DLA-NZ900 Projection Distance
Screen
Size
Diagonal
(inch)
Projection Distance (inch)
17:9 Screen 16:9 Screen 2.35:1 Screen 2.40:1 Screen 4:3 Screen
Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end
60 65.5 135.1 69.1 142.2 73.1 150.3 73.3 150.8 85.2 174.7
70 77.0 158.2 81.1 166.4 85.8 175.8 86.1 176.4 100.0 204.3
80 88.5 181.2 93.1 190.6 98.5 201.4 98.8 202.1 114.7 234.0
90 99.9 204.2 105.2 214.8 111.2 227.0 111.6 227.7 129.5 263.6
100 111.4 227.3 117.2 239.0 123.9 252.5 124.3 253.3 144.2 293.2
110 122.8 250.3 129.3 263.3 136.7 278.1 137.1 279.0 158.9 322.9
120 134.3 273.4 141.3 287.5 149.4 303.7 149.9 304.6 173.7 352.5
130 145.8 296.4 153.4 311.7 162.1 329.2 162.6 330.3 188.4 382.1
140 157.2 319.4 165.4 335.9 174.8 354.8 175.4 355.9 203.2 411.8
150 168.7 342.5 177.5 360.1 187.5 380.3 188.1 381.6 217.9 441.4
160 180.1 365.5 189.5 384.3 200.2 405.9 200.9 407.2 232.6 471.0
170 191.6 388.5 201.5 408.5 212.9 431.5 213.6 432.8 247.4 500.7
180 203.1 411.6 213.6 432.8 225.7 457.0 226.4 458.5 262.1 530.3
190 214.5 434.6 225.6 457.0 238.4 482.6 239.1 484.1 276.8 559.9
200 226.0 457.6 237.7 481.2 251.1 508.1 251.9 509.8 291.6 589.6
210 237.4 480.7 249.7 505.4 263.8 533.7 264.7 535.4 306.3 619.2
220 248.9 503.7 261.8 529.6 276.5 559.3 277.4 561.1 321.1 648.8
230 260.3 526.8 273.8 553.8 289.2 584.8 290.2 586.7 335.8 678.5
240 271.8 549.8 285.9 578.0 301.9 610.4 302.9 612.3
250 283.3 572.8 297.9 602.2 314.7 636.0 315.7 638.0
260 294.7 595.9 309.9 626.5 327.4 661.5 328.4 663.6
270 306.2 618.9 322.0 650.7 340.1 687.1 341.2 689.3
280 317.6 641.9 334.0 674.9
290 329.1 665.0
300 340.6 688.0
Screen
Size
Diagonal
(inch)
Projection Distance (mm)
17:9 Screen 16:9 Screen 2.35:1 Screen 2.40:1 Screen 4:3 Screen
Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end Wide-end Tele-end
60 1.66 3.43 1.75 3.61 1.86 3.82 1.86 3.83 2.16 4.44
70 1.96 4.02 2.06 4.23 2.18 4.47 2.19 4.48 2.54 5.19
80 2.25 4.60 2.37 4.84 2.50 5.12 2.51 5.13 2.91 5.94
90 2.54 5.19 2.67 5.46 2.83 5.76 2.83 5.78 3.29 6.70
100 2.83 5.77 2.98 6.07 3.15 6.41 3.16 6.43 3.66 7.45
110 3.12 6.36 3.28 6.69 3.47 7.06 3.48 7.09 4.04 8.20
120 3.41 6.94 3.59 7.30 3.79 7.71 3.81 7.74 4.41 8.95
130 3.70 7.53 3.90 7.92 4.12 8.36 4.13 8.39 4.79 9.71
140 3.99 8.11 4.20 8.53 4.44 9.01 4.45 9.04 5.16 10.46
150 4.28 8.70 4.51 9.15 4.76 9.66 4.78 9.69 5.53 11.21
160 4.58 9.28 4.81 9.76 5.09 10.31 5.10 10.34 5.91 11.96
170 4.87 9.87 5.12 10.38 5.41 10.96 5.43 10.99 6.28 12.72
180 5.16 10.45 5.43 10.99 5.73 11.61 5.75 11.65 6.66 13.47
190 5.45 11.04 5.73 11.61 6.05 12.26 6.07 12.30 7.03 14.22
200 5.74 11.62 6.04 12.22 6.38 12.91 6.40 12.95 7.41 14.98
210 6.03 12.21 6.34 12.84 6.70 13.56 6.72 13.60 7.78 15.73
220 6.32 12.79 6.65 13.45 7.02 14.21 7.05 14.25 8.16 16.48
230 6.61 13.38 6.95 14.07 7.35 14.85 7.37 14.90 8.53 17.23
240 6.90 13.96 7.26 14.68 7.67 15.50 7.69 15.55
250 7.19 14.55 7.57 15.30 7.99 16.15 8.02 16.20
260 7.49 15.13 7.87 15.91 8.32 16.80 8.34 16.86
270 7.78 15.72 8.18 16.53 8.64 17.45 8.67 17.51
280 8.07 16.31 8.48 17.14
290 8.36 16.89
300 8.65 17.48
©JVCKENWOOD Corporation
