2
CONTENTS
IMPORTANT SAFEGUIDES
...................................................
P.4
PRODUCT FEATURES.....................................................................
.P.6
INSTALLATION...................................................................................
P.6
OPERATING THE APPLIANANCE
..............................................
P.7
CARE AND
MAINTENANCE
.......................................................
P.9
TROUBLESHOOTING
.................................................................
.
P.9
WARRANTY TERMS
.................................................................
.
P.10
....
3
Thanks for choosing our products, hope that our products can bring you different feelings. Please
read the following safety and operating instructions carefully before using the wine cooler.
IMPORTANT SAFEGUIDES
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an
adapter, and do not use an extension cord.
Read all instructions before using the wine chiller.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous.
Before you throw away your old wine chiller, take off the door but leave the shelves in
place so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the appliance.
Replace all panels before operating.
It is recommended that a separate circuit, serving only your appliance be provided.
Use receptacles that cannot be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire
hazard or explosion. And do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance. The fumes can create a fire
hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power
line of the unit is disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect power before cleaning or servicing. Failure to do
so can result in electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this material. All other servicing should be referred to a qualified
technician.
Use two or more people to move and install appliance. Failure to do so can result in
back or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be
completely unobstructed. Choose a well-ventilated area with temperatures above
16°C (60.8°F) and below 32°C (89.6°F). This unit must be installed in an area
protected from the element, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high
heat.
The appliance must be installed with all electrical, water and drain connections in
accordance with state and local codes. A standard electrical supply, properly
grounded in accordance with the National Electrical Code and local codes and
ordinances is required.
Do not kink or pinch the power supply cord of appliance.
The fuse (or circuit breaker) size should be 13 amperes.
Never allow children to operate, play with or crawl inside the appliance.
Do not use solvent-based cleaning agents of abrasives on the interior. These
cleaners may damage or discolor the interior.
Do not use this apparatus for other than its intended purpose.
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance.
4
Before the appliance is used, it must be properly positioned and installed
as described in this manual, so read the manual carefully. To reduce the
risk of fire, electrical shock or injury when using the appliance.
● It is recommended that a separate circuit, serving only your appliance be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
● Never clean appliance parts with flammable fluids. These fumes can create a fire hazard
or explosion. And do not store or use gasoline or other flammable vapours and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
● Before proceeding with cleaning and maintenance operations, make sure the power line of
the unit is disconnected.
● Do not connect or disconnect the electric plug when your hands are wet.
● Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so
can result in electrical shock or death.
● DO NOT use mechanical devices to defrost refrigerator. DO NOT puncture refrigerant
tubing.
● To be repaired only by trained service personnel. DO NOT puncture refrigerant tubing.
● Consult repair manual / owner’s guide before attempting to service this product. All safety
precautions must be followed.
● To prevent a child from being entrapped, keep out of reach of children and not in the
vicinity of the cooler.
EXTENSION CORD
Because of potential safety hazards, it is strongly recommended that you do not use an
extension cord with this appliance. However, if you must use an extension cord, it is
absolutely necessary that it be a UL/CUL Listed, 3-wire grounding type appliance
extension cord having a grounding type plug and outlet and that the electrical rating of
the cord be 115 volts and at least 10 amperes.
WARNING
To reduce the risk of fire, electrical shock, or injury when using
your appliance, follow these basic precautions:
Read all instructions before using the wine chiller.
DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or
abandoned appliances are still dangerous.
Before you throw away your old wine chiller, take off the door but leave the shelves
in place so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
Do not store or use gasoline or any other flammable vapours and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
-Save these instructions-
5
PRODUCT FEATURES
• Dual cooling zones for storing different beverages and wines together.
• Beverage Refrigerator (Left Zone) Capacity: 80 standard 12oz cans
• Wine Refrigerator (Right Zone) Capacity:288 standard 750ml wine bottles
• Stainless steel glass doors with sleek black cabinet
• Stainless steel handle
• Tempered double-layered glass door with stainless steel frame
• Adjustable temperature for both zones
• Soft White Interior Lights
• Fahrenheit and Celsius degree optional temperature indicators
• 3 removable glass shelves - Beverage Refrigerator (Left Zone)
• 6 removable wire shelves - Wine Refrigerator (Right Zone)
INSTALATION
Before the first use
● Remove the exterior and interior packing materials.
● It is important for the appliance to be leveled in order to work properly. You may need to
adjust the feet to make it level.
● Let the appliance stand upright for approximately 24 hours before connecting it to
the power source, which helps to reduce the possibility of a cooling-system
malfunction from handling during transportation.
● Use a soft cloth to clean the interior surface with lukewarm water.
Door handle installation
①sealing ②screws ③Phillips screwdriver ④Handle
1
2
Fig:1 Fig:2
6
How to install the handle：
1)Pull away the sealing gasket where the handle is to be installed as shown in Fig1. The
gasket is easily displaced by hand. No tools are necessary.
2)Align the handle with the screws installed. Tighten the screws using a Phillips head
screwdriver until the handle sets both flush and secured tightly against the door frame. (DO
NOT over tighten as this will cause damage to the handle assembly).
3) Install the sealing gasket to its original position.
OPERATING THE APPLIANANCE
Control Panel
①Lighting button
②
Temperature up
③
Display window
④Fahrenheit and Celsius indicate light
⑤Temperature down
⑥
Fahrenheit & Celsius switch button
⑦
Power button
Built-in installation
These appliances are designed for both built-in or free standing installation. For built-in
installation, ensure proper service access and ventilation, allow at least ¼” (6.35mm) space
on each side and at the top
＞875mm
＞590mm
780mm
870mm
853mm
770mm
535mm
585mm
1 2 3 4 5 6 7
F
/ C
7
Power On / Off
● When the appliance is plugged into a power outlet, it powers on automatically.
● Touch the power button to turn on the appliance.
Press power button for 3 seconds to turn off
the appliance if needed.
Light Control
● Touch the lighting button to turn on (or turn off) the interior cool LED lighting.
Set Temperature
Touch the or button to increase or decrease the temperature of the selected zone.
The temperature will increase 1ºF or 1ºC if you touch the button once; On the contrary the
temperature will decrease 1ºF or 1ºC if you touch the button once.
Cooling Zone
Temperature Range
Beverage Refrigerator (Left Zone)
2
℃
-10
℃
(35
℉-50℉
)
Wine Refrigerator (Right Zone)
5
℃
-18
℃
(41
℉
-64
℉
)
Note:
●
If the appliance is power off suddenly. Please turn on the appliance after 3-5 minutes later. The
temperature setting is with automatic memory function.
● This wine cooler is suitable for the ambient temperature 5-32℃/41-89.6ºF. If
temperature is higher or lower than it, the performance may be affected.
●
If it is the first time to use this appliance, it is normal that the preset temperature and display
temperature is different. Everything will back to normal after few hours working.
Note: To keep the light automatically turns off 10 mins later, please press the lighting mark
until you hear 2 “beep”, we have the tutorial video to guide you if you need it,
please contact: [email protected]
Wired Shelves
The appliance is equipped with three wired shelves. You can remove the shelf by lift up and pull
it out smoothly.
To prevent damaging the door gasket, make sure to have the door all the way opened when
pulling the bottom shelf out of the rail compartment.
For easy access to the storage content, you can pull the shelf approximately 30% out of the
rail compartment, however this unit was designed with a stopper on each side of the shelf
track to prevent bott les from falling.
8
Storage
CARE AND MAINTENANCE
Cleaning your wine cooler
Turn off the power, unplug the appliance, and remove all items including shelves
Wash the inside surfaces with a wa rm water and soft clot h
Wash the shelves with a mild detergent solution
Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts
Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and
wipe dry with a clean soft cloth. Do n ot use steel wool or steel brush on the stainless
steel. These will contaminate the stainless steel with steel p
articles and rusting may
occur.
Power failure
Most power failures are corrected within a few hours and should not affect the temperature
of your appliance if you minimize the number of times the door is opened. If the power is
going to be off for a longer period of time, you need to take the proper steps to protect your
contents.
9
Moving your wine chiller
●Remove all items (bottles)
●Tape down securely all loose items (shelves) inside your appliance.
●Turn the adjustable leg up to the base to avoid damage.
●Tape the door shut. Be sure the appliance stays secure in the upright position during
transportation. If you absolutely need to transport the chiller horizontally, transport the chiller
on its back (door on top). Also protect outside of appliance with a blanket, or similar item.
Energy saving tips
The wine chiller should be located in the coolest area of the room, away from heat producing
appliances, and out of the direct sunlight.
TROUBLESHOOTING GUIDE
You can solve many common wine chiller problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling the
service.
PROBLEM
POSSIBLE CAUSE
Wine cooler does not operate.
Not plugged in.
The appliance is turned off.
The circuit breaker tripped or a blown fuse.
Wine cooler is not cold enough.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The compressor turns on and off
frequently.
The room temperature is hotter than normal.
A lots of bottles has been added to the chiller.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work
Not plugged in.
The circuit breaker tripped or a blown fuse.
The light button is “OFF”.
Vibrations.
The chiller is not leveled
The bottles are vibrating.
There is an object under the chiller.
The chiller seems to make too much
noise.
The flow of refrigerant is normal
The circulation of the refrigeration
The chiller is not level.
The door will not close properly.
The chiller is not level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.
10
Warranty Terms
Warranty Period
1. Customers are entitled to replacement or free repair service in case of quality defect(s) found
in the product within 15 days upon receipt of the prod uct.
2. Customers are entitled to free repair service from TAZPI for any product proven defe ctive in
material or workmanship that results in product failure during normal consumer usage and
conditions within the valid warranty period, which is 12 months counting from the date of selling.
How
eve
r, warranty period varies by product component and country of pur chase. Please contact
our after-sales service team via support@tazpi .com for detailed warranty information .
Warranty Exclusions
1. Product s subjected to unauthorized repair, misuse, collision, neglect, mishandling, soaking,
accident, and unautho rized alteration.
2. Product s subjected to improper use or whose labels o r security tags have been torn off or
altered.
3. Product s whose warranty h
as expire
d.
4. Product s damaged due to force majeure, such as fire, flood, lightening, e tc.
Warranty Claim Procedure
1. If failure or any problem o ccurs to your product after purchase, please contact us on Amazon,
or you can always contact TAZPI ’s customer service through email at support@tazpi .com or
website at www.tazpi .com.
2. TAZPI ’s cust omer service will guide you through the whole service procedure regarding any
product issue or prob lem you have encountered.
T
A
Z
PI
reserves the right to reex
a
mine damaged or returned products.
Contact Card
Web: www.tazpi .com
E-mail:
Phone:
（252）772-1994
