Includes (1) 1.2V AA 800mAH Ni-MH rechargeable battery
LED
REF.
PARTS NAME
A
Solar Panel Unit
B
Glass Lens
C
Connection Tube
D
Ground Stake
1
Includes (1) white LED. The lifetime for LEDs is estimated to be 100,000 hours.
PACKAGE CONTENTS
Read all instructions before assembly. Failure to do so may result in faulty assembly and
potential injury.
FUNCTION: The built-in solar panels convert sunlight into electricity. The rechargeable battery stores the energy and converts
the power into light for use during the night. The lighting hours of the solar light depends on the geographical location and
weather condition. Stronger or longer exposure to sunlight enables the battery to s
tore more energy and provide longer lighting
hours.
LOCATION: It is important to select an outdoor location with full, direct sunlight where the solar panel can receive at least 8
hours of sunlight each day. Shady areas will not enable batteries to be fully charged. This will reduce the lighting hours at
night. It is also important to avoid placing the solar light by light sources, such as street lights or porch lights, which may cause
the solar light to turn off automatically. The solar light is designated for
outdoor usage and ideal for night lighting of garden,
paths, etc.
CLEANING AND MAINTENANCE: Please use a damp cloth to clean the solar panel. Do not use any chemical or abrasive
cleaner. It is important to ensure that no moisture enters into the solar light. Replacement parts may be ordered by using the
fixture model number and part's name; call the phone number located at the top and bottom of this instruction manual.
RECHARGEABLE BATTERY: This product contains (1) 1.2V AA 800mAH Ni-MH rechargeable batte
ry. When the battery
expires, it must be recycled or disposed of properly. Please contact your local waste disposal authority for correct procedure.
Do not put battery into fire.
Sku Number: 343-6126
ASBURY 4PK SOLAR PATH Light
Model Number: ELJ6671G
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at
855-232-6423
Monday – Friday 8:00 a.m. – 8:00 p.m. (EST)
ASSEMBLY (Figure 1) Figure 1
OPERATIONAL INSTRUCTIONS (Figure 2)
Figure 2
CHANGING BATTERIES (Figure 2 & 3)
Figure 3
The light does not come on at night:
2
· Never push the fixture into the ground by the fixture head.
· Before attaching the Solar Panel Unit (Part A) to the Glass Lens (Part B), pull out the isolated
tag which is on the bottom of the Solar Panel Unit (Part A). After assembling, take the light to
direct sunshine that allows the rechargeable battery to reach its maximum capacity. Ensure the
light is in full sunlight for 8 hours. The unit will then automatically light up at dusk.
Note: Lights with crystalline panels may have a protec
tive film over the solar panel.
This must be removed prior to use.
· Twist the Glass Lens (Part B) counter clockwise and remove it from the Solar Panel Unit (PartA).
See Figure 3.
· Replace the old battery with new battery. Make sure the polarity is correct.
· Reposition the battery cover tightly.
· Open the battery chamber cover on the bottom of Solar Panel Unit (Part A). Figure 2.
TROUBLESHOOTING
ASSEMBLY AND BATTERY REPLACEMENT INSTRUCTIONS
· Place the assembled light on top of the ground stake (Part D).
· Gently remove all parts from the package and lay them out on a smooth surface.
· Attach the Glass Lens (Part B) to the Solar Panel Unit (Part A) by twisting.
· Insert the Glass Lens (Part B) into the Connection Tube (Part C).
CAUTION: In compacted, clay, or hard soils, moisten the ground with water before
inserting the stake into the ground to avoid breakage.
· Choose the ground area where you would like the light and insert the stake (Part D) firmly into
the ground.
Lighting hours are short:
Always
keep the solar light distant from other night light sources, such as exterior lights. Reposition the light to avoid close
contact with other night light sources.
Make sure solar panel is clean and free of dirt and debris. If needed use a damp cloth to clean the solar panel. Do not use
any chemical or abrasive cleaner. It is important to ensure that no moisture enters into the solar light.
Check the location of the solar light. Make sure it is in a sunny area, and the battery can be fully charged during
day time.
Check the rechargeable battery and make sure that it is in contact with the metal plate and the polarity is correct. If the
battery is worn out, replace the battery with a 1.2V AA 800 mAH Ni-MH rechargeable battery.
Make sure the isolated tag was pulled out.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at
855-232-6423
Monday – Friday 8:00 a.m. – 8:00 p.m. (EST)
