Motion Sensor
VERSION A0
User Manual
1
Operation Instruction
The other devices should support Zigbee 3.0
protocol. Detailed information is in accordance
with the final product.
Download DC Home app.
Pull out the battery insulation sheet
from the Motion Sensor.
Motion Sensor works intelligently with Renogy ONE to
communicate with other devices.
Renogy ONE
Add Device
Add Gateway
25%
A
Device
Device
Battery
RBT12400LFPL-...
Controller
Scene Community Me
RCC60RVRU
%
25
A
0 0
W
0
2
Add Motion Sensor to Renogy ONE.
On DC Home app, choose “Renogy ONE”, tap "+ > Add
Device" in the upper right corner of the interface. Long
press the reset button on Motion Sensor for 5s until the
LED indicator flashes red three times. This means
Motion Sensor has entered the pairing mode. Wait until
the pairing completes.
Prior to adding Motion Sensor to Renogy ONE, make
sure that Renogy ONE has been bound to DC Home
app. For details, see the User Manual of Renogy
ONE.
If adding Motion Sensor to Renogy ONE fails, move
the sensor closer to Renogy ONE and redo the
adding.
Product Introduction
Features
3
Specifications
Model
Battery model
SNZB-03
CR2450 (3V)
Wireless connection Zigbee (IEEE 802.15.4)
-10°C-40°C (14°F-104°F)
Working temperature
Working humidity
10-90%RH (non-condensing)
Material PC
Dimensions
40 x 35 x 28 mm
(1.57 x 1.38 x 1.10 in)
LED indicator
Reset button
SNZB-03 is a Zigbee low-energy motion sensor that can
detect the movement of objects in real time.
By connecting it with Renogy ONE, you can create a
smart scene to control other devices.
Low Energy Movement Detection Smart Scene
4
Connect multiple devices
concurrently to Renogy ONE
Power on Renogy ONE, set the sensor to pairing mode.
Choose Renogy ONE on DC Home app, tap "+ > Add
Device". Tap the sensor name to add it to Renogy ONE.
Renogy ONE
Add Device
Add Gateway
25%
A
Device
Device
Battery
RBT12400LFPL-...
Controller
Scene Community Me
RCC60RVRU
%
25
A
0 0
W
0
Add Devices
Found Devices
Motion Sensor
Door Sensor
Cancel Confirm
Zigbee Relay
Alternatively, you can long-press the sensor on DC
Home app to delete it from Renogy ONE.
Place the Motion Sensor on a table for use.
5
Delete Sensor from Renogy ONE
Installation Methods
To disconnect the sensor from Renogy ONE, long press
the reset button on the sensor for 5s until the LED
indicator flashes three times successfully.
Tear off the protective film of the 3M adhesive, and
stick the sensor to the target installation position.
FCC Warning
Changes or modifications not expressly approved by the
party responsible for compliance could avoid the user ’s
authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interface;
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with
minimum distance20cm between the radiator & your
body. This transmitter must not be co-located or
operating in conjunction with any other antenna or
transmitter.
FCC Radiation Exposure Statement:
6
Do not install Motion Sensor on a metal surface
because it affects the wireless communication
distance.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
Note:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
7
Shenzhen Sonoff Technologies Co., Ltd.
1001, BLDG8, Lianhua Industrial Park, Shenzhen,
GD, China
ZIP code: 518000
MADE IN CHINA
Disclaimer
Renogy makes no warranty as to the accuracy,
sufficiency, or suitability of information in the User
Manual because continuous product improvements
are going to be made.
Renogy assumes no responsibility or liability for
losses or damages, whether direct, indirect,
consequential, or incidental, which might arise out of
the use of information in the User Manual.
Renogy is not responsible or liable for the failures,
damages, or injuries resulting from repair attempted
by unqualified personnel or improper installation and
operation.
The illustrations in the User Manual are for
demonstration purposes only. Details may appear
slightly different depending on product revision and
market region.
Renogy reserves the right to change the information
in the User Manual without notice.
All trademarks are property of their respective
owners.
