USER MANUAL
TITLE GUITAR AMPLIFIER
MODEL PVAMP30
：
：
www.pyleaudio.com
1. INPUT This is an instrument input for plugging in
virtually anything.
3. GAIN This is the distortion intensity control
for the overdrive channel.
4. SELECT This switch is select the drive channel or normal
channel.
5. VOLUME This is the overall level control for the
overdrive channel.
6. BASS This equalization control adjusts the amount of
boost in the low frequency range.
7. MIDDLE This equalization control adjusts the amount of
boost in the middle frequency range.
8. TREBLE This equalization control adjusts the amount of
boost in the high frequency range.
9. OUTPUT This is a 1/4"jack for hooking up external speakers
to the amplifier.
10.HEADPHONE This is a 1/4"3-conductor stereo headphone jack
for plugging in headphones.
11. POWER This on/off switch provides power the unit.
Functions
TECHNICAL SPECIFICATIONS
Power
~110V, 60 Hz
Rated Power
45 Watts Peak
Load Impedance
4 Ohms
Speaker
6
Signal/Noise Ratio
70dB
Frequency Response
20HZ to 16KHZ
Dimension
13.2*7.7*11.6 (in)
Weight
13.2LBS
CAUTION:
WARNING:
AVIS:
ATTENTION:
CHASSIS SURFACE HOT.
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK,DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.
RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR.
SUPERFICIE DE CHASSIS CHAUDE.
OUTPUT
HEADPHONE
INPUT
GAIN
VOLUME
BASS
TREBLE
POWER
PVAMP30
SELECT
VOLUME
MIDDLE
11
2. VOLUME This is the overall level control for the
normal channel.
PVAMP30
