DOUBLE BURNER
Model Number: 104555
UPC: 681131045551
Customer Assistance
1-855-451-2897 (US)
Please consider the option to recycle the packaging material and donate any
appliance you are no longer using.
Double Burner_104555_IM_US_V2_121204.indd 1 12/4/12 10:07:39 AM
2
3
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed
to prevent the risk of re, electric shock, burns, or other injuries or damages:
Read all instructions before use.•
Do not touch hot surfaces. Use handles or knobs.•
To protect against electrical shock do not immerse cord, plugs, or the appliance •
in water or other liquids.
Close supervision is necessary when any appliance is used by or near children.•
Unplug from outlet when not in use and before cleaning. Allow it to cool before •
putting on or taking o parts and before cleaning the appliance.
Do not operate appliance with a damaged cord or plug, or after the appliance •
malfunctions or has been dropped or damaged in any manner. Call our
tollfree customer assistance number for information on examination, repair, or
adjustment.
The use of accessory attachments not recommended by the appliance •
manufacturer may cause injuries.
Do not use outdoors or in a damp area.•
Do not let cord hang over edge of table or counter, or touch hot surfaces.•
Do not place on or near a hot gas or electric burner, or in a heated oven.•
Extreme caution must be used when moving an appliance containing hot oil or •
other hot liquids. Do not move during operation.
To disconnect, turn the control dial fully counterclockwise to position • (ill.
d
),
then remove plug from the wall outlet.
Do not use this appliance for anything other than its intended use.•
This appliance is for • HOUSEHOLD USE ONLY.
SAvE THESE INSTRUCTIONS!
ADDITIONAL SAFEGUARDS
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
Extension cords
A short power-supply cord is to be provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. Longer detachable power-
supply cords or extension cords are available and may be used if care is exercised in
their use. If a longer detachable power-supply cord or extension cord is used,
The marked electrical rating of the cord set or extension cord should be at least •
as great as the electrical rating of the appliance, and
The extension cord should be a grounding-type 3-wire cord, and•
The longer cord should be arranged so that it will not drape over the countertop •
or tabletop where it can be tripped over, snagged, or pulled on unintentionally
(especially by children).
Grounding instructions
This appliance must be grounded while in use.
CAUTION: To ensure continued protection against risk of electric shock, connect to
properly ground outlets only.
Grounding instructions – US only
The appliance has a plug that looks like Figure A. An adaptor, as shown in Figure B,
should be used for connecting a 3-prong grounding plug to a 2-wire receptacle. The
grounding tab, which extends from the adaptor, must be connected to a permanent
ground such as a properly grounded receptacle as shown in Figure C, using a metal
screw.
Double Burner_104555_IM_US_V2_121204.indd 2 12/4/12 10:07:40 AM
2
3
ADDITIONAL SAFEGUARDS
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
Extension cords
A short power-supply cord is to be provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. Longer detachable power-
supply cords or extension cords are available and may be used if care is exercised in
their use. If a longer detachable power-supply cord or extension cord is used,
The marked electrical rating of the cord set or extension cord should be at least •
as great as the electrical rating of the appliance, and
The extension cord should be a grounding-type 3-wire cord, and•
The longer cord should be arranged so that it will not drape over the countertop •
or tabletop where it can be tripped over, snagged, or pulled on unintentionally
(especially by children).
Grounding instructions
This appliance must be grounded while in use.
CAUTION: To ensure continued protection against risk of electric shock, connect to
properly ground outlets only.
Grounding instructions – US only
The appliance has a plug that looks like Figure A. An adaptor, as shown in Figure B,
should be used for connecting a 3-prong grounding plug to a 2-wire receptacle. The
grounding tab, which extends from the adaptor, must be connected to a permanent
ground such as a properly grounded receptacle as shown in Figure C, using a metal
screw.
Grounding prong
Circuit grounding conductor
connected properly
(A)
Metal mounting
screw
Cover of grounded
outlet box
(C)
Adapter
(B)
Grounding means
Double Burner_104555_IM_US_V2_121204.indd 3 12/4/12 10:07:40 AM
4
5
PARTS
1
2
3
8
4
5
7 6
Die-cast heat plate1.
Heat plate ring2.
Power plug3.
Housing unit4.
Non-skip rubber feet5.
Temperature control 6.
dial (main dial positions:
, LOW, HIGH)
Work indicator light7.
Power-on indicator light8.
ILLUSTRATIONS
Double Burner_104555_IM_US_V2_121204.indd 4 12/4/12 10:07:40 AM
4
5
ILLUSTRATIONS
a
c
b
5” 12cm
5” 12cm
5”
12cm
5”
12cm
d
e
f
h
i
g
j
k
Double Burner_104555_IM_US_V2_121204.indd 5 12/4/12 10:07:41 AM
6
7
OPERATION
Before rst use
Remove all packaging materials, labels and/or stickers from your double burner.•
Clean your double burner thoroughly before using for the rst time (• Cleaning).
NOTE: Due to the manufacturing process, the double burner may emit a slight
burning odor when it is rst activated. Use the double burner in a well-ventilated
area, select the highest setting (ill.
e
), and allow it to sit for a few minutes without
any cooking utensils.
Operating instructions
This unit is intended for gently boiling water and is not intended to braise, brown
or fry foods. There are 2 heat plate rings on the appliance. The larger die-cast heat
plate is rated at 900W. The smaller die-cast heat plate is rated at 600W. Use the
larger die-cast heat plate for fast cooking, and use the small die-cast heat plate for
simmering or warming.
Before plugging in your double burner, check to ensure that the electrical circuit is
not overloaded with other appliances. This appliance should always be operated on
a separate 120V~ 60Hz, AC outlet.
Place the double burner on a at, even, and heat-resistant countertop surface.•
Be sure to leave at least 5 inches of space around the appliance for proper •
ventilation (ill.
a
).
Insert the plug • (3) into the wall outlet. The blue power-on indicator light (8)
illuminates immediately (ill.
b
).
Put a pot or pan on the center of one die-cast heat plate • (1) (ill.
c
). Always use
a pot or pan the same size as the die-cast heat plate (ill.
j
). Do not use pots or
pans that are unstable and easily tipped (ill.
h
+
k
).
Turn the temperature control dial • (6) clockwise from the o position to the
desired setting (from LOW to HIGH) (ill.
e
). When one die-cast heat plate is
working, the red work indicator light (7) beside the working die-cast heat plate
illuminates.
When you are done, turn the temperature control dial • (6) to o position
(ill.
d
).
When not in use, unplug the double burner from the wall outlet to make sure •
that it is completely o. The power-on indicator light (8) goes o. This helps
prevent accidental burns.
Double Burner_104555_IM_US_V2_121204.indd 6 12/4/12 10:07:41 AM
6
7
OPERATION
Before rst use
Remove all packaging materials, labels and/or stickers from your double burner.•
Clean your double burner thoroughly before using for the rst time (• Cleaning).
NOTE: Due to the manufacturing process, the double burner may emit a slight
burning odor when it is rst activated. Use the double burner in a well-ventilated
area, select the highest setting (ill. ), and allow it to sit for a few minutes without
any cooking utensils.
Operating instructions
This unit is intended for gently boiling water and is not intended to braise, brown
or fry foods. There are 2 heat plate rings on the appliance. The larger die-cast heat
plate is rated at 900W. The smaller die-cast heat plate is rated at 600W. Use the
larger die-cast heat plate for fast cooking, and use the small die-cast heat plate for
simmering or warming.
Before plugging in your double burner, check to ensure that the electrical circuit is
not overloaded with other appliances. This appliance should always be operated on
a separate 120V~ 60Hz, AC outlet.
Place the double burner on a at, even, and heat-resistant countertop surface.•
Be sure to leave at least 5 inches of space around the appliance for proper •
ventilation (ill. ).
Insert the plug • (3) into the wall outlet. The blue power-on indicator light (8)
illuminates immediately (ill. ).
Put a pot or pan on the center of one die-cast heat plate • (1) (ill. ). Always use
a pot or pan the same size as the die-cast heat plate (ill. ). Do not use pots or
pans that are unstable and easily tipped (ill. + ).
Turn the temperature control dial • (6) clockwise from the o position to the
desired setting (from LOW to HIGH) (ill. ). When one die-cast heat plate is
working, the red work indicator light (7) beside the working die-cast heat plate
illuminates.
When you are done, turn the temperature control dial • (6) to o position
(ill. ).
When not in use, unplug the double burner from the wall outlet to make sure •
that it is completely o. The power-on indicator light (8) goes o. This helps
prevent accidental burns.
OPERATION
CAUTION: This appliance generates heat and steam during use. Proper precautions
must be taken to prevent the risk of burns, res, or other injury to persons or
damage to property.
CAUTION: The metal surfaces of the double burner and pots/pans will get hot. Do
not touch while in use (ill.
i
). Allow the appliance to cool for at least 30 minutes
before handling.
CLEANING
Proper maintenance will ensure many years of service from your appliance.
Clean the double burner after every use. This appliance contains no user serviceable
parts and requires little maintenance. Leave any servicing or repairs to qualied
personnel.
CAUTION: Before cleaning and storing, turn the temperature control dial (6) to the
fully counterclockwise position (ill.
d
). Unplug the double burner from the wall
outlet to prevent electric shock, and let the double burner cool down completely.
Use a damp, soapy cloth or sponge to clean the surface of the double burner •
(ill.
g
).
Kind of soiling Procedure
light soiling wipe with a damp cloth or sponge
sticky soiling scrape o and wipe with a damp cloth
lime residue
(caused by over boiling water)
remove with vinegar or a mild
detergent
Do not use chemical abrasive cleaners, steel wool, or scouring pads.•
Wipe soap completely from the die-cast heat plate • (1) and heat plate ring (2)
after cleaning.
WARNING: Never immerse the appliance in water or other liquids.
Double Burner_104555_IM_US_V2_121204.indd 7 12/4/12 10:07:41 AM
8
CUSTOMER ASSISTANCE
If you have a claim under this warranty, please call our Customer Assistance Number.
For faster service, please have the model number and product name ready for the
operator to assist you. This number can be found on the bottom of your appliance
and on the front page of this manual.
Model Number: __________________ Product Name: __________________
Customer Assistance Number 1-855-451-2897 (US)
Keep these numbers for future reference!
TROUBLESHOOTING
PROBLEM SOLUTION
Double burner is not working. Check the power connection. The plug (3)
should be inserted properly in the outlet.
Double burner emits smoke or
vapor.
Switch o the burner completely, let it
cool down, and clean the burner.
If additional assistance is needed, please contact our Customer Assistance at
1-855-451-2897 (US).
TECHNICAL DATA
Rated voltage: 120V ~ 60Hz Rated power input: 1500W
Rated current: 12.5A
Double Burner_104555_IM_US_V2_121204.indd 8 12/4/12 10:07:41 AM
8
CUSTOMER ASSISTANCE
If you have a claim under this warranty, please call our Customer Assistance Number.
For faster service, please have the model number and product name ready for the
operator to assist you. This number can be found on the bottom of your appliance
and on the front page of this manual.
Model Number: __________________ Product Name: __________________
Customer Assistance Number 1-855-451-2897 (US)
Keep these numbers for future reference!
Two-year limited warranty
What does your warranty cover?
• Anydefectinmaterialorworkmanship.
For how long after the original purchase?
• Twoyears.
What will we do?
• Provideyouwithanewone.
• Forthoseitemsstillunderwarrantybut
no longer available, WAL-MART reserves
the right to replace with a similar
FARBERWARE branded product of equal
or greater value.
How do you make a warranty claim?
• Saveyourreceipt.
• Properlypackyourunit.Werecommend
using the original carton and packing
materials.
• Returntheproducttoyournearest
WAL-MART store or call Customer
Assistance at 1-855-451-2897 (US).
What does your warranty not cover?
• Partssubjecttowear,including,
without limitation, glass parts, glass
containers, cutter/strainer, blades, seals,
gaskets, clutches, motor brushes, and/
or agitators, etc.
• Commercialuseoranyotherusenot
found in printed directions.
• Damagefrommisuse,abuse,or
neglect, including failure to clean
product regularly in accordance with
manufacturer's instructions.
How does state law relate to this
warranty?
• Thiswarrantygivesyouspeciclegal
rights, and you may also have other
rights which vary from state to state or
province to province.
• Thiswarrantyisinlieuofanyother
warranty or condition, whether
express or implied, written or oral,
including, without limitation, any
statutory warranty or condition
of merchantability or tness for a
particular purpose.
• WAL-MART,FARBERWAREandthe
product manufacturer expressly
disclaim all responsibility for special,
incidental, and consequential
damages or losses caused by use
of this appliance. Any liability is
expressly limited to an amount equal
to the purchase price paid whether
a claim, however instituted, is based
on contract, indemnity, warranty, tort
(including negligence), strict liability, or
otherwise. Some states or provinces do
not allow this exclusion or limitation of
incidental or consequential losses, so
the foregoing disclaimer may not apply
to you.
What if you encounter a problem with this
product while using it outside the country
of purchase?
• Thewarrantyisvalidonlyinthecountry
of purchase and if you follow the
warranty claim procedure as noted.
© 2012 Farberware Licensing Company, LLC. All Rights Reserved.
Copyrights and Trademarks of Farberware Licensing Company,
LLC, including FARBERWARE®, are used under license from
Farberware Licensing Company, LLC.
TROUBLESHOOTING
PROBLEM SOLUTION
Double burner is not working. Check the power connection. The plug (3)
should be inserted properly in the outlet.
Double burner emits smoke or
vapor.
Switch o the burner completely, let it
cool down, and clean the burner.
If additional assistance is needed, please contact our Customer Assistance at
1-855-451-2897 (US).
TECHNICAL DATA
Rated voltage: 120V ~ 60Hz Rated power input: 1500W
Rated current: 12.5A
Double Burner_104555_IM_US_V2_121204.indd 9 12/4/12 10:07:42 AM
