Installation of Base Legs
Models 4291 and 4292
Before installing heater to the base legs make sure you have the
following items:
(2) - Base Leg (4) - Screws
Installation Procedure:
1. Set the back of the heater on table with the bottom of heater
extending beyond the table edge.
2. Fasten the base legs to heater using the screws.
Base
leg
Screw
(ST4 x 18-C-H)
Screw
(ST4 x 13-C-H)
Model : 4292 Model : 4291
Base
leg
Screw
(ST4 x 13-C-H)
