INSTRUCTION MANUAL
LED FLOOD LIGHT
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installing and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 6 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
INTRODUCTION & WARRANTY
VT-4455
SKU WATTS
USEFUL
LUMENS
BEAM
ANGLE
DF CRI
INPUT
VOLTAGE
OPERATION
TEMPERATURE
DIMENSION
BODY
TYPE
MODEL
N.W
[KGS]
0.56
1.1
2.8
MAX
MOUNTING
HEIGHT
<5M
<5M
<5M
PROJECTED
AREA [MMP]
29970
58624
135198
VT-44101
VT-44201
5740 lm
231996
232166
232176
50W
100W
232006
232186
232196
232206
232216
115° >0.9
>0.9
>0.9
>70
>70
>70
AC: 220-240V
50Hz
AC: 220-240V
50Hz
AC: 220-240V
50Hz
AC: 220-240V
50Hz
185x162x35mm
256x229x42mm
406x333x47mm
115°
115°
11480 lm
22960 lm
-20° to +45°C Aluminium
Aluminium
Aluminium
Aluminium
200W
VT-44003
34440 lm
232036
238256
300W 115°
LIFE SPAN
[HOURS]
30,000
VT-44033 0.41 <5M 23616
3450 lm
231976
231986
30W 115° >0.9 >70
AC: 220-240V
50Hz
164x34x144mm
-20° to +45°C
Aluminium
30,000
30,000
30,000
30,000 >0.9 >70 -20° to +45°C
498x411.6x48mm 4.39 <5M 204977
-20° to +45°C
-20° to +45°C
1.78 <5M 92018
IK
RATING
IK05
IK05
IK05
IK05
IK05
IK05VT-44153
232016
232026
>0.9 >70
AC: 220-240V
50Hz
331x47x278mm115°
17220 lm
Aluminium150W 30,000 -20° to +45°C
SUPER BRIGHT
LM/WATT EFFICIENCY
135
+
Replaceable (LED only)
light source by a professional
6
6 YEAR
WARRANTY*
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [email protected] FOR MORE
PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC WEST EUROPE LTD.
GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
• Please make sure to turn o the power before starting the installation.
• Installation must be performed by a qualified electrician.
• The light source contained in this luminaire shall only be replaced by the manufacturer or
his service agent or a similar qualified person.
• If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively
replaced by the manufacturer or his service agent or a similar qualified person in order to
avoid a hazard.
• Terminal block not included.
• Proper grounding should be ensured throughout the installation.
• For outdoor use.
• Replace any cracked protective shield.
• Minimum distance from lighted objects 1m.
NOTE
INSTALLATION DIAGRAM
WARNING
WIRE LENGTH
30W
50W
100W
150W
200W
300W
15cm
15cm
100cm
100cm
100cm
100cm
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
• To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be
eectively fixed to the wall if the wiring is within arm's reach.
• In order to maintain the IP protection of the product, the cable entry/gland should be
installed on the bottom side.
1 2
4 5
3
• DO NOT USE IN AREAS WITH LIMITED VENTILATION OR OUTSIDE THE RATED AMBIENT TEMPERATURE
RANGE. *CONNECT WITH WATERPROOF CABLE HOUSE ONLY. *ENSURE ELECTRICITY IS SWITCH OFF
BEFORE INSTALLATION.
• Please do not mount to a surface that is prone to vibrations.*
Remove the screw and the bracket aerward. (Figure 1)Before drilling, mark the hole position for fixing the
bracket onto the wall (Screw not supplied). (Figure 2)
• Screw the retaining bracket to the wall with a suitable quantity of screws. (Figure 4)
• Mount the bracket back to the fixture. Adjust the floodlight according to the desired position. Tighten the
screw. (Figure 5) Connect your main cable (HO5RN-F3G1.0mm2 Recommended) with the input lead of our
product through the waterproof junction box. Note, the line (-) of the lead. (Need to use the junction box of
IP65 or above, ensure to tighten the waterproof screw) Switch on the power to make sure if the product is
working.
INSTALLATION INSTRUCTION
DISMANTLING INSTRUCTIONS
(For Market surveillance team only)
Note: Light source removal will void the warranty
