REVISED BULLETIN
SERVICE PARTS LIST
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
BULLETIN NO.
STARTING
SERIAL NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- Rubber Gasket (1)
2 --------------- Attachment Body (1)
3 43-31-0018 Brush Ring (1)
4 49-90-1959 Hose Clip Adaptor (1)
5 12-25-0327 Nameplate (Not Shown) (1)
54-05-5325
Dry Coring Attachment
5319-DE
Nov. 2019
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
3
4
2
1
FIG. NOTES
5 A clean, dry surface is essential for proper
performance for any adhesive system. The area
intended for application of any adhesive label or
nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a
clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. Lisbon Road, Brookîżeld, Wisc. 53005
Drwg. 1
