Built-in Induction cooker
1
Your safety is important to us. Please read this information before using
your cooktop.
• Disconnect the appliance from the mains electricity supply before carry-
ing out any work or maintenance on it.
• Connection to a good earth wiring system is essential and mandatory.
• Alterations to the domestic wiring system must only be made by a quali-
fied electrician.
• Failure to follow this advice may result in electrical shock or death.
• Read these instructions carefully before installing or using this appli-
ance.
No combustible material or products should be placed on this appliance
at any time.
Please make this information available to the person responsible for
installing the appliance as it could reduce your installation costs.
• In order to avoid a hazard, this appliance must be installed according to
these instructions for installation.
• Only personnel with the corresponding qualifications should properly
install and earth this equipment.
• This appliance should be connected to a circuit with an isolation switch
to completely disconnect the power supply.
• Failure to install the appliance correctly could invalidate any warranty or
liability claims.
• Take care - panel edges are sharp.
• If not used with caution, the user may be injured or get cut.
2
• If the cooktop is broken or cracked, switch off the main power supply
(wall switch) immediately and contact a qualified technician.
• power supply (wall switch) and contact a qualified technician.
• Switch the cooktop off before cleaning or maintenance.
• Failure to follow this advice may result in electrical shock or death.
• This appliance complies with electromagnetic safety standards.
• However, persons with cardiac pacemakers or other electrical implants
(such as insulin pumps) must consult with their doctor or implant manu-
facturer before using this appliance to make sure that their implants will
not be affected by the electromagnetic field.
• Failure to follow this advice may result in death.
• During use, accessible parts of this appliance will become hot enough
to cause burns.
• Do not let your body, clothing or any item other than suitable cookware
contact the Induction glass until the surface is cool.
• Metallic objects such as knives, forks, spoons and lids should not be
placed on the hob surface since they can get hot.
• Keep children away.
• The handle of the pan may be hot to the touch. Ensure that the handle
of the pan is not above the other cooking zones that are switched on.
• Failure to follow this advice could result in burns and scalds.
• The razor-sharp blade of a cooktop scraper is exposed when the safety
cover is retracted. Use with extreme care and always store safely and out
of reach of children.
3
• If not used with caution, the user may be injured or get cut.
• Over-boiling will result in smoking and grease spills, and ignition may
occur.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Do not place or leave any magnetisable objects (e.g. credit cards,
memory cards)or electronic devices (e.g. computers, MP3 players) near
the appliance, as they may be affected by its electromagnetic field.
• Never use your appliance for warming or heating the room.
• After use, always turn off the cooking zones and the cooktop as
described in this manual (i.e. by using the touch controls). Do not rely on
the pan detection feature to turn off the cooking zones when you remove
the pans.
• Do not allow children to play with the appliance or sit, stand, or climb on
it.
• Do not store items of interest to children in cabinets above the appli-
ance. Children climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in the area where the appli-
ance is in use.
• Children or persons with disabilities who have limited ability to use the
appliance should have a responsible and qualified person to instruct
them in its use. The instructor should be satisfied that they can use the
appliance without posing a danger to themselves or their surroundings.
• Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be done by a
qualified technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop. Do not stand on
your cooktop.
• Do not use pans with jagged edges or drag pans across the Induction
glass surface as this can scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to
clean your cooktop, as these can scratch the Induction glass.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
• This appliance is intended to be used in household and similar applica-
tions such as: -staff kitchen areas in shops, offices and other working
environments; -farm houses; -by clients in hotels, motels and other
residential type environments; -bed and breakfast type
• WARNING: The appliance and its accessible parts become hot during
use.
• Care should be taken to avoid touching heating elements.
• WARNING: Unattended cooking on a hob with fat or oil can be danger-
ous and may result in fire. NEVER try to extinguish a fire with water, but
switch off the appliance and then cover flame e.g. with a lid or a fire blan-
ket.
• WARNING: Danger of fire: do not store items on the cooking surfaces.
• WARNING: If the surface is cracked, switch off the appliance to avoid
the possibility of electric shock, for hob surfaces of glass-ceramic or simi-
lar material which protect live parts.
• A steam cleaner not recommend to use.
• The appliance is not intended to be operated by means of an extemal
timer or separate remote-control system.
• CAUTION: The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
• WARNING: In order to prevent tipping of the appliance, this stabilizing
means must be installed. Refer to the instructions for installation.
• WARNING: Use only hob guards designed by the manufactuer of the
cooking appliance or indicated by the manufacture of the appliance in the
instruction for use as suitable or hob guards incorporated in the appliance.
The use of inappropriate guards can cause accidents.
This appliance incorporates an earth connection for functional purposes
only.
Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Instal-
lation Manual in order to fully understand how to install correctly and oper-
ate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruc-
tion /Installation Manual for future reference.
4
• Over-boiling will result in smoking and grease spills, and ignition may
occur.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Do not place or leave any magnetisable objects (e.g. credit cards,
memory cards)or electronic devices (e.g. computers, MP3 players) near
the appliance, as they may be affected by its electromagnetic field.
• Never use your appliance for warming or heating the room.
• After use, always turn off the cooking zones and the cooktop as
described in this manual (i.e. by using the touch controls). Do not rely on
the pan detection feature to turn off the cooking zones when you remove
the pans.
• Do not allow children to play with the appliance or sit, stand, or climb on
it.
• Do not store items of interest to children in cabinets above the appli-
ance. Children climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in the area where the appli-
ance is in use.
• Children or persons with disabilities who have limited ability to use the
appliance should have a responsible and qualified person to instruct
them in its use. The instructor should be satisfied that they can use the
appliance without posing a danger to themselves or their surroundings.
• Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be done by a
qualified technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop. Do not stand on
your cooktop.
• Do not use pans with jagged edges or drag pans across the Induction
glass surface as this can scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to
clean your cooktop, as these can scratch the Induction glass.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
• This appliance is intended to be used in household and similar applica-
tions such as: -staff kitchen areas in shops, offices and other working
environments; -farm houses; -by clients in hotels, motels and other
residential type environments; -bed and breakfast type
• WARNING: The appliance and its accessible parts become hot during
use.
• Care should be taken to avoid touching heating elements.
• WARNING: Unattended cooking on a hob with fat or oil can be danger-
ous and may result in fire. NEVER try to extinguish a fire with water, but
switch off the appliance and then cover flame e.g. with a lid or a fire blan-
ket.
• WARNING: Danger of fire: do not store items on the cooking surfaces.
• WARNING: If the surface is cracked, switch off the appliance to avoid
the possibility of electric shock, for hob surfaces of glass-ceramic or simi-
lar material which protect live parts.
• A steam cleaner not recommend to use.
• The appliance is not intended to be operated by means of an extemal
timer or separate remote-control system.
• CAUTION: The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
• WARNING: In order to prevent tipping of the appliance, this stabilizing
means must be installed. Refer to the instructions for installation.
• WARNING: Use only hob guards designed by the manufactuer of the
cooking appliance or indicated by the manufacture of the appliance in the
instruction for use as suitable or hob guards incorporated in the appliance.
The use of inappropriate guards can cause accidents.
This appliance incorporates an earth connection for functional purposes
only.
Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Instal-
lation Manual in order to fully understand how to install correctly and oper-
ate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruc-
tion /Installation Manual for future reference.
5
• Over-boiling will result in smoking and grease spills, and ignition may
occur.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Do not place or leave any magnetisable objects (e.g. credit cards,
memory cards)or electronic devices (e.g. computers, MP3 players) near
the appliance, as they may be affected by its electromagnetic field.
• Never use your appliance for warming or heating the room.
• After use, always turn off the cooking zones and the cooktop as
described in this manual (i.e. by using the touch controls). Do not rely on
the pan detection feature to turn off the cooking zones when you remove
the pans.
• Do not allow children to play with the appliance or sit, stand, or climb on
it.
• Do not store items of interest to children in cabinets above the appli-
ance. Children climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in the area where the appli-
ance is in use.
• Children or persons with disabilities who have limited ability to use the
appliance should have a responsible and qualified person to instruct
them in its use. The instructor should be satisfied that they can use the
appliance without posing a danger to themselves or their surroundings.
• Do not repair or replace any part of the appliance unless specifically
recommended in the manual. All other servicing should be done by a
qualified technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop. Do not stand on
your cooktop.
• Do not use pans with jagged edges or drag pans across the Induction
glass surface as this can scratch the glass.
• Do not use scourers or any other harsh abrasive cleaning agents to
clean your cooktop, as these can scratch the Induction glass.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
• This appliance is intended to be used in household and similar applica-
tions such as: -staff kitchen areas in shops, offices and other working
environments; -farm houses; -by clients in hotels, motels and other
residential type environments; -bed and breakfast type
• WARNING: The appliance and its accessible parts become hot during
use.
• Care should be taken to avoid touching heating elements.
• WARNING: Unattended cooking on a hob with fat or oil can be danger-
ous and may result in fire. NEVER try to extinguish a fire with water, but
switch off the appliance and then cover flame e.g. with a lid or a fire blan-
ket.
• WARNING: Danger of fire: do not store items on the cooking surfaces.
• WARNING: If the surface is cracked, switch off the appliance to avoid
the possibility of electric shock, for hob surfaces of glass-ceramic or simi-
lar material which protect live parts.
• A steam cleaner not recommend to use.
• The appliance is not intended to be operated by means of an extemal
timer or separate remote-control system.
• CAUTION: The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
• WARNING: In order to prevent tipping of the appliance, this stabilizing
means must be installed. Refer to the instructions for installation.
• WARNING: Use only hob guards designed by the manufactuer of the
cooking appliance or indicated by the manufacture of the appliance in the
instruction for use as suitable or hob guards incorporated in the appliance.
The use of inappropriate guards can cause accidents.
This appliance incorporates an earth connection for functional purposes
only.
Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Instal-
lation Manual in order to fully understand how to install correctly and oper-
ate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruc-
tion /Installation Manual for future reference.
7
8
1. Heating zone selection controls
2. Timer control
3. Power /Time regulating control
4. Safety lock control
5. ON/OFF control
6. Pause function control
7. Boost function control
8. Heat preservation function
control
• Only use cookware with a base suitable for induction cooker. Look for
the induction symbol on the packaging or on the bottom of the pan.
• You can check whether your cookware is suitable by carrying out a
magnet test. Move a magnet towards the base of the pan. If it is attracted,
the pan is suitable for induction.
• If you do not have a magnet:
1. Put some water in the pan you want to check.
2. If the water is heating, the pan is suitable.
• Cookware made from the following materials is not suitable: pure stain-
less steel, aluminum or copper without a magnetic base, glass, wood,
porcelain, ceramic, and earthenware.
Do not use cookware with jagged edges or a curved base
• Touch it with your fingerpulp, not your fingertip.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry, and that there is no
object(e.g. a utensil or a cloth) covering them. Even a thin film of water
may make the controls difficult to operate.
3. Touch the selection button of the desired
cooking zone.The corresponding power
indicator will start flashing.
to
1. To turn off a cooking zone, press the
corresponding selection button and touch
the" "for at least 2 seconds.
2. To switch off the hob, press the
On/Off button.
To stop the booster,press the booster
button again.
To stop the booster and set any
power level,use the slider.
“ b ”
booster button
• Press the selection button of the
cooking zone,in which which you want to
deactivate the booster.
b
b
b
Then press the Timer button The timer
display will show 30 min.
When the remaining time of the last
setting has elapsed, this cooking zone will
also be switched off.
button again. The remaining
button.
To continue operation, press the
selection button for the desired cooking
zone. The 30-minute countdown then
starts again.
After 30 minutes, the hob automatically
stops. All cooking zones are then in
standby mode and the power indicator
flashes.
To stop the 30 minute timer, press the
timer button again without selecting
any cooking zone.
2. Touch the heat preservation button " ", the cooking zone indica-
tor will display "A" and then display "U".
3.To cancel the heat preservation function, touch the heating zone
button, and then touch heat preservation button " ". The heating
zone will go back to cooking by touch the slider bar.
Using the Heat preservation function
The heat preservation function is suitable for keeping food warm.
Use the heat preservation function to get the stable temper ature.
button.
“ ”
“ ”
The timer displays "Lo" or, if the timer has been set
previously, "Lo" is displayed alternately with the remaining
time.
1. Touch the selection button of the heating zone that you wish to use
the heat preservation function and the indicator light next to the
button will flash.
they switch off automatically after a set time (see table below).
Take care when frying as the oil and fat heat up very quickly. At extremely high
temperature oil and fat will ignite spontaneously and this presents a serious
fire risk.
1. Power off the cooktop.
2. Apply a cooktop cleaner while
the glass is still warm (but not
hot!)
3. Rinse and wipe dry with a
clean cloth or paper towel.
4. Power back on the cooktop.
• When the power to the cooktop is
switched off, there will be no 'hot
surface' indication but the cooking
zone may still be hot! Take extreme
care.
• Heavy-duty scourers, some nylon
scourers and harsh/abrasive
cleaning agents may scratch the
glass. Always read the label to
check if your cleaner or scourer is
suitable.
• Never leave cleaning residue on
the cooktop: the glass may become
stained.
Remove these immediately with
a fish slice, palette knife or razor
blade scraper suitable for
Induction glass cooktops, but
beware of hot cooking zone
surfaces:
1. Power off the cooktop.
2. Hold the blade or utensil at a
30°angle and scrape the soiling
or spill to a cool area of the
cooktop.
3. Clean the soiling or spill up
with a dish cloth or paper towel.
4. Follow steps 2 to 4 for
Everyday soiling on glass'
above.
1. Power off the cooktop.
2. Soak up the spill
3. Wipe the touch control area
with a clean damp sponge or
cloth.
4. Wipe the area completely dry
with a paper towel.
5. Power back on the cooktop.
• Remove stains left by melts and
sugary food or spillovers as soon as
possible. If left to cool on the glass,
they may be difficult to remove or
even permanently damage the glass
surface.
• Cut hazard: when the safety cover
is retracted, the blade in a scraper is
razor-sharp. Use with extreme care
and always store safely and out of
reach of children.
• The cooktop may beep and turn
itself off, and the touch controls may
not function while there is liquid on
them. Make sure you wipe the touch
control area dry before turning the
cooktop back on.
Boilovers, melts,
and hot sugary
spills on the glass
Spillovers on the
touch controls
℃
+4+1 +4+1 +4+1
/0.16inch
/0.1inch
• The work surface is square and level, and no structural members inter-
fere with space requirements.
• The work surface is made of a heat-resistant material.
If the cooker is installed above an oven, the oven has a built-in cooling
fan.
• The installation will comply with all clearance requirements and applica-
ble standards and regulations.
• A suitable isolating switch providing full disconnection from the mains
power supply is incorporated in the permanent wiring, mounted and posi-
tioned to comply with the local wiring rules and regulations.
• The isolating switch must be of an approved type and provide a 3 mm
air gap contact separation in all poles (or in all active [phase] conductors
if the local wiring rules allow for this variation f the rquiremnts)
• The isolating switch will be easily accessible to the customer with the
cooker installed.
• You consult local building authorities and by-laws if in doubt regarding
installation.
• You use heat-resistant and easy-to-clean finishes (such as ceramic
tiles) for the wall surfaces surrounding the cooker.
• The power supply cable is not accessible through cupboard doors or
drawers.
• There is adequate flow of fresh air from outside the cabinetry to the base
of the cooker.
• If the cooker is installed above a drawer or cupboard space, a thermal
protection barrier is installed below the base of the cooker.
• The isolating switch is easily accessible by the customer
1. The induction hotplate must be installed by qualified personnel or tech-
nicians.We have professionals at your service. Please never conduct the
operation by yourself.
2. The cooker will not be installed directly above a dishwasher, fridge,
freezer, washing machine or clothes dryer, as the humidity may damage
the cooker electronics.
3. The induction hotplate shall be installed so that better heat radiation
can be ensured to enhance its reliability.
4. The wall and induced heating zone above the table surface shall with-
stand heat.
5. To avoid any damage, the sandwich layer and adhesive must be resis-
tant to heat.
Green
Wire
Green
