Sealey PRS4400 12/24V RoadStart Jump Starter 4400 Peak Amps User Manual

PREMIER 12V/24V 2200A/4400A ROADSTART®

JUMP STARTERS

MODELS: PRS2200, PRS4400

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9 Trained users only.

1.1. ELECTRICAL SAFETY FOR USE OF CHARGER

 WARNING! It is the user’s responsibility to check the following:

9 Check all electrical equipment and appliances to ensure that they are safe before using.

9 Inspect power supply leads, plugs and all electrical connections for wear and damage.

9 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.

8 DO NOT use worn or damaged cables, plugs or connectors.

9  EnsurethatanyfaultyitemisrepairedorreplacedimmediatelybyaSealeyqualiedtechnician.

9  Ifthecableorplugisdamagedduringuse,switcho󰀨theelectricitysupplyandremovefromuse.

9 SealeyrecommendthatanRCD(ResidualCurrentDevice)isusedwithallelectricalproducts.

Important:Ensurethatthevoltageratingontheappliancesuitsthemainspowersupply.

8 DO NOT pull or carry the appliance by the power cable.

8 DO NOT pull the plug from the socket by the cable.

 WARNING!Forthepurposesofrechargingthebattery,onlyusethedetachablesupplyunitprovidedwiththisappliance. 

DO NOT try to take the charger plug apart.

8 DO NOT use the charger plug to charge or power any other electrical item.

8 DO NOTgetthechargerwet,oruseinwet,dampconditions(forindooruseonly).

9  Theremovaloftheplughastobesuchthatanoperatorcancheckfromanyofthepointstowhichhehasaccessthattheplugremains

 removed.

1.2. BATTERY SAFETY

 WARNING!Toreducetheriskofburnsorre:

8 DO NOTattempttoopen,disassemble,modifyorservicethebatterypack.

8 DO NOTcrush,puncture,shortexternalcontactsordisposeofinreorwater.

8 DO NOTexposetotemperaturesabove60°C(140°).

9 Replace only with the battery pack designated for this product.

9 Recycle or dispose of used battery as stipulated by local regulation.

9 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool

water and seek immediate medical attention.

9 Ensure the internal battery is fully charged before initial use.

8 DO NOTmove/handle/usetheRoadStart®whenitisbeingcharged.

8 DO NOTleavebatteryinadischargedstate,rechargebatteryimmediately.Onlyusechargersupplied.Beforestorage,fullyrecharge

 thebattery,subsequentlyrechargethebatteryatleastonceeverysixmonthsofnon-use.

1.3. GENERAL SAFETY

▲ DANGER! RISK OF EXPLOSIVE GASES. PREVENT FLAMES AND SPARKS. PROVIDE ADEQUATE VENTILATION DURING

CHARGING. WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE

GASES DURING NORMAL OPERATION. FOR THIS REASON, IT IS IMPORTANT THAT YOU FOLLOW THESE INSTRUCTIONS

EACH TIME YOU USE THE ROADSTART®.

 Itisveryimportanttoreadandfollowtheseinstructionscarefully,eachtimeyouusetheRoadstart.

9  Followtheseinstructionsandthosepublishedbythebatteryandvehiclemanufacturer,andthemakerofanyequipmentyouintendto

 useinthevicinityofthebattery.Remembertoreviewwarningmarksonallproductsandonengines.

 WARNING! Modernvehiclescontainextensiveelectronicsystems.

9  YouarerequiredtocheckwiththevehicleManufacturer,foranyspecicinstructionsregardingtheuseofthistypeofequipmenton

 eachvehicle.Noliabilitywillbeacceptedfordamage/injury,wherethisproductisnotusedinaccordancewithallinstructions.

Original Language Version

Refer to

instructions

Electrical shock

hazard

Wear eye

protection

Wearprotective

gloves

Warning

corrosive

substance

Warning:

explosive

material

Keep away

from sources of

ignition

Use in well

ventilatedareas

Keep in dry area

protect from rain

PRS2200PRS4400Issue:104/06/25

1.3.1. PERSONAL PRECAUTIONS

9  Ensurethereisanotherpersonwithinhearingrangeofyourvoiceandcloseenoughtocometoyouraid,should a problem arise when

 workingnearalead-acidbattery.

9  Wearsafetyeyeprotectionandprotectiveclothing.Avoidtouchingeyeswhileworkingnearbattery.

9  Havefreshwaterandsoapnearbyincasebatteryacidcontactsskin,clothingoreyes.

9 Wash immediately with soap and water if battery acid contacts skin or clothing. If acid enters eye, flush eye immediately with cool, clean

 runningwaterforatleast15minutesandseekimmediatemedicalattention.

9  Removepersonalmetallicitemssuchasrings,bracelets,necklacesandwatches.Alead-acidbatterycanproduceashort-circuitcurrent

 whichishighenoughtoweldaringortheliketometal,whichwouldcausesevereburns.

9  Ensurehands,clothing(especiallybelts)areclearoffanbladesandothermovingorhotpartsofengine,removetiesandcontainlonghair.

8 DO NOTsmokeorallowasparkorflameinthevicinityofbatteryorengine.

1.3.2. SAVE THESE INSTRUCTIONS–ChargetheRoadstart®’sinternalbattery.Onlyusesuppliedchargerimmediatelyafterpurchase, 

 aftereachuseandasoftenaspossible.ItishighlyrecommendedtoleavetheRoadstart®permanentlyconnectedtotheautomatic

 charger.ThismanualwillshowyouhowtouseyourRoadstart®safelyandeffectively.Pleaseread,understandandfollow 

these instructions and precautions carefully, as this manual contains important safety and operating instructions.

9  UsetheRoadStart®intheuprightpositiononlyandensureitisplacedonastablesurfacewhichwilladequatelysupportitsweight.

9 Keep tools and other items away from the engine and ensure you can see the battery and working parts of engine clearly.

9 Keep children and unauthorised persons away from the working area.

8 DO NOTallowpowerclampstotoucheachotherortomakecontactwithanymetallicpartofthevehicle.

8 DO NOTcrossconnectpowerleadsfromRoadStart®tobattery.Ensurepositive(+/RED)istopositiveandnegative(-/BLACK)isto

 negative.

8 DO NOT pull the cables or clamps from the battery terminals.

8 DO NOT charge outdoors, or in damp, or wet locations and DO NOToperatewithinthevicinityofflammableliquidsorgases.

8 DO NOT use for a task for which it is not designed.

9 When not in use, store carefully in a safe, dry, childproof location.

9  Onlyuseforstartingvehicleswith12/24Vsystems.DO NOTuseforothervehiclessuchasaircraft,shipsetc.

8 DO NOTuseinplaceofavehiclebatteryorasabatterycharger.

8 DO NOTjumpstartmorethan3timesinarow.Itcoulddamagetheunitbyoverheating.Givetwominutesbetweenattempts.

9 Remove the product from the vehicle battery within 30 seconds of jump starting. If not, it could lead to damage.

8 DO NOTmodifyordisassembleRoadStart®.Onlyarepairtechnicianmayrepairthisunit.

8 DO NOTdropunit.Ifunitreceivesasharpbloworisotherwisedamagedinanywayhaveitcheckedbyaqualiedtechnician.

8 DO NOTusetheunittojumpstartavehiclewhilechargingtheinternalbattery.

9 The appliance contains batteries that are only replaceable by skilled persons.

9  Thisappliancecontainsbatteriesthatarenon-replaceable.

 WARNING!Forthepurposesofrechargingthebattery,onlyusethedetachablesupplyunitprovidedwiththisappliance.

9  Childrenfromage8yearsandabove,personswithreducedphysical,sensory,ormentalcapabilitiesthosewithlackofexperienceand

 knowledgecanusetheappliance,iftheyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceinasafewayto

 understandthehazardsinvolved.

9  ChildrenshallNOTplaywiththeappliance.

9  Cleaningandusermaintenanceontheapplianceshallnotbemadebychildrenwithoutsupervision.

9  Theapplianceshallbedisconnectedfromitspowersourceduringserviceandwhenreplacingparts.

2. INTRODUCTION

PRS2200:Highperformance22AhAGMbatterieshousedinrobustcasing,speciallyformulatedtojumpstartupto8Lpetroland5Ldiesel

engines.PeakAmps12V2200A,ColdCrankingAmps12V800A.LCDscreenshowsboththevoltageandpercentageoftheinternal

batteries.0/12VRotaryswitchforspark-freeconnection.Suppliedwith1.7mheavydutycableandcopperclamps.Builtinsafetyfeatures

includereversechargingbothvisualandaudible,shortcircuitandreversepolarityprotections.3W350Lumenworklightwithvedi󰀨erent

settings,idealforuseindarkenvironments.SOSmodeincludedforuseinemergencysituations.Outputsinclude5V2.4AUSBcharging

portforchargingmobilephones/tabletsaswell12V15Aoutputsocketthatwillacceptany12Vdevicewithavehicleaccessorysocket

plug.Suppliedwithchargerwithautomaticpowercut-o󰀨,whichpreventsdamagetobatterywhilstchargingfromthemains.PRS4400:

Highperformancetwo22AhAGMbatterieshousedinrobustcasing,speciallyformulatedtojumpstartupto13Lpetrolanddieselengines.

Peakamps12V4400A,24V1600A,ColdCrankingAmps12V2200A,24V800A.LCDscreenshowsboththevoltageandpercentageof

theinternalbatteries.0/12/24VRotaryswitchforspark-freeconnection.Suppliedwith1.7mheavy-dutycableandcopperclamps.Builtin

safetyfeaturesincludereversechargingbothvisualandaudible,shortcircuitandreversepolarityprotections.3W350Lumenworklightwith

vedi󰀨erentsettingsidealforuseindarkenvironments.SOSmodeincludedforuseinemergencysituations.Outputsinclude5V2.4AUSB

chargingportforchargingmobilephones/tabletsaswell12V15Aoutputsocketthatwillacceptany12Vdevicewithavehicleaccessory

socketplug.Suppliedwithchargerwithautomaticpowercut-o󰀨preventsdamagetobatterywhilstchargingfromthemains.

3. SPECIFICATION

Original Language Version

PRS2200PRS4400Issue:105/06/25

Model PRS2200 PRS4400

RatedVoltage 12V 12/24V

PeakAmps 2200A 4400A12V1600A24V

CCA 800A 2200A12V,800A24V

Cable Length 1.7m 1.7m

Auxiliary Output 12V15A 12V15A

USBOutput 5V2.4A 5V2.4A

Plug Type 3-PinBS 3-PinBS

Weight 12kg 19kg

Charger Specication

Supply 230V-50Hz1.5A 230V-50Hz1.5A

Output 15.4V4A 15.4V4A

4. FEATURES

5. OPERATION

5.1.  ReadtheENTIREIMPORTANTSAFETYINSTRUCTIONSsectionatthebeginningofthismanualincludingalltextundersubheadings

therein before setup or use of this product.

5.2. CHARGING THE JUMP STARTER

 IMPORTANT:YOUMUSTCHARGECOMPLETELYBEFOREFIRSTUSE,AFTEREVERYJUMPSTART,ANDEVERY30DAYS

 ORWARRANTYISVOID.Onlyusethedetachablechargerunitprovidedwiththeappliance.

 WARNING!TOPREVENTSERIOUSINJURY:

 Chargeonanon-ammablesurface.

 PressTESTButtontocheckbatterylevel:displayalternatesbetweenbattery%andvolts.

 WhentheBatteryisabove75%thismeansthebatteryisinagoodstate,noneedforcharging.

 WhentheBatteryisbetween50-75%itneedsrecharging.

 WhentheBatteryisbetween50%orless,itneedrechargingimmediately.

NOTE: Refer to Troubleshooting Section for any protection alert.

 Turnmainswitchtoo󰀨position.

 TurnWorkLightandUSBo󰀨.DisconnectanydeviceconnectedtotheUSBPort.

 PlugtheChargerinto230V-50Hzsupply

Plug Charging Cable into Charging Port on rear.

 Whilecharging,CHGwillappearontheDisplayalternatingwiththebatterylevelpercentage.

When charging is complete FULL will appear on the Display.

When the Jump Starter is fully charged, unplug Charging Cable from the power supply and the Jump Starter.

5.3. USING THE WORK LIGHT

 PressandholdtheLIGHT/USSButtonapproximately3secondstoturntheWorkLightoninbrightmode.

 PresstheButtonrepeatedlytocyclethroughlow,ashing,rapidashing,andSOSmodes.

 ToturntheWorkLighto󰀨,presstheLIGHT/USSButton.

NOTE:WorkLightstopsworkingwhenbatteryvoltageleveldropsbelow11V.

5.4. JUMP STARTING A VEHICLE

NOTE:Readthevehicleowner’smanualpertainingtojump-startingpriortousingtheRoadstart®.

 PressTESTButtontocheckbatterylevel.TheRoadstart®mustbefullycharged.Rechargeasneeded,refertosectionabove.

 Turno󰀨thevehicleignitionswitchandallaccessories(lights,radio,climatecontrol,etc.).

 TurnmainSwitcho󰀨.YoumayleavetheWorkLightonifneeded.

 WARNING!TOPREVENTSERIOUSINJURY:DO NOTTOUCHPOSITIVEANDNEGATIVEBATTERYCLAMPSTOGETHER.

 ConnecttheredPositiveBatteryCabletovehicle’spositivebatteryterminal.ConnecttheblackNegativeBatteryCabletoanon-

 movingmetalpartofthevehicle.

 WARNING!TOPREVENTSERIOUSINJURY:DO NOTCONNECTTOTHENEGATIVETERMINALOFTHEBATTERY.

NOTE:IftheBatteryClampsareconnectedincorrectly,analarmwillsoundandErrorCodeEr1willappearontheDisplay.Review

 andchangetheconnections.Ifthebattery’svoltageistoohigh,analarmwillsoundandErrorCodeEr2willappearontheDisplay.

 DisconnecttheBatteryClamps,itwillnotbepossibletojumpstartwiththisunit.

 Whenthecorrectconnectionhasbeenmade,the“externalbatteryvoltagevalue”willappearontheDisplay.

 •12VBattery-TurntheMainSwitchtothe12Vposition.

 •24VBattery-TurntheMainSwitchtothe24Vposition.(PRS4400)

 Attempttostartthevehicle.Ifthevehicledoesnotstartwithin5seconds,turnMainSwitcho󰀨andwaitatleast3minutesbeforetrying

again.

 Afterthevehicleisstarted,turntheMainSwitcho󰀨.RemovetheblackNegativeBatteryClamprst,andthentheredPositiveBattery

Clamp.

Recharge the Jump Starter.

5.5. POWERING DC APPLIANCES

 PressTESTButtontocheckbatterylevel.Rechargeasneeded.

1: Display

2:Voltageindicator

3: Charge indicator

4:12VDCport

5:USBport

6:Light/USBbutton

7:Testbutton

8:Mainswitch:PRS440012/24Vshown

9:+clamp

10:-clamp

11: Worklight

12: Charge port on rear

Original Language Version

PRS4400shown.PRS220012Vonly

PRS2200PRS4400Issue:105/06/25

 TurnMainSwitcho󰀨.Turnapplianceo󰀨.

 Plugapplianceintothe12VDCOutlet,thenturnon.Whennished,turno󰀨thenunplugappliance.

5.6. CHARGING/POWERING USB DEVICES

 PressTESTButtontocheckbatterylevel.Rechargeasneeded,accordingtoChargingsection.

 PlugthedeviceintotheUSBPort.

 PresstheLIGHT/USSButton.TheUSBIndicatorwillilluminate.

 Whennished,pressLIGHT/USSButtonagain.RemovethedevicefromtheUSBPort.NOTE:USBPortstopsworkingwhenbattery

 voltageleveldropsbelow11V.

5.7. IN EVENT OF BREAKDOWN: Removefromuse.Professionalrepaironly.

6. MAINTENANCE

6.1.  Proceduresnotspecicallyexplainedinthismanualmustbeperformedonlybyaqualiedtechnician.

 WARNING!TOPREVENTSERIOUSINJURY:UnplugRoadstart®,turntheMainSwitcho󰀨andallowtocoolcompletelybefore 

performing any inspection, maintenance, or cleaning procedures.

6.2. BEFORE EACH USE, inspect the general condition of the Jump Starter. Check for:

• loose hardware

• cracked or broken parts

• damaged electrical wiring or cable insulation

 •anyotherconditionthatmaya󰀨ectitssafeoperation.

6.3. Keep unit clean and clamps free of dirt, debris, or grease.

6.4. For longer working life, protect unit from sunlight and moisture.

6.5.  AFTERUSE,wipeexternalsurfaceswithacleancloth.

6.6. RECOMMENDED MAINTENANCE:

 Rechargejump-startaftereveryusage.

 Rechargeevery3monthsasregularmaintenance.

7. END OF LIFE

 WARNING!TOPREVENTSERIOUSINJURY:CONTAINSNON-SPILLABLE,SEALEDLEAD-ACIDBATTERY.BATTERYMUST

 BERECYCLEDORDISPOSEDOFPROPERLY.

7.1. BATTERY DISPOSAL: Contains batteries that are only replaceable by skilled persons.

7.1.1. Disposal must comply with standards for hazardous waste disposal in your area.

8. TROUBLESHOOTING

Display Alarm Issue Issue Information Correction

Er1 Yes Protection ReversedPolarity

Protection

Disconnect the clamps from the battery posts. Then properly

reconnect the clamps to the battery

Posts(+)to(+)and(-)to(-)/Groundedterminal.

Er2 Yes Protection ExternalBatteryVoltageis

Higherthan30VDC

Disconnect the clamps from the external

Battery.Correcttheexternalhighvoltageissueoftheexternalbattery.

Hi Yes Protection InternalBatteryVoltageis

higherthan15VDC

Unplugthecharger,ifbatteryisbeingrecharged.Havetheproduct

evaluatedandrepairedbyaqualiedtechnician.

LO Yes Protection Externalbatteryvoltageis

lowerthan6VDC

Disconnect the clamps from the external battery.

Roadstart®onlyworkswith12Vbatterysystem.

%,Voltage,Lo,

CHG

Yes Alert Reminder that internal

battery

Levelislowerthan11.5V

DC and needs to be

recharged

Presstestbuttontoresetthealarm.RechargetheRoadstart®.All

functions are working.

VoltageLo,CHG Yes Alert Reminder that the internal

batterylevelislowerthan

11.5VDCandneedstobe

recharged.

Presstestbuttontoresetthealarm.Recharge.OnlylightandUSB

are working.

Voltage,Lo,CHG Yes Urgent Reminder that internal

battery is lower than

11vDCandneedstobe

recharged.

Press“TEST”buttontoresetthealarm.

Recharge.Noneofthefunctionsareworking.

Original Language Version

PRS2200PRS4400Issue:105/06/25

Original Language Version

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

according to local regulations.

Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentparts

without prior notice.

Important:NoLiabilityisacceptedforincorrectuseofthisproduct.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

WEEE REGULATIONS

DisposeofthisproductattheendofitsworkinglifeincompliancewiththeEUDirectiveonWasteElectricalandElectronicEquipment

(WEEE).Whentheproductisnolongerrequired,itmustbedisposedofinanenvironmentallyprotectiveway.Contactyourlocalsolid

waste authority for recycling information.

PURCHASE HERE

PRS2200PRS4400Issue:105/06/25

Sealey PRS4400 12/24V RoadStart Jump Starter 4400 Peak Amps

Product's Documents

Instructions

Specifications

Sealey PRS4400 Questions and Answers
