Washer-Dryer

User Manual

GD7510644UW

2820529778/ EN/ / 22/11/2021 14:14

EN / 2

Table of Contents

1 Safety Instructions........................ 4

1.1 Intended Use ............................... 4

1.2 Safety of Children, Vulnerable

Persons and Pets ........................

1.3 Electrical Safety........................... 5

1.4 Handling Safety ........................... 6

1.5 Installation Safety ........................ 6

1.6 Operational Safety....................... 8

1.7 Drying Safety ............................... 9

1.8 Maintenance and Cleaning

Safety ..........................................

2 Important Instructions for Envir-

onment ...........................................

2.1 Compliance with WEEE Directive 12

2.2 Package Information.................... 12

3 Technical Speciﬁcations .............. 13

4 Installation ..................................... 14

4.1 Appropriate Installation Location . 14

4.2 Installation of Bottom Panel

Cover ...........................................

4.3 Removing Transportation Safety

Bolts.............................................

4.4 Connecting to Water Supply........ 15

4.5 Connecting the Drain Hose to the

Drain ............................................

4.6 Adjusting the Stands.................... 16

4.7 Electrical Connection................... 16

4.8 Handling the Product ................... 17

5 Preparation .................................... 17

5.1 Sorting the Laundry ..................... 17

5.2 Preparing Laundry for Washing... 18

5.3 Tips for Energy and Water Sav-

ing................................................

5.4 Start Up ....................................... 18

5.5 Loading the Laundry.................... 19

5.6 Correct Load Capacity................. 19

5.7 Using Detergent and Softener ..... 19

5.8 Tips for Efficient Washing............ 21

5.9 Tips for Efficient Drying ............... 23

5.10 Displayed Programme Duration .. 23

6 Operating the Product .................. 24

6.1 Control Panel............................... 24

6.2 Symbols on the Display ............... 25

6.3 Preparing the Machine ................ 25

6.4 Selection of Washing Program .... 26

6.5 Washing Programmes .................. 26

6.6 Temperature Selection.................. 28

6.7 Spin Speed Selection.................... 28

6.8 Drying Programmes ...................... 29

6.9 Washing and Drying Pro-

grammes .......................................

6.10 Programme and Consumption

Table .............................................

6.11 Auxiliary Function Selection.......... 33

6.11.1 Auxiliary Functions .................... 34

6.11.2 Functions/Programmes Selec-

ted by Pressing the Function

Keys for 3 Seconds ...................

6.12 Drying Steps ................................. 36

6.13 End Time....................................... 36

6.14 Starting the Programme................ 37

6.15 Loading Door Lock........................ 37

6.16 Changing the Selections After

Programme has Started................

6.17 Cancelling the Programme ........... 39

6.18 End of Programme........................ 39

6.19 Standby Mode............................... 39

6.20 HomeWhiz Feature and Remote

Control Function............................

6.20.1 HomeWhiz Setup ...................... 40

6.20.2 Setting up a Washing Machine

Connected to Someone Else's

Account .....................................

6.20.3 Remote Control Function and

Using It ......................................

6.20.4 Troubleshooting......................... 42

7 Maintenance and Cleaning ............ 43

7.1 Cleaning the Detergent Drawer .... 43

7.2 Cleaning the Loading Door and

the Drum .......................................

7.3 Cleaning the Body and Control

Panel.............................................

7.4 Cleaning the Water Intake Filters.. 43

7.5 Draining Remaining Water and

Cleaning the Pump Filter ..............

8 Troubleshooting ............................. 45

9 DISCLAIMER / WARNING............... 50

10 GRUNDIG UK AND IRELAND

STANDARD MANUFACTURER

GUARANTEE TERMS AND CON-

DITIONS ...........................................

EN / 3

Please read this user manual first!

Dear Customer,

Thank you for choosing Grundig product. We hope that you get the best results from your

product which has been manufactured with high quality and state-of-the-art technology.

Therefore, please read this entire user manual and all other accompanying documents

carefully before using the product.

Follow all warnings and information in the user manual. Thus, you protect yourself and

your product against possible dangers.

Keep the user manual. If you hand over the product to someone else, provide the user

manual as well. Warranty terms, usage and troubleshooting methods of your product are in

user guide.

Symbols and Definitions

The following symbols are used in the user guide:

Danger that could result in death or injury.

Important information or useful hints about usage.

Read the user manual.

Recyclable materials.

Hot surface warning.

WARNING Danger that may result in property damage to the product or its environment.

EN / 4

1 Safety Instructions

This section includes the safety

instructions necessary to pre-

vent the risk of personal injury

or material damage.

Our company shall not be held

responsible for damages that

may occur if these instructions

are not observed.

• Installation and repair opera-

tions shall always be per-

formed by Authorised Ser-

vice.

• Use original spare parts and

accessories only.

• Do not repair or replace any

component of the product un-

less it is clearly specified in

the operation manual.

• Do not modify the product.

1.1 Intended Use

• This product has been de-

signed for domestic use. It is

not for commercial purposes

or it should not be used out of

its intended use.

• Use only for washing and dry-

ing textile products that are

marked accordingly.

• The manufacturer assumes

no responsibility for any dam-

age due to misuse or mis-

handling.

• This appliance is intended to

be used in household and

similar applications. For ex-

ample;

– Personnel kitchens of

stores, offices and other

work environments;

– Ranches,

– By customers of hotels,

motels and other accom-

modation facilities

– Bed and breakfasts, hostel-

like environments

– Common areas of apart-

ment blocks or laundries.

1.2 Safety of Children,

Vulnerable Persons

and Pets

• This product may be used by

children aged 8 years and

older and persons with under-

developed physical, sensory

or mental capabilities or lack

of experience and knowledge

if they have been given su-

pervision or instruction con-

cerning use of the appliance

in a the product safe way and

the hazards involved.

• Children under the age of 3

should be kept away unless

continuously supervised.

EN / 5

• Electrical products are dan-

gerous for children and pets.

Children or pets should not

play with, climb on top or in-

side the product. Check in-

side the product before use.

• Use child lock to prevent chil-

dren from intervening with the

product.

• Do not forget to close the

loading door when leaving

the room where the product is

located. Children and pets

may get locked inside and

drown.

• Children should not perform

cleaning and user mainten-

ance works without an adult’s

supervision.

• Keep the packaging materials

away from children. Risk of

injury and suffocation.

• Keep all detergents and ad-

ditives used for the product

away from children’s reach.

• Cut the power cable and

break and deactivate the

locking mechanism of the

loading door before disposing

of the product for children’s

safety.

1.3 Electrical Safety

• Product should be unplugged

during installation, mainten-

ance, cleaning and repair

procedures.

• Damaged power cables

should be replaced by the au-

thorised service in order to

prevent possible danger.

• The product should not be

fed via an external switching

device such as a timer or

connected to a circuit that is

regularly switched on and off

by a device.

• Do not tuck the power cord

under the product or to the

rear of the product. Do not

put heavy items on the power

cord. Do not over bend, crush

and touch the power cable to

sources of heat.

• Do not use an extension

cord, multi-plug or adaptor to

operate your product.

• The plug shall be easily ac-

cessible. If this is not pos-

sible, a mechanism that

meets the electrical legisla-

tion and that disconnects all

terminals from the mains

(fuse, switch, main switch,

etc.) shall be available on the

electrical installation.

• Do not touch the plug with

wet hands.

• When unplugging the appli-

ance, don't hold the power

cord, but the plug.

• Make sure the plug is not

wet, dirty or dusty.

EN / 6

1.4 Handling Safety

• Unplug the product before

moving, remove the water

outlet and water main con-

nections. Drain any water left

inside the product.

• This product is heavy, do not

handle it by yourself. Do not

hold extruding parts such as

the laundry loading door to lift

and move the product. The

upper tray should be tightly

fixed for moving.

• Your product is heavy; it

should be carried carefully by

two people if a staircase is in-

volved. It may cause injuries

if your product falls on you.

Do not hit and drop the

product while carrying.

• Carry the product in an up-

right position.

• Make sure that the hoses as

well as the power cable are

not folded, pinched or

crushed after the product is

fitted into its place after in-

stallation or cleaning proced-

ures.

1.5 Installation Safety

• Check the information on the

manual and installation in-

structions to prepare the

product for installation and

make sure the electrical

mains, clean water mains and

water outlet are suitable. If

not, call a qualified electrician

and plumber to have them

make the necessary arrange-

ments. These operations are

the responsibility of the cus-

tomer.

• Check for any damage on the

product before installing it. Do

not have the product installed

if it is damaged.

• Injuries may occur if hands

are put into uncovered slots.

Close the holes of the trans-

portation safety bolts with

plastic plugs.

• Do not install or leave the

product at locations where it

may be exposed to external

environment conditions.

• Do not install the product at

locations where the temperat-

ure drops below 0 ºC.

• Do not place the product on a

carpet or similar surface. It

would create fire hazard

since it cannot receive air

from underneath.

• Place the product on a level

and hard surface and balance

with the adjustable legs.

• Connect the product to a

grounding plug protected by a

fuse suitable to the current

EN / 7

values on the type label.

Make sure the grounding is

carried out by an expert elec-

trician. Do not use the

product without suitable

grounding to local/national

regulations.

• Plug the product in a socket

with voltage and frequency

values suitable to those indic-

ated on the type label.

• Do not plug the product to

loose, broken, dirty, greasy

sockets or sockets that has

come out their seats or sock-

ets with a risk of water con-

tact.

• Use the new hose set

provided with the product. Do

not re-use old hose sets. Do

not make additions to the

hoses.

• Connect the water inlet hose

directly to the water tap. The

pressure from the tap should

be minimum 0.1 MPa (1 bar)

and maximum 1MPa (10

bars). 10 to 80 litres of water

should be running from the

tap in a minute in order for

the product to function prop-

erly. If the water pressure is

above 1 MPa (10 Bars), a

pressure-reducing valve

should be fitted. The max-

imum allowed temperature is

25°C.

• Fit the end of the water dis-

charge hose to the dirty water

discharge drain, the sink or

the bathtub.

• Place the power cable and

houses in locations without

risk of tripping.

• Do not install the product be-

hind a door, a sliding door or

at another location that will

prevent the door from open-

ing completely.

• If a drier is to be placed on

the product, fix with a suitable

connection apparatus ob-

tained from the authorised

service.

• There is a risk of contact with

electrical pieces when the up-

per trays is removed. Do not

dismantle the upper tray of

the product.

• Place the product at least 1

cm away from the edges of

furniture.

• Make sure the room in which

the installation performed is

adequately ventilated, as

there may be a risk of un-

desirable gases coming out

of the device igniting other

fuels in the room or interact-

ing with an open flame.

EN / 8

1.6 Operational Safety

• When you are using the ap-

pliances, use only detergents,

softeners and supplements

suitable for washing ma-

chines.

• Do not use chemical solvents

on the product. These materi-

als contain an explosion risk.

• Do not operate defective or

damaged products. Unplug

the product (or turn off the

fuse it is connected to), turn

off the water tap and call an

authorised service.

• Do not place sources of igni-

tion (burning candle, cigar-

ettes, etc.) or sources of heat

(irons, furnaces, ovens, etc.)

on top of or near the product.

Do not put inflammable/ex-

plosive materials near the

product.

• Do not get on the product.

• Unplug the product and turn

off the tap if you will not be

using the product for long

periods.

• Detergent/maintenance ma-

terials may splash out of the

detergent drawer if it is

opened while the machine is

working Contact of the deter-

gent with your skin and eyes

is dangerous.

• Make sure pets do not climb

inside the product. Check in-

side the product before use.

• Do not force open the locked

loading door. The door will

open once the washing is

completed. If the door does

not open, use the solutions

for “loading door does not

open” error in the

Troubleshooting section.

• Do not wash elements con-

taminated with gasoline, ker-

osene, benzene, reducers, al-

cohol or other inflammable or

explosive materials and in-

dustrial chemicals.

• Do not directly use dry clean-

ing detergent and do not

wash, rinse, spin or dry laun-

dry contaminated with dry

cleaning detergent.

• Do not place your hands into

the rotating drum. Wait until

the drum no longer rotates.

• Do not place your hand or a

metal object under the wash-

ing machine.

• If washing laundry at high

temperatures, the discharged

washing water would burn

your skin if in contact with

your skin, for ex. when the

draining hose is connected to

the tap. Do not touch the dis-

charge water.

EN / 9

• Take the following precau-

tions to prevent formation of

biofilm and malodours:

– Make sure the room where

the washing machine is

placed is well ventilated.

– Wipe the door gasket and

loading door glass with a

dry and clean cloth at the

end of the programme.

• The glass of the loading door

will heat up when washing or

drying at high temperatures.

Therefore, do not allow espe-

cially children to touch the

loading door glass while

washing or drying.

1.7 Drying Safety

• Laundry that has been previ-

ously washed, cleaned, con-

taminated or stained with

gasoline/gas, dry cleaning

solvents or other inflam-

mable/explosive materials

should not be dried in the ma-

chine because they give off

inflammable or explosive va-

pours. Otherwise, fire hazard

arises.

• Laundry contaminated with

materials such as vegetable

or mineral oil, acetone, alco-

hol, gasoline, gas oil, stain re-

movers, naphtha, turpentine,

paraffin or paraffin removers

should be washed separately

in hot water by adding extra

detergent before being dried

in the washing machine with

dryer. Otherwise, fire hazard

arises.

• Do not dry textile products

that contain predominantly

foam, rubber or rubber-like

parts (e.g. shower caps, wa-

terproof textile products, rub-

ber products and clothes) or

the ones that are filled and

damaged (e.g. Pillows or

coats). There is a risk of

burns.

• If you use a laundry ball, de-

tergent scale, laundry cage or

ball in your machine, these

products may melt during dry-

ing. If you are going to

choose the drying feature, do

not use these products. Oth-

erwise, fire hazard arises.

• If you use industrial chemic-

als for cleaning, do not use

the drying function. Other-

wise, fire hazard arises.

• The door becomes very hot

after drying process. After

drying is over, open the door

of the device completely. Do

not touch the metal door loc-

ated inside of the door glass.

There is a risk of burns due to

high temperatures.

EN / 10

• During Drying programmes, a

cooling step is performed as

the last step to ensure that

the laundry remains at a tem-

perature where it will not be

damaged. You may be ex-

posed to hot steam if you

open the cover without com-

pleting the cooling step. Risk

of seething.

• If the drying programmes are

interrupted (as a result of pro-

gramme cancellation or

power failure), the laundry in

the machine may be hot. Be

careful.

• Do not stop the machine be-

fore the drying programme is

completed. If you have to

stop the machine, take out all

the laundry inside of it and

place them in a suitable place

and wait for them to cool.

• Your product is suitable to

operate between the temper-

atures of 0°C and +35°C.

• Ambient temperatures

between 15°C and +25°C are

ideal for your product.

• Do not overload the machine

for drying. Observe the spe-

cified maximum load levels

for drying.

• If the laundry has been

washed with a stain remover,

run an additional rinsing

speed before starting the dry-

ing speed.

• Do not dry leather laundry

and laundry containing

leather (such as leather tags

on jeans) in the machine. The

colour left by the leather parts

may smear on other textiles.

• If there is a problem that you

cannot solve using the in-

formation given in the safety

instructions section, turn off

and unplug the machine and

call an Authorized Service.

• In your washer-dryer, you can

only wash laundry, only dry

laundry or do both of these

processes. The machine

should not be used for a long

period of time only for drying

wet laundry. While the ma-

chine is only used for drying,

it should be run empty in a

short washing programme

every 15 starts.

• Before putting laundry in the

machine, check all of them

and make sure that there is

no object such as lighter,

coin, metal object and pin,

etc. in their pockets or inside

of them.

EN / 11

• Lingerie that has metal parts

should not be dried in the ma-

chine. Metal parts may come

off during drying and cause

damage to the machine. Put

them in a bag or pillow case.

• Do not dry large laundry such

as tulle curtains, curtains,

sheets/beddings, blankets,

rugs in the machine. Laundry

may get damaged.

• Do not dry unwashed laundry

in the machine.

• Do not use softener or anti-

static agent unless recom-

mended by the manufacturer.

• Products such as softener

should be used in accord-

ance with the manufacturer's

instructions.

• Do not dry silk, wool and sim-

ilar delicate clothes in the ma-

chine. Otherwise, wool

clothes can shrink and dam-

age may be caused in other

delicate clothes.

• Check the symbols on laun-

dry label before washing and

drying processes.

• The machine automatically

cleans the lint itself that

comes out of the laundry dur-

ing drying. The machine per-

forms automatic water in-

takes for cleaning. For this

reason, the water tap of the

machine should also be open

during drying programmes.

• Prevent the lint from accumu-

lating around the product.

1.8 Maintenance and

Cleaning Safety

• Do not wash the product with

pressure washers, by spray-

ing vapour, water or pouring

water.

• Do not use sharp or abrasive

tools to clean the product. Do

not use household cleaners,

soap, detergent, gas, gasol-

ine, thinner, alcohol, varnish,

etc. while cleaning.

• Cleaning agents containing

solvents might reek poison-

ous fumes( for ex. cleaning

solvent. Do not use cleaning

products containing solvents.

• There may be detergent

residues in the detergent

drawer when you open it for

cleaning.

• Do not dismantle the filter of

the discharge pump while the

product is running.

• The temperature in the ma-

chine may rise up to 90ºC.

Clean the filter after the water

in the machine cools down in

order to avoid risk of getting

burnt.

EN / 12

2 Important Instructions for Environment

2.1 Compliance with WEEE

Directive

This product complies with EU

WEEE Directive (2012/19/EU).

This product bears a classifica-

tion symbol for waste electrical

and electronic equipment

(WEEE).

This product has been manu-

factured with high quality parts and materi-

als which can be reused and are suitable

for recycling. Do not dispose of the waste

product with normal domestic and other

wastes at the end of its service life. Take it

to the collection center for the recycling of

electrical and electronic equipment. Please

consult your local authorities to learn about

these collection centers.

Compliance with RoHS Directive:

The product you have purchased complies

with EU RoHS Directive (2011/65/EU). It

does not contain harmful and prohibited

materials specified in the Directive.

2.2 Package Information

Packaging materials of the product are

manufactured from recyclable materials in

accordance with our National Environment

Regulations. Do not dispose of the pack-

aging materials together with the domestic

or other wastes. Take them to the pack-

aging material collection points designated

by the local authorities.

EN / 13

3 Technical Speciﬁcations

Supplier’s name or commercial brand GRUNDIG

Model name

GD7510644UW

7178543300

Washing capacity (cotton) (kg) 10

Drying capacity (cotton) (kg) 6

Maximum spin speed (cycle/min) 1400

Built-In No

Height (cm) 84

Width (cm) 60

Depth (cm) 60

Single Water inlet / Double Water inlet +/-

Electrical input (V/Hz) 230 V /50Hz

Total current (A) 10

Total power (W) 2200

Main model code 1421

You can access technical information of the product by

scanning the QR code on the energy label with a mobile

device connected to the internet.

The consumption values apply when wireless network connection is turned off.

EN / 14

4 Installation

Please read the “Safety Instruc-

tions” section first!

While performing the installation of

the product, the calibration mode*

always should be run before the

first use.

Calibration mode provides accurate

sensing of laundry amount during

washing. To run the calibration

mode, the spin function should be

cancelled by selecting the Drum

Cleaning** programme.

The machine should be empty

while the calibration cycle is run-

ning.

This process takes about 15

minutes. To complete the calibra-

tion mode, you should wait until the

programme is finished.

*Calibration mode may not be avail-

able on some models. Spin speed

cannot be selected in models

without this feature.

**The programme name may vary

depending on the model. For the

appropriate programme selection,

you can review the programme de-

scriptions section.

• Preparation of the location and electrical,

tap water and waste water installations at

the place of installation is under cus-

tomer's responsibility.

• Make sure that the water inlet and dis-

charge hoses as well as the power cable

are not folded, pinched or crushed while

pushing the product into its place after in-

stallation or cleaning procedures.

• Prior to installation, visually check if the

product has any defects on it. Do not

have the product installed if it is dam-

aged. Damaged products cause risks for

your safety.

4.1 Appropriate Installation

Location

• Place the product on a hard and level

floor. Do not place it onto a carpet with

high pile or other similar surfaces. Pla-

cing on an improper floor shall cause

noise and vibration problems.

• Do not place the product on the power

cable.

• Do not install the product at places where

temperature may fall below 0 ºC. Freez-

ing might damage your product.

• Leave a minimum space of 1 cm

between the product and the furniture.

• If you will install the product on a surface

with steps, never place it close to the

edge.

• Do not place the product on any platform.

• There shall not be any locked, sliding or

hinged doors that may prevent the load-

ing door from opening completely in the

installation location of this product.

• Do not place heat sources such as

cooker, irons, ovens, heater etc. on the

appliance and do not use them on the

product.

4.2 Installation of Bottom Panel

Cover

• In order to increase the sound comfort of

the product, it is recommended to install

the cover after removing the packaging

foam.

Cover A

Tilt the machine back slightly. Rest the tabs

of Cover A against the lower panel. Com-

plete the assembly by rotating the cover.

EN / 15

4.3 Removing Transportation

Safety Bolts

a. Loosen all transportation safety bolts

with an appropriate wrench until they

turn freely.

b. Bend the inner part by pressing it at the

grip areas and pull the part out.

c. Attach the plastic covers supplied in the

User Manual bag into the holes on the

rear panel.

WARNING

Remove the transportation safety

bolts before operating the product.

Otherwise, the product will get

damaged.

WARNING

Keep the transportation safety bolts

in a safe place to reuse when the

product needs to be moved again

in the future.

Install the transportation safety

bolts in reverse order of the disas-

sembly procedure.

Never move the product without the

transportation safety bolts properly

fixed in place.

4.4 Connecting to Water Supply

WARNING

The water pressure required for the

operation of the product is between

1-10 bars (0.1-1 MPa). To ensure a

smooth operation of the machine,

10 - 80 liters of water shall be sup-

plied in a minute from a fully

opened tap. If the water pressure is

higher, install a pressure reducing

valve.

WARNING

Models with a single water inlet

shall not be connected to the hot

water tap. In such a case the laun-

dry will get damaged or the product

will switch to protection mode and

will not operate.

Do not use old or used water inlet

hoses on a new product. It may

cause water leakage from your ma-

chine and stain your laundry.

a. Connect the special hose supplied with

the product to the water inlet on the

product.

WARNING

Make sure that the cold water con-

nection is performed correctly dur-

ing the installation of the product.

Otherwise, your laundry may come

out as hot at the end of the washing

cycle and thus they may be worn.

b. Tighten all hose nuts by hand. Never

use a tool when tightening the nuts.

c. Open the taps completely after making

the hose connection to check for water

leaks at the connection points. If any

leak occurs, turn off the tap and remove

the nut. Check the gasket and tighten

the nut carefully again. In order to pre-

vent the water leaks and resultant dam-

ages, keep the taps closed when you do

not use the product.

4.5 Connecting the Drain Hose to

the Drain

a. Attach the end of the drain hose directly

to waste water drain, washbasin or

bathtub.

EN / 16

Your house will be flooded if the

water draining hose is dislocated

during water draining. There is also

a risk of burning due to the high

washing temperatures. In order to

prevent such situations and make

sure that the product performs wa-

ter intake and drain processes

without any problem, fix the drain

hose securely.

b. Connect the hose to a minimum height

of 40 cm and a maximum height of 90

cm.

c. If the hose is placed on the floor (or at a

maximum height of 40 cm from the floor)

and then its height is increased, dischar-

ging of water becomes difficult, and

laundry may come out very wet from the

machine. Thus, follow the heights

provided in the figure.

d. To prevent the waste water to go back

into the product again and to ensure

easy drainage, do not immerse the end

of the hose into the waste water or do

not insert it into the drain for more than

15 cm. If it is too long, cut it short.

e. The end of the hose should not be bent,

it should not be stepped on and the

hose must not be pinched between the

drain and the product. Otherwise, water

discharge issues may emerge.

f. If the length of the hose is too short, use

it by adding an original extension hose.

The length of the hose shall not be

longer than 3.2 m. To prevent water

leaks, always secure the connection

between the extension hose and the

draining hose of the product with a suit-

able clamp so that it does not come off

and cause leaks.

4.6 Adjusting the Stands

WARNING

In order to ensure that the product

operates more silently and vibra-

tion-free, it must stand level and

balanced on its feet. Ensure that

the product is balanced by adjust-

ing the feet. Otherwise, the product

may move from its place and cause

crushing, noise and vibration prob-

lems.

To avoid damaging the lock nuts,

do not use any tools to loosen the

nuts.

a. Loosen the lock nuts on the feet by

hand.

b. Adjust the feet until the product stands

level and balanced.

c. Tighten all lock nuts again by hand.

4.7 Electrical Connection

Connect the product to a grounded outlet

protected by a 13 A fuse. Our company

shall not be responsible for the damages

that shall be incurred due to using the

product without grounding according to

local regulations.

• Connection must comply with national

regulations.

• The electrical connection cable infra-

structure of the product must be ad-

equate and suitable for product require-

ments. It is recommended to use a

Ground Fault Circuit Breaker (GFCI).

• Power cable plug must be within easy

reach after installation.

EN / 17

• If the current supply to the fuse or

breaker in the house is less than 13

Amps, have a qualified electrician install

a 13 amp supply.

• The voltage specified in the "Technical

specifications" section must be equal to

your mains voltage.

• Do not make connections via extension

cables or multi-plugs. Overheating and

burning may occur due to the connecting

cable.

Damaged power cables should be

replaced by the authorised service

in order to prevent possible danger.

Important

Fitting a different plug:

As the colours of the wires in the mains

lead of this appliance may not correspond

with the coloured markings identifying the

terminals on your plug, proceed as follows:

a. Connect the green - yellow or green

(earth) wire to the terminal in the plug

marked ‘E’ or with the symbol f or col-

oured green and yellow or green.

b. Connect the blue (neutral) wire to the

terminal in the plug marked ‘N’ or col-

oured black.

c. Connect the brown (live) wire to the ter-

minal in the plug marked ‘L’ or coloured

red.

With the alternative plugs a 13 A fuse must

be fitted either in the plug or adaptor or in

the main fuse box. If in doubt contact a

qualified electrician.

4.8 Handling the Product

a. Unplug the product before handling it.

b. Disconnect the water outlet and water

main connections. 3 Drain all the water

that remains in the product. See Drain-

ing Remaining Water and Cleaning the

Pump Filter

c. Install the shipping bolts in reverse or-

der of the disassembly procedure. See

Removing the Shipping Bolts

Never carry the product without the

shipping bolts properly attached!

Your product is so heavy that it

shall not be carried by one person.

Your product shall be carried by

two people and more care shall be

taken on the stairs as it is a heavy

product. If the product falls on you,

it may cause injury.

The packaging materials are dan-

gerous for children. Keep pack-

aging materials at a safe place

away from the reach of children.

5 Preparation

Please read the “Safety Instruc-

tions” section first

5.1 Sorting the Laundry

• Sort laundry according to type of fabric,

colour, and degree of soiling and allow-

able water temperature.

• Always observe the instructions given on

the garment care labels.

EN / 18

5.2 Preparing Laundry for Washing

• Laundry items with metal attachments

such as, underwiring, belt buckles or

metal buttons will damage the product.

Remove the metal pieces or wash such

clothes by putting them in a laundry bag

or pillow case.

• Take out all substances in the pockets

such as coins, pens and paper clips, and

turn pockets inside out and brush. Such

objects may damage the product or

cause noise problem.

• Put small size clothes such as infant’s

socks and nylon stockings in a laundry

bag or pillow case.

• Place curtains in without compressing

them. Remove curtain attachment items.

Curtain attachment items may cause

pulling and tearing on the curtain.

• Fasten zippers, sew loose buttons and

mend rips and tears.

• Wash “Machine washable” or “Hand

washable” labelled products only with an

appropriate programme. Dry these types

of clothes by hanging them or laying

them flat. Do not dry them in the ma-

chine.

• Do not wash colours and whites together.

New, dark coloured cottons release a lot

of dye. Wash them separately.

• Only use paints / colour changing agents

and descalers suitable for use in ma-

chines. Always observe the instructions

on the packaging

• Tough stains must be treated properly

before washing. If you are not sure,

check with a dry cleaner.

• Wash trousers and delicate laundry

turned inside out.

• Laundry that are subjected to materials

such as flour, lime dust, milk powder, etc.

intensely must be shaken off before pla-

cing into the product. Such dusts and

powders on the laundry may build up on

the inner parts of the product in time and

can cause damage.

• Before washing laundry made of angora

wool, keep them in the freezer section of

the refrigerator for few hours. This will re-

duce pilling

5.3 Tips for Energy and Water

Saving

Following information will help you use the

product in an ecological and energy/water-

efficient manner.

• Operate the product in the highest load

capacity allowed for the programme you

have selected, but do not overload. See

"Programme and consumption table"

• Observe the temperature instructions on

the detergent packaging.

• Wash slightly soiled laundry at low tem-

peratures.

• Use faster programmes for small quantit-

ies of lightly soiled laundry.

• Do not use prewash and high temperat-

ures for laundry that is not heavily soiled

or stained.

• If you plan to dry your laundry in a dryer,

select the highest spin speed recommen-

ded during washing process.

• Do not use more detergent than the re-

commended on the detergent packaging.

5.4 Start Up

Before starting to use the product make

sure that the preparations described in sec-

tion “Environmental Instructions” and “In-

stallation”. To prepare the product for

washing laundry, perform first operation in

Drum Cleaning programme. If this pro-

gramme is not available in your product,

apply the method which is described in sec-

tion "Cleaning the loading door and the

drum".

Use an anti-limescale product suit-

able for the washing machines

Some water has remained in the

product due to the quality control

processes in the production. It is

not harmful for the product.

EN / 19

5.5 Loading the Laundry

a. Open the loading door.

b. Put the laundry items into the product in

a loose manner.

c. Push the loading door to close until you

hear a locking sound. Ensure that no

items are caught in the door. The load-

ing door is locked while a programme is

running. The door lock will open a few

minutes after the washing programme

has ended. Then you can open the

loading door. If the door does not open,

apply the solutions provided for “Load-

ing door cannot be opened” error in the

Troubleshooting section.

5.6 Correct Load Capacity

The maximum load capacity depends on

the type of laundry, the degree of soiling

and the desired washing programme.

The product automatically adjusts the water

amount according to the weight of the laun-

dry put inside it.

Follow the instructions in “Pro-

gramme and consumption table”.

When the appliances is overloaded

product’s washing performance will

drop. Moreover, noise and vibration

problems may occur.

For a successful drying perform-

ance, do not put more laundry in

the machine than specified.

Bathrobe: 1200 g

Bedding: 700 g

Sheet: 500 g

Pillow Case: 200 g

Table Cloth: 250 g

Negligee/Pyjamas: 200 g

Lingerie: 100 g

Shirts: 200 g

Blouse: 100 g

Towel: 200 g

The loading door is locked while a

programme is running. The door

lock will open once the programme

is completed. If the inner part of the

machine is very hot at the end of

the program, the loading door will

not open until the temperature

drops. If the door does not open,

apply the solutions provided for

“Loading Door Cannot Be Opened”

error in the Troubleshooting sec-

tion.

WARNING

If the laundry is placed incorrectly,

noise and vibration problems may

occur in the machine.

5.7 Using Detergent and Softener

WARNING

Read the manufacturer instructions

on the package while using deter-

gents, softeners, starch, bleach and

decolourants, anti-limescale and

follow the dosage information

provided. Use a measuring cup, if

any.

The detergent drawer comprises of three

compartments:

(1) for prewash,

(2) for main washing,

(3) for softener,

( ) a syphon piece in the softener com-

partment,

EN / 20

( ) there is a liquid detergent apparatus

for liquid detergent use in the main washing

compartment.

Detergent, Softener and Other Cleaning

Agents

• Add detergent and softener before start-

ing the washing programme.

• Do not leave the detergent drawer open

when the washing programme is on.

• If you are using a programme without

pre-washing, do not put detergent in the

pre-wash compartment (compartment no.

“1”).

• Do not put liquid detergent in the pre-

wash compartment (compartment no. “1”)

in a programme with prewashing.

• Do not select a programme with pre-

washing if you are using a detergent pod

or dispensing ball. Place the detergent

pod or the dispensing ball directly among

the laundry in the product.

• If you are using a liquid detergent, follow

the directions under “Liquid detergent

use” and do not forget to bring the liquid

detergent apparatus to the correct posi-

tion.

• Do not add washing chemicals (Liquid

detergent, Softener, etc.) while the ma-

chine is during Drying step.

Choosing the Detergent type

Detergent type to be used depends on the

washing programme, fabric type and col-

our.

• Use different detergents for coloured and

white laundry.

• Wash your delicate clothes only with spe-

cial detergents (liquid detergent, wool

shampoo, etc.) intended solely for delic-

ate clothes and at suggested pro-

grammes.

• When washing dark coloured clothes and

quilts, it is recommended to use liquid de-

tergent.

• Wash woollens at suggested programme

with special detergent made specifically

for woollens.

• Please review the programme descrip-

tions part for suggested programme for

different textiles.

• All recommendations about detergents

are valid for selectable temperature

range of programmes.

Only detergents, softeners and ad-

ditives suitable for washing ma-

chines should be used.

Do not use soap powder.

Adjusting the Detergent Amount

The amount of detergent depends on the

amount of laundry, how soiled they are and

the water hardness.

• Do not exceed the recommended dosage

values on the detergent packaging in or-

der to eliminate excessive foam and poor

rinsing problems, to save money and pro-

tect the environment.

• Use less amounts of detergent for fewer

or less soiled laundry.

Using Softeners

Put the softener in the softener compart-

ment of the detergent drawer.

• Do not exceed the (>max<) level sign in

the softener compartment.

• If the softener is not fluid, dilute with wa-

ter before placing in the softener com-

partment.

WARNING

Do not use liquid detergents or

other materials with cleaning prop-

erties unless they are intended for

use in washing machines for

softening the laundry.

Using Liquid Detergents

If the Product Has a Liquid Detergent

Apparatus

• Press and rotate the apparatus at where

it is shown when you want to use liquid

detergents. The part falling below will

serve as a barrier for liquid detergent.

• Clean with water at its place or by remov-

ing from its place when it is necessary.

Do not forget to place the apparats in the

main washing compartment (compart-

ment no. “2”) after cleaning.

• The apparatus should be up if you will

use a powder detergent.

EN / 21

Use of Gel and Tablet Detergents

• If the detergent is fluid and there is no li-

quid detergent compartment in your

product, place the gel detergent in the

main washing detergent compartment in

first water intake. If your product has a li-

quid detergent compartment, fill the com-

partment with detergent before starting

the programme.

• If the gel detergent is not fluid or is in a

capsule liquid tablet, place directly inside

the drum before washing.

• Put the tablet detergent in the main

washing compartment (compartment no.

“2”) or directly inside the drum before

washing.

• Tablet detergents may leave residue in

the detergent compartment. If you face

such residues, place the tablet detergent

among the laundry in the next washes in

a way that it will be at the bottom side of

the drum.

• Use tablet or gel detergent without se-

lecting the pre-wash function.

• Do not forget to remove elements such

as plastic detergent compartment from

the drum before drying.

Using Starch

• Put in the liquid starch, powder starch or

fabric dye in the softener compartment.

• Do not use softener and starch in the

same washing programme simultan-

eously.

• Wipe the inside of the product with a

damp and clean cloth after using starch.

Using Anti-Limescale

• When necessary, only use anti-limescale

produced for washing machines.

Using Bleach and Decolourants

• Select a programme with pre-washing

and add bleach at the start of pre-wash-

ing. Do not put detergent in the pre-wash

compartment. As an alternative applica-

tion, select a programme with additional

rinsing and add the bleach while the

product is receiving water to the deter-

gent compartment in the first rinsing step.

• Do not mix and use bleach and detergent

together.

• As bleach may cause skin irritation use

only small amounts (1/2 tea cups - ap-

proximately 50 ml and rinse the laundry

well.

• Do not pour bleach directly onto the laun-

dry.

• Do not use bleach for coloured clothes.

• Select a programme with low temperat-

ure washing while using oxygen-based

decolourants.

• Oxygen-based decolourants can be used

together with detergents. However, if it

does not have the same viscosity as the

detergent, first place the detergent in

compartment no. “2” in the detergent

drawer and wait for the product to rinse

away the detergent during water intake.

Add the decolourant to the same com-

partment while the machine continues

taking in water.

5.8 Tips for Efficient Washing

Clothes

Light Colours and

Whites

Colours

Black/Dark Col-

ours

Delicates/ Wool-

lens/Silks

(Recommended temperat-

ure range based on soil

level: 40-90 °C)

(Recommended temper-

ature range based on

soil level: cool -40 °C)

(Recommended

temperature range

based on soil level:

cool -40 °C)

(Recommended

temperature

range based on

soil level: cool -30

°C)

EN / 22

Soiling Level

Heavily Soiled

(difficult stains

such as grass,

coffee, fruits

and blood.)

It may be necessary to

pre-treat the stains or per-

form prewash.

Powder and liquid deter-

gents recommended for

whites can be used at

dosages recommended

for heavily soiled clothes.

It is recommended to use

powder detergents to

clean clay and soil stains

and the stains that are

sensitive to bleaches.

Powder and liquid deter-

gents recommended for

colours can be used at

dosages recommended

for heavily soiled

clothes. It is recommen-

ded to use powder de-

tergents to clean clay

and soil stains and the

stains that are sensitive

to bleaches. Detergents

which do not contain de-

colourant should be

used.

Liquid detergents

suitable for colours

and black/dark col-

ours can be used at

doses recommen-

ded for heavily

soiled clothes.

Prefer liquid de-

tergents produced

for delicate

clothes. Woollen

and silk clothes

must be washed

with special wool-

len detergents.

Normally

Soiled

(For example,

stains caused

by body on col-

lars and cuffs)

Powder and liquid deter-

gents recommended for

whites can be used at

dosages recommended

for normally soiled

clothes.

Powder and liquid deter-

gents recommended for

colours can be used at

dosages recommended

for normally soiled

clothes. Detergents

which do not contain de-

colourant should be

used.

Liquid detergents

suitable for colours

and black/dark col-

ours can be used at

doses recommen-

ded for moderately

soiled clothes.

Prefer liquid de-

tergents produced

for delicate

clothes. Woollen

and silk clothes

must be washed

with special wool-

len detergents.

Lightly Soiled

(No visible

stains exist.)

Powder and liquid deter-

gents recommended for

whites can be used at

dosages recommended

for lightly soiled clothes.

Powder and liquid deter-

gents recommended for

colours can be used at

dosages recommended

for lightly soiled clothes.

Detergents which do not

contain decolourant

should be used.

Liquid detergents

suitable for colours

and black/dark col-

ours can be used at

doses recommen-

ded for lightly

soiled clothes.

Prefer liquid de-

tergents produced

for delicate

clothes. Woollen

and silk clothes

must be washed

with special wool-

len detergents.

EN / 23

5.9 Tips for Efficient Drying

Programmes

Cotton Drying

Synthetic Dry-

ing

Babyprotect+

Washing and

Drying

Clean and

Wear

Types of Clothing

Durable

Clothes Con-

taining Cotton

Sheets, bed-

dings, baby

clothes, t-

shirts, sweat-

shirts, durable

knitted clothes,

jeans, canvas

pants, shirts,

cotton socks

vs.

Are Not Re-

commended!

It washes and

dries consecut-

ively! Sheets,

beddings, baby

clothes, t-

shirts, sweat-

shirts, durable

knitted clothes,

jeans, canvas

pants, shirts,

cotton socks

vs.

It washes and

dries consecut-

ively! Sheets,

beddings, baby

clothes, t-

shirts, sweat-

shirts, durable

knitted clothes,

jeans, canvas

pants, shirts,

cotton socks

vs.

Clothes such

as shirts, t-

shirts, sweat-

shirts etc. that

have been

worn for a

short time and

are unstained

A very small

amount of

laundry should

be loaded.

Synthetic

Clothes (Poly-

ester, nylon

etc.)

Are Not Re-

commended!

It is recommen-

ded for clothes

containing

polyester,

nylon, poly-

acetate, ac-

rylic. Drying is

not recommen-

ded for clothes

containing vis-

cose. Attention

should be paid

to the drying in-

structions on

the care label.

It is recommen-

ded for clothes

containing

polyester,

nylon, poly-

acetate and ac-

rylic at low

temperatures,

taking into ac-

count the

washing and

drying warn-

ings indicated

on the care la-

bel.

It is recommen-

ded for clothes

containing

polyester,

nylon, poly-

acetate and ac-

rylic at low

temperatures,

taking into ac-

count the

washing and

drying warn-

ings indicated

on the care la-

bel.

Lightly soiled

and unstained

shirts, t-shirts

and synthetic

containing

laundry. A very

small amount

of laundry

should be

loaded.

Delicate (Con-

taining Silk,

Woollen,

Cashmere, An-

gora wool etc.)

Laundry

Are Not Re-

commended!

Are Not Re-

commended!

Are Not Re-

commended!

Are Not Re-

commended!

Are Not Re-

commended!

Blankets,

coats, curtains

etc. bulky laun-

dry.

Are Not Re-

commended! It

is not suitable

to dry bulky

laundry in the

washing ma-

chine. Dry

these laundry

by hanging

them or laying

them flat.

Are Not Re-

commended! It

is not suitable

to dry bulky

laundry in the

washing ma-

chine. Dry

these laundry

by hanging

them or laying

them flat.

Are Not Re-

commended! It

is not suitable

to dry bulky

laundry in the

washing ma-

chine. Dry

these laundry

by hanging

them or laying

them flat.

Are Not Re-

commended! It

is not suitable

to dry bulky

laundry in the

washing ma-

chine. Dry

these laundry

by hanging

them or laying

them flat.

Are Not Re-

commended! It

is not suitable

to dry bulky

laundry in the

washing ma-

chine. Dry

these laundry

by hanging

them or laying

them flat.

5.10 Displayed Programme Duration

You can view the programme duration on

the display of your machine while selecting

a programme. Depending on the amount of

laundry you have loaded into your machine,

foaming, unbalanced load conditions, fluc-

tuations in power supply, water pressure

and programme settings, the programme

duration is automatically adjusted while the

programme is running.

SPECIAL CASE: At programme start of

Cottons and Cotton Eco programmes, dis-

play shows the duration of half load. It is

the most common use case. After pro-

gramme starts, in 20-25 minutes actual

load is detected by the machine. And if the

detected load is higher than half load;

washing programme will be adjusted ac-

cordingly and programme duration in-

creased automatically. You can follow this

change on the display.

EN / 24

6 Operating the Product

Please read the “Safety Instruc-

tions” section first!

6.1 Control Panel

2 3 4

56789101112

1 Programme Selection Button 2 Temperature Level Lights

3 Spin Level Indicator Lights 4 Display

5 Start/Pause Button 6 Remote Control Button

7 End Time Setting Button 8 Drying Level Adjustment Button

9 Auxiliary Function Button 2 10 Auxiliary Function Button1

11 Spin Speed Adjustment Button 12 Temperature Setting Knob

EN / 25

6.2 Symbols on the Display

1 2 3

91011121314151617

1 Temperature Indicator 2 Spin Speed Indicator

3 Duration information 4 Door lock is engaged symbol

5 Programme follow-up indicator 6 No Water indicator

7 Add Garment Indicator 8 Bluetooth Connection Indicator

9 Remote Control Indicator 10 Delayed Start Enabled Indicator

11 Drying Level Indicator 12 Child Lock Enabled symbol

13 Auxiliary Function Indicators 2 14 Auxiliary Function Indicators 1

15 No spin indicator 16 Rinse Hold Indicator

17 Cold Water indicator

The visuals used for machine de-

scription in this section are schem-

atic and may not match exactly with

the features of your machine.

6.3 Preparing the Machine

a. Check if the hoses are connected

tightly.

b. Plug in your machine.

c. Turn on the tap completely.

d. Place the laundry inside the machine.

e. Put detergent and softener.

EN / 26

6.4 Selection of Washing Program

a. Determine the programme suitable for

the type, quantity and soiling level of the

laundry in accordance with "Programme

and consumption table".

Programmes are limited to the

highest spin speed appropriate for

that particular type of fabric.

When selecting a programme, al-

ways consider the type of fabric,

colour, soiling level and permissible

water temperature.

b. Select the desired programme with the

Programme Selection knob.

6.5 Washing Programmes

Use the following main programmes de-

pending on the type of fabric.

After selecting the appropriate washing pro-

gram, by pressing the Drying button before

starting the program, you can set your ma-

chine to switch to the drying step (automat-

ically or timedly) at the end of the washing

program, without any pauses/interruptions.

Each time you press the button, the step in

which the drying process will take place is

shown in the row of information and the re-

lated symbol lights up. You can see when

the programme will finish on the display of

the machine, according to the drying selec-

tions you will add to the washing pro-

grammes. If you want, by keeping pressing

the button you can dry for the maximum

time allowed.

You can take a glance at the programmes

for which you can select the drying function

in the Programme and Consumption tables.

Symbols shown on the display are

schematic and may not match with

the product one-to-one.

If you do not want to perform drying

process after the programme you

have selected, press and hold the

Drying auxiliary function button until

the Drying light turns off.

When washing and drying using the

Drying function of your machine,

load a maximum of 6 kilograms of

laundry into the machine. If you

load more laundry than the capacity

of the machine, your laundry will

not dry and the machine will run

longer and consume more energy.

WARNING

The drying function cannot be se-

lected for the washing programme

for woollen clothes.

• Eco 40-60

In the Eco 40-60 programme, you may

wash normally soiled cotton laundry that

are specified to be washed together at

40°C or 60°C. This programme is the

standard test programme according to the

EU environmentally friendly design and en-

ergy labelling regulations.

Although this programme washes longer

than other washing programmes, it is more

efficient in terms of energy and water con-

sumption. Actual water temperature may be

different from the stated wash temperature.

When you load the machine with less laun-

dry (e.g. ½ capacity or less), periods in pro-

gramme stages may automatically get

shorter. In this way, energy and water con-

sumption would be much less.

In order to evaluate compliance with EU

environmentally friendly design and energy

labelling regulations, the washing and dry-

ing cycle should be run by selecting the

cupboard dry function of eco 40-60 pro-

gramme. The washing and drying cycle can

clean normally soiled laundry declared to

be washable at 40 °C or 60 °C in a single

cycle and dries them so that they can be

put in a cupboard immediately.

EN / 27

• Cottons

You can wash your durable cotton laundry

(sheets, bedlinen, towels, bathrobes, un-

derwear etc.) in this programme. When the

quick wash function button is pressed, pro-

gramme duration becomes notably shorter

but effective washing performance is en-

sured with intense washing movements. If

the quick wash function is not selected, ef-

fective washing and rinsing performance is

ensured for your heavily soiled laundry.

• Synthetics

You can wash your laundry (such as t-

shirts, blouses, synthetic/cotton blended

fabrics etc.) in this programme. When the

quick wash function button is pressed, pro-

gramme duration becomes notably shorter

and effective washing performance is en-

sured for your lightly soiled laundry. If the

quick wash function is not selected, effect-

ive washing and rinsing performance is en-

sured for your heavily soiled laundry.

• WoolProtect

Use to wash your woollen/delicate laundry.

Select the appropriate temperature comply-

ing with the tag of your clothes. Your laun-

dry will be washed with a very gentle wash-

ing action in order not to damage the

clothes.

• Down Wear

Use this programme to wash your coats,

vest, jackets etc. containing feathers with a

"machine-washable" label on them. Thanks

to special spinning profiles, it is ensured

that the water reaches the air gaps

amongst the feathers.

• Spin + Pump

You can use this program to remove the

water on the garment/inside the machine.

• Rinsing

Use when you want to rinse or starch sep-

arately.

• Shirts

This programme is used to wash the shirts

made from cotton, synthetic and synthetic

blended fabrics altogether. It reduces

wrinkles. Steam is applied at the end of the

programme to help the wrinkle reducing

function. The special spin profile and steam

applied at the end of the programme re-

duce the wrinkles on your shirts. When the

quick wash function is selected, the Pre-

treatment algorithm is executed.

• Apply the pre-treatment chemical on your

garments directly or add it together with

the detergent in the powder detergent

compartment. Thus, you can obtain the

same performance as you obtain with

normal washing in a much shorter period

of time. Usage life of your shirts in-

creases. Do not use pre-wash detergent

if you are planning to use delay function

of your machine. Pre-wash detergent

may cause stains on your clothes.

** It is recommended to operate the cycle

with no more than 6 shirts to minimise the

wrinkle level in your shirts with this cycle.

When washing is operated with more than

6 shirts, there may be differences on the

wrinkle levels and humidity on shirts at the

end of cycle.

• Mini / Mini 14'

Use this programme to wash your lightly

soiled or unspotted cotton clothes in a short

time but not for towels or heavy cottons.

The programme duration can be reduced

down to 14 minutes when the quick wash

function is selected. When the quick wash

function is selected, maximum 2 (two) kg of

laundry must be washed.

• Dark Care/ Jeans

Use this programme to protect the colour of

your dark-coloured garments or jeans. It

ensures high performance washing with

special drum movement even if the temper-

ature is low. It is recommended to use li-

quid detergent or woollen shampoo for dark

coloured laundry. Do not wash your delic-

ate clothes containing wool or etc.

• Mix

Use to wash your cotton and synthetic

clothes together without sorting them.

• Lingerie

You can use this programme to wash delic-

ate garments that are suitable for hand

wash and delicate women's underwear.

Small amount of garments must be washed

in a washing net. Hooks, buttons etc. must

be done up and zips must be zipped up.

EN / 28

• Sports

You can use this programme to wash

sports and outdoors garments that contain

cotton/synthetics mix and water repellent

covers such as gore-tex etc. It makes sure

your garments are washed gently thanks to

special rotating movements.

• Downloaded Programme

This is a special programme that allows

you to download different programmes

when you want to. At the start, there is a

programme you can see with the Home-

Whiz application as default. However, you

can use the HomeWhiz application to se-

lect a programme from the predefined pro-

gramme set, and then change and use it.

Select Programme Download fea-

ture if you want to use HomeWhiz

feature and Remote Control func-

tion. Detailed information can be

found in HomeWhiz Feature and

Remote Control Function.

6.6 Temperature Selection

Whenever a new programme is selected,

the recommended temperature for the pro-

gramme appears on the temperature indic-

ator. It is possible that the recommended

temperature value is not the maximum tem-

perature that can be selected for the cur-

rent programme.

Press the Temperature Adjustment button

to change the temperature. Temperature

decreases gradually.

Temperature Adjustment button

only works backwards. For ex-

ample, if you want to select 60°C

while 40°C is written on the display,

you need to press the button sev-

eral times until you reach 60°C, go-

ing backwards from 40°C.

If you go to Cold Wash option and

press Temperature Adjustment but-

ton again, the recommended max-

imum temperature for the selected

programme will be displayed. Press

the Temperature Adjustment button

again to decrease the temperature.

Finally, the Cold light that indicates cold

washing illuminates on the display.

You can also change the temperature after

the washing starts. You can also change

the desired temperature after the washing

programme starts. However, you need to

do this before the heating phase starts.

6.7 Spin Speed Selection

Whenever a new programme is selected,

the recommended spin speed of the selec-

ted programme is displayed on the Spin

Speed indicator. It is possible that the re-

commended spin speed value is not the

maximum spin speed that can be selected

for the current programme.

Press the Spin Speed Adjustment button to

change the spin speed. Spin speed de-

creases gradually.

Then, depending on the model of the

product, "Rinse Hold " and "No Spin

" options appear on the display.

EN / 29

Spin Speed Adjustment button only

works backwards. For example, if

you want to select 1000 rpm while

800 rpm (cycle/min) is written on

the display, you need to press the

button several times until you reach

1000 rpm, going backwards from

800 rpm.

If you are not going to unload your laundry

immediately after the programme com-

pletes, you can use Rinse Hold function in

order to prevent them from getting wrinkled

when there is no water in the machine.

This function holds the laundry in the

final rinsing water. If you want to spin

your laundry after the Rinse Hold

function:

a. Adjust the Spin Speed.

b. Press Start / Pause. The programme will

resume. Machine drains the water and

spins the laundry.

If you want to drain the water at the end of

the programme without spinning, use No

Spin function.

No change can be made in pro-

grammes where spin speed adjust-

ment is not allowed.

You can change the spin speed after the

washing starts if the washing steps allow it.

Changes cannot be made if the steps do

not allow it.

Auxiliary function selection for drying:

When you select a new washing program,

press the Auxiliary Function Selection but-

ton to set the drying option suitable for this

program.

In programmes that do not allow

the drying setting, when the Drying

auxiliary function button is pressed,

the drying light will not change and

a warning noise will be heard.

For only drying programmes, set

the appropriate drying option by

pressing the Auxiliary Function Se-

lection button.

6.8 Drying Programmes

WARNING

The machine automatically cleans

the lint that from the laundry during

drying programme. The machine

uses water during drying. For this

reason, the water tap of the ma-

chine should also be open during

drying programmes.

When you select a new washing

program, press the Auxiliary Func-

tion Selection button to set the dry-

ing option suitable for this program.

In drying programmes, there is a spinning

step. Your machine performs this process

in order to shorten the drying duration.

When the drying programme is selected,

the spin speed setting is in the range of

Maximum spin speed.

In programmes that do not allow the drying

setting, when the Drying auxiliary function

button is pressed, the drying light will not

change and a warning noise will be heard.

For only drying programmes, set the appro-

priate drying option by pressing the Auxili-

ary Function Selection button.

In case of water outage, washing

and drying cannot be performed.

• Synthetic Dry

Use this programme to dry synthetic laun-

dry with a dry weight of up to 4 kilograms.

You can only dry in this program.

For the dry weight of the laundry,

see Correct Load Capacity

EN / 30

• Cotton Dry

Use this programme to dry cotton laundry

with a dry weight of up to 6 kilograms. You

can only dry in this program.

When you will dry laundry consist-

ing of towels and bathrobes only,

load a maximum of 4,5 kilograms of

laundry.

For the dry weight of the laundry,

see Correct Load Capacity

6.9 Washing and Drying

Programmes

• 6 kg Wash&Dry

Use this programme to dry cotton laundry

weighing up to 6 kg immediately after the

washing programme, without making any

other selections.

External Drying auxiliary function

cannot be selected while this pro-

gramme is selected.

In the 6 kg of Washing and 6 kg of Drying

programme, it is recommended to fill the

machine to the level shown in the figure

above for ideal drying conditions (you can

see the level arrow when you open the

loading door).

• Mini Wash&Dry

Use this programme to wash 0.5 kg of laun-

dry (2 shirts) in 40 minutes or to wash 1 kg

of laundry (5 shirts) in 60 minutes.

Clean and Wear programme is de-

signed to quickly wash and dry

daily clothes that have been worn

for a short time and are not heavily

contaminated. This programme is

suitable for fine-textured and quick-

drying laundry (shirts, t-shirts).

For thick textured laundry that

takes longer to dry, other drying op-

tions or programmes should be

used.

• HygieneCare+Wash&Dry

A steam step applied at the beginning of

the program helps to soften the dirt.

Use this programme to wash and quickly

dry laundry weighing up to 2 kilograms, re-

quiring anti-allergic and hygienic washing

(cotton laundry such as baby clothes,

sheets, lingerie).

The Baby+ programme has been

tested and approved by the “British

Allergy Foundation” (Allergy UK)

located in the United Kingdom.

• HygieneRefresh

Hygienic washing with hot air

(programme duration 58 min.)

The hygienic ventilation programme en-

sures that the temperature of the laundry is

kept at relatively high temperatures with a

precise heating method and hygienic clean-

ing is performed via air.

Use this programme for fast hygienic clean-

ing of your cotton or synthetic dry clothes

with hot air.

Hygienic Ventilation programme

does not use water. Use this pro-

gramme for clothes you want to

clean by ventilation.

NOTICE: Do not put chemicals

such as detergents, bleach, stain

remover, etc. in the detergent

drawer in the hygienic ventilation

programme. No pre-treatment to

laundry is required before turning

on the programme.

EN / 31

Refreshing with hot air (48 min. and 38

min..)

The default duration is 58 minutes if you

select the “Hygienic Ventilation” pro-

gramme. With “Fast+” auxiliary function you

can select different programme durations

such as 48 minutes and 38 minutes.

6.10 Programme and Consumption Table

For washing:

Auxiliary Functions

Programme

Temperature

°C

Max. Load

(kg)

Water Con-

sumption (l)

Energy Con-

sumption

(kWh)

Max. Speed

Steam

Express

Prewash

Anti Crease+

Drying

Temperature °C

Cottons

90 10 98 2,75 1400 • • • • • Cold - 90

60 10 98 2,00 1400 • • • • • Cold - 90

40 10 95 1,10 1400 • • • • • Cold - 90

Eco 40-60

***

10 65,0 0,990 1400 • 40-60

***

5 44,0 0,800 1400 • 40-60

***

2,5 36,0 0,400 1400 • 40-60

Eco 40-60 + Cupboard Dry

***

6 60,0 3,695 1400 • 40-60

***

3 43,0 2,095 1400 • 40-60

Synthetics

60 4 76 1,60 1200 • • • • • Cold - 60

40 4 74 1,10 1200 • • • • • Cold - 60

Mini / Mini 14'

90 10 75 2,30 1400 • • • • Cold - 90

60 10 75 1,30 1400 • • • • Cold - 90

30 10 75 0,25 1400 • • • • Cold - 90

Mini / Mini 14' + Express 30 2 45 0,15 1400 • • • • Cold - 90

WoolProtect 40 2 60 0,60 1200 Cold - 40

Shirts 60 4 70 1,4 800 * • • • • Cold - 60

Machine Care 90 - 80 2,60 600 * * 90

Downloaded Programme *****

Mix 40 4 83 1,10 800 • • • • • Cold - 40

Sports 40 5 60 0,65 1200 • • Cold - 40

Dark Care/ Jeans 40 5 86 1,05 1200 • • • • • Cold - 40

Down Wear 60 - 100 1,60 800 • Cold - 60

Lingerie 30 1 78 0,30 600 Cold - 30

• : Selectable.

* : Automatically selected, cannot be can-

celled.

*** : Eco 40-60 programme is a test pro-

gramme according to 40 ° C temperature

selection, EU regulation EU / 2019/2014

and EN 60456: 2016 / A11: 2020 standard.

Selection of 40 °C temperature and cup-

board dry in the Eco 40-60 programme is a

washing and drying cycle test programme

as per EU/2019/2014 EU regulation and

EN 62512.

***** : These programmes can be used with

the HomeWhiz application. Energy con-

sumption may increase due to connection.

EN / 32

****** : These auxiliary functions can be

used by selecting the Programme Person-

alisation feature.

- : See the programme description for max-

imum load.

Please read Installation section of

the manual before first use.

The auxiliary functions in the table

may vary according to the model of

your machine.

Water and energy consumption

may vary subject to the changes in

water pressure, water hardness

and temperature, ambient temper-

ature, type and amount of laundry,

selection of auxiliary functions and

spin speed, and changes in electric

voltage.

Selection patterns for auxiliary

functions can be changed by the

manufacturer company. New selec-

tion patterns can be added or re-

moved.

The spin speed of your machine

may vary according to the pro-

gramme; this spin speed cannot ex-

ceed the max. spin speed of your

machine.

The amount of noise and humidity

varies according to the spin speed;

when the higher spin speed is se-

lected during the spinning phase,

the laundry contains less moisture

but higher noise occurs at the end

of the programme.

You can see the washing duration

on the display of your machine

while selecting a programme. De-

pending on the amount of laundry

you have loaded into your machine,

there may be a difference of 1-1.5

hours between the duration shown

on the display and the actual dura-

tion of the wash cycle. Duration will

be automatically updated soon after

the washing starts.

Always select the lowest appropri-

ate temperature. The most efficient

programmes in terms of energy

consumption are generally those

that wash at low temperatures for a

long time.

For drying:

Auxiliary Functions Drying Level

Programme

Max. Load (kg)

Water Consumption (l)

Energy Consumption (kWh)

Max. Speed

Steam

Prewash

Express

Anti Crease+

Drying

Extra Dry

Cupboard Dry

Iron Dry

Time Based Drying - minute

Temper-

ature Se-

lection °C

Cotton Dry - 6 50 3,9 1400 • * • • • • -

Synthetic Dry - 4 35 2,5 - • * • • • -

EN / 33

Hygiene-

Care+Wash&Dry

60 2 120 3,8 1400 * • * • • • • 90-30

6 kg Wash&Dry 60 6 115 6 1400 • * • • • • 60-Cold

Mini Wash&Dry 30 0,5 35 0,6 1200 • * • 30-Cold

Mini Wash&Dry 30 1 44 1 1200 • * • 30-Cold

HygieneRefresh - 2 1 0,5 - • • * -

Consumption Values (EN)

Temperat-

ure Selec-

tion °C

Spin Speed

(cycle/min)

Capacity

(kg)

Programme

Duration

(h:min)

Energy

Consump-

tion (kWh/

cycle)

Water Con-

sumption

(liter/cycle)

Laundry

Temperat-

ure (°C)

Residual

Moisture

Percent (%)

Eco 40-60

40 1400 10,0 03:58 0,990 65,0 36 53,9

40 1400 5,0 02:59 0,800 44,0 39 53,9

40 1400 2,5 02:59 0,400 36,0 24 53,9

Cottons 20 1400 10 04:00 0,750 95,0 20 53,9

Cottons 60 1400 10 04:00 2,000 98,0 60 53,9

Synthetics 40 1200 4 02:35 1,100 74,0 40 40

Mini / Mini

14'

30 1400 10 00:28 0,250 75,0 23 62

Eco 40-60

+ Cupboard

Dry

40 1400 6,0 09:30 3,695 60,0 24 53,9

40 1400 3,0 06:50 2,095 43,0 23 53,9

The consumption values given for programmes other than the Eco 40-60 programme for washing and drying online

are only indicative.

6.11 Auxiliary Function Selection

Select the desired auxiliary functions before

starting the programme. Whenever a pro-

gramme is selected, icons of the auxiliary

function symbol that is selected together

with it illuminates.

EN / 34

When an auxiliary function button

that cannot be selected with the

current programme is pressed, the

washing machine will make a warn-

ing sound.

Some functions cannot be selected

together. If a second auxiliary func-

tion conflicting with the first one is

selected before starting the ma-

chine, the function selected first will

be cancelled and the second auxili-

ary function selection will remain

active. For example, if you want to

select Quick Wash after you have

selected the Additional Water, Ad-

ditional Water will be cancelled and

Quick Wash will remain active.

An auxiliary function that is not

compatible with the programme

cannot be selected. (See "Pro-

gramme and consumption table")

Some programmes have auxiliary

functions that must be operated

simultaneously. Those functions

cannot be cancelled. The frame of

the auxiliary function will not be illu-

minated, only inner area will be illu-

minated.

If the selected wetness level (Iron

Dry, Cupboard Dry, Cupboard Ex-

tra Dry) cannot be reached at the

end of the drying programme, your

machine automatically extends the

programme duration. The pro-

gramme takes longer.

If Timed Drying is selected, the pro-

gramme finishes at the end of the

drying duration even if the laundry

has not dried.

During the drying programme, if the

selected wetness level (Iron Dry,

Cupboard Dry, Cupboard Extra

Dry) is reached or extra dryness is

detected in the timed drying op-

tions, the programme will take a

shorter time. The time shortening is

shown on the display.

6.11.1 Auxiliary Functions

• Prewash

A Prewash is only worthwhile for heavily

soiled laundry. Not using the Prewash will

save energy, water, detergent and time.

• Express

You can press Quick Wash adjustment but-

ton to shorten the duration after the pro-

gramme is selected. For some pro-

grammes, the duration can shorten by over

50%. High washing performance is

achieved in spite of the reduced duration.

While it differs for each programme, when

you press the Quick Wash button once, the

duration will drop to a certain level. When

you press the same key for the second

time, it drops to the minimum level.

Do not use Quick Wash adjustment button

when washing heavily soiled laundry for a

better washing performance.

Shorten the programme duration by using

the Quick Wash key for Moderately and

Slightly soiled laundry.

• Remote Control

You can use this auxiliary function key to

connect your product to smart devices. For

detailed information, see HomeWhiz Func-

tion Feature and Remote Control Function.

• Customized Programme

This auxiliary function can only be used for

Cotton and Synthetics programmes to-

gether with the HomeWhiz application.

When this auxiliary function is activated,

you can add up to 4 auxiliary rinsing steps

to the programme. You can select and use

some auxiliary functions even though they

are not found on your product. You can in-

crease and decrease the duration of the

Cottons and Synthetics programmes within

a safe range.

When the Programme Personalisa-

tion auxiliary function is selected,

the washing performance and en-

ergy consumption will be different

than the declared value.

EN / 35

• Drying

This function allows the laundry to dry after

washing. Check in the programme table

with which programmes this auxiliary func-

tion can be selected.

6.11.2 Functions/Programmes

Selected by Pressing the

Function Keys for 3 Seconds

• Machine Care

Press and hold the related auxiliary func-

tion button for 3 seconds to select the pro-

gramme. Regularly clean (once every 1 to

2 months) the drum for ensuring the re-

quired hygiene. Steam is applied before the

programme to soften the residues in the

drum. Turn on the programme when the

machine is completely empty. For more ef-

fective results, place powder anti-limescale

(drum cleaning materials) suitable for

washing machines inside the detergent

compartment “2”. There is a drying step

after drum cleaning in this programme for

the inside of the drum to dry.

This is not a washing programme.

This is a maintenance programme.

Do not turn this programme on

when there is something inside the

machine. When you attempt to op-

erate, the machine automatically

senses that there is load inside,

and may quit or resume the pro-

gramme as per the model of your

machine. An effective cleaning is

not achieved if the programme is

resumed.

• Anti Crease+

This function is selected when the spin se-

lection button is pressed and held for 3

seconds and the programme follow-up light

for the relevant step turns on. When selec-

ted, it aerates the laundry for up to 8 hours

at the end of the programme to prevent

creasing. You can cancel the programme

and take your laundry out at any time dur-

ing the 8-hour duration. Press the function

selection key or the machine on/off key to

cancel the function. The programme follow-

up light will remain on until the function is

cancelled or the step is complete. If the

function is not cancelled, it will be active in

the subsequent washing cycles as well.

• Steam

This function can be selected by pressing

and holding the related auxiliary function

button for 3 seconds.

This function helps to reduce the creases of

your cotton, synthetic and mixed clothes,

shorten the ironing time and remove the dirt

by softening.

*Your laundry may be hotter at the end of

the washing cycle when the steam function

is applied at the end of the programme.

This is an expected condition within the op-

erating conditions of the programme.

• Child Lock

Use Child Lock function to prevent children

from tampering with the machine. Thus you

can avoid any changes in a running pro-

gramme.

You can switch on and off the ma-

chine with On / Off button when the

Child Lock is active. When you

switch on the machine again, pro-

gramme will resume from where it

has stopped.

When the Child Lock is enabled, an

audio warning will be given if the

buttons are pressed. Audio warning

will be cancelled if the buttons are

pressed five times consecutively.

To activate the child lock:

Press and hold Drying Level Adjustment

button for 3 seconds. After the countdown

as “CL 3-2-1” on the display is over, “CL

On” (Child Lock On) symbol appears on the

display. You may release the Drying Level

Adjustment button when this symbol is dis-

played.

To deactivate the child lock:

Press and hold Drying Level Adjustment

button for 3 seconds. After the countdown

“CL 3-2-1” on the display is over, “CL

Off” (Child Lock Off) symbol appears on the

display.

EN / 36

• Bluetooth

You can use the bluetooth connection func-

tion to pair your machine with your smart

device. This way, you can use your smart

device to get information about your ma-

chine and control it.

To activate bluetooth connection:

Press the Remote Control function button

for 3 seconds. “3-2-1 countdown will be dis-

played and Bluetooth symbol will appear on

the display. Release the Remote Control

function button. Bluetooth icon will flash

when the product is pairing with your smart

appliance. The icon’s light remains on if the

connection is successful.

For deactivating the Bluetooth

connection:

Press the Remote Control function button

for 3 seconds. Countdown “3-2-1” will be

displayed, and then Bluetooth icon will dis-

appears on the display.

First setup of the HomeWhiz applic-

ation must be complete for the

bluetooth connection to be activ-

ated. After setup, pressing the re-

mote control function button while

the knob is at Download Pro-

gramme/Remote Control position

will automatically activate the

bluetooth connection.

6.12 Drying Steps

Iron Dry

Drying is performed until the Iron Dry step

is reached at the drying level.

Cupboard Dry

Drying is performed until the Cupboard Dry

step is reached at the drying level.

Extra Dry

Drying is performed until the Cupboard Ex-

tra Dry step is reached at the drying level.

The dryness level may vary de-

pending on the laundry mixing and

material type as well as amount

and wetness level.

Clothes containing lace, tulle,

stone, beads, sequins, wires etc.

and laundry with high silk content

should not be dried in the machine.

Time Based Drying – minute

To achieve the desired dryness level at a

low temperature, you can choose from dry-

ing durations of 30, 90 and 150 minutes.

When drying a small amount of laundry

(maximum 2 items), the timed drying steps

in Cotton or Synthetic drying programmes

should be selected.

If the laundry is not at the desired dryness

level at the end of the drying programme,

timed drying can be selected to finish the

process.

When this function is selected, the machine

performs drying for the set time regardless

of the drying level.

6.13 End Time

Time display

When the end time function is selected, the

remaining time until the programme starts

is shown in hours such as 1h, 2h, and the

remaining time to complete the programme

after your programme starts is shown in

hours and minutes as in the 01:30 ex-

ample.

Programme duration may differ

from the values in section "Pro-

gramme and consumption table"

depending on the water pressure,

water hardness and temperature,

ambient temperature, amount and

the type of laundry, auxiliary func-

tions selected and the changes at

the mains voltage.

EN / 37

With the End Time function, the end time of

the programme may be set up to 24 hours.

After pressing End Time button, the pro-

gramme's estimated ending time is dis-

played. If the End Time is set, End Time in-

dicator is illuminated.

In order for the End Time function is activ-

ated and the programme is completed at

the end of the specified time, you must

press Start/Pause button after adjusting the

time.

If you want to cancel End Time function,

press On/Off button to turn off and on the

machine.

When you have activated the End

Time function, do not add liquid de-

tergent in the powder detergent

compartment no 2. There is the risk

of staining of the clothes

a. Open the loading door, place the laun-

dry and put detergent, etc.

b. Select the washing programme, temper-

ature, spin speed and, if required, the

auxiliary functions.

c. Set the End Time of your choice by

pressing the End Time button. End Time

indicator lights.

d. Press Start / Pause. Time countdown

starts.

Additional laundry can be added

into the machine during the End

Time countdown. At the end of the

countdown, End Time indicator

turns off, washing cycle starts and

the time of the selected programme

appears on the display.

The door remains locked during the

End Time countdown. To unlock

the door, you need to put the ma-

chine in pause mode by pressing

the programme start/pause button.

At the end of the countdown, End

Time indicator turns off, washing

cycle starts and the duration of the

selected programme appears on

the display.

When the End Time selection is

completed, the time appearing on

the display consists of end time

plus the duration of the selected

programme.

6.14 Starting the Programme

a. Start the programme by pressing the

Start/Pause button.

b. The flashing light of Start/Pause button

starts to illuminate steadily, indicating

that the programme has started.

c. Loading door is locked. "Locking Door"

expression appears on the display while

the door is being locked.

6.15 Loading Door Lock

There is a locking system on the loading

door of the machine that prevents opening

of the loading door in cases when the water

level is unsuitable.

"Door Locked" symbol appears on the dis-

play when the loading door is locked.

EN / 38

If the Remote Control Function is

selected, the door will be locked. In

order to open the door you must

deactivate Remote Start Function

by either pressing the Remote Start

button or changing the programme

position.

Opening the loading door in case of

power failure:

In case of a power failure, you can

use the loading door emergency

handle under the pump filter lid to

manually open the loading door.

Before opening the loading door,

make sure that there is no water in

the machine to avoid flooding.

a. Turn off and unplug the appliance.

b. Open the pump filter lid.

c. Pull down the loading door emergency

handle with a tool and release. Then

open the loading door.

d. If the loading door does not open then

repeat the previous step.

6.16 Changing the Selections After

Programme has Started

Adding Laundry after the Programme

has Started :

If the water level in the machine is suitable

when you press Start/Pause button, the

door lock will be deactivated and the door

will open, allowing you to add garments.

The door lock icon on the display goes off

when the door lock is deactivated. After

adding garments, close the door and press

Start/Pause button once again to resume

the washing cycle.

If the water level in the machine is not suit-

able when you press Start/Pause button,

the door lock cannot be deactivated and

the door lock icon on the display remains

on.

If the temperature of the water in-

side the machine is above 50°C,

you cannot deactivate the door lock

for safety reasons, even if the water

level is suitable.

Switching the machine to pause mode:

Press the Start/Pause button to switch the

machine to pause mode. Pause symbol will

flash on the display.

EN / 39

Changing the programme selection after

programme has started:

The programme change is allowed when

the current programme is running unless

the Child Lock is enabled. This action will

cancel the current programme.

The selected programme starts

anew.

Changing the auxiliary function, speed

and temperature:

Depending on the step the programme has

reached, you can cancel or activate the

auxiliary functions. See “Auxiliary function

selection”

You can also change the speed and tem-

perature settings. See ‘’Spin speed selec-

tion" and "Temperature selection".

The loading door will not open if the

water temperature in the machine

is high or the water level is above

the loading door baseline.

6.17 Cancelling the Programme

The programme is cancelled when pro-

gramme selection knob is turned to a differ-

ent programme or machine is turned off

and on again using the programme selec-

tion knob.

If you turn the programme selection

knob when the Child Lock is en-

abled, the programme will not be

cancelled. You should cancel the

Child Lock first.

If you want to open the loading

door after you have cancelled the

programme but it is not possible to

open the loading door since the wa-

ter level in the machine is above

the loading door baseline, then turn

the Programme Selection knob to

Pump+Spin programme and drain

the water in the machine.

6.18 End of Programme

End symbol appears on the display when

the programme is completed.

If you do not press any button for 10

minutes, the machine will switch to OFF

mode. Display and all indicators are turned

off.

Completed programme steps will be dis-

played if you press any button.

6.19 Standby Mode

Your machine has the "Standby Mode" fea-

ture.

After turning the machine on with the On/

Off button, if no programme is started or no

other action is taken during the selection

phase, or if nothing is performed within ap-

proximately 2 minutes after the selected

programme is over, the machine automatic-

ally switches to energy saving mode. Fur-

thermore, if your product has a display that

shows the programme time, this display is

completely turned off. If you turn the pro-

gramme selection button or touch any but-

ton, the lights are illuminated and the

screen will turn on again. The choices you

make when exiting the energy saving state

may change.

Check your selections’ accuracy before

starting the programme. Adjust your set-

tings again if necessary. This is not an er-

ror.

6.20 HomeWhiz Feature and Remote

Control Function

HomeWhiz allows you to use your smart

device to check your washing machine and

get information about its status. With

HomeWhiz application you can use your

smart device to perform various procedures

that can also be performed on the machine.

Plus, you can use some features only with

the HomeWhiz function.

You must download the HomeWhiz applic-

ation from the app store of your smart

device to use the bluetooth feature of your

machine.

Make sure that your smart device is con-

nected to internet to install the app.

If you are using the app for the first time,

please follow the on-screen instructions to

complete your user account registration.

Once the registration procedure is com-

EN / 40

plete, you can use all products with the

HomeWhiz feature in your house on this

account.

You can touch the “Appliances” tab in the

HomeWhiz application to view appliances

paired with your account. Following the in-

stallation of the application, HomeWhiz

function enables the washing machine to

send you instant notifications via your

smart appliance.

In order to use the HomeWhiz func-

tion, the application must be in-

stalled on your smart appliance,

and your washing machine must be

paired with your smart appliance

via Bluetooth. If your washing ma-

chine is not paired with your smart

appliance, it will work like an appli-

ance without HomeWhiz feature.

Your product will work when it is

paired with your smart appliance

via Bluetooth. Controls that have

been made through the application

will be activated with this pairing.

Therefore, the strength of the

Bluetooth signal between the

product and the smart appliance

should be sufficient.

Please visit www.homewhiz.com link to

learn which Android and IOS ver-

sions are supported by HomeWhiz

application.

All safety measures described in

the "GENERAL SAFETY IN-

STRUCTIONS” titled section of the

user manual are also valid for re-

mote operation with HomeWhiz

function

6.20.1 HomeWhiz Setup

In order for the application to run, a con-

nection between your appliance and the

HomeWhiz Application must be estab-

lished. For this connection to be estab-

lished you must follow the steps below for

setup procedure on both the appliance and

the HomeWhiz Application.

a. If you are adding a device for the first

time, touch “Appliances” tab on the

HomeWhiz Application. Select “ADD

APPLIANCE” (touch here for setting up

a new appliance) button in the upper

right corner. Perform the setup by fol-

lowing both the steps below and the

steps in the HomeWhiz Application.

b. To start the setup, make sure that your

machine is turned off. Press and hold

the Temperature button and the Remote

Control Function button simultaneously

for 3 seconds to switch your machine to

HomeWhiz setup mode.

c. When the appliance is in HomeWhiz

setup mode, you will see an animation

on the display and the bluetooth icon

will flash until your machine gets paired

with smart device. Only programme

knob will be active in this mode. Other

buttons will be inactive.

d. Follow the instructions in display of

HomeWhiz application.

e. Wait until the installation is complete.

When setup is complete, give your

washing machine a name. Now, you

can tap and see the product you have

added in the HomeWhiz Aplication.

EN / 41

Your washing machine will auto-

matically turn off if you cannot real-

ize the setup successfully within 5

minutes. In this case, you have to

start the setup process all over

again. If the problem continues,

please contact the Authorised Ser-

vice.

You can use your washing machine

with more than one smart device.

To do this, download the Home-

Whiz app on the other smart device

as well. When you launch the app,

you will need to log in with the ac-

count you previously created and

paired your washing machine. Oth-

erwise, please read "Setting up a

washing machine that is connected

to someone else's account".

You need internet connection on

your smart device to proceed with

HomeWhiz setup. Otherwise, the

HomeWhiz application will not let

you finish the setup procedure suc-

cessfully. Please contact your inter-

net service provider if you are hav-

ing problems with your internet con-

nection.

HomeWhiz Application may require

you to type the product number

shown on the product label. You

can find the product label inside of

the appliance door. The product

number is located on this label.

6.20.2 Setting up a Washing

Machine Connected to

Someone Else's Account

If the washing machine that you want to

use has been previously registered to the

system with someone else's account, you

need to establish a new connection

between your HomeWhiz App and the ap-

pliance.

a. Download HomeWhiz Application on the

new smart device you want to use.

b. Create a new account and log in to this

account on the HomeWhiz app.

c. Follow the steps described in Home-

Whiz Setup (HomeWhiz Setup) and pro-

ceed with the setup procedure.

Since the HomeWhiz Feature and

Remote Control function on your

appliance is operated via pairing

using Bluetooth technology only

one Homewhiz application can op-

erate it at a time.

6.20.3 Remote Control Function

and Using It

After HomeWhiz setup, bluetooth will auto-

matically turn on. To activate or deactivate

the Bluetooth connection, please see

“Bluetooth 3”.

If you turn off and on your machine while

bluetooth is active, it will automatically re-

connect. In cases such as paired device

going off the range, bluetooth will automat-

ically turn off. For this reason, you will need

to turn on the bluetooth again if you want to

use the Remote Control function.

You can check the bluetooth symbol on the

display to track your connection status. If

the symbol is continuously on, you have

bluetooth connection. If the symbol is flash-

ing, the product is trying to connect. If the

symbol is off, you have no connection.

EN / 42

WARNING

If the Bluetooth connection is

turned on in your product, then the

Remote Control function can be se-

lected.

If the Remote Control function can-

not be selected, check the connec-

tion status. If the connection cannot

be established, repeat the initial

setup steps over the product.

For safety reasons, the product

door will be locked and remain

locked regardless of the operating

mode of the product when the Re-

mote Control function is activated.

If you want to open the door of the

product, you will need to turn the

programme selection knob or press

the remote control key to deactivate

the remote control function.

When you want to control your washing

machine remotely, after the front lid is

closed, you need to activate the Remote

Control function by pressing the Remote

Control button while the programme knob is

in the Download Programme/Remote Con-

trol position button on the control panel of

your washing machine. Once access is es-

tablished to the product, you will see a

screen similar to the one below.

When the Remote Control is enabled, you

can only manage the machine, turn it off

and follow the status through your washing

machine. And all functions except child lock

can be managed through the application.

You can follow whether the Remote Control

function is On or Off through the function

indicator on the button.

If the Remote Control function is Off, all the

operations are handled on the washing ma-

chine and only status follow-up is allowed

on the application.

In the event that Remote Start function can-

not be turned on, appliance will make a

warning sound when you press the button.

This might happen in cases such as when

the appliance is turned on and there is no

paired smart device via bluetooth.

Bluetooth settings being Off or the washing

machine's door being open are examples

for such cases.

Once you activate this function on the

washing machine, it will remain enabled

apart from certain conditions and allow you

to control your washing machine remotely

via bluetooth.

In certain cases, it deactivates itself for

safety reasons:

• When your washing machine undergoes

a power interruption.

• When programme knob is turned and a

different programme selected or appli-

ance is turned off.

6.20.4 Troubleshooting

Do the following if you have a problem with

controlling or connection. Observe whether

the problem persists or not after the action

you have performed.

a. Check whether your smart device is

connected to the relevant home net-

work.

b. Restart the product application.

c. Turn bluetooth off and then on via user

control panel.

d. If the connection cannot be established

with the above processes, repeat the

initial set-up settings on the washing

machine.

If the problem persists, consult an Author-

ised Service Agent.

EN / 43

7 Maintenance and Cleaning

Please read the “Safety Instruc-

tions” section first!

Service life of your product extends and fre-

quently experienced problems will be re-

duced if it is cleaned at regular intervals.

7.1 Cleaning the Detergent Drawer

Clean the detergent drawer at regular inter-

vals (once every 4 to 5 wash) as mentioned

below to prevent accumulation of powder

detergent.

Clean the syphon if excess amounts of wa-

ter and fabric softener mixture remains in

the softener compartment.

a. Press the marked part of the syphon

within the softener compartment and

then pull the drawer towards yourself to

take it out.

b. Lift and remove the syphon from behind

as shown.

c. Rinse drawer and syphon in the sink

with plenty of warm water. Use gloves or

suitable brush to prevent contact of

residues in the drawer with your skin.

d. Firmly fit the syphon and the drawer

back after cleaning.

7.2 Cleaning the Loading Door and

the Drum

For products with drum cleaning pro-

gramme, please see the Operating the

product section.

Repeat Drum Cleaning process in

every 2 months.

NOTICE: Use an anti-limescale

suitable for the washing machines.

After every washing make sure that no for-

eign substance is left in the product.

If the holes on the door gasket shown in the

figure is blocked, open the holes using a

toothpick.

Foreign metal substances will cause rust

stains in the drum. Clean the stains on the

drum surface by using cleaning agents for

stainless steel.

Never use steel wool or wire wool. These

will damage the painted, chrome coated

and plastic surfaces.

We recommend you to wipe the door gas-

ket with a dry and clean cloth at the end of

the programme. This will remove residues

on the door gasket in your machine and

prevent formation of malodours.

7.3 Cleaning the Body and Control

Panel

Wipe the body of the product with soapy

water or non-corrosive mild gel detergents

as necessary, and dry with a soft cloth.

Use only a soft and damp cloth to clean the

control panel. Do not use cleaning products

that contain bleach

7.4 Cleaning the Water Intake

Filters

There is a filter at the end of each water in-

take valve at the rear of the product and

also at the end of each water intake hose

where they are connected to the tap. These

filters prevent foreign substances and dirt in

the water to enter the product. Filters

should be cleaned if they are dirty.

EN / 44

a. Close the taps.

b. Remove the nuts of the water intake

hoses to access the filters on the water

intake valves and clean them with an

appropriate brush. If the filters are too

dirty, remove them from their places

with a pliers and clean in this way.

c. Take out the filters on the flat ends of

the water intake hoses together with the

gaskets and clean thoroughly under run-

ning water.

d. Replace the gaskets and filters carefully

and tighten their nuts by hand.

7.5 Draining Remaining Water and

Cleaning the Pump Filter

The filter system in your product prevents

solid items such as buttons, coins and fab-

ric fibres clogging the pump impeller during

draining of washing water. Thus, the water

will be drained without any problem and the

service life of the pump will extend.

If the product fails to drain water inside it,

the pump filter is clogged. Filter must be

cleaned whenever it is clogged or in every

3 months. Water must be drained off first to

clean the pump filter.

In addition, prior to transporting the product

(e.g., when moving to another house) water

should be drained completely.

NOTICE:

Foreign substances left in the pump

filter may damage your product or

may cause noise problem.

In regions where freezing is pos-

sible, the tap must be closed, sys-

tem hose must be removed and the

water inside the product must be

drained when the product is not in

use.

After each use, turn off the tap to

which the mains hose is connected.

In order to clean the dirty filter and drain

the water:

a. Unplug the product to cut off the supply

power.

Temperature of the water inside the

product may rise up to 90 ºC. To

avoid the risk of scalding, clean the

filter after the water inside the

product is cooled down.

b. Open the filter cover.

c. Follow the below procedures in order to

drain water.

If the product does not have an

emergency water draining hose, in order

to drain the water:

• Place a large container at the end of the

hose to collect the water from the filter.

• When the pump filter starts leaking water

loosen it by turning (opposite clockwise).

Fill the running water to the container you

placed in front of the filter. Keep a cloth

ready to clean the water that may spill.

EN / 45

• Completely turn and remove the pump fil-

ter when the water in the product leaks

out.

a. Clean any residues inside the filter as

well as fibres, if any, around the pump

impeller region.

b. Replace the filter.

c. If the filter cap is composed of two

pieces, close the filter cap by pressing

on the tab. If it is one piece, seat the

tabs in the lower part into their places

first, and then press the upper part to

close.

8 Troubleshooting

Please read the “Safety Instruc-

tions” section first!

Programmes do not start after the

loading door is closed.

• Start / Pause / Cancel button is not

pressed. >>> Press Start / Pause / Can-

cel button.

• It may be difficult to close the loading

door in case of excessive loading. >>>

Reduce the amount of laundry and make

sure that the loading door is closed prop-

erly.

Programme cannot be started or

selected.

• The product has switched to self-protec-

tion mode due to a supply problem (line

voltage, water pressure, etc.). >>> De-

pending on the product model, select an-

other program by turning the Program

Selection button or pressing and holding

the On/Off button for 3 seconds to cancel

the program. Previous programme will be

cancelled. See Cancelling the Pro-

gramme [}39]

Water inside the product.

• Some water has remained in the product

due to the quality control processes in

the production. >>> This is not a failure;

water is not harmful to the product.

The product does not take water in.

• Tap is turned off. >>> Turn on the taps.

• Water inlet hose is bent. >>> Flatten the

hose.

• Water inlet filter is clogged. >>> Clean

the filter.

• Loading door is not closed. >>> Close

the door.

The product does not drain water.

• Water drain hose is clogged or twisted.

>>> Clean or flatten the hose.

• Pump filter is clogged. >>> Clean the

pump filter.

Product vibrates or makes noise.

• Product is standing unbalanced. >>> Ad-

just the stands to balance the product.

• A hard substance has entered into the

pump filter. >>> Clean the pump filter.

• Transportation safety bolts are not re-

moved. >>> Remove the transportation

safety bolts.

• Laundry quantity in the product is too

little. >>> Add more laundry to the

product.

• Excessive laundry is loaded in the

product. >>> Take out some of the laun-

dry from the product or distribute the load

by hand to balance it homogeneously in

the product.

• Product is leaning on a rigid item. >>>

Make sure that the product is not leaning

on anything.

There is water leaking from the bottom

of the product.

• Water drain hose is clogged or twisted.

>>> Clean or flatten the hose.

• Pump filter is clogged. >>> Clean the

pump filter.

Product stopped shortly after the

programme started.

• Machine has stopped temporarily due to

low voltage. >>> Product will resume run-

ning when the voltage restores to the

normal level.

EN / 46

Product directly drains the water it takes

in.

• Draining hose is not at adequate height.

>>> Connect the water draining hose as

described in the user manual.

No water can be seen in the product

during washing.

• Water is inside the invisible part of the

product. >>> This is not a failure.

Loading door cannot be opened.

• Loading door lock is activated because of

the water level in the product. >>> Drain

the water by running the Pump or Spin

programme.

• Product is heating up the water or it is at

the spinning cycle. >>> Wait until the pro-

gramme completes.

• Loading door may be stuck because of

the pressure it is subjected to. >>> Grab

the handle and push and pull the loading

door to release and open it.

• If there is no power, loading door of the

product will not open. >>> To open the

loading door, open the pump filter cap

and pull down the emergency handle po-

sitioned at the rear side of the said cap.

See Loading Door Lock [}37]

Washing takes longer than specified in

the user manual. (*)

• Water pressure is low. >>> Product waits

until taking in adequate amount of water

to prevent poor washing quality due to

the decreased amount of water. There-

fore, the washing time extends.

• Voltage is low. >>> Washing time is pro-

longed to avoid poor washing results

when the supply voltage is low.

• Input temperature of water is low. >>>

Required time to heat up the water ex-

tends in cold seasons. Also, washing

time can be lengthened to avoid poor

washing results.

• Number of rinses and/or amount of rins-

ing water have increased. >>> Product

increases the amount of rinsing water

when good rinsing is needed and adds

an extra rinsing step if necessary.

• Excessive foam has occurred and auto-

matic foam absorption system has been

activated due to too much detergent us-

age. >>> Use recommended amount of

detergent.

Programme duration does not

countdown. (On models with display) (*)

• Timer may stop during water intake. >>>

Timer indicator will not countdown until

the product takes in adequate amount of

water. The product will wait until there is

sufficient amount of water to avoid poor

washing results due to lack of water.

Timer indicator will resume countdown

after this.

• Timer may stop during heating step. >>>

Timer indicator will not countdown until

the product reaches the selected temper-

ature.

• Timer may stop during spinning step.

>>> Automatic unbalanced load detec-

tion system is activated due to the unbal-

anced distribution of the laundry in the

product.

Programme duration does not

countdown. (*)

• There is unbalanced load in the product.

>>> Automatic unbalanced load detec-

tion system is activated due to the unbal-

anced distribution of the laundry in the

product.

Product does not switch to spinning

step. (*)

• There is unbalanced load in the product.

>>> Automatic unbalanced load detec-

tion system is activated due to the unbal-

anced distribution of the laundry in the

product.

• The product will not spin if water is not

drained completely. >>> Check the filter

and the draining hose.

• Excessive foam has occurred and auto-

matic foam absorption system has been

activated due to too much detergent us-

age. >>> Use recommended amount of

detergent.

EN / 47

Washing performance is poor: Laundry

turns gray. (**)

• Insufficient amount of detergent has been

used over a long period of time. >>> Use

the recommended amount of detergent

appropriate for water hardness and the

laundry.

• Washing has been made at low temper-

atures for a long time. >>> Select the

proper temperature for the laundry to be

washed.

• Insufficient amount of detergent is used

with hard water. >>> Using insufficient

amount of detergent with hard water

causes the soil to stick on the cloth and

this turns the cloth into gray in time. It is

difficult to eliminate graying once it hap-

pens. Use the recommended amount of

detergent appropriate for water hardness

and the laundry.

• Excessive amount of detergent is used.

>>> Use the recommended amount of

detergent appropriate for water hardness

and the laundry.

Washing performance is poor: Stains

persist or the laundry is not whitened.

(**)

• Insufficient amount of detergent is used.

>>> Use the recommended amount of

detergent appropriate for water hardness

and the laundry.

• Excessive laundry is loaded in. >>> Do

not load the product in excess. Load with

amounts recommended in the "Pro-

gramme and consumption table".

• Wrong programme and temperature were

selected. >>> Select the proper pro-

gramme and temperature for the laundry

to be washed.

• Wrong type of detergent is used. >>>

Use original detergent appropriate for the

product.

• Detergent was put in the wrong compart-

ment. >>> Put the detergent in the cor-

rect compartment. Do not mix the bleach-

ing agent and the detergent with each

other.

Washing performance is poor: Oily

stains appeared on the laundry. (**)

• Regular drum cleaning is not applied.

>>> Clean the drum regularly. For this

procedure, see --- MISSING LINK ---

Washing performance is poor: Clothes

smell unpleasantly. (**)

• Odours and bacteria layers are formed

on the drum as a result of continuous

washing at lower temperatures and/or in

short programmes. >>> Leave the deter-

gent drawer as well as the loading door

of the product ajar after each washing.

Thus, a humid environment favourable

for bacteria cannot occur in the machine

Colour of the clothes faded. (**)

• Excessive laundry was loaded in. >>> Do

not load the product in excess.

• Detergent in use is damp. >>> Keep de-

tergents closed in an environment free of

humidity and do not expose them to ex-

cessive temperatures.

• A higher temperature was selected. >>>

Select the proper programme and tem-

perature according to the type and soiling

degree of the laundry.

Washing machine does not rinse well.

• The amount, brand and storage condi-

tions of the detergent used are inappro-

priate. >>> Use a detergent appropriate

for the washing machine and your laun-

dry. Keep detergents closed in an envir-

onment free of humidity and do not ex-

pose them to excessive temperatures.

• Detergent was put in the wrong compart-

ment. >>> If detergent is put in the pre-

wash compartment although prewash

cycle is not selected, the product can

take this detergent during rinsing or

softener step. Put the detergent in the

correct compartment.

• Pump filter is clogged. >>> Check the fil-

ter.

• Draining hose is folded. >>> Check the

drain hose.

Laundry became stiff after washing. (**)

• Insufficient amount of detergent is used.

>>> Using insufficient amount of deter-

gent for the water hardness can cause

EN / 48

the laundry to become stiff in time. Use

appropriate amount of detergent accord-

ing to the water hardness.

• Detergent was put in the wrong compart-

ment. >>> If detergent is put in the pre-

wash compartment although prewash

cycle is not selected, the product can

take this detergent during rinsing or

softener step. Put the detergent in the

correct compartment.

• Detergent was mixed with the softener.

>>> Do not mix the softener with deter-

gent. Wash and clean the drawer with hot

water.

Laundry does not smell like the

softener. (**)

• Detergent was put in the wrong compart-

ment. >>> If detergent is put in the pre-

wash compartment although prewash

cycle is not selected product, the can

take this detergent during rinsing or

softener step. Wash and clean the

drawer with hot water. Put the detergent

in the correct compartment.

• Detergent was mixed with the softener.

>>> Do not mix the softener with deter-

gent. Wash and clean the drawer with hot

water.

Detergent residue in the detergent

drawer. (**)

• Detergent was put in wet drawer. >>>

Dry the detergent drawer before putting

in detergent.

• Detergent has gotten damp. >>> Keep

detergents closed in an environment free

of humidity and do not expose them to

excessive temperatures.

• Water pressure is low. >>> Check the

water pressure.

• The detergent in the main wash compart-

ment got wet while taking in the prewash

water. Holes of the detergent compart-

ment are blocked. >>> Check the holes

and clean if they are clogged.

• There is a problem with the detergent

drawer valves. >>> Call the Authorised

Service Agent.

• Detergent was mixed with the softener.

>>> Do not mix the softener with deter-

gent. Wash and clean the drawer with hot

water.

Detergent residue on the clothes.

• The machine might have been over-

loaded. >>> Do not overload the ma-

chine.

• Wrong programme and temperature were

selected. >>> Select the proper pro-

gramme and temperature for the laundry

to be washed.

• Wrong type of detergent might have been

used. >>> Select the proper detergent for

the laundry to be washed.

Too much foam forms inside the

product. (**)

• Improper detergents for the washing ma-

chine is used. >>> Use detergents appro-

priate for the washing machine.

• Excessive amount of detergent is used.

>>> Use only sufficient amount of deter-

gent.

• Detergent was stored under improper

conditions. >>> Store detergent in a

closed and dry location. Do not store in

excessively hot places.

• Some meshed laundry such as tulle may

foam too much because of their texture.

>>> Use smaller amounts of detergent

for this type of item.

• Detergent was put in the wrong compart-

ment. >>> Make sure you place the de-

tergent in the appropriate compartment.

• Softener is being taken early by the

product. >>> There may be problem in

the valves or in the detergent drawer.

Call the Authorised Service Agent.

Foam is overflowing from the detergent

drawer.

• Too much detergent is used. >>> Mix 1

tablespoonful softener and ½ l water and

pour into the main wash compartment of

the detergent drawer. >>> Put detergent

into the product suitable for the pro-

grammes and maximum loads indicated

in the “Programme and consumption

EN / 49

table”. When you use additional chemic-

als (stain removers, bleaches and etc.),

reduce the amount of detergent.

Laundry remains wet at the end of the

programme. (*)

• Excessive foam has occurred and auto-

matic foam absorption system has been

activated due to too much detergent us-

age. >>> Use recommended amount of

detergent.

Drying lasts too long.

• The machine might have been over-

loaded. >>> Do not overload the ma-

chine.

• Spinning might not be sufficient for laun-

dry. >>> Select a higher spin speed in

the washing step of the Washer-Dryer.

• Tap is turned off. >>> Turn on the taps.

Laundry comes off wet after the drying

step.

• The programme selected might not be

suitable for the type of laundry. >>>

Check the care labels on clothes and se-

lect a programme accordingly, or select

timed programmes additionally.

• The machine might have been over-

loaded. >>> Do not overload the ma-

chine.

• Spinning might not be sufficient for laun-

dry. >>> Select a higher spin speed in

the washing step of the Washer-Dryer.

Machine does not start or programme

cannot be started.

• Power cable might be unplugged. >>>

Make sure that the power cable is

plugged in.

• Programme might not be set, or the Start/

Pause/Cancel button might be not

pressed. >>> Make sure the programme

is set and the machine is not in Standby

mode.

• Child lock might be activated. >>> Dis-

able Child Lock.

Laundry shrinks, fades, tarnishes or

gets damaged.

• The programme selected might not be

suitable for the type of laundry. >>>

Check the care labels on clothes and se-

lect a programme accordingly, or select

timed programmes additionally. You

should not dry laundry that is not suitable

for drying.

Machine does not dry.

• Laundry might not be dried or the drying

step might not be enabled. >>> Check if

the drying function is selected after the

selected washing programme.

Loading door cannot be opened.

• The door of your machine might not be

opening due to safety reasons. >>> If the

door locked indicator is still active on the

display after the drying step, the machine

will keep the door locked for your safety

until it cools down.

• If there is no power, loading door of the

product will not open. >>> To open the

loading door, open the pump filter cap

and pull down the emergency handle po-

sitioned at the rear side of the said cap.

See Loading Door Lock [}37]

(*) The product does not switch to spinning

step when the laundry is not evenly distrib-

uted in the drum to prevent any damage to

the product and to its surrounding environ-

ment. Laundry should be rearranged and

re-spun.

(**) Regular drum cleaning is not applied.

Clean the drum regularly. See --- MISSING

LINK ---

If you cannot eliminate the problem

although you follow the instructions

in this section, consult your dealer

or the Authorised Service Agent.

Never try to repair a nonfunctional

product yourself.

Check the HomeWhiz section for

the relevant troubleshooting inform-

ation.

EN / 50

9 DISCLAIMER / WARNING

Some (simple) failures can be adequately

handled by the end-user without any safety

issue or unsafe use arising, provided that

they are carried out within the limits and in

accordance with the following instructions.

(See the “Self-Repair” section.)

Therefore, except for parts that are indic-

ated as they can be repaired by the end

users in the "Self-Repair" section, repairs

should strictly be done by the authorized

service station to avoid any safety issues

and it is mandatory to keep Grundig

product warranty valid.

Self-Repair

Self-repair can be done by the end-user

with regard to the following spare parts:

door, door hinge and seals, other seals,

door locking assembly and plastic peripher-

als such as detergent dispensers (an up-

dated list is also available in https://

www.grundig.com.tr/destek as of 1st of

March 2021).

Moreover, to ensure product safety and to

prevent risk of serious injury, the mentioned

self-repair shall be done following the in-

structions in the user manual for self-repair

or which are available in https://

www.grundig.com.tr/destek. For your

safety, unplug the product before attempt-

ing any self-repair.

The Grundig shall not be held responsible

for any safety problems that may arise due

to repairs or repair attempts by end users

that are not made in accordance with the

instructions specified in the manuals or at

https://www.grundig.com.tr/destek and on

the parts that are not included in the list of

up-to-date parts accessed from https://

www.grundig.com.tr/destek. In such a case,

the Grundig product warranty will be void.

Therefore, it is highly recommended that

end-users refrain from the attempt to carry

out repairs falling outside the mentioned list

of spare parts, contacting in such cases au-

thorised professional repairers or registered

professional repairers. On the contrary,

such attempts by end-users may cause

safety issues and damage the product and

subsequently cause fire, flood, electrocu-

tion and serious personal injury to occur.

By way of example, but not limited to, the

following repairs must be addressed to au-

thorised professional repairers or registered

professional repairers: motor, pump as-

sembly, main board, motor board, display

board, heaters etc.

The manufacturer/seller cannot be held li-

able in any case where end-users do not

comply with the above.

EN / 51

10GRUNDIG UK AND IRELAND STANDARD MANUFACTURER

GUARANTEE TERMS AND CONDITIONS

Your new Grundig product is guaranteed against faulty materials, defective components or

manufacturing defects.

The standard guarantee starts from the date of original purchase of the product and lasts for a period of

twenty four (24) months unless Beko plc (the “Manufacturer”) agrees to extend the guarantee for the

product in writing.

If you have purchased a Built-In/integrated product, the standard guarantee starts from the date of original

purchase of the product, and lasts for a period of thirty six (36) months unless Beko plc (the “Manufac-

turer”) agrees to extend the guarantee for the product in writing.

If you have registered Built-In/integrated product within 90 days of purchase by completing the online regis-

tration form, then the standard 36-month guarantee will be extended to 60 months, under the same terms

and conditions as detailed below.

If you have any questions about the guarantee on your product (including how long it is

valid), please contact your retailer or our contact centre on 0333 207 9920 (UK and North-

ern Ireland) or 01 691 0203 (Republic of Ireland)

This guarantee does not in any way diminish or affect your statutory rights in connection

with the product. This guarantee is in addition to your statutory rights as a consumer. If you

have any questions about these rights, please contact the retailer from which you pur-

chased the product. In certain circumstances, it is possible that your statutory rights may

offer additional or higher levels of protection than those offered under the terms of this

guarantee.

What is covered by this guarantee?

• Repairs to the product required as a result of faulty materials, defective components or

manufacturing defects.

• Functional replacement parts to repair a product.

• The costs of a Grundig Approved Engineer to carry out the repair.

What is not covered?

• Transit and delivery damage.

• Cabinet or appearance parts, including but not limited to control knobs, flaps and

handles.

• Accessories and/or consumable items including but not limited to ice trays, scrapers, cut-

lery baskets, filters and light bulbs.

• Repairs necessary as a direct or indirect result of:

– Accidental damage, misuse or abuse of a product.

– An attempted repair of a product by anyone other than a Grundig Approved Engineer

(the “Engineer”).

– Installation or use of a product where such installation or use fails to meet the require-

ments contained in this guarantee or the User Instructions Booklet.

• Repairs to a product operated at any time on commercial or non-residential household

premises (unless we have previously agreed to the installation environment).

This guarantee is limited to the cost of repairing the product. To the extent permitted by

law, the Manufacturer does not accept and will not be held liable for any financial loss in-

curred in connection with the failure of any product to operate in accordance with the ex-

pected standards. Such financial loss includes but is not limited to loss arising from:

• Time taken off work.

• Damaged food, clothing or other items.

• Meals taken at restaurants or from takeaways.

EN / 52

• General compensation for inconvenience.

Important Notes

1. Your product is designed and built for domestic household use only.

2. The guarantee will automatically be void if the product is installed or is used in com-

mercial or non-residential domestic household premises, unless we have previously

agreed to the installation environment.

3. The product must be correctly installed, located and operated in accordance with the

instructions contained in the User Instructions Booklet provided with your product.

4. Professional installation by a qualified Electrical Domestic Appliance Installer is recom-

mended for all Washing Machines, Dishwashers and Electric Cookers (as incorrect in-

stallation may result in you having to pay for the cost of repairing the product).

5. Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland

for Republic of Ireland) registered gas installer.

6. This guarantee is given in respect of products purchased and used within the United

Kingdom and the Republic of Ireland.

7. This guarantee is effective from the initial date of purchase of a new product from an

authorised retailer and will be void if the product is resold.

8. This guarantee does not apply to graded sales (where the product is purchased as a

“second”).

9. Possession of a copy of these terms and conditions does not necessarily mean that a

product has the benefit of this guarantee. If you have any questions, please call our

Call Centre on the number set out above.

10. The Manufacturer reserves the right to terminate the guarantee if its staff or represent-

atives are subjected to physical or verbal abuse in the course of carrying out their du-

ties.

11. Optional extras, where available (i.e. extendable feet) are supplied on a chargeable

basis only.

Does Grundig offer replacements?

This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion,

replace your product with a new product instead of carrying out a repair. Where a replace-

ment is offered, this would normally be an identical model but when this is not possible, a

model of similar specification will be provided. The Manufacturer will cover the costs and

arrange for the delivery of the new product and for the return of the old product. Any costs

related to disconnecting the faulty product and installing the replacement product will not

be borne by the Manufacturer unless previously agreed to in writing. The original guaran-

tee will continue to apply to the replacement product; the new product will not come with a

new guarantee.

When will the repair take place?

Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these

hours may be possible at the sole discretion of the Manufacturer but cannot be guaran-

teed. Whilst our Engineers will endeavour to minimize inconvenience and to meet requests

for specific timed appointments, this cannot be guaranteed. We will not be liable for delays

or if it is unable to carry out a repair because a convenient appointment cannot be ar-

ranged.

EN / 53

Will there be any charge for the repairs?

It is your responsibility to provide evidence to the Engineer that your product is covered by

this guarantee with a proof of purchase. The Manufacturer reserves the right to charge for

the reasonable cost of any service call if:

• You cannot provide evidence that your product is covered by this guarantee.

• Where a service call has been made and the engineer finds that there is no fault with

your product.

• That your product has not been installed or operated in accordance with the User In-

structions Booklet.

• That the fault was caused by something other than faulty materials, defective compon-

ents or manufacturing defects.

• For missed appointments.

Payment of these costs are due immediately upon the Engineer providing you with an in-

voice. The Manufacturer reserves the right to terminate the guarantee if you fail to pay the

costs for the service call in a timely manner.

If you are a resident of the United Kingdom, this guarantee will be governed by English law

and subject to the English Courts, save where you live in another part of the United King-

dom, in which case the law and courts of that location will apply.

If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law

and the Irish courts will have jurisdiction.

This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Hert-

fordshire. WD18 8QU. Beko plc is registered in England and Wales with company registra-

tion number 02415578.

GRUNDIG UK AND IRELAND PROSMART INVERTER MOTOR GUARANTEE TERMS

AND CONDITIONS

This 10-year guarantee relates to Grundig products that feature the Eco Inverter

Motor.

The Eco Inverter Motor guarantee terms and conditions are in addition to our Standard

guarantee terms and conditions detailed in the previous section.

In order to activate the 10 year guarantee you MUST register the appliance within 90 days of the original

purchase date. You can register by first visiting registermygrundig.co.uk and by following the online in-

structions.

Grundig Free standing appliances come with a 24-month parts and labour guarantee as

standard.

Grundig Built-in/integrated appliances come with a 36-month parts and labour guarantee

as standard, which can be extended to a 60 months parts and labour guarantee by regis-

tering within 90 days of the original purchase date.

To make a claim against your Grundig Eco Inverter Motor Guarantee (the “Guarantee”), all

customer and product details must be registered with Beko plc using the procedure out-

lined below.

1. This extra 7 or 8 years (or 5 years for Built-in appliances registered within 90 days of

the original purchase date) Guarantee is only effective after the expiration of the stand-

ard manufacturer’s guarantee.

2. It is only valid for the Eco Inverter motors of selected washing machines, washer-dry-

ers, tumble dryers and dishwashers. It does not cover any labour charge or any other

components of the product. In addition, it is only valid for one replacement of the Eco

Inverter motor during the extra 7 or 8 years (or 5 years for Built-in appliances re-

gistered within 90 days of the original purchase date) guarantee period.

EN / 54

3. To activate your guarantee, you MUST register your appliance within 90 days of the

original purchase date, by visiting registermygrundig.co.uk.

4. Customers will receive a unique reference code as proof of guarantee validation,

which must be quoted at the time of a claim being made.

5. Any repair/replacement of the Eco Inverter motor must only be carried out by an au-

thorised Grundig Service Agent (the “Service Agent”).

6. Labour for the repair/replacement of the Eco Inverter motor is not included in this guar-

antee and is chargeable directly by the Service Agent.

7. Any additional components fitted to the product at any time will not be covered by this

guarantee and will be chargeable directly by the Service Agent.

8. The guarantee is not transferable and cannot be exchanged for cash.

9. There are no alternative or additional offers to this Guarantee.

10. The guarantee is exclusive of the manufacturer’s standard guarantee

11. The Terms and Conditions shown above are in addition to the standard terms and con-

ditions of your product guarantee. Please read and refer to such Terms and Conditions

when making any claim.

12. We may use the information you provide for marketing purposes and to analyse your

purchasing preferences. We may keep your information for a reasonable period for

these purposes in accordance with the applicable Data Protection Laws and General

Data Protection Regulations (GDPR). You can opt into this service during the registra-

tion process. Further details are available at http://www.Grundig.co.uk/cookie-and-pri-

vacy.

13. These Terms and Conditions are governed by the laws of England and Wales; manu-

facturer: Beko plc, Beko House, 1 Greenhill Crescent, Watford WD18 8QU. Company

Registration Number: 02415578.

HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE

Please keep your purchase receipt or other proof of purchase details in a safe place; you

will need to have this documentation available should the product require attention under

guarantee.

Please take a few moments to complete the details below, as you will need this information when you call us, or to

use our online services. When you call us you may be required to input your serial number into your telephone

keypad. For help please visit grundig.co.uk/support/model-finder

• The product model number is printed on the Operating Instruction Booklet / User guide

• The product model and serial number is printed on the Rating Label affixed to the appli-

ance.

• The Retailer (Purchased from) and Date of purchase will be printed on your purchase re-

ceipt or other proof of purchase paperwork

Recording of these details alone will not count as proof of purchase. A valid proof of pur-

chase is required for requesting service under guarantee.

Model number Serial number Purchased from Date of purchase

For service under guarantee or for product advice please call our Contact centre

Before requesting service please check the troubleshooting guide in the Operating Instruc-

tions booklet, as a charge may be levied where no fault is found, and even though your

product may still be under guarantee.

EN / 55

After arranging service the area around the product must be easily accessible to the Engin-

eer, without the need for cabinets or furniture to be removed or moved.

It is your responsibility to ensure our Engineers have a clean and safe environment to carry

out any repairs.

Please have your Model number and Serial number available when you call us, as you may be required to input

your serial number into your telephone keypad during your call.

UK Mainland & Northern Ireland:

0333 207 9920

Landline or mobile calls to 0333 numbers cost no more than calls to geographic numbers

01 or 02, and are charged at the basic rate. Calls from landlines and mobiles are included

in free call packages but please check with your telephone service provider for exact call

charges.

Republic of Ireland:

01 691 0203

Service once the manufacturers guarantee has expired

If you have purchased an extended guarantee please refer to the instructions contained

within the extended guarantee agreement document, otherwise please call us using the

appropriate number above, where service can be obtained at a charge.

Should you experience any difficulty in obtaining service please call us on 0333 207 9920

or 01 691 0203

Send us a secure message through our online contact us form. Please visit our website,

click Contact Us and choose a product support topic from the list of options. Complete the

required details and click send message.

Product registrations

For UK registrations please visit registermygrundig.co.uk and for the Republic of Ireland

please call 01 514 3552†.

† Calls cost up to 9 cents a minute (plus call set up fee of 29 cents).

Grundig GD7510644U Washer Dryer HomeWhiz

Product's Documents

User Manual

Specifications

Grundig GD7510644U Questions and Answers
