User Manual
VWS820SCB-X
vintec.com
VWD820SCB-X
VBS820SCB-X
– WARNING: Do not use electrical appliances inside the
compartments.
– WARNING: Do not store explosive substances such as
aerosol cans with a flammable propellant in this
appliance.
– WARNING: This appliance is intended to be used in
household and similar applica�ons such as:
- Staff kitchen areas in shops, offices and other working
environments;
- Farm houses and by clients in hotels, motels and other
residen�al type environments;
- Bed and breakfast type environments;
- Catering and similar non-retail applica�ons
– WARNING: Do not use electrical appliances inside the
food storage compartments of the appliance, unless
they are the type recommended by the manufacturer.
– WARNING: If the power cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
– WARNING: When posi�oning the appliance ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate mul�ple portable socket-
outlets or portable power supplies at the rear of the
appliance.
– WARNING: Your appliance is fi�ed with long life LED
ligh�ng. In the unlikely event the LED lights should fail,
then the LED lights should be serviced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
– WARNING: In Queensland Australia, the authorised
pers on must hold a Gas Work Authorisa�on for
hydrocarbon refrigerants, before carrying out servicing
or repairs which involve the removal of covers.
The environment and personal safety must be
considered when disposing of this appliance.
Please ensure the appliance is taken to a recycle centre
for safe recycling.
This appliance contains insula�on formed with
flammable blowing gases and flammable refrigerant.
Avoid safety hazards by carefully disposing of this
appliance.
It is hazardous for anyone other than an Authorised
Service Person to carry out servicing or repairs to this
appliance.
– WARNING: Keep ven�la�on openings in the appliance
enclosure or in the built-in structure clear of
obstruc�on.
– WARNING: Do not use mechanical devices or other
means to accelerate the defros�ng process, other than
those recommended by the manufacturer.
– WARNING: Do not damage the refrigerant circuit.
3
User Manual
- The room for installing the appliance must be at least 1
cubic metre per 8 grams of refrigerant. The refrigerant
quan�ty contained in this appliance is listed above in
grams; it is also noted on the Ra�ng Plate of the
appliance.
The informa�on in this document is subject to
modifica�on without any prior no�ce.
Some models are available in dedicated countries only.
VINTEC offers no guarantee for our Wine Cellar and
Beverage Centre if it is being used for any purpose other
than that for which it was specifically designed.
VINTEC cannot be held responsible for any error in this
manual.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabili�es, or lack of experience and knowledge,
unless they have been given supervision or instruc�on
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure they do not play
with the appliance (AU & NZ).
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabili�es or lack of experience and knowledge
if they have been given supervision or instruc�on
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision .
This appliance uses flammable refrigerant, please
secure the cooling pipe during the delivery process.
Posi�on the wine cellar away from direct sunlight and
sources of heat (stove, heater, radiator, etc.). Never
clean appliance parts with flammable fluids. The fumes
can create a fire hazard or explosion. When disposing
your appliance, please choose an authorized disposal site.
Children should be supervised to ensure that they do
not play with the appliance.
R600A WARNINGS
The following models use small quan�ty of R600A
(iso-butane) flammable refrigerant:
VWS820SCB-X/VWD820SCB-X/VBS820SCB-X: –35g
For your safety please observe the following
recommenda�ons :
- This appliance contains a small quan�ty of R600A
refrigerant which is flammable. Avoid safety hazards
by carefully installing, handling, servicing and disposing
of this appliance.
- During transporta�on and installa�on, ensure that the
tubing of the refrigerant circuit is not damaged.
- Avoid using or manipula�ng sharp objects near the
appliances.
- Leaking refrigerant can ignite and may damage the eyes.
- In the event any damage does occur, avoid exposure to
open fires and any device which creates a spark.
Disconnect the appliance from the mains power.
- Thoroughly ven�late the room in which the appliance is
located for several minutes.
- No�fy Customer Service for necessary ac�on and advice.
WARNING
This appliance is not intended for storing food of any sort.
Improper use of the grounding plug can result in the risk
of electric shock. Consult a qualified electrician or
service person if the grounding instruc�ons are not
completely understood. If the supply cord is damaged,
it must be replaced by a qualified person in order to
avoid electrical hazard.
INSTALLATION
Unpack and remove all of the protec�on and adhesive
strips from the packaging around and inside the Wine
socket to country standards, linked to the ground)．It is
NOT recommended to use a mul�-socket or extension
lead;
- have a surge protector fi�ed to the electrical outlet;
- away from the microwave oven. Certain microwave
ovens do not have wave interference shield. When
placed within 1 meter vicinity of the wine cabinet, they
may affect the opera�on of the wine cabinet.
Notes:
- VWS820SCB-X/VWD820SCB-X/VBS820SCB-X models are
slot-in type as per the drawings in the installa�on sec�on
(page 5).
The Wine Cellar and Beverage Centre should be placed
where declares climate class.
If the ambient temperature is above or below this range,
the performance of the unit may be affected. Placing
your unit in extreme cold or hot condi�ons may cause
interior temperatures to fluctuate. The ideal range of
temperature may not be reached. (See Climate Class
at the end of this manual).
Grounding instrucons
The Wine Cellar and Beverage Centre must be grounded
in case of an electrical short circuit. Grounding reduces
the risk of electrical shock. The Wine Cellar and Beverage
Centre is equipped with a power cord having a grounding
wire and plug. The Wine Cellar and Beverage Centre plug
Affix the back spacer at the back of the cellar for air
circula�on and heat evacua�on.
Compressor run appliances require good ven�la�on
for effec�ve and longer usage. Your Vintec Wine Cellar
and Beverage Centre is supplied with a back spacer.
- not be too damp (laundry, pantry, bathroom etc.);
- have a flat floor;
- have a standard and reliable electricity supply (standard
- be unencumbered and well ven�lated;
- be well away from any heat source and direct sunlight;
VINTEC recommends that you �ghten the back feet to
the maximum and adjust the front feet to level of the
Wine Cellar and Beverage Centre.
Fixing the Back spacer:
4
User Manual
Allow 24 hours before switching on the Wine Cellar and
Beverage Centre. During this me we recommend that
you leave the door open to clear any residual odours.
BEFORE LOADING & PLUGGING IN THE WINE CELLAR AND
BEVERAGE CENTRE.
Important: All models without front venng (air opening)
are strictly for free standing only.
Recommendaons:
The loca�on you have selected for your Wine Cellar and
Beverage Centre should:
Move your Wine Cellar and Beverage Centre to its final
loca�on. The Wine Cellar and Beverage Centre should be
installed in a suitable place where the compressor will
not be subject to physical contact.
- WARNING: Ensure the plug is accessible when the
appliance is in posi�on, or a switch is incorporated in
fixed wiring according to the wiring rules.
(See licensed electrician for further advice).
Levelling your Wine Cellar and Beverage Centre: Wine
Cellar and Beverage Centre must be leveled BEFORE
loading your wines. Your Vintec Wine Cellar and
Beverage Centre is equipped with 4 adjustable feet to
facilitate easy leveling.
Cellar and Beverage Centre. The Wine Cellar and
Beverage Centre must be posi�oned such that the plug
is accessible. Release the power cord.
must be plugged into a properly affixed and grounded
electrical outlet.
Note: In loca�ons where there is frequent lightning, it is
advisable to use surge protectors.
INSTALLATION
The Wine Cellar and Beverage Centre should be placed
on a level surface in a dry, well -ven�lated room (max.
75% rela�ve air humidity). In hot humid climate areas
and par�cularly on hot rainy days, humidity in the amb-
ient air can condense on the cold external surfaces, glass
door or door sealing gasket strip. Especially when appli-
ance is set at the coldest temperature se�ng in a long
period of �me during high humid days which is a natural
phenomenon.During monsoon season or high humidity
days, we recommend se�ng the temperature at warmer
or at cellaring temperature mode. Or you can simply
wipe off any moisture or water droplets with so� dry
cloth.Condensa�on will disappear when humidity level
drops or temperature set to a warmer se�ng.
IMPORTANT - THIS SPACER MUST BE ATTACHED TO
THE UNIT BEFORE THE INSTALLATION, FOR
VENTILATION PURPOSE.
FAILURE TO DO WILL VOID THE WARRANTY
UNDER-BENCH INSTALLATION INSTRUCTIONS
INSTALLATION
Cross secon
30mm30mm
5
User Manual
Front View (VWS820SCB-X/VWD820SCB-X
/VBS820SCB-X)
DIMENSIONS:
VWS820SCB-X/VWD820SCB-X/VBS820SCB-X
This Vintec Wine Cellar and Beverage Centre is not
designed to be fully integrated behind a joinery door.
Please note that:
For VWS820SCB-X/VWD820SCB-X/VBS820SCB-X
a minimum cut out width of 615mm is required to
facilitate installa�on, removal and servicing.
1. Vintec “Slot-in” Wine Cellar and Beverage Centres
are front ven�ng but are not designed to be fully
integrated behind a joinery door.
INSTALLATION DRAWINGS FOR fornt ven�ng under
bench Wine Cellars and Beverage Centres:
3. Vintec “Slot-in” Wine Cellar and Beverage Centres
draw air from the rear and expels it through the metal
grid under the door at the front. If a kick board is to be
placed in front of the Wine Cellar and Beverage Centre’s
grid another one must be fi�ed into the kick board with
a minimum air flow allowance of 150cm².
4. Vintec “Slot-in” Wine Cellar and Beverage Centres have
a power switch located on the control panel so power
point loca�on is not cri�cal.
5. The Wine Cellar and Beverage Centre requires a
standard 240 volt/10 amp power point. (Or according
to different countries specifica�ons).
6. The power cord is min 1.8m in length and is fixed on the
right side at the back when looking from front of cabinet.
7. As with most appliances of today, the Wine Cellar and
Beverage Centre has sensi�ve electronic components
which are suscep�ble to damage through lightning and
electricity supply faults. It is therefore advised to use a
power surge protector to avoid problems of this nature.
8. Air vent within the joinery must be provided for Vintec
“Slot-in” Wine Cellar and Beverage Centres (Front venng)
In Hot climate zone, an air vent or grid, with a minimum
ven�la�on size of 200mm x 40mm MUST be cut out at
the rear top of the back par��oning or at the top of either
side of the par��oning, allowing cool fresh air full access
to flow into the 30mm gap located at the rear of the
cabinet.
2. Vintec “Slot-in” Wine Cellar and Beverage Centres
require 10mm clearance on both sides and 30mm on top,
30mm clearance at the rear (Back spacer is provided), to
facilitate installa�on, removal, servicing and ven�la�on.
This air vent or grid must not be opened on the same
side as other appliances such as ovens or an area that
is sealed and without access to fresh cool air. Failing
to comply with the above specifica�ons could result in
WARRANTY void.
Cabinet Height
820-870mm
Cabinet Width
Total depth
595mm
525mm+30mm（Back spacer）
Dimensional drawings:
30mm
01 mm
01 mm
01 mm
01 mm
30mm
595 mm
516 mm
820mm
850mm
525 mm
555 mm
03 mm
30mm
F or nt iV we
Side iV we
oT p iV we
TURNING ON YOUR WINE CELLAR AND BEVERAGE CENTRE.
Plug in and switch on the cellar by pressing on the
power bu�on for a few seconds.
When you use the Wine Cellar and Beverage Centre for
the first �me (or restart the Wine Cellar and Beverage
Centre a�er having it shut off for a long �me), there
will be a few degrees variance between the temperature.
Once the Wine Cellar and Beverage Centre is running for a
few hours everything will stabilise.
OPERATING NOISES
To reach the desired temperature se�ngs, VINTEC
Wine Cellar and Beverage Centres, like all Wine Cellar
and may produce the following types of noises. These
noises are normal and may occur as follows:
- Gurgling sound - caused by the refrigerant flowing
through the appliance’s coils.
- Cracking/popping sounds - resul�ng from the
contrac�on and expansion of the refrigerant gas to
produce cold.
- Fan opera�ng sound - to circulate the air within the
Wine Cellar and Beverage Centre.
An individual’s percep�on of noise is directly linked to
the environment in which the Wine Cellar and Beverage
Centre is located, as well the specific type of models.
VINTEC Wine Cellar and Beverage Centres are in line
with interna�onal standards for such appliances.
VINTEC will always do its utmost to sa�sfy its
customers but will not retake possession of the goods
due to complaints based on normal opera�ng noise
occurrences.
LOADING YOUR WINE CELLAR AND BEVERAGE CENTRE.
You may load your wine bo�les in single or double rows
while taking note of the following: if you do not have
enough bo�les to fill your Wine Cellar and Beverage
Centre, it is be�er to distribute the load throughout the
Wine Cellar and Beverage Centre so as to avoid all on
top or all below type loads.
5
STORAGE
6
User Manual
FOR VWS820SCB-X，Total: 41bo�les
Storage diagram
FOR VWD820SCB-X，Total: 40bo�les
TEMPERATURE STABILITY AND WINE STORAGE
Please note that depending on the loading and
se�ngs chosen it takes about 24 hours for the Wine
Cellar and Beverage Centre to see the temperature
stabilising. During this �me the LED seems to move
erra�cally in par�cular for dual zone models. It is
normal and this process occurs whenever the se�ng
is modified and/or whenever a large amount of
bo�les are added to the cellar. Designed to store and
mature all wines: red, white and sparkling. These
Wine Cellar reproduce the ideal condi�ons for wine
storage, at a constant recommended temperature
of 12°C. They can also be set to provide ideal serving
temperature for full enjoyment of the wine’s quali�es.
Unless stated by the wine maker on the bo�le,
VINTEC recommends 7°C for your champagne,
12°C for whites and 18°C for reds. (Refer to Wine
Service Temperature recommenda�on chart).
Designed to store wines at the correct temperature
for best enjoyment. The upper chamber can hold 17
or 12 bo�les, depending on the models, at a
temperature of 6°C to 10°C dedicated mainly to
white, sparkling wines and champagnes. The lower
chamber accommodates 23 bo�les depending on
the models, mainly for red wines, which could be
stored either at room temperature (18°C-20°C) for
consump�on or at 12°C for a longer �me of storage.
TEMPERATURE SETTINGS
This appliance memorizes and saves its set
temperature. In case of a power outage, the unit
adjusts to its previous temperature se�ng when
power resumes.
Temperature
diva�on
+/-2.5℃
+/-2.5℃
Se�ng
12℃
6℃
Model
VWS820SCB-X
Upper compartment: 6℃
Lower compartment: 12℃
Factory preset chart
VBS820SCB-X
VWD820SCB-X
+/-2.5℃
+/-2.5℃
5
STORAGE
7
User Manual
- Do remove or relocate adjustable wooden shelves to
accommodate larger type of bo�les or increase the
capacity of the cellar by stacking the bo�les up when
necessary. (See removing shelves).
- Keep smalls gap between the walls and the bo�les to
allow air circula�on. Like an underground cellar air
circula�on is important to prevent mould and for a
be�er homogeneous temperature within the cellar.
- Do not over load your Wine Cellar and Beverage
Centre to facilitate air circula�on.
- Do not stack more than 1.5 rows of standard 0.75L
bo�les per shelves to facilitate air circula�on.
- Avoid obstruc�ng the internal fans (Located
inside on the back panel of the Wine Cellar and
Beverage Centre).
- Do not slide the shelves outwards beyond the
fixed posi�on to prevent the bo�les from falling.
- Do not pull out more than one loaded shelf at a
�me as this may cause the Wine Cellar and
Beverage Centre to �lt forward.
FOR VBS820SCB-X，Total: 141cans (Max)
- Do not cover the wooden shelves with alloy foil or
other materials, as it will obstruct air circula�on.
- Do not move your Wine Cellar and Beverage Centre
while it is loaded with wines. This might distort the
body of the Wine Cellar and Beverage Centre and
cause back injury.
Statements for User Instruc�on Manual for Dual-Zone
temperature se�ngs;
WINE SERVING TEMPERATURE CHART
All wines mature at the same temperature, which is a
constant temperature set between 12℃ to 14℃.
The below chart is an indica�ve temperature chart to
indicate the best temperature for drinking purposes.
Champagne NV, Sparkling, Spumante, 6℃
Dry White Semillon, Sauvignon Blanc, 8℃
Champagne Vintage, 10℃
Dry White Chardonnay, 10℃
Dry White Gewürztraminer, Riesling, Pinot grigio,
Sweet White Sauternes, Barsac, Montbazillac, Ice10℃
Wine, Late Harvest , 10℃
Beaujolais, 13℃
Sweet White Vintage: Sauternes, 14℃
White Vintage Chardonnay , 14℃
Red Pinot Noir, 16℃
Red Grenache, Syrah , 16℃
Red Vintage Pinot Noir, 18℃
Cabernet & Merlot: French, Australian, New Zealand,
18℃
Chilean, Italian, Spanish, Californian, Argen�nean,
Vintage Bordeaux . 18℃
IMPORTANT INFORMATION ABOUT TEMPERATURE
Your VINTEC Wine Cellar and Beverage Centre has been
designed to guarantee op�mum condi�ons for storing
and/or serving your wines.
Fine wines require long and gentle developments and
need specific condi�ons in which to reach their full
poten�al.
All wines mature at the same temperature, which is a
constant temperature set between 12
℃ to 14℃. Only
the temperature of degusta�on (wine apprecia�on) varies
according to the type of wines (see Wine Serving
Temperature Chart above). This being said and as it is for
natural cellars used by wine producers for long periods of
storage, it is not the exact temperature that is important,
but its consistency. In other words, as long as the tempera-
ture of your Wine Cellar and Beverage Centre is constant
(between 12
℃ to 14℃) your wines will be stored in perfe-
ct condi�ons.
Not all wines will improve over the years. Some should be
consumed at an early stage (2 to 3 years) while others
have tremendous ageing capability (50 and over). All wines
have a peak in maturity. Do check with your wine mercha-
nt to get the relevant informa�on
All units are equipped with a double glazed glass door
that has a LOW-E layer to minimise condensa�on on the
glass door.
The Wine Cellar and Beverage Centre is not totally sealed;
Some fresh air is allowed through the drainpipe.
Air is circulated through the cellar by means of a fan/fans
and the hollow shelves.
Notes: During the refrigera�ng cycle, heat is given off
which disperses through the external surfaces of the
Wine Cellar and Beverage Centre. Avoid touching the
surfaces during those cycles.
ADJUSTABLE WOODEN SHELVES:
ADJUSTING/REMOVING THE SHELVES
- For easy access to the storage content, you must pull
the shelves approximately 1/3 of its depth out of the
rail compartment. These wine cabinets, however, are
designed with a notch on each side of the shelf tracks
to prevent bo�les from falling.
- To prevent damaging the door gasket, make sure to
have the door all the way opened when pulling shelves
out of the rail compartment.
- When removing any of these shelves out of the rail
compartment: to fit or remove the shelf, �lt the shelf
as per the diagram and simply pull out, or push in the
shelf un�l it sits on the support brackets securely.
12
User Manual
by the natural cork to maintain a long las�ng seal.
Notes: The water collected by condensa�on, is therefore
recycled.
VBS820SCB-X models
DEFROSTING/CONDENSATION/ HYGROMETRY/
VENTILATION
Your Wine Cellar and Beverage Centre is designed with
Auto-cycle defrost system. During Off-cycle the refrigerat-
ed surfaces of the Wine Cellar and Beverage Centre defr-
ost automa�cally. Defrost water from the Wine Cellar and
Beverage Centre storage compartment drains automa�ca-
lly and part of it goes into a drainage container, which is
located at the back of the Wine Cellar and Beverage Cen-
tre next to the compressor.The heat is transferred from
the compressor and evaporates any on that has collected
in the pan. Part of the remaining water is collected within
the Wine Cellar and Beverage Centre for humidity purpo-
ses.
This system enables the crea�on of the correct humidity
level inside your Wine Cellar and Beverage Centre required
WINE SERVING & DEFROSTING &
ADJUSTABLE SHELVES
13
User Manual
VWS820SCB-X /VWD820SCB-X models
- To prevent damaging the door gasket, make sure
to have the door all the way opened when pulling
shelves out of the rail compartment.
- To Remove Shelves:
1. Fully extend the shelf you wish to remove(Fig. A)
2. Li� the front of the shelf up (Fig. A)
3. Holding the shelf track, push the shelf in, then
up to release from the rear dampers(Fig. B)
REVERSIBILITY OF THE DOOR
WARNING: To avoid accidents during the process of
changing the door, we recommend that you get assistance.
The glass door is heavy and may cause injury if dropped.
① Right upper door hinge decora�ve cover
② Limi�ng screws
③ Le� upper corner decora�ve cover
④Upper and lower door hinge screws
⑤upper and lower door hinges
⑥ right upper limit parts
⑦ lower right limit parts
⑧right upper corner decora�ve cover
⑨Le� upper hinge decora�ve cover
⑩upper and lower decora�ve nails
1) Open the door, push out the right door hinge
decora�ve cover (1) and the le� upper corner decora�ve
cover (3) completely according to the arrow direc�on,
and take it away (Fig.1.2);
2) Disassemble the 2 screws (2) (Fig.1) of the right upper
limit (6), move the door body outward and remove it,
and then remove the right upper limit (6) Installed in
the lower le� corner of the door body (Fig.4);
3) disassemble 2 screws (2) (Fig.3) of the right lower
limiter (7), remove the right lower limiter (7) and set
aside;
4) take out the upper and lower decora�ve nails
(10), disassemble 6 upper and lower door hinge screws
(4), and remove the upper and lower door hinges (5),
a�er the reversal, they are respec�vely installed on the
le�, as shown by the arrow in the figure (Fig.5);
5) first align the spacing part sha� core (6) at the bo�om
of the door body with the door hinge sha� mandrel hole,
and install it on the le� door hinge (Fig.6);
6) Install the lower right limi�ng piece (7) into the mand-
rel mandrel hole of the upper hinge, then push the door
to align with the screw hole of the limi�ng piece (7),
�ghten it with screws (2), and install the door (Fig.7);
7) Take out the le� door hinge decora�ve cover (9) and
the right upper door corner decora�ve cover (8) from
the accessory bag, align the decora�ve cover with the
groove on the door, and push the door hinge cover in
the direc�on of the arrow and install it (Fig.7.8).
Note: Changing the door requires the coopera�on of
two people.
How to replace ac�vated carbon pack
Fig.1
Fig.2
Fig.4
Fig.5
Fig.3
DOOR REVERSAL & HOW TO REPLACE ACTIVATED CARBON PACK
ANTI-TIP BRACKET INSTALLATION INSTRUCTIONS
14
User Manual
An�-Tip Bracket Installa�on Instruc�ons
Tools You Will Need
FOR YOUR SAFETY:While performing installa�on described in
this sec�on, gloves, safety glasses, or goggles should be worn.
Installing the An�-Tip Bracket
WARNING:
This appliance may �p when shelves are extended,causing
damage or injury. If this appliance is used in a FREE STANDING
applica�on, the an�-�p bracket must be installed following
these instruc�ons!
An�-Tip bracket parts list:
A: An�-�p bracket
(1pcs)
B: Hexagon bolt
(1pcs)
size (6mmx 20mm) (1/4"x4/5")
C: Lock washer
(1pcs)
size (6)
D: Flat washer
(1pcs)
size (6)
E: Screw
(2pcs)
size (ST4x35)
F: Expansion screw
(1pcs)
size (6mmx60mm) (1/4"x2.4")
Secure the bracket with the screws provided.
An�-�p bracket installa�on
The bracket can be installed at the le� bo�om OR right
bo�om of the back of the unit.
You can choose which side is convenient for you.
An�-�p bracket moun�ng hole instruc�on:
Loca�on a: Fixed moun�ng hole for unit
Loca�on b: Fixed moun�ng holes for Drywall
Loca�on c: Fixed moun�ng holes for Wood floor
Loca�on d: Fixed moun�ng holes for Concrete floor
Loca�on e: Moun�ng hole on the back unit
IMPORTANT:Determine the final loca�on of the appliance
before a�emp�ng to install the bracket. You will need to
choose one of the three installa�on methods below.
DRYWALL installa�on:
1. A�er you have chosen the installa�on loca�on, place the
bracket on the floor with Loc b against the wall, use Screw
(E)(2pcs) to secure the bracket to the wall. Ensure at least
one screw is secured into a stud.
2. Move the unit to align Loc e to bracket Loc a, secure with
the bolt (B). lock washer (C) and flat washer (D).
NOTE: The screws MUST enter into a wood stud. If the wall
contains metal studs or similar materials, then the floor
installa�on must be used.
1. Pull back the back clip of the box with your fingernail first,
so that the clip is free from the slot of the lid, and then the lid
can be removed (Fig.1.2).
2. Then take out the ac�vated carbon pack ② from the
manual bag, tear off the sealed bag, and put it into the
ac�vated carbon box (Fig.3).
3. Push the card slot at the front of the cover to the card
slot (4), and press down the back of the cover so that the
card slot is inserted into the card slot (Fig.5).
Then reset filter reminder light on your wine cellar cabinet's
UI control panel.
You can purchase a new air filter in this website :
www.shop.vinteclub.com
OPERATION ANOMALIES
Ensure that there is power to the electrical supply plug by
connec�ng another electrical appliance to it. Check fuse,
if any. Make sure that the door is closed properly.
POWER FAILURES
This appliance memorizes and saves its set
temperature. In case of a power outage, the unit
adjusts to its previous temperature se�ng when
power resumes.
To avoid sudden change of temperature while the
power is off, you should avoid opening the door.
For longer periods of power failure, do take steps
to protect your wine.
Irrespec�ve of the cause, if you no�ce either
abnormal temperature or humidity levels inside your
Wine Cellar and Beverage Centre, be reassured that
only long and frequent exposure to these abnormal
condi�ons can cause a detrimental effect on your
wines.
TROUBLESHOOTING GUIDE
Common problems may easily be solved, saving you
the cost of a possible service call.
Please read carefully the instruc�on manual and refer
to the troubleshoo�ng guide chart.
5
TROUBLESHOOTING
15
User Manual
CONCRETE FLOOR installa�on:
1. A�er you have chosen the installa�on loca�on, choose any
hole of Loc d to secure the bracket into the concrete floor.
2. Using a concrete bit, drill 8mm (3/8") pilot hole 45-55mm
(1.7"-2") deep.
3. Remove the nut, spring washer and washer of the expansion
screw.
4. Carefuly tap the expansion screw into the concrete, using a
hammer or mallet,
5. Align Loc d and secure the nut. spring washer, washer �ghtly
back on the expansion screw and fix on the concrete floor.
6. Move the unit to align Loc e to bracket Loc a, secure with the
bolt(B),lock washer (C) and flat washer (D).
ATTENTION:
Check the bracket ：A�er installing the bracket,try using light
force to �p the unit. If the unit does not �p then the bracket
mounted securely.
If the unit does �p, the bracket MUST be reinstalled following
these instruc�ons.
PROBLEM
POSSIBLE CAUSE
Wine Cellar and Beverage
Centre does not operate.
Wine Cellar and Beverage
Centre is not cold enough.
Turns on and off frequently.
The light does not work.
Not plugged in.
The appliance is turned off.
The circuit breaker tripped or the fuse is
broken.
Check the temperature control se�ng.
External environment may require a
higher se�ng.
The door is opened too o�en.
The door is not closed completely.
The door gasket does not seal properly.
The room temperature is higher than
normal.
A large amount of contents has been
added to the Wine Cellar and Beverage
Centre.
The door is opened too o�en.
The door is not closed completely.
The temperature control is not set
correctly.
The door gasket does not seal properly.
Not plugged in.
The circuit breaker tripped or a blown
fuse.
The bulb is out of order.
The light bu�on is “OFF”.
Check to assure that the Wine Cellar and
Beverage Centre is level.
Vibra�ons.
WOOD FLOOR installa�on:
1. A�er you have chosen the installa�on loca�on, place the
bracket on the wood floor, use: Screw (E) (2pcs) align Loc c
and secure the bracket into wood floor.
2. Move the unit to align Loc e to bracket Loc a, secure with
the bolt(B).lock washer (C) and flat washer (D).
If your Wine Cellar and Beverage Centre appears to be
malfunc�oning, unplug it and contact your VINTEC’s
a�er sales service. Any interven�on on the cold circuit
should be performed by a refrigera�on technician
who should carry out an inspec�on of the circuit seal-
ing system. Similarly, any interven�on on the electri-
cal circuit shouldbe performed bya qualified
electrician.
Notes : Any interven�on performed by a non- authori-
sed technician by Vintec will lead to the warranty bei-
ng considered as null and void.
TROUBLESHOOTING & DATA
16
User Manual
The door will not close properly.
The Wine Cellar and Beverage Centre is
not level.
The door was reversed and not properly
installed.
The gasket is faulty. (Magnet or rubber
is spoiled).
The shelves are out of posi�on.
The Wine Cellar and Beverage
Centre seems to make too
much noise.
A Gurgling noise may come from the low
side of the refrigerant system, which is
normal as each cycle ends in your Wine
Cellar and Beverage Centre.
Contrac�on and expansion of the inside
walls may cause popping and crackling
noises.
The Wine Cellar and Beverage Centre is
not level.
Technical Data:
VWS820SCB-X
Models
750ml
Gas charge(g)
Net capacity
Preset Temperature (°C)
A
djustable t
e
m
p
in
degrees
Heater
(
1)
41
35g
132L
12°C
6 to 18 °C
- -
bordeaux
375ml
Beer
-
-
141
17 upper/
23 lower
-
35g
35g
124L
132L
6°C
upper 6°C
lower 12°C
upper 6-12°C
lower 10-18°C
2-10°C
Yes
Net weight
Gross weig
Number of shelves:
Dimensions (mm) (WxDxH)
ht
3
50kg
4
5
Packaged Dimensions
(mm) (WxDxH)
595x564x820
595x564x820
595x564x820
650x665x885
650x665x885
650x665x885
54kg
Capacity
(1)
Freestanding orSolt-in
Both
Both
Both
1. Models with a heater will raise their temperature to the set
temperature if the ambient temperature is below the set
temperature. Models without a heater will not raise the
If the refrigerant of these appliances are R600a , Flammable
to avoid the fire or explode caused.
VWD820SCB-X
VBS820SCB-X
50kg
54kg
44kg
48kg
Risk of Fire
Place appliance in a lower humidity area.
warmer above the coldest temperature
lower levels (recommended place appli-
air humidity area)
exterior surfaces, glass door,
sealing gasket strip.
This is a natural phenomenon
The symbols you will see in this booklet have these meanings:
safety.
WARNING
CAUTION
IMPORTANT
refrigerator.
economical and ecological use of the refrigerator.
ENVIRONMENT
refrigerator.
This refrigerator is designed and intended to be used in normal
.
Ambient Room Temperature Limits
This appliance is designed to operate in ambient
temperatures specified by its temperature class
marked on the ra�ng plate.
Class
Tropical
Extended Temperate
Temperate
Subtropical
Symbol
SN
N
ST
T
Ambient Temperatures
range(℃
﹢10 to﹢32
﹢16 to﹢32
﹢16 to﹢38
﹢16 to﹢43
)
In environments with higher humidity levels, condensate
droplets may appear on the appliance’s exterior door
surfaces.
If condensate droplets occur, here are some sugges�ons to
address the issue:
· Ensure adequate ven�la�on around the appliance to
reduce humidity levels.
· Wipe and clean the surfaces to prevent any build-up of
moisture and condensa�on.
· If the appliance se�ngs are too cold, try adjus�ng them
to be warmer to minimize condensa�on.
· Consider to move or relocate the appliance to a loca�on
with lower humidity levels.
· Use dehumidifiers in the room to lower overall humidity,
if possible.
Rela�ve
Humidity
≦75%
This document sets out the terms and conditions of the product
warranties for Vintec Appliances. It is an important document.
Please keep it with your proof of purchase documents in a safe place
for future reference should there be a manufacturing defect in your
Appliance. This warranty is in addition to other rights you may have
under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘Vintec’ is the brand controlled by Electrolux Home Products Pty Ltd
of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341
in
respect of Appliances purchased in Australia and Electrolux (NZ) Limited
(collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount Wellington, in
respect of Appliances purchased in New Zealand;
(e)
‘Warranty
Period’ means the period
in clause 3 of this
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not
exclude, restrict, or modify in any way) other rights and remedies under
a law to which the Appliances or services relate, including any non-
3.
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible
for service, without special equipment and subject to these te
rms and
conditions, repair or replace any parts which it considers to be defective.
Electrolux may, in its absolute discretion, choose whether the remedy
for a valid warranty claim is repair or replacement. Electrolux
or
its
ASC may use refurbished parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux or its ASC. Travel and transportation will
be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or de
fective parts or workmanship. This
warranty does not cover:
(c)
cosmetic
damage which does not
the operation of the
Appliance;
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
(v) power surges, electrical storm damage or incorrect power supply;
(vi) incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii) insect or vermin infestation;
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
(b) the Appliance is
without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced.
8.
How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the
terms of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replac
ement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
‘Acceptable quality’ and ‘major failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant to the provisions of the Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
11.
You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: VINTEC
Vintec Undercounter_Warr_Oct24
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
AUSTRALIA
FOR SERVICE
or to the address of your nearest
authorised service centre in Australia
PLEASE CALL 1800 666 778
For the cost of a local call
FOR ACCESSORIES
PLEASE CALL 1800 666 778
For the cost of a local call (Australia only)
or visit www.vintecclub.com
NEW ZEALAND
FOR SERVICE
or to the address of your nearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
FOR ACCESSORIES
PLEASE CALL 0800 550 020
(New Zealand only)
or visit www.vintecclub.com
Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in new Zealand
for a period of 24 months, following the date of original purchase of the
Appliance. Specific components are warranted against manufacturing
defects in Australia and New Zealand for the periods listed below;
• Compressor - Further 3 years
(b) parts and Appliances not supplied by Electrolux;
(a) light globes, batteries,
or similar perishable parts;
vintec.com
Vintec. We are part of the
Electrolux Family. To add
a touch of professional
inspiration to your home,
visit electrolux.com.au
© 2019 Electrolux Home Products Pty Ltd. ABN 51 004 762 341
Rev00_Sep 2024
Stay in touch and share your
user experience by following us:
@vintecclub
Service and support
1800 666 778
customercare@vintec.com.au
In the rare event that your Vintec cabinet does not perform
to your satisfaction, contact our dedicated support team:
