USER MANUAL
HW-S68CB
You can access the FULL MANUAL on Samsung’s on-line customer support center by scanning the QR code on the
left. To see the manual on your PC or mobile device, download the manual in document format from Samsung’s
website. (http://www.samsung.com/support)
SAFETY INFORMATION
• The following also applies to the Wireless Subwoofer
(PS-WC74B).
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Refer to the table below for an explanation of symbols which may
be on your Samsung product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Class II product : This symbol indicates that a
safety connection to electrical earth (ground) is
not required.
If this symbol is not present on a product with
a power cord, the product MUST have a reliable
connection to protective earth (ground).
AC voltage : Rated voltage marked with this
symbol is AC voltage.
DC voltage : Rated voltage marked with this
symbol is DC voltage.
Caution. Consult Instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
WARNING
• To reduce the risk of re or electric shock, do not expose this
appliance to rain or moisture.
• To prevent injury, this apparatus must be securely set on a solid
surface or attached to a wall in accordance with the installation
instructions.
• This product contains chemicals known to the State of California
to cause cancer and birth defects or other reproductive harm.
CAUTION
• Do not expose this apparatus to dripping or splashing. Do not put
objects lled with liquids, such as vases, on the apparatus.
• To turn this apparatus off completely, you must pull the power
plug out of the wall socket. Consequently, the power plug must
be easily and readily accessible at all times.
FCC NOTE (for U.S.A):
FCC Supplier’s Declaration of Conformity
Responsible Party - U.S. Contact Information:
Samsung Electronics America, Inc.
85 Challenger Road.
Ridgeeld Park, NJ 07660
Phone: 1-800-SAMSUNG (726-7864)
FCC Compliance Statement :
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution :
• Any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate this equipment.
• This product satises FCC regulations when shielded cables and
connectors are used to connect the unit to other equipment.
To prevent electromagnetic interference with electric
appliances, such as radios and televisions, use shielded cables
and connectors for connections.
Class B FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorienting or relocating the receiving antenna.
• Increasing the separation between the equipment and receiver.
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for
help.
FCC Radiation Exposure Statement :
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna
or transmitter.
CALIFORNIA USA ONLY (Applicable for networking models only.)
This Perchlorate warning applies only to primary CR(Manganese
Dioxide) Lithium coin cells in the product sold or distributed ONLY
in California USA “Perchlorate Material - special handling may
apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.”
Dispose unwanted electronics through an approved recycler. To
nd the nearest recycling location, go to our website:
www.samsung.com/recycling Or call, 1‐800‐SAMSUNG
WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov.
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not hinder in any way the safety purpose of the polarized
or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades
and a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
PRECAUTIONS
1. Make sure to rest the AC/DC Adapter at on a table or the oor.
If you place the AC/DC Adapter so that it is hanging with the AC
cord input facing upwards, water or other foreign substances
could enter the Adapter and cause the Adapter to malfunction.
2. Ensure that the AC power supply in your house complies with
the power requirements listed on the identication sticker
located on the bottom of your product. Install your product
horizontally, on a suitable base (furniture), with enough space
around it for ventilation (3~4 inches). Make sure the ventilation
slots are not covered. Do not place the unit on ampliers or
other equipment which may become hot. This unit is designed
for continuous use. To fully turn off the unit, disconnect the AC
plug from the wall outlet. Unplug the unit if you intend to leave
it unused for a long period of time.
3. During thunderstorms, disconnect the AC plug from the wall
outlet. Voltage peaks due to lightning could damage the unit.
4. Do not expose the unit to direct sunlight or other heat
sources. This could lead to overheating and cause the unit to
malfunction.
5. Protect the product from moisture (i.e. vases), and excess heat
(e.g. a replace) or equipment creating strong magnetic or
electric elds. Unplug the power cable from the AC wall socket if
the unit malfunctions. Your product is not intended for industrial
use. It is for personal use only. Condensation may occur if your
product has been stored in cold temperatures. If transporting the
unit during the winter, wait approximately 2 hours or until the unit
has reached room temperature before using.
6. The battery used with this product contains chemicals that are
harmful to the environment. Do not dispose of the battery in the
general household trash. Do not expose the battery to excess
heat, direct sunlight, or re. Do not short circuit, disassemble, or
overheat the battery. CAUTION : Danger of explosion if the battery
is replaced incorrectly. Replace only with the same or equivalent
type.
01 CHECKING THE
COMPONENTS
Soundbar Main Unit / Subwoofer / Soundbar Remote Control
/ Batteries / Power Cord X 2 (Subwoofer, Soundbar) / AC/DC
Adapter / HDMI Cable / Wall Mount Guide / Holder-Screw X 2
/ Bracket-Wall Mount X 2 / Screw (M4 x L10) X 2
NOTES
• For more information about the power supply and power
consumption, refer to the label attached to the product. (Label:
Bottom of the Soundbar Main Unit)
• To purchase additional components or optional cables, contact a
Samsung Service Center or Samsung Customer Care.
• Design, specications, and App screen are subject to change
without prior notice.
02 PRODUCT OVERVIEW
Front Panel / Top Panel of the Soundbar
Volume
Multi Function Button
In standby mode, press the (Multi Function) button to
turn on the Soundbar.
Press the (Multi Function) button to change the mode.
LED Indicator
White On -> Off
“Digital Audio In” or
“TV ARC”
White On -> Off
“Wi-Fi”
White On -> Off
“Bluetooth”
Mic On/Off Button
Press the (Mic On/Off) button to turn on or off the
microphone.
LED Indicator
Red On
“Mic Off”
“Mic On”
LED indicator
The LED Indicator ashes, glows, or changes color
depending on the Soundbar's current mode or status.
Bottom Panel of the Soundbar
SERVICE
DC 19V
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
SERVICE
DC 19V
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
SERVICE
DC 19V
DC 19V (Power Supply In)
Connect the AC/DC power adapter.
SERVICE
Connect a USB storage device to upgrade the product's
software.
DIGITAL AUDIO IN (OPTICAL)
Connect to the digital (optical) output of an external
device.
HDMI (ARC)
Connect to the HDMI (ARC) port on a TV.
03 CONNECTING THE
SOUNDBAR
Connecting Electrical Power
• For more information about the required electrical power and
power consumption, refer to the label attached to the product.
(Label: Bottom of the Soundbar Main Unit)
SERVICE
DC 19V
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
SERVICE
DC 19V
Bottom of the Soundbar Main Unit
Rear of Subwoofer
Blue Blinks
• The LINK LED indicator stops blinking and glows a solid blue
when a connection is established between the Soundbar and the
Wireless Subwoofer.
AH81-15239M-01
© 2022 Samsung Electronics Co., Ltd. All rights reserved.
QUESTIONS OR COMMENTS?
Country
IN THE US
1-800-SAMSUNG
(726-7864)
www.samsung.com/us/support
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefi eld Park, NJ 07660
Samsung Service Center
Web Site Address
04 CONNECTING WITH A CABLE
HDMI Cable
Optical Cable (not supplied)
Bottom of the Soundbar
TV
HDMI IN
(ARC)
HDMI OUT
OPTICAL OUT
HDMI 입력
(ARC)
HDMI 출력
OPTICAL 출력
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
SERVICE
DC 19V
White On -> Off
“Digital Audio In”
Bottom of the Soundbar
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
SERVICE
DC 19V
TV / BD / DVD player /
Set-top box / Game console
HDMI IN
(ARC)
HDMI OUT
OPTICAL OUT
HDMI 입력
(ARC)
HDMI 출력
OPTICAL 출력
White On -> Off
“Digital Audio In”
NOTES
• When the TV sound is not output, press the (Multi Function)
button at the top of the Soundbar or the (Source) button
on the remote control to select the “Digital Audio In” mode.
• The recommended cable is High Speed HDMI Cable with Ethernet.
• When you use an optical cable and the terminals have covers, be
sure to remove the covers.
Using the Q-Symphony Function
For Q-Symphony, the Soundbar syncs with a Samsung TV to output
sound through two devices for optimum surround effect. When the
Soundbar is connected, the menu, “TV+Soundbar” appears under
the Sound Output menu of the TV.
• TV menu example: TV + S-Series Soundbar (HDMI / Wi-Fi)
NOTES
• It can operate according to the Codec supported by TV.
• This function is supported only when the HDMI Cable or Optical
Cable (not supplied) or Wi-Fi is connected.
• The message displayed may differ with the TV model.
• Ensure that your TV and Soundbar are connected to the same
wireless router/frequency.
• This function is available in some Samsung TVs and some
Soundbar models.
Using the SpaceFit Sound
Provides optimized sound quality by analyzing the listening spaces.
05 CONNECTING WIRELESSLY
Connecting a TV or Bluetooth Device via
Bluetooth
SOUND
MODE
WOOFER
TONE
CONTROL
CH LEVEL
OR
OR
When in “Bluetooth” mode
5 Sec
Red → Green → Blue Blinks
Cyan Blinks X3
Pairing
Connection is complete
“Ready to connect via Bluetooth.”
NOTE
• If asked for a PIN code when connecting a Bluetooth device,
enter <0000>.
Connecting via Wi-Fi (Wireless Network)
To connect a Soundbar to a mobile device via a wireless network
(Wi-Fi), the SmartThings app is required.
1. Connect your mobile device (smartphone, tablet, etc.) to the
Wi-Fi network the TV is connected to.
2. Install and launch the SmartThings app on your mobile device
(smartphone, tablet, etc.).
3. Follow the instructions in the app screen on the mobile device
to connect the Soundbar to your Wi-Fi network.
06 TROUBLESHOOTING
Refer to the instructions below if this product does not function
properly. If the problem you are experiencing is not listed below
or if the instructions below do not help, turn off the product,
disconnect the power cord, and contact Samsung Electronics at
1-800-SAMSUNG (1-800-726-7864).
Soundbar does not turn on.
• Check whether the power cord of the Soundbar is correctly inserted
into the outlet.
If the subwoofer does not connect automatically.
1. Turn off the Soundbar main.
2. Press and hold ID SET on the rear of the subwoofer for at least 5 seconds.
Rear of Subwoofer
5 sec
"Blinking blue fast"
3. Press the Up button on the remote control for 5 seconds.
SOUND
MODE
PAIR
5 sec
Red → Green → Blue Blinks
4. Check if the LINK LED is solid blue (connection complete).
• The LINK LED indicator stops blinking and glows a solid blue
when a connection is established between the Soundbar and the
Wireless Subwoofer.
Soundbar works erratically.
• After removing the power cord, insert it again.
• Try again after resetting the product.
• If there is no signal, the Soundbar automatically turns off after a
certain period of time. Turn on the power.
Remote control does not work.
• Point the remote directly at the Soundbar.
• Replace the batteries with new ones.
The red LED indicator light on the soundbar stays on.
• The microphone is turned off. Turn on the microphone.
LED Indicator
Red On
“Mic Off”
“Mic On”
The Soundbar does not output any sound.
• The volume of the Soundbar is too low or muted. Adjust the volume.
• When any external device (STB, Bluetooth device, mobile device,
etc.) is connected, adjust the volume of the external device.
• For sound output of the TV, select Soundbar.
(Samsung TV: Home ( ) → Menu → Settings ( ) → All Settings
( )→ Sound → Sound Output → Select Soundbar)
• Remove the cable from the Soundbar and then reconnect it.
Sound is not output from the subwoofer.
• Check whether the LED on the rear of the Subwoofer and Surround
Speakers lights in blue. Reconnect it when the blue LED blinks or the
red LED lights.
If the TV is not connected via HDMI (ARC).
• Check whether the HDMI cable is correctly connected to the ARC
terminal.
• Connection may not be possible due to the connected external
device (set-top box, game console, etc.). Directly connect the
Soundbar.
• HDMI-CEC may not be activated on the TV. Turn on the CEC on the TV
menu. (Samsung TV: Home ( ) → Menu → Settings ( ) →
All Settings ( ) → Connection → External Device Manager →
Anynet+ (HDMI-CEC) ON)
The Soundbar will not connect via Bluetooth.
• When connecting a new device, switch to Bluetooth Pairing for
connection. (Press the PAIR button on the remote control or press
the (Mic On/Off) button on the body for at least 5 seconds.)
• Reconnect it after removing the Bluetooth speaker list on the device
to connect. (Samsung TV: Home ( ) → Menu → Settings ( ) →
All Settings ( ) → Sound → Sound Output → Bluetooth Speaker
List)
The sound drops out when connected via Bluetooth.
• Some devices can cause radio interference if they are located too
close to the Soundbar. e. g. microwaves, wireless routers, etc.
• If your device that is connected via Bluetooth moves too far away
from the Soundbar, it may cause the sound to drop out. Move the
device closer to the Soundbar.
• If a part of your body is in contact with the Bluetooth transceiver or
the product is installed on metal furniture, the sound may drop out.
Check the installation environment and conditions for use.
Unable to connect to Wi-Fi.
• Make sure the wireless router is turned on and then reconnect the
wireless router after rebooting.
• The Soundbar will not connect if the wireless signal is too weak.
Try moving the router closer to the Soundbar, or eliminating any
obstacles that are between the Soundbar and the router, if possible.
The Soundbar does not turn on automatically with the TV.
• When you turn off the Soundbar while watching TV, power
synchronization with the TV is disabled. First turn off the TV.
07 LICENSE
Dolby, Dolby Atmos, and the double-D symbol are registered
trademarks of Dolby Laboratories Licensing Corporation.
Manufactured under license from Dolby Laboratories.
Condential unpublished works. Copyright © 2012-2021 Dolby
Laboratories. All rights reserved.
For DTS patents, see http://patents.dts.com. Manufactured under
license from DTS, Inc. (for companies headquartered in the U.S./Japan/
Taiwan) or under license from DTS Licensing Limited (for all other
companies). DTS, Digital Surround, Virtual:X, and the DTS logo are
registered trademarks or trademarks of DTS, Inc. in the United States
and other countries. © 2021 DTS, Inc. ALL RIGHTS RESERVED.
The terms HDMI, HDMI High-Denition Multimedia
Interface, HDMI Trade dress and the HDMI Logos are
trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
LIMITED WARRANTY TO ORIGINAL CONSUMER PURCHASER
WITH PROOF OF PURCHASE AND/OR PROOF OF DELIVERY
This SAMSUNG brand product, as supplied and distributed by SAMSUNG and delivered new, in the original carton to the original
consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited
warranty period of:
One (1) Year Parts and Labor*
(*90 Days Parts and Labor for Commercial Use)
This limited warranty begins on the date of delivery to the original consumer purchaser, and is valid only on products
purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for
problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized
service center. The original dated bill of sale and/or proof of delivery must be presented upon request to SAMSUNG or
SAMSUNG’S authorized service center. Transportation of the product to and from the service center is the responsibility
of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or
reconditioned parts or products if found to be defective during the limited warranty period speci ed above.
All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer.
SAMSUNG’s obligations with respect to software products distributed by SAMSUNG under the SAMSUNG brand
name are set forth in the applicable end user license agreement. Non-SAMSUNG hardware and software products,
if provided, are on an “AS IS” basis.
Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and
except to the extent otherwise expressly provided for in this statement, noncommercial use of this product, and
shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and
installation; applications and uses for which this product was not intended; altered product or serial numbers;
cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of
products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs,
external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product or result in
service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to
follow operating instructions, cleaning, maintenance and environmental instructions that are covered and
prescribed in the instruction book; product removal or reinstallation; reception problems and distortion related to
noise, echo, interference or other signal transmission and delivery problems. SAMSUNG does not warrant
uninterrupted or error-free operation of the product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO
WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY
PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR
CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE
LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS
PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST
SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND
CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND
LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND
THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG
NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO
ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR
EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you speci c legal rights, and
you may also have other rights which vary from state to state.
To obtain warranty service, please contact SAMSUNG customer care center.
The bene ts of this Limited Warranty extend only to the original purchaser of Samsung products from an authorized
Samsung reseller. THIS LIMITED WARRANTY SHALL NOT APPLY TO ANY SAMSUNG PRODUCTS PURCHASED
FROM UNAUTHORIZED RESELLERS OR RETAILERS, EXCEPT IN STATES WHERE SUCH RESTRICTION MAY BE
PROHIBITED. For a list of Samsung authorized retailers, please go to:
http://www.samsung.com/us/peaceofmind/authorized_resellers.html.
• Use your phone, tablet or computer as a remote control for Spotify.
Go to spotify.com/connect to learn how
• The Spotify Software is subject to third party licenses found here :
https://www.spotify.com/connect/third-party-licenses.
• Apple, Airplay, iPhone, iPad, and Mac are trademarks of Apple Inc.,
registered in the U.S. and other countries.
• Use of the Works with Apple badge means that an accessory has
been designed to work specically with the technology identied
in the badge and has been certied by the developer to meet Apple
performance standards.
[ENERGY STAR]
ENERGY STAR qualied model only
– Your Samsung product is ENERGY STAR qualied in its factory default
setting. Change to certain features, settings and functionality in this
product can change the power consumption, possibly beyond the limits
required for ENERGY STAR qualication.
– Environmental Protection Agency and Department of Energy. ENERGY
STAR is a joint program of the Government agencies, designed to promote
energy efcient products and practices.
Refer to www.energystar.gov for more information of the ENERGY STAR Program.
ENERGY STAR qualied model only
(Applicable to Thin Client models only)
As an ENERGY STAR® Partner, SAMSUNG has determined that this product
meets the ENERGY STAR® guidelines for energy efciency.
– The ENERGY STAR Program has been to reduced greenhouse gas
emissions and save energy through voluntary labeling.
– Power management setting of this product have been enabled by default,
and have various timing setting from 1 minutes to 5 hours.
– The product can wake with a button press on the chassis from sleep mode.
ENERGY STAR qualied model only (The other models)
– As an ENERGY STAR Partner, Samsung has determined that this product or
product models meets the ENERGY STAR guideline for energy efciency.
To send inquiries and requests for questions regarding open sources,
contact Samsung Open Source (http://opensource.samsung.com)
08 IMPORTANT NOTES
ABOUT SERVICE
• Figures and illustrations in this User Manual are provided for reference only
and may differ from actual product appearance.
• An administration fee may be charged if either:
a. An engineer is called out to your home at your request and there is no
defect in the product.
b. You bring the unit to a repair center and there is no defect in the product.
• You will be advised of the amount of the administration fee before any work
is done or a home visit is made.
• If you have a problem with this product, we strongly recommend you read
the appropriate section of this manual, visit the Support page for your
product at www.samsung.com, or call Samsung Product Support (1-800-
726-7864) to nd an answer before you contact a service center for a repair.
09 SPECIFICATIONS AND GUIDE
Specications
Model Name
HW-S68CB
Weight
6.0 lbs (2.7 kg)
Dimensions (W x H x D)
26.4 x 2.4 x 4.1 inches
(670.0 x 62.0 x 105.0 mm)
Operating Temperature Range
+41°F to +95°F (+5°C to +35°C)
Operating Humidity Range
10 % ~ 75 %
AMPLIFIER
Rated Output power
(30W x 2) + (30W x 2) + (30W x 2) + 20W
Supported play formats
Dolby 5.1ch / Dolby Digital Plus /
Dolby ATMOS (Dolby Digital Plus) /
DTS 5.1ch / LPCM 2ch
Subwoofer Name
PS-WC74B
Weight
13.0 lbs (5.9 kg)
Dimensions (W x H x D)
8.1 x 13.9 x 11.9 inches
(205.0 x 353.0 x 302.0 mm)
AMPLIFIER
Rated Output power
120W
NOTES
• Samsung Electronics Co., Ltd reserves the right to change the
specications without notice.
• Weight and dimensions are approximate.
Precaution : The Soundbar will restart automatically
if you turn on/turn off Wi-Fi.
Wi-Fi
Port deactivation method
Press the CH LEVEL button on the remote control of the
Soundbar for 30 seconds to turn Wi-Fi On / Off.
Bluetooth
Port deactivation method
Press the TONE CONTROL button on the remote control of the
Soundbar for 30 seconds to turn Bluetooth On / Off.
