IMPORTANT SAFETY PRECAUTIONS
Hot Chocolate Maker
& Milk Frother
Instruction manual
READ ALL
INSTRUCTIONS
BEFORE USING THE APPLIANCE.
KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
IMPORTANT
SAFEGUARDS
• THIS IS AN ATTENDED APPLIANCE. Do not leave unattended
during use, unplug after each use (risk of re if an unattended
appliance is left operating).
• This appliance must not be used by children younger than 8 years old or
persons with very extensive and complex disabilities. Children aged 8-14
years and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge shall not use this appliance, unless they
are supervised and have been given instruction concerning the use of the
appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made
by children unless they are older than 8 and supervised. Keep the appliance
and its cord out of reach of children less than 8 years old. Risk of re,
electric shock, scalding or injury to persons.
• This appliance is intended for indoor household use only. If the appliance is
used improperly or for professional or semi-professional purposes or if it is
not used according to these instructions the Guarantee becomes invalid and
Dualit refuses any liability for damage caused.
Electrical Safety
• Ensure that the voltage of the appliance corresponds to that of the mains
supply. Risk of electric shock and re.
• WARNING: This appliance must be earthed. Risk of electric shock and
re.
• In order to avoid a hazard, if the Power Cord is damaged it must, for
safety reasons, be replaced by Dualit or a qualied electrician. Call Dualit’s
Customer Helpline on +44 (0) 1293 652 500. Risk of electric shock and
re.
• Do not operate any appliance with a damaged Power Cord or Plug, or after
the appliance malfunctions or has been dropped, damaged or cracked in any
manner. Risk of re, electric shock and re.
• This appliance conforms to directive 2014/30/EU regarding electromagnetic
compatibility.
• Never touch the Power Cord with wet hands. Risk of electric shock.
• Never use the plug without the fuse cover tted. Ensure replacement fuse
is the same current value as the original. Replacement fuses are available and
should be ASTA approved to BS1362. Risk of electric shock and re.
• Never plug an appliance into a socket/outlet with other appliances
connected to it or a socket/outlet with additional features such as, but not
limited to, USB sockets, built-in Wi-Fi boosters, remote
Wi-Fi/Bluetooth or similar smart switching functionality. Failure to do this
may cause an overload, trip a circuit breaker or blow a fuse. Risk of electric
shock and re or damage to socket/outlet and plug. The socket/outlet
should be protected by a Residual Current Device (RCD).
• The use of extension cables is not authorised by the manufacturer and may
cause damage or accidents. Risk of electric shock.
General Safety
• The use of accessory attachments not recommended by Dualit may result in
re, electric shock or injury to persons.
• Do not touch the metal body when the appliance is in use. Risk of burns
or scalding.
• Do not place the appliance on a polished wood, marble or porous surface.
Risk of property damage.
• Do not operate on an uneven surface. Risk of injury.
• Do not use a scouring pad or abrasive cleaner on the appliance body. Risk
of damage.
• CAUTION: To prevent damage to the appliance do not use alkaline cleaning
agents when cleaning, use a soft cloth and a mild detergent. Risk of damage.
• Unplug the appliance from the mains to allow to cool before cleaning,
maintaining or moving. Caution: Hot liquid. For details, please refer to
cleaning section. Risk of re, electric shock, scalding or injury to
persons.
• The Power Cord should not be allowed to come into contact with hot
surfaces. Risk of electric shock.
• A short Power Cord is provided to reduce risks resulting from becoming
entangled in or tripping over a longer cord. Risk of injury and electric
shock.
• Do not place the appliance over or close to sources of heat such as electric
rings, hot ovens or open ames. Risk of electric shock and re.
• The appliance shall not be placed in a cabinet or appliance garage when in use.
Risk of re.
• NOTE: Any plug cut from the power supply cord should be disposed of
immediately. Inserting any cut off plug into a 13A socket-outlet is hazardous.
Risk of electric shock and re.
• To be protected against electrical hazards, re and injury to persons, do not
immerse the power cord, plug or appliance in water or any other liquid. Risk
of electric shock.
• Avoid spilling any liquid on the connector. Risk of electric shock.
• Only use the appliance with the Power Base supplied. Risk of electric
shock and re.
• Allow the Milk Frother to cool down completely before cleaning and storing.
Risk of burns or scalding.
• Do not ll above the ‘Max’ mark. Risk of electric shock and burns.
• Do not use in bathroom or outdoors. Risk of electric shock.
• Remove the appliance from its Power Base before lling or pouring. Risk of
electric shock.
• Take care when pouring – pour slowly and do not over-tilt the Milk Frother.
Risk of burns or scalding.
• Milk will remain hot for a considerable amount of time after heating and can
present a scald hazard. Keep the Jug, Power Base and the mains lead
away from the edge of worktops and out of reach of children.
• Heating element surface is subject to residual heat after use. Risk of
scalding.
• Do not misuse the appliance; it is designed for use with milk and food items
only. Risk of injury.
• Do not allow cable to touch hot surfaces, or to hang over edge of a table or
counter top. Risk of re or electric shock.
BEFORE FIRST USE
• Read this instruction manual before you start using the appliance. It gives you
important safety information and will ensure you get the most out of your
Dualit product.
• Unpack the box with care, keeping all the packaging materials until you are
satised everything is present and in working order. Once satised recycle the
packaging appropriately.
• Keep this manual and your proof of purchase in a safe place.
• Don’t forget to register your product at www.dualit.com/register
• Remove all packaging before use. Risk of re.
SAVE THESE
INSTRUCTIONS
In the interest of improving products, Dualit Ltd. reserves the right to change the product
specication without prior notice. All illustrations are for representation only, your model
may vary from illustrations shown.
INSTRUCTIONS ON ENVIRONMENT
PROTECTION
Do not dispose of this product in the usual household waste at the
end of its life cycle. Please hand it over to a collection point for the
recycling of electrical and electronic appliances. The symbol on the
product, the instruction of use or the packaging will inform you
about the methods of disposal. The materials are recyclable as
mentioned on its marking. By recycling, material recycling or other
forms of re-utilization of old appliances you are making an important contribution
to protect our environment. Please enquire with the Local Authority for the
authorised disposal location.
REGISTER YOUR PRODUCT FOR THE CHANCE TO
WIN A £225 PRIZE DRAW!
DON’T FORGET TO
REGISTER YOUR PRODUCT
WWW.DUALIT.COM/REGISTER
OR BY POST
DON’T FORGET
TO REGISTER
YOUR PRODUCT
WWW. DUALIT.COM/REGISTER
OR BY POST
APPLIANCE DOES NOT TURN ON
1. Appliance is not plugged in. 1. Check that the plug is in the socket and the switch is turned on.
2. The plug fuse may have failed. 2. Replace the 5 amp plug fuse if necessary and check your residual current device (RCD). Never use the plug without the fuse cover tted. Ensure
replacement fuse is the same current value as the original. Replacement fuses are available and should be ASTA approved to BS.1362.
3. Heating element is broken or thermal fuse
has been activated.
3. Please contact Dualit Customer Services
+
for further help.
4. Jug is still warm from previous cycle. 4. Between cycles, pour cold water into the Jug and allow to cool.
NON-STICK COATING IS DAMAGED
1. The milk has overheated after the cycle. 1.1 Ensure that the milk level is within the minimum and maximum ll markings to avoid overheating and damaging the non-stick coating.
1.2 Do not lift the Jug before the cycle is completed to avoid overheating and damaging the non-stick surface.
2. Non-stick coating damaged when cleaning. 2. Do not use abrasive cloths or insert sharp objects when cleaning the inside of the Jug.
LARGE AMOUNT OF CHOCOLATE RESIDUE LEFT INSIDE JUG AFTER CYCLE
1. Chocolate is not melting and mixing into
the milk.
1.1 Chocolate should be added after the Whisk with Basket attachment and milk have been placed into the Jug.
1.2 We recommend using cold milk straight from the fridge, to improve melting efciency for chocolate beverages.
1.3 Use less chocolate or break into smaller pieces. Using chocolate with lower cocoa content will reduce/eliminate chocolate residue.
1.4 Do not turn the device off when cycle is in progress. This will reduce chocolate melting time and increase the chance of residue build-up.
1.5 Leave the device for 1 minute after a completed cycle to allow longer melting time. Move the Whisk up and down to encourage melting.
1.6 Ensure the device is allowed to cool fully between cycles.
WHISK IS NOT SPINNING OR IS NOISY WHEN SPINNING
1. Whisk has misaligned from motor. 1.1 Remove the Whisk from the Jug and re-insert. This should allow the Whisk to rotate normally and to eliminate noise.
1.2 Ensure that the Jug and all attachments are clean before using as any residue can disrupt the magnetisation and centralisation of the Whisk.
2. The chocolate segments have knocked the
Whisk out of place.
2. Remove the attachments from the Jug and re-insert. Always use the Basket attachment when making chocolate beverages.
3. Attachments are not properly afxed. 3. If using the Basket or Flat White Cap, slide onto the Whisk and push down until it clicks into place.
4. Milk/chocolate has dried onto the Whisk,
Flat White Cap or Basket.
4. Check the Whisk, Flat White Cap and Basket spin freely before using your device (remove the Whisk and use your nger to spin). Any residue may
affect functionality. Ensure the Jug and all accessories are clean before use and before storing.
THE POWER BUTTON IS FLASHING BUT THE DEVICE WILL NOT TURN
1. The boil-dry feature has been activated. 1. This feature protects the device if it gets too hot. Wash the Jug with cold water and make sure to ll above the MIN line when adding milk.
TROUBLESHOOTING
+
TO CONTACT CUSTOMER SERVICES, PLEASE EMAIL INFO@DUALIT.COM WITH YOUR MODEL AND SERIAL NUMBERS.
GB-B
TO REPLACE FUSE: REMOVE
SILVER LABEL TO ACCESS
SCREW OR REMOVE COVER.
GENERAL
• Always use cold milk straight from the fridge.
• The Milk Frother works best with milk that has a high protein level e.g. dairy or soya.
• Dualit recommends using semi-skimmed or UHT milk. Full fat milk will not froth well as the fat content
is greater than 3%. Remember, different milks froth at different rates.
• When using plant-based milk such as soya, oat, almond etc., make sure to use ‘barista-grade’ as these
varieties will produce more froth.
CHOCOLATE
• Breaking the chocolate into smaller pieces will ensure it melts more efciently and reduces residue.
• If you nd chocolate residue in the Jug after serving, on next use wait 1 minute after the cycle has
nished, before pouring.
• Choosing a chocolate with a lower cocoa content will reduce the amount of residue as it has a lower melting point.
• If you nd chocolate residue on the Basket after frothing, move the Whisk up and down while submerged in the hot milk, until it has
melted.
• Check that the Whisk and Basket spin freely before using your device. Any residue may affect functionality. Ensure the Jug and all
Attachments are clean before use and before storing.
• If you prefer a sweeter chocolate drink, add up to 50g of chocolate. Note this may increase the amount of residue.
• You can make two Chocolate Milkshakes at the same time; divide the volume of liquid between two cups and add 70g of ice per cup.
DRINK WHISK ATTACHMENT MILK FROTHER INGREDIENTS METHOD
FLAT WHITE
⅓ espresso, ⅔ heated milk
Flat White Cap 225ml-325ml cold milk
Place Whisk with any required
Attachment in Jug then add milk.
Press the Power Button. While frothing
brew coffee and add to a cup. Pour
frothed milk into your cup when ready.
LATTÉ
Espresso shot, heated milk,
thin layer of froth
Basket 225ml cold milk
CAPPUCCINO
Equal parts espresso,
heated milk, frothed milk
Whisk only 180ml cold milk
HOT CHOCOLATE Basket
225ml cold milk
+ 25g-35g chocolate*
Place Whisk with
Basket Attachment
into Jug. Add milk and
chocolate/coffee. Press
the Power Button. Pour
frothed drink into your
cup when ready.
MOCHA WITH
INSTANT COFFEE
Basket
225ml cold milk + 25g-35g chocolate*
+ 1 x serving instant coffee
MOCHA WITH
ESPRESSO
Basket
225ml cold milk + 25g-35g chocolate*
+ 1 x shot espresso
MILKSHAKE Whisk only 120ml cold milk
First add a handful of ice and 100ml of
cold milk, into a large glass. Place the
Whisk into the Jug and add 120ml of
milk. Press the Power Button. Pour
frothed milk into your glass when ready.
CHOCOLATE
MILKSHAKE
Basket
225ml cold milk
+ 25g-35g chocolate*
Attach the Basket to the Whisk and
place in the Jug. Add 225ml of milk and
the chocolate. Press the Power Button.
While frothing, add a handful of ice to a
large glass. Pour frothed chocolate milk
into your glass when ready.
*The Milk Frother is designed to be used with a wide range of chocolate. For best results we recommend using chocolate akes,
though you can use chocolate segments no larger than 1cm² and 0.5cm thick, powder or buttons no smaller than 1cm diameter
and 0.5cm thick. Use pure chocolate only, with no added ingredients such as nuts, raisins, biscuit, coconut, caramel, wafer, nougat etc.,
as they may block the whisk. You may need to chop the chocolate to the recommended sizes. Note: Deviating from the recommended
ingredients can affect the volume of beverage produced and performance of your appliance. Never ll above the ‘Max’ or under
the ‘Min’ ll volumes.
WHISK ASSEMBLEY OPTIONS
FLAT WHITE CAP BASKET WHISK ONLY
Remove all packaging,
tape and protective paper.
BEFORE FIRST USE: Clean
the Lid, Attachments and
inside of Jug with warm,
soapy water, rinse well then
dry. Do not immerse. Risk
of electric shock, re
and product damage.
The surface must be at in order to keep the machine level and
stable. Risk of injury. Position in a safe space away from:
• Heat sources. Risk of electric shock and re.
• Water taps. Risk of electric shock.
Do not position:
• In a cupboard. Risk of re.
• Close to curtains or ammable material. Risk of re.
• On a tray that collects liquid. Risk of electric shock.
• On a polished wood, marble or porous surface. Risk of
property damage.
1
2 3
Register your appliance on
www.dualit.com. This
will only take 60 seconds.
You will need the product
model and serial numbers
that are on the rating label
on the base of the product.
SCAN TO
REGISTER
SETTING UP YOUR MILK FROTHER
KNOW YOUR MILK FROTHER
USING AND CLEANING YOUR MILK FROTHER
HINTS AND TIPS
QUICK REFERENCE GUIDE
You can make a wide variety
of drinks in your Milk Frother.
It is important to follow the
instructions, use the correct
Whisk Assembly and ll to the
correct Fill Markings on the Jug
to achieve perfect results.
FLAT WHITE CAP
+
WHISK
BASKET
+
WHISK
WHISK
Click Click
FAILURE TO CLEAN YOUR MILK FROTHER AS PER INSTRUCTIONS WILL INVALIDATE YOUR GUARANTEE AND CAUSE
DAMAGE TO YOUR PRODUCT.
1
MIN
2 3 4
WARNING: Clean immediately
after each use. Unplug, remove
Jug from Power Base and remove
the Whisk and Attachments.
Clean inside of Jug, Whisk and
Attachments with warm, soapy
water and a non-abrasive cloth.
Rinse with cold water. Wipe
exterior with a damp, non-
abrasive cloth. Never immerse
the Jug or Power Base in water.
Risk of electric shock, re
and product damage.
NOTE: If you are using the
the Milk Frother for multiple
cycles consecutively, you will
need to allow time for the
Jug to cool. After 2 cycles ll
the Jug with cold water and
stand for 1 minute before
discarding. Repeat after each
additional cycle.
The Whisk and Attachments
only may be placed in the
dishwasher. Use a wash cycle
below 40°C and place on the
top shelf. If you have nished
using the Milk Frother, dry
thoroughly before storing
with the Lid in place.
1
Select your drink from the
Quick Reference Guide.
Assemble the Whisk if required
and place in the Jug. Fill Jug to
the specied volume according
to the Guide, with cold milk
straight from the fridge. Add
chocolate and/or coffee if
using. Press the Power Button.
When the cycle has nished,
the Power Button light will go
out. Pour and enjoy.
U
N
P
L
U
G
W
H
E
N
N
O
T
I
N
U
S
E
40 C
JUG
LID
BASKET FLAT WHITE
CAP
ATTACHMENTS
WHISK
POWER BUTTON
POWER CORD
PLUGPOWER BASE
U
N
P
L
U
G
W
H
E
N
N
O
T
I
N
U
S
E
SCAN FOR
MORE RECIPES
SHOP HOT
CHOCOLATE
