TIMED WATERING:
Turn dial clockwise and align the desired
number of minutes with the TIME INDICATOR.
To turn o before time runs out, rotate the dial
back to “0” and push up on the release lever to
turn o.
MANUAL (NON TIMED) WATERING:
Depress the RELEASE LEVER and rotate dial
counter clockwise to “Manual On”. Water will stay
on unless you turn it o. Rotate back to “0” and
push up on release lever to turn water o.
RIEGO CON TEMPORIZADOR:
Gire el selector en dirección de las manecillas del
reloj y alinee el número deseado de minutos con
el INDICADOR DE TIEMPO. Antes de que se
termine el tiempo, gire el selector a “0” y presione
la palanca de liberación para apagarlo.
RIEGO MANUAL
(SIN TEMPORIZADOR):
Baje la PALANCA DE LIBERACIÓN y gire el
selector en dirección contraria a las manecillas
del reloj a la posición “Manual On”. El sistema de
riego permanecerá encendido a menos que lo
apague. Gire el selector a “0” y presione la
palanca de liberación para apagarlo.
Dial
El Selector
Release Lever
Palanca de Liberación
