SOUNDLINK REVOLVE II
IMPORTANT SAFETY INSTRUCTIONS
2
|
ENG
Please read and keep all safety, security, and use instructions.
Bose Corporation hereby declares that this product is in compliance with the essential requirements and
other relevant provisions of Directive 2014/53/EU and all other applicable EU directive requirements.
The complete declaration of conformity can be found at: www.Bose.com/compliancewww.Bose.com/compliance
This product conforms to all applicable Electromagnetic Compatibility Regulations 2016 and all other
applicable UK regulations. The complete declaration of conformity can be found at:
www.Bose.com/compliancewww.Bose.com/compliance
Bose Corporation hereby declares that this product is in compliance with the essential requirements per
Radio Equipment Regulations 2017 and all other applicable UK regulations. The complete declaration of
conformity can be found at:
www.Bose.com/compliancewww.Bose.com/compliance
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
6. Only use attachments/accessories specified by the manufacturer.
7. Unplug this apparatus during lightning storms or when unused for long periods of time.
8. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, objects have fallen into the apparatus, does not operate
normally, or has been dropped.
WARNINGS/CAUTIONS
This symbol means there is uninsulated, dangerous voltage within the product enclosure that may constitute
a risk of electrical shock.
This symbol means there are important operating and maintenance instructions in this guide.
This product contains magnetic material. Consult your physician on whether this might aect your
implantable medical device.
• Keep the product away from fire and heat sources. Do NOT place naked flame sources, such as lighted candles, on
or near the product.
• Do NOT make unauthorized alterations to this product.
• Do NOT use a power inverter with this product.
• Use this product only with an agency-approved LPS power supply that meets local regulatory requirements (e.g.,
UL, CSA, VDE, CCC).
• Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain
readily operable.
• Do not expose products containing batteries to excessive heat (e.g. from storage in direct sunlight, fire or the like).
• The product label is located on the bottom of the product.
3
|
ENG
REGULATORY AND LEGAL INFORMATION
NOTE:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Bose Corporation could void the user’s authority to operate this
equipment.
This device complies with part 15 of the FCC Rules and with ISED Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This device complies with FCC and ISED Canada radiation exposure limits set forth for general population.
This equipment should be installed and operated with a minimum distance of 20 cm between radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Meets IMDA Requirements.
CAN ICES-3(B)/NMB-3(B)
Management Regulation for Low-power Radio-frequency Devices
Article XII
According to “Management Regulation for Low-power Radio-frequency Devices” without permission granted by
the NCC, any company, enterprise, or user is not allowed to change frequency, enhance transmitting power or alter
original characteristic as well as performance to an approved low power radio-frequency devices.
Article XIV
The low power radio-frequency devices shall not influence aircraft security and interfere legal communications; If
found, the user shall cease operating immediately until no interference is achieved. The said legal communications
means radio communications operated in compliance with the Telecommunications Act.
The low power radio-frequency devices must be susceptible with the interference from legal communications or ISM
radio wave radiated devices.
DON’T attempt to remove the rechargeable lithium-ion battery from this product. Contact your local Bose retailer or
other qualified professional for removal.
Please dispose of used batteries properly, following local regulations. Do not incinerate.
This symbol means the product must not be discarded as household waste, and should be delivered to an
appropriate collection facility for recycling. Proper disposal and recycling helps protect natural resources,
human health and the environment. For more information on disposal and recycling of this product, contact
your local municipality, disposal service, or the shop where you bought this product.
Removal of the rechargeable lithium-ion battery in this product should be conducted only by a qualified
professional. Please contact your local Bose retailer or see products.bose.com/static/compliance/index.htmlproducts.bose.com/static/compliance/index.html
for further information.
REGULATORY AND LEGAL INFORMATION
4
|
ENG
Product Power State Table
The product, in accordance with the Ecodesign Requirements for Energy Related Products Directive 2009/125/EC and
the Ecodesign for Energy-Related Products and Energy Information (Amendment) (EU Exit) Regulations 2020, is in
compliance with the following norm(s) or document(s): Regulation (EC) No. 1275/2008, as amended by Regulation
(EU) No. 801/2013.
Required Power State Information
Power Modes
Standby Networked Standby
Power consumption in specified power mode, at
230V/50Hz input
≤
0.5 W Bluetooth®
≤ 2.0 W
Time after which equipment is automatically switched
into mode
≤
20 minutes
≤
5 minutes
Power consumption in networked standby if all wired
network ports are connected and all wireless network
ports are activated, at 230V/50Hz input
N/A
≤
2.0 W
Network port deactivation/activation procedures.
Deactivating all networks will enable standby mode.
Bluetooth: Deactivate by clearing the pairing list by pressing and
holding the Bluetooth button for 10 seconds. Activate by pairing with
a Bluetooth source.
For Europe:
Frequency band of operation 2400 to 2483.5 MHz.
Maximum transmit power less than 20 dBm EIRP.
Maximum transmit power is below regulatory limits such that SAR testing is not necessary and exempt per
applicable regulations.
China Restriction of Hazardous Substances Table
Names and Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substances and Elements
Part Name
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
(CR(VI))
Polybrominated
Biphenyl
(PBB)
Polybrominated
diphenylether
(PBDE)
PCBs X O O O O O
Metal Parts X O O O O O
Plastic Parts O O O O O O
Speakers X O O O O O
Cables X O O O O O
This table is prepared in accordance with the provisions of SJ/T 11364.
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part
is below the limit requirement of GB/T 26572.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials
used for this part is above the limit requirement of GB/T 26572.
REGULATORY AND LEGAL INFORMATION
5
|
ENG
Taiwan Restriction of Hazardous Substances Table
Equipment name: Bose SoundLink Revolve II, Type designation: 419357
Restricted substances and its chemical symbols
Unit
Lead
(Pb)
Mercury (Hg) Cadmium (Cd)
Hexavalent
chromium (Cr+6)
Polybrominated
biphenyls (PBB)
Polybrominated
diphenyl ethers
(PBDE)
PCBs
- ○ ○ ○ ○ ○
Metal Parts
- ○ ○ ○ ○ ○
Plastic Parts
○ ○ ○ ○ ○ ○
Speakers
- ○ ○ ○ ○ ○
Cables
- ○ ○ ○ ○ ○
Note 1: “○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value
of presence.
Note 2: The “−” indicates that the restricted substance corresponds to the exemption.
Please complete and retain for your records
The serial and model numbers are located bottom of the speaker.
Serial number: ____________________________________________________________________
Model number: 419357
Please keep your receipt with your owner’s guide. Now is a good time to register your Bose product.
You can easily do this by going to global.Bose.com/registerglobal.Bose.com/register
Date of Manufacture: The eighth digit in the serial number indicates the year of manufacture; “0” is 2010 or 2020.
China Importer: Bose Electronics (Shanghai) Company Limited, Part C, Plant 9, No. 353 North Riying Road, China
(Shanghai) Pilot Free Trade Zone
EU Importer: Bose Products B.V., Gorslaan 60, 1441 RG Purmerend, The Netherlands
Taiwan Importer: Bose Taiwan Branch, 9F-A1, No. 10, Section 3, Minsheng East Road, Taipei City 104, Taiwan
Phone Number: +886-2-2514 7676
Mexico Importer: Bose de México, S. de R.L. de C.V., Paseo de las Palmas 405-204, Lomas de Chapultepec,
11000 México, D.F. Phone Number: +5255 (5202) 3545
UK Importer: Bose Limited, Bose House, Quayside Chatham Maritime, Chatham, Kent, ME4 4QZ, United Kingdom
The CMIIT ID is located on the rubber foot on the bottom of the product.
REGULATORY AND LEGAL INFORMATION
6
|
ENG
Security Information
This product is capable of receiving security updates from Bose automatically when connected to the
Bose Connect app. In order to receive security updates via the mobile application, you must complete the
product setup process in the Bose Connect app. If you do not complete the setup process, you will be
responsible for installing security updates that Bose makes available via btu.Bose.com
Apple, the Apple logo, iPad, iPhone, iPod, and Siri are trademarks of Apple Inc., registered in the U.S. and other
countries. App Store is a service mark of Apple Inc. The trademark “iPhone” is used in Japan with a license from
Aiphone K.K.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by Bose Corporation is under license.
Google and Google Play are trademarks of Google LLC.
The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries.
Bose, Bose Home Speaker, Bose Music, Bose Portable Home Speaker, Bose Portable Smart Speaker, Bose Smart
Soundbar, Bose Smart Speaker, Bose Soundbar, SimpleSync, SoundLink, and SoundLink Revolve are trademarks of
Bose Corporation.
Bose Corporation Headquarters: 1-877-230-5639
©2021 Bose Corporation. No part of this work may be reproduced, modified, distributed, or otherwise used without
prior written permission.
CONTENTS
7
|
ENG
WHAT’S IN THE BOX
Contents ............................................................................................................................. 10
BOSE CONNECT APP SETUP
Download the Bose Connect app ............................................................................ 11
SPEAKER PLACEMENT
Placement guidelines .................................................................................................... 12
POWER
Connect to power ........................................................................................................... 13
Power on/o your speaker ......................................................................................... 13
Battery protection mode ............................................................................................. 14
Auto-o .............................................................................................................................. 14
Disable auto-o ....................................................................................................... 14
SPEAKER CONTROLS
Media playback and volume ....................................................................................... 16
Phone calls......................................................................................................................... 17
Access voice control .............................................................................................. 17
Voice alerts ................................................................................................................ 17
VOICE PROMPTS
Pre-installed languages ................................................................................................ 18
Select a language ........................................................................................................... 18
Change the language .................................................................................................... 18
Disable voice prompts .................................................................................................. 18
CONTENTS
8
|
ENG
BLUETOOTH® CONNECTIONS
Choose your pairing method ..................................................................................... 19
Pair your mobile device ................................................................................................ 20
Pair a mobile device with NFC .................................................................................. 21
Pair an additional mobile device ............................................................................... 22
Disconnect a device ....................................................................................................... 22
Reconnect a device ........................................................................................................ 22
MULTIPLE BLUETOOTH CONNECTIONS
Identify connected mobile devices .......................................................................... 23
Switch between two connected devices ............................................................... 23
Connect a previously paired device ........................................................................ 23
Clear the speaker pairing list ...................................................................................... 23
Use the Bose Connect app ......................................................................................... 23
WIRED CONNECTIONS
Connect the 3.5 mm stereo cable ............................................................................ 24
Connect the USB cable ................................................................................................ 24
SPEAKER STATUS
Battery status ................................................................................................................... 26
Bluetooth status .............................................................................................................. 26
Input status ....................................................................................................................... 26
CONTENTS
9
|
ENG
PAIR BOSE PRODUCTS
Choose your pairing method ..................................................................................... 27
Pair with another Bose SoundLink Bluetooth speaker .................................... 27
Pair the speakers using the Bose Connect app (recommended) ........ 27
Pair the speakers manually ................................................................................. 28
Switch between Party mode and Stereo mode .......................................... 29
Disable Party mode or Stereo mode............................................................... 29
Pair with a Bose Smart Speaker or Soundbar ..................................................... 30
Compatible products..................................................................................................... 30
Pair using the Bose Music app .......................................................................... 30
Reconnect to a Bose Smart Speaker or Soundbar ............................................ 31
CARE AND MAINTENANCE
Clean the speaker ........................................................................................................... 32
Replacement parts and accessories ........................................................................ 32
Limited warranty ............................................................................................................. 32
Technical information .................................................................................................... 32
TROUBLESHOOTING
Try these solutions first ................................................................................................ 33
Other solutions ................................................................................................................ 33
Reset your speaker ......................................................................................................... 35
10
|
ENG
CONTENTS
Confirm that the following parts are included:
SoundLink Revolve II
Bluetooth speaker
USB cable
NOTE: If any part of the product is damaged, don’t use it. Contact your authorized
Bose dealer or Bose customer service.
Visit:
worldwide.Bose.com/Support/SLRiiworldwide.Bose.com/Support/SLRii
WHAT’S IN THE BOX
11
|
ENG
BOSE CONNECT APP SETUP
The Bose Connect app lets you set up and control the speaker from any mobile
device, such as a smartphone or tablet.
Using the app, you can manage Bluetooth connections, choose your voice prompt
language, manage speaker settings, and get new features.
DOWNLOAD THE BOSE CONNECT APP
1. On your mobile device, download the Bose Connect app.
BOSE CONNECT
2. Follow the app instructions.
12
|
ENG
SPEAKER PLACEMENT
PLACEMENT GUIDELINES
• For best Bluetooth performance, place your mobile device within 30 ft (9 m) of your
speaker, and make sure there is a clear line of sight between you and your speaker.
Moving your device farther away, or not having a clear line of sight may impact
sound quality, and your device may disconnect from your speaker.
• Keep other wireless equipment at least 3 ft (1 m) away from your speaker.
• Place your speaker and your device outside of and away from metal cabinets,
other audio/video components, and direct heat sources.
CAUTIONS
• Stand your speaker on its base. Standing your speaker on any other side may cause
damage to your speaker and aect sound quality.
• Avoid placing your speaker on wet or dirty surfaces.
13
|
ENG
POWER
CONNECT TO POWER
Your speaker ships with a partial charge. Before using your speaker for the first time,
connect it to an AC (mains) outlet. Your speaker does not need to be fully charged,
but it does require the initial connection to activate the battery.
NOTE: Use a 1500mA (1.5A) USB power supply for the best speaker charging
experience. Using a power supply with less than 1500mA (1.5A) may result
in a slower charging time or your speaker may not be able to charge while
playing audio.
1. Plug the small end of the USB cable into the micro-B USB connector on
your speaker.
2. Plug the other end into a USB power supply (not provided).
The battery light 6 blinks amber, and your speaker emits a tone. When fully
charged, 6 glows green.
POWER ON/OFF YOUR SPEAKER
On the button pad, press the Power button I.
• The first time you power on your speaker, the Bluetooth light glows blue, and you
hear a voice prompt to select a language (see page 18).
• If you have already powered on your speaker and paired at least one mobile device,
the Bluetooth light blinks white and connects to the last two paired mobile devices.
You hear “Battery <number> percent. Connected to <mobile device name>.” The
Bluetooth light glows solid white.
POWER
14
|
ENG
BATTERY PROTECTION MODE
When your speaker is unplugged and unused for more than three days with a
r emaining charge of less than 10 percent, it enters battery protection mode to
preserve battery power. To reactivate your speaker, connect it to AC (mains) power.
When not in use, store your speaker in a cool place.
CAUTION: Do not store your speaker for extended periods when fully charged or
when the battery light 6 blinks red.
AUTO-OFF
Your speaker powers o after 20 minutes of inactivity (no sound coming from your
speaker) while using the following connections and power sources:
• AUX connection operating on battery or AC (mains) power.
• Bluetooth connection operating on battery power.
Disable auto-o
1. Press and hold H and the Input mode button 7 simultaneously.
You hear “Auto-o disabled.”
2. Repeat to re-enable the auto-o feature.
15
|
ENG
SPEAKER CONTROLS
The button pad enables you to power on your speaker and control your speaker’s
playback, volume, and speakerphone.
NOTE: Certain mobile devices may not support these functions.
Power button
Bluetooth
button
Multi-function button
Input
mode
button
Volume up
Volume down
SPEAKER CONTROLS
16
|
ENG
The Multi-function button V controls music sources and speakerphone calls on your
mobile device from your speaker.
MEDIA PLAYBACK AND VOLUME
FUNCTION WHAT TO DO
Play/Pause
Press V.
NOTE: In Input mode, pressing V mutes the audio
(see page 24).
Skip forward to the
next track
Double-press V.
Skip backward to the
previous track
Triple-press V.
Volume up
Press H.
Volume down
Press z.
SPEAKER CONTROLS
17
|
ENG
PHONE CALLS
FUNCTION WHAT TO DO
Make a call
Press and hold the Multi-function button V to activate
voice control on your mobile device. See “Access voice
control” below.
Switch a call from
speakerphone to your
mobile device, while on a call
Press and hold V.
Answer/End a call
Press V.
Decline an incoming call
Press and hold V.
Answer a second incoming
call and put the current call
on hold
While on a call, press V to answer a second call.
Decline a second incoming call
and stay on current call
While on a call, press and hold V for one second.
Switch between two calls
With two active calls, double-press V.
Mute/unmute a call
While on a call, press H and z simultaneously.
Access voice control
The microphone in the speaker acts as an extension of the microphone in your
smartphone. Using V on the speaker, you can access voice control on your mobile
device to make/take calls, play music, tell you the weather, give you the score of a
game, and more.
Press and hold V to access voice control on your device. You hear a tone that
indicates voice control is active.
Voice alerts
Your speaker identifies incoming callers (when applicable). To disable this feature, see
page 18.
18
|
ENG
Voice prompts guide you through the Bluetooth pairing and connecting processes.
PRE-INSTALLED LANGUAGES
• English • German • Korean • Swedish • Polish
• Spanish • Mandarin • Italian • Dutch
• French • Japanese • Portuguese • Russian
SELECT A LANGUAGE
1. Press z or H to scroll through available languages.
2. When you hear your language preference, press and hold the Multi-function
button V to select it.
You hear a beep and “Ready to pair.”
CHANGE THE LANGUAGE
1. Press and hold z and the Input mode button 7 simultaneously until you hear the
voice prompt for the first language option.
2. Press z or H to scroll through available languages.
3. When you hear your language preference, press and hold V until you hear a beep,
and “Connected to <mobile device name>.”
DISABLE VOICE PROMPTS
Press and hold z and H simultaneously until you hear “Voice prompts o.”
NOTE: Repeat to re-enable voice prompts.
VOICE PROMPTS
19
|
ENG
BLUETOOTH CONNECTIONS
Bluetooth wireless technology lets you stream music from mobile devices such as
smartphones, tablets, and computers. Before you can stream music from a device,
you must pair the device with your speaker.
CHOOSE YOUR PAIRING METHOD
You can pair your device with your speaker using Bluetooth wireless technology or
Near Field Communication (NFC).
You can also use the Bose Connect app to pair your device (see page 11).
What is NFC?
NFC is a technology that enables mobile devices to establish wireless communication
with each other by simply tapping the devices together. Refer to your device owner’s
guide to see if your model supports NFC.
If your device does not support Bluetooth
pairing via NFC or if you are unsure:
Follow the instructions for “Pair your mobile
device” on page 20.
If your device supports Bluetooth pairing
using NFC:
Follow the instructions for “Pair a mobile
device with NFC” on page 21.
NOTE: If your device supports Bluetooth pairing via NFC, you can use either
pairing method.
20
|
ENG
BLUETOOTH CONNECTIONS
PAIR YOUR MOBILE DEVICE
When you power on your speaker for the first time, the speaker automatically
searches for your mobile device.
1. On your device, turn on the Bluetooth feature.
TIP: The Bluetooth feature is usually found in the Settings menu.
2. Select your Bose Revolve II SoundLink speaker from the device list.
Once paired, you hear “Connected to <mobile device name>,” and the Bluetooth
light glows solid white.
NOTE: To pair an additional device, see page 22.
21
|
ENG
BLUETOOTH CONNECTIONS
PAIR A MOBILE DEVICE WITH NFC
NOTE: When you power on your speaker for the first time, make sure a language is
selected before you pair your mobile device with NFC.
1. Unlock your mobile device, and turn on the Bluetooth and NFC features.
Refer to your device owner’s guide to learn more about these features.
2. Tap and hold the NFC touchpoint on your device to the top center of your speaker.
The target area is the Bose logo.
Your device may prompt you to accept pairing.
Once paired, you hear “Connected to <mobile device name>,” and the Bluetooth
light glows solid white.
22
|
ENG
BLUETOOTH CONNECTIONS
PAIR AN ADDITIONAL MOBILE DEVICE
You can store up to eight paired mobile devices in the speaker pairing list.
• Press and hold the Bluetooth button l until the Bluetooth light blinks blue,
and you hear, “Ready to pair another device.” Pair your device to the speaker
(see page 20).
• If your device supports pairing via NFC, see page 21.
DISCONNECT A DEVICE
• Turn o the Bluetooth feature on your device.
• If your device supports pairing via NFC, tap and hold the NFC touchpoint on your
device to the top center of your speaker. The target area is the Bose logo.
RECONNECT A DEVICE
When powered on, your speaker tries to reconnect with the two most
recently-connected devices.
NOTE: The devices must be within range and powered on.
If your device supports pairing via NFC, tap and hold the NFC touchpoint on your
device to the top of your speaker. The target area is the Bose logo.
23
|
ENG
MULTIPLE BLUETOOTH CONNECTIONS
You can store up to eight paired mobile devices in the speaker pairing list, and your
speaker can be actively connected to two mobile devices at a time.
NOTE: You can only play audio from one device at a time.
IDENTIFY CONNECTED MOBILE DEVICES
Press the Bluetooth button l to hear which devices are currently connected.
SWITCH BETWEEN TWO CONNECTED DEVICES
1. Pause audio on your first device.
2. Play audio on your second device.
CONNECT A PREVIOUSLY PAIRED DEVICE
1. Press l to hear which device is currently connected.
2. Press l within two seconds to connect to the next device in your speaker’s
pairing list.
3. Repeat until you hear the desired device name.
You hear a tone that indicates the device is connecting.
4. Play audio on the connected device.
CLEAR THE SPEAKER PAIRING LIST
1. Press and hold l for 10 seconds, until you hear “Bluetooth device list cleared.
Ready to pair.”
All devices are cleared and your speaker is ready to pair a new device.
2. Delete your speaker from the Bluetooth list on your device.
USE THE BOSE CONNECT APP
You can also easily manage multiple connected devices using the Bose Connect app
(see page 11).
24
|
ENG
WIRED CONNECTIONS
You can connect the audio output of a smartphone, tablet, computer or other type of
mobile device to the AUX connector or micro-B USB connector.
CONNECT THE 3.5 MM STEREO CABLE
The AUX connector accepts a 3.5 mm stereo cable plug (not provided).
1. Using a 3.5 mm stereo cable, connect your mobile device to the AUX connector on
your speaker.
2. Press the Power button I on your speaker.
3. Press and release the Input mode button 7 until you hear “AUX audio.”
CONNECT THE USB CABLE
1. Using the USB cable, connect your device to the micro-B USB connector on
your speaker.
2. Press I on your speaker.
3. Press and release 7 until you hear “USB audio.”
25
|
ENG
The top of the speaker has a series of lights that glow according to system state.
Input light
Battery
light
Bluetooth
light
SPEAKER STATUS
SPEAKER STATUS
26
|
ENG
BATTERY STATUS
Shows the battery charge level. Each time you power on your speaker, the battery
light 6 displays the battery charge level for two seconds and a voice prompt
announces the battery charge level.
To check the battery charge level, press and hold the Power button I for three
seconds while checking 6.
NOTE: Battery performance varies with the content played and the volume level at
which it is played. In typical use, the speaker battery lasts up to 13 hours.
LIGHT ACTIVITY SYSTEM STATE
Solid green Medium to full charge
Blinks amber Charging
Solid amber Medium charge
Blinks red Need to charge
BLUETOOTH STATUS
Shows the connection status of a mobile device.
LIGHT ACTIVITY SYSTEM STATE
Blinks blue Ready to connect
Blinks white Connecting
Solid white Connected
INPUT STATUS
Shows the connection status of a device connected with an AUX or micro-B
USB cable.
LIGHT ACTIVITY SYSTEM STATE
Solid white Speaker is ready to play content from a device
NOTE: For more information on using a cable to connect a device, see page 24.
27
|
ENG
PAIR BOSE PRODUCTS
You can pair your SoundLink Revolve II speaker with other Bose speakers to play
audio together.
CHOOSE YOUR PAIRING METHOD
The way you pair with another Bose speaker varies depending on the type of speaker
you’re pairing with. Choose your pairing method from the table below.
SPEAKER PAIRING METHOD
Bose SoundLink Bluetooth speaker
See “Pair with another Bose SoundLink
Bluetooth speaker” below.
Bose Smart Speaker or
Soundbar
See “Pair with a Bose Smart Speaker or Soundbar” on
page 30.
PAIR WITH ANOTHER BOSE SOUNDLINK
BLUETOOTH SPEAKER
You can pair your Bose SoundLink Bluetooth speakers together to play in the
following modes using the Bose Connect app (recommended) or the speaker
control buttons:
• Party mode (left and right speakers play in unison)
• Stereo mode (left speaker and right speaker play separately)
You can set this up using the Bose Connect app (recommended) or the speaker
control buttons.
Refer to your Bose owner’s guide to determine if your secondary speaker supports
these modes.
Pair the speakers using the Bose Connect app
(recommended)
For more information, download the Bose Connect app.
PAIR BOSE PRODUCTS
28
|
ENG
Pair the speakers manually
If you are unable to access the Bose Connect app, follow the instructions below.
Party mode
1. Make sure both speakers are powered on.
2. Make sure a speaker is connected to your mobile device.
3. On the speaker connected to your device, press and hold the Bluetooth button l
and H simultaneously.
4. Release the buttons when you hear “Press the Bluetooth and volume down
buttons simultaneously on a second Bose device.”
5. On the other speaker, press and hold l and z simultaneously.
6. Release the buttons when the speaker emits a tone.
After 10 seconds, you hear “Party mode” from both speakers simultaneously. Party
mode is enabled. You are now able to play audio in unison using your device.
7. For an optimal experience, position your speakers:
• In the same room or outdoor area
• So there are no obstructions between them
NOTE: Performance may vary based on mobile device, distance and
environmental factors.
PAIR BOSE PRODUCTS
29
|
ENG
Stereo mode
1. Configure your speakers for Party mode (see page 28).
2. On a speaker, press the Bluetooth button l and H simultaneously.
3. Release the buttons when you hear “Stereo mode.” You hear “Left” from the left
speaker and “Right” from the right speaker.
Stereo mode is enabled. You are now able to play audio in stereo using your
mobile device.
4. For an optimal experience, position your speakers:
• In the same room or outdoor area
• Within 10 feet of each other, free from obstructions
• So that your distance to each speaker is equal
NOTE: Performance may vary based on mobile device, distance and
environmental factors.
Switch between Party mode and Stereo mode
On either speaker, press l and H simultaneously.
Disable Party mode or Stereo mode
Do one of the following on either speaker:
• Press and hold l until you hear “Bose speakers unlinked.”
• Press and hold the Multi-function button V and H simultaneously until you hear
“Bose speakers unlinked.”
• Press the Power button I to power o the speaker.
PAIR BOSE PRODUCTS
30
|
ENG
PAIR WITH A BOSE SMART SPEAKER OR SOUNDBAR
With Bose SimpleSync™ technology, you can pair your SoundLink Revolve II speaker
with a Bose Smart Speaker or Bose Smart Soundbar to listen to the same song in two
dierent rooms at the same time.
NOTE: SimpleSync™ technology has a Bluetooth range of 30 ft (9 m). Walls and
construction materials can aect reception.
COMPATIBLE PRODUCTS
You can pair your SoundLink Revolve II speaker with any Bose Smart Speaker or Bose
Smart Soundbar.
Popular compatible products include:
• Bose Smart Soundbar 700/Bose Soundbar 700
• Bose Smart Soundbar 300
• Bose Smart Speaker 500/Bose Home Speaker 500
• Bose Home Speaker 300
• Bose Portable Smart Speaker/Bose Portable Home Speaker
New products are added periodically. For a complete list and more information, visit:
worldwide.Bose.com/Support/Groupsworldwide.Bose.com/Support/Groups
Pair using the Bose Music app
1. On your SoundLink Revolve II speaker, press and hold the Bluetooth button l until
the Bluetooth indicator blinks blue, and you hear “Ready to pair another device.”
2. Use the Bose Music app to connect your speaker to a compatible Bose
product. For more information, visit:
worldwide.Bose.com/Support/Groupsworldwide.Bose.com/Support/Groups
NOTES:
• Make sure that your SoundLink Revolve II speaker is within 30 ft (9 m) of your
Bose Smart Speaker or Bose Smart Soundbar.
• You can pair your SoundLink Revolve II speaker with only one product at a time.
PAIR BOSE PRODUCTS
31
|
ENG
RECONNECT TO A BOSE SMART SPEAKER
OR SOUNDBAR
Power on your SoundLink Revolve II speaker (see page 13).
Your SoundLink Revolve II speaker tries to connect to the two most
recently- connected Bluetooth devices, including your Bose Smart Speaker or
Bose Smart Soundbar.
NOTES:
• Your Bose Smart Speaker or Bose Smart Soundbar must be within range
(30 ft or 9 m) and powered on.
• If your SoundLink Revolve II speaker doesn’t connect, see “Connect a previously
paired device” on page 23.
32
|
ENG
CARE AND MAINTENANCE
CLEAN THE SPEAKER
• Clean the surface of the speaker with a soft, damp cloth (water only).
• Do not use any sprays near the speaker. Do not use any solvents, chemicals, or
cleaning solutions containing alcohol, ammonia or abrasives.
• Do not allow liquids to spill into any openings.
REPLACEMENT PARTS AND ACCESSORIES
Replacement parts and accessories can be ordered through Bose customer service.
Visit:
worldwide.Bose.com/Support/SLRiiworldwide.Bose.com/Support/SLRii
LIMITED WARRANTY
The speaker is covered by a limited warranty. Visit our website at
global.Bose.com/warrantyglobal.Bose.com/warranty for details of the limited warranty.
To register your product, visit
global.Bose.com/registerglobal.Bose.com/register for instructions.
Failure to register will not aect your limited warranty rights.
TECHNICAL INFORMATION
Input Voltage: 5V
Input Current: 1.6A
33
|
ENG
TRY THESE SOLUTIONS FIRST
If you experience problems with the speaker:
• Check the battery light 6 (see page 26). Charge your speaker if necessary.
• Secure all cables.
• Check the state of status lights (see page 26).
• Place your speaker according to placement guidelines (see page 11).
• Make sure your mobile device supports Bluetooth or pairing via NFC technology
(see page 21).
OTHER SOLUTIONS
If you could not resolve your issue, see the table below to identify symptoms and
solutions to common problems. If you are unable to resolve your issue, contact
Bose customer service.
Visit:
worldwide.Bose.com/contactworldwide.Bose.com/contact
SYMPTOM SOLUTION
No power (battery)
Battery may be in protection mode or discharged. Connect it to
AC (mains) power.
Battery does not charge
Connect the USB cable to a dierent USB power supply.
Use a dierent USB cable.
Connect to a dierent AC (mains) power source.
Speaker does not pair
with mobile device
On your mobile device, turn the Bluetooth feature o and then
on. Remove your speaker from the Bluetooth list on your device.
Pair your device again.
Pair a dierent device (see page 22).
Clear your speaker’s pairing list (see page 23). Pair your
device again.
Reset your speaker (see page 35).
Speaker does not pair
with NFC
Unlock your device and turn on the Bluetooth and NFC features.
Tap and hold the NFC touchpoint on the back of your device to
the top of your speaker.
Remove your device from the case.
Make sure a language is selected (see page 18).
Use Bluetooth to pair your device (see page 20).
TROUBLESHOOTING
TROUBLESHOOTING
34
|
ENG
SYMPTOM SOLUTION
Bose SoundLink
Bluetooth speakers
do not pair together
manually
Download the Bose Connect app for an additional method for
pairing your Bose speakers (see page 11).
No sound
On your mobile device, turn the Bluetooth feature o and then
on. Remove your speaker from the Bluetooth list on your device.
Pair your device again.
Increase the volume on your speaker, your device and
music source.
Make sure voice prompts are on. Press the Bluetooth button l to
hear the connected mobile device. Make sure you are using the
correct device.
Use a dierent music source.
Pair a dierent device (see page 22).
If two devices are connected, pause your other device.
No sound from a
cabled device
Power on the device and play music.
Increase the volume on your speaker and device.
Press and release the Input mode button 7 until the Input light
glows white.
Use a dierent cable.
Connect a dierent device.
Poor sound quality
Use a dierent music source.
Pair a dierent device (see page 22).
If there are two devices connected, disconnect the second device.
Increase the volume on the device.
Check device audio settings.
Poor sound quality from
a cabled device
Increase the volume on your speaker and device.
Use a dierent cable.
Connect a dierent device.
Check device audio settings.
Audio plays from the
wrong device (when two
devices are connected)
Make sure voice prompts are on. Press the Bluetooth button l to
hear the connected device(s). Make sure you are using the correct
device.
Pause or quit the music source on the device playing music.
Disconnect the second device.
TROUBLESHOOTING
35
|
ENG
SYMPTOM SOLUTION
Speaker powers o
If using a cabled device, increase the volume on your device.
Disable auto-o (see page 14).
Speaker does not
pair with a Bose
Smart Speaker or
Soundbar
Press and hold l until the Bluetooth indicator blinks blue, and you
hear “Ready to pair another device.”
Make sure that your SoundLink Revolve II speaker is within
30 ft (9 m) of your Bose Smart Speaker or Bose Smart Soundbar.
Speaker does not
reconnect to a
previously- paired
Bose Smart Speaker or
Soundbar
See “Connect a previously paired device” on page 23.
Delayed audio
when paired with a
Bose Smart Speaker or
Soundbar
Download the Bose Connect app and run available software
updates (see page 11).
RESET YOUR SPEAKER
Factory reset clears paired mobile devices and language settings from your speaker
and returns it to the original factory settings.
1. Power on your speaker.
2. Press and hold the Power button I for 10 seconds.
The speaker powers o.
3. Press I.
The Bluetooth light glows blue, and you hear a voice prompt to select a language
(see page 18).
©2021 Bose Corporation
100 The Mountain Road, Framingham, MA 01701-9168 USA AM858882-0010 Rev. 02
