ROADSTART® 2000A 12V JUMP STARTER
POWER PACK
MODEL NO: RS2000
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
Modern vehicles contain extensive electronic systems.
You are required to check with the vehicle manufacturer, for any specic instructions regarding the use of this type of
equipment on each vehicle. No liability will be accepted for damage / injury, where this product is not used in accordance with
all instructions.
9 Ensure that the vehicle is in a well ventilated area.
9 Apply the handbrake and select neutral or ‘park’ before attempting to start.
9 Ensure that the ignition switch and all ancillary electrical equipment is switched off.
9 Keep clear of any pulleys, belts etc. that will move once the engine starts.
9 Take care to ensure correct connection polarity; red clamp to positive, black clamp to negative.
9 Energise the unit only at ambient temperatures between -30°C and 40°C.
9 When not in use, switch off and store in a cool, dry place out of the reach of children.
8 DO NOT allow this power pack to become wet.
8 DO NOT dismantle this unit: there are no user serviceable parts inside.
8 DO NOT use in explosive atmospheres (e.g. the presence of flammable liquids, gases or dust).
8 DO NOT place the product in a high-temperature environment.
8 DO NOT use the unit if it appears damaged in any way.
8 DO NOT use this product for any purpose other than that for which it is designed.
8 DO NOT disassemble or modify the product.
8 DO NOT leave in direct sunlight or expose to heat.
8 DO NOT use abrasive or solvent cleaners on this product.
8 DO NOT allow children or pets to play with this product
8 DO NOT allow the positive and negative clamps to touch.
8 DO NOT connect both cable clamps to the same piece of metal.
8 DO NOT abuse the product. Handle with care.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open, disassemble, modify or service the battery pack.
8 DO NOT crush, puncture, short external contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°).
8 DO NOT use the product to start a bulging car battery.
9 Replace only with the battery pack designated for this product.
9 Recycle or dispose of used battery as stipulated by local regulation.
8 If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Easily ts in a glove box or backpack and benets from being compact and lightweight. Powered by lithium-ion technology and fully
protected against short circuit, overload and reverse polarity. Fitted with a 20,000mAh lithium-ion battery and two USB Type A outlets
(5V/3A, 9V/2A,12V/1.5A), Type-C input and output leads (5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/2.25A) and DC output 15V/10A this
unit can also supply several full charges for smartphones and tablets/laptops. Capable of starting an average 10L petrol or 8L diesel
engine. Integral LED ashlight with multiple settings (Solid, SOS, Flash). Supplied in a sturdy hard-shell zip-up case with battery
clamps and 2x USB cables.
3. SPECIFICATION
Model No: .......................................................... RS2000
Cable & Clamp Length: .......................................430mm
Capacity: ..........................20Ah @ 3.7V or 5Ah @ 14.8V
Maximum Current:............2000A Peak, 1000A Cranking.
Maximum Starting Capacity: ........... 10L Petrol/8L Diesel
Size (W x D x H): ...............................113 x 66 x 243mm
Voltage: .....................................................................12V
RS2000 Issue 2 (H) 19/09/23
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear eye
protection
Wear protective
gloves
WARNING!
Electricity
Keep in dry
area. Protect
from rain
Warning
corrosive
substance
Keep away
from sources of
ignition
Use in well
ventilated
areas
WARNING!
Explosive
material
4. OPERATION
NO. FUNCTION OPERATION
1 ON/OFF Button
(Multifunctional)
Press to see remaining capacity.
Long press to turn on/o the ashlight.
2 USC C Input &
Output (PD45W)
Fast charge/discharge
3 USB Output
Port 1
Charge your devices (QC 3.0 compatible)
faster, with 75% increase in speed.
4 USB Output
Port 2
Charge your devices (QC 3.0 compatible)
faster, with 75% increase in speed.
5 DC Output Port Charge other products through a cigarette
lighter.
6 EC 5 Port Insert the plug into the EC5 port to jump
start the car.
7 BOOST Button Press this button before starting the car.
8 LCD Screen Charge and discharge status and clamp
startup display
NO. OPERATION
1 Percentage of battery capacity: percentage of battery
charge/discharge/standby
2 Charging and discharging power display
3 Alarm prompt
4 BOOSTER button: Ready to jump start the vehicle
5 DC output display
6 Type-C charging and discharging display
7 USB output display
8 Output display
9 Input display
CHARGING THE DEVICE
4.2.1. Connect one end of the USB cable to the AC adapter, and the other end to USB C input port to begin charging.
4.2.2. Press the ON/OFF button to start charging. The percentage of battery capacity and power will display.
4.2.3. When the battery is fully charged, the LCD screen will turn o automatically. Full charge can take up to 10 hours.
4.2.4. Unplug the cable when no charge is required.
NOTE: ensure the jump starter is fully charged before rst use. The jump starter will power o automatically when no load is detected,
or when charging is complete.
4.1. POWER BANK
This device can be used as a power bank with compatible devices such as smartphones, tablets or laptops.
4.1.1. Connect the Roadstart to a compatible device.
4.1.2. Press the ON/OFF button to start charging.
4.1.3. Unplug the cable when no charge is required.
4.2. LED FLASHLIGHT
4.2.1. Long press ON/OFF button for 3 seconds to turn on the light.
4.2.2. Press ON/OFF button to switch between 4 modes: Solid, SOS, Flash and O.
4.3. JUMP START
NOTE: this product is for 12V batteries (maximum 10.0L petrol or 8.0L diesel engines).
Check to make sure the battery power of the jump starter is more than 50% before you use it to start your car.
4.3.1. Insert the plug of the clamp completely into the jump starter.
4.3.2. Connect the red clamp to the positive terminal (+) of the car battery
4.3.3. Connect the black clamp to the negative terminal (-) of the car battery.
4.3.4. Press the ON/OFF button and long press ‘BOOST’ until the LCD screen displays ‘BOOST’.
4.3.5. Start the car.
5. MAINTENANCE
5.1. STORAGE
9 Store the product in a clean, shaded and well-ventilated area.
8 DO NOT place the product in a high-temperature environment.
9 Keep the product away from children and pets.
9 Check the battery level at least once every six months and charge the product in time.
5.2. CLEANING
8 DO NOT use detergents to clean the product. Clean with a soft cloth.
RS2000 Issue 2 (H) 19/09/23
Original Language Version
© Jack Sealey Limited
RS2000 Issue 2 (H) 19/09/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
6. TROUBLESHOOTING
ERROR MODE CAUSE SOLUTION
+ Buzzer alarm + number ‘9’
Reverse connection Correct the connection between the clamp and
the positive and negative poles of the battery
+ Buzzer alarm + number ‘8’
Temperature too high/low Allow to cool. Ensure temperature of the jump
starter is between -20
o
c and 60
o
c
+ Buzzer alarm + number ‘7’
Overcurrent protection Stop the device and the safe mode will
disappear after 30 seconds
+ Buzzer alarm + number ‘6’
Trying to start the vehicle more than
4 times within 10 minutes
Stop the device and the safe mode will
disappear after 10 minutes
+ Buzzer alarm + number ‘5’
Two clamps are short-circuited Ensure clamps are not touching or connected to
the same piece of metal
+ Buzzer alarm + number ‘4’
When the external battery voltage is
higher than the jump starter voltage
Disconnect the jump starter and the car battery
+ Buzzer alarm + number ‘3’
Voltage of the jump starter is too low
to start the vehicle
Recharge the jump starter as soon as possible
to prevent battery damage
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
