Philips TAR4500/10 Clock Radio

User manual - Transcript

• Page 1: Register your product and get support at wwwphilipscomsupport User manual TAR4500 4000 Series Clock Radio
• Page 2 - English - : 1 Important 2 Safety 2 2 Your clock radio 3 Introduction 3 Whats in the box 3 Overview of the clock radio 4 3 Get started 5 Install batteries 5 Connect power 5 Turn onSwitch to standby 5 Adjust volume 5 Adjust display brightness 5 4 ClockAlarm setting 6 Setting the clock 6 Set alarm time 6 Activatedeactivate alarm timer 6 Snooze the alarm 6 Stop alarm sounds 6 Set sleep timer 6 5 Listen to FM radio 7 Tune to FM radio stations 7 Store FM radio stations automatically 7 Store FM radio stations manually 7 Select a preset radio station 7 6 Other features 8 Set daylight saving 8 USBtype C port for charging out 8 7 Product specications 8 8 Troubleshooting 9 9 Notice 9 Compliance 9 1EN Contents
• Page 3 - English - : 2 EN 1 Important Safety Read these instructions Heed all warnings Follow all instructions Do not block any ventilation openings Install in accordance with the manufacturers instructions Do not install near any heat sources such as radiators heat registers stoves or other apparatus including ampliers that produce heat Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles and the point where they exit from the clock radio Only use attachmentsaccessories specied by the manufacturer Unplug this apparatus during lightning storms or when unused for long periods of time Refer all servicing to qualied service personnel Servicing is required when the apparatus has been damaged in any way such as powersupply cord or plug is damaged liquid has been spilled or objects have fallen into the apparatus the apparatus has been exposed to rain or moisture does not operate normally or has been dropped Battery usage CAUTION To prevent battery leakage which may result in bodily injury property damage or damage to the clock radio Do not replace a battery with an incorrect type that can defeat a safeguard for example some lithium battery types Leaving a battery in an extremely high temperature surrounding or an extremely low air pressure environment may result in an explosion or leakage of ammable liquid or gas Install all batteries correctly and as marked on the unit Remove batteries if they are exhausted or if the remote control if included is not to be used for a long time Batteries contain chemical substances They should be disposed of properly If you suspect that a battery has been swallowed or placed inside any part of the body seek immediate medical attention When you change the batteries always keep all new and used batteries out of reach of children Ensure that the battery compartment is completely secure after you replace the battery If the battery compartment cannot be completely secured discontinue use of the product Keep out of reach of children and contact the manufacturer This clock radio shall not be exposed to dripping or splashing Do not place any sources of danger on the clock radio eg liquid lled objects lighted candles Where the plug of the Direct Plugin Adapter is used as the disconnect device the disconnect device shall remain readily operable Please use the product safely in an environment with temperature between 0C and 45 C Do not mix old and new batteries Do not mix alkaline standard carbonzinc or recharge able nicad nimh etc batteries CAUTION Danger of explosion if batteries are incorrectly replaced Replace only with the same or equivalent type Battery in extreme high or low temperatures during use storage or transportation and low air pressure at high altitude can pose safety hazards
• Page 4 - English - : TAR450010 3EN Your clock radio Congratulations on your purchase and welcome to Philips To fully benet from the support that Philips offers register your product at wwwphilipscomsupport Introduction With this clock radio you can listen to FM radio Whats in the box Check and identify the contents of your package Main unit Power adaptor Quick start guide Safey sheet Warranty set two alarms to ring at different times charge your mobile devices Wireless speaker Note Power adaptor quantity and plug type vary by regions Images illustrations and drawings shown on this user manual are for reference only actual product may vary in appearance
• Page 5 - English - : 4 EN Overview of the clock radio PRESET Store radio stations in memory Select a preset radio station SNOOZE BRIGHTNESS Snooze alarm Adjust display brightness SCAN Scan and store radio stations automatically ALR 1 Set alarm VOL Adjust volume HOUR TUN Set hour Tune to FM radio stations Select previous preset station VOL Adjust volume Display panel Display current status Set alarm ALR 2 DST SET Set time Set daylight saving Set minute Tune to FM radio stations Select next preset station MIN TUN SLEEP Set the sleep timer USBtype C charging out port Charge your mobile devices DC IN Connect to the supplied power adaptor FM Antenna Turn on or switch to standby
• Page 6 - English - : 5EN Adjust display brightness Press BRIGHTNESS to select different brightness levels or turn off the display screen High Medium Low Off Note Power adaptor quantity and plug type vary by regions Images illustrations and drawings shown on this user manual are for reference only actual product may vary in appearance Get started Always follow the instructions in this chapter in The batteries can only back up clock and alarm settings Connect the power adapter to the wall outlet sequence Install batteries Turn onSwitch to standby Caution Risk of product damage Make sure that the power voltage corresponds to the voltage printed on the back or underside of the clock radio Risk of electrical shock When you unplug the power cord always pull the plug from the socket Never pull the cord Connect power Caution Risk of explosion Keep the batteries away from heat sunshine or re Never discard batteries in re Batteries contain chemical substances so they should be disposed of properly Do not mix battery types eg alkaline with carbon zinc Only use batteries of the same type for the set Note The type plate is located at the bottom of the clock radio Open the battery compartment at the bottom of the unit Insert 2pcs AAA batteries not supplied with correct polarity as indicated then close the battery compartment Press to turn the unit on The radio switches to the FM source Press to switch the unit to Standby The time if set is displayed Adjust volume While listening press VOL VOL to adjust volume
• Page 7 - English - : 6 EN Set sleep timer This clock radio can switch to standby mode automatically after a preset period Press SLEEP to select a period in minutes The clock radio switches to standby mode automatically after the preset period To deactivate the sleep timer Press SLEEP until OFF off appears Setting clock Note You can only set time in standby mode In standby mode press SET to activate the clock setting mode the 24Hquot to blink Press TUN TUN to select lt12Hgt or lt24Hgt hour format then press SET to conrm the time will blink Press HOUR to set hour and press MIN to set minute then press SET to conrm The time is set ClockAlarm setting Note lf no button is pressed in approx 10 seconds the unit exits clock setting mode automatically Press and hold ALR 1 or ALR 2 for 3 seconds to activated the alarm setup mode the icon or and alarm time will blink Press HOUR to set hour and press MIN to set minute then press ALR 1 or ALR 2 to conrm the icon or and bUZ alarm source will blink Press TUN TUN to select alarm source buzzer or radio then press ALR 1 or ALR 2 to conrm If radio is selected as the alarm source the icon or and radio station preset number will blink p ress TUN TUN to select radio preset radio station then press ALR 1 or ALR 2 to conrm Set alarm time Note Make sure that you have set the clock correctly Tip The unit exits alarm setting mode when being idle for 10 seconds Alarm timeout is 60 minutes if no user action Press ALR 1 or ALR 2 to activate or deactivate the alarm timer If the alarm timer is activated the icon or will appear Activatedeactivate alarm timer If the alarm timer is deactivated the icon or will disappear When the alarm sounds press or corresponding ALR 1ALR 2 Stop alarm sounds the alarm stops but the alarm settings remain When the alarm sounds press SNOOZE The alarm snoozes and repeats ringing 10 minutes later The icon or will blink Snooze the alarm During alarm snooze time press SNOOZE to select another period in minutes to ringing gain 10 20 50 6030 40
• Page 8 - English - : 7EN Listen to FM radio Note Keep the clock radio away from other electronic devices to avoid radio interference For better reception fully extend and adjust the position of the FM antenna Tune to FM radio stations 1 Press to turn on the clock radio 2 Press and hold TUN TUN for 3 seconds The clock radio tunes to a station with strong reception automatically 3 Repeat Step 2 to tune to more radio stations To tune to a station manually Press TUN TUN to select a frequency Note The tuning grid of the clock radio is 50KHz the radio frequency on the display panel will increase 01MHz by pressing TUN TUN twice Tip To remove a prestored station store another station in its place Select a preset radio station In FM tuner mode press PRESET to select a preset number Store FM radio stations automatically Store FM radio stations manually In FM tuner mode press and hold SCAN for 3 seconds The unit stores all the available FM radio stations automatically and broadcasts the rst station Note You can store a maximum of 20 FM radio stations 1 In FM tuner mode tune to an FM radio station 2 Press and hold PRESET for 3 seconds to activate programming mode The preset number begins to blink 3 Press TUN TUN to select a number Press PRESET again to conrm 5 Repeat steps 1 to 4 to store more FM radio stations Option A 1 In FM tuner mode press PRESET 2 Press TUN TUN to select a preset radio station Option B Note After 3 seconds preset radio station will be conrm automatically
• Page 9 - English - : 8 EN Connect the standard size end of a USB cable not included to the USBtype C Port on back of the unit and connect the other end to the charging port on your device USBtype C port for charging out Other features If the daylight saving is ON add one hour in current time the DST will appear If the daylight saving is OFF reduce one hour in current time the DST will disappear Set daylight saving Press DST for 3 seconds to turn daylight saving function onoff Product specications Note Product information is subject to change without prior notice Output Power RMS 700mW 10 THD Max14W Tuner FM Amplier Tuning Range 875108 MHz Charging out Tuning Grid 50 KHz Sensitivity Mono 26 dB SN Ratio lt22 dBf Total Harmonic Distortion lt10 Signal to Noise Ratio gt50 dBA General information USBtype C charging port Power Supply 50V 30A 50V 20A Operation Power Consumption lt2 W Standby Power Consumption lt1 W Dimensions W x H x D 103x1035x103 mm Weight Main unit 345g
• Page 10 - English - : 9EN Troubleshooting Warning Never remove the casing of the product To keep the warranty valid never try to repair the device yourself If you encounter problems when using this device check the following points before requesting service If the problem remains unsolved go to the Philips webpage wwwphilipscomsupport When you contact Philips make sure that the device is nearby and the model number and serial number are available No power Make sure that the AC power plug of the unit is connected properly Make sure that there is power at the AC outlet No sound Adjust the volume No response from the unit Disconnect and reconnect the AC power plug then turn on the unit again Poor radio reception Keep the clock radio away from other electronic devices to avoid radio interference Fully extend and adjust the position of the antenna Alarm does not work Set the clockalarm correctly Clockalarm setting erased Power has been interrupted or the power plug has been disconnected Reset the clockalarm Replace the backup batteries This symbol means the product must not be discarded as household waste and should be delivered to an appropriate collection facility for recycling Follow local rules and never dispose of the product and rechargeable batteries with normal household waste Correct disposal of old products and rechargeable batteries helps prevent negative consequences for the environment and human health This symbol means that the product contains batteries covered by European Regulation EU 20231542 which cannot be disposed of with normal household waste Inform yourself about the the local separate collection system for electrical and electronic collection system for electrical and electronic products and batteries Follow local rules and never dispose of the product and batteries with normal household waste Correct disposal of old products and batteries helps prevent negative consequences for the environment and human health Any changes or modications made to this device that are not expressly approved by MMD Hong Kong Holding Limited may void the users authority to operate the product Hereby TP Vision Europe BV declares that the product is in compliance with the essential requirements and other relevant provisions of RED Directive 201453EU and UK Radio Equipment Regulations SI 2017 No 1206 You can nd the Declaration of Conformity on wwwphilipscomsupport This product complies with the radio interference requirements of the European Community This product is designed and manufactured with highquality materials and components which can be recycled and reused Notice Compliance
• Page 11 - English - : TAR450010UMV10 MMD Hong Kong Holding Limited All rights reserved Specications are subject to change without notice Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips NV and are used under license This product has been manufactured by and is sold under the responsibility of MMD Hong Kong Holding Limited or one of its affiliates and MMD Hong Kong Holding Limited is the warrantor in relation to this product
