملانمةيلاتلاعاونامدختست
صارقأوأحاولألكشعتافظنملا
تاكبشوأتايركلكشعتافظنملا
دادسنايدافتلمادختسالبقهايملاب)تافظنملاوأةشمقاتامعنمكلذكو(زيكرتلاةيلاعوأةزكرملاداوملافيفختنيعتي
ريجحلا
مدختسا.نوللايفريغتلضرعتيدقليسغلانإف،كلذفخبو.ةيواحلايفةرشابمفظنملاعضت،ليغشتلاليجأترايتخادنع
.ليغشتلاليجأتريتخادنعفظنملاففجم
ىوتسمروهدتيفببستلااهنأشنمةناوطسايفةيئايميكلاداوملااياقبف.ةناوطسافيظنتلةفظنمداوميأمدختست
.ليسغلا
WW70T4020CX_04221C-00_AR.indd 31 2021/2/2 15:00:20
background
ةيبرعلا 32
ليغشتلا ءدب لبق ام
ليغشتلا ءدب لبق ام
يلم ام عبتا ،اافظنملا جرد يف فيظنتلا داحم عضحل
1 ..
ً
يلقتافظنملاجردحتفا
2 . ةيسيئرلا ليسغلا ةريجح يفليسغلافظنمعض
.ددصلااذهباهتايصوتوأةعنصملاةهجلاتاميلعتقفو
.33ةحفصبداشرتساىجر
ُ
ي،ةلئاسلاتافظنملامادختس
A
3 ..ةشمقا معنم ةريج
ُ
ح يفةشمقامعنمعض
.)A( ىصقا دولاةمعيطختمدعنيعتي
4 .عض،ليسغلالبقامةيصاخمادختسةجاحبتنكاذإ
ليسغلا لبق ام ةريج
ُ
ح يفليسغلالبقامفظنم
.اهتايصوتوأعينصتلاةهجتاميلعتقفو
5 ..تافظنملاجردقلغأ
WW70T4020CX_04221C-00_AR.indd 32 2021/2/2 15:00:20
background
33 ةيبرعلا
ليغشتلا ءدب لبق ام
هيبنت
فظنملاعضوميفةردوبلافيظنتلاقوحسمعضت
.لئاسلا
هعضولبقزكرملاةشمقامعنمفيفختبمازتلانيعتي
.ةلاسغلاب
معنم ةريج
ُ
ح يفيسيئرلافيظنتلاقوحسمعضت
.ةشمقا
)طقف كلذ معدت يتلا امدحملا يف( ةلئاسلا اافظنملا مادختسا ااميلعت
A
مث.ةيسيئرلا ليسغلا ةريج
ُ
ح يفلئاسلاءاعولخدأ:
ً
وأ
بوسنمنوكيثيحبءاعولايفلئاسلاسبملافظنمعض
.)A( ىصقا دولا ةمعلفسأفظنملا
هيبنت
.ءاعولابةدوجوملاىصقادحلاةمعزواجتت
قوحسملامادختساةلاحيفةلئاسلاتافظنملاةيواحعفرا
.فظنملا
ةلئاسلا اافظنملا مادختسا دنعفظنملا قحوسملا مادختسا دنع
WW70T4020CX_04221C-00_AR.indd 33 2021/2/2 15:00:20
background
ةيبرعلا 34
اايلمعلا
اايلمعلا
مكوتلا ةححل
09
02
08
03
04
05
06
07
01
01 ةرودلاديدحتصرقرودرايتخصرقلاردأ
02 ضرعلاةشاش
اهمامتردقملايقبتملاتقولاوليسغللةيلاحلاةرودلانع
َ
تامولعملا
ِ
ضرعلا
ُ
ةشاشحضوت
.امةلكشمثودحلاحيفتامولعملاداوكأضرعتكلذكو
03 ةرارحلاةجرد
.ةيلاحلاةرودللةبسنلابهايملاةرارحةجردرييغتلانهطغضا
04 نارود
راتخملاةرودللةبسنلابنارودلاتارمددعرييغتلطغضا
.هايملايفليسغلالظيثيحبفطشلاةيلمعقيلعتيرجي:)رشؤم ب( فطشلا فاقمإ
.نارودةرودلغشوأهايملافرص،ليسغلاجارخ
.يئاهنلافيرصتلاةروددعبسبملاةناوطساففجت: نارود نودب
رهظيامدنع.ناوث3ةدملنارودعطغضا،طقففيشنتةرودذيفنتل : طقف فيشنت ةرود
ةعرسللصتىتحنارودعطغضلاررك،ةشاشلاعريودتلاةعرسوليسغلاةرودتقو
تقوفقوتي.ليسغلاةوردءدبلتقؤم فاقمإ/ءدبعطغضامث.اهرتخاوةبوغرملانارودلا
راتخملاةرودلاعنارودلا
05 تارايخ
.ليسغلاةرودعرايخلااذهرفوتفقوتيو.تارايخلاديدحتلطغضا
06
ليغشتلاليجأت
ءدبنمةفيظولاهذهكنكم
ُ
تو.ةيلاحلاةرودلامامتإداعيمديدحتةفيظولاهذهحيتت:ليغشتلاليجأت
ةلاسغللةيلخادلاةيقطنملامكحتلاةادأةطساوبكلذوهديدحتيرجييذلاتقولايفليسغلاةرود
دعوملايفليسغلاةيلمعءاهنكتلاسغجمربيف
ً
ثمةديفمتادادعاهذهف.كتادادعإقفو
.ةداعكلزنملهيفدوعتيذلا
.تاعاسلابةيلاحلاةدحولاراتختلرزلاعطغضا
07
عقن
عقبلانمريثكلاةلازإعةيصاخلاهذهدعاس
ُ
تو.عقنةفيظوليغشتفاقيإ/ليغشتلرزلاعطغضا
.ةبعصلا
WW70T4020CX_04221C-00_AR.indd 34 2021/2/2 15:00:21
background
35 ةيبرعلا
اايلمعلا
08
تقؤمفاقيإ/ءدب
.هفاقيإوأليغشتلاءدبلطغضا
09
ةقاطلا
.ةلاسغلاليغشتفاقيإ/ليغشتلطغضا
.ةصاخلاتازيملامسقعجار،تارايخلالوحتامولعملانمديزمل
.ناوث3ةدملطغضلالصاوورزلاعطغضا:)ناوث3(*
ءدبلل ةلهسو ةريسم ااحطخ
1
6
2
4
3
5
1 ..ةلاسغلاليغشتلةقاطلا
رزعطغضا
2 ..ليسغلاجمانربرايتخةرودلا ددو
ُ
م صرقردأ
3 .رورضلايضتقتامقفو)نارود وةرارولا ةجرد (ةرودلاتادادعإريغ
4 ..بوغرملارايخلاءاقتنرزلااذهعىرخأةرمطغضا.اارايخ طغضا،امرايخةفاض
5 .هذهنميأمادختسايفتبغراذإ.كيلعريسيتللعقن
و ليغشتلا ليجأت
نملكلنيتعيرسنيتمئاقةلاسغلاهذهحيتت
.لباقملارزلاعطغضا،تارايخلا
6 ..تقؤم فاقمإ/ءدب
عطغضا
يتا عبتا ،ليغشتلا لخ ةرودلا رييغتل
1 ..ليغشتلافاقيتقؤم فاقمإ/ءدبعطغضا
2 ..ةفلتخمةرودرتخا
3 ..ةديدجةرودءدبلتقؤم فاقمإ/ءدبرزعطغضا
WW70T4020CX_04221C-00_AR.indd 35 2021/2/2 15:00:21
background
ةيبرعلا 36
اايلمعلا
اايلمعلا
ةرودلل ةماع ةمؤر
ةيسايقلا اارودلا
ةرودلافصحلا
نزو ىصقأ
)مجك(
مجك 8مجك 7
نطق
ةيلخادلاسبملاوأةدئاملاشرافموأريرسلاةيطغأوأةينطقلاسبملل
.ناصمقلاوأفشانملاو
زولاقفوا
ً
يكيتاموتوأاهليدعتوفطشلاوليسغلاةدمطبضيرجي
دحلا
ىصقا
دحلا
ىصقا
نطق
ريرسلاةيطغأونطقلاةشمقيلاثملاءاداةضفخنملاةقاطلاعضوققح
ُ
ي
.ناصمقلاوفشانملاوةيلخادلاسبملاوةدئاملاشرافمو
ةرارحلانملقأةيلعفلالسغلاةرارحةجردنوكتدق،ةقاطلاريفوتضارغو
.ةددح
ُ
ملا
دحلا
ىصقا
دحلا
ىصقا
ةيعانطصاةشمقا
ديامايلوبلاةدامو)اريفيرتلاونيلويدلا(رتسيلوبلانمةعونصملاةشمقل
.ةجسنانمكلذلثام
ُ
ياموأ)نولينلاونولريبلا(
4.04.0
فطش+نارود .ليسغلاعةشمقامعنمعضودعبيفاضافطشلاةزيمرفويو
دحلا
ىصقا
دحلا
ىصقا
فيفجت/فرص
ةبوطرلاةلازإلجةيفاضإفيفجتةيلمعليغشتوةيواحلالخادهايملافيرصتل
.لاعفوحنعليسغلانم
دحلا
ىصقا
دحلا
ىصقا
ضوحلافيظنت
.هنمايرتكبلاوخاسوانمصلختلابضوحلافيظنت
ايئاقلتراطخايرجي.ضيبموأفظنمعضونودبةلسغ40لككلذذيفنتيرجي
.ةلسغ40لكدعب
.ةناوطساولخنمدكأت
.ةناوطسافيظنتلةفظنمداوميأمدختست
--
'15عيرسلالسغلا
.ةعرسباهجاتحتيتلامجك2.0نملقأنزوبخاستاةفيفخسبملالسغل
نمامارغ20نمرثكأمادختسا.تافظنملانمامارغ20نملقأمادختسا
.تافظنملااياقبكرتيدقتافظنملا
.ىصقأدحبةلئاسلاتافظنملانملم20مادختسا،ةلئاسلاتافظنملل
2.02.0
يمويليسغ .ناصمقلاوةيلخادلاسبملالثما
ً
يمويمدختستيتلاسبملل4.04.0
ةقيقر/فوص
لثمةلاسغلاباهليسغنكمييتلاةقيقرلاسبملاوةيفوصلاةشمقابصاخ
)ةيريرحلا(ةيتحتلاةيئاسنلاسبملاو،ردصلاتامحو،ةفافشلاةشمقا
.طقفا
ً
يوديلسغ
ُ
تيتلاةشمقانماهريغو
نمةجسناةيامحلعقنلاوئداهلازازتهاعةقيقر /فحصةروددمتعت
.فلتلا/شامكنا
.لئاسفظنمودياحمفظنممادختسابىصو
ُ
ي
2.02.0
WW70T4020CX_04221C-00_AR.indd 36 2021/2/2 15:00:21
background
37 ةيبرعلا
اايلمعلا
ةرودلافصحلا
نزو ىصقأ
)مجك(
مجك 8مجك 7
راخبلابفيظنت
.ةيلخادلاسبملالثم،دلجلارشابتيتلاناتكلاونطقلاةجسنأ
.عأوأةيوئمةجرد60ةرارحةجردددحةيحصلاجئاتنلالضفأعلوصحلل
.)ميقعتلا(ايريتكبلاعءاضقلاوةيساسحلاةياعربراخبلاتارودزيمتت
4.04.0
ناولا
ةنكادلاكسبملسغنامضلفيفجتلاليلقتويفاضافطشلاعدمتعي
ً
ديجاهفطشوفطلبةلضفملا
4.04.0
فشارش
.كلذإامو،شارفلاةيطغأوتاءموريرسلاةيطغ
نملقأنزولانأدكأتوتاشورفملانمدحاوعونلسغا،جئاتنلالضفأقيقحتل
.مارجوليك2.0
2.02.0
WW70T4020CX_04221C-00_AR.indd 37 2021/2/2 15:00:21
background
ةيبرعلا 38
اايلمعلا
اايلمعلا
ةظحم
هنأشنمتارودلايفةعنصملاةهجلااهتددحيتلاةعسلابسحيولعلايلزنملاففجملاوأةيلزنملاةلاسغلاءلمبمازتلانإ
.هايملاوةقاطلاعظافحلايفماهسا
عأتوصلاناك،ريوطتلاةلحرميفريودتلاةعرستدازاملكف:ريودتلاةعرسبةيقبتملاةبوطرلاوءاضوضلاوأتوصلاىوتسمرثأتي
.لقأةيقبتملاةبوطرلاىوتحمتناكو
.لوطأتارتفلوةضفخنمةرارحتاجردعلمعتماعلكشبيتلاتارودلايهةقاطلاكهتساىوتسمعةءافكرثكاتارودلا
اارايخ
رايخلافصحلا
فثكم .داتعملانملوطأةرودلكليغشتةدمنوكيو.خاستاديدشليسغلل
يلوأليسغ .ةيساساليسغلاةرودلبقةيلوأليسغةرودرايخلااذهفيضي
+فطش .ةيفاضإفطشتارودةفاضرزلااذهعطغضا
WW70T4020CX_04221C-00_AR.indd 38 2021/2/2 15:00:22
background
39 ةيبرعلا
اايلمعلا
ليغشتلا ليجأت
ةعاسةدايزب(.ةعاس24ىتحةدحاوةعاسنمتقولاليجأترايتخاب،قحتقويف
ً
ايئاقلتليسغلاةيلمعءاهنةلاسغلاطبضكنكمي
.لسغلاةيلمعنمءاهتناهيفيرجييذلاتقولاإةضورعملاةعاسلاريشت.)ةدحاو
1 .رورضلاتضتقااذإةرودلاتادادعإريغمث.ةرودرتخا
2 ..بوغرملاتقولللصتىتحىرخاولتةرمليغشتلا ليجأتطغضا
3 ..تقؤم فاقمإ/ءدبعطغضا
.ةعاسلالمعءدبعمكرايتخابصاخلا
ُ
رشؤملاءيضي
4 ..ةقاطلارزعطغضلابةلاسغلاليغشتدعأ،ليغشتلا ليجأتءاغل
لاثم
ليغشتلاليجأتةيصاخفضأكلذقيقحتل.نيتعاسا
ً
ساسأهتدمنأعمنانمتاعاسثثدعبجمانربءاهتنإيفبغرتكنأضرفنل
أدبت؟كلذدعبثدحياذام.ءاسم02:00ةعاسلادنعتقؤم فاقمإ/ءدبرزعطغضاوتاعاس3عهطبضعميلاحلاجمانربلاإ
.ةلاحلاهذهلينمزلاطخلايليامضرعيو.ءاسم05:00ةعاسلادنعيهتنتتوءاسم03:00ةعاسلادنعلمعلاةلاسغلا
م 02:00
تاعاس3عليغشتلاليجأتطبضا
م 03:00
أدبإ
م 05:00
ةياهن
WW70T4020CX_04221C-00_AR.indd 39 2021/2/2 15:00:22
background
ةيبرعلا 40
اايلمعلا
اايلمعلا
اادادعإ
لافطا لفق
،اهدادعإوأةلاسغلاليغشتءدبنمعضرلاوألافطاعنمل
.ةقاطلارزءانثتسابرارزاعيمجلافطالفقلفقي
ةجرد رزع
ً
وطمطغضا،لافطالفقةيصاخطبضل
طغضا،طيشنتلل.
ٍ
ناوثثثةدملا
ً
عمنارود رزوةرارولا
.تقؤم فاقمإ/ءدب
ع
رزع
ً
وطمطغضا،لافطالفقةيصاخلمعفاقي
.
ٍ
ناوثثثةدملا
ً
عمنارود رزوةرارولا ةجرد
ةظحم
ةفاضإتدرأاذإهنإف،لافطالفقمادختساةلاحيف
لفق"لمعفاقيإ
ً
وأكيلعنيعتيهنإف؛ليسغوأفظنم
."لافطا
ليغشتةداعإدعبةطشناهلاحعلظتوتدادعايرست
.ةلاسغلا
دضلفقنوكيامدنعليسغةروددعببابلاحتفكنكم
ُ
ي
حتفلبقةفيظولاليغشتفقوأ.ليغشتلاديقلافطا
.ليسغلاجارخإكنكميىتحبابلا
احصلا ليغشت فاقمإ/احصلا ليغشت
يرجيامدنع.ةلاسغللتوصلاليغشتفاقيإوأليغشتكنكمي
توصردصينلهنإف،ليغشتلافاقيإعةفيظولاهذهطبض
لظت،كلذعمو.يئابرهكلارايتلاعاطقناهيبنتو،ةرودلامامتإ
.ةطشنىرخاتاوصا
اارايخ ونارود يرزعطغضا،توصلامتكل
.ناوث3ةدملامهيلعطغضلابرمتساوا
ً
عم
ثثةدملةيناثةرمنيرزلاعطغضا،تمصلامتكءاغل
.
ٍ
ناوث
ليغشتةداعإدعبةطشناهلاحعلظتوتدادعايرست
.ةلاسغلا
WW70T4020CX_04221C-00_AR.indd 40 2021/2/2 15:00:23
background
41 ةيبرعلا
ةنايصلا
ةنايصلا
.يضارتفااهرمععظافحلاوءاداىوتسمضفخنيىتحةفيظنةلاسغلاعظفاح
ضحولا فيظنت
70 - 60نيباميلإليسغلاةرودهذهيفءاملانيخستيرجي.ايرتكبلانمصلختلاوضوحلافيظنتلمظتنملكشبةرودلاهذهذفن
.سويزلسةجرد
1 ..ةلاسغلاليغشتل ةقاطلارزعطغضا
2 ..ضحولا فيظنت رايتخةرودلا ددو
ُ
مردأ
3 ..تقؤم فاقمإ/ءدبعطغضا
ةظحم
رييغتنكم
ُ
يوسويزلسةجرد70عددح
ُ
مضحولا فيظنتيفهايملاةرارحةجردنإ
.ةلسغ40لكةرمضحولا فيظنتةرودليغشتبىصو
ُ
يو
.فظنملاإءاملامعنمفضأوأهايملارسعىوتسمقفوفظنملانمةبسانملاةيمكلافضأ،سلكمكارتنودةلوليحلل
ضحولا فيظنت ريكذتلا هبنم
.LEDوأةنوقيأبامإنوكيسضوحلافيظنتهبنمنإف،زارطلاعا
ً
دامتعا
.مكحتلاةحولعءيضتةنوقيانإف،تانوقيلةبسنلاب
.مكحتلاةحولبتارايخلاةقطنميفوأ،ةيلاتلاضوحلافيظنتةرودلولحدنعLEDءيضت،LEDsةلاحيف
.ماظتنابضحولا فيظنتذيفنتبحصني.ليسغةرم40لكةرممكحتلاةحولعضمويضحولا فيظنتهبنمرهظي
نإفكلذعمو.ةعباسلاةلسغلانم
ً
ءدبريكذتلااذهرهظيو.ةعباتتمتارم6هلهاجتكنكم
ُ
ي،ةرملوهبنملااذهىرتامدنع
.ةيلاتلانيعبراةلسغلادنعةيناثةرمرهظيريكذتلا
."0"ةلاسرلظتدقنإف،ةيلمعرخأءاهنإدعبىتح
ريش
ُ
يامنإولمعلانعاهفقويوأةلاسغلاكلذفقوي.ةقاطلارزعرقنلابضحولا فيظنتةرودريودتتارمددعليجستكنكم
ُ
ي
.تارودلاددعإ
.يعيبطلكشبلمعتةلاسغلانإف،"0"ةلاسريفتختملاذإىتح
.ةيحصلاةياقولابلصتتضارغمظتنملكشبةوردلاليغشتبىصويكلذكهنإو
WW70T4020CX_04221C-00_AR.indd 41 2021/2/2 15:00:23
background
ةيبرعلا 42
ةنايصلا
ةنايصلا
)يكذلا صوفلا( Smart Check
عهتبثوApple StoreوأPlay Storeنم”Samsung Smart Washer“قيبطتليزنتةيادبنيعتي،ةفيظولاهذهلمعنيكمتل
ريماكلاةيصاخيذليابوملازاهج
)نوفيأويسكاج(Galaxy&iPhoneةلسلسعمصوصخلاهجوعقفاوتيل)يكذلاصحفلا(Smart Checkقيبطتريوطتىرج
.)طقفةموعدملاتيدوملا(
1 .صحفلا(Smart Checkعضوإلوخدلل.ضرعلاةشاشعيتامولعمزمررهظي،صحفلاإجاتحيرمأةلاسغلافشتكتامدنع
.ناوث3ةدملاعمليغشتلا ليجأت
واارايخ عطغضلايفرمتساوطغضا،)يكذلا
2 ..تدجونإتامولعملاداوكأضرعتويتاذلاصيخشتلاءارجإبةلاسغلاأدبت
3 .. )يكذلا صوفلا( Smart Check عطغضاوصاخلاليابوملازاهجعSamsung Smart Washerقيبطتلغش
4 .ا
ً
يكيتاموتوأقيبطتلافرعتيانهو.ةلاسغلايكذلافتاهلااريماكهجاوتثيحبةلاسغلاضرعةشاشنمبرقلابلومحملازاهجلاعض
.تامولعملادوكع
5 ..ةبسانملالولحلاعمةلكشملالوحةلصفمتامولعمرفويهنإف،حيحصلكشبتامولعملازمرعقيبطتلافرعتيامدنع
ةظحم
.ةغللاءانب)يكذلاصحفلا(Smart Checkمسافلتخيدق
.ضورعملادوكلاعفرعتلايفقفخيدققيبطتلانإف،ةشاشلاعءوضلاسكعتةلاسغلاتناكاذإ
.قيبطتلاةشاشإا
ً
يوديدوكلالخدأ،)يكذلاصحفلا(Smart Checkدوكعفرعتلايفقيبطتلاقفخأاذإ
WW70T4020CX_04221C-00_AR.indd 42 2021/2/2 15:00:23
background
43 ةيبرعلا
ةنايصلا
ئراحطلا دنع فمرصتلا
.ليسغلاجارخإلبقةناوطسايفدوجوملاهايملافرص،ءابرهكلاعاطقناةلاحيف
A
1 .ذخأمنمةلاسغلالصفامثةلاسغلاليغشتفقوأ
.ءابرهكلا
2 ..حتفنيل)A( ةافصملا ءاطغنميولعلاءزجلاعطغضا
B
3 .موطرخبحسامثءاطغلالوحعستمغرافءاعوعض
كاسماعمءاعولللصيلءىراوطلاةلاحيففيرصتلا
.)B( بحبنا محطرخب
C
4 . دنع فمرصتلا بحبنأءاملاعدوموطرخلاءاطغحتفا
.ءاعولايفقفدتي)C( ئراحطلا
5 .موطرخدعأمثموطرخلاءاطغقلغأ،غيرفتلانمءاهتناب
.حشرملاءاطغقلغأ.هعضومإفيرصتلا
ةظحم
.عقوتملانمربكأةيواحلايفءاملاةيمكنريبكءاعومدختسا
WW70T4020CX_04221C-00_AR.indd 43 2021/2/2 15:00:23
background
ةيبرعلا 44
ةنايصلا
ةنايصلا
فيظنتلا
ةلاسغلا حطس
.ةلاسغلاعهايملاعضت.ةلكآداومعيوتحييلزنمفظنماهيلعشامقةعطقمدختسا
ةيكبشلا ةافصملا
.نيماعلكةرمهايملابدادملةيكبشلاةافصملافظن
1 ..ءابرهكلالباكلصفاوةلاسغلاليغشتفقوأ
2 ..هايملاروبنصقلغأ
3 .طغ.ةلاسغلانميفلخلابناجلانمهكفوموطرخلاررح
.هنمهايملاجورخنودةلوليحللشامقةعطقبموطرخلا
4 .مامصةحتفنمةيكبشلاةافصملابحسلة
ّ
يد
َ
ر
َ
زمدختسا
.لوخدلا
5 .رمغيرجيثيحبقمعبهايملايفةيكبشلاةافصملارمغا
.نونسلايذلصوملا
6 ..لظلايفا
ً
مامتةيكبشلاةافصملاففج
7 .دعأولوخدلامامصةحتفيفةيكبشلاةافصملالاخدإدعأ
.لوخدلامامصيفءاملاموطرخلصو
8 ..هايملاروبنصحتفا
ةظحم
.”4C“أطخلاةشاشلاضرعت،دادسنلةيكبشلاةافصملاتضرعتاذإ
WW70T4020CX_04221C-00_AR.indd 44 2021/2/2 15:00:23
background
45 ةيبرعلا
ةنايصلا
اافلخملا ةافصم
.تاعاقفلاريثأتليلقتلقةدودسملاتافلخملاةافصمنإ.دادسناثودحعنملرهشلايفنيترمتافلخملاةافصمفظن
1 ..ءابرهكلالباكلصفاوةلاسغلاليغشتفقوأ
2 . فمرصتلل"مسقعجار.ةيواحلالخاديقابلاءاملافرص
."ئراحطلا دنع
3 ..حتفنيلةافصملاءاطغنميولعلاءزجلاعطغضا
4 .هايملا
ّ
فرصوراسيلاإاافلخملا ةافصم ءاطغردأ
.ةيقبتملا
5 .نأدكأت.ةمعانةاشرفمادختسابتافلخملاةافصمفظن
تافلخملاةافصمفلخةدوجوملافيرصتلاةخضمةحورم
.ةدودسمريغ
6 .هاجتةافصملاءاطغردأوتافلخملاةافصمبيكرتدعأ
.نيميلا
ةظحم
نامأءاطغةيصاخبتافلخملايفاصمضعبزيمتت
نامأءاطغحتفل.لافطاثبعنودةلوليحللةممص
ُ
م
سكعهردأولخادللءاطغلاعطغضا،تافلخملاةافصم
ةجوملاضبانلاةيكينايكمدعاس
ُ
تانهو.ةعاسلابراقعهاجتا
.ةافصملاحتفعناماءاطغيف
براقعهاجتايفهردأ،تافلخملاةافصمنامأءاطغقلغل
.يعيبطرمأاذهوكلذلخا
ً
توصكربنزلاردصي.ةعاسلا
ةظحم
.ةشاشلاع”5C“أطخلارهظي،دادسنااهبتافلخملاةافصمتناكاذإ
هيبنت
رستثودحإكلذبمازتلامدعيدؤيدق.ةافصملافيظنتدعبةافصملاءاطغقغإنمدكأت
رستثودحوأليغشتلابللخإكلذبمازتلامدعيدؤيدق.ةافصملافيظنتدعبحيحصلكشبةافصملاعضوقغإنمدكأت
WW70T4020CX_04221C-00_AR.indd 45 2021/2/2 15:00:23
background
ةيبرعلا 46
ةنايصلا
ةنايصلا
ليسغلا قحوسم جرد
A
1 .نميلخادلابناجلاع)A( رمروتلا عارذبلفسا
ً
كسمم
.
ً
يلقجردلاحتفا،جردلا
2 ..ةمعانةاشرفمادختسابيراجءاميفجردلاتانوكمفظن
3 .اياقبةلازجاجزةاشرفمادختسابجردلافيوجتفظن
ردلافيوجتيفسلكلاوفظنملا
4 .نم لئاسلا فظنملا ةريجحو رمروتلا عارذبيكرتدعأ
ردلا
5 ..هقلغللخادللقوحسملاجردبعفدا
ةظحم
.ةيلاخةناوطسانوكتامنيبفطش+نارودةرودلاذقن،فظنملانميقبتملاءزجلاةلاز
WW70T4020CX_04221C-00_AR.indd 46 2021/2/2 15:00:24
background
47 ةيبرعلا
ةنايصلا
دمجتلا ةلاح حصإ
.سويزلس0نودةرارحلاةجردتضفخنااذإةلاسغلادمجتتدق
1 ..ءابرهكلالباكلصفاوةلاسغلاليغشتفقوأ
2 ..هايملاديروتموطرخءاخرهايملاروبنصعئفادلاهايملابص
3 ..ئفادلاهايملايفهعقناوهايملاديروتموطرخلزأ
4 ..قئاقد10ةدملهكرتاوةلاسغلاةناوطسأيفئفادلاهايملابص
5 ..هايملاروبنصإهايملابدادماموطرخلصودعأ
ةظحم
.يعيبطلكشبةلاسغلالمعتىتحهعأتاوطخلاررك،يعيبطلكشبةلاسغلالمعتملاذإ
مادختسا ءحس نم ةينمزلا اارتفلا نأشب ءاجر رذولا بجم
.مادختسانودةليوطتارتفلةلاسغلاكرتبنجت
.ةلاحلاهذهيفةقاطلالباكلصفاوةلاسغلانمهايملافيرصتنيعتي
1 ..فطش+نارودرايتخةرودلا ددو
ُ
مردأ
2 ..تقؤم فاقمإ/ءدبرزعطغضاوةناوطساغرفأ
3 .رودلامامتإدنعءاملابدادماموطرخلصفاوءاملاروبنصقلغأ
4 ..ءابرهكلالباكلصفاوةلاسغلاليغشتفقوأ
5 ..ةناوطسالخرميءاوهلاعدوبابلاحتفا
WW70T4020CX_04221C-00_AR.indd 47 2021/2/2 15:00:24
background
ةيبرعلا 48
اهحصإو ءاطخا فاشكتسا
اهحصإو ءاطخا فاشكتسا
.ةشاشلاعتاميلعتلاعبتاوLEDةشاشعتامولعملاةلاسرنمققحت،امةلكشمةمثناكاذإ
.ةمدخلازكرمبلاصتاىجر
ُ
ي،ةلكشملاترمتسااذإف
صوفلاو ققوتلا طاقن
.تاحارتقانمهبامبرجويلاتلالودجلانمققحت،ةلاسغلابةلكشمتهجاواذإ
ةلكشملاعبتملا ءارجا
.لمعت  ةلاسغلا
.يئابرهكلارايتلاردصمبةلاسغلاسباقليصوتنمدكأت
.ماكحإببابلاقغإنمدكأت
.ةحوتفمهايملاردصمتايفنحنأدكأت
.ةلاسغلاليغشتءدبلطغضلابرمتساوتقؤمفاقيإ/ءدب
عرقنا
.طشنريغلافطالفق
نأنمدكأت
ةقطقطلكشعءاضوضلانمةلسلسءارجإبموقتدق،ءتمايفةلاسغلاءدبلبق
.ةعيرسفيرصتةرودءارجإوبابلالفقنمققحتلل
رئادلاعطاقطبضةداعإوأرهصملاصحفا
.ةيبرهكلاةقاطلاردصمبليصوتلاةمسنمققحت
.ةيطلوفلايفضافخنافاشتكا
.ءابرهكلاكلسليصوتمتاذإاممققحت-
.بابلابةقلاعريغسبملانأدكأت
ريغ ءاملا ةيمك نحكت امبر
تعطقنا امبر وأ ةيفاك
.هايملا اادادمإ
.
ً
ماكهايملاروبنصحتفا
.ماكحإببابلاقغإنمدكأت
.دمجتمريغءاملابةيذغتلاموطرخنأدكأت
ً
دودسموأا
ً
ينثمسيلءاملابةيذغتلاموطرخنأدكأت
.ءاملاطغضةيافكنمدكأت
.ةنخاسلاهايملاوةدرابلاهايملاروبنصليصوتةمسنمدكأت
.دادسنلتضرعتامبرفةيكبشلاةافصملافظن
يف فظنملا نم ردق يقبتم
دعب ىتح اافظنملا جرد
.ليسغلا ةرود لامتكإ
.فاكءامطغضبةلاسغلاليغشتنمدكأت
.قوحسملاجردفصتنميفليسغلاقوحسمةفاضإنمدكأت
ً
ميلس
ً
اخدإفطشلاءاطغلاخدإنمدكأت
.بسان
ُ
ملاعضوملايففظنملاديدحتصرقنأدكأت،ا
ً
يبيبحا
ً
فظنممدختستتنكاذإ
.تافظنملاجردفظنوفطشلاءاطغلزأ
WW70T4020CX_04221C-00_AR.indd 48 2021/2/2 15:00:24
background
49 ةيبرعلا
اهحصإو ءاطخا فاشكتسا
ةلكشملاعبتملا ءارجا
وأ ةلاسغلا يف ةفينع اازازتها
.ةيلاع ءاضحض
.ةقلزريغةبلصةيضرأعاهنأوةلاسغلاتيبثتىوتسمءاوتسانمدكأت
.ةلاسغلاعافتراطبضلءاوتسالجرأبنعتسا،ةيوتسمةيضرانكتملاذإ
.نحشلاريماسمةلازإنمدكأت
.رخآءيشيةلاسغلاةسمممدعنمدكأت
.ةلاسغلايفةدوجوملاسبملانزوعيزوتنمدكأت
.يداعلاليغشتلاءانثأيفءاضوضلانمردقروتوملاردص
ُ
ينأنكم
ُ
ي
ءانثأيفءاضوضلانمردقيلوارسلاءادرلاوأنداعملابةنيزملاسبملاببستدقكلذك
.يعيبطرمأاذهو.اهلسغ
هذهلزأ،ليسغلامامتإدعب.ا
ً
تاوصأا
ً
يندعملاتمعلالثمةيندعملاضارغاببس
ُ
تكلذك
.حشرملاةبلعوأةيواحلانمةيندعملاضارغا
،زنيجوأمامحسنر
ُ
بلثم،سبملانمةدحاوةعطقليسغةلاحيفو.سبملاعيزوتدعأ
.ةشاشلاعيف”Ub“هيبنتلاةلاسررهظتو،ةيضرميئاهنلافيشنتلاةجيتننوكتدق
.نارودلا وأ /و ،فمرصتلا مدع
،فيرصتللةقاعإيأتدجواذإ.فرصلاماظندادتماعفرصلاموطرخةماقتسانمدكأت
.ةنايصلاةمدخبلصتاف
.ةدودسمريغءاملاموطرخبةلصتملاةيكبشلاةافصملانأنمدكأت
.تقؤم فاقمإ/ءدب رزلاعطغضاوبابلاقلغأ
.كنامأوكتمسلكلذوبابلاقلغلبقرودتوأةلاسغلالمعتنل
ً
دودسموأا
ً
دمجمسيلءاملابةيذغتلاموطرخنأدكأت
ً
دودسمسيلفرصلاماظننأوفيرصتلاماظنبلصتمفرصلاموطرخنأدكأت
نعا
ً
تقؤمفقوتتةلاسغلانإفةيفاكلاةوقلابةلاسغللةيفاكلاهايملاةيمكرفوتتملاذإ
اهنإفةيفاكلاةوقلابهايملانمةيفاكلاةيمكلاةلاسغللرفوتتنأامو.فيفجتلاوأفيرصتلا
.يعيبطلكشبلمعلادواعت
.ليصوتلاعونعءانبفيرصتلاموطرخعضومةمسنمدكأت
.دادسنلتضرعتامبرفتافلخملاةافصمفظن
.حتفم  ةلاسغلا باب
.ةلاسغلالمعفاقيتقؤم فاقمإ/ءدبرزعطغضا
.بابلالفقررحتييتحةليلقناوثرماقرغتسيدق
.يبرهكلارايتلالصفوألمعلانعةلاسغلافقوتعقئاقد3رمتىتحبابلاحتفنكمي
راخللةلاسغلاةيواحلايفءاملالكفيرصتنمدكأت
بابلاحتفامثةيواحلايفهايملافرص.ةيواحلايفهايمدوجوةلاحيفبابلاحتفنكم
ُ
ي
ً
يودي
نمءاملافيرصتمامتإدعببابلالفقحابصمأفطني.أفط
ُ
مبابلالفقحابصمنأدكأت
.ةلاسغلا
يقابو ةلاسغ
ُ
لا ةدامز
.اافظنملا
.تافظنملانماهبىصوملاعاونامادختسانمدكأت
.هتو
ْ
غ
َ
روأنوباصلاة
َ
لاس
ُ
غنوكتةدايزعنملةيلاعفلاةيلاعةفظنمةداممدختسا
فيفخليسغلاوأةريغصلاليسغلاتايمكوأرسيلاءامللةفظنملاةداملاةيمكضفخ
.ةطيسبوأةريغصخاسوأبخاستا
.HEريغةفظنمةداممادختسابىصوي
WW70T4020CX_04221C-00_AR.indd 49 2021/2/2 15:00:24
background
ةيبرعلا 50
اهحصإو ءاطخا فاشكتسا
اهحصإو ءاطخا فاشكتسا
ةلكشملاعبتملا ءارجا
ةيفاضإ ةيمك عضو نكم
ُ
م 
.اافظنملا نم
.حومسملادحلازواجتتةشمقامعنموفظنملانمةيقبتملاةيمكلانأدكأت
.فقحتم
.لماعيبرهكذفنميفءابرهكلالباكعض
رئادلاعطاقطبضةداعإوأرهصملاصحفا
.ةلاسغلالمعءدبلتقؤم فاقمإ/ءدبرزعطغضاوبابلاقلغأ
.كنامأوكتمسلكلذوبابلاقلغلبقرودتوأةلاسغلالمعتنل
ةقطقطلكشعءاضوضلانمةلسلسءارجإبموقتدق،ءتمايفةلاسغلاءدبلبق
.ةعيرسفيرصتةرودءارجإوبابلالفقنمققحتلل
ةلاسغلالصاوتامبروةطيسبةرتفرظتنا.ةرودلايفعقنةرتفوأتقؤمفاقيإدجويدق
.ليلقدعبلمعلا
.هايملاريبانصيفةدوجوملادادماموطرخيفةيكبشلاةافصملادادسنامدعنمدكأت
ً
يرودةيكبشلاةافصملافظن
نعا
ً
تقؤمفقوتتةلاسغلانإفةيفاكلاةوقلابةلاسغللةيفاكلاهايملاةيمكرفوتتملاذإ
اهنإفةيفاكلاةوقلابهايملانمةيفاكلاةيمكلاةلاسغللرفوتتنأامو.فيفجتلاوأفيرصتلا
.يعيبطلكشبلمعلادواعت
ريغ ةرارح ةجرد يذ ءامب ءلملا
.ةبسانم
.
ً
ماكا
ً
حتفنيروبنصلاحتفا
.حيحصةرارحلاةجردديدحتنأنمدكأت
.ءاملاطوطخعضوبمق.ةمئملاتايفنحلابةلصتمميطارخلانأنمدكأت
يفسويزلس49ةجردعنخاسلاءامللىندادحلاعءاملاناخسطبضنمدكأت
.ضيوعتلالدعموئفادلاءاملاةعسصحفاكلذك.روبنصلا
.ةدودسمةيكبشلاةافصملانوكتدق.ةيكبشلاةافصملافظنوميطارخلالصفإ
مكحتلاةزيممايقءانثأءاملاةرارحةجردلرييغتثدحيدقف،ءاملابكتلاسغءلممتيامدنع
.يعيبطرمأاذهو.مداقلاءاملاةرارحةجردنمققحتلاب
ً
ايكيتاموتوأةرارحلاةجردب
قلطنيطقفدرابلاءاملاوأ/وطقفنخاسلاءاملانأءاملابكتلاسغءلمءانثأيفظحتدق
رابلاوأنخاسلاءاملاعليسغلاةرارحتاجردرايتخادنععيزوتلاةدحوربع
كتلاسغددحتامنيبةرارحلاةجردبيكيتاموتوامكحتلاةيصاخلةيعيبطلاةفيظولايههذه
.ءاملاةرارحةجرد
يف
ً
لبم ا
ً
بطر لظم ليسغلا
.ليسغلا ةرود ةماهن
.ةيفاضاوأةيلاعلافيفجتلاةعرسمدختسا
.هتو
ْ
غ
َ
روأنوباصلاة
َ
لاس
ُ
غنوكتةدايزعنملةيلاعفلاةيلاعةفظنمةداممدختسا
وأدحاوضرغ(ةريغصلاليسغلاةيمكدق.
ً
ادجةريغص)سبملاةيمك(ليسغلاةيمك
.
ً
ماكا
ً
فيفجتفيفجتلامدعونزاوتلامدعإيدؤت)نيضرغ
ً
دودسموأا
ً
دمجمسيلءاملاديروتموطرخنأدكأت
WW70T4020CX_04221C-00_AR.indd 50 2021/2/2 15:00:24
background
51 ةيبرعلا
اهحصإو ءاطخا فاشكتسا
ةلكشملاعبتملا ءارجا
.ءاملا برست
.ماكحإببابلاقغإنمدكأت
.طبرلاةمكحمموطرخلاتصولكنأنمدكأت
.فيرصتلاماظنيفهتيبثتوةحيحصةقيرطبفيرصتلاموطرخفرطلاخدإنمدكأت
.دئازلاليمحتلابنجت
.هتو
ْ
غ
َ
روأنوباصلاة
َ
لاس
ُ
غنوكتةدايزعنملةيلاعفلاةيلاعةفظنمةداممدختسا
.فيرصتلاموطرخنمققحت
.ةيضراععوضومريغفيرصتلاموطرخفرطنأدكأت-
ً
دودسموأا
ً
دمجمسيلفيرصتلاموطرخنأدكأت-
.ةلاسغلا نع ردصت حئاور ةمث
.ةهيركحئاورببس
ُ
ياموهوتافيوجتلايفةدئازلانوباصلا
ُ
ة
َ
لاس
ُ
غعمجت
.اهميقعتلةفظنملاليسغلاتارودعةلاسغلايرودلاليغشتلا
.)ططخ
ُ
ملارظنا(بابلاةبلجفظن
.ليسغلاةرودمامتإدعبةلاسغللةيلخادلاءازجافظن
ااعاقف ةمؤر نكم
ُ
م 
معدت يتلا امدحملا(
.)طقف ااعاقفلا
ً
دجةريثكةيواحلايفضارغاتناكاذإتاعاقفلاةيؤركنكم
ُ
يدق
.تاعاقفلانوكتحيتتدقخاستاةديدشسبملا
.ءمعلاةمدخزكرمبلصتا،ةلكشملارارمتساةلاحيف
WW70T4020CX_04221C-00_AR.indd 51 2021/2/2 15:00:24
background
ةيبرعلا 52
اهحصإو ءاطخا فاشكتسا
اهحصإو ءاطخا فاشكتسا
اامحلعملا زحمر
.تاحارتقانمهبامبرجويلاتلالودجلانمققحت.ضرعلاةحولعتامولعملازومردحأرهظيدق،لطعللةلاسغلاضرعتةلاحيف
دحكلاعبتملا ءارجا
4C
.ءاملابةلاسغلاةيذغتيرجي
.ةحوتفمهايملاردصمتايفنحنأدكأت
.ةدودسمريغءاملاميطارخنأدكأت
.ةدمجمريغهايملاريبانصنأدكأت
.فاكءامطغضبةلاسغلاليغشتنمدكأت
.ةنخاسلاهايملاوةدرابلاهايملاروبنصليصوتةمسنمدكأت
.دادسنلتضرعتامبرفةيكبشلاةافصملافظن
يرجيس،هسفنتقولايف.قئاقد3ةدملهايملاةلاسغلافرص
ُ
ت،"4C"ةلاسررهظتامدنع
.ةقاطلارزليطعت
4C2
رابلاءاملاروبنصبدرابلاءاملابةيذغتلاموطرخليصوتةمسنمدكأت
ضرعتيدقليسغلانإفنخاسلاءاملاروبنصبدرابلاءاملابةيذغتلاموطرخليصوتىرجاذإ
.تارودلاضعبيفخسفتلل
5C
.ءاملافرصيرجي
ً
دودسموأا
ً
دمجمسيلءاملابةيذغتلاموطرخنأدكأت
.ليصوتلاعونعءانبفيرصتلاموطرخعضومةمسنمدكأت
.دادسنلتضرعتامبرفتافلخملاةافصمفظن
رصلاماظندادتماعفرصلاموطرخةماقتسانمدكأت
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
dC
.حوتفمبابلانوكيامنيبةلاسغلاليغشت
.ماكحإببابلاقغإنمدكأت
.بابلابةقلاعريغسبملانأدكأت
OC
.ءاملاةيمكةدايز
.فيفجتلادعبليغشتلادعأ
.يلحملاSamsungةمدخزكرمبلصتا،ةشاشلاعا
ً
رهاظداوكادحألظاذإ
LC، LC1
.فيرصتلاموطرخنمققحت
.ةيضراععوضومريغفيرصتلاموطرخفرطنأدكأت
ً
دودسموأا
ً
دمجمسيلفيرصتلاموطرخنأدكأت
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
3C
.روتوملالمعةمسنمققحت
.ليسغلاةرودءدبةداعإلواح
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
WW70T4020CX_04221C-00_AR.indd 52 2021/2/2 15:00:24
background
53 ةيبرعلا
اهحصإو ءاطخا فاشكتسا
دحكلاعبتملا ءارجا
UC
.)ةيطلوفلاةدايزأطخ(ينورتكلامكحتلاصحفلةجاحةمث
.كساةريفضوPCBنمققحت
.ةيبرهكلاةقاطلاردصمبليصوتلاةمسنمققحت
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
.ةيطلوفلايفضافخنافاشتكا
.ةقاطلالباكبيكرتنمققحت
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
HC
رارحلاةجردعافترانمققحتلا
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
1C
.ةحيحصةقيرطبلمعيءاملاىوتسمرعشتسم
رخأةرمةرودلاءدبةداعإمثةلاسغلاليغشتفاقيإبرج
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
لعفمريغةقاطلارزنوكيو
.قئاقد3ةدملهايملاةلاسغلافرص
ُ
ت،"4C"ةلاسررهظتامدنع
.ةدملاهذهلاوط
8C
.ةويوص ةقمرطب لمعم  MEMS رعشتسم
.ليسغلاةرودليغشتدعأو،ةلاسغلاليغشتفقوأ
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
AC
.ةيعرفلاوةيسيئرلاPBAنيبتيصوتلاةمسنمققحت
.ليسغلاةرودليغشتدعأو،ةلاسغلاليغشتفقوأ
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
AC6
.ةسكاعلاو ةيسيئرلا PBA نيب ايصحتلا ةمس نم ققوت
.ةلاحلاعادامتعايداعلاليغشتلاإا
ً
يكيتاموتوألمعلاةلاسغلادواعتدق
.ليسغلاةرودليغشتدعأو،ةلاسغلاليغشتفقوأ
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
DC1
.مئم لكشب لمعم  يسيئرلا بابلا حتف/ لفق
.ليسغلاةرودليغشتدعأو،ةلاسغلاليغشتفقوأ
.ءمعلاةمدخزكرمبلصتا،ةحوللاعا
ً
رهاظتامولعملادوكلظاذإ
0
.ةرهاظ"0"ةلاسرلظتو،ريودتلاتايلمعرخأدعبلمعلانعا
ً
يئاقلتفقوتت
ىصويكلذعمو.ضحولا فيظنتةرودليغشتنوديعيبطلكشبلمعتةلاسغلا
.ةيحصلاةياقولابلصتتضارغةوردلاليغشتب
.يلحملاSamsungةمدخزكرمبلصتا،ةشاشلاعروهظلابرمتسيداوكادحأنأتدجواذإ
WW70T4020CX_04221C-00_AR.indd 53 2021/2/2 15:00:24
background
ةيبرعلا 54
اافصاحملا
اافصاحملا
ةشمقاب ةمانعلا لودج
يكوفيفجتوضييبتوليسغ:يلاتلاوحنلاعزومرةعبرأةيانعلاتاقاطبنمضتت.سبملابةيانعلاتاميلعتةيلاتلازومرلاحضوت
تاميلعتعبتا.ةدروتسملاوةيلحملاسبمللةعنصملاتاكرشلانيبقسانتلازومرلاهذهمادختسانمضي.)رمامزلاذإفاجفيظنتو(
.ليسغلالكاشمليلقتوسبملارمعةدايزلةيانعلاةقاطب
ةمواقمداوميكلارظحي
ةقيقرسبم
يأمادختسابفاجلافيظنتلامادختسانكمي
ةبيذمداوم
م˚95دنعلسغلانكميفاجفيظنت
م˚60دنعلسغلانكمي
ففخملادوقولاوأديرولكوربلابفاجلافيظنتلا
طقفR113وأيقنلالوحكلاوأ
م˚40دنعلسغلانكمي
لوحكلاوأتارئاطلادوقوبفاجلافيظنتلا
طقفR113وأيقنلا
م˚30دنعلسغلانكميفاجلافيظنتلامادختسارظحي
طقفيوديلسغةدورفميهوففجت
طقففاجفيظنتفجتلاهرشننكمي
درابلاءاملاعمضييبتةداممادختسانكميةلامحعةقلعميهوسبملافيفجت
ضييبتةداممادختسارظحيةيداعةرارح،ريودتلابفيفجت
ىصقأدحبم˚200دنعيكلانكميةفيفخةرارح،ريودتلابفيفجت
ىصقأدحبم˚150دنعيكلانكميريودتلاباهفيفجترظحي
ىصقأدحبم˚100دنعيكلانكمي
WW70T4020CX_04221C-00_AR.indd 54 2021/2/2 15:00:27
background
55 ةيبرعلا
اافصاحملا
ةئيبلا ةمامح
صلختلابةصاخلاةيلحملانيناوقلاةاعارمىجر
ُ
ي،زاهجلااذهنمصلختلاتررقاذإ.ريودتلاةداعةلباقداومنمعونصمزاهجلااذه
راغصلالافطاوأتاناويحلاضرعتعنملبابلالزأ.ةقاطردصمبزاهجلاليصوتنكميرذعتيىتحرايتلاكلسعطقا.تايافنلانم
.زاهجلالخادسابتحل
.ليسغلاقوحسملةعنصملاةكرشلاتاداشرإيفةنيبملاةيمكلانمرثكأليسغقوحسمعضت
.طقفةجاحلادنعليسغلاةرودلبقضييبتلاداوموعقبلاةلازإداوممدختسا
.)مدختسملاجمانربلل
ً
اقفوةيمكلافلتخت(ةلماكنازوأبليسغلاءارجإلخنمءابرهكلاوءاملارفو
رايغلا عطق نامض
رخأميدقتنملقاعتاونسرشعةدملنييئاهنلانيمدختسملاونيفرتحملاحصايصصختملةيلاتلارايغلاعطقرفاوتنمضن
.قاوسلليدوملانمةدحو
.فظنملاتاعزومةيكيتسبلافارطاو،بابلالفقةعومجمو،ىرخابلجلاو،بلجلاو،بابلاتصفمو،بابلا
WW70T4020CX_04221C-00_AR.indd 55 2021/2/2 15:00:27
background
ةيبرعلا 56
اافصاحملا
اافصاحملا
ةينفلا اافصاحملا ةمئاق
.)A-Z(وأ)9-0(نماهتميقفلتختنأنكم
ُ
يوةفلتخمتيدوم"*"ةمعينعت
A
B
C
D
E
عحنلاةيمامأ ةئبعت ةوتف ااذ كيتامحتأ ةلاسغ
زارطلامسا
WW8*T4*4***
WW8*T4*2***
WW7*T4*4***
WW7*T4*2***
داعبا
رعلا(A
مم600
)عافترا(B
مم850
)قمعلا(C
مم550
D
مم630
E
مم1072
ءاملاطغضلاكسابوليك800~لاكسابوليك50
يفاصلانزولامجك65مجك65
فيشنتلاوليسغلاةعسمجك8.0مجك7.0
ةقاطلاكهتسانيخستلاولسغلا
تلوف220طاو1900
تلوف240طاو2300
فيشنتلاتارود
WW8*T4*4***
WW7*T4*4***
WW8*T4*2***
WW7*T4*2***
ةقيقدلايفةرود1400ةقيقدلايفةرود1200
ةظحم
.لضفأةدوجقيقحتفدهبكلذوراعشإنودرييغتللةضرعتافصاوملاوميمصتلانإ
WW70T4020CX_04221C-00_AR.indd 56 2021/2/2 15:00:28
background
WW70T4020CX_04221C-00_AR.indd 57 2021/2/2 15:00:28
background
WW70T4020CX_04221C-00_AR.indd 58 2021/2/2 15:00:28
background
WW70T4020CX_04221C-00_AR.indd 59 2021/2/2 15:00:28
background
DC68-04221C-00
؟ااقيلعت وأ ةلئسأ كمدل له
دلبلاع لصتاع تنرتنا ع انعقحم رز وأ
NIGERIA08007267864www.samsung.com/africa_en/support
WW70T4020CX_04221C-00_AR.indd 60 2021/2/2 15:00:28

Specifications

Samsung WW80T4020CX/NQ Questions and Answers
