GRANDHEAT 2500 FLATBED TOUCH WHITE
66
ENGLISH
1. PARTS AND COMPONENTS
Fig. 1.
1. Control panel
2. Display
3. Door
4. Door handle
Control panel
Fig.2
1. Automatic menus
2. Time/weight knob
3. On/off
4. Defrost
5. Clock
6. Stop/Cancel
7. Reheat
8. Start/+30 s
2. BEFORE USE
Take the product out of the box. If the microwave has a protective lm, tear it off before
starting operation. Check carefully if there is any damage, and if there is, immediately notify
the Technical Support Service.
The product must be placed on a at, stable and dry place and kept away from corrosive
materials, heat and humidity, such as gas burners or water.
The product must be placed in such way that the plug is accessible and must ensure an
effective grounding in case of leakage in order to avoid electric shocks.
The microwave door must be closed in order to operate.
In case there is any manufacturing rests in the microwave cavity or on the heating elements,
leave the microwave open to ensure good ventilation. In such case, it is recommended to heat
a glass of water at high power for several times.
Warning: Do not remove the light brown mica cover that is attached to the microwave cavity
to protect the magnetron.
GRANDHEAT 2500 FLATBED TOUCH WHITE
67
ENGLISH
3. PRODUCT INSTALLATION
Countertop installation
Place the appliance on a at, stable surface.
The minimum installation height is 85 mm.
The rear surface of appliance shall be placed against a wall.
Leave a minimum clearance of 30 cm above the microwave, a minimum clearance of 20 cm is
required between the microwave and any adjacent walls.
Do not remove the legs from the bottom of the microwave.
Blocking the intake and/or outlet openings can damage the microwave.
Place the microwave as far away from radios and TV as possible. Operation of microwave may
cause interference to your radio or TV reception.
Plug the device into a power supply.
Warning: Do not install microwave over a range cooktop or other heat-producing appliance.
If installed near or over a heat source, the microwave could be damaged, and the warranty
would be void.
4. OPERATION
Clock settings
When the device is plugged in, it will beep once.
Tap the clock icon to set the time. The hour digits will blink.
Turn the knob to set the correct hour, between 00 and 23.
Tap the clock icon. The minutes digits will blink.
Turn the knob to set the correct minutes, between 00 and 59.
Tap the clock icon to save the time settings.
Note: If the clock is not set, the current time will not be displayed when the device is turned on.
During the process of clock setting, tap the Stop/Clear icon to go back to the previous status
automatically.
Timer
Turn the Time/weight knob to increase or decrease the cooking time.
Note: If the clock has been set (24-hour system), the display will show the current time.
Pause or cancel
During the cooking process press the Stop/Cancel button once to pause or 2 to cancel the
cooking process. During the conguration of the cooking settings, press the button to cancel
GRANDHEAT 2500 FLATBED TOUCH WHITE
68
ENGLISH
the settings.
Microwave cooking
Tap the On/off icon once. The screen will display “P100".
Tap the On/off icon several times to select the microwave power, from P100 to P20.
Tap the Start/+30s icon to conrm.
Turn the knob to select the desired cooking time. The set time should be 0:05-60:00.
Tap the Start/+30s icon to start cooking.
Microwave power chart
Press Once Twice 3 times 4 times 5 times
Microwave
power
P100 P80 P60 P40 P20
Weight defrost
Tap the Weight defrost icon once, the display will show “dEF1”.
Turn the knob to select the weight of the food to be defrosted.
The weight must be between 100 and 2000 g.
Tap the Start/+30s icon to start the defrost process.
Time defrost
Tap the Time defrost icon once, the display will show “dEF2”.
Turn the knob “+” or “-“ to set the desired defrost time.
The maximum time is 60 minutes.
Tap the Start/+30sec icon to start the defrost process.
Reheat
The Reheat function is used to reheat cooked food. Press the Reheat button to activate this
function. The display will show 0.2 kg-0.4 kg-0.6 kg in cycle. Once the weight is selected, press
the start button to start reheating food.
Express cooking
In standby mode, tap the Start/+30s icon to operate the appliance at 100 % power level for
30 seconds. Each touch on the same icon will increase the cooking time by 30 seconds. The
maximum time is 60 minutes.
Turn the time knob to select the desired cooking time. After setting the cooking time, tap the
Start/+30s icon to start cooking at 100 % power level.
During operation, each touch on the same icon will increase the cooking time by 30 seconds.
Note: This option is not available under Weight defrost or Auto menu cooking modes.
GRANDHEAT 2500 FLATBED TOUCH WHITE
69
ENGLISH
Multi-sequence cooking
A maximum of 2 sequences can be set for a cooking process. If one of the sequences included
is defrosting, it should be set as the rst one.
Note: Auto menu and Express cooking menu cannot be set as one of the multi-sequences.
Example: Defrost food for 5 minutes, then cook with 80 % microwave power for 7 minutes.
Tap the Weight defrost icon, the display will show “dEF2”.
Turn the time knob to select 5 defrost minutes.
Tap the On/off icon twice to select 80 % microwave power.
Tap the Start/+30s icon to conrm.
Turn the time knob to set the cooking time to 7 minutes.
Tap the Start/+30s icon to start cooking.
Checking settings
During operation, tap the On/off icon, the current power level will be displayed for 3 seconds.
During operation, tap the Clock icon, the current time will be displayed for 3 seconds.
Child lock system.
In standby mode, hold down the Stop/Cancel icon for 3 seconds. The device will emit a long
beep indicating this function has been activated.
In standby mode, hold down the Stop/Cancel icon for 3 seconds. The device will emit a long
beep indicating this function has been deactivated.
Auto menu
In standby mode, tap the corresponding icon to select the Auto menu function.
Turn the knob to set the weight.
Tap the Start/+30s icon to start cooking.
Menus:
Menu Weight Display
Pizza 200 g 200
400 g 400
Meat
250 g 250
350 g 350
450 g 450
GRANDHEAT 2500 FLATBED TOUCH WHITE
70
ENGLISH
Vegetables
200 g 200
300 g 300
400 g 400
Potato
200 g 200
400 g 400
600 g 600
Fish
250 g 250
350 g 350
450 g 450
Popcorn
50 g 50
85 g 85
100 g 100
The above information correspond to food at 20 ºC and 25 ºC. If the food is at different
temperatures, the cooking effect will be different. Adjust time and temperature according to
the food’s temperature.
When cooking potatoes, for example, it is recommended to cover the food with a layer of wrap
to prevent evaporation of water during cooking.
The shape, weight and temperature of the food will affect the cooking process and results.
When using the automatic cooking menu programme, please follow the conditions mentioned.
If the cooking result is not satisfactory, modify settings.
Auto reminder
When the cooking or defrost process is completed, the device will emit 3 beeps. If the door
is not opened or “Stop/Cancel” button is not pressed, the microwave will beep once every 3
minutes.
5. CLEANING AND MAINTENANCE
The device, as well as food rests, must be cleaned and removed regularly.
Unplug the cable from the power supply before starting the cleaning. Do not immerse the
product in water or any other uid during cleaning.
The lack of maintenance and cleaning of the product may cause a deterioration on its surface
and affect its lifespan.
Do not use strong detergents, powder abrasives or metal brushes to clean the device.
Do not remove the mica plate.
When the microwave has been used for a long time, some strong odours may arise from inside.
GRANDHEAT 2500 FLATBED TOUCH WHITE
71
ENGLISH
In order to get rid of them, follow one of the steps below:
Place several lemon slices in a cup and heat them at high power for 2 or 3 minutes.
Place a cup of red tea inside the microwaves and heat it at high power for 2 or 3 minutes.
Place orange peels inside the microwaves and heat it at high power for 1 minute.
Use a dampened soft cloth to clean enclosures, door, interior walls and the door frame.
Warning: All maintenance tasks must be strictly carried out by qualied technical personnel.
6. TROUBLESHOOTING
Problem Cause Solution
The device stops working or
does not turn on
The power cord is not
properly plugged.
Disconnect it and connect it
again after 10 seconds.
Fuse blow or short circuit. Contact the ofcial Technical
Support Service of Cecotec.
Faulty power outlet. Test the power outlet with a
different appliance.
The device does no heat The door is not closed
properly.
Close the door properly.
7. TECHNICAL SPECIFICATIONS
01675 GrandHeat 2500 Flatbed Touch White
Rated input power: 1280 W
Rated output power: 800 W
230V ~ 50 Hz
Capacity: 25L
Made in China | Designed in Spain
8. DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), species that old household electrical appliances must
not be disposed of with the normal unsorted municipal waste. Old appliances
must be collected separately, in order to optimise the recovery and recycling
of the materials they contain and reduce the impact on human health and
the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation to dispose
GRANDHEAT 2500 FLATBED TOUCH WHITE
72
ENGLISH
of the appliance correctly.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.
9. TECHNICAL SUPPORT AND WARRANTY
This product is under warranty for 2 years from the date of purchase, as long as the proof
of purchase is submitted, the product is in perfect physical condition, and it has been given
proper use, as explained in this instruction manual.
The warranty will not cover the following situations:
The product has been used for purposes other than those intended for it, misused, beaten,
exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault
attributable to the customer.
The product has been disassembled, modied, or repaired by persons, not authorised by the
ofcial Technical Support Service of Cecotec.
Faults deriving from the normal wear and tear of its parts, due to use.
The warranty service covers every manufacturing defects of your appliance for 2 years, based
on current legislation, except consumable parts. In the event of misuse, the warranty will not
apply.
If at any moment you detect any problem with your product or have any doubt, do not hesitate
to contact Cecotec Technical Support Service at +34 963 210 728.
Fig./Img./Abb./Rys./Obr. 1
1
2
3
4
1
2
3 4 5
6 7 8
Fig./Img./Abb./Rys./Obr. 2
aire. Mantenga las aperturas libres de objetos, despejadas de polvo y
pelusas, y no las tapone con ropa o los dedos. Mantenga el pelo alejado
de las partes en movimiento.
Apague y desenchufe el producto de la fuente de alimentación cuando
no se vaya a utilizar por un tiempo, antes de limpiarlo, antes de montar
o desmontar los componentes y antes de retirar la batería.
No altere la batería de ninguna forma.
No utilice ninguna batería que no le haya sido proporcionada con el
producto original de Cecotec.
No coja el adaptador de corriente por el cable ni enrolle el cable a su
para guardarlo.
Utilice el dispositivo en lugares donde la temperatura ambiente esté
entre 5 y 40 ºC.
Asegúrese de que el ltro de alta eciencia y el cepillo están instalados
correctamente antes de poner el dispositivo en funcionamiento.
Tire del enchufe para desconectarlo, no tire del cable.
No sumerja el cable, el enchufe o cualquier otra parte del producto en
agua o cualquier otro líquido, ni exponga las conexiones eléctricas al
agua. Asegúrese de que tiene las manos completamente secas antes de
tocar el enchufe o encender el producto.
El aparato no debe ser usado por niños desde 0 hasta 12 años.
Este electrodoméstico puede ser usado por niños a partir de 12 años de
edad si están continuamente supervisados.
Este producto puede ser usado por personas con capacidades
físicas, sensoriales o mentales reducidas, o con falta de experiencia
y conocimiento si están supervisados o han recibido instrucción
concerniente al uso del aparato de una forma segura y entienden los
riesgos que este implica.
Supervise a los niños para asegurarse de que no jueguen con
Cecotec Innovaciones S. L.
C/de la Pinadeta s/n, 46930
Quart de Poblet, Valencia, Spain
EA01210112
