Getting to Know the Camera 1
First Steps 5
Basic Photography and Playback 15
Technical Notes 20
Kit Lens 47
DIGITAL CAMERA
User's Manual
En
• Read this manual thoroughly before using the camera.
• To ensure proper use of the camera, be sure to read
“For Your Safety” (page xv).
• After reading this manual, keep it in a readily accessible
place for future reference.
Scan for detailed operating instructions.
nikon download center Z 5
ii
Package Contents
Be sure all items listed here were included with your camera.
•
Memory cards are sold separately.
•
Purchasers of the lens kit option should confirm that the
package also includes a lens. Manuals for the lens may also be
provided.
Package Contents
❏
Camera
❏
BF-N1 body cap
❏
DK-29 rubber eyecup
(comes attached to
camera)
❏
EN-EL15c rechargeable
Li-ion battery with terminal
cover
❏
MH-25a battery charger
(comes with either an AC
wall adapter or power
cable of a type and shape
that varies with the country
or region of sale)
❏
Strap
❏
Warranty (printed on the
back cover of this manual)
❏
User’s Manual
❏
UC-E24 USB cable
❏
BS-1 accessory shoe cover
Z 5 Model Name: N1933
iii
Package Contents
D
The Nikon Download Center
A pdf version of this manual is available from the Nikon
Download Center, together with an English-language
reference manual with detailed operating instructions,
which can be viewed online in html. Visit the Nikon
Download Center to download firmware updates,
NX Studio and other Nikon software, and manuals for Nikon products
including cameras, NIKKOR lenses, and flash units.
https://downloadcenter.nikonimglib.co
m/
iv
About This Manual
❚❚
Symbols
The following symbols and conventions are employed in this
manual. Use them to help locate the information you need.
❚❚
Conventions
•
This camera uses SD, SDHC, and SDXC memory cards, referred
to throughout this manual as “memory cards”. SD, SDHC, and
SDXC may also on occasion be referred to as “SD memory
cards”.
•
Throughout this manual, battery chargers are referred to as
“battery chargers” or “chargers”.
•
Throughout this manual, the display in camera monitor and
viewfinder during shooting is referred to as the “shooting
display”; in most cases, the illustrations show the monitor.
•
Throughout this manual, smartphones and tablets are referred
to as “smart devices”.
•
Throughout this manual, the term “default settings” is used to
refer to the settings in effect at shipment. The explanations in
this manual assume that default settings are used.
About This Manual
D
This icon marks notes, information that should be read before
using this product.
A
This icon marks tips, additional information you may find
helpful when using this product.
0
This icon marks references to other sections in this manual.
v
About This Manual
A
For Your Safety
“For Your Safety” contains important safety instructions. Be sure to read
them before using the camera. For more information, see “For Your
Safety” (
0
xv).
❚❚
Nikon User Support
Visit the site below to register your camera and keep up-to-date
with the latest product information. You will find answers to
frequently asked questions (FAQs) and can contact us for
technical assistance.
https://www.europe-nikon.com/support
vi
Table of Contents
Package Contents.................................................................................... ii
About This Manual ................................................................................. iv
Menu List ................................................................................................. viii
For Your Safety ....................................................................................... xv
Notices....................................................................................................... xx
Getting to Know the Camera 1
Parts of the Camera................................................................................. 1
Camera Body ...................................................................... 1
First Steps 5
Charging the Battery .............................................................................. 5
Inserting the Battery............................................................................... 7
Removing the Battery ..................................................... 7
Inserting Memory Cards........................................................................ 8
Removing Memory Cards .............................................. 8
Attaching a Lens ...................................................................................... 9
Detaching Lenses........................................................... 10
Choose a Language and Set the Clock ......................................... 11
Basic Photography and Playback 15
Taking Photographs (
b
Auto) ......................................................... 15
Shooting Movies (
b
Mode) .............................................................. 17
Playback ................................................................................................... 18
Viewing Photos............................................................... 18
Viewing Movies .............................................................. 19
Table of Contents
vii
Table of Contents
Technical Notes 20
Specifications......................................................................................... 20
Nikon Z 5 Digital Camera ............................................ 20
Approved Memory Cards................................................................... 33
Portable Chargers (Power Banks) ................................................... 34
Trademarks and Licenses................................................................... 35
Notices...................................................................................................... 39
Bluetooth and Wi-Fi (Wireless LAN) ............................................... 41
Kit Lens 47
NIKKOR Z 24–70mm f/4 S Lens........................................................ 47
Parts of the Lens: Names and Functions ............... 47
Specifications .................................................................. 48
NIKKOR Z 24–200mm f/4–6.3 VR Lens .......................................... 49
Parts of the Lens: Names and Functions ............... 49
Specifications .................................................................. 50
NIKKOR Z 24–50mm f/4–6.3 Lens ................................................... 52
Parts of the Lens: Names and Functions ............... 52
Specifications .................................................................. 53
Warranty Terms - Nikon Europe Service Warranty ................... 55
viii
Menu List
The camera offers the following menus. For a more complete
description of individual menu items, refer to the “Menu Guide”
chapter in the Online Manual.
Menu List
PLAYBACK MENU
Delete
Playback folder
Playback display options
Dual-format recording PB slot
Image review
After delete
Rotate tall
Copy image(s)
Slide show
Rating
PHOTO SHOOTING MENU
Reset photo shooting menu
Storage folder
File naming
Role played by card in Slot 2
Choose image area
Image quality
Image size
NEF (RAW) recording
ISO sensitivity settings
White balance
Set Picture Control
Manage Picture Control
Color space
Active D-Lighting
Long exposure NR
High ISO NR
Vignette control
ix
Menu List
Diffraction compensation
Auto distortion control
Flicker reduction shooting
Metering
Flash control
Flash mode
Flash compensation
Focus mode
AF-area mode
Vibration reduction
Auto bracketing
Multiple exposure
HDR (high dynamic range)
Interval timer shooting
Time-lapse movie
Focus shift shooting
Silent photography
PHOTO SHOOTING MENU MOVIE SHOOTING MENU
Reset movie shooting menu
File naming
Destination
Choose image area
Frame size/frame rate
Movie quality
Movie file type
ISO sensitivity settings
White balance
Set Picture Control
Manage Picture Control
Active D-Lighting
High ISO NR
Vignette control
Diffraction compensation
Auto distortion control
Flicker reduction
x
Menu List
Metering
Focus mode
AF-area mode
Vibration reduction
Electronic VR
Microphone sensitivity
Attenuator
Frequency response
Wind noise reduction
Headphone volume
Timecode
MOVIE SHOOTING MENU CUSTOM SETTING MENU
Reset custom settings
a Autofocus
a1 AF-C priority selection
a2 AF-S priority selection
a3 Focus tracking with lock-on
a4
Auto-area AF face/eye
detection
a5 Focus points used
a6 Store points by orientation
a7 AF activation
a8
Limit AF-area mode
selection
a9 Focus point wrap-around
a10 Focus point options
a11 Low-light AF
a12
Built-in AF-assist
illuminator
a13
Manual focus ring in AF
mode
xi
Menu List
b Metering/exposure
b1 EV steps for exposure cntrl
b2
Easy exposure
compensation
b3 Center-weighted area
b4
Fine-tune optimal
exposure
c Timers/AE lock
c1
Shutter-release button
AE-L
c2 Self-timer
c3 Power off delay
CUSTOM SETTING MENU
d Shooting/display
d1 CL mode shooting speed
d2 Max. continuous release
d3 Sync. release mode options
d4 Exposure delay mode
d5 Shutter type
d6 File number sequence
d7 Apply settings to live view
d8 Framing grid display
d9 Peaking highlights
d10
View all in continuous
mode
CUSTOM SETTING MENU
xii
Menu List
e Bracketing/flash
e1 Flash sync speed
e2 Flash shutter speed
e3 Exposure comp. for flash
e4
Auto
c
ISO sensitivity
control
e5 Modeling flash
e6 Auto bracketing (mode M)
e7 Bracketing order
CUSTOM SETTING MENU
f Controls
f1 Customize
i
menu
f2 Custom controls
f3 OK button
f4 Shutter spd & aperture lock
f5 Customize command dials
f6 Release button to use dial
f7 Reverse indicators
g Movie
g1 Customize
i
menu
g2 Custom controls
g3 OK button
g4 AF speed
g5 AF tracking sensitivity
g6 Highlight display
CUSTOM SETTING MENU
xiii
Menu List
SETUP MENU
Format memory card
Save user settings
Reset user settings
Language
Time zone and date
Monitor brightness
Monitor color balance
Viewfinder brightness
Viewfinder color balance
Limit monitor mode selection
Information display
AF fine-tuning options
Non-CPU lens data
Clean image sensor
Image Dust Off ref photo
Pixel mapping
Image comment
Copyright information
Beep options
Touch controls
HDMI
Location data
Wireless remote (WR) options
Assign remote (WR) Fn button
Airplane mode
Connect to smart device
Connect to PC
Conformity marking
Battery info
USB power delivery
Energy saving
Slot empty release lock
Save/load menu settings
Reset all settings
Firmware version
SETUP MENU
xiv
Menu List
RETOUCH MENU
NEF (RAW) processing
Trim
Resize
D-Lighting
Red-eye correction
Straighten
Distortion control
Perspective control
Monochrome
Image overlay
Trim movie
MY MENU
Add items
Remove items
Rank items
Choose tab
xv
For Your Safety
To prevent damage to property or injury to yourself or to others, read “For
Your Safety” in its entirety before using this product.
Keep these safety instructions where all those who use this product will
read them.
For Your Safety
A
DANGER: Failure to observe the precautions marked with this icon
carries a high risk of death or severe injury.
A
WARNING: Failure to observe the precautions marked with this icon
could result in death or severe injury.
A
CAUTION: Failure to observe the precautions marked with this icon
could result in injury or property damage.
A
WARNING
Do not use while walking or operating a vehicle.
Failure to observe this precaution could result in accidents or other
injury.
Do not disassemble or modify this product. Do not touch internal
parts that become exposed as the result of a fall or other accident.
Failure to observe these precautions could result in electric shock or
other injury.
Should you notice any abnormalities such as the product producing
smoke, heat, or unusual odors, immediately disconnect the battery
or power source.
Continued operation could result in fire, burns or other injury.
Keep dry. Do not handle with wet hands. Do not handle the plug
with wet hands.
Failure to observe these precautions could result in fire or electric shock.
xvi
For Your Safety
Do not let your skin remain in prolonged contact with this product
while it is on or plugged in.
Failure to observe this precaution could result in low-temperature burns.
Do not use this product in the presence of flammable dust or gas
such as propane, gasoline or aerosols.
Failure to observe this precaution could result in explosion or fire.
Do not directly view the sun or other bright light source through the
lens.
Failure to observe this precaution could result in visual impairment.
Do not aim the flash or AF-assist illuminator at the operator of a
motor vehicle.
Failure to observe this precaution could result in accidents.
Keep this product out of reach of children.
Failure to observe this precaution could result in injury or product
malfunction. In addition, note that small parts constitute a choking
hazard. Should a child swallow any part of this product, seek immediate
medical attention.
Do not entangle, wrap or twist the straps around your neck.
Failure to observe this precaution could result in accidents.
Do not use batteries, chargers, or AC adapters not specifically
designated for use with this product. When using batteries,
chargers, and AC adapters designated for use with this product, do
not:
•
Damage, modify, forcibly tug or bend the cords or cables, place
them under heavy objects, or expose them to heat or flame.
•
Use travel converters or adapters designed to convert from one
voltage to another or with DC-to-AC inverters.
Failure to observe these precautions could result in fire or electric shock.
xvii
For Your Safety
Do not handle the plug when charging the product or using the AC
adapter during thunderstorms.
Failure to observe this precaution could result in electric shock.
Do not handle with bare hands in locations exposed to extremely
high or low temperatures.
Failure to observe this precaution could result in burns, or frostbite.
A
CAUTION
Do not leave the lens pointed at the sun or other strong light
sources.
Light focused by the lens could cause fire or damage to product’s
internal parts. When shooting backlit subjects, keep the sun well out of
the frame. Sunlight focused into the camera when the sun is close to the
frame could cause fire.
Turn this product off when its use is prohibited. Disable wireless
features when the use of wireless equipment is prohibited.
The radio-frequency emissions produced by this product could interfere
with equipment onboard aircraft or in hospitals or other medical
facilities.
Remove the battery and disconnect the AC adapter if this product
will not be used for an extended period.
Failure to observe this precaution could result in fire or product
malfunction.
Do not fire the flash in contact with or in close proximity to the skin
or objects.
Failure to observe this precaution could result in burns or fire.
xviii
For Your Safety
Do not leave the product where it will be exposed to extremely high
temperatures, for an extended period such as in an enclosed
automobile or in direct sunlight.
Failure to observe this precaution could result in fire or product
malfunction.
Do not look directly at the AF-assist illuminator.
Failure to observe this precaution could have adverse effects on vision.
Do not transport cameras or lenses with tripods or similar
accessories attached.
Failure to observe this precaution could result in injury or product
malfunction.
A
DANGER (Batteries)
Do not mishandle batteries.
Failure to observe the following precautions could result in the batteries
leaking, overheating, rupturing, or catching fire:
•
Use only rechargeable batteries approved for use in this product.
•
Do not expose batteries to flame or excessive heat.
•
Do not disassemble.
•
Do not short-circuit the terminals by touching them to necklaces,
hairpins, or other metal objects.
•
Do not expose batteries or the products in which they are inserted to
powerful physical shocks.
•
Do not step on batteries, pierce them with nails, or strike them with
hammers.
Charge only as indicated.
Failure to observe this precaution could result in the batteries leaking,
overheating, rupturing, or catching fire.
xix
For Your Safety
If battery liquid comes into contact with the eyes, rinse with plenty
of clean water and seek immediate medical attention.
Delaying action could result in eye injuries.
Follow the instructions of airline personnel.
Batteries left unattended at high altitudes in an unpressurized
environment may leak, overheat, rupture, or catch fire.
A
WARNING (Batteries)
Keep batteries out of reach of children.
Should a child swallow a battery, seek immediate medical attention.
Keep batteries out of reach of household pets and other animals.
The batteries could leak, overheat, rupture, or catch fire if bitten,
chewed, or otherwise damaged by animals.
Do not immerse batteries in water or expose to rain.
Failure to observe this precaution could result in fire or product
malfunction. Immediately dry the product with a towel or similar object
should it become wet.
Discontinue use immediately should you notice any changes in the
batteries, such as discoloration or deformation. Cease charging
EN-EL15c rechargeable batteries if they do not charge in the
specified period of time.
Failure to observe these precautions could result in the batteries leaking,
overheating, rupturing, or catching fire.
When batteries are no longer needed, insulate the terminals with
tape.
Overheating, rupture, or fire may result should metal objects come into
contact with the terminals.
If battery liquid comes into contact with a person's skin or clothing,
immediately rinse the affected area with plenty of clean water.
Failure to observe this precaution could result in skin irritation.
xx
Notices
•
No part of the manuals included with this product may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form, by any means, without Nikon’s prior written
permission.
•
Nikon reserves the right to change the appearance and specifications of
the hardware and software described in these manuals at any time and
without prior notice.
•
Nikon will not be held liable for any damages resulting from the use of
this product.
•
While every effort has been made to ensure that the information in
these manuals is accurate and complete, we would appreciate it were
you to bring any errors or omissions to the attention of the Nikon
representative in your area (address provided separately).
●
Notice Concerning Prohibition of Copying or Reproduction
Note that simply being in possession of material that has been digitally
copied or reproduced by means of a scanner, digital camera, or other
device may be punishable by law.
•
Items prohibited by law from being copied or reproduced
Do not copy or reproduce paper money, coins, securities, government
bonds, or local government bonds, even if such copies or reproductions
are stamped “Sample”.
The copying or reproduction of paper money, coins, or securities which
are circulated in a foreign country is prohibited.
Unless the prior permission of the government has been obtained, the
copying or reproduction of unused postage stamps or post cards issued
by the government is prohibited.
The copying or reproduction of stamps issued by the government and
of certified documents stipulated by law is prohibited.
Notices
xxi
Notices
•
Cautions on certain copies and reproductions
The government has issued cautions on copies or reproductions of
securities issued by private companies (shares, bills, checks, gift
certificates, etc.), commuter passes, or coupon tickets, except when a
minimum of necessary copies are to be provided for business use by a
company. Also, do not copy or reproduce passports issued by the
government, licenses issued by public agencies and private groups, ID
cards, and tickets, such as passes and meal coupons.
•
Comply with copyright notices
Under copyright law, photographs or recordings of copyrighted works
made with the camera cannot be used without the permission of the
copyright holder. Exceptions apply to personal use, but note that even
personal use may be restricted in the case of photographs or recordings
of exhibits or live performances.
●
Use Only Nikon Brand Electronic Accessories
Nikon cameras are designed to the highest standards and include
complex electronic circuitry. Only Nikon brand electronic accessories
(including lenses, chargers, batteries, AC adapters, and flash accessories)
certified by Nikon specifically for use with this Nikon digital camera are
engineered and proven to operate within the operational and safety
requirements of this electronic circuitry.
The use of non-Nikon electronic accessories could damage
the camera and may void your Nikon warranty. The use of
third-party rechargeable Li-ion batteries not bearing the
Nikon holographic seal shown at right could interfere with normal
operation of the camera or result in the batteries overheating, igniting,
rupturing, or leaking.
For more information about Nikon brand accessories, contact a local
authorized Nikon dealer.
xxii
Notices
D
Before Taking Important Pictures
Before taking pictures on important occasions (such as at weddings or
before taking the camera on a trip), take a test shot to ensure that the
camera is functioning normally. Nikon will not be held liable for damages
or lost profits that may result from product malfunction.
D
Life-Long Learning
As part of Nikon’s “Life-Long Learning” commitment to ongoing product
support and education, continually-updated information is available
on-line at the following sites:
•
For users in the U.S.A.: https://www.nikonusa.com/
•
For users in Europe: https://www.europe-nikon.com/support/
•
For users in Asia, Oceania, the Middle East, and Africa:
https://www.nikon-
asia.com/
Visit these sites to keep up-to-date with the latest product information,
tips, answers to frequently-asked questions (FAQs), and general advice on
digital imaging and photography. Additional information may be
available from the Nikon representative in your area. See the following
URL for contact information: https://imaging.nikon.com/
1
Parts of the Camera
Getting to Know the Camera
Camera Body
Parts of the Camera
4
7
6
5
1
9
8
12 11 10
321
1
Eyelet for camera strap
2
E
(focal plane mark)
3
Stereo microphone (
0
17)
4
Movie-record button (
0
17)
5
Power switch (
0
11, 15)
6
Shutter-release button (
0
15)
7
E
button
8
S
button
9
Main command dial
10
Speaker
11
Mode dial
12
Accessory shoe (for optional
flash unit)
2
Parts of the Camera
123
13
6
4
5
9
8
10
11
7
12
1
Image sensor
2
M
button
3
AF-assist illuminator
Red-eye reduction lamp
Self-timer lamp
4
Cover for accessory terminal
and USB and HDMI connectors
5
Cover for headphone and
microphone connectors
6
Lens mounting mark (
0
9)
7
Headphone connector
8
Charge lamp
9
USB connector
10
HDMI connector
11
Accessory terminal
12
Connector for external
microphone
13
Body cap (
0
9)
3
Parts of the Camera
14 13 1112
7
6
5
8
9
10
20
15
19
17
18
16
2134
1
Diopter adjustment control
2
DISP button
3
Photo/movie selector (
0
15,
17)
4
AF-ON button
5
Sub-selector
6
i
button
7
Memory card slot cover (
0
8)
8
Memory card access lamp
9
J
button
10
Multi selector
11
G
button
12
c
(
E
) button
13
W
(
Q
) button
14
X
button
15
Monitor
16
O
button
17
K
button (
0
18)
18
Rubber eyecup
19
Viewfinder
20
Eye sensor
4
Parts of the Camera
D
Product Serial Number
The serial number for this product can be
found by opening the monitor.
6
7
9
8
3
5
4
10
1
2
1
Lens mount (
0
9)
2
Lens release button (
0
10)
3
CPU contacts
4
Tripod socket
5
Power connector cover
6
Battery-chamber cover
7
Battery-chamber cover latch
8
Fn2 button
9
Fn1 button
10
Sub-command dial
5
Charging the Battery
First Steps
Charge the supplied EN-EL15c battery in the supplied MH-25a
battery charger before use. Insert the battery and plug the
charger in (depending on the country or region, the charger
comes with either an AC wall adapter or a power cable).
D
The Battery and Charger
Read and follow the warnings and cautions in “For Your Safety” (
0
xv).
•
AC wall adapter: After inserting the AC wall adapter into the
charger AC inlet (
q
), slide the AC wall adapter latch as shown
(
w
) and rotate the adapter 90 ° to fix it in place (
e
).
Charging the Battery
6
Charging the Battery
•
Power cable: After connecting the power cable with the plug
in the orientation shown, insert the battery and plug the cable
in.
•
An exhausted battery will fully charge in about 2 hours and
35 minutes.
D
If the CHARGE Lamp Flashes Rapidly
If the CHARGE lamp flashes rapidly (8 times a second):
•
A battery charging error has occurred: Unplug the charger and
remove and reinsert the battery.
•
The ambient temperature is too hot or too cold: Use the battery
charger at temperatures within the designated temperature range (0–
40 °C/+32–104 °F).
If the problem persists, unplug the charger and end charging. Bring the
battery and charger to a Nikon-authorized service representative.
Battery charging (flashes) Charging complete (steady)
7
Inserting the Battery
•
Turn the camera off before inserting or removing the battery.
•
Using the battery to keep the orange battery latch pressed to
one side, slide the battery into the battery chamber until the
latch locks it in place.
Removing the Battery
To remove the battery, turn the camera
off and open the battery-chamber cover.
Press the battery latch in the direction
shown by the arrow to release the
battery and then remove the battery by
hand.
Inserting the Battery
8
Inserting Memory Cards
•
Turn the camera off before inserting or removing memory
cards.
•
The camera is equipped with two
memory card slots: Slot 1 (
q
) and Slot 2
(
w
), allowing use of two memory cards.
If you are using only one memory card,
insert it into Slot 1.
•
Holding the memory card in the orientation shown, slide it
straight into the slot until it clicks into place.
Removing Memory Cards
After confirming that the memory card
access lamp is off, turn the camera off,
open the memory card slot cover, and
press the card in to eject it (
q
). The card
can then be removed by hand (
w
).
Inserting Memory Cards
64
GB
9
Attaching a Lens
•
The camera can be used with Z mount lenses. The lens
generally used in this manual for illustrative purposes is a
NIKKOR Z 24–70mm f/4 S.
•
Be careful to prevent dust entering the camera.
•
Confirm that the camera is off before attaching the lens.
- Remove the camera body cap (
q
,
w
) and rear lens cap (
e
,
r
).
- Align the mounting marks on the camera (
t
) and lens (
y
).
Do not touch the image sensor or lens contacts.
Attaching a Lens
10
Attaching a Lens
- Rotate the lens as shown until it clicks into place (
u
).
•
Remove the front lens cap before taking pictures.
D
F Mount Lenses
•
Be sure to attach the FTZ mount adapter (available separately) before
using F mount lenses.
•
Attempting to attach F mount lenses directly to the camera could
damage the lens or image sensor.
Detaching Lenses
•
After turning the camera off, press and
hold the lens release button (
q
) while
turning the lens in the direction shown
(
w
).
•
After removing the lens, replace the
lens caps and camera body cap.
11
Choose a Language and Set the Clock
The language option in the setup menu is automatically
highlighted the first time menus are displayed. Choose a
language and set the camera clock.
1
Turn the camera on.
2
Highlight [Language] in the
setup menu and press
2
.
The [Language] item is automatically
highlighted in the setup menu the
first time the
G
button is pressed
after purchase.
Choose a Language and Set the Clock
12
Choose a Language and Set the Clock
3
Select a language.
Press
1
or
3
to highlight the desired language and press
J
(the languages available vary with the country or region in
which the camera was originally purchased).
4
Highlight [Time zone and date]
and press
2
.
5
Choose a time zone.
•
Select [Time zone] in the [Time
zone and date] display.
•
Highlight a time zone in the [Time
zone] display and press
J
.
•
The display shows a time zone map listing the selected
cities in the chosen zone and the difference between the
time in the chosen zone and UTC.
13
Choose a Language and Set the Clock
6
Turn daylight saving time on or
off.
•
Select [Daylight saving time] in
the [Time zone and date] display.
•
Highlight [On] (daylight saving time
on) or [Off] (daylight saving time off) and press
J
.
•
Selecting [On] advances the clock one hour; to undo the
effect, select [Off].
7
Set the clock.
•
Select [Date and time] in the [Time
zone and date] display.
•
Press
J
after using the multi
selector to set the clock to the date
and time in the selected time zone (note that the camera
uses a 24-hour clock).
8
Choose a date format.
•
Select [Date format] in the [Time
zone and date] display.
•
Highlight the desired date (year,
month, and day) display order and
press
J
.
14
Choose a Language and Set the Clock
9
Exit the menus.
Lightly press the shutter-release
button halfway to exit to shooting
mode.
D
The
t
Icon
A flashing
t
icon in the shooting display indicates that the camera clock
has been reset. The date and time recorded with new photographs will
not be correct; use the [Time zone and date] > [Date and time] option in
the setup menu to set the clock to the correct time and date. The camera
clock is powered by an independent clock battery. The clock battery
charges when the main battery is inserted in the camera. It takes about 2
days to charge. Once charged, it will power the clock for about a month.
A
SnapBridge
Use the SnapBridge app to synchronize the camera clock with the clock
on a smartphone or tablet (smart device). See SnapBridge online help for
details.
15
Taking Photographs (
b
Auto)
Basic Photography and
Playback
Select
b
(auto) mode for simple “point-and-shoot”
photography.
D
Lenses with Retractable Barrels
Lenses with retractable barrels must be
extended before use. Rotate the lens zoom ring
as shown until the lens clicks into the extended
position.
1
Turn the camera on.
The monitor turns on.
2
Select photo mode by rotating the photo/movie
selector to
C
.
3
Rotate the mode dial
to
b
.
Taking Photographs (
b
Auto)
16
Taking Photographs (
b
Auto)
4
Press the shutter-release button halfway to focus.
•
The focus point will be displayed in
green when the camera focuses. If
the camera is unable to focus, the
AF-area brackets will flash.
•
The AF-assist illuminator may light
to assist the focus operation if the
subject is poorly lit.
•
You can also focus by pressing the AF-ON button.
5
Smoothly press the shutter-release button the rest
of the way down to take the photograph.
•
You can also take a photograph by
touching the monitor. Touch your
subject to focus and lift your finger
to release the shutter.
17
Shooting Movies (
b
Mode)
b
(auto) mode can also be used for simple, “point-and-shoot”
movie recording.
1
Turn the camera on.
The monitor turns on.
2
Select movie mode by rotating the photo/movie
selector to
1
.
Note that optional flash units cannot be used when the
camera is in movie mode.
3
Rotate the mode dial to
b
.
4
Press the movie-record button
to start recording.
5
Press the movie-record button again to end
recording.
Shooting Movies (
b
Mode)
18
Playback
Press the
K
button to view photos and movies recorded with
the camera.
Viewing Photos
Photos can be viewed by following the steps below.
1
Press the
K
button.
•
A picture will be displayed in the
monitor or viewfinder.
•
The memory card containing the
picture currently displayed is shown
by an icon.
2
Press
4
or
2
to view
additional pictures.
•
When pictures are displayed in the
monitor, you can view other
pictures by flicking a finger left or
right over the display.
•
To end playback and return to shooting mode, press the
shutter-release button halfway.
Playback
19
Playback
Viewing Movies
Movies are indicated by a
1
icon. Tap the
a
icon in the display
or press the
J
button to start playback (a progress bar shows
your approximate position in the movie).
12
3
4
675
1
1
icon
2
Length
3
a
icon
4
Current position/total length
5
Progress bar
6
Volume
7
Guide
20
Specifications
Technical Notes
Nikon Z5 Digital Camera
Specifications
Type
Type
Digital camera with support for interchangeable
lenses
Lens mount Nikon Z mount
Lens
Compatible
lenses
•
Z mount NIKKOR lenses
•
F mount NIKKOR lenses (mount adapter required;
restrictions may apply)
Effective pixels
Effective pixels 24.3 million
Image sensor
Type 35.9 × 23.9 mm CMOS sensor (Nikon FX format)
Total pixels 24.93 million
Dust-reduction
system
Image sensor cleaning, Image Dust Off reference data
(requires NX Studio)
21
Specifications
Storage
Image size
(pixels)
•
[FX (36 × 24)] selected for image area:
- 6016 × 4016 (Large: 24.2 M)
- 4512 × 3008 (Medium: 13.6 M)
- 3008 × 2008 (Small: 6.0 M)
•
[DX (24 × 16)] selected for image area:
- 3936 × 2624 (Large: 10.3 M)
- 2944 × 1968 (Medium: 5.8 M)
- 1968 × 1312 (Small: 2.6 M)
•
[1:1 (24 × 24)] selected for image area:
- 4016 × 4016 (Large: 16.1 M)
- 3008 × 3008 (Medium: 9.0 M)
- 2000 × 2000 (Small: 4.0 M)
•
[16:9 (36 × 20)] selected for image area:
- 6016 × 3384 (Large: 20.4 M)
- 4512 × 2536 (Medium: 11.4 M)
- 3008 × 1688 (Small: 5.1 M)
•
Photographs taken while filming movies at a
frame size of 3840 × 2160: 3840 × 2160
•
Photographs taken while filming movies at other
frame sizes: 1920 × 1080
File format
(image quality)
•
NEF (RAW): 12 or 14 bit (lossless compressed or
compressed)
•
JPEG: JPEG-Baseline compliant with fine (approx.
1:4), normal (approx. 1:8), or basic (approx. 1:16)
compression; size-priority and optimal-quality
compression available
•
NEF (RAW)+JPEG: Single photograph recorded in
both NEF (RAW) and JPEG formats
22
Specifications
Picture Control
System
Auto, Standard, Neutral, Vivid, Monochrome, Portrait,
Landscape, Flat, Creative Picture Controls (Dream,
Morning, Pop, Sunday, Somber, Dramatic, Silence,
Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue,
Red, Pink, Charcoal, Graphite, Binary, Carbon);
selected Picture Control can be modified; storage for
custom Picture Controls
Media
SD (Secure Digital) and UHS-II compliant SDHC and
SDXC memory cards
Double card
slots
The card in Slot 2 can be used for overflow or backup
storage or for separate storage of NEF (RAW) and JPEG
images; pictures can be copied between cards.
File system DCF 2.0, Exif 2.31
Viewfinder
Viewfinder
1.27-cm/0.5-in. approx. 3690k-dot (Quad VGA) OLED
electronic viewfinder with color balance and auto and
11-level manual brightness controls
Frame coverage Approx. 100% horizontal and 100% vertical
Magnification Approx. 0.8× (50 mm lens at innity, −1.0 m
−1
)
Eyepoint
21 mm (−1.0 m
−1
; from center surface of viewfinder
eyepiece lens)
Diopter
adjustment
−4 – +2 m
−1
Eye sensor
Automatically switches between monitor and
viewfinder displays
Storage
23
Specifications
Monitor
Monitor
8-cm/3.2-in., approx. 1040k-dot tilting TFT touch-
sensitive LCD with 170° viewing angle, approximately
100% frame coverage, and color balance and 11-level
manual brightness controls
Shutter
Type
Electronically-controlled vertical-travel focal-plane
mechanical shutter; electronic front-curtain shutter;
electronic shutter
Speed
1
/
8000
– 30 s (choose from step sizes of
1
/
3
and
1
/
2
EV),
bulb, time, X200
Flash sync
speed
X=
1
/
200
s; synchronizes with shutter at
1
/
200
s or slower;
auto FP high-speed sync supported
Release
Release mode Single frame, Continuous L, Continuous H, Self-timer
Approximate
frame advance
rate
•
Continuous L: Approx. 1 – 4 fps
•
Continuous H: Approx. 4.5 fps
* Maximum frame advance rate as measured by in-
house tests.
Self-timer
2 s, 5 s, 10 s, 20 s; 1–9 exposures at intervals of 0.5, 1, 2,
or 3 s
24
Specifications
Exposure
Metering
system
TTL metering using camera image sensor
Metering mode
•
Matrix metering
•
Center-weighted metering: Weight of 75% given
to 12 mm circle in center of frame; weighting can
instead be based on average of entire frame
•
Spot metering: Meters 4 mm circle (about 1.5% of
frame) centered on selected focus point
•
Highlight-weighted metering
Range
−
3 – +17 EV
* Figures are for ISO 100 and f/2.0 lens at 20 °C/68 °F
Mode
•
b
: Auto, P: programmed auto with flexible
program, S: shutter-priority auto, A: aperture-
priority auto, M: manual
•
U1, U2 and U3: user settings modes
Exposure
compensation
–5 – +5 EV (choose from step sizes of
1
/
3
and
1
/
2
EV)
available in modes P, S, A, and M
Exposure lock Luminosity locked at detected value
ISO sensitivity
(Recommended
Exposure
Index)
ISO 100–51200 (choose from step sizes of
1
/
3
and
1
/
2
EV); can also be set to approx. 0.3, 0.5, 0.7, or 1 EV
(ISO 50 equivalent) below ISO 100 or to approx. 0.3,
0.5, 0.7, or 1 EV (ISO 102400 equivalent) above ISO
51200; auto ISO sensitivity control available
Active
D-Lighting
Auto, Extra high, High, Normal, Low, and Off
25
Specifications
Multiple
exposure
Add, average, lighten, darken
Other options
HDR (high dynamic range), photo mode flicker
reduction
Autofocus
Type Hybrid phase-detection/contrast AF with AF assist
Detection
range
−3 – +19 EV
* Without low-light AF: −2 – +19 EV
* Measured in photo mode at ISO 100 and a
temperature of 20 °C/68 °F using single-servo AF
(AF-S) and a lens with a maximum aperture of f/2.0
Lens servo
•
Autofocus (AF): Single-servo AF (AF-S); continuous-
servo AF (AF-C); full-time AF (AF-F; available only in
movie mode); predictive focus tracking
•
Manual focus (M): Electronic rangefinder can be
used
Focus points
273 focus points
* Number of focus points available in photo mode
with single-point AF selected for AF-area mode and
FX selected for image area
AF-area mode
Pinpoint (available in photo mode only), single-point,
and dynamic-area AF (available in photo mode only);
wide-area AF (S); wide-area AF (L); auto-area AF
Focus lock
Focus can be locked by pressing shutter-release
button halfway (single-servo AF/AF-S) or by pressing
the center of the sub-selector
Exposure
26
Specifications
Vibration reduction (VR)
Camera on-
board VR
5-axis image sensor shift
Lens on-board
VR
Lens shift (available with VR lenses)
Flash
Flash control
TTL: i-TTL flash control; i-TTL balanced fill-flash is used
with matrix, center-weighted, and highlight-weighted
metering, standard i-TTL fill-flash with spot metering
Flash mode
Front-curtain sync, slow sync, rear-curtain sync, red-
eye reduction, red-eye reduction with slow sync, off
Flash
compensation
–3 – +1 EV (choose from step sizes of
1
/
3
and
1
/
2
EV)
available in modes P, S, A, and M
Flash-ready
indicator
Lights when optional flash unit is fully charged;
flashes as underexposure warning after flash is fired at
full output
Accessory shoe
ISO 518 hot-shoe with sync and data contacts and
safety lock
Nikon Creative
Lighting
System (CLS)
i-TTL flash control, radio-controlled Advanced
Wireless Lighting, optical Advanced Wireless Lighting,
modeling illumination, FV lock, Color Information
Communication, auto FP high-speed sync, unified
flash control
White balance
White balance
Auto (3 types), natural light auto, direct sunlight,
cloudy, shade, incandescent, fluorescent (7 types),
flash, choose color temperature (2500 K–10,000 K),
preset manual (up to 6 values can be stored), all with
fine-tuning except choose color temperature
27
Specifications
Bracketing
Bracketing Exposure and/or flash, white balance, and ADL
Movie
Metering
system
TTL metering using camera image sensor
Metering mode Matrix, center-weighted, or highlight-weighted
Frame size
(pixels) and
frame rate
•
3840 × 2160 (4K UHD): 30p (progressive)/25p/24p
•
1920 × 1080: 60p/50p/30p/25p/24p
* Actual frame rates for 60p, 50p, 30p, 25p, and 24p
are 59.94, 50, 29.97, 25, and 23.976 fps respectively
* Quality selection (normal/
m
) available at all sizes
except 3840 × 2160, when quality is fixed at
m
File format MOV, MP4
Video
compression
H.264/MPEG-4 Advanced Video Coding
Audio
recording
format
Linear PCM (for movies recorded in MOV format) or
AAC (for movies recorded in MP4 format)
Audio
recording
device
Built-in stereo or external microphone with
attenuator option; sensitivity adjustable
Exposure
compensation
–3 – +3 EV (choose from step sizes of
1
/
3
and
1
/
2
EV)
available in modes P, S, A, and M
28
Specifications
ISO sensitivity
(Recommended
Exposure
Index)
•
M: Manual selection (ISO 100–25600; choose from
step sizes of
1
/
3
and
1
/
2
EV); auto ISO sensitivity
control (ISO 100–25600) available with selectable
upper limit
•
P, S, A: Auto ISO sensitivity control (ISO 100–25600)
with selectable upper limit
•
b
: Auto ISO sensitivity control (ISO 100–25600)
Active
D-Lighting
Same as photo settings, Extra high, High, Normal,
Low, and Off
Other options
Time-lapse movie recording, electronic vibration
reduction, time codes
Playback
Playback
Full-frame and thumbnail (4, 9, or 72 images or
calendar) playback with playback zoom, playback
zoom cropping, movie playback, photo and/or movie
slide shows, histogram display, highlights, photo
information, location data display, auto image
rotation, and picture rating
Interface
USB
Type C USB connector (SuperSpeed USB); connection
to built-in USB port is recommended
HDMI output Type C HDMI connector
Accessory
terminal
Built-in (can be used with MC-DC2 remote cords and
other optional accessories)
Audio input
Stereo mini-pin jack (3.5 mm diameter; plug-in power
supported)
Audio output Stereo mini-pin jack (3.5 mm diameter)
Movie
29
Specifications
Wi-Fi/Bluetooth
Wi-Fi
•
Standards:
- IEEE 802.11b/g/n (Africa, Asia, Bolivia, Europe, and
Oceania)
- IEEE 802.11b/g/n/a/ac (U.S.A., Canada, Mexico)
- IEEE 802.11b/g/n/a (other countries in the
Americas)
•
Operating frequency:
- 2412–2462 MHz (channel 11; Africa, Asia, Bolivia,
Europe, and Oceania)
- 2412–2462 MHz (channel 11) and 5180–5825 MHz
(U.S.A., Canada, Mexico)
- 2412–2462 MHz (channel 11) and 5180–5805 MHz
(other countries in the Americas)
•
Maximum output power (EIRP):
- 0.7 dBm (2.4 GHz)
-6.2 dBm (5 GHz)
•
Authentication: Open system, WPA2-PSK
Bluetooth
•
Communication protocols: Bluetooth Specification
Version 4.2
•
Operating frequency:
- Bluetooth: 2402–2480 MHz
- Bluetooth Low Energy: 2402–2480 MHz
•
Maximum output power (EIRP):
- Bluetooth: –4.8 dBm
- Bluetooth Low Energy: –6.3 dBm
Range (line of
sight)
Approximately 10 m (32 ft)
*
* Without interference. Range may vary with signal
strength and presence or absence of obstacles.
30
Specifications
Power source
Battery
One EN-EL15c rechargeable Li-ion battery
*
* EN-EL15b/EN-EL15a/EN-EL15 batteries can also be
used. Note, however, that fewer pictures can be
taken on a single charge than with the EN-EL15c.
The EH-7P charging AC adapter can be used to
charge EN-EL15c/EN-EL15b batteries only.
Battery pack
MB-N10 battery pack (available separately); takes two
EN-EL15c
*
batteries
* EN-EL15b/EN-EL15a/EN-EL15 batteries can be used
in place of the EN-EL15c. The number of pictures
that can be taken on a single charge (i.e., battery
endurance) will however drop compared to the
EN-EL15c.
Charging AC
adapter
EH-7P charging AC adapter (available separately)
AC adapter
EH-5d/EH-5c/EH-5b AC adapter; requires EP-5B power
connector (available separately)
Tripod socket
Tripod socket 1/4 in. (ISO 1222)
Dimensions/weight
Dimensions
Approx.134 × 100.5 × 69.5 mm/5.3 × 4.0 × 2.8 in.
(width × height × depth)
Weight
Approx. 675 g (1 lb. 7.9 oz.) with battery and memory
card but without body cap; approx. 590 g/1 lb. 4.9 oz.
(camera body only)
31
Specifications
•
Unless otherwise stated, all measurements are performed in conformity
with Camera and Imaging Products Association (CIPA) standards or
guidelines.
•
All figures are for a camera with a fully-charged battery.
•
The sample images displayed on the camera and the images and
illustrations in the manuals are for expository purposes only.
•
Nikon reserves the right to change the appearance and specifications of
the hardware and software described in this manual at any time and
without prior notice. Nikon will not be held liable for damages that may
result from any mistakes that this manual may contain.
Operating environment
Temperature 0 °C–40 °C (+32 °F–104 °F)
Humidity 85% or less (no condensation)
32
Specifications
❚❚
MH-25a Battery Charger
The symbols on this product represent the following:
m
AC,
p
DC,
q
Class II equipment (the construction of the product is
double-insulated)
❚❚
EN-EL15c Rechargeable Li-ion Battery
Rated input AC 100 to 240 V, 50/60 Hz, 0.23–0.12 A
Rated output DC 8.4 V/1.2 A
Supported
batteries
EN-EL15c/EN-EL15b/EN-EL15a/EN-EL15 Rechargeable
Li-ion Battery
Charging time
Approx. 2 hours 35 minutes
* Time required to charge battery at an ambient
temperature of 25 °C (77 °F) when no charge
remains
Operating
temperature
0 °C–40 °C (+32 °F–104 °F)
Dimensions
Approx. 95 × 33.5 × 71 mm/3.7 × 1.3 × 2.8 in. (width ×
height × depth), excluding projections
Length of
power cable
Approx. 1.5 m (4.9 ft), if supplied
Weight
Approx. 115 g (4.1 oz), excluding supplied power
connector (power cable or AC wall adapter)
Type Rechargeable lithium-ion battery
Rated capacity 7.0 V/2280 mAh
Operating
temperature
0 °C–40 °C (+32 °F–104 °F)
Dimensions
Approx. 40 × 56 × 20.5 mm/1.6 × 2.2 × 0.8 in. (width ×
height × depth)
Weight Approx. 80 g (2.9 oz), excluding terminal cover
33
Approved Memory Cards
•
The camera can be used with SD, SDHC, and SDXC memory
cards.
•
UHS-I and UHS-II are supported.
•
Cards rated UHS Speed Class 3 or better are
recommended for movie recording and playback. Slower
speeds may result in recording or playback being interrupted.
•
When choosing cards for use in card readers, be sure they are
compatible with the device.
•
Contact the manufacturer for information on features,
operation, and limitations on use.
Approved Memory Cards
34
Portable Chargers (Power Banks)
Portable chargers can be used to power the camera or charge
the camera battery. The following table lists the portable
chargers that have been tested and approved for use, together
with the approximate number of shots that can be taken with,
and the approximate number of times the camera battery can
be charged using, each device.
1 Camera and Imaging Products Association (CIPA) standard.
[Viewfinder only] selected for monitor mode. Measured at 23 °C/
73.4 °F (±2 °C/3.6 °F) with a NIKKOR Z 24–70mm f/4 S lens under the
following test conditions: one photograph taken at default settings
once every 30 s. The “number of shots” is the number of shots that can
be taken using a fully-charged portable charger to supply power to a
camera with a fully-charged battery (EN-EL15c).
2 The number of times the camera battery (EN-EL15c) can be fully
charged using a portable charger at full charge.
•
The only batteries that can be charged from portable chargers
are the EN-EL15c and EN-EL15b.
•
See the documentation provided with the portable charger for
information on use.
•
Use a USB cable with two Type-C connectors supplied with the
portable charger when employing the device to power the
camera or charge the camera battery.
•
Up-to-date information on portable chargers is available on
the website of the manufacturers. Availability may vary with
country or region.
Portable Chargers (Power Banks)
Manufacturer Model number
Number of
shots
1
Number of
charges
2
Anker PowerCore+ 26800 PD 45W 2120 3
35
Trademarks and Licenses
•
The SD, SDHC, and SDXC logos are trademarks of SD-3C, LLC.
•
Windows is either a registered trademark or a trademark of
Microsoft Corporation in the United States and/or other
countries.
•
Apple®, App Store®, the Apple logos, iPhone®, iPad®, Mac, and
macOS are trademarks of Apple Inc. registered in the U.S. and/
or other countries.
•
Android, Google Play and the Google Play logo are trademarks
of Google LLC. The Android robot is reproduced or modified
from work created and shared by Google and used according
to terms described in the Creative Commons 3.0 Attribution
License.
•
IOS is a trademark or registered trademark of Cisco Systems,
Inc., in the United States and/or other countries and is used
under license.
•
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing, LLC.
Trademarks and Licenses
36
Trademarks and Licenses
•
The Bluetooth® word mark and logo are registered trademarks
owned by Bluetooth SIG, Inc., and any use of such marks by
Nikon is under license.
•
Wi-Fi and the Wi-Fi logo are trademarks or registered
trademarks of the Wi-Fi Alliance.
•
All other trade names mentioned in this manual or the other
documentation provided with your Nikon product are
trademarks or registered trademarks of their respective
holders.
D
FreeType License (FreeType2)
Portions of this software are copyright © 2012 The FreeType Project
(https://www.freetype.org
). All rights reserved.
D
MIT License (HarfBuzz)
Portions of this software are copyright © 2018 The HarfBuzz Project
(https://www.freedesktop.org/wiki/Software/HarfBuzz
). All rights
reserved.
Use of the Made for Apple badge means that an accessory has been
designed to connect specifically to the Apple products identified in the
badge, and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this
device or its compliance with safety and regulatory standards. Please
note that the use of this accessory with an Apple product may affect
wireless performance.
37
Trademarks and Licenses
D
Unicode® Character Database License (Unicode® Character
Database)
The software for this product uses the Unicode® Character Database
License open-source software. The terms of the software license are as
follows:
COPYRIGHT AND PERMISSION NOTICE
Copyright © 1991-2019 Unicode, Inc. All rights reserved.
Distributed under the Terms of Use in
https://www.unicode.org/copyright.html.
Permission is hereby granted, free of charge, to any person obtaining a
copy of the Unicode data files and any associated documentation (the
"Data Files") or Unicode software and any associated documentation (the
"Software") to deal in the Data Files or Software without restriction,
including without limitation the rights to use, copy, modify, merge,
publish, distribute, and/or sell copies of the Data Files or Software, and to
permit persons to whom the Data Files or Software are furnished to do so,
provided that either
(i) this copyright and permission notice appear with all copies of the
Data Files or Software, or
(ii) this copyright and permission notice appear in associated
Documentation.
38
Trademarks and Licenses
THE DATA FILES AND SOFTWARE ARE PROVIDED "AS IS", WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY
RIGHTS. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS
INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL
INDIRECT OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS,
WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER
TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE
OR PERFORMANCE OF THE DATA FILES OR SOFTWARE.
Except as contained in this notice, the name of a copyright holder shall
not be used in advertising or otherwise to promote the sale, use or other
dealings in these Data Files or Software without prior written
authorization of the copyright holder.
D
AVC Patent Portfolio License
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC
VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-
COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO
PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
https://www.mpegla.com
39
Notices
Notices for Customers in the U.S.A.
Federal Communications Commission (FCC) Radio Frequency Interference Statement
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part 15
of the FCC rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or
television reception, which can be
determined by turning the equipment
off and on, the user is encouraged to try
to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced
radio/television technician for help.
CAUTIONS
Modifications
The FCC requires the user to be
notified that any changes or
modifications made to this device that
are not expressly approved by Nikon
Corporation may void the user’s
authority to operate the equipment.
Interface Cables
Use the interface cables sold or provided
by Nikon for your equipment. Using
other interface cables may exceed the
limits of Class B Part 15 of the FCC rules.
Nikon Inc., 1300 Walt Whitman Road,
Melville, New York 11747-3064, U.S.A.
Tel.: 631-547-4200
Notices
The Battery Charger
IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE
INSTRUCTIONS
DANGER—TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS
For connection to a supply not in the U.S.A., use an attachment plug adapter
of the proper configuration for the power outlet if needed. This power unit
is intended to be correctly oriented in a vertical or floor mount position.
40
Notices
Power Cable
At voltages over AC 125 V (U.S.A. only): The power cable must be rated for the
voltage in use, be at least AWG no. 18 gauge, and have SVG insulation or
better with a NEMA 6P-15 plug rated for AC 250 V 15 A.
Notice for Customers in Canada
CAN ICES-3 B / NMB-3 B
Notices for Customers in Europe
This symbol indicates
that electrical and
electronic equipment is
to be collected
separately.
The following apply only
to users in European countries:
• This product is designated for
separate collection at an
appropriate collection point. Do not
dispose of as household waste.
• Separate collection and recycling
helps conserve natural resources
and prevent negative consequences
for human health and the
environment that might result from
incorrect disposal.
• For more information, contact the
retailer or the local authorities in
charge of waste management.
This symbol on the
battery indicates that the
battery is to be collected
separately.
The following apply only
to users in European
countries:
• All batteries, whether marked with
this symbol or not, are designated
for separate collection at an
appropriate collection point. Do not
dispose of as household waste.
• For more information, contact the
retailer or the local authorities in
charge of waste management.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
41
Bluetooth and Wi-Fi (Wireless LAN)
This product is controlled by the United States Export Administration
Regulations (EAR). The permission of the United States government is not
required for export to countries other than the following, which as of this
writing are subject to embargo or special controls: Cuba, Iran, North Korea,
Sudan, and Syria (list subject to change).
The use of wireless devices may be prohibited in some countries or regions.
Contact a Nikon-authorized service representative before using the wireless
features of this product outside the country of purchase.
The Bluetooth transmitter in this device operates in the 2.4 GHz band.
Notice for Customers in the U.S.A. and Canada
This device complies with part 15 of FCC Rules and Innovation, Science and
Economic Development Canada’s licence-exempt RSSs. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC WARNING
The FCC requires the user to be notified that any changes or modifications
made to this device that are not expressly approved by Nikon Corporation
may void the user’s authority to operate the equipment.
Bluetooth and Wi-Fi (Wireless LAN)
42
Bluetooth and Wi-Fi (Wireless LAN)
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down
through the MAC, through the digital and analog baseband, and finally to the
RF chip. Several special packets are initiated by the MAC. These are the only
ways the digital baseband portion will turn on the RF transmitter, which it
then turns off at the end of the packet. Therefore, the transmitter will be on
only while one of the aforementioned packets is being transmitted. In other
words, this device automatically discontinue transmission in case of either
absence of information to transmit or operational failure.
Frequency Tolerance: ±20 ppm
FCC Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Co-location
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
Nikon Inc., 1300 Walt Whitman Road, Melville, New York 11747-3064, U.S.A.
Tel.: 631-547-4200
43
Bluetooth and Wi-Fi (Wireless LAN)
FCC/ISED RF Exposure Statement
The available scientific evidence does not show that any health problems are
associated with using low power wireless devices. There is no proof, however,
that these low power wireless devices are absolutely safe. Low power Wireless
devices emit low levels of radio frequency energy (RF) in the microwave range
while being used. Whereas high levels of RF can produce health effects (by
heating tissue), exposure of low-level RF that does not produce heating
effects causes no known adverse health effects. Many studies of low-level RF
exposures have not found any biological effects. Some studies have
suggested that some biological effects might occur, but such findings have
not been confirmed by additional research. This product has been tested and
found to comply with FCC/ISED radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines and RSS-102 of the ISED radio frequency (RF) Exposure rules.
Please refer to the SAR test report that was uploaded to FCC website.
Compliance with RSS-247 Issue 2 §6.4
Data transmission is always initiated by software, which is the passed down
through the MAC, through the digital and analog baseband, and finally to the
RF chip. Several special packets are initiated by the MAC. These are the only
ways the digital baseband portion will turn on the RF transmitter, which it
then turns off at the end of the packet. Therefore, the transmitter will be on
only while one of the aforementioned packets is being transmitted. In other
words, this device automatically discontinue transmission in case of either
absence of information to transmit or operational failure.
Notice for Customers in Canada
For indoor use only (5150-5350MHz).
Notice for Customers in Europe and in Countries Complying with the
Radio Equipment Directive
Hereby, Nikon Corporation declares that the radio equipment
type Z 5 is in compliance with Directive 2014/53/EU.
The full texts of the EU declarations of conformity are available at
the following internet addresses:
https://imaging.nikon.com/support/pdf/DoC_N1933.pdf
44
Bluetooth and Wi-Fi (Wireless LAN)
Notice for Customers in the UK
Hereby, Nikon Corporation declares that the radio equipment type
Z 5 is in compliance with Radio Equipment Regulations 2017.
The full text of the UKCA declaration of conformity is available at the
following internet address:
https://imaging.nikon.com/support/pdf/UKCA_DoC_N1933.pdf
Wi-Fi
• Operating frequency:
- 2412–2462 MHz (channel 11)
• Maximum output power (EIRP):
- 2.4 GHz band: 0.7 dBm
- 5GHz band: 6.2dBm
Bluetooth
• Operating frequency:
- Bluetooth: 2402–2480 MHz
- Bluetooth Low Energy:
2402–2480 MHz
• Maximum output power (EIRP):
- Bluetooth: –4.8 dBm
- Bluetooth Low Energy: –6.3 dBm
This product complies with the UK PSTI Act 2022 and the statement of
compliance and security update period is available at the following internet
address:
https://www.nikonimgsupport.com/eu/BV_article?lang=en_GB&articleNo=000066765
Notice for Customers in Singapore
This device complies with radio-frequency regulations. The content of
certification labels not affixed to the device is given below.
Trade Name:
Model: Z 5
Complies with
IMDA Standards
DA103423
45
Bluetooth and Wi-Fi (Wireless LAN)
Notice for Customers in Nigeria
Security
Although one of the benefits of this product is that it allows others to freely
connect for the wireless exchange of data anywhere within its range, the
following may occur if security is not enabled:
• Data theft: Malicious third-parties may intercept wireless transmissions to
steal user IDs, passwords, and other personal information.
• Unauthorized access: Unauthorized users may gain access to the network
and alter data or perform other malicious actions. Note that due to the
design of wireless networks, specialized attacks may allow unauthorized
access even when security is enabled.
• Unsecured networks: Connecting to open networks may result in
unauthorized access. Use secure networks only.
Connection and use of this communications
equipment is permitted by the Nigerian
Communications Commission
46
Bluetooth and Wi-Fi (Wireless LAN)
A Conformity Marking
The standards with which the camera complies can be viewed using the
[Conformity marking] option in the setup menu.
A Certificates
47
NIKKOR Z 24–70mm f/4 S Lens
Kit Lens
Note that lens kits may not be available in some countries or
regions.
Parts of the Lens: Names and Functions
The parts of the NIKKOR Z 24–70mm f/4 S are listed below.
NIKKOR Z 24–70mm f/4 S Lens
45678
12
91011
12
3
13
14
1
Lens hood
2
Lens hood lock mark
3
Lens hood alignment mark
4
Lens hood mounting mark
5
Zoom ring
6
Focal length scale
7
Focal length mark
8
Control ring
9
Lens mounting mark
10
Rubber lens-mount gasket
11
CPU contacts
12
Focus-mode switch
13
Front lens cap
14
Rear lens cap
48
NIKKOR Z 24–70mm f/4 S Lens
Specifications
Nikon reserves the right to change the appearance, specifications, and
performance of this product at any time and without prior notice.
Mount Nikon Z mount
Focal length 24 – 70 mm
Maximum aperture f/4
Lens construction
14 elements in 11 groups (including 1 ED lens
element, 1 aspherical ED element, 3 aspherical
elements, elements with Nano Crystal Coat, and a
fluorine-coated front lens element)
Angle of view
•
FX format: 84° – 34° 20´
•
DX format: 61° – 22° 50´
Focal length scale Graduated in millimeters (24, 28, 35, 50, 70)
Focusing system Internal focusing system
Minimum focus
distance
0.3 m (0.99 ft) from focal plane at all zoom
positions
Diaphragm blades 7 (rounded diaphragm opening)
Aperture range f/4 – 22
Filter-attachment
size
72 mm (P = 0.75 mm)
Dimensions
Approx. 77.5 mm maximum diameter × 88.5 mm
(distance from camera lens mount flange when
lens is retracted)
Weight Approx. 500 g (1 lb 1.7 oz)
49
NIKKOR Z 24–200mm f/4–6.3 VR Lens
Note that lens kits may not be available in some countries or
regions.
Parts of the Lens: Names and Functions
The parts of the NIKKOR Z 24–200mm f/4–6.3 VR are listed
below.
NIKKOR Z 24–200mm f/4–6.3 VR Lens
45678
12
9101112
3
13
14
1
Lens hood
2
Lens hood lock mark
3
Lens hood alignment mark
4
Lens hood mounting mark
5
Zoom ring
6
Focal length scale
7
Focal length mark
8
Control ring
9
Lens mounting mark
10
Rubber lens-mount gasket
11
CPU contacts
12
Zoom lock switch
13
Lens cap (front cap)
14
Lens cap (rear cap)
50
NIKKOR Z 24–200mm f/4–6.3 VR Lens
Specifications
Mount Nikon Z mount
Focal length 24 – 200 mm
Maximum aperture f/4 – 6.3
Lens construction
19 elements in 15 groups (including 2 ED
elements, 1 aspherical ED element, 2 aspherical
elements, and elements with an ARNEO coat and a
fluorine-coated front lens element)
Angle of view
•
FX format: 84°–12° 20’
•
DX format: 61°–8°
Focal length scale
Graduated in millimeters (24, 35, 50, 70, 105, 135,
200)
Focusing system Internal focusing system
Vibration
reduction
Lens shift using voice coil motors (VCMs)
Minimum focus
distance
(measured from
focal plane)
•
24 mm zoom position: 0.5 m (1.64 ft)
•
35 mm zoom position: 0.54 m (1.78 ft)
•
50 mm zoom position: 0.55 m (1.81 ft)
•
70 mm zoom position: 0.58 m (1.91 ft)
•
105 mm zoom position: 0.65 m (2.14 ft)
•
135 mm zoom position: 0.68 m (2.24 ft)
•
200 mm zoom position: 0.7 m (2.30 ft)
Maximum
reproduction ratio
0.28×
Diaphragm blades 7 (rounded diaphragm opening)
51
NIKKOR Z 24–200mm f/4–6.3 VR Lens
Nikon reserves the right to change the appearance, specifications, and
performance of this product at any time and without prior notice.
Aperture range
•
24 mm zoom position: f/4 – 22
•
200 mm zoom position: f/6.3 – 36
The minimum aperture displayed may vary
depending on the size of the exposure increment
selected with the camera.
Filter-attachment
size
67 mm (P = 0.75 mm)
Dimensions
Approx. 76.5 mm/3.1 in. maximum diameter ×
114 mm/4.5 in.
(distance from camera lens mount flange)
Weight Approx. 570 g (1 lb 4.2 oz)
52
NIKKOR Z 24–50mm f/4–6.3 Lens
Note that lens kits may not be available in some countries or
regions.
Parts of the Lens: Names and Functions
The parts of the NIKKOR Z 24–50mm f/4–6.3 are listed below.
*Available separately.
NIKKOR Z 24–50mm f/4–6.3 Lens
12 56789 10 11
4
312
1
Lens hood
*
2
Lens hood lock mark
3
Lens hood alignment mark
4
Lens hood mounting mark
5
Zoom ring
6
Focal length scale
7
Focal length mark
8
Control ring
9
Lens mounting mark
10
CPU contacts
11
Lens cap (front cap)
12
Lens cap (rear cap)
53
NIKKOR Z 24–50mm f/4–6.3 Lens
Specifications
Nikon reserves the right to change the appearance, specifications, and
performance of this product at any time and without prior notice.
Mount Nikon Z mount
Focal length 24 – 50 mm
Maximum aperture f/4 – 6.3
Lens construction
11 elements in 10 groups (including 2 ED elements
and 3 aspherical elements)
Angle of view
•
FX format: 84°–47°
•
DX format: 61°–31° 30’
Focal length scale Graduated in millimeters (24, 28, 35, 40, 50)
Focusing system Internal focusing system
Minimum focus
distance
0.35 m (1.15 ft) from focal plane at all zoom
positions
Maximum
reproduction ratio
0.17× (50 mm zoom position)
Diaphragm blades 7 (rounded diaphragm opening)
Aperture range
•
24 mm zoom position: f/4 – 22
•
50 mm zoom position: f/6.3 – 36
Filter-attachment
size
52 mm (P = 0.75 mm)
Dimensions
Approx. 73.5 mm (2.9 in.) maximum diameter ×
51 mm (2.1 in.) (distance from camera lens mount
flange when lens is retracted)
Weight Approx. 195 g (6.9 oz)
54
55
Warranty Terms - Nikon Europe Service Warranty
Dear Nikon Customer,
We thank you for your purchasing this Nikon product. Should
your Nikon product require warranty service, please contact the
dealer from whom it was purchased or a member of our
authorized service network within the sales territory of Nikon
Europe B.V. (e.g. Europe/Russia/others). See details under:
https://www.europe-nikon.com/support
In order to avoid any unnecessary inconvenience, we advise you
to read the user manuals carefully before contacting the dealer
or our authorized service network.
Your Nikon equipment is guaranteed against any manufacturing
defects for one full year from the date of original purchase. If
during this period of guarantee the product proves defective
due to improper material or workmanship, our authorized
service network within the sales territory of Nikon Europe B.V.
will, without charge for labor and parts, repair the product in the
terms and conditions set as below. Nikon reserves the right (at its
sole discretion) to replace or repair the product.
1. This warranty is only provided upon presentation of the
completed warranty card and original invoice or purchase
receipt indicating the date of purchase, product type and
dealer’s name, together with the product. Nikon reserves the
right to refuse free-of-charge warranty service if the above
documents cannot be presented or if the information
contained in it is incomplete or illegible.
Warranty Terms - Nikon Europe Service
Warranty
56
Warranty Terms - Nikon Europe Service Warranty
2. This warranty will not cover:
• necessary maintenance and repair or replacement of parts
due to normal wear and tear.
• modifications to upgrade the product from its normal
purpose as described in user manuals, without the prior
written consent of Nikon.
• transport costs and all risks of transport relating directly or
indirectly to the warranty of the products.
• any damage resulting from modifications or adjustments
which may be made to the product, without the prior
written consent of Nikon, in order to comply with local or
national technical standards in force in any other country
than the ones for which the product was originally designed
and/or manufactured.
3. The warranty will not be applicable in the case of:
• damage caused by misuse including but not limited to
failure to use the product for its normal purpose or
according to the user instructions on the proper use and
maintenance, and to installation or use of the product
inconsistent with the safety standards in force in the
country where it is used.
• damage caused by accidents including but not limited to
lightning, water, fire, misuse or neglect.
• defacing, illegibility or removal of the model or serial
number on the product.
• damage resulting from repairs or adjustments which have
been conducted by unauthorized service organizations or
persons.
• defects in any system into which the product is
incorporated or with which it is used.
57
Warranty Terms - Nikon Europe Service Warranty
4. This service warranty does not affect the consumer’s statutory
rights under applicable national laws in force, nor the
consumer’s right against the dealer arising from their sales/
purchase contract.
Notice: An overview of all authorized Nikon Service Stations can
be found online by following this Link
(URL = https://www.europe-nikon.com/service/).
No reproduction in any form of this manual, in whole or in part (except
for brief quotation in critical articles or reviews), may be made without
written authorization from NIKON CORPORATION.
SB4E04(11)
6MOA5811-04
