User Manual
DIGITAL CAMERA
KODAK PIXPRO WPZ2
1
Declaration of Conformity
Responsible Party: JK Imaging Ltd.
Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
Company website: kodakpixpro.com
INDUSTRY CANADA
This device complies with Canadian RSS-247.
This device complies with Industry Canada license-exempt RSS standard (s).Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Radiation Exposure Statement:
This product complies with the Canadian portable RF exposure limit set forth for an uncontrolled
environment and is safe for intended operation as described in this manual. Additional RF exposure
reduction can be achieved if the product can be kept as far as possible from the user body or set the device
to lower output power if such function is available.
BEFORE YOU START
2
For Customers in Europe
This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of electrical
waste and electronic equipment in the European countries. Please do not throw the equipment into
domestic refuse. Please use the return and collection systems available in your country for proper,
safe disposal of this product.
“CE” mark indicates that this product complies with the European requirements for safety, health,
environment and customer protection. “CE” marked cameras are intended for sales in Europe.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the RED Directive 2014/53/EU. The following
test methods have been applied in order to prove presumption of conformity with the essential
requirements of the RED Directive 2014/53/EU:
- EN 62368-1:2014
Safety of Information Technology Equipment
- EN 55032:2015/AC:2016 Class B
- EN 61000-3-2:2014
- EN 61000-3-3:2013
- EN 55035:2017
- EN 50360:2017
Assessment of electronic and electrical equipment related to human exposure restrictions for
electromagnetic fields (0 Hz-300 GHz)
- EN 300 328 V2.2.2 (2019-07)
Wideband transmission systems; Data transmission equipment operating in the 2.4 GHz ISM band and
using wide band modulation techniques
3
- EN 301 489-1 V2.1.1 (2017-02)
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility
(EMC) standard for radio equipment and services; Part 1: Common technical requirements
- EN 301 489-17 V3.1.1 (2017-02)
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility
(EMC) standard for radio equipment; Part 17: Specific conditions for Broadband Data Transmission
Systems
For SAR statement
A minimum separation distance of XX cm must be maintained between the user’s body and the device,
including the antenna during body-worn operation to comply with the RF exposure requirements in Europe.
To compliance with RF Exposure requirements in Europe, third-party belt-clips, holsters or similar
accessories used by this device should not contain any metallic components. The use of accessories that
do not satisfy these requirements may not comply with RF exposure requirements, and should be avoided.
Hereby, Sintai Optical (Shenzhen) Co., Ltd, declares that this KODAK PIXPRO WPZ2 is in compliance
with the essential requirements and other relevant provisions of Directive 2014/53/EU.
Manufacturer: Sintai Optical (Shenzhen) Co., Ltd
Address: Qiwei Ind Sec, 1st, 2nd,& 3RD Bldg, Lisonglang Village, Gongming Town, Bao’an
District, Shenzhen, Guangdong, China
Batteries: Please dispose of used batteries at designated collection centers.
Packaging: Please follow local regulations for the recycling of packaging.
4
For Customers in the U.S.A.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This product complies with the FCC portable RF exposure limit set forth for an uncontrolled environment
and is safe for intended operation as described in this manual. Additional RF exposure reduction can be
achieved if the product can be kept as far as possible from the user body or set the device to lower output
power if such function is available.
5
About this Manual
Thank you for purchasing this KODAK PIXPRO Digital Camera. Please read this manual carefully and keep it
in a safe place for future reference.
JK Imaging Ltd. reserves all rights of this document. No part of this published manual may be
reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or
computer language, in any form, by any means, without the prior written permission of JK Imaging Ltd.
All trademarks mentioned in this manual are used for identification purposes only and are properties of
their respective owners.
This manual provides you with instructions on how to use your new KODAK PIXPRO Digital Camera. Every
eort has been made to ensure that the contents of this manual are accurate; however JK Imaging Ltd.
reserves the right to make changes without notice.
Throughout this manual, the following symbols are used to help you locate information quickly and
easily:
Indicates useful information.
The following symbols may be used throughout this manual to facilitate your understanding of how to
operate the camera:
[Item properties]: The optional properties in the camera interface are indicated by the [ ] symbol.
6
If there is dust, sand or other foreign materials on
the waterproof rubber of the battery cover and its
contact surface, please wipe it with a clean, dry
and lint free cloth as soon as possible.
Before using the product underwater, make sure
that there is no damage to or foreign debris on
the waterproof rubber gasket. Then close the
battery cover tightly to ensure the waterproof
capability of the product.
Waterproof rubber with scratches and cracks
will allow water to penetrate into the product.
Contact customer service immediately
for maintenance with replacement of new
waterproof rubber.
SAFETY NOTES
Waterproof / Dustproof / Shockproof
JIS / IEC waterproof grade 8 (IPX8).
JIS / IEC dustproof grade 6 (IP6X).
Height for shockproof rating is 2m (6.6 feet).
Waterproofing Notes:
Do not use the product below 15 meters (49.2
feet) underwater. The product can remain
waterproof for one hour at the depth of 15m
(49.2 feet).
Do not use this product in a geothermal spring
or in water at a temperature greater than 40 °C
(104°F).
Please do not open the battery cover
underwater.
If water accidentally comes in contact with the
product, please do not open the battery cover.
Turn the product o, and dry it with a clean, dry
and lint free cloth. Then open the battery cover,
and remove the battery and the memory card.
When opening the battery cover, if there are
water drops on the contact surface between
the inside of the battery cover and the body,
please dry the water drops.
After using the product in water or near sand,
mud or other foreign materials, please rinse it
with clean water (close the battery cover before
cleaning). After cleaning, dry the product with a
clean, dry and lint free cloth.
Waterproof Rubber
7
Safety Notes for this Camera
Do not drop the camera or allow it to hit solid
objects.
Do not attempt to disassemble or repair the
camera.
Do not use or store the camera in a hot
environment or in direct sunlight.
Do not use or store the camera near powerful
magnetic fields, for example near a magnet or
transformer.
Avoid touching the lens of the camera.
Do not expose the camera to direct sunlight for
a long period of time.
If water accidentally comes in contact with
the interior of the camera, turn the camera
o immediately, remove the battery and the
memory card and dry it completely within 24
hours.
When you take the camera from a cold
environment to a warmer environment,
condensation may occur. Please wait for a
reasonable period of time before you turn the
camera on.
Make sure the camera is turned o before you
remove the battery and memory card.
When you clean the body of the camera, do
not use abrasive, alcohol-based or organic
cleansers or solvents.
Use a professional lens cleaning cloth and
appropriate cleaner to wipe and clean the lens.
Download your photos and remove the memory
card when you are going to store the camera
for long periods of time.
If this camera is not in use for a long period of
time, please keep it in a dry and clean storage
location.
Our company will not pay compensation for any
failure of playback of pictures or videos caused
by improper operation.
8
Safety Notes for Battery
Please use a battery that is the same type as the
one included.
Please use the included USB cable and AC
adapter to charge the battery inside the
camera.
If battery fluid leaks inside the camera, contact
our customer service department immediately.
If battery fluid leaks onto your skin, rinse your
skin with clean water and seek immediate
medical attention.
Disposal of used batteries should be carried
out in accordance with your local (national or
regional) regulations.
To prevent the battery from being damaged,
do not drop the battery or allow it to hit solid
objects or to be scratched by foreign objects.
Do not let the battery come in contact with
metal objects (including coins) to avoid short
circuiting, discharging, excessive heat or
possible leakage.
Do not attempt to disassemble the battery.
Do not expose the battery to water. Always keep
the battery contacts dry.
Do not heat the battery or throw it into a fire to
avoid a possible explosion.
Do not store the battery in a hot environment or in
direct sunlight
.
If the battery overheats during charging or use,
stop charging or stop use immediately. Turn o
the product, remove the battery carefully and
wait until it cools down.
When the camera is stored for a long period of
time, remove the battery and keep it in a safe,
dry place that is not accessible to infants and
children.
In colder environments, the performance of the
battery could be noticeably reduced.
When you install the battery, align the battery
markings according to the positive and
negative markings inside the camera battery
compartment. Never force the battery into the
battery compartment.
9
Safety Notes for Memory Cards
The memory card referred to in this user manual
is a microSD card/microSDHC card that is Class
4 or higher and no larger than 32GB.
We highly suggest buying only well-known,
name brand memory cards to ensure peak
performance and reliability.
Format the microSD/microSDHC memory card
using the camera before you use it to store
photo or video files or when you insert a new
microSD/microSDHC memory card.
Do not drop the microSD/microSDHC memory
card or allow it to hit solid objects to avoid
damaging it.
Do not attempt to disassemble or repair the
microSD/microSDHC memory card.
Do not expose the microSD/microSDHC
memory card to water. Always keep it dry.
Do not remove the microSD/microSDHC
memory card when the camera is turned on.
Otherwise, the memory card and photo/video
files could be permanently damaged.
Do not directly edit the data on the microSD/
microSDHC memory card. Copy the data to
your computer before you edit files.
When the camera is stored for long periods
of time, be sure to download your photos and
remove the microSD/microSDHC memory card.
Store the microSD/microSDHC memory card in
a dry environment.
Do not modify the name of the files or folders
of the microSD/microSDHC memory card using
your computer. Modifying the file names may
cause the files to not be recognized on the
camera or a possible permanent error may
occur.
A photo taken with the camera will be stored
in the folder that is automatically generated
on the microSD/microSDHC memory card. Do
not store photos that are not taken using this
camera in these folders as the pictures cannot
be recognized during playback.
When you insert the microSD/microSDHC
memory card, make sure the notch of the card
matches the markings on the top of the camera
card slot.
10
Other Safety Notes
Do not disconnect the power or turn the
camera o during the updating process. Doing
so may cause incorrect data to be written and
the camera may not power on later.
When using your camera on an airplane,
observe the relevant rules specified by the
airline and FAA regulations.
Due to the limitations of manufacturing
technology, the LCD may have a few dead or
bright pixels. These pixels do no eect the
quality or performance of the camera, photos
or video.
If the LCD screen is damaged, pay particular
attention to the liquid crystal in the screen. If
any of the following situations arise, take the
recommended immediate action indicated
below:
1. If liquid crystal comes in contact with your
skin, please wipe with a dry cloth, wash
thoroughly with soap, and rinse with plenty
of clean water.
2. If liquid crystal gets into your eye, flush the
eye immediately with plenty of clean water
for at least 15 minutes and then seek for
medical assistance.
3. If liquid crystal is swallowed, immediately
flush your mouth thoroughly with clean
water and induce vomiting. Seek for medical
assistance.
WARNING
Altering, tampering or modifying the any parts
of WPZ2 camera are unauthorized and will void
the manufacturer’s warranty and “could” void
Federal and/or State Compliance.
11
BEFORE YOU START ........................ 1
SAFETY NOTES ............................... 6
CONTENTS ..................................... 11
GETTING STARTED ......................... 15
Accessories Included ................................... 15
Part Names ................................................... 16
Installing Battery and microSD/microSDHC
Memory Card ................................................ 18
Charging the Battery .................................... 20
Turning Camera On and O......................... 21
How to Take Pictures .................................... 21
Set your Language, Date/Time .................... 22
Set your Language, Date/Time
after the First Power-On ......................... 22
Resetting your Language ....................... 22
Resetting Date/Time .............................. 23
MODE OVERVIEW .......................... 24
Display Setting ............................................. 24
LCD Screen Display ...................................... 25
Overview of the Screen Icons in
Photo Shooting Mode ............................ 25
Overview of the Screen Icons in
Movie Mode ............................................ 26
Using the Mode Button ................................ 27
Auto Mode .................................................... 28
Program AE ................................................... 30
Manual Mode ................................................ 30
Movie Mode .................................................. 31
Scene Mode (SCN) ....................................... 32
Panorama Mode ..................................... 35
Anti-Shake .............................................. 36
Underwater Mode
................................ 37
CONTENTS
12
Wi-Fi® Mode .................................................. 38
BASIC OPERATION ......................... 45
Using the Zoom Function............................. 45
Macro Mode.................................................. 46
Self-Timer Setting ......................................... 47
Flash Mode ................................................... 48
EV Setting ..................................................... 49
Exposure Compensation ....................... 49
ISO .......................................................... 50
Shutter Adjustment ................................ 50
Using Quick Recording ................................ 51
PLAYBACK ...................................... 52
Overview of the Screen Icons in
Playback Mode ............................................. 52
Viewing Photos and Videos ......................... 53
Thumbnail View ............................................ 54
Using Zoom Playback (for Still Pictures Only)
55
Continuous Capture Group Playback .......... 56
Animation Panorama Play ............................ 57
Slideshow ..................................................... 58
Deleting Photos and Videos ......................... 59
USING THE MENUS ........................ 60
Photo Setup Menu ........................................ 60
Expo Metering (Exposure Metering) ..... 60
Image Size .............................................. 61
Continuous Auto Focus (AF ) ................. 61
Continuous Shot .................................... 62
Focus Setting ......................................... 63
White Balance Setting ........................... 63
Color Eect ............................................ 64
Select Scene .......................................... 65
13
Photo Shooting Setting Menu ..................... 67
Quality .................................................... 67
Auto Focus (AF) Assist Beam ................. 68
Digital Zoom ........................................... 68
Date Imprint ........................................... 69
Quick Review.......................................... 69
Face Detection ....................................... 70
Movie Menu .................................................. 71
Expo Metering (Exposure Metering) ..... 71
Video Quality .......................................... 72
Color Eect ............................................ 73
Movie Setting Menu ..................................... 74
Digital Zoom ........................................... 74
Playback Menu ............................................. 75
Display Mode .......................................... 75
HDR ......................................................... 76
Red-Eye Reduction ................................. 76
Rotate ..................................................... 77
Resize ..................................................... 77
Color ...................................................... 78
Playback Setting Menu ................................ 79
Protect .................................................... 80
Delete ..................................................... 81
DPOF (Digital Print Order Format) ......... 82
Trim ......................................................... 82
Setup Menu .................................................. 83
Power Saver............................................ 84
Sound Settings....................................... 84
Language ................................................ 85
World Time ............................................. 85
Date & Time ............................................ 85
LCD Brightness ....................................... 85
SD Card /Firmware ....................................... 86
Format ................................................... 87
14
Copy to Card .......................................... 87
File Numbering ....................................... 88
Reset ....................................................... 88
Firmware (FW) Version ........................... 89
CONNECTIONS .............................. 90
Connecting to a Computer .......................... 90
Setting the USB Mode ........................... 90
Transferring Files to Your Computer ..... 91
Connecting to Pictbridge
Compatible Printers ..................................... 92
Setting the USB Mode ........................... 92
Connecting to your Printer .................... 93
Using the Pictbridge Menu .......................... 94
Print (with Date) ..................................... 94
Print (without Date) ................................ 95
Print Index .............................................. 96
Print DPOF Images ................................. 97
Exit .......................................................... 97
APPENDICES .................................. 98
Specifications ............................................... 98
Prompts and Warning Messages ................. 102
Troubleshooting ........................................... 106
microSD Memory Card Compatibility ... 108
15
GETTING STARTED
Your camera box should contain the camera model you purchased along with the following accessories.
If anything is missing or appears to be damaged, please contact your retailer first or our customer service
center. (The AC Adapters may be a little dierent in shape due to the dierence of countries or regions this
type of cameras are sold to, and are subject to matching the physical product).
Accessories Included
Micro USB Cable
Warranty Card
AC Adapter Wrist StrapRechargeable
Li-ion Battery
W
arranty Ca
rd
Quick Start Guid
e
Quick Start Guide
Service Card
ST
OP
16
Part Names
8
7
63
1
2
4 5
1. Strap Eyelet
2. Shutter Button
3. Power Button
4. Auto Focus (AF) Assist Beam/
Self-Timer Lamp
5. Speaker
6. Microphone
7. Flash Lamp
8. Lens
17
9
10
11
12
13
14
15
16
17
19
20
22 212324
18
25
26
9. Mode Button
10. Zoom Button
11. Indicator Lamp
12. Quick Video Recording Button
13. Display Button/Arrow Button (Up)
14. Flash Button/Arrow Button (Right)
15. SET Button
16. Delete Button/Self-Timer Button/
Arrow Button (Down)
17. Playback Button
18. Menu Button
19. Battery Cover Door
20. Battery Cover Door (Open) Toggle
Switch
21. Battery Cover Door Lock
22. Macro Button/Arrow Button (Left)
23. LCD
24. Tripod Socket (1/4’’ Standard)
25. Micro USB Port
26. microSD/microSDHC Card Slot
(32GB max)
18
2. Insert the battery into the battery compartment
as shown in step ③ being sure to line up metal
contacts on bottom of battery with the contacts
in slot. Push the battery down until it locks in
place.
3
1. Unlock the battery cover door lock as shown
in step ①, push the battery cover door open
switch to open the battery cover door as shown
in step ②.
2
1
Installing Battery and microSD/microSDHC Memory Card
Battery
Lock Knob
19
3. Insert the microSD/microSDHC memory card
(not to exceed 32GB) into the memory card
slot as shown in step ④, push exposed edge
of the microSD/microSDHC memory card
fully into the slot with your fingertip.
4. Close the battery cover door as shown in step
⑤, push the battery cover door switch to
close the battery cover door as shown in step
⑥ and be sure to lock the battery cover door
latch as shown in step ⑦.
4
7
5
6
A microSD/microSDHC memory card is NOT included with this camera packaging and needs to be
purchased separately. This camera takes a microSD/microSDHC memory card. We recommend using a
name brand memory card that is Class 4 or higher and has a capacity of 4GB to 32GB. This camera is
not compatible with standard SD cards.
To remove your microSD/microSDHC memory card, open the battery cover door, gently press the
memory card to eject it and remove it carefully.
20
Before you charge your battery, make sure the
camera is o and the battery is inserted correctly.
1. Connect the camera to the power charger using
the supplied USB cable.
2. Insert the plug of the power charger into the
wall outlet to charge the battery.
The charger is for indoor use only.
After the battery is stored for long periods of
time, use the supplied power charger to fully
charge the battery prior to use.
Charging Indicator:
Steady orange : Charging
The indicator lamp will go out once charging
is finished and the camera will power o
automatically. To maximize battery life,
charge the battery for at least 4 - (4-hours)
hours the first time.
When the camera is turned o, you can also
connect the camera to your PC using a USB
cable to charge the battery.
Please charge the battery indoors between
0°C and 40°C (32°F and 104°F).
Charging the Battery
1
2
3
21
Turning Camera On and Off
Press the Power button to turn the camera on. To
turn the camera o, press the Power button again.
Power Button
When the power is o, press and hold
the play
button to power on and enter
Playback mode.
How to Take Pictures
1. Hold the camera with both hands, being careful
to not block the flash and lens with fingers.
2. Point the lens toward the object you want to
take a picture of, then frame it with the LCD.
3. Use the zoom button to select Tele or Wide
position to zoom in or out on your subject(s).
4. Gently press the shutter button half-way down
to focus on your subject
(s). When the focus
frame turns green, press the shutter button
completely down to take your photo.
22
2. Press the up/down arrow buttons to select ,
and press the button or right arrow button to
enter the menu.
3. Press the up/down arrow buttons to select
[Language] and press the
button or right
arrow button to enter the menu.
4. Press the arrow buttons to select your desired
language and press the
button to confirm.
5. Press the
button and the snapshot screen
will appear.
2019.08.01 00:00
Sound Settings
Power Saver
Language
World Time
Date & Time
English
Home
Auto
Set your Language, Date/Time
Set your Language, Date/Time after the First
Power-On
1. When you turn the camera on for the first time,
the language selection screen appears.
2. Press the arrow buttons to select your desired
language.
3. After you press the
button to confirm your
language selection, the Date/Time settings
screen will appear.
4. Press the left/right arrow buttons to select the
Date/Time to be adjusted: Time is displayed in
YYYY.MM.DD/HH:MM.
5. Press the up/down arrow buttons to adjust the
value for the desired Date/Time.
6. Press the
button to confirm the time settings
and the snapshot screen will appear.
Resetting your Language
After you set your language for the first time,
follow the instructions below to reset your desired
language.
1. Press the
button and press the up/down
arrow buttons to select . Press the button
to enter the menu.
23
English
Français
Español
Svenska
Português
Italiano
Deutsch
Рyсский
Language
Resetting Date/Time
After you set your Date/Time for the first time,
follow the instructions below to reset date and
time.
1. Press the
button and press the up/down
arrow buttons to select . Press the button
to enter the menu.
2. Press the up/down arrow buttons to select
,
and press the
button or right arrow button to
enter the menu.
3. Press the up/down arrow buttons to select [Date
& Time] and press the
button or right arrow
button to enter the menu.
4. Press the left/right arrow buttons to select the
Date/Time to be adjusted: Time is displayed in
YYYY.MM.DD/HH:MM.
5. Press the up/down arrow buttons to press the
value for your selected entry. After you finish
your settings, press the
button to confirm.
6. Press the
button and the following snapshot
screen will appear.
2019.08.01 00:00
Sound Settings
Power Saver
Language
World Time
Date & Time
English
Home
Auto
Date & Time
Back
. .
08 01 00
:
00
H-M
2019
24
Press the button to display the settings:
Classic, Full, O.
Classic: Displays the camera parameters on screen
x3.5
-0.3
EV
15
F3.0 400
ISO
1234
00:56:00
SD
Full: Camera parameters with Grid and Histogram
F3.0
SD
x3.5
-0.3
EV
15
F3.0 400
ISO
1234
00:56:00
O: Does not display any additional icons on
screen
Display Setting
MODE OVERVIEW
25
LCD Screen Display
Overview of the Screen Icons in Photo Shooting Mode
SD
17
22
21
20
18
1
2
34
5
6
7
9
10
8
11121314
1516
19
x3.5
-0.3
EV
15
F3.0 400
ISO
1234
00:56:00
1 Shooting Mode 6 White Balance
12
Remaining
Recording Time
17 Aperture Value
2 Macro Mode 7 Color Eect 18 Continuous Shot
3 Zoom Display 8
Number of Remaining
Shots
13
Exposure
Compensation
19 Expo Metering
4
Memory Card/
Built-In Memory
9 Image Size 14 Focus Frame 20 Self-Timer
10 Video Quality 15 Shutter Speed 21
Auto Focus (AF)
Mode
5 Battery Status 11 ISO Value 16 Histogram 22 Flash Mode
26
Overview of the Screen Icons in Movie Mode
x3.5
-0.3 EV
00:56:00
SD
123
4
65
7
8
910
11
12
13
1
Movie Mode
6
Battery Status 11 Focus Frame
2
Macro Mode
7
Color Eect 12 Expo Metering
3
Self-Timer
8
Video Quality 13 Auto Focus (AF) Mode
4
Zoom Display
9
Remaining Recording Time
5
Memory Card/Built-In Memory
10
Exposure Compensation
27
Using the Mode Button
This camera provides a convenient Mode button that allows you to switch easily between dierent modes.
After pressing the Mode button to enter the Mode Selection Menu, press the left/right button to choose the
selected mode. Press the button to confirm your selection. All the available modes are listed below:
Mode Name Icon Description
Auto Mode
In this mode, the optimal conditions for taking pictures will be set based on
the subject and environment. It is the most commonly used mode for taking
pictures.
Program AE
Under dierent scenes, the user can switch the ISO and EV value according to
personal preference, the camera can automatically set the shutter speed and
aperture value.
Manual Mode
Shutter Speed and ISO can be configured manually in this mode.
Movie Mode
Record videos.
Scene Mode
Choose from 18 dierent pre-set scene types and eects for your photos.
Underwater Mode
Switch to take still pictures underwater.
Wi-Fi
®
Mode
Enable image transmission and remote control by connecting smart device
with Wi-Fi®.
28
Auto mode is the most common and easiest mode to take photos. While operating in this mode, the camera
automatically optimizes numerous camera settings to take photos and videos with the best possible results.
x3.5
SD
1234
00:56:00
Follow these steps:
1. Press the
button to select Auto Mode ( ) and then press button to confirm.
2. Hold the camera steadily and aim at the subject. The optimum scene mode will be selected
automatically.
3. Compose your picture in the LCD and press the shutter button halfway down to focus on your subject
(s).
4. The LCD will show a green focus frame when the subject is in focus.
5. Fully press down the shutter button to take your photo.
Auto Mode
29
The camera will automatically detect the most suitable scene to capture the best pictures.
Mode Name Description
Landscape Mode
For landscapes, automatically adjusts the exposure and reproduces vivid
green and blue colors.
Portrait Mode
Most suitable for capturing people with focus on their faces.
Night Portrait
When you take portraits at night, or in low light conditions, automatically
adjusts the exposure for people and night scenes.
Backlit Portrait
When the sun or any other light source is behind you, automatically
adjusts the foreground exposure to produce the best pictures possible.
Night Landscape Mode
For night scenes, automatically increases the ISO value to compensate for
low light.
Macro Mode
The macro setting is ideal for shooting small objects or close-up photos.
Auto Mode
The camera automatically adjusts the exposure and focus to ensure the
best possible pictures.
Macro ON/OFF and flash are automatically controlled, users cannot change the settings.
30
Manual Mode
When selecting ( Manual Mode ), you can adjust
shutter speed manually and ISO value.
1. Press the
button to select Manual Mode
( ), press button to confirm.
400 ISO
15 sec
-0.3 EV
F3.0
F3.0
2. Press the left/right arrow buttons to select an
adjustment setting.
3. Press the up/down buttons to adjust the
parameters.
4. Press the
button to confirm the settings and
enter the shooting screen.
Program AE
When selecting (Program AE) mode is selected,
you can adjust the EV value and ISO value.
1. Press the
button to select Program AE ( ),
press button to confirm.
-0.3 EV
400 ISO
F3.0
F3.0
1/50
2. Press the left/right arrow buttons to select an
adjustment setting.
3. Press the up/down buttons to adjust the
parameters.
4. Press the
button to confirm the settings and
enter the shooting screen.
31
Movie Mode
Switch to this mode to record videos.
1. Press the
button to select Movie Mode
( ) and then press button to confirm.
2. Press down the Shutter Button to start
recording.
00:00:06
3. Once you are finished, press the Quick Video
Recording Button or the Shutter Button to stop
recording and return to the shooting screen.
In the recording process, you can push
the zoom buttons to Zoom in or out on the
subject.
Please refer to the table below for unavailable
options in
modes: (O:Available X: Not
Available)
Options
Mode
Aperture Shutter EV ISO
X X O O
X O X O
X X O X
Please note that even if an option is not able
to be adjusted in a particular mode, its value
will still be displayed on the shooting screen.
32
Scene Mode (SCN)
You can select an appropriate mode from the 18 scene modes according to the type of environment you are
shooting in. The camera then automatically configures the most appropriate settings for the best possible
photos.
1. Press the
button to select Scene Mode and then press button to enter the Scene Mode menu.
Portrait
2. Press the arrow buttons to select a scene and press the button to confirm.
3. To change to a dierent scene, press the
button and then the button and finally the arrow buttons
to to reselect the scene.
33
Scene Description
Portrait
Most suitable for capturing people, focusing on their face.
Landscape For landscapes and outdoor shots. Vivid reproduction of greens and blues.
Sport
For fast-moving subjects. Captures sharp, action shots with minimal blur.
This mode is not recommended for shooting indoors.
Beach For taking pictures in areas with strong sunlight.
Sunset For sunsets. Captures subjects in strong sunlight.
Fireworks For fireworks at night. Use of a tripod is recommended with this setting.
Night Landscape For night scenes. Use of a tripod is recommended with this setting.
Snow For snowy conditions. Reproduces natural, clear, white scenes.
Children
Turns flash o automatically. Avoids disturbing the subject and is suitable for
taking photos of children and pets.
Panorama Mode
For shooting up to 360-degrees of landscape.
34
Scene Description
Glass For objects behind transparent glass.
Anti-Shake Digital image stabilization to take clear pictures in the handheld state.
Panning Shot
Suitable for capturing fast moving objects to have a clear subject with a
blurred background.
Night Portrait For portraits against night scenery.
Party
Suitable for taking indoor party pictures, even under complicated lighting
conditions.
Indoor For indoor settings. Reduces blur and improves color accuracy.
Leaf For plants. Captures brilliant shots of greenery and blossoms.
Museum For museums or flash-free areas. Retains color and reduces blur.
35
Panorama Mode
This feature allows you to capture a panoramic
view that will have significantly more content
than a single photograph. Follow the arrow while
keeping the camera steady to seamlessly shoot an
ultra-wide scene of up to 360 degrees.
Follow the steps below:
1. Select the Panorama Mode (
) and then
press the button to confirm.
2. Press the arrow buttons to select a desired
shooting direction. Should you not select a
direction, the default shooting direction is
“right.” 2 seconds later, the camera will be ready
to take pictures. You can also press the
button or press the shutter button halfway down
to get ready to take panaramic pictures.
3. Compose your shot on the LCD and half press
the shutter button to focus on the subject. After
focusing, fully press the shutter button down to
take the first picture. At this time, the process
dialog of panorama mode stitching appears on
the screen.
1/50F3.3
Save Cancel
4. Pan the camera according to the set direction.
When the range of motion does not exceed the
range that the camera can detect, the progress
bar behind the arrow partially turns red. When it
completely turns red, panorama mode shooting
is finished.
In Panorama Mode, the Flash, Self-Timer,
Macro Modes and Exposure Compensation
are not available. Focus Adjustment is also
not available at this time.
During Panorama Mode shooting, press the
button to interrupt shooting and save the
current pictures. Press the down button
( ) to cancel shooting and delete
previously taken pictures.
36
During panorama mode shooting, when the
moving direction of the camera is wrong or
the angle deviates from the internal settings,
the LCD shows a warning message [Improper
alignment. Please try again.] and the current
pictures taken are saved.
Panoramic image can be played back by
the method of flash playing. Please see the
animation panoramic playback on page 57.
Anti-Shake
This mode can help reduce photo blur caused by
shakiness of hands, low light and/or slow shutter
speed.
Use Anti-Shake mode in dark environments or
when using a slower shutter speed.
Shooting in a windy or unstable environment
(such as a moving vehicle) may cause blurry
images.
37
Underwater Mode
When you are in the water, you can select Underwater Mode in the Mode Selection menu to take pictures
under water.
Press the
button to enter Underwater Mode ( ) and then press button to confirm.
Underwater Mode
Save
38
Wi-Fi® Mode
Enable image transmission and remote control by connecting smart device with Wi-Fi®.
Before utilizing Wi-Fi® Mode, please review the following:
Your smart device operating system version needs to be iOS 11 or higher, or ANDROID 6.0 or higher. If
not, please upgrade your smart device before using the APP.
Please do not use in places that have a high intensity magnetic field, electrostatic and electric wave
interference (for example near a microwave oven), which may cause failure in receiving signals.
To maintain a connection, please keep the camera within 10 meters (32.8 feet) without signal shielding
interference.
Please do not use Wi-Fi® connection functionality on a plane.
The camera and the smart device can only be connected one to one.
Downloading the APP package:
Download a dedicated installation package from the application store (APP name: PIXPRO Remote Viewer
) and then install it.
• ANDROID
™ devices : Search and download the APP “PIXPRO Remote Viewer” in Google play, and
install it following the instructions on the interface.
• iOS
™ devices : Search and download the APP “PIXPRO Remote Viewer” in APP store, and install it
following the instructions on the interface.
39
Press the button to select and then press
button to enter the Wi-Fi® selection interface.
●
To ensure a stable connection, please connect
to the new camera in Wi-Fi settings
●
Ensure that the password is correct.
Next
• Next: Enter the SSID interface.
Press the mode button to disconnect.
Settings of Camera:
Press the up/down buttons to select options to
be adjusted, and press the
button to enter the
option setting interface.
Wi-Fi Mode
Cancel
Change Password
Setting pre-connected device for the
following serial number:
SSID:
PIXPRO WPZ2_XXXX
WPA2-PSK: XXXXXXXX
• Change Password: Enter the WPA2 PSK
password refresh interface.
Yes: Create a new WPA2
PSK password.
No: Back to previous page.
• Cancel: Back to previous page.
40
Settings of Smart Device:
1. Enable the Wi-Fi® of smart device and then
search surrounding wireless devices.
2. Select the name of camera SSID to be
connected and then input the eight-digit
number password after WPA2-PSK on the
camera.
3. Click the icon of the PIXPRO Remote Viewer
APP
to enable the APP.
Set up completion:
Once the APP is connected to the camera,
functional operation can be enabled on the
connected smart device.
Every WPZ2 camera is shipped with a
default factory Wi-Fi® password that is
randomized and unique to that camera and
will not change unless you wish to reset the
password with a new randomly generated
password. If you wish to change the Wi-Fi®
password in your WPZ2 from the assigned,
unique factory password, you can do so by
selecting and using the Change Password
setting. If “Yes” is selected, a new random
password will be generated and saved in
the camera until changed or if you use the
“Reset” function. If you reset your WPZ2 to
the factory settings, then the initial, randomly
factory assigned and unique Wi-Fi® password
will be restored to your camera. (Please refer
to Reset instructions on page 88).
41
Display of Wi-Fi® Connection Status:
The Wi-Fi® has successfully connected but APP is
not enabled.
Connected with device
MAC address: xx:xx:xx
Disconnect
The Wi-Fi® has successfully connected and APP is
enabled.
Connected with App
XXXXX
Disconnect
42
To disconnect from Wi-Fi®:
Wi-Fi Mode
No
Disconnect from device?
Yes
• No: Keep Wi-Fi® connected and back to
previous page.
• Yes: Disconnect and back to Wi-Fi®
connection screen.
Disconnected from smart device Wi-Fi®:
Disconnected, please check wifi device
and try again.
Back
• Back: Back to the SSID interface.
43
Setting
The name of this camera can be changed under
Wi-Fi® settings.
1. In other modes, press the
button and press
the up/down button to select . Press the
button to enter the menu.
2. Press the up/down button to select
and
press the
button or right arrow button to
enter the menu.
3. Press the up/down buttons to select options
to be adjusted and then press the
button to
enter the menu.
DSC Device
MAC Address:
PIXPRO WPZ2_XXXX
38:67:93:XX:XX:XX
4. Press the button to confirm settings and
then skip the menu.
DSC Device
The default name of DSC device is [PIXPRO WPZ2_
XXXX]. Change the name of DSC device through
typing.
Name between 1-17 Letters
PIXPRO WPZ2_XXXX
Cancel
DSC Device
Save
#!?
ABCDEFGH IJ
KL
MNO
PQ RST
UV
WXYZ
A/a
4 567 90
123
Meanings of Interface Icons:
Icon Description
Delete the last letter
Switch the display of letters
in capital and lowercase
Move the Cursor
#!?
Switch the symbol input
Input Space
MAC Address
Check the wireless MAC address of this camera.
44
APP Operating Instructions
Refer to the "PIXPRO Remote Viewer User Manual"
located on the web:
Americas / Europe
http://kodakpixpro.com/Americas/
support/downloads.php
45
Your camera is equipped with two types of Zoom
Functions: Optical Zoom and Digital Zoom. Press
the Zoom button of the camera to zoom in or out
on the subject while taking pictures.
Using the Zoom Function
BASIC OPERATION
x3.5
-0.3
EV
15
F3.0 400
ISO
1234
00:56:00
SD
Zoom Indicator
When the Optical Zoom reaches the threshold as
Digital Zoom, release and turn the Zoom Button to
T to switch between the Optical Zoom and Digital
Zoom.
46
Macro Mode
The Macro Setting is ideal for shooting small
objects or close-up photos. This mode allows you
to focus on subjects very close to the camera.
1. Press the left arrow button (
) to enter the
Macro Menu.
Macro O
2. Press the left/right arrow buttons to select the
following 2 modes:
•
Macro O
Select this option to disable Macro.
•
Macro On
Select this to focus on subjects 5cm
from the lens.
3. Press the
button to confirm the settings and
exit the menu.
47
Self-Timer Setting
Use this function to take pictures at pre-set
intervals. The camera shutter speed can be set to
2 seconds, 10 seconds or when a smile is detected.
1. Press the down arrow button (
) to enter
the Self-Timer Menu.
Self-timer O
2. Press the left/right arrow buttons to select one
of the following 4 modes:
•
Self-timer O
Disables the Self-Timer.
•
Self-timer 2sec
A single picture is shot 2 seconds after
the Shutter Button is pressed.
•
Self-timer 10sec
A single picture is shot 10 seconds after
the Shutter Button is pressed.
•
Self-timer Smile
Press the Shutter Button and a picture
will be taken immediately after a smile
is detected.
3. Press the
button to confirm the settings and
exit the menu.
When enabling the Self-Timer, pressing the
Shutter Button or the (
) button will
select the highlighted Self-Timer option and
return to the shooting screen, and keep the
Self-Timer setting.
When enabling the smile detection, pressing
the Shutter Button or the
button will select
the Self-Timer smile option (if highlighted)
and return to the shooting screen, and
keeping the Self-Timer smile setting.
48
Flash Mode
The flash provides supplemental light for scenes.
The flash is usually used when shooting against the
light to highlight the object; it is also suitable for
metering and shooting in darker scenes to improve
the exposure.
1. Press the right arrow button (
) to enter the
Flash Settings Menu.
Force O
2. Press the left/right arrow buttons to select one
of the following 6 modes:
•
Force O
Flash is turned o.
•
Flash Auto
Camera flash goes o automatically
based on lighting conditions.
•
Fill Flash
The flash will engage with each shot
even, supplementing the existing light
in a scene and helping to eliminate
shadows.
•
Slow Sync.
This allows you to take pictures of
people at night that clearly show
both your subjects and the night
time backdrop. The use of a tripod is
recommended when shooting with this
setting.
•
Slow Sync.+Red-Eye
Use this mode for slow synchrony shots
with red-eye reduction.
•
Red-Eye Reduction
The camera emits a brief pre-flash
before the picture is taken to reduce
red-eye eects.
3. Press the
button to confirm the settings and
exit this option.
49
EV Setting
The EV function menu of the camera includes
functions, such as EV (Exposure Value) Adjustment,
ISO, Shutter Adjustment, Aperture Adjustment,
etc. Using the appropriate function settings can
improve your pictures.
To select the best setting for optimum photos,
follow these steps:
1. Press the
button to display the Settings
screen.
2. Press the left/right arrow buttons to select the
Setting options.
-0.3 EV
-0.3 EV 400 ISO
400 ISO
F3.0
1/50
3. Press the up/down arrow buttons to adjust the
option values.
4. Press the
button to complete the setting and
enter Shooting Mode.
Exposure Compensation
Set up to adjust the picture brightness. In the case
of a very high contrast between the photographed
object and the background, the brightness of the
picture can be appropriately adjusted.
(This can be adjusted in
Mode)
-0.3 EV
-0.3 EV 400 ISO
400 ISO
F3.0
1/50
The adjustable range of exposure value is from EV
-3.0 to EV +3.0.
50
ISO
ISO allows you to set the sensitivity of the camera
sensor. Please use a higher ISO value in darker
places and a lower value in brighter conditions.
(This can be adjusted in
Mode)
-0.3 EV
400 ISO
-0.3 EV
400 ISO
F3.0
F3.0
1/501/50
The camera's ISO settings include: Auto, 100, 200,
400, 800, 1600 and 3200.
Shutter Adjustment
For shutter speed, the camera may automatically
set the aperture value corresponding to the
manually set shutter speed to obtain the most
suitable exposure value. The movement of objects
may be shown by adjusting the shutter speed.
High shutter value can help you more clearly
capture fast moving objects, while low shutter
value can better show the movement of objects.
(This can be adjusted in Mode)
-0.3 EV
15 sec
400 ISO400 ISO
15 sec
-0.3 EV
F3.0
51
Using Quick Recording
While in the Photo Shooting Mode, press the Quick Video Recording Button to begin recording a video.
00:00:06
Once you are finished, press the Quick Video Recording Button or the Shutter Button to stop and store
the video. The camera’s microSD Memory Card (max 32GB ) will store the video and return to the shooting
screen.
52
PLAYBACK
1/45
08-01
08-01 15:3715:37
x2
SD
12 3
4
5
6
7
8
20192019
9
11
12
13
25
10
1 DPOF File
2 File Protection
3 Memory space (indicating the current number
of photos and total number of photos)
4 Memory Card/Built-in Memory
5 Battery Status
6 Zoom Magnification Area
7 Image Zoom Ratios
8 Image Zone
9 Shooting Date
10. Continuous Capture Group Playback
11 Red-Eye Reduction
12 HDR
13 Date Folder
Overview of the Screen Icons in Playback Mode
53
Viewing Photos and Videos
To view captured photos and video clips on the LCD:
1. After pressing the
button, the last photo or video clip taken will be displayed on the LCD.
2. Use the left/right navigation buttons to scroll through the photos or video clips stored on the built-in
memory or on the Memory Card in the camera.
3. To play a selected video clip, press the
button to enter the Movie Playback Mode.
An operation guide appears on the screen when playing back a video. Press the appropriate buttons to
enable the corresponding functions.
00:00:47 00:01:23
00:00:47 00:01:23
1 Increase Volume
2 Pause
3 Fast Forward
4 Decrease Volume
5 Rewind
6 Return back to the beginning of the video
7 Play
8 Frame Forward
9 Cancel Playback
10 Frame Backward
Mute
54
Thumbnail View
When in Playback Mode, press the on the Zoom
button to display thumbnail images of photos and
videos on the screen.
1. Slide the Zoom button to switch between 3 x 3
and 4 x 4 thumbnails.
2. When a 3 x 3 or 4 x 4 thumbnail is displayed,
press the arrow buttons to select the picture or
video clip to view.
3. Press the arrow buttons to select a picture or
video clip to view and press the button to
restore it to the original size.
If the
indicator appears on the LCD, then
a movie file is currently being displayed.
55
4. Press the arrow buttons to navigate and select
the desired portion of the photo to be zoomed
in on.
5. Press the button to return the image to its
original scale.
Movie images cannot be magnified.
Using Zoom Playback (for Still Pictures Only)
When playing back photos, you can also use the
Zoom Button to zoom in on the photos, 2 to 8
times their original magnification.
1. Press the left/right buttons to select the picture
on which to use the zoom feature.
2. Press the on the Zoom Button to zoom in.
3. The bottom right corner of the screen will
display the amount zoomed in as well as the
area of the photo shown.
x2
56
Continuous Capture Group Playback
Cont.Shot-High Speed (VGA) and Cont.Shot-Fast (4M) can make continuous capture for group image
playback.
1. Press the
button to enter playback screen.
2. Press the left/right buttons to select Cont. Group.
3. Press the
to start playback.
25
25
1/45
SD
2019
2019
08-01 15:37
15:37
08-01
57
Panoramic Animation Playing is when full size images are played in accordance with the shooting direction.
After playing, it will automatically return to the initial panorama screen.
1. Press the
button to enter Playback Screen.
2. Press the left/right arrow buttons to select animated panoramic photos.
3. Press the
button to play in selected shooting direction.
1/45
SD
10-25 15:37
2019
In the process of panoramic animation playback, press the down button ( ) to stop playing and
return to the playback screen.
Animation Panorama Play
Pause
Cancel Play
Video Panorama Playing Pause
58
This setting allows you to view all the stored pictures as a slideshow.
1. Press the
button to enter playback screen.
2. Press the
button to enter slide option.
3. Press the left/right buttons to select slideshow playing or [Cancel] to return to the playback
screen.
Play Slide Show
Eect 1
4. Press the button to confirm the setting.
Slideshow
59
Deleting Photos and Videos
In Playback Mode, press the down arrow button
( ) to select your desired photos and videos.
To delete photos or videos:
1. Press the button to switch to Playback Mode.
2. Press the left/right arrow buttons to select the
photos and videos to be deleted.
3. Press the down arrow button (
) and the
deletion screen is displayed.
Delete One
Exit
4. Press the up/down arrow buttons to select
[Delete One] or [Exit] and press the button
to confirm.
Erased photos/video clips cannot be
recovered.
Please refer to page 81 for instructions on
deleting more than one image at a time.
60
Photo Setup Menu
USING THE MENUS
Mode:
1. In Photo Shooting Mode, press the button to
enter the Photo Shooting Menu.
2. Press the up/down arrow buttons to select the
Photo Shooting Menu and settings.
3. Press the left/right arrow buttons to select the
Photo Shooting Menu to be set and press the
button to confirm.
Expo Metering: AiAE
Functions that can be enabled are dierent
under each mode.
Expo Metering (Exposure Metering)
Use this setting to select the "target" size of the
camera's field of view to be metered.
Expo Metering: AiAE
There are 3 options:
• AiAE (Artificial Intelligence AE): Evaluates
the light intensity at multiple points in the
frame and automatically determines the
best value for the light meter.
• Spot metering targets a small area in the
center of the camera's field of view.
• Center metering targets a slightly larger
area in the center of the camera’s field of
view.
61
Image Size
The size setting refers to the image resolution in
pixels. A higher image resolution allows you to
print that image in larger sizes without degrading
the photo image quality.
16MP:4608×3456(4:3)
The bigger the number of recorded pixels is,
the better the image quality becomes. As the
number of recorded pixels lessens, you will
be able to record more images on a memory
card.
Continuous Auto Focus (AF )
Use the Continuous AF setting to be able to
continuously focus automatically when taking
pictures.
Cont.AF: O
There are 2 options:
• O
• On
62
Continuous Shot
Use this setting to perform continuous shooting.
After entering this mode, you can shoot multiple
images by continuously holding the shutter button
down.
Time-Lapse 30sec
There are 8 options:
•
Single
Capture a single shot only.
•
Continuous Shot
Take several pictures at a time.
•
Cont.Shot-High Speed (VGA)
For continuous shot with VGA pixel.
•
Cont.Shot-Fast (4M)
For continuous shot with 4M pixels.
•
Time-Lapse 30sec
•
Time-Lapse 1min
•
Time-Lapse 5min
• Time-Lapse 10min
In Continuous Shot mode, the flash is
automatically set to Force O in order to
achieve quick succession of shots.
63
Focus Setting
This setting allows you to select dierent modes
for optimum focus.
Single-AF
There are 2 options:
•
Single-AF: The focus frame appears on
the center of the LCD to help you focus
on the subject.
•
Multi-AF: The camera automatically
focuses the subject in a wider area to
find the focal point.
White Balance Setting
The white balance setting allows you to adjust the
color temperature for dierent lighting conditions
to ensure the most accurate color reproduction.
1. Press the
button to enter the white balance
setting menu.
2. Press the left/right arrow buttons to select the
White Balance Setting options.
AWB
There are 9 options in mode:
•
AWB
•
Daylight
•
Cloudy
•
Fluorescent
64
• Fluorescent CWF
•
Incandescent
•
Manual WB (Fully press the Shutter
Button to detect the white balance
value)
•
Color Temp. (1900K~10000K)
Press the direction buttons up/down to
"Adjust the K value"; Press the direction
button left to exit the K value.
•
Underwater
There are 4 options in
mode:
•
AWB
•
Manual WB (Fully press the Shutter
Button to detect the white balance
value)
•
Color Temp. (1900K~10000K)
Press the direction buttons up/down to
"Adjust the K value"; Press the direction
button left to exit the K value.
•
Underwater
3. Press the
button to confirm the settings and
exit the menu.
Color Effect
The Image Color Setting allows you to select
dierent color eects.
1. Press the
button to select the Image Color
Setting Menu.
2. Press the left/right arrow buttons to select the
Image Color Setting options.
Normal
There are 20 options:
•
Normal
•
Vivid
•
Japan Style
•
Italian Style
•
French Style
•
Punk
65
Select Scene
Select a scene mode under SCN Mode.
Night Portrait
Press SET To Select Scene
Please refer to P32 for more detailed instructions.
•
Black and White
•
Sepia
•
Partial Color-Red
•
Partial Color-Blue
•
Partial Color-Yellow
•
Partial Color-Green
•
Negative
•
Dreamy
•
Vignetting
•
Salon
•
Fish Eye
•
Reflection
•
4 Grids -Stylish(2M)
•
Sketch
66
• Options in the shooting mode (O: Available X: Unavailable)
Options
Shooting Modes
O O O O O
O O O X O
X X X O X
X O O X O
X O O X O
O O O X X
X O O X O
X O O O X
67
Mode:
1. Press the button in Photo Shooting Mode
and press the up/down buttons to select .
Press SET To Enter
Menu
2. Press the button to enter the menu.
3. Press the up/down arrow buttons to select
and press the button or right arrow button to
enter the menu.
4. Press the up/down arrow buttons to pick the
item to be selected and press the
button or
right arrow button to enter the menu.
5. Press the up/down arrow buttons to select an
option and press the
button to confirm.
Photo Shooting Setting Menu
Quality
The quality setting can be used to adjust the image
compression ratio.
Quality
Best
Fine
Normal
There are three options for picture quality:
• Best (16M Average File Size: 4.0MB)
• Fine (16M Average File Size: 2.5MB)
• Normal (16M Average File Size: 2.0MB)
68
Auto Focus (AF) Assist Beam
In a darker environment, the AF assist beam setting
can be turned on for better focus.
AF Assist Beam
O
On
Digital Zoom
This setting is for adjusting digital zoom. If this
function is disabled, only optical zoom can be
used.
Digital Zoom
O
On
69
Quick Review
This option allows quick review of the photos
immediately after they are taken. Each photo is
displayed on the LCD screen based on the selected
time.
Quick Review
O
1 sec
2 sec
3 sec
There are 4 options:
• O
• 1 sec
• 2 sec
• 3 sec
Date Imprint
Include a Date/Time stamp on the photo image.
Date Imprint
O
Date
Date/Time
2019/08/01 00:00
• O
• Date
• Date/Time
70
Face Detection
Detects and focuses on faces to make all faces as
clear as possible in Photo Mode.
Face Detection
O
On
1. Hold the camera steadily and then focus on
the object to detect its face. A focus frame will
appear at the face on the screen when a face is
detected.
2. Press the shutter button half-way down to
focus. The LCD will show a green focus frame
when the subject is in focus.
1/151/15
F3.0F3.0
3. Press the shutter button all the way down to
take pictures.
The closed eyes detection is usually on. If the
camera detects in the course of quick review
there is a face with eyes closed, a prompt of
closed eyes will appear
.
71
Movie Menu
Mode:
1. Press the
button, select the mode and
press the button to enter the Movie Menu.
Expo Metering: AiAE
2. Press the up/down arrow buttons to select the
Movie Menu to be set.
3. Press the left/right arrow buttons to select the
Movie Menu to be set and press the
button
to confirm.
Expo Metering (Exposure Metering)
Use this setting to select the "target" size of the
camera's field of view to be metered.
Expo Metering: AiAE
There are 3 options:
• AiAE (Artificial Intelligence AE): Evaluates
the light intensity at multiple points in the
frame and automatically determines the
best value for the light meter.
• Spot metering targets a small area in the
center of the camera's field of view.
• Center metering targets a slightly larger
area in the center of the camera’s field of
view.
72
Video Quality
Set the image resolution used during video recording.
Size: 1080p 30fps
The speed requirements for reading and writing high resolution image pixel images to an SD card are as
follows:
No.
Image Pixels
Frames Recommendation Recording Time (4GB) About
1
1920 x 1080 * 30
Class 6 30 Minutes
2
1280 x 720 * 60
Class 6 32 Minutes
3 1280 x 720 *
30
Class 4 58 Minutes
4 640 x 480 30 Class 4 105 Minutes
5 640 x 480 120 Class 6 53 Minutes
•
Size: 1080p 30fps
•
Size: 720p 60fps
•
Size: 720p 30fps
•
Size: 640x480 30fps
•
Size: High Speed Movie
73
* The recording limit is 29 minutes at one
time.
When recording in higher pixel resolutions for
extended periods of time, this can cause the
camera to generate heat. This is not a camera
malfunction.
When the video format is set as 640x480
(120fps), shooting time is 30 seconds,
playback time is 2 minutes.
Sound recording is disabled when 640x480
120fps is chosen.
Color Effect
The Image Color Setting allows you to select
dierent color eects.
1. Press the button to select the Image Color
Setting Menu.
2. Press the left/right arrow buttons to select the
image Color Setting options.
Normal
Normal
There are 8 options:
•
Normal
•
Vivid
•
Black and White
•
Sepia
•
Partial Color-Red
•
Partial Color-Blue
•
Partial Color-Yellow
•
Partial Color-Green
74
Movie Setting Menu
Mode:
1. Press the
button, and select to enter the
video recording screen.
2. Press the
button and press the up/down
arrow buttons to select . Press the button
to enter the menu.
Press SET To Enter
Menu
3. Press the up/down arrow buttons to select
and press the button or right arrow button to
enter the menu.
4. Select the items to be set and press the
button or the right arrow button to enter the
menu.
5. Press the up/down arrow buttons to select an
option and press the
button to confirm.
Digital Zoom
This setting is for adjusting digital zoom. If this
function is disabled, only optical zoom can be
used.
Digital Zoom
O
On
75
Playback Menu
Mode:
1. Press the button to display the playback
screen and press the button to enter the
menu.
2. Press the up/down arrow buttons to select the
playback desired and press
button to enter.
3. Press the left/right arrow buttons to select an
option and press the
button to confirm.
Normal Mode
Press SET To Confirm
Refer to the following pages 75 to 78 for more
details about each setting.
Display Mode
Select the settings and press the button to
display the settings screen.
Normal Mode: Display all images.
Normal Mode: Display all images.
Date Mode: Arranged by date.
Cont. Photo Mode: Arranged by Cont.
Photo Group.
The Date Folder is displayed in date order
based on camera's Date/Time Settings.
If there is no Continuous Shot image file in
memory, Continuous Shot Playback mode
cannot be enabled.
76
HDR
With the HDR function, pictures that are
overexposed may be corrected to optimize
the highlights and lowlights captured to more
accurately represent the actual scene.
Select the
settings, and press the button to
display the settings screen.
Cancel
: HDR
: Cancel
After using the HDR function, the image will
be saved as a new file and the original file is
still stored in the memory.
Red-Eye Reduction
You can use this setting to reduce the red-eye of
the picture.
Select the
settings, and press the button to
display the settings screen.
Cancel
: Red-Eye Reduction
: Cancel
77
Rotate
You can use this setting to change the orientation of
the picture.
Select the
settings, and press the button to
display the settings screen.
Cancel
: Turn Right
: Turn Left
: Cancel
Videos and panoramic pictures cannot be
rotated.
The rotated picture file will replace the
original photo.
Resize
This setting allows you to resize a picture to a
particular resolution and saves it as a new picture.
Select the
settings and press the button to
display the settings screen.
Cancel
: Resize to 1024x768
Resize to 1024x680
Resize to 1024x576
: Resize to 640x480
Resize to 640x428
Resize to 640x360
: Cancel
This function can only be used to downsize
photos to a lower resolution.
Sizes of photos taken in panorama mode and
sizes of rotated photos cannot be adjusted.
78
Color
This setting allows you to change the picture color eect. The file is saved as a new photo and stored in
memory together with the original photo.
Select the
settings, and press the button to display the settings screen.
Cancel
There are 19 options available:
Cancel Sepia Vignetting
Vivid Partial Color-Red Salon
Japan Style (8M) Partial Color-Blue Fish Eye
Italian Style (8M) Partial Color-Yellow Reflection
French Style (8M) Partial Color-Green 4 Grids - Stylish(2M)
Punk (4M) Negative (8M)
Black and White Dreamy
79
Mode:
1. Press the button to show the playback
screen, press the button, and press the up/
down arrow buttons to select .
2. Press the
button to enter the menu.
3. Press the up/down arrow buttons to select
and press the button or right arrow button to
enter the menu.
Protect
DPOF
Delete
Trim
4. Press the up/down arrow buttons to select the
item to be set and press the button or right
arrow button to enter the menu.
5. Press the up/down arrow buttons to select an
option and press the
button to confirm.
Refer to the following pages 80 to 82 for more
details about each setting.
Playback Setting Menu
80
Protect
To prevent any pictures or videos from being accidentally erased, use this setting to lock one or all of the
files.
Protect
Cont. Group
All
Reset
Date Folder
One
There are 5 sub menus available:
• One: Lock the selected photo or video if they are unprotected; unlock the selected photo or video if
they are protected.
• Date Folder: Protect all photos in the Date Folder.
• Cont. Group: Protect all photos in the Cont. Photo Folder.
• All: Lock all photos or videos.
• Reset: Cancel all locked photos or videos.
81
The “ ” indicator means a file is protected.
File protection must be removed before a file
can be deleted.
Deleting files will cause DPOF settings to be
reset.
Deleted files will be permanently deleted and
will not be able to be recovered or restored.
When one photo in the Cont. Photo and Date
Folders is protected, it will be kept but any
other photos will be deleted.
Delete
You can delete one or all photo/video files.
Delete
Cont. Group
All
Date Folder
One
There are 4 sub menus available:
• One: Delete one photo or video.
• Date Folder: Delete all photos in the Date
Folder.
• Cont. Group: Delete all photos in the Cont.
Photo Folder
• All: Delete all photos or videos.
82
Trim
The Trim setting allows you to crop photos and
save them as new pictures.
1. Select [Yes] to confirm trim. Select a section of
the photo to be trimmed using the zoom button
and arrow buttons to trim a photo.
2X
2. Press the button and the [Save change?]
prompt appears. Select [ ] to change and
save the picture. Select [ ] to cancel changes
and return to the trim prompt screen.
The image cannot be clipped/trimmed again
once it has been clipped to 640 X 480.
A trimmed picture cannot be trimmed again.
DPOF (Digital Print Order Format)
The DPOF feature allows you to compile and select
a group of pictures that you would like to print and
will save your selection on the memory card so
that you can use the memory card to print without
having to individually specify the photos you want
to print.
All
Reset
One
DPOF
A printer that supports DPOF is needed for
photo printing.
83
Setup Menu
Mode :
1. Press the button in any mode and press the
up/down buttons to select .
2. Press the
button to enter the menu.
3. Press the up/down arrow buttons to select
and press the button or right arrow button to
enter the menu.
2019.08.01 00:00
Sound Settings
Power Saver
Language
World Time
Date & Time
English
Home
Auto
4. Press the up/down arrow buttons to select the
item to be set and press the button or right
arrow button to enter the menu.
5. Press the up/down arrow buttons to select an
option and press the
button to confirm.
Refer to the following pages 84 to 85 for more
details about each setting.
84
Sound Settings
With this setting you may adjust the sound volume.
Press the left/right arrow buttons to adjust the
volume and press the
button to confirm.
Sound Settings
Volume
Back
Power Saver
This setting allows you to save power and get the
maximum possible running time for your camera's
battery. Follow the steps below to turn the LCD
and camera o automatically after a consecutive
period of inactivity.
Power Saver
Auto
Normal
Best
• Auto
• Normal
• Best
Power
Saver
LCD power
o time
Turn o time
Auto 3 min 5 min
Normal 1 min 3 min
Best 30 sec 1 min
85
Language
Refer to the “Resetting your Language” section on
page 22.
World Time
The World Time setting is a useful function for your
overseas trips. This feature enables you to display
the local time on the LCD while you are abroad.
1. Press the up/down arrow buttons to select the
departure place (
) and destination ( )
fields.
2. Press the left/right arrow buttons to select a
city located in the same time zone as that of the
field. Press the
button to confirm settings.
Singapore ,Hong Kong,Taipei,
Beijing,Manila
World Time
Date & Time
Refer to the “Resetting Date/Time” section on page
23.
LCD Brightness
Use this setting to adjust the brightness of your
LCD.
Press the up/down arrow buttons to select an
option and press the
button to confirm .
LCD Brightness
Normal
+2
-2
+1
-1
Normal
86
Mode :
1. Press the button, press the up/down arrow buttons to select and press the button to enter the
menu.
2. Press the up/down arrow buttons to select
and press the button or right arrow button to enter the
menu.
3. Press the up/down arrow buttons to select the item to be set and press the
button or right arrow
button to enter the menu.
Format
File Numbering
Copy to Card
Reset
FW Version X.XX
4. Press the up/down arrow buttons to to select an option and press the button to confirm.
Refer to the following pages 87 to 89 for more details about each setting.
SD Card /Firmware
87
Copy to Card
Use this setting to copy the files stored in the
camera’s built-in memory to a memory card.
Copy to Card
Copy files from built-in memory to
the memory card.
No
Yes
If there is no card available in the camera, this
function will not be displayed.
Format
Please Note: formatting enables you to delete all
contents on the memory card and camera’s built-in
memory, including protected photo and movie files.
Format
Doing so will clear all data.
No
Yes
If you select [Yes] the camera will format its
memory.
If there is no memory card in the camera, the
built-in memory will be formatted; if there is
a memory card, only the memory card will be
formatted.
88
File Numbering
After you take a picture or video clip, the camera
will automatically save it with a sequential number.
You can use this to reset the file numbering to 1.
File Numbering
Create a new directory and
reset the file number.
No
Yes
Reset
Use this setting to restore the camera to its original
factory default settings.
Reset
Reset camera settings to
factory defaults.
No
Yes
89
Firmware (FW) Version
Use this setting to view the current camera
firmware version.
FW Version
Current Ver:1.XX
Back
When there is a new firmware version saved on the
SD card, select [Yes] to update.
FW Version
Current Ver:1.XX
New Ver.:2.XX
Cancel
Yes
Update Firmware?
90
Connecting to a Computer
You can use a USB cable to connect the camera and copy (transmit) photos to a computer, printer or other
device.
Setting the USB Mode
The camera’s USB port can be used to connect to either a computer or a printer. The following steps will
allow you to ensure that the camera is correctly configured to connect with a PC.
1. Press the
button, press the up/down arrow buttons to select and press the button to enter the
menu.
2. Press the up/down arrow buttons to select
and press the button or right arrow button to enter the
menu.
3. Press the up/down arrow buttons to select [USB] and press the
button or right arrow button to enter the
menu.
4. Press the up/down arrow buttons to select [PC] and press the
button to confirm.
USB
PC
Printer
CONNECTIONS
91
Transferring Files to Your Computer
The computer will automatically detect the
camera as a removable drive. Double-click the
“My Computer“ icon on the desktop to locate the
removable drive and to copy folders and files in
the drive to a directory on your PC as you would
copy any typical folder or file.
Follow the steps below to connect the camera to a
computer:
1. Make sure both the camera and computer are
turned on.
2. Connect one end of the supplied USB cable to
the USB port on your camera.
3. Connect the other end of the cable to an
available USB port on your computer.
4. After the transmission is complete, disconnect
the USB cable according to your computer
manufacturer's instructions specifying how to
safely remove USB devices.
92
Pictbridge technology allows printing of the
photos saved on the memory card by a printer.
To find out if a printer is Pictbridge compatible,
simply look for the Pictbridge logo on the
packaging or check the owner's manual for
specifications. With the Pictbridge function on
your camera, you can print the captured photos
directly to a Pictbridge compatible printer using
the supplied USB cable, without the need for a PC.
Setting the USB Mode
The camera’s USB port can be set to connect with
either a PC or a printer. The following steps will
ensure that the camera is correctly configured to
connect with a compatible printer.
1. Press the
button, press the up/down arrow
buttons to select and press the button to
enter the menu.
2. Press the up/down arrow buttons to select
and press the button or right arrow button to
enter the menu.
Connecting to Pictbridge Compatible Printers
3. Press the up/down arrow buttons to select
[USB] and press the button or right arrow
button to enter the menu.
4. Press the up/down arrow buttons to select
[Printer] and press the
button to confirm.
USB
PC
Printer
After the camera is reset, it will switch to PC
mode automatically from USB Mode.
See “Using the Pictbridge Menu“ section on
page 94.
93
Connecting to your Printer
1. Make sure both the camera and printer are
turned on.
2. Connect one end of the supplied USB cable to
the USB port on your camera.
3. Connect the other end of the cable to the USB
port on the printer.
If the camera is not connected to a Pictbridge
compatible printer, the following error message
will appear on the LCD.
Connection Failed!
The error message above will also appear
if the USB Mode is set incorrectly, in which
case you should disconnect the USB cable,
check the USB Mode settings, ensure that the
printer is turned on, and then try connecting
the USB cable again.
94
Using the Pictbridge Menu
After setting the USB mode to Printer, the
Pictbridge menu will appear.
PictBridge
Print (with Date)
Exit
Print (without Date)
Print Index
Print DPOF Images
Press the up/down arrow buttons to select a menu
item and press the button or right arrow button
to enter the item.
Refer to the following sections for more detailed
information on each setting.
Print (with Date)
If you have set the date and time on your camera,
the date and time will be recorded and saved with
each photo you take.
1. In the Pictbridge menu, select [Print (with Date)]
and the screen as shown below appears.
01
Back
2. Press the left/right arrow buttons to select a
photo to be printed.
95
3. Press the up/down arrow buttons to select the
number of copies for the currently displayed
photo.
4. Press the
button and the following screen
will appear.
Print (with Date)
Cancel
Yes
5. Select [Yes] and press the button to confirm;
select [Cancel] to cancel printing.
Print (without Date)
Use this setting to print the photos without dates
on them.
1. In the Pictbridge menu, select [Print (without
Date)] and the screen as shown below appears.
01
Back
2. Press the left/right arrow button to select the
photo to be printed.
3. Press the up/down arrow buttons to select the
number of copies for the currently displayed
photo.
4. Press the
button and the following screen
will appear.
96
Print (Without Date)
Cancel
Yes
5. Select [Yes] and press the button to confirm;
select [Cancel] to cancel printing.
Print Index
You can print all photos in the camera via this
function.
1. In the Pictbridge menu, select [Print Index] and
the screen as shown below appears.
Yes
Print Index
Cancel
Yes
2. Select [Yes] and press the button to confirm;
select [Cancel] to cancel printing.
97
Print DPOF Images
To use DPOF printing, you must select your photos
for printing using the DPOF settings before hand.
See “DPOF” section on page 82.
1. In the Pictbridge menu, select [Print DPOF
Images] and the screen as shown below
appears.
Print DPOF Images
Cancel
Yes
2. Select [Yes] and press the button to confirm;
select [Cancel] to cancel printing.
Exit
Select [Exit] to exit the Pictbridge menu. At this
time, the message [Remove USB Cable!] will
appear on the screen.
Remove USB Cable!
Disconnect the USB cable from the camera and
printer.
98
Specifications
APPENDICES
Design and specifications are subject to change without notice.
Image Sensor
Type 1/2.3" BSI CMOS
Eective Pixels 16.35 Megapixels
Total Pixels 16.76 Megapixels
Lens
Focal Length 4.9mm (Wide) — 19.6mm (Tele)
35mm Film Equivalent 27mm (Wide) — 108mm (Tele)
F Number F3.0 (Wide) — F6.6 (Tele)
Lens Construction 7 groups 7 elements
Optical Zoom 4x
Focusing Range
Normal: (Wide) 60cm ~
∞
(Tele) 100cm ~
∞
Macro: 5cm ~
∞
(Wide Only)
Autofocus System TTL Autofocus
Anti-Handshake Digital Image Stabilization
Digital Zoom 6x Digital Zoom (Combined Zoom: 24x)
99
Number of
Recording
Pixels
Still Image
(4:3)
16MP: 4608 × 3456
10MP: 3648 × 2736
5MP: 2592 × 1944
3MP: 2048 × 1536
0.3MP: 640 × 480
(3:2)
14MP: 4608 × 3072
(16:9)
12MP: 4608 × 2592
2MP: 1920 × 1080
Movie
1920 × 1080 (30fps), 1280 × 720 (60/30fps), 640 x 480 (30fps),
High-Speed Movie: 640 × 480 (120fps)
Image Compression Best, Fine, Normal
DCF, DPOF (Ver1.1) Support Yes
File Format
Still Image Exif 2.3 (JPEG)
Movie MOV [Image: H.264; Audio: Linear PCM (Monaural)]
Shooting Modes
Auto Mode, Program AE, Manual Mode, Movie Mode, Scene Mode,
Underwater Mode, Wi-Fi® Mode
Scene Mode
Portrait, Landscape, Sport, Beach, Sunset, Fireworks, Night Landscape,
Snow, Children, Panorama Mode, Glass, Anti-Shake, Panning Shot, Night
Portrait, Party, Indoor, Leaf, Museum
Detection Features Face, Smile, Blink
Waterproof Up to 15m
Shockproof Up to 2m
Dustproof Equivalent to JIS/IEC (IP6X)
100
Red-Eye Removal Yes
HDR Yes (Post-Processing)
Panorama Up to 360°
LCD Display 2.7 inch (230k Pixels)
ISO Sensitivity Auto, ISO100/200/400/800/1600/3200
AF Method Single AF, Multi-AF (TTL 25-point), Face-Detection
Exposure Metering Method
Artificial Intelligence AE (AiAE), Center-Weighted Average,
Spot (Fixed to Center of Frame), Face AE
Exposure Control Method Program AE (AE-Lock Available)
Exposure Compensation ±3 EV in 1/3 Step Increments
Shutter Speed 1/2000 ~ 4 Seconds (Manual: 30 Seconds)
Burst Mode Up to 6 fps at Full Resolution
Playback Modes
Single, Index (9/16 Thumbnails), Slide Show, Date, Burst Shooting
Zoom (Approx. x2 ~ x8)
White Balance Control
Auto (AWB), Daylight, Cloudy, Fluorescent, Fluorescent CWF,
Incandescent, Manual WB, Color Temp.(1900k-10000k), Underwater
101
Flash
Flash Method Internal
Flash Modes
Force O, Flash Auto, Fill Flash, Slow Sync.,
Slow Sync.+Red-Eye Reduction, Red-Eye Reduction
Recording Media
Internal Memory: Approx. 8MB
microSD/microSDHC Card (Up to 32GB Support) [MMC Card not
supported ]
Multi-Language Support 26 Languages
Jacks USB 2.0 (Micro 5 pin USB)
Wi-Fi® Yes (802.11 b/g/n)
Remote Control Yes (via smart device)
Power
Rechargeable Li-ion Battery LB-015, 3.7V 700mAh, In-Camera
Charging
Shooting Capability (Battery
Performance)
Approx. 200 Shots (Based on CIPA Standards)
Approx. 70 Min for Video (@1080p/30fps)
Operation Environment Temperature: 0 ~ 40
o
C, Humidity: 0 ~ 90%
Dimensions (W×H×D) Approx. 103.2 × 66.7 × 52.4 (Based on CIPA Standards)
Weight Approx. 176g (Body Only)
102
Prompts and Warning Messages
Message Description Action
Warning! Battery exhausted.
The camera battery is depleted. It is
a warning indicating that the camera
is going to shut o.
Charge battery or replace with a
charged battery. The camera will
shut down in 2 seconds.
Lens obstruction, Re-start
Camera.
The lens is jammed or some foreign
object is preventing the lens from
functioning properly.
Turn the camera o and restart it
to reset the lens.
Suggest using tripod.
When continuous exposure is
enabled, this prompt message is
displayed when the photo shooting
screen is displayed for the first time.
The message will disappear after
2 seconds.
Built-in memory error!
An error has occurred in the internal
memory.
Try shutting o the camera and
turning it on again. This message
will disappear after 2 seconds.
Improper alignment.
Please try again.
The oset is too big for panorama
shooting.
Keep the camera steady while
shooting to maintain alignment.
103
Message Description Action
Warning! Do not turn o
your camera during update!
The message appears during the
firmware update process.
The message disappears after the
camera update and restart.
Connection Failed!
Failure to connect to your PC,
printer, TV.
Remove USB cable, reinsert cable,
and retry connection.
Please update firmware
after the battery is fully
charged!
The firmware cannot be updated
when power is insuicient.
Charge the battery fully before
reattempting to update firmware.
Card Full !
Indicates that the memory card is
full.
Replace memory card with another
that has available memory or delete
photos or videos to create more
room on the card. This message will
disappear after 2 seconds.
Memory Full !
Indicates that the camera memory
is full.
Erase files or insert a memory card
that has available memory. It will
disappear after 2 seconds.
104
Message Description Action
Card Error !
During power-on, the memory
card cannot be recognized or a
read/write error has occurred.
Format the memory card. WARNING: Formatting
the memory card will erase all data on the card.
Copy the data from the memory card to another
storage, such as a computer. Otherwise, all data
will be erased during formatting. This message
will disappear after 2 seconds.
Card is not formatted.
When an error occurs in the
memory card, the message
"Not Formatted" will appear.
Format the memory card. WARNING: Formatting
the memory card will erase all data on the card.
Copy the data from the memory card to another
storage, such as a computer. Otherwise, all data
will be erased after the format.
Slow access
When a memory card lower
than Class 4 is used to record
a HD movie, the writing speed
will be slower and recording
will not continue.
Replace the memory card with a card that is
Class 4 or higher.
This message will disappear after 2 seconds.
Cannot write to SD
card.
The photo shooting or video
recording has been interrupted,
so recording cannot continue.
Turn the camera o. Then remove and reinsert
the memory card and turn on the camera to
restart.
No Red-Eye Detected!
Red eyes have not been
detected in the image.
The message will disappear after 2 seconds.
105
Message Description Action
This image cannot be
edited.
The file format does not support editing
or the edited file cannot be edited again.
The message will disappear after 2
seconds.
Exceeded maximum
folder number.
This indicates that the memory card
exceeded the maximum number of
folders (999). This could cause a long
read time during the camera's power up.
Copy the data to your PC and format
the memory card using the camera.
Too many pictures for
fast processing.
During the playback by date, the images
exceed specifications so that it is not
possible to play by date.
The message disappears after 2
seconds and the camera returns to
normal playback mode.
Unable to recognize
files.
The format of the file to be viewed is not
supported or the file is corrupted so it
cannot be properly read.
The message disappears only after
the file is deleted.
No Picture!
When you press the play button, no
image files exist in the camera or on
memory card.
The message disappears after 2
seconds and returns to the photo
shooting screen.
Protected!
Undeletable!
The file is protected. The message
appears when you go into delete mode.
If you want to delete a protected file,
first unlock the selected photo or
video (see page 80).
This message will disappear after 2
seconds.
106
Troubleshooting
Problem Possible causes Solution
Camera does not turn on
The battery has been depleted.
The battery is not inserted
correctly.
Replace the battery.
Correctly reinstall the battery.
Camera turns o suddenly
during operation
The battery has been depleted.
Replace the battery.
Charge the battery.
Make sure the camera is actually
shutting o and not entering
Power Save Mode, where the
LCD will turn o after the camera
has been idle for a period of
time.
The picture is blurred
Camera movement while taking a
picture.
Turn on Anti-Shake mode.
Images and video files
cannot be saved
The memory card is full.
Use another memory card or
delete unnecessary files.
107
Problem Possible Causes Solution
Images will not print from
the connected printer
The camera is not connected to
the printer correctly.
The printer is not Pictbridge
compatible.
The printer is out of paper or ink.
The printer paper is jammed.
Check the connection between the
camera and printer.
Use a Pictbridge compatible
printer.
Load paper into the printer or
replace the ink cartridge in the
printer.
Remove the jammed paper.
Saving data to memory
card is slow
Using a memory card below
Class 4 may result in slower
recording times.
Use a memory card with Class 4 or
higher to improve performance.
Too many movies to
process
The number of pictures or folders
in the memory card exceed the
specifications, so the playback
can not be displayed.
Delete unwanted files.
The flash
flashes on the
LCD screen.
Current shooting environment
requires flash.
Turn on flash.
108
If you choose to change the factory assigned, random Wi-Fi® password on your WPZ2 camera, please
be sure to update and enter the new randomly assigned password on your smart device. Some smart
devices will automatically remember and save any previously entered Wi-Fi® password. Be sure to clear
the old password on your smart device manually before attempting to connect the WPZ2’s Wi-Fi® to
your device. (Depending upon your smart device make and model, operation may vary, so please refer
to your smart device user manual and instructions.
1
2
3
2
iOS™ Example Android™ Example
microSD Memory Card Compatibility
This camera does not take standard SD cards and uses microSD Cards. Refer to the chart below for
compatible types of microSD cards (√: Compatible X: Not Compatible)
micro
SD
micro
SDHC
micro
SDXC
Conversion adapter
to SD card
SD SDHC SDXC
Format FAT12, 16 FAT32
exFAT -
FAT12, 16 FAT32
exFAT
Capacity Up to 2GB 4~32GB 64GB~2TB
-
Up to 2GB 4~32GB 64GB~2TB
Compatibility
√ √ X X X X X
109
It indicates that the writing speed class will be displayed on the memory card.
Use a memory card with the appropriate writing speed for the video recording mode to be recorded.
(O: Recommended X: Not recommended)
Speed
Class
UHS
Speed
Class
Video
Speed
Class
Video Recording
4K FHD HD VGA
90MB/sec
V90
O O O O
60MB/sec
UHS-III V60
O O O O
30MB/sec
UHS-I V30
O O O O
10MB/sec
Class 10 V10
O O O O
6MB/sec
Class 6 V6
X O O O
4MB/sec
Class 4
X X X O
2MB/sec
Class 2
X X X O
© 2022 JK Imaging Ltd. All Rights Reserved.
The Kodak trademark, logo and trade dress are used under license from Eastman Kodak Company.
All other logos, products or company names that are referred to in this document are trade names, trademarks or
registered trademarks of their holders. The holders are not ailiated with JK Imaging Ltd., our products or our website.
JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA
kodakpixpro.com
Made in Myanmar (Burma)
Ver. 6.0
