FIG. PART NO.
*1 22-64-0785
2 44-76-0050
*3 31-44-1116
4 06-55-l 050
5 05-78-0305
6 23-66-l 805
7 06-82-7409
8 06-82-2568
*9 31-44-l 711
10 06-82-2598
11 42380190
12 06-82-7375
13 40-50-7770
14 22-22-1325
15 22-l 8-0680
16 23-44-0210
* 17 12-20-0231
18 22-84-0710
19 45-04-0720
20 31-70-0125
* 21 31-50-0555
22 02-04-0845
23 18-50-0090
24 22-20-0660
25 16-50-0130
27 02-04-l 229
28 28-28-l 565
29 32-02-3020
30 02-04-0910
DESCRITPION OF PART
Cord Set
Cord Protector
Left Handle Half
1 O-24 Hex Nut
Switch Screw T-15
Switch
8-16 x l/2” Pan Hd. Plast. T-20
1 O-24 x 7/8” Sk. Pan Hd. T-25
Right Handle Half
1 O-24 x 2-314” Sk. Pan Hd. T-25
Bumper
8-16 x 2-l/2” Taptite T-20
Brush Holder Spring
Brush Holder Assembly
Carbon Brush Assembly
Brush Retaining Screw
Service Nameplate Kit
Fan
Shoulder Screw
Tool Rest
Motor Housing
Ball Bearing
120 Volt Field
Brush Tube
120 Volt Armature
Ball Bearing
Diaphragm
Armature Gear
Ball Bearing
NO. REQ.
(1)
(1)
(1)
(5)
(4)
(1)
(1)
(3)
(1)
(2)
(1)
(2)
(2)
(2)
(2)
(2)
(1)
(1)
(2)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
(1)
(1)
(1)
FIG. PART NO.
31 32-75-3030
32 28-50-6190
33 06-82-7407
34 38-50-5330
35 02-04-l 229
36 34-80-2600
37 06-42-0400
38 43-34-O 195
39 49-l 2-0280
40 _______ --
41 43-34-0190
42 06-55-2475
49-96-4050
49-96-4075
DESCRITPION OF PART
NO. REQ.
Spindle Gear
(1)
Spindle Housing
(1)
10-14 x l-9/16” Pan Hd. T-25
(4)
Spindle Shaft
(1)
Ball Bearing
(1)
Internal Retaining Ring
(1)
Woodruff Key
(1)
Inner Wheel Flange
(1)
Wheel Guard
(1)
3” Grinding Wheel(Select from Catalog) (1)
Outer Wheel Flange
(1)
3/8 - 24 Hex Nut
(1)
g/16” Open End Wrench
(1)
1 “Open End Wrench
(1)
FIG. LUBRICATION
31 314 Oz. Type “D” Grease, No. 49-08-4110.
