CONTENTS
IMPORTANT SAFEGUIDES
...................................................
P.3
PRODUCT FEATURES.....................................................................
.P.5
INSTALLATION...................................................................................
P.5
OPERATING THE APPLIANANCE
..............................................
P.6
CARE AND
MAINTENANCE
.......................................................
P.8
TROUBLESHOOTING
.................................................................
.
P.9
WARRANTY TERMS
.................................................................
.
P.10
...
3
Thanks for choosing our products, hope that our products can bring you different feelings. Please
read the following safety and operating instructions carefully before using the wine cooler.
IMPORTANT SAFEGUIDES
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an
adapter, and do not use an extension cord.
Read all instructions before using the wine chiller.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous.
Before you throw away your old wine chiller, take off the door but leave the shelves in
place so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the appliance.
Replace all panels before operating.
It is recommended that a separate circuit, serving only your appliance be provided.
Use receptacles that cannot be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire
hazard or explosion. And do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance. The fumes can create a fire
hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power
line of the unit is disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect power before cleaning or servicing. Failure to do
so can result in electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this material. All other servicing should be referred to a qualified
technician.
Use two or more people to move and install appliance. Failure to do so can result in
back or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be
completely unobstructed. Choose a well-ventilated area with temperatures above
16°C (60.8°F) and below 32°C (89.6°F). This unit must be installed in an area
protected from the element, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high
heat.
The appliance must be installed with all electrical, water and drain connections in
accordance with state and local codes. A standard electrical supply, properly
grounded in accordance with the National Electrical Code and local codes and
ordinances is required.
Do not kink or pinch the power supply cord of appliance.
The fuse (or circuit breaker) size should be 13 amperes.
Never allow children to operate, play with or crawl inside the appliance.
Do not use solvent-based cleaning agents of abrasives on the interior. These
cleaners may damage or discolor the interior.
Do not use this apparatus for other than its intended purpose.
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance.
4
Before the appliance is used, it must be properly positioned and installed
as described in this manual, so read the manual carefully. To reduce the
risk of fire, electrical shock or injury when using the appliance.
● It is recommended that a separate circuit, serving only your appliance be provided. Use
receptacles that cannot be turned off by a switch or p ull ch ain.
● Never clean appliance parts with flammable fluids. These fumes can create a fire hazard
or explosion. And do
not store or use gasoline or other flammable vapours an d liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
● Before proceeding with cleaning and maintenance operations, make sure the power line of
the unit is disconnected.
● Do not connect or disconnect the electric plug when your hands are wet.
● Unplug the a ppliance or discon nect power before cleaning or servicing. Failure to do so
can result in electrical sh ock or death.
● DO NOT use mechanical devices to defrost refrigerator. DO NOT puncture refrigerant
tubing.
● To be repaired only by trained service personnel. DO NOT puncture refrigerant tubing.
● Consult repair m anual / owner’s guide before attempting to service this product. All safety
precautions must be followed.
● To prevent a child from b eing entrapped, keep out of reach of children and no t in the
vicinity of the cooler.
EXTENSION CORD
Because of potential saf ety ha zards, it is str
ongly recommended that you do not use an
extension cord with this appliance. However, if you must use an extension cord, it is
absolutely necessary that it be a UL/CUL Liste d, 3-wire grounding type appliance
extension cord having a grounding type plug and outlet and that the electrical rating of
the cord be 115 volts and at least 10 amperes.
WARNING
To reduce the risk of f ire, electrical shock, or injury when using
your appliance, follow these basic precautions:
.
Read all instructions before using the wine cooler.
.
DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or
abandoned appliances are still dangerous.
.
Before you throw away your old wine cooler, take off the door but leave the shelves
in place so that children may not easily climb inside.
.
Never allow children to o perate, play with, or crawl inside the appliance.
.
Never clean a ppliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
.
Do not store or use gasoline or any other flammable vapours and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
-Save these instructions-
5
PRODUCT FEATURES
• Dual cooling zones for storing different beverages an d wines together.
• Beverage Refrigerator (Left Zone) Capacity: 80 standard 12oz cans
• Wine Refrigerator (Right Zone) Capacity:28 sta ndard 750ml wine bottles
• Stainless steel glass doors with sleek black cabinet
• Stainless steel handle
• Tempered double-layered glass door with stainless steel frame
• Adjustable temp erature f or both zones
• Soft blue Interior Lights
• Fahrenheit an d Celsius degree optional temperature indicators
• 3 removable wire shelves - Beverage Refrigerator (Left Zone)
• 6 removable shelves - Wine Refrigerator (Right Zone)
INSTALATION
Before the first use
● Remove the exterior and interior packing materials.
● It is important for the appliance to be leveled in order to work pro perly. You may need to
adjust the feet to make it level.
● Let th e appliance stand upright for approximately 24 h ours before connecting it to
the power source, which helps to reduce t he possibility of a cooling-system
malfunction from handling during transportat ion.
● Use a soft cloth to clean th e interior surface with lukewarm water.
Door handle installation
①sealing ②screws ③Phillips screwdriver ④Handle
1
3
2
4
2
Fig:1 Fig:2
wire
6
How to install the handle：
1)Pull away the sealing gasket where the handle is to be installed as sh own in Fig1. The
gasket is easily displaced by hand. No tools are necessary.
2)Align the handle with the screws installed. Tighten the screws using a Phillips he
ad
screwdriver until the handle sets both flush and secured tightly against the door frame. (DO
NOT over tighten as this will cause damage to the handle assembly).
3) Install the sealing gasket to its original position.
OPERATING THE APPLIANANCE
Control Panel
1 2 3 4 5 6 7
①Lighting button
②
Temperature up
③
Display window
④Fahrenheit and Celsius indicate light
⑤Temperature down
⑥
Fahrenheit & Celsius switch button
⑦
Power button
C
F
°
°
C
FF
7
Power On / Off
● When the appliance is plugged into a power outlet, it powers o n automatically.
● Touch the power button to turn on the appliance.
Press power button for 3 seconds to turn off
the appliance if needed.
Light Control
● Touch the lighting button to turn on (or turn off) the interior cool LED lighting.
Set Temperature
Touch the or button to increase o r decrease the temperature of the selected zone.
The temperature will increase 1ºF or 1ºC if you touch the button once; On the contrary the
temperature will decrease 1ºF or 1ºC if you touch th e but ton o nce.
Cooling Zone
Temperature Range
Beverage Refrigerator (Left Zone)
2
℃
-10
℃
(35
℉-50℉
)
Wine Refrigerator (Right Zone)
5
℃
-18
℃
(41
℉
-64
℉
)
Note:
●
If the appliance is power off suddenly. Please turn on the appliance after 3-5 minutes later. The
temperature setting is with automatic memory function.
● This wine cooler is suitable for the ambient temperature 5-32℃/41-89.6ºF. If
temperature is higher or lower than it, the performance may be affected.
●
If it is the first time to use this appliance, it is normal that the preset temperature and display
temperature is different. Everything will back to normal after few hours working.
Shelf
●To avoid the damage of door sealing, please open the door fu lly when you slide out the
shelves.
●For your convenience of taking wine, you can pull out the shelf b y 1 /3. Our product is
designed with shelf holder to prevent the shelf pull o ver and fall off the cabinet.
●If you need to take off the shelf from cabinet, you can pull out the shelf to the position
where the notch of shelf is exactly under the plastic post and then lift it up and out. (See
figure below)
8
Storage
CARE AND MAINTENANCE
Cleaning your wine cooler
Turn off the power, unplug the appliance, and remove all items including shelves
Wash the inside surfaces with a wa rm water and soft clot h
Wash the shelves with a mild detergent solution
Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts
Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and
wipe dry with a clean soft cloth. Do n ot use steel wool or steel brush on the stainless
steel. These will contaminate the stainless steel with steel p
articles and rusting may
occur.
Power failure
Most power failures are corrected within a few hours and should not affect the temperature
of your appliance if you minimize the number of times the door is opened. If the power is
going to be off for a longer period of time, you need to take the proper steps to protect your
contents.
9
Moving your wine cooler
●Remove all items (bot tles)
●Tape down securely all loose items (shelves) inside your appliance.
●Turn the adjustable leg up t o the base to avoid d am age.
●Tape the door shut. Be sure the a ppliance stays secure in t he upright position during
transportation. If you absolutely need to transport the cooler horizontally, transport the cooler
on its back (door on top). Also protect outside of a ppliance with a blanket, or similar item.
Energy saving tips
The wine cooler should be located in the coole st area of the room, away f ro m heat producing
appliances, and out of the direct sunlight.
TROUBLESHOOTING GUIDE
You can solve many co mmon wine cooler problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem bef ore calling the
service.
PROBLEM
POSSIBLE CAUSE
Wine cooler does not operate.
Not plugged in.
The appliance is tu rn ed of f.
The circuit breaker tripp ed or a blown fuse.
Wine cooler is not cold enough.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The compressor turns on and off
frequently.
The room temperature is ho tter than normal.
A lots of bottles has been added to the cooler.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work
Not plugged in.
The circuit breaker tripp ed or a blown fuse.
The light button is “OFF”.
Vibrations.
The cooler is not leveled
The bottles are vibrating.
There is an object under the cooler.
The cooler seems to make too much
noise.
The flow of refrigerant is normal
The circulation of the refrigeration
The cooler is not level.
The door will not close p ro perly.
The cooler is not level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.
10
Warranty Terms
Warranty Period
in the product within 15 days upon receipt of the product.
Warranty Exclusions
1. Products subjected to unauthorized repair, misuse, collision, neglect, mishandling, soaking, accident,
2. Products subjected to improper use or whose labels or security tags have been torn off or altered.
3. Products whose warranty has expired.
4. Products damaged due to force majeure, such as fire, flood, lightening, etc.
Warranty Claim Procedure
can always contact our customer service through email at [email protected].
2. Our customer service will guide you through the whole service procedure regarding any product
issue or problem you have encountered.
We reserve the right to reexamine damaged or returned products.
Contact Card
Support Phone : (213)432-5433
Support Email : [email protected]
