PACKAGE CONTENTS
Includes (1) 1.2V AA 800mAH Ni-MH rechargeable battery
LED
Includes (1) warm white LED. The lifetime for LEDs is estimated to be 100,000 hours.
REF.
PARTS NAME
A
Solar Panel Unit
B
Shepherd Hook
C
Connection Tube
D
Ground Stake
Read all instructions before assembly. Failure to do so may result in faulty assembly and
potential injury.
FUNCTION:
The built-in solar panels convert sunlight into electricity. The rechargeable battery stores the energy and converts
the power into light for use during the night. The lighting hours of the solar light depends on the geographical location and
weather condition. Stronger or longer exposure to sunlight enables the battery to store more energy and provide longer lighting
hours.
LOCATION: It is important to select an outdoor location with full, direct sunlight where the solar panel can receive at least 8
hours of sunlight each day. Shady areas will not enable batteries to be fully charged. This will reduce the lighting hours at night.
It is also important to avoid placing the solar light by light sources, such as street lights or porch lights, which may cause the solar
light to turn off automatically. The solar light is designated for outdoor usage and ideal for night lighting of garden, paths, etc.
CLEANING AND MAINTENANCE: Please use a damp cloth to clean the solar panel. Do not use any chemical or abrasive
cleaner. It is important to ensure that no moisture enters into the solar light. Replacement parts may be ordered by using the
fixture model number and part's name; call the phone number located at the top and bottom of this instruction manual.
RECHARGEABLE BATTERY: This product contains (1) 1.2V AA 800mAH Ni-MH rechargeable battery. When the battery
expires, it must be recycled or disposed of properly. Please contact your local waste disposal authority for correct procedure. Do
not put battery into fire.
Sku Number: 343-4449
LIGNITE HANGING LNTN 10L
Model Number: ELI0958G
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 855-232-6423
Monday – Friday 8:00 a.m. – 8:00 p.m. (EST)
A
B
C
D
ASSEMBLY AND BATTERY REPLACEMENT INSTRUCTIONS
ASSEMBLY (Figure 1) Figure 1
· Gently remove all parts from the package and lay them out on a smooth surface.
· Put Solar Panel Unit (Part A) and Connection Tube (Part C) together.
· Place the assembled light on top of the ground stake (Part D).
· Choose the ground area where you would like to place the light.
· The Solar Panel Unit (Part A) can be also used on the table or hang on a Sepherd hook (Part B).
· Never push the fixture into the ground by the fixture head.
CAUTION: In compacted, clay, or hard soils, moisten the ground with water before
inserting the stake into the ground to avoid breakage.
OPERATIONAL INSTRUCTIONS (Figure 2) Figure 2
·Before attaching the Solar Panel Unit (Part A) to the Connection tube (Part C), slide the switch
which is on the bottom of the Solar Panel Unit (Part A ) as shown in Figure 2.
· After assembling, take the light to direct sunshine that allows the rechargeable battery to reach its
maximum capacity. Ensure the light is in full sunlight for 8 hours. The unit will then automatically
light up at dusk.
Note: Lights with crystalline panels may have a protective film over the solar panel. This
must be removed prior to use.
CHANGING BATTERIES (Figure 2 & 3)
Figure 3
· Pull the Solar Panel Unit (Part A) and remove it from the Connection Tube (Part C).
· Use a screwdriver to screw out 3 screws on the middle of the Solar Panel Unit (Part A) and open
the battery chamber.
· Replace the old battery with new battery. Make sure the polarity is correct.
· Reposition the battery chamber tightly.
TROUBLESHOOTING
The light does not come on at night:
ü Make sure the switch is in the "ON" position.
ü Check the rechargeable battery and make sure that it is in contact with
the metal plate and the polarity is correct. If the
battery is worn out, replace the battery with a 1.2V AA 800mAH Ni-MH rechargeable battery.
ü Always keep the solar light distant from other night light sources, such as exterior lights. Reposition the light to avoid close
contact with other night light sources.
ü Make sure solar panel is clean and free of dirt and debris. If needed use a damp cloth to clean the solar panel. Do not use
any chemical or abrasive cleaner. It is important to ensure that no moisture enters into the solar light.
Lighting hours are short:
ü Check the location of the solar light. Make sure it is in a sunny area, and the battery can be fully charged during day time.
