1. Pull out the outlet wires and grounding wire from the post. Make wire connections
using the wire nuts:
---The black wire from the fixture to the black wire from the post.
---The white wire from the fixture to the white wire from the post.
---The grounding wire from fixture to the grounding wire from the post.
Carefully tuck the wires back into the post.
2. Place the fixture on the post, then secure it with the set screws.
3. Install a bulb (not included). See relamping label at socket area or packaging for
maximum allowed wattage.
4. Thread the nipple into the holes of the cap, then secure it with a hex nut.
5. Attach the cover onto the cap by inserting the nipple, then secure it with the finial.
6. Attach the cap onto the fixture, then secure it with two screws.
7. Turn on the power at the main fuse or circuit breaker box.
Grounding Wire
Fixture Wire
Wire Nut
Post
Hex Nut
Nipple
Cap
Cover
Dry Wall Screw
Fixture
Screw
Finial
060118
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
WARNING: BE SURE TO SHUT OFF POWER AT THE MAIN FUSE OR CIRCUIT
BREAKER BOX BEFORE INSTALLING OR SERVICING THIS FIXTURE.
NOTE: Before installing, consult local electrical codes for wiring and grounding requirements.
OP37295/OP14695
