PUCRC50
Smart Vacuum Cleaner
Automatic Robot Cleaning Vacuum
www.PyleUSA.com
2
Please read this User Manual carefully before using
and keep it properly for future use.
• About Your PUCRC50 Robot Vacuum Cleaner
1. TOP VIEW
2. BOTTOM VIEW
3. WATER TANK (OPTIONAL MODELS)
Start/Stop
On/O
Bumper
Drive wheel
Dust box cover
Side Brush
Suction Port
Anti-falling Sensor
Direction
Wheel
Side Brush
Battery Box
Mounting Pole
Cleaning Cloth
Water Tank Cap
Water Tank
Water Leaking Area
Anti-falling Sensors
Remove side brush screw Take o side brush
www.PyleUSA.com
3
• Maintenance
1. Clean or replace the side brush
The side brushes can sometimes be deformed during transportation or
when the product is used under particular conditions. If this happens, it is
possible to return to the original shape by putting bristles in hot water.
2. Clean Anti-falling sensors
Wipe three anti-falling sensors with a clean,dry cloth.
3. Clean the Dust Bin and Filter
www.PyleUSA.com
4
2
1
3
Mounting
Poles
1. Remove and empty the dust bin after each use
2. Clean the dust bin
A. Push out the cover and clean lter B. Clean or replace lter
3. Remove or Install Battery
•
Using the PUCRC50 Robot Vacuum Cleaner
1. Water Tank Use and Mopping (Optional Model)
For wet mopping, please mount the water tank and mopping cloth before
use. When it’s not in use, please take o water tank and mopping cloth.
Pour out left water and dry it for next use.
1. Attach Cleaning Cloth to water tank.
2. Fill clean water into water tank.
3. Attach the water tank to bottom of
the robot, x the mounting pole
properly.
www.PyleUSA.com
5
2. General Dry Vacuuming & Sweeping
Full Cleaning Mode: Press one (1 time) ON/OFF Switch button to start, it
cleans for 80-100 minutes and stops automatically when battery is low;
Single room Cleaning Mode: Press twice (2 times) ON/OFF Switch button
to start, it cleans 45 minutes and stop automatically.
•
Frequent Asked Questions
Q: Why does the Side Brush occasionally spin backwards?
A: When caught on items such as carpet tassels or wires, the Side Brush may
spin slowly or briey spin backwards to free itself. This may also occur on
thick or high-pile carpets. If this behavior should occur on hard oor
surfaces or when on tassels or wires are presented, the Side Brush should
be cleaned. Using a small screwdriver, to move the screw from the center
of the Side Brush rst, then remove the Side Brush and clean any hair or
debris wrapped around the shaft thoroughly. Re-install the Side Brush
properly after cleaning it.
Q: Why does the
Robot Vacuum Cleaner stops occasionally?
A: It might be stopped because of low power, or stuck by obstacles, or by
carpet with long rugs, or moves onto carpet when cleaning with water
tank and mop attached.
PUCRC50 is not supposed to clean carpet with
long rugs, or when with water tank attached. Please be sure that there are
no cables, clothes, curtain belts, or any other materials scattered in it’s
cleaning area, to avoid tangling or trapping your robot during cleaning.
Q: Why doesn’t
the Robot Vacuum Cleaner slows down as it
approaches certain obstacles?
A: The
PUCRC50 uses its light Touch Bumper technology to identify walls
and other obstacles, allowing it to slow down and gently touch the
obstacles with its bumper before changing direction. It may be less
eective at sensing and slowing down from extremly dark or black
surfaces, or for objects that are less than two inches wide.
www.PyleUSA.com
6
• Cleans Multiple Floors
• The Robot Vacuum Cleaner works on wood, carpet, tile, vinyl, and
linoleum, and adjusts automatically to dierent oor types. It mops hard
oor with water tank, but doesn’t mop carpet with long rugs.
•
The Robot Vacuum Cleaner automatically senses stairs and other clis.
It might stall when confronting rounded edges and might slide over
particularly slippery surfaces.
•
Anti-Tangle System
The Robot Vacuum Cleaner won’t get stuck on cords, carpet fringe or
tassels. When it detects that it had picked up a cord or tassel, it will
automatically stop its main brushes or side brush and try to escape.
It may make a clicking noise when anti-tangle is activated.
•
Important Safety Instructions
• This appliance should only be used for domestic cleaning, as described in
this user guide.
•
Always switch o and remove the charger from the socket before
cleaning the appliance or any maintenance task.
• This Appliance can be used by children aged from 16 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
•
If the power cord is damaged, stop using the appliance immediately.
To avoid a safety hazard, an authorized service engineer must replace the
power cord. If the area to be cleaned containers a balcony, a physical
barrier should be used to prevent access to the balcony and ensure safe
operation.
www.PyleUSA.com
7
• Small children and pets must be supervised while the cleaner is cleaning.
•
Use only the original charger supplied with the appliance.
Check that your supply voltage is the same as that stated on the charger.
• Leaks from battery cells can occure under extreme usage or temperature
conditions. If the liquid gets on skin, wash quickly with water. If the liquid
gets into eyes, ush them immediately with clean water for a minimium
10 minutes. See medical attention.
•
It is normal for the charger to become warm to the touch when charging.
Don’t pick up hard or sharp objects, matches, hot ashes, cigarette ends or
other similar items.
•
Don’t spray with or pick up ammable liquids, cleaning uids, aerosols or
their vapours.
•
Don’t continue to user your appliance or charger if it appears faulty.
•
To ensure the continued safe and ecient operation of this appliance we
recommend that any servicing or repairs are only carried out by an
authorized service engineers.
•
Don’t replace the robot batteries with non-rechargeable batteries.
•
End of life battery removal. If the appliance is to be disposed, the batteries
must rstly be removed. It must be disconnected from the supply mains
when removing the battery.
www.PyleUSA.com
8
• TROUBLESHOOTING
• Remarks:
Please be aware of that the robot is not supposed to clean on carpet
when the water tank and mop are attached;
Please empty and clean the dust bin in time, dirty dust bin will
reduce the cleaning power and eciency.
Problems
The robot cleaner doesn’t work
Cleaning power is weak
The robot cleaner is very noisy while
leaning
The robot cleaner stops working/
cleans intermittently
The robot cleaner fails to detect stairs
The robot cleaner is trapped
Causes and Solutions
Check that the robot cleaner is switched on.
Check the dust container, lter and motor are
clean or not.
Check if the robot cleaner needs to be charged.
Turn power o and:
Empty dust container.
Check and clean the lter and motor.
Check and clean the oor brushes.
Check and clean the sensors.
Check and clean the drive wheels..
Clean the dust container and lter.
Check the brushes and drive wheels for dirt and
debris.
Check the cleaning mode setting.
No Power, charge the robot and use it again.
Check and clean the sensors.
The robot cleaner will attempt to free itself but in
some cases assist the robot cleaner manually.
www.PyleUSA.com
9
PUCRC50
Smart Vacuum Cleaner - Automatic Robot Cleaning Vacuum
Features:
•
Keep it Clean: Sweep, Dust & Vacuum
•
Versatile & Convenient Floor Clean Ability
•
Smart, Self-Programmed Cleaning Path Navigation
•
Low-Prole Design Slides Underneath Furniture
•
Anti-Fall Stair Sensors & Protective Bumper Housing
•
Obstacle Detection Cleans Around Household Objects
•
Works on Hardwood, Linoleum, Tile, Low/Hard Carpet Floors
•
Convenient Dust Collection Bin Opens for Quick Disposal
•
Automatic 'Bag-less' Design for Easy Cleaning
•
One Button Operation & Auto-Start Activation
•
(3) Cleaning Pattern Modes: Auto/Random, Spiral, Edge
•
Built-in Rechargeable Battery 2200mAh
•
Dual Spinning Side Brush Lifts Debris
•
Includes Charging / Power Adapter
•
Perfect for the Home or Oce
What’s in the Box:
•
Smart Robot Vacuum
•
Water Tank
•
Detachable Brushes
•
Mopping Cloth
•
Washable Dust Filter
•
Rechargeable Battery
•
Charging / Power Adapter
•
Manual
Technical Specs:
• Dust Bin Capacity: 0.2L
•
Battery Type: 2200mAh
•
Average Charge Time: 4 Hours
•
Vacuum Operation Run-Time: Up to 100 Minutes
•
Power: 100-240V AC 50/60Hz
•
Sold as: 1
